Model Number:
RHM2573
Family Combination Microwave
User Guide
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
PLEASE RETAIN
FOR FUTURE REFERENCE
Page(s)
Safety instructions
3-9
About your microwave
10-11
Product information
12
Unpacking the microwave
13
Product overview
14
Microwave
oven installation
15-16
Turntable
installation
17-18
Control
panel
19
How to use the microwave
20-33
Cooking tips
33
Cleaning the microwave
34
Problem solving
35-38
Guarantee &
customer services
39
Spare parts
40
Connection to the mains supply
41-42
Notes
43
Disposal information
44
CONTENTS
2
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
3
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
• If the door or door seals are damaged, the oven must not
be operated until it has been repaired by a competent
person.
• It is hazardous for anyone other than a competent person
to carry out any service or repair operation that involves
the removal of a cover which gives protection against
exposure to microwave energy.
• Liquids and other foods must not be heated in sealed
containers since they are liable to explode.
• The appliance and its accessible parts may become hot
during use. Care should be taken to avoid touching
heating elements.
• Do not leave the microwave oven unattended while you
are using it.
• Do not use the microwave when it is empty. This could
damage the oven.
• This appliance is intended to be used in the household
and general domestic applications. It is not intended to
be used in industrial or commercial applications.
4
SAFETY INSTRUCTIONS
WARNING:
• This microwave is intended for heating food and
beverages only. The drying of food or clothing and
heating of warming pads, wheat bags, slippers, sponges,
damp cloth and similar is extremely dangerous and may
lead to risk of injury, ignition or fire.
• Do not use metal pans, dishes with metal handles or
anything with a metal trim inside the microwave. Do not
use paper covered wire twist-ties on plastic bags.
• Never put objects into the openings on the outer case.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge,
only if they are being supervised or have been given
instruction in the safe use of the appliance and
understand the hazards involved. Children should not
play with the appliance.
• Food containing a mixture of fat and water (for example,
stock) should stand for 30 to 60 seconds in the oven
after it has been turned off. This is to allow the mixture
to settle and to prevent it from bubbling when a spoon is
placed in it, or a stock cube is added.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
5
SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
• When heating or cooking food or liquid, remember
that there are certain foods (such as, jam, Christmas
pudding, and mincemeat) which heat up very quickly.
• Microwave heating of beverages can result in delayed
eruptive boiling, therefore care must be taken when
handling the container.
• The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature must be
checked before consumption, in order to avoid burns.
Do not heat baby bottles with the teat left on.
Remove it if replacing the bottle back into the oven.
• Eggs in their shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended.
• Do not cook any food surrounded by a membrane, such
as egg yolks, potatoes, chicken livers, sausages,
ready meals and so on without piercing them several
times with a fork.
• Do not try to deep-fry foods in this microwave oven.
• Do not overcook food.
6
SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
• When heating food in plastic or paper containers, keep
an eye on the oven due to the possibility of ignition.
• If materials inside the oven smoke or catch fire, keep
the oven door closed to stifle the flames, turn the oven
off at the wall switch, or shut the power off at the fuse
or circuit-breaker panel. If smoke is emitted , switch off
or unplug the appliance and keep the door closed in
order to stifle any flames.
• Please remember that as food or liquids heat up,
they will release steam or may be spitting. Never cover
any containers fully, always leave a gap for steam to
escape.
• Do not use plastic containers when heating or cooking
foods that contain a lot of fat or sugar.
• Always have the glass tray and turntable support in
place when using the microwave oven.
• Do not cook food directly on the glass tray. Put food on
a suitable plate or in a bowl before putting it in the oven.
7
SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
• When using the grill rack and Healthy Fry, be aware that
these will become HOT during cooking as they aren’t
heatproof. Please use suitable oven gloves when
removing these.
• Do not use melamine dishes as they contain a
material which will absorb microwave energy. This may
cause the dishes to crack or burn, and will slow down
the cooking speed.
• Use only cookware and utensils that are approved to use
in a microwave oven.
• Do not use the microwave oven for heating utensils,
plates or dishes.
• Do not cook using a container with a restricted
opening, such as bottles, as they may explode.
• Before you clean your microwave oven, turn it off and
unplug it.
• Keep the inside of the oven clean. When food or
liquids stick to the oven walls, wipe with a damp
cloth. We recommend that you do not use harsh
detergent or abrasives.
8
SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
• On the right hand wall of the cavity is the wave
guide cover, microwaves are passed through this to
enable your food to cook. It is important that this
wave guide cover is kept clean at all times. To do
this wipe with mild detergent and water, then dry.
• The oven should be cleaned regularly and any food
deposits removed. Failure to maintain the oven in a
clean condition could lead to deterioration of the
surface that could adversely affect the life of the
appliance and possibly result in a hazardous situation.
• You should clean the outside of the oven with a
damp cloth. Do not allow water to seep into the
ventilation openings.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of
the glass.
• If steam builds up inside or around the outside of the
oven door, wipe with a soft cloth. This may happen
when the microwave oven is used in humid conditions.
9
SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
• Regularly remove the glass turntable to clean it, wash
it in warm soapy water or a dishwasher. Regularly
clean the turntable support and oven floor. Simply
wipe the bottom surface of the oven with mild
detergent and water, then dry. You can wash the
turntable support in mild soapy water.
• Failure to maintain the oven in a clean condition,
especially if liquid is left under the turntable, could lead
to deterioration of the surface that will adversely affect
the life of the appliance that may result in a
hazardous condition.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
ABOUT YOUR MICROWAVE
10
Thank you for purchasing your Russell Hobbs microwave oven.
This stylish large capacity 25 litre Russell Hobbs Microwave features a
modern and crisp design with microwave, grill and convection
functionality enabling you to cook a variety of dishes with just one
appliance.
Cooking meals for family and friends or reheating large plates of food
becomes simple and easy with 900 watts of microwave power and 10
auto cook menus.
The true fan assisted oven acts exactly the same as a conventional oven
which gives you the option of an extra cooking facility, for large dinner
parties and family gatherings.
The combination aspect enables you to combine microwave energy, a
grill, and convection heating (fan assisted) so you can heat, roast, crisp
and brown. Ideal for cooking lasagnes, pizzas, baked potatoes and
cottage pies.
The Healthy Fry tray and Healthy Fry auto cook menus, included with
the unit can produce healthy low fat crisp food in minutes with only a
touch of oil. Much healthier than deep frying!
This microwave has a 31.5cm wide removable glass turntable and a
stainless steel interior for easy cleaning. It also has weight and time
defrost settings, a child safety lock and a simple, functional control
panel, including clock and digital timer. It comes complete with a grill
rack and Healthy Fry tray, giving everything you need to use every
function of this combination microwave.
ABOUT YOUR MICROWAVE
How do microwaves work?
Microwaves are high-frequency electromagnetic waves similar to
radio waves. While radio waves may vary in length from one metre
to many kilometres, microwaves are very short (less than 12.5
centimetres.)
Microwaves do not make any heat themselves but cause water
molecules in the food to vibrate.
This vibration produces heat that cooks the food. This is why your
food will come out of the microwave piping hot, while your utensils
inside the oven stay much cooler. The microwaves do not stay in the
air or in the food when you open the microwave oven door.
The microwave oven will work using an ordinary household
electrical socket. Inside the microwave oven is the magnetron,
which turns the electrical energy into microwaves.
Microwaves cannot travel through metal, so the inside of the oven
is lined with metal. The door is lined with a fine metal mesh which
stops microwaves getting through. This means that when the
microwave oven door is shut, there is no possibility that the
microwaves can be released.
11
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
12
PRODUCT INFORMATION
Model number RHM2573
Rated Voltage 230-240V ~ 50Hz
Rated Output Power (Microwav
e)
850 - 900W
Rated Power (Grill) 1050 - 1100W
Rated Power (Convection) 2300 - 2500W
Argos article number 687/7433
Imported by:
Argos
Home Retail Group PLC
Milton Keynes
MK9 2NW
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
UNPACKING THE MICROWAVE
Before you use your microwave oven
1. Remove all the packaging. Do not remove the small piece of card
from the right hand side of the cavity wall (refer to the below
image). This is called a wave-guide cover which allows the
microwaves to pass through to cook the food.
Please ensure you keep this cover clean at all times by wiping it
with a damp cloth. Do not remove/place it in a dishwasher.
2. Check the oven after unpacking for any visual damage such as:
● A misaligned door
● Damage to the door
● Dents or holes in the door window and screen
● Dents in the inside
If you can see any damages do not use the oven, please contact
Product Care at www.productcare.co.uk or call 0345 209 7461.
This microwave oven weighs approximately 18.2Kg so you must put
it on a horizontal surface that is strong enough to support this
weight.
The oven must be placed away from high temperature and steam.
Do not put anything on the top of the microwave oven.
13
1. Safety interlock latches
2. Microwave window
3. Ventilation slots
4. Oven cavity
5. Turntable ring
6. Turntable coupling
7. Glass turntable
8. Waveguide cover
9. Control panel
14
PRODUCT OVERVIEW
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
1
2
3
4
5 6 7
8
9
Healthy Fry Tray Grill Rack
Grill Rack & Healthy Fry Tray to be used for grilling, convection & Healthy Fry
cooking only.
CAUTION: GRILL RACK AND HEALTH FRY TRAY WILL BE HOT AFTER COOKING.
PLEASE WEAR OVEN GLOVES
15
MICROWAVE OVEN INSTALLATION
• Place the oven as far away from radios and televisions as
possible. Using the oven may cause interference with the
reception.
• Plug the oven into a suitable 13 amp mains socket, make
sure the voltage is the same as on the rating label (do not use
extension cables or mains socket adaptors.)
• The microwave oven should be used freestanding only and must
not be built-in or used in a cabinet.
• Select a level surface that provides enough space for the outlet
vents.
16
MICROWAVE OVEN INSTALLATION
DO NOT obstruct
the ventilation
from the microwave
30cm
7.5cm
20cm
7.5cm
Min85cm
WARNING:
DO NOT install the oven over a cooker or other heat or steam
producing appliances as this will damage the microwave oven.
The minimum installation height is 85cm.
A minimum clearance of 7.5cm is required between the oven and
adjacent walls. Leave a minimum clearance of 30cm above the
oven.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
STEP 1) The turntable coupling should slot into the centre of microwave
STEP 2) T he turntable ring slots into the indents in the middle
STEP 3) The glass tray indents fit around the turntable coupling
17
TURNTABLE INSTALLATION
• Before first use, check that any securing tape and all packaging
has been removed from the glass tray and turntable ring
assembly.
• These parts must never be restricted from rotating.
• Never place the glass tray upside down.
• To assemble the turntable, follow the steps below in numerical
order.
18
TURNTABLE INSTALLATION
The glass tray, turntable ring, and turntable coupling assembly
must always be used during cooking (as shown below).
• Do not place the food directly onto the glass tray, always place
on or in a suitable microwaveable cookware.
Please check that crockery is microwave safe before using.
• If the glass tray or turntable ring assembly has been
damaged in any way, contact Product Care using the below:
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
19
CONTROL PANEL
SCREEN DISPLAY
Cooking time, power, action indicators, and
clock time are displayed.
FUNCTION DIAL
Turn this dial to select Microwave, Grill, Combination,
Convection, Defrost, Clock/Kitchen Timer and Auto
Cook Menu functions
Press this dial for Quick Start Cooking
HEALTHY FRY
Press this button for the Healthy Fry auto cook menus.
ECO
In standby mode, press this button to turn the display
off. Press any button to turn the display on again.
STOP/CANCEL
Press the Stop/Cancel button twice to clear
everything. Press and hold for 3 seconds to
enable/disable child lock.
PARAMETER DIAL
This dial is used to select and confirm the time, weight
and auto cook menus. To select the dials has to be
rotated and to confirm the dial has to be pressed.
Press this dial to confirm a setting and start cooking
20
HOW TO USE THE MICROWAVE
Turn on the power
Insert the plug into a suitable 13amp mains socket.
Note: Make sure the voltage is the same as on the rating label located on
the back of the microwave (do not use extension cables or mains socket
adaptors.). The microwave oven will flash and beep.
Setting the clock (24 hour)
When the microwave oven is turned on the buzzer will ring once.
1) Turn the “FUNCTION” dial to “CLOCK/KITCHEN TIMER” and “0m 00s” and
“Kitchen Timer” will be shown on the display.
2) Turn the “PARAMETER” dial and “00 00” and “Clock” will be shown on the
display.
3) Press the “PARAMETER” dial to confirm and start to input the time. The
hour figures will start to flash on the display.
4) Turn the “PARAMETER” dial to the required hour time (note this is a 24
hour clock so the input should be 0 - 23) and press the “PARAMETER” dial to
confirm. The minute figures will start to flash.
5) Turn the “PARAMETER” dial to the required minute time and press the
“PARAMETER” dial to confirm. The time is now set and will be shown on the
display.
Note:
During the process of clock setting, if you press the "STOP/CANCEL“ button,
the clock will return to the previous setting.
Using the Kitchen Countdown Timer
1) Turn the “FUNCTION” dial to “CLOCK/KITCHEN TIMER” and “0m 00s” and
“Kitchen Timer” will be shown on the display.
2) Press “PARAMETER” dial to confirm and start to input the time.
3) Turn the “PARAMETER” dial to the required time (note the kitchen timer
is in minutes and has a maximum setting of 95 minutes) and press the
“PARAMETER” dial to confirm. The Kitchen Timer will start to count down.
21
HOW TO USE THE MICROWAVE
Microwave cooking
Once you have correctly installed the unit, turned on the power and set the
clock, you are ready to start cooking.
Your microwave has 5 power levels, the lowest at 10%, then 30%, 50%, 80%,
up to 100% (or full power.)
Most recipes are cooked on full power – this should be indicated on the
packaging of microwavable food.
1. To select a power level, turn the “FUNCTION” dial to “Microwave” and
“P10” and “Microwave” will be shown on the display.
2. Turn the “PARAMETER” dial clockwise to select the microwave power.
"P10", "P8","P5", "P3","P1"will be displayed.
3. Press the “PARAMETER” dial to confirm.
4. Turn the “PARAMETER” dial to adjust the cooking time. The time setting
should be set between 0:05- 95:00.
5. Press “PARAMETER” dial to start the cooking process.
The maximum cooking time is 95 minutes. To add more time during cooking,
simply press the “FUNCTION” dial.
Do not operate the oven empty, this can cause irreparable damage.
Pausing cooking
If you want to pause the cooking to turn over or stir the contents, simply open
the door, then close again and press the “PARAMETER” dial to continue the
cycle.
If you wish to stop cooking with time left on the display, take out the
contents, close the door and press the “STOP/CANCEL” button once to clear.
Press power
button
Cooking power
Equivalent
power
rating
P10 100% 900W
P8 80% 720W
P5 50% 450W
P3 30% 270W
P1 10% 90W
22
HOW TO USE THE MICROWAVE
Grill cooking
Note:
This function is only recommended for browning food as it is not as powerful
as a household grill. The grill element should be preheated to ensure
optimum operation and cooking. The recommended preheat time is 10-15
minutes. To preheat simply run the microwave on grill setting using the steps
shown below for the desired preheat time.
A grill rack has been provided for use in the microwave when using the grill
function. This can be used on either side for grilling closer to or further away
from the element.
1. To select a the Grill function, turn the “FUNCTION” dial to “Grill” and “G”
and “Grill” will be shown on the display.
2. Turn the “PARAMETER” dial to adjust the cooking time. The time setting
should be between 0:05- 95:00.
3. Press “PARAMETER” dial to start the cooking process.
Note:
Half way through the grill time, the unit will sound twice to tell you to turn
the food over (if possible.) In order to achieve more even grilling, you should
turn the food over, close the door, and then press “PARAMETER” dial to
continue cooking. If the food is not turned, the oven will continue cooking
without interruption.
COMBINATION COOKING (MICROWAVE + GRILL + CONVECTION)
Combination cooking enables you to combine microwave energy, a grill
and convection heating (fanned hot air) so you can heat, roast, crisp and
brown.
Which function shall I use?
C-1 Method: Microwave & Convection.
This is for when you would heat food quickly in the microwave, but give an
oven/baked finish. For example, heating lasagne: the lasagne is cooked
quickly in the microwave, but partially cooked in convection mode.
C-2 Method: Microwave & Grill.
This is for when you would cook food quickly using the microwave
function, but want a crisp grilled result. For example, a jacket potato: the
potato is cooked using the microwave but grilled for a crisp skin, giving an
oven result.
C-3 Method: Grill & Convection.
You would use this method as you would use your household oven to cook
food, but also give a grilled finish. For example, Pizza: the convection mode
creates a crisp pizza, and grills cheese for a better result.
C-4 Method: Microwave, Grill & Convection.
This is for when you would heat food quickly in the microwave, but give an
oven/baked finish. For example, cottage pie: the cottage pie is cooked fast
in the microwave, but partially cooked in convection mode and grilled.
23
HOW TO USE THE MICROWAVE
24
COMBINATION COOKING (MICROWAVE + GRILL + CONVECTION)
Combination function/program table
For the various settings the cooking time is divided as below:
1. To select a the Combination function, turn the “FUNCTION” dial to
“Combi.” and “C-1” and “Combi” will be shown on the display.
2. Turn the “PARAMETER” dial to select the required combination method
C-1 to C-4. Press the “PARAMETER” dial to confirm your selected
combination method.
3. Turn the “PARAMETER” dial to adjust the cooking time. The time
setting should be between 0:05- 95:00.
4. Press “PARAMETER” dial to start the cooking process.
Microwave Grill Convection
C-1
900W 165
℃
48% 52%
C-2
900W 165
℃
48% 52%
C-3
200
℃
200
℃
50% 50%
C-4
900W 200
℃
200
℃
16% 42% 42%
HOW TO USE THE MICROWAVE
25
HOW TO USE THE MICROWAVE
Convection cooking (With preheating function)
The convection cooking allows you to cook food using the unit as a
traditional oven; the microwave function is not used. It is recommended
that you preheat the oven to the appropriate temperature before placing
the food in the oven.
1. To select a the Convection function, turn the “FUNCTION” dial to
“Convection” and “150°C” and “Convection” will be shown on the display.
2. Turn “PARAMETER” dial to select the desired convection function
temperature. Note: The temperature can be set between 150°C to 240°C, in
10 degree intervals.
3. Press the “PARAMETER” dial to confirm the chosen temperature.
4. Press the “PARAMETER” dial to start preheating. When the preheating
temperature is reached, the buzzer will sound twice to remind you to place
the food in the oven. The preheated temperature will display and flash.
Open the door and place the food in the microwave oven, then close the
door.
5. Turn “PARAMETER” dial to adjust the cooking time. The maximum time
available is 95 minutes.
6. Press the “PARAMETER” dial to commence cooking.
Note:
• The cooking time cannot be entered until the preheating temperature is
reached. Once the temperature is reached, the door must be opened to
input the cooking time.
• If the time is not entered after 5 minutes of reaching the temperature,
the oven will stop preheating. The buzzer will sound five times and turn
back to the waiting state.
26
HOW TO USE THE MICROWAVE
Convection cooking (Without preheating function)
The convection cooking allows you to cook food using the unit as a
traditional oven when the microwave function is not used. It is
recommended that you preheat the oven to the appropriate temperature
before placing the food in the oven. However if you want to start cooking
without preheating the oven please follow the below steps and be aware
that the cooking time of the food will have to be extended:
1. To select a the Convection function, turn the “FUNCTION” dial to
“Convection” and “150°C” and “Convection” will be shown on the display.
2. Turn “PARAMETER” dial to select the desired convection function
temperature. Note: The temperature can be set between 150°C to 240°C, in
10 degree intervals.
3. Press the “PARAMETER” dial to confirm the chosen temperature.
4. Turn “PARAMETER” dial to adjust the cooking time. The maximum time
available is 95 minutes.
5. Press the “PARAMETER” dial to commence cooking.
27
HOW TO USE THE MICROWAVE
Quick Start cooking
One of the quickest ways to start microwave cooking is by using the “+30SEC.”
function.
1. Press the “FUNCTION” dial to cook with 100% power level for 30 seconds.
Each press on the same dial increases the cooking time by 30 seconds. The
maximum cooking time is 95 minutes. Alternatively in standby model you can
turn the “PARAMETER” dial to choose your cooking time and cook with 100%
power level by pressing the “PARAMETER” dial.
2. During the microwave cooking process, press the “FUNCTION” dial to cook
with 100% power level for 30 seconds. Each press of the dial increases the
microwave cooking time by 30 seconds.
Note: This function does not work for defrost and auto menu cooking.
Defrosting by Weight
1. To select a the Defrost function, turn the “FUNCTION” dial to “Defrost” and
“d1” and “Defrost” will be shown on the display.
2. Press the “PARAMETER” dial to confirm “d1”, “000g” will be shown on the
display.
2. Turn the “PARAMETER” dial to select the weight of the food. At the same
time, “100g” will be shown on the display. The weight should be set between
100g - 2000g.
3. Press the “PARAMETER” dial to start defrosting.
Defrosting by Time
1. To select a the Defrost function, turn the “FUNCTION” dial to “Defrost” and
“d1” and “Defrost” will be shown on the display.
2. Turn the “Parameter” dial and the display will show “d2”. Press the
“PARAMETER” dial to confirm “d2” and ”00m 00s” will be shown on the display.
3. Turn the “PARAMETER” dial to select the cooking time. The maximum time is
95 minutes.
4. Press “PARAMETER” dial to start the defrosting process.
28
HOW TO USE THE MICROWAVE
Auto Menu
1. To select a the Auto Menu function, turn the “FUNCTION” dial to “Auto
Menu” and “A1” and “Auto Menu” will be shown on the display. There are
10 Auto Menus; "A1","A2","A3"...."A10" and an Auto Menu cooking guide is
on the following page.
2. Turn the “PARAMETER” dial to select the required Auto Menu.
3. Press the “PARAMETER” dial to confirm the menu you require.
4. Turn the “PARAMETER” dial to choose the weight of the food or the
quantity of food
5. Press “PARAMETER” to commence the cooking process.
Note: When you select “A8” for cake, please do not put the cake mix into the
oven immediately. Follow the pre-heating instructions ( refer to page 25) and
the oven will be pre-heated to 180 degrees.
After several minutes, the buzzer sounds twice to remind you to put the cake
into the oven. After putting the cake in the oven, please press “PARAMETER”
dial to start again.
29
HOW TO USE THE MICROWAVE
Display Weight (g) Power Setting
A1 – Auto Reheat
150g 150
100%
250g 250
350g 350
450g 450
600g 600
A2 - Potato
1 1 (approx. 230g)
100%2 2 (approx. 460g)
3 3 (approx. 690g)
A3 - Meat
150g 150
100%
300g 300
450g 450
600g 600
A4 - Vegetable
150g 150
100%350g 350
500g 500
A5 - Fish
150g 150
80%
250g 250
350g 350
450g 450
650g 650
A6 - Pasta
50g 50 (add 450ml of water)
80%100g 100 (add 800ml of water)
150g 150 (add 1200ml of water)
A7 - Soup
200g 200ml
100%400g 400ml
600g 600ml
A8 - Cake 475g 475 Pre-heat to 180°c
A9 - Pizza
200g 200
C-4300g 300
400g 400
A10 - Chicken
500g 500
C-4
750g 750
1000g 1000
1200g 1200
30
HOW TO USE THE MICROWAVE
Healthy Fry
The Healthy Fry (Teflon) tray and Healthy Fry Auto Cook Menus, included
with this model can produce healthy low fat crisp food in minutes with only a
touch of oil. Much healthier than deep frying! The Healthy Fry Auto Menus
use a combination of convection, grill and microwave energy.
Note:
• The Healthy Fry (Teflon) tray and grill rack that has been provided must
be used with the Healthy Fry Function Auto Menus.
• Food must be spread evenly on the Healthy Fry (Teflon) tray or the
desired results will not be obtained.
• If cooking a large quantity of vegetables or fries then you may need to
reselect the require auto menu for the second time
• Always check the food is cooked thoroughly and if required put the food
in on the same setting for a second time. Check the food at regular
intervals during the second cooking time.
• For the best results turn the food halfway through its cooking program.
1. Place the food that you want to be cooked on to the Healthy Fry (Teflon)
tray provided and place the tray on the grill rack . You must ensure the food
is evenly spread out or the desired results will not be obtained.
2. To select a the Healthy Fry function, press the “HEALTHY FRY” dial to and
“H-1” and “Healthy Fry” will be shown on the display. There are 9 Healthy
Fry Auto Menus; “H1",“H2",“H3"....“H9" and an Healthy Fry Auto Menu
cooking guide on the following page.
3. Turn the “PARAMETER” dial to select the required Healthy Fry Auto Menu.
4. Press the “PARAMETER” dial to start preheating. When the preheating
temperature is reached, the buzzer will sound twice to remind you to place
the food in the oven. The preheated temperature will display and flash. Open
the door and place the food in the microwave oven, then close the door.
5. Press the “PARAMETER” again and the cooking process will commence.
31
HOW TO USE THE MICROWAVE
Healthy Fry tray
& Grill Rack
Oil Temperature
Time
(approximately)
H1 – Frozen French
Fries*
Yes (low grill
rack setting)
N/A 210°c 20 mins
H2 – Frozen Potato
Croquettes
Yes (low grill
rack setting)
N/A 230°c 20 mins
H3 – Homemade &
Frozen Chips
Yes (low grill
rack setting)
Tablespoon
(
homemade
chips only)
230°c 25 mins
H4 – Frozen Onion
Rings
Yes (low grill
rack setting)
N/A 230°c 15 mins
H5 –
Frozen Chicken
Nuggets/Fish Fingers
Yes (low grill
rack setting)
N/A 230°c 15 mins
H6 – Escalope
Yes (low grill
rack setting)
Brush with oil
200°c 25 mins
H7
–
Prawns/Shrimps
Yes (low grill
rack setting)
N/A 200°c 15 mins
H8 – Vegetables
Yes (low grill
rack setting)
Brush with oil
230°c 10 mins
H9 – Spring Rolls
Yes (low grill
rack setting)
Brush with oil
200°c 15 mins
32
HOW TO USE THE MICROWAVE
ECO mode
In standby mode, press this button to turn the display off. Press any button
to turn the display on again.
Child lock function
The child lock function is ideal to stop children from altering cooking times if
unsupervised. No buttons will function in this mode.
To set the lock, in waiting state, press “STOP/CANCEL” for 3 seconds, there
will be a long ‘beep’ as the lock activates, and a key will illuminate on the
display.
The lock is now functional.
To cancel the lock, press “STOP/CANCEL” for 3 seconds, there will be a long
‘beep’ signalling that the lock is cancelled, and the lock symbol will
disappear.
General information
• The “PARAMETER” dial must be pressed again to continue cooking if the
door is opened during a cooking cycle.
• Once the cooking programme has been set, if the PARAMETER” dial is
not pressed within 5 minutes, the current time will display and the
setting will be cancelled. The buzzer will sound five times to remind you
when cooking is finished.
Utensil information
• Do not use metal pans or dishes with metal handles.
• Do not use anything with a metal trim.
• Do not use paper-covered wire twist-ties on plastic bags.
• Do not use melamine dishes as they contain a material which will absorb
microwave energy. This may cause the dishes to crack or burn, and will
slow down the cooking speed.
• Use only cookware that is approved to be used in a microwave oven.
• Do not cook using a container with a restricted opening, such as bottles,
as they may explode.
• Do not heat baby bottles with the teat left on. Remove before placing
the bottle back into the oven.
33
HOW TO USE THE MICROWAVE
• Only use thermometers that are approved for microwave ovens.
• Do not use the microwave oven for heating utensils.
Defrosting tips
Microwaves penetrate around 4cm into most food. To maximize defrosting
effectiveness follow the below guidelines.
1. For thick foods, turn regularly during operation in order to defrost evenly.
2. If food weighs over 500g, it is advised to turn at least 2 times.
3. Defrosted food should be consumed as soon as possible, it is not
advisable to put back into the fridge or freeze again.
Cooking tips - The following may affect cooking results:
Food arrangement
If possible, thicker bits of food should be placed around the outside of the
dish and the thinner parts toward the centre, spread out as evenly as
possible. Do not overlap food if possible as this could result in uneven
cooking results.
Cooking length
If you are unsure of the cooking time it is advisable to start with a short
cooking time and monitor cooking progress before adding further time.
Overcooking could lead to a risk of fire. Ensure food is cooked thoroughly
before consuming.
Cooking food evenly
Foods such as meat should be turned frequently to ensure more even
cooking results. If the food is liquid based, stir during the cooking time is
advisable.
Allow standing time
When the microwave has stopped cooking, leave the food to rest for an
adequate length of time to allow for cooking completion and cooling.
34
CLEANING THE MICROWAVE
• Before you clean the oven, turn it off and unplug it.
• Keep the inside of the oven clean. When food or liquids stick to the
oven walls, wipe with a damp cloth. We recommend that you do not
use harsh detergents or abrasives.
• On the right hand side wall of the cavity is the wave guide cover,
microwaves are passed through this to enable your food to cook. It is
important that this wave guide cover is kept clean at all times. To do
this wipe with mild detergent and water, then dry.
• You should clean the outside of the oven with a damp cloth. Do not
allow water to seep into the ventilation openings.
• Do not allow the control panel to become wet. Clean with a soft,
damp cloth. Do not use detergents, abrasives or spray-on cleaners
on the control panel.
• If steam builds up inside or around the outside of the oven door,
wipe with a soft cloth. This may happen when the microwave oven is
used in humid conditions.
• Regularly remove the glass turntable to clean it, and wash it in warm
soapy water. Regularly clean the turntable support and oven floor.
Simply wipe the bottom surface of the oven with mild detergent and
water, then dry. You can wash the turntable support in mild soapy
water.
• When removing the turntable support of the oven, make sure you
put it back properly.
• If the inside of the oven smells, put a cup of water with the juice and
skin of one lemon in a deep microwave bowl. Microwave it for three
minutes, wipe thoroughly and then dry with a soft cloth.
Problem Potential reason
Potential solution
If the
microwave
doesn’t work
1. Microwave is not
plugged in
Make sure that the plug is plugged in securely into the
mains and the switch is on. If it is not, remove the plug
from the socket, wait 10 seconds and plug it in again
securely.
2. Plug is not working
The plug socket that the microwave is plugged into may
have become faulty. Plug the microwave into another
known good plug socket, ensure that the socket is
turned on and check if the microwave now works.
3. The plug has a blown
fuse or the mains circuit
has a blown fuse/tripped
fuse
Check the plug for a blown circuit fuse or a tripped main
circuit breaker. If these seem to be working properly,
test the socket with another appliance.
4. Microwave has
developed a fault
Contact customer services to talk through the problem
to see if any solutions for the fault can be found. If not
and the product is within its warranty period, then the
microwave should be returned to the retailer where it
was purchased from for a replacement or refund.
If the
microwave
power will not
work
1. Door is not closed
Make sure the door is securely closed. Otherwise, the
microwave will not engage or operate.
2. The timer dial has not
been turned.
Start the microwave by turning the dial and pressing the
start button.
Not heating
Magnetron not working
The component that produces the microwaves is called
a magnetron, if food is not being heated or is 'luke'
warm then it is likely this component has developed a
fault.
If the microwave is within its warranty period, please
contact customer services for further advice or take the
microwave back to the retailer where it was purchased
from for a refund or replacement.
35
PROBLEM SOLVING
The microwave oven may cause interference to your radio, TV or similar
equipment. If this happens, you can stop the interference by moving the
radio, TV or equipment as far away from your microwave oven as possible.
WARNING: To reduce the risk of personal injury, always
unplug the microwave before performing maintenance
or trouble shooting checks.
36
PROBLEM SOLVING
Problem Potential reason Potential solution
Sparking
1. Burnt on food
debris
Spillages or splashes can burn and catch fire, all food that is
put into the microwave should be appropriately covered. All
spillages or splashes must be cleaned, and all areas of
microwave cleaned after each use.
Burnt on food debris in the microwave, on the wave guide
and the behind the wave guide can cause the microwave to
'spark'. This is because burnt on debris can be focused on by
the microwaves and spark.
Microwaves must be cleaned thoroughly after every use to
ensure no food is burnt on to any part of the microwave.
If the microwave does 'spark' the wave guide must be
disposed, the microwave must be cleaned thoroughly and
then contact customer services for a replacement wave
guide.
The replacement wave guide should be fitted and the
microwave should operate normally. However, if the
microwave 'sparks' again on first use (after the waveguide has
been replaced and the microwave been cleaned,) please
contact customer services for further advice.
2. Metal or foil
No metal or foil should be put inside a microwave as it can
cause 'sparking' which can damage the microwave.
The only metal accessories that should be used inside the
microwave are the ones supplied by the manufacturer.
3. Pressure build up in
food
Food with none porous skins (potatoes for example), must be
pierced to allow steam to escape. As the
buildup
of pressure
can cause food to burst and create a 'fire hazard‘.
Heat spots
Operated empty or
with no moisture
Microwaves cannot be run empty.
M
icrowaves need moisture
to operate correctly.
If microwaves are operated empty or used to heat up plates
(this is not permitted), the microwaves can focus on a single
point inside the microwave. This can cause a heat spot, which
can cause the area to become deformed, warped or start to
melt.
If microwaves are operated empty or to heat up foreign
objects, this will void the warranty.
37
PROBLEM SOLVING
Problem Potential reason
Potential solution
Condensation
or excess
water
1. Food that is being
cooked
By the very nature of how a microwave works, it ‘excites’ the
water molecules in the food it is heating, causing them to
move about and generate heat from within the food. Often
when the food heats up it reaches the point where steam is
released. Dependant on the food type being heated (and its
water content level), the length of time being heated for –
and so the amount of steam generated
–
it is inevitable that
some of the steam will condense and form back into water
droplets within the microwave cavity. This can usually be
found on the inner walls or most commonly on the back of
the glass door. If not cleaned up, these droplets can start to
form small ‘pools’ of water.
2. Cooling vents covered
Cooling vents allow the heat and steam to escape from the
microwave. These cannot be covered as it can cause
excessive water to settle inside the microwave or the
microwave to overheat.
The installation instructions in the instruction manual must be
followed or the warranty will be void.
Paint damage/
peeling
Maintenance
If the microwave is within its warranty period, please contact
customer services for further advice or take the microwave
back to the retailer where it was purchased from for a refund
or replacement
Light not
working
Bulb not working
Due to the construction of microwaves and certain
'dangerous' components inside, the light bulb can only be
changed by a qualified service engineer.
If the microwave is within its warranty period, please contact
customer services for further advice or take the microwave
back to the retailer where it was purchased from for a refund
or replacement
Over heating
Cooling vents covered
Cooling vents allow the heat and steam to escape from the
microwave. These cannot be covered as it can cause
excessive water to settle inside the microwave or the
microwave to overheat.
The installation instructions in the manual must be followed
or the warranty will be void.
Too noisy
1. Glass turntable fitted
incorrectly
Check if the glass turntable has been placed correctly on the
turntable and is not hitting the walls/doors of the microwave
during operation.
2. Dishes/plate are too
large for the microwave
Check if the dishes/plates are the correct size for the
microwave and that are not hitting the walls/door of
microwave during operation.
38
PROBLEM SOLVING
Problem Potential reason
Potential solution
Door not
shutting/
locking
1. Glass turntable fitted
incorrectly
Check if the glass turntable has been placed correctly on the
turntable and is not stopping the door from shutting
correctly.
2. Latches have become
deformed
If the microwave is within its warranty period, please
contact customer services for further advice or take the
microwave back to the retailer where it was purchased from
for a refund or replacement.
Turntable not
rotating
1. Turntable coupling
not fitted or tape not
removed
Check if the turntable coupling is fitted correctly and the
transportation tape has been removed.
2. Turntable roller ring
not fitted or fitted
incorrectly
Check if the coupling has be placed under the turntable and
that it is positioned correctly.
3. Glass turntable fitted
incorrectly
Check if the glass turntable has been placed correctly on the
turntable.
4. Turntable has
developed a fault
If the microwave is within its warranty period, please
contact customer services for further advice or take the
microwave back to the retailer where it was purchased from
for a refund or replacement.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
39
GUARANTEE & CUSTOMER SERVICES
At Russell Hobbs, we take all our customer feedback seriously.
Feel free to contact our Product Care Team, on 0345 209 7461
Monday – Friday: 8am-8pm & Saturday: 9am – 1pm,
who will be more than happy to assist you.
This product is guaranteed for 12 months from the date of the
original purchase. If any defect arises due to faulty materials or
workmanship, the faulty product must be returned to the place of
purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with the original
proof of purchase.
• The product must be installed and used in accordance with the
instructions contained in this instruction guide and any other
instructions for use which are supplied.
• It must be used for domestic purposes only and for its intended
use.
• This warranty does not cover wear and tear, damage, misuse
or consumable parts.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
40
SPARE PARTS
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
To check the availability of the following spare parts, simply contact
our friendly Customer Services team using the details provided at the
bottom of this page.
Glass turntable
Turntable Ring
Wave Guide cover
Turntable coupling
Grill rack
Healthy Fry tray
41
CONNECTION TO THE MAINS SUPPLY
WARNING- THIS APPLIANCE MUST BE EARTHED
This appliance is designed to operate from a mains supply of
230-240V~ 50Hz.
Check that the voltage marked on the product corresponds
with your supply voltage.
This product is fitted with a 13A plug complying with BS1363.
If this plug is unsuitable or needs to be replaced, refer to customer
services.
Important: The wires in the mains lead are coloured in
accordance with the following code:
GREEN/YELLOW – EARTH
BLUE - NEUTRAL
BROWN – LIVE
42
CONNECTION TO THE MAINS SUPPLY
For UK use only – PLUG
• As the colours of the wires in the mains lead of this appliance may
not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
• The GREEN/YELLOW wire is the EARTH and must be connected to
the terminal which is marked with the letter E or by the earth
symbol or coloured GREEN or GREEN/YELLOW.
• The BLUE wire is the NEUTRAL and must be connected to the
terminal marked with the letter N or coloured BLACK.
• The BROWN wire is the LIVE wire and must be connected to the
terminal marked with the letter L or coloured RED.
• Always ensure that the plug cord grip is fastened correctly.
• If a 13A (BS1363) fused plug is used it must be fitted with a 13amp
fuse conforming to BS1362 and be BSI or ASTA approved.
If the fuse cover is lost the plug must not be used until a replacement
is obtained from an electrical supplier.
If you need to remove the plug, cut it from the mains lead and
dispose of it. NEVER attempt to re-use this plug or insert it into a
socket outlet, as there is a very great risk of electrical shock.
43
NOTES
44
Revision 2
This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is
marked on a product/batteries, it means that the product/batteries should not be
disposed of with your general household waste. Only discard
electrical/electronic/battery items in separate collection schemes, which cater for the
recovery and recycling of materials contained within. Your co-operation is vital to ensure
the success of these schemes and for the protection of the environment. For your
nearest disposal facility, visit www.recycle-more.co.uk or ask in store for details.
We reserve the right, due to possible changes to design, to alter the instruction manual
without prior notice.
For Customer Services & Spare
Parts please call
0345 209 7461
Opening times: Monday - Friday
8am – 8pm & Saturday 9am –1pm
Or visit us at
www.productcare.co.uk
