Operating Instructions
Microwave Oven
Household Use Only
Model No.
NN-ST975S
NN-ST785S
NN-ST775S
NN-ST765S
1200 W
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING THIS
PRODUCT, AND SAVE THIS MANUAL FOR FUTURE USE.
Inverser le manuel pour lire les instructions en français.
Panasonic Canada Inc.
5770 Ambler Drive
Mississauga, Ontario
L4W 2T3
Tel: (905) 624-5010
www.panasonic.com
F0003BP83CP
PA0215-31217
Printed in China
© Panasonic Appliances Microwave Oven (Shanghai) Co., Ltd. 2015
F0003BP83CP_En.indd 1 2017/12/20 9:23:06
Table of Contents
Safety Information
Microwave Oven Safety ...................................................................................... 1
Important Safety Instructions .......................................................................... 2-5
Installation and Grounding Instructions ........................................................5-6
Safety Precautions ........................................................................................... 7-8
Operation
Control Panel ....................................................................................................... 12
Starting to Use Your Oven ................................................................................... 13
Setting the Clock .................................................................................................13
Child Safety Lock................................................................................................. 13
Function Features................................................................................................ 14
Selecting Power & Cook Time ............................................................................. 15
3-Stage Cooking .................................................................................................. 15
Keep Warm Feature ............................................................................................ 16
Quick 30 Feature ................................................................................................. 16
Coffee/Milk Feature ............................................................................................. 16
Popcorn Feature .................................................................................................. 17
More/Less Feature ..............................................................................................17
Inverter Turbo Defrost Feature ............................................................................ 18
Defrosting Tips & Techniques .........................................................................18-19
Sensor Reheat Feature ....................................................................................... 20
Sensor Cook Feature ..........................................................................................20
Sensor Cook Chart .............................................................................................. 21
Microwave Recipes .............................................................................................22
Timer Feature (Kitchen Timer/Stand Time/Delay Start) ....................................... 23
Microwave Shortcuts ...................................................................................... 24-25
Food Characteristics............................................................................................ 26
Cooking Techniques .......................................................................................26-27
Quick Guide to Operation .................................................................................... 30
Maintenance
General Information
Care and Cleaning of Your Microwave Oven....................................................... 10
Before Requesting Service .................................................................................. 28
Warranty .............................................................................................................. 29
Cookware Guide .................................................................................................... 9
Oven Components Diagram ................................................................................ 11
Specifications ......................................................................................................31
User's Record ...................................................................................................... 32
F0003BP83CP_En.indd 2 2017/12/20 9:23:06
1
DANGER
WARNING
CAUTION
Microwave Oven Safety
Your safety and the safety of others are very important.
We have provided important safety messages in this manual and on your
appliance. Always read and obey all safety messages.
This is the safety alert symbol. It is used to alert you to poten-
tial hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and
either the word “DANGER”, “WARNING” or “CAUTION”. These
words mean:
You can be killed or seriously injured if
you don’t immediately follow instructions.
You can be killed or seriously injured if
you don’t follow instructions.
CAUTION indicates a potentially haz-
ardous situation which, if not avoided,
may result in minor or moderate injury.
All safety messages will tell you what the potential hazard is, tell you how to
reduce the chance of injury, and tell you what can happen if the instructions
are not followed.
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
1. Do not attempt to operate this oven with the door open since open-
door operation can result in harmful exposure to microwave energy. It is
important not to defeat or tamper with the safety interlocks.
2. Do not place any object between the oven front face and the door or
allow soil or cleaner residue to accumulate on sealing surfaces.
3. Do not operate the oven if it is damaged. It is particularly important that
the oven door close properly and that there is no damage to the:
(1) door (bent),
(2) hinges and latches (broken or loosened),
(3) door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by anyone except properly
qualified service personnel.
F0003BP83CP_En.indd 1 2017/12/20 9:23:06
2
WARNING
—To reduce the risk of burns, electric
shock, fire, injury to persons, or exposure to excessive microwave
energy:
Thank you for purchasing a Panasonic Microwave Oven.
Your microwave oven is a cooking appliance and you should use as much care
as you use with a stove or any other cooking appliance. When using electric
appliance, basic safety precautions should be followed, including the following:
IMPORTANT SAFETY INSTRUCTIONS
1. Read all instructions before using this appliance.
2. Read and follow the specific “PRECAUTIONS TO AVOID POSSIBLE EXPO-
SURE TO EXCESSIVE MICROWAVE ENERGY,” found on page 1.
3. This appliance must be grounded. Connect only to a properly grounded outlet.
See “GROUNDING INSTRUCTIONS” found on page 6.
4. As with any cooking appliance, DO NOT leave oven unattended while in use.
5. Install or locate this appliance only in accordance with the installation instruc-
tions found on page 5, 6.
6. DO NOT cover or block any openings on this appliance.
7. DO NOT store this appliance outdoors. DO NOT use this product near
water — for example, near a kitchen sink, in a wet basement, or near a
swimming pool or similar locations.
8. Use this appliance only for its intended use as described in this manual. DO
NOT use corrosive chemicals, vapors or non-food products in this appliance.
This type of oven is specifically designed to heat, or cook food.It is not
designed for industrial or laboratory use. The use of corrosive chemicals in
heating or cleaning will damage the appliance and may result in radiation
leaks.
9. When cleaning surfaces of the door and oven that come together upon closing
the door, use only mild, non-abrasive soaps or detergents applied with a
sponge or soft cloth.
10. DO NOT allow children to use this appliance, unless closely supervised by an
adult. DO NOT assume that because a child has mastered one cooking skill
he/she can cook everything.
11. DO NOT operate this appliance if it has a damaged cord or plug, if it is not
working properly, or if it has been damaged or dropped.
12. DO NOT immerse cord or plug in water.
13. Keep cord away from heated surfaces.
14. DO NOT let cord hang over edge of a table or counter.
15. This appliance should be serviced only by qualified service personnel.
Contact the nearest authorized service center for examination, repair or
adjustment.
F0003BP83CP_En.indd 2 2017/12/20 9:23:06
3
IMPORTANT SAFETY INSTRUCTIONS
(continued)
16. Some products such as whole eggs with or without shell, narrow neck bottles
and sealed containers — for example, closed glass jars — may explode and
should not be heated in this oven.
17. To reduce the risk of fire in the oven cavity:
(a) DO NOT overcook food. Carefully attend appliance when paper, plastic,
or other combustible materials are placed inside the oven to facilitate
cooking.
(b) Remove wire twist-ties from paper or plastic bags before placing bag in
oven.
(c) If material inside the oven ignites, keep oven door closed, turn oven
off, and disconnect the power cord, or shut off power at the fuse or
circuit breaker panel.
(d) DO NOT use the cavity for storage purposes. DO NOT leave paper
products, cooking utensils or food in the cavity when not in use.
18. Superheated Liquids
Liquids, such as water, coffee, or tea are able to be overheated beyond the
boiling point without showing evidence (or signs) of boiling. Visible bubbling is
not always present when the container is removed from the microwave oven.
THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER
WHEN THE CONTAINER IS DISTURBED OR A UTENSIL IS INSERTED INTO
THE LIQUID.
To reduce the risk of injury to persons:
(a) STIR THE LIQUID BOTH BEFORE AND HALFWAY THROUGH HEATING
IT.
(b) DO NOT heat water and oil, or fats together. The film of oil will trap
steam, and may cause a violent eruption.
(c) DO NOT use straight-sided containers with narrow necks.
(d) After heating, allow the container to stand in the microwave oven for a short
time before removing the container.
19. DO NOT cook directly on the turntable. It can crack, cause injury or damage to
the oven.
F0003BP83CP_En.indd 3 2017/12/20 9:23:06
4
WARNING
IMPORTANT SAFETY INSTRUCTIONS
(continued)
TO AVOID THE RISK OF SHOCK:
DO NOT remove outer panel from oven. Repairs must be done only by a qualified
service person.
TO REDUCE THE RISK OF EXPOSURE TO
MICROWAVE ENERGY:
DO NOT tamper with, or make any adjustments or repairs to
Door, Control Panel Frame, Safety Interlock Switches, or any
other part of oven. Microwave leakage may result.
TO AVOID THE RISK OF FIRE:
1. DO NOT operate the microwave oven empty or use metal
containers. When using the microwave oven without
water or food, microwave energy can not be absorbed
and will continuously reflect throughout the cavity. This will
cause arcing and damage the oven cavity, door or other
components, which can lead to a fire hazard.
2. DO NOT store flammable materials next to, on top of, or in the oven.
3. DO NOT dry clothes, newspapers or other materials in the oven, or use news-
paper or paper bags for cooking.
4. DO NOT hit or strike Control Panel. Damage to controls may occur.
5. DO NOT use recycled paper products unless the paper product is labeled as
safe for microwave oven use. Recycled paper products may contain impurities
which may cause sparking.
TO AVOID THE RISK OF SCALDING:
POT HOLDERS should always be used when removing items from the oven.
Heat is transferred from the HOT food to the cooking container and from the
container to the Glass Tray. The Glass Tray can also be very HOT after removing
the cooking container from the oven. The wire rack is designed for use only in the
browning mode and will be hot after use. Care in handling must be exercised.
SAVE THESE INSTRUCTIONS
For proper use of your oven, read remaining safety cautions and operating instructions.
Glass Tray
1. DO NOT operate the oven without the Roller Ring and the Glass Tray in place.
2. DO NOT operate the oven without the Glass Tray fully engaged on the drive
hub. Improper cooking or damage to the oven could result. Verify that the
Glass Tray is properly engaged and rotating by observing its rotation when you
press Start. Note: The Glass Tray can turn in either direction.
3. Use only the Glass Tray specifically designed for this oven. DO NOT substitute
any other glass tray.
4. If the Glass Tray is hot, allow to cool before cleaning or placing in water.
5. DO NOT cook directly on the Glass Tray. Always place food in a microwave
safe dish, on a rack set in a microwave safe dish.
6. If food or utensils on the Glass Tray touch oven walls, causing the tray to stop
moving, the tray will automatically rotate in the opposite direction.
F0003BP83CP_En.indd 4 2017/12/20 9:23:06
5
IMPORTANT SAFETY INSTRUCTIONS
(continued)
Roller Ring
1. The Roller Ring and oven fl oor should be cleaned frequently to prevent
excessive noise.
2. Always replace the Roller Ring and the Glass Tray in their proper positions.
3. The Roller Ring must always be used for cooking along with the Glass Tray.
IMPORTANT SAFETY INSTRUCTIONS
INSTALLATION AND
GROUNDING INSTRUCTIONS
Examine Your Oven
Unpack oven, remove all packing material and examine the oven for any dam-
age such as dents, broken door latches or cracks in the door. Notify dealer
immediately if oven is damaged.
DO NOT
install if oven is damaged.
Placement of Oven
1. The oven must be placed on a fl at, stable surface. Place the front surface of the
door 7.6 cm (3 inches) or more from the counter top edge to avoid accidental
tipping of the microwave oven during normal use. For proper operation, the oven
must have suffi cient air fl ow. Allow 7.6 cm (3 inches) of space on both sides of the
oven and 5 cm (2 inches) of space on top of the oven.
(a) DO NOT block air vents. If they are blocked during operation, the oven may
overheat and be damaged.
(b)
DO NOT
place oven near a hot, damp surface such as a gas or electric
range, or dishwasher.
(c) DO NOT operate oven when room humidity is excessive.
2. This oven is manufactured for household use only. It is not approved or tested
for mobile vehicle, marine, or commercial use.
Installation
1.
DO NOT
block air vents. If they are blocked during operation, the oven may
overheat. If the oven overheats, a thermal safety device will turn the oven off.
The oven will remain inoperable until it has cooled.
2. If the oven is designed for installation into a wall cabinet, only use the proper
Panasonic trim kit available from a local Panasonic dealer, or online from the
Panasonic Canada eStore. Follow all instructions packed with the trim kit.
3. Use of a non-Panasonic trim kit will void the Manufacturer’s warranty for the
Microwave oven.
F0003BP83CP_En.indd 5 2017/12/20 9:23:07
6
WARNING
—
IMPROPER USE OF THE GROUNDING
PLUG CAN RESULT IN A RISK OF ELECTRIC SHOCK.
IMPORTANT SAFETY INSTRUCTIONS
(continued)
INSTALLATION AND GROUNDING
INSTRUCTIONS
(continued)
Consult a qualified electrician or service person if the grounding instructions are not
completely understood, or if doubt exists as to whether the appliance is properly grounded.
If it is necessary to use an extension cord, use only a three wire extension cord that has a
three-prong polarized grounding plug, and a three-slot receptacle that will accept the plug
of the appliance. The marked rating of the extension cord should be equal to or greater
than the electrical rating of the appliance.
Grounding Instructions
THIS APPLIANCE MUST BE GROUNDED. In the event of an electrical short circuit,
grounding reduces the risk of electric shock by providing an escape wire for the electric
current. This appliance is equipped with a cord having a grounding wire with a grounding
plug. The plug must be plugged into an outlet that is properly installed and grounded.
• Plug into properly installed and grounded 3-prong outlet.
• DO NOT remove ground prong.
• DO NOT use an adapter.
Power Supply
1. A short power-supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2. Longer cord sets or extension cords may be used if care is exercised in their use.
DO NOT let cord hang over edge of a table or counter.
3. If a long cord or extension cord is used,
• The marked electrical rating of the cord set or extension cord should be at least as
great as the electrical rating of the appliance.
• The extension cord must be a grounding-type 3-wire cord.
• The longer cord should be arranged so that it will not drape over the counter top or
tabletop where it can be pulled on by children or tripped over accidentally.
Wiring Requirements
1. The oven must be operated on a SEPARATE CIRCUIT. No other
appliance should share the circuit with the microwave oven. If it does, the branch circuit
fuse may blow or the circuit breaker may trip.
2. The oven must be plugged into a 15 AMP or 20 AMP, 120 VOLT, 60 Hz GROUNDED
OUTLET. (Beginning in 2017, all new construction and all renovated single family
homes must have at least a 20 A, 120 VOLT, 60 Hz GROUNDED OUTLET). Where
a standard two-prong outlet is encountered, it is the responsibility and obligation of the
consumer to have it replaced with a properly grounded three-prong outlet.
3. The VOLTAGE used must be the same as specified on this microwave oven (120 V,
60 Hz). Using a higher voltage is dangerous and may result in a fire or oven damage.
Using a lower voltage will cause slow cooking. Panasonic is NOT responsible for any
damages resulting from the use of the oven with any voltage other than specified.
TV / RADIO / WIRELESS EQUIPMENT INTERFERENCE
This product has been tested and found to comply with the limits for Microwave Oven. This product
can radiate radio frequency energy, which could cause interference to such products as radio, TV,
baby monitor, cordless phone, Bluetooth, wireless router, etc., which can be confi rmed by turning
this product off and on. If present, the user is encouraged to try to correct by taking one or more of
the following countermeasures:
(1) Increase the spacing distance between the microwave oven and other product receiving the
interference.
(2) If possible, use a properly installed receiver antenna and/or reorient the receiving antenna of
the other product receiving the interference.
(3) Plug the microwave oven into a different outlet from the other product receiving the interference.
(4) Clean door and sealing surfaces of the oven. (See Care and Cleaning of Your Microwave Oven)
F0003BP83CP_En.indd 6 2017/12/20 9:23:07
7
SAFETY PRECAUTIONS
Follow These Safety Precautions When Cooking in Your Oven.
IMPORTANT
Proper cooking depends upon the power, the time setting and quantity of
food. If you use a smaller portion than recommended but cook at the time
for the recommended portion, fire could result.
1) HOME CANNING / STERILIZING / DRYING FOODS / SMALL
QUANTITIES OF FOODS
• DO NOT use your oven for home canning. Your oven cannot maintain the food
at the proper canning temperature. The food may be contaminated and then
spoil.
• DO NOT use the microwave oven to sterilize objects (baby bottles, etc.). It is
difficult to keep the oven at the high temperature needed for sterilization.
• DO NOT dry meats, herbs, fruits or vegetables in your oven. Small quantities
of food or foods with low moisture content can dry out, scorch or catch on fire if
overheated.
2) POPCORN
3) DEEP FAT FRYING
• DO NOT deep fat fry in your microwave oven. Cooking oils may burst into
flames and may cause damage to the oven and perhaps result in burns.
Microwave utensils may not withstand the temperature of the hot oil, and can
shatter or melt.
4) FOODS WITH NONPOROUS SKINS
• DO NOT COOK/REHEAT WHOLE EGGS, WITH OR WITHOUT THE SHELL.
Steam buildup in whole eggs may cause them to explode, and possibly damage
the oven or cause injury. Reheating SLICED hard-boiled eggs and cooking
SCRAMBLED eggs is safe.
• Potatoes, apples, whole squash and sausages are examples of foods with
nonporous skins. These types of foods must be pierced before microwave
cooking to prevent them from exploding.
CAUTION: Cooking dry or old potatoes can cause fire.
Popcorn may be popped in a microwave oven corn popper. Microwave popcorn
which pops in its own package is also available. Follow popcorn manufacturers'
directions and use a brand suitable for the cooking power of your microwave
oven.
CAUTION: When using pre-packaged microwave popcorn, you can follow
recommended package instructions or use the popcorn pad (refer to page 17).
Otherwise, the popcorn may not pop adequately or may ignite and cause a fire.
Never leave oven unattended when popping popcorn. Allow the popcorn bag
to cool before opening, always open the bag away from your face and body to
prevent steam burns.
F0003BP83CP_En.indd 7 2017/12/20 9:23:07
8
SAFETY PRECAUTIONS
(continued)
5) GLASS TRAY / COOKING CONTAINERS / FOIL
• Cooking containers get hot during microwaving. Heat is transferred from the
HOT food to the container and the Glass Tray. Use pot holders when removing
containers from the oven or when removing lids or plastic wrap covers from
cooking containers, to avoid burns.
• The Glass Tray will get hot during cooking. It should be allowed to cool before
handling or before paper products, such as paper plates or microwave popcorn
bags, are placed in the oven for microwave cooking.
• When using foil in the oven, allow at least 2.5 cm (1-inch) of space between foil
and interior oven walls or door.
• Dishes with metallic trim should not be used, as arcing may occur.
6) PAPER TOWELS / CLOTHS
• DO NOT use paper towels or cloths which contain a synthetic fiber woven into
them. The synthetic fiber may cause the towel to ignite. Use paper toweling
under supervision.
7) BROWNING DISHES / OVEN COOKING BAGS
• Browning dishes or grills are designed for microwave cooking only. Always
follow instructions provided by the manufacturer. DO NOT preheat browning
dish for longer than 6 minutes.
• If an oven cooking bag is used for microwave cooking, prepare according to
package directions. DO NOT use a wire twist-tie to close bag; instead use
plastic ties, cotton string or a strip cut from the open end of the bag.
8) THERMOMETERS
• DO NOT use a conventional meat thermometer in your oven. Arcing may occur.
Microwave safe thermometers are available for both meat and candy.
9) BABY FORMULA / BABY FOOD
• DO NOT heat baby formula or baby food in the microwave oven. The glass jar
or surface of the food may appear warm while the interior can be so hot as to
burn the infant's mouth and esophagus.
10) REHEATING PASTRY PRODUCTS
• When reheating pastry products, check temperatures of any fillings before
eating. Some foods have fillings which heat faster and can be extremely hot,
while the surface remains warm to the touch (e.g. jelly donuts).
11) GENERAL OVEN USAGE GUIDELINES
• DO NOT use the oven for any purpose other than the preparation of food.
F0003BP83CP_En.indd 8 2017/12/20 9:23:07
9
Cookware Guide
Item Microwave Comments
Aluminum Foil
Yes for
Shielding
only
Small strips of foil can be molded around thin parts of meat or
poultry to prevent overcooking. Arcing can occur if foil is too
close to oven wall or door and damage to your oven will result.
Browning Dish Yes
Browning dishes are designed for microwave cooking only.
Check browning dish information for instructions and heating
chart. Do not preheat for more than 6 minutes.
Brown paper bags No May cause a fire in the oven.
Dinnerware:
Labeled “Microwave
Safe”
Yes
Check manufacturers' use and care directions for use in
microwave heating. Some dinnerware may state on the back
of the dish, “Oven-Microwave Safe”.
Unlabeled Dinnerware ? Use CONTAINER TEST blew.
Disposable polyester
Paperboard Dishes
Yes
Some frozen foods are packaged in these dishes. Can be
purchased in grocery stores.
Fast Food Carton with
Metal handle
Yes Metal handle may cause arcing.
Frozen Dinner Tray Metal No Metal can cause arcing and damage to your oven.
Frozen Dinner Tray
Microwave safe
Yes Heat only 1 tray in the oven at one time.
Glass Jars No
Most glass jars are not heat resistant. Do not use for cooking
or reheating.
Heat Resistant Oven
Glassware & Ceramic
Yes
Ideal for microwave cooking and browning.
(See CONTAINER TEST blew)
Metal Bakeware No
Not recommended for use in microwave ovens. Metal can
cause arcing and damage to your oven.
Metal Twist-Ties No May cause arcing which could cause a fire in the oven.
Oven Cooking Bag Yes
Follow manufacturers' directions. Close bag with the nylon
tie provided, a strip cut from the end of the bag, or a piece of
cotton string. Do not close with metal twist-tie. Make six 1 cm
(
½
-inch) slits near the closure.
Paper Plates & Cups Yes
Use to warm cooked foods, and to cook foods that require
short cooking times such as hot dogs in the Microwave mode.
Paper Towels & Napkins Yes
Use to warm rolls and sandwiches, only if labeled safe for
microwave use.
Recycled Paper Towels &
Napkins
No
Recycled paper products may contain impurities which may
cause sparks or create a fire hazard.
Parchment Paper Yes
Use as a cover to prevent spattering. Safe for use in
microwave, microwave/convection and conventional ovens.
Plastic:
Microwave Safe
Cookware
Yes, use
caution
Should be labeled, “Suitable for Microwave heating.” Check
manufacturers' directions for recommended uses. Some
microwave safe plastic containers are not suitable for cooking
foods with high fat or sugar content. The heat from hot food
may cause the plastic to warp.
Plastic, Melamine No This material absorbs microwave energy. Dishes get HOT!
Plastic Foam Cups
Yes, use
caution
Plastic foam will melt if foods reach a high temperature. Use
to reheat foods to a low serving temperature only.
Plastic Wrap Yes
Use to cover food during cooking to retain moisture and
prevent spattering. Should be labeled “Suitable for Microwave
heating”. Check package directions.
Straw, Wicker, Wood
Yes, use
caution
Use only for short term reheating and to bring food to a low serving
temperature. Wood may dry out & split or crack when used.
Thermometers,
Microwave safe
Yes Use only microwave safe meat and candy thermometers.
Thermometers,
Conventional
No
Not suitable for use in microwave oven,will cause sparks and
get hot.
Wax paper Yes
Use as a cover to prevent spattering and to retain moisture in
the Microwave mode only.
CONTAINER TEST
TO TEST A CONTAINER FOR SAFE MICROWAVE OVEN USE: Fill a microwave safe cup with cool water
and place it in the microwave oven alongside the empty container to be tested; heat one (1) minute at P10
(HIGH). If the container is microwave oven safe (transparent to microwave energy), the empty container
should remain comfortably cool and the water should be hot. If the container is hot, it has absorbed some
microwave energy and should NOT be used. This test cannot be used for plastic containers.
F0003BP83CP_En.indd 9 2017/12/20 9:23:07
10
Care and Cleaning of Your Microwave Oven
After cooking, the oven should be cleaned with a soft cloth moistened with soapy water. If the oven is
not cleaned occasionally to eliminate grease, it can accumulate and cause the oven to “Smoke” during
use.
BEFORE CLEANING:
Unplug oven at wall outlet. If outlet is inacces-
sible, leave oven door open while cleaning.
AFTER CLEANING:
Be sure to place the Roller Ring and the
Glass Tray in the proper position and press
Stop/Reset Pad to clear the Display.
Label:
Do not remove, wipe with
a damp cloth.
Glass Tray:
Remove and wash in warm soapy
water or in a dishwasher.
Outside oven surfaces:
Clean with a damp cloth.
To prevent damage to the
operating parts inside the oven,
water should not be allowed to
seep into ventilation openings.
Control Panel:
* Covered with a
removable protective
film to prevent
scratches during
shipping. Small
bubbles may appear
under this film.
(Hint
- To remove film,
apply masking or
clear tape to an
exposed corner and
pull gently.)
* If the Control Panel
becomes wet, clean
it with a soft, dry
cloth. Do not use
harsh detergents or
abrasives.
Inside of the oven:
Wipe with a damp cloth
after using, mild detergent
may be used if needed. The
use of harsh detergents or
abrasives.
Roller Ring and oven cavity floor:
Clean the bottom surface of the oven
with mild detergent water or window
cleaner, and dry. Roller Ring may be
washed in mild soapy water or dish-
washer. These areas should be kept
clean to avoid excessive noise.
Do not remove waveguide cover:
It is important to keep cover clean
in the same manner as the inside
of the oven.
Oven Door:
Wipe with a soft, dry
cloth when steam
accumulates inside or
around the outside of
the oven door. During
cooking, especially
under high humidity
conditions, steam
is given off from the
food. (Some steam will
condense on cooler
surfaces, such as the
oven door. This is
normal.) Inside surface
is covered with a heat
and vapor barrier film.
Do not remove.
IT IS IMPORTANT TO KEEP THE OVEN CLEAN AND DRY.
FOOD RESIDUE AND CONDENSATION MAY CAUSE RUSTING
OR ARCING AND DAMAGE TO THE OVEN. AFTER USE, WIPE
DRY ALL SURFACES-INCLUDING VENT OPENINGS, OVEN
SEAMS, AND UNDER GLASS TRAY.
F0003BP83CP_En.indd 10 2017/12/20 9:23:07
11
Oven Components Diagram
1
External Air Vent
2
Internal Air Vent
3
Door Safety Lock System
4
Exhaust Air Vent
5
Control Panel
6
Identification Plate
7
Glass Tray
8
Roller Ring
9
Heat/Vapor Barrier Film
(do not remove)
10
Waveguide Cover
(do not remove)
11
Door Release Button
12
Warning Label
13
Menu Label
14
Power Supply Cord
15
Power Supply Plug
1
4
5
7
12
3
12
9
2
10
15
14
8
13
3
6
11
Note
: The illustration is for reference only.
F0003BP83CP_En.indd 11 2017/12/20 9:23:07
12
Control Panel
Beep Sound:
When a pad is pressed correctly, a beep will be heard.
If a pad is pressed and no beep is heard, the unit did not or cannot accept the instruction.
When operating, the oven will beep twice between programmed stages. At the end of any
complete program, the oven will beep 5 times.
Note:
• If there is no operation for 6 minutes after setting cooking program, the oven will automatically
cancel the cooking program. The display will return to clock or colon display.
• If no beep sound is heard, check “Beep ON/OFF” function feature (P14).
Display Window
Popcorn Pad
(
page 17)
Coffee/Milk Pad
(
page 16)
Sensor Reheat Pad
(
page 20)
Start Pad
After cooking program
setting, one tap allows
oven to begin functioning.
If door is opened or Stop/
Reset Pad is pressed once
during oven operation,
Start Pad must be pressed
again to restart oven.
Sensor Cook Pad
(
page 20)
Keep Warm Pad
(
page 16)
Inverter Turbo Defrost
Pad (
page 18)
Power Level Pad
(
page 15)
Clock Pad
(
page 13)
Quick 30 Pad
(
page 16)
More/Less Pad
(
page 17)
Timer Pad
(
page 23)
Stop/Rest Pad
Before cooking: One tap
clears all your instructions.
During cooking: One
tap temporarily stops the
cooking process. Another
tap cancels all your
instructions, and time of
day or colon appears in
the Display Window.
Number Pads
* The control panels
of
NN-ST975S/
ST785S/ST775S/
ST765S
have same
key layout.
F0003BP83CP_En.indd 12 2017/12/20 9:23:08
13
Starting to Use
Your Oven
1.
• Press Clock once.
Colon flashes.
2.
• Set time of day using
the number pads.
Time appears in
the display window;
colon continues
flashing.
3.
• Press Clock.
Colon stops flash-
ing; time of day is
entered.
NOTES:
1. To reset the clock, repeat step 1-3.
2. The clock will retain the time of day
as long as the oven is plugged in and
electricity is supplied.
3. Clock is a 12-hour display.
4. Oven will not operate while colon is
flashing.
Setting the Clock
Example: To set 11:25 a.m. or p.m.
Child Safety Lock
This feature prevents the electronic oper-
ation of the oven until cancelled. It does
not lock the door.
To set:
• Press Start 3 times.
The indication light
appears in the display
window.
“
” continues to be
displayed until Child
Lock is cancelled.
Keypads may be
pressed but the
microwave will not
start.
To Cancel:
• Press Stop/Reset 3
times.
The display will
return to colon or
time of day when
Child Lock has been
cancelled.
NOTES:
1. You can set the Child Lock feature when
the display shows a colon or time of day.
2. To set or cancel child safety lock, Start
or Stop/Reset pad must be pressed 3
times within 10 seconds.
1.
Display Window
• Plug into a properly
grounded electrical
outlet.
“88:88” will display.
F0003BP83CP_En.indd 13 2017/12/20 9:23:08
14
Function Features
This unique function of your Panasonic microwave oven allows you to establish the initial
non-cooking features of your Oven.
This microwave oven has the functions below:
LB/KG CHOICE: The oven has both imperial and metric weight measurements.
BEEP CHOICE: The oven has both Beep On and Beep Off mode.
Plug into a properly grounded electrical outlet.
LB/KG CHOICE
• Press Start once.
The oven automatically defaults to
the imperial measure system (LB).
• Press Timer once to choose
metric weight measurements
(KG).
BEEP CHOICE
• Press Start twice.
The default mode is Beep On.
• Press Timer once. The mode
changes to Beep Off.
After setting, press Stop/Reset to exit.
NOTES: 1. These choices can be selected only when you plug-in the oven.
2. Press Stop/Reset pad to select default setting.
Set LB/KG and BEEP by following the steps below:
1.
• Plug into a properly grounded electrical outlet.
2.
• Press Start once.
3.
• Press Timer once to choose metric weight measurements (KG).
4.
• Press Start once to Beep Choice.
5.
• Press Timer once. The mode changes to Beep Off.
NOTE: After setting, it will revert back to LB/KG setting if Start pad is pressed again, press
Stop/Reset to exit.
F0003BP83CP_En.indd 14 2017/12/20 9:23:08
15
3-Stage Cooking
This feature allows you to program 2-3
Stages of cooking continuously.
Example: Continually set P10 for 5
minutes, P7 for 3 minutes
and P4 for 5 minutes.
1.
Press once
• Enter the desired
Power level.
2.
• Set Cooking Time
using number pads.
3.
Press 4 times
• Enter the desired
Power level.
4.
• Set Cooking Time
using number pads.
5.
Press 7 times
• Enter the desired
Power level.
6.
• Set Cooking Time
using number pads.
7.
• Press Start.
Cook will start. The
time in the display
window will count
down.
NOTES:
1. The maximum number of stages for
cooking is 3.
2. When selecting P10 (HIGH) power for
the first stage, you may begin at step 2.
3. When operating, two beeps will sound
between each stage.
4. Inverter turbo defrost, sensor or other
auto features can not be used with 3
stage cooking.
Selecting Power
& Cook Time
Example: To cook at P6 (MEDIUM)
power for 1 minute 30 seconds
1.
Press 5 times
• Press Power Level
until the desired power
level appears in the
display window.
2.
• Set Cooking Time using
number pads.
3.
• Press Start.
Cooking will start.
The time in the
display window will
count down.
Press Power Level
once
twice
3 times
4 times
5 times
6 times
7 times
8 times
9 times
10 times
P10 (HIGH)
P9
P8
P7 (MEDIUM-HIGH)
P6 (MEDIUM)
P5
P4
P3 (MEDIUM-LOW)/DEFROST
P2
P1 (LOW)
NOTES:
1. When selecting P10 (HIGH) power for
the first stage, you may begin at step 2.
2. When selecting P10 (HIGH) power, the
maximum programmable time is 30
minutes. For other power levels, the
maximum time is 99 minutes and 99
seconds.
3. For reheating, use P10 (HIGH) for
liquids, P7 (MEDIUM-HIGH) for most
foods and P6 (MEDIUM) for dense
foods.
4. For defrosting, use P3 (MEDIUM-LOW).
DO NOT OVERCOOK. This oven requires
less time to cook than an older unit.
Overcooking will cause food to dry out
and may cause a fire. A microwave oven's
cooking power tells you the amount of
microwave power available for cooking.
F0003BP83CP_En.indd 15 2017/12/20 9:23:08
16
Coffee/Milk Feature
This feature allows you to reheat coffee/
milk without setting power and time.
Example: To reheat 2 cup coffee.
1.
Press twice.
• Press Coffee/Milk
until the desired menu
appears in the display
window.
Press
Menu
once
twice
3 times
4 times
1 cup coffee
(1-1)
2 cups coffee
(1-2)
1 cup milk
(2-1)
2 cups milk
(2-2)
2.
Optional
• (see More/Less
Feature.)
(
page 17)
3.
• Press Start.
Reheat will start.
The time in the
display window will
count down.
NOTES:
1. Use a microwave safe cup.
2. Heated coffee/milk can erupt if not mixed
with air. Do not heat coffee/milk in your
microwave oven without stirring before
and halfway through heating.
3. Care must be exercised not to overheat
coffee/milk when using the Coffee/
Milk feature. It is programmed to give
proper result when heating 1 cup or 2
cups of coffee/milk, starting from room
temperature for coffee and refrigerator
temperature for milk. Overheating will
cause an increased risk of scalding, or
water eruption. Refer to page 3, item 18.
4. 1 cup of milk is 200 ml to 250 ml and 1
cup of coffee is 150 ml to 200 ml.
Keep Warm Feature
This feature will keep food warm for up to
30 minutes after cooking.
Example:
To keep 2 cups of gravy warm
1.
• Press Keep Warm.
2.
Thru
• Set warming time, up to
30 minutes.
3.
• Press Start.
Keep Warm will
start. The time in the
display window will
count down.
NOTE:
Keep Warm can be programmed as the
final stage after cook time/s have been
manually entered. It cannot be used in
combination with inverter turbo defrost,
sensor or other auto features.
Quick 30 Feature
This feature allows you to set or add
cooking time in 30 seconds increments up
to 5 minutes.
To Set Time using Quick 30:
Example:
To cook at P6 (MEDIUM) pow-
er for 1 minute 30 seconds
1.
Press 5 times
• Enter the desired
Power level (see page
15 for directions).
2.
Press 3 times
• Press Quick 30 until
the desired cooking
time (up to 5 minutes)
appears in the display
window.
3.
• Press Start.
Cooking begins and
the time will count
down. At the end of
cooking, 5 beeps
sound.
NOTES:
1. When selecting P10 (HIGH) power for
the first stage, you may begin at step 2.
2. After setting the time by Quick 30 Pad,
you cannot use number pads.
To Add Time using Quick 30:
Example: A
dd 3 minutes.
Press 6 times
• During manual
cooking, press Quick
30 until the desired
cooking time (up to 5
minutes) appears in
the display window.
F0003BP83CP_En.indd 16 2017/12/20 9:23:08
17
Popcorn Feature
Example: To pop 3.5 oz. (99
g
) of popcorn
1.
Press once
• Press Popcorn until
the desired size
appears in the display
window.
Press Weight
once
twice
3 times
3.5 oz. (99
g
)
2.75 oz. (78
g
)
1.5 oz. (42
g
)
2.
Optional
• (see More/Less
Feature.)
3.
• Press Start.
After several
seconds, cooking
time appears in
the display window
and begins to count
down.
NOTES ON POPCORN FEATURE:
1. Pop one bag at a time.
2. Place bag in oven according to manu-
facturers’ directions.
3. Start with popcorn at room temperature.
4. Allow popped corn to sit unopened for a
few minutes.
5. Open bag carefully to prevent burns,
because steam will escape.
6. Do not reheat unpopped kernels or reuse
bag.
NOTE:
If popcorn is of a different weight than list-
ed, follow instructions on popcorn package.
Never leave the oven unattended.
If popping slows to 2 to 3 seconds between
pops, stop oven. Overcooking can cause
fire.
REMARKS:
When popping multiple bags one right
after the other, the cooking time may vary
slightly. This does not affect the popcorn
results.
For Popcorn:
By using the More/Less Pad, the
programs can be adjusted to cook popcorn
for a longer or shorter time if desired.
1 tap = Adds approx. 10 secs.
2 taps = Adds approx. 20 secs.
3 taps = Subtracts approx. 10 secs.
4 taps = Subtracts approx. 20 secs.
5 taps = Original setting
Press More/Less Pad before pressing
Start.
For Sensor Reheat/Cook and Coffee/
Milk:
Preferences for food doneness vary
with each individual. After having used
the Sensor Reheat/Cook and Coffee/
Milk feature a few times, you may decide
you would prefer your food cooked to a
different doneness.
For Sensor Reheat/Cook:
1 tap = More (Adds approx. 20% time)
2 taps = Less (Subtracts approx. 20% time)
3 taps = Original setting
For Coffee/Milk:
1 tap = More (Adds approx. 10% time)
2 taps = Less (Subtracts approx. 10% time)
3 taps = Original setting
Press More/Less Pad before pressing
Start.
More/Less Feature
F0003BP83CP_En.indd 17 2017/12/20 9:23:09
18
Inverter Turbo Defrost Feature
Example: To Defrost 1.5 pounds of meat
Place food on microwave safe dish.
1.
• Press Inverter Turbo
Defrost.
2.
• Set weight of the food,
using the number pads.
3.
• Press Start.
Defrosting will start.
The time will count
down. Larger weight
foods will cause
a signal midway
through defrosting.
If 2 beeps sound,
turn over, rearrange
foods or shield with
aluminum foil.
Conversion Chart:
Follow the chart to convert ounces or
hundredths of a pound into tenths of a pound.
To use Inverter Turbo Defrost, enter the weight
of the food in lbs. (1.0) and tenths of a lb. (0.1).
If a piece of meat weighs 1.95 lbs. or 1 lb.
14 oz., enter 1.9 lbs.
Ounces Hundredths
of a Pound
Tenths of
a Pound
0
1 - 2
3 - 4
5
6 - 7
8
9 - 10
11 - 12
13
14 - 15
.01 - .05
.06 - .15
.16 - .25
.26 - .35
.36 - .45
.46 - .55
.56 - .65
.66 - .75
.76 - .85
.86 - .95
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
This feature allows you to automatically defrost foods such as: meat, poultry and seafood
simply by entering the weight.
Note:
The maximum weight for Inverter Turbo Defrost is 3
kg
(6 lb).
Defrosting Tips & Techniques
Preparation for freezing:
1. Freeze meats, poultry, and fish in packages with only 1 or 2 layers of food. Place wax
paper between layers.
2. Package in heavy-duty plastic wraps, bags (labeled “For Freezer”), or freezer paper.
3. Remove as much air as possible.
4. Seal securely, date, and label.
To Defrost:
1. Remove wrapper. This helps moisture to evaporate. Juices from food can get hot and
cook the food.
2. Set food in microwave-safe dish.
3. Place roasts fat-side down. Place whole poultry breast-side down.
4. Select power and minimum time so that items will be under-defrosted.
5. Drain liquids during defrosting.
6. Turn over (invert) items during defrosting.
7. Shield edges and ends if needed. (See Cooking Techniques).
After Defrosting:
1. Large items may be icy in the centre. Defrosting will complete during STANDING TIME.
2. Let stand, covered, following stand time directions on page 19.
3. Rinse foods as indicated in the chart.
4. Items which have been layered should be rinsed separately or have a longer tand time.
F0003BP83CP_En.indd 18 2017/12/20 9:23:09
19
Defrosting Tips & Techniques
(continued)
FOOD
MANUAL
DEFROST
TIME at P3
(min/
kg
) (min/lb)
DURING DEFROSTING
AFTER
DEFROSTING
Stand Time Rinse
Fish and Seafood
[up to 1.4
kg
(3 lbs.)]
Crabmeat
12 6 Break apart/Rearrange
5 min. YES
Fish Steaks 8 to 12 4 to 6 Turn over
Fish Fillets 8 to 12 4 to 6
Turn over/Rearrange/
Shield ends
Sea Scallops 8 to 12 4 to 6
Break apart/Remove
defrosted pieces
Whole fish 8 to 12 4 to 6 Turn over
Meat
Ground Meat
8 to 10 4 to 5
Turn over/Remove defrosted
portion/Shield edges
10 min.
NO
Roasts
[1.1-1.8
kg
(2½ - 4 lbs.)]
10 to 16 5 to 8
Turn over/Shield ends and
defrosted surface
30 min in refrig.
Chops/Steak 12 to 16 6 to 8
Turn over/Rearrange/Shield
ends and defrosted surface
5 min.
Ribs/T-bone 12 to 16 6 to 8
Turn over/Rearrange/Shield
ends and defrosted surface
Stew Meat 8 to 16 4 to 8
Break apart/Rearrange/
Remove defrosted pieces
Liver (thinly sliced) 8 to 12 4 to 6
Drain liquid/Turn over/
Separate pieces
Bacon (sliced) 8 4 Turn over ----
Poultry
Chicken, Whole
[up to 1.4
kg
(3 lbs.)]
8 to 12 4 to 6 Turn over/Shield 20 min in refrig.
YES
Cutlets 8 to 12 4 to 6
Break apart/Turn over/
Remove defrosted Pieces
5 min.
Pieces 8 to 12 4 to 6 Break apart/Turn over/Shield
10 min.
Cornish hens 12 to 16 6 to 8 Turn over/Shield
Turkey Breast
[2.3 - 2.7
kg
(5 - 6 lbs.)]
12 6 Turn over/Shield 20 min in refrig
F0003BP83CP_En.indd 19 2017/12/20 9:23:09
20
Sensor Reheat
Feature
This sensor feature allows you to reheat
food without setting time. The oven
simplifies programming.
Example: To To reheat a plate of food
1.
• Press Sensor
Reheat.
2.
Optional
• (see More/Less
Feature.)
(
page 17)
3.
• Press Start.
Cooking starts.
Cooking is complete when 5 beeps sound.
(When steam is detected by the Genius
Sensor and 2 beeps sound, the remaining
cooking time will appear in the display
window.)
NOTE:
Casseroles - Add 3 to 4 tablespoons of
liquid, cover with lid or vented plastic wrap.
Stir when time appears in the display window.
Canned foods - Empty contents into
casserole dish or serving bowl, cover dish
with lid or vented plastic wrap. After reheating,
let stand for a few minutes.
Plate of food - Arrange food on plate; top
with butter, gravy, etc. Cover with lid or vented
plastic wrap. After reheating, let stand for a
few minutes.
DO NOT USE SENSOR REHEAT
1. To reheat bread, meat pie and pastry
products. Use manual power and time
for these foods.
2. For raw or uncooked foods.
3. If oven cavity is warm.
4. For beverages.
5. For frozen foods.
Sensor Cook
Feature
This sensor feature allows you to cook food
without setting time. The oven simplifies
programming.
Example: To cook Frozen Entrées
1.
Press 6 times
• Press Sensor Cook
until the desired food
number appears in the
display window
2.
Optional
• (see More/Less
Feature.)
(
page 17)
3.
• Press Start.
Cooking starts.
Cooking is complete when 5 beeps
sound. (For some menus, when steam
is detected by the Genius Sensor and 2
beeps sound, the remaining cooking time
will appear in the display window.)
For the best results with the GENIUS
SENSOR, follow these recommendations.
BEFORE Reheating/Cooking:
1. The room temperature surrounding the
oven should be below 35 °C (95 °F).
2. Food weight should exceed 110
g
(4 oz.).
3. Be sure the glass tray, the outside of the
cooking containers and the inside of the
microwave oven are dry before placing food
in the oven. Residual beads of moisture
turning into steam can mislead the sensor.
4. Cover food with lid, or with vented plastic
wrap. Never use tightly sealed plastic
containers—they can prevent steam from
escaping and cause food to overcook.
DURING Reheating/Cooking:
DO NOT open the oven door until beeps
sound. Doing so will cause inaccurate
cooking since the steam from food is no
longer contained within the oven cavity.
Once the cooking time begins to count
down, the oven door may be opened to stir,
turn or rearrange foods for some menus.
AFTER Reheating/Cooking:
All foods should have a stand time.
F0003BP83CP_En.indd 20 2017/12/20 9:23:09
21
Sensor Cook Chart
Recipe Serving/Weight Hints
1. Oatmeal
0.5 - 1 cup
(40 - 80
g
)
Place inside a microwave safe serving bowl with no
cover. Follow manufacturers’ directions for preparation.
2.
Breakfast
Sausage
2 - 8 links
Follow manufacturers’ directions for preparation of
precooked breakfast sausage. Place in a radial pattern.
3. Omelet 2 - 4 eggs Follow Basic Omelet recipe on page 22.
4. Quinoa
45 - 180
g
(¼ - 1 cups)
Place quinoa in a microwave safe 3 qt casserole dish.
Add 2 parts water to 1 part quinoa. Cover with lid or
vented plastic wrap. After 2 beeps, stir. Let stand 14
minutes before serving.
5. Soup
250 ml - 500 ml
(1 - 2 cups)
Pour soup into a microwave safe serving bowl. Cover
with vented plastic wrap. Stir after cooking.
6. Frozen
Entrées
(220 - 800
g
)
(8 - 28 oz.)
Follow manufacturers’ directions for preparation. After
2 beeps, stir or rearrange. Be careful when removing
the film cover after cooking. Remove facing away from
you to avoid steam burns. If additional time is needed,
continue to cook manually.
7. Frozen Pizza
(single)
220
g
(8 oz.)
Follow manufacturers’ directions for preparation.
Add more time of cooking if needed.
8. Potatoes
(pierce skin)
1 - 4 potatoes
(170 - 220
g
each)
(6 - 8 oz. each)
Pierce each potato with a fork 6 times spacing
around surface. Place potato or potatoes around the
edge of paper-towel-lined glass tray (Turn-table), at
least 2.5 cm (1 inch) apart. Do not cover. Let stand 5
minutes to complete cooking.
9. Fresh
Vegetables
110 - 450
g
(4 - 16 oz.)
All pieces should be the same size. Wash thoroughly,
add 1 tbsp of water per ½ cup of vegetables, and cover
with lid or vented plastic wrap. Do not salt/butter until
after cooking.
10.
Frozen
Vegetables
170 - 450
g
(6 - 16 oz.)
Wash thoroughly, add 1 tbsp. of water per ½ cup of
vegetables, and cover with lid or vented plastic wrap.
After 2 beeps, stir or rearrange. Do not salt/butter until
after cooking. (Not suitable for vegetables in butter or
sauce.)
11. Rice
½ - 1½ cups
(110 - 335
g
)
Place rice with hot tap water in a microwave safe cas-
serole dish. Cover with lid or vented plastic wrap. Let
stand 5 to 10 minutes before serving.
12. Frozen
Dinners
300 - 450
g
(11 - 16 oz.)
Follow manufacturers’ directions for covering or remov-
ing covers. Do not use frozen foods packaged in foil
trays. After 2 beeps, stir or rearrange.
13. Pasta
55 - 220
g
(2 - 8 oz.)
Place 2 oz. pasta and 3 cups hot tap water in a micro-
wave safe 2 qt casserole, salt and oil, if desired, cov-
ered with lid or vented plastic wrap. For 4 oz. pasta use
4 cups water, for 6 oz. pasta use 6 cups water in 3 qt
casserole, for 8 oz. pasta use 7 cups water.
14. Fish Fillets
110 - 450
g
(4 - 16 oz.)
Arrange in a single layer. Cover with lid or vented plas-
tic wrap.
F0003BP83CP_En.indd 21 2017/12/20 9:23:09
22
Microwave Recipes
Basic omelet
1 tablespoon butter or margarine
2 eggs
2 tablespoons milk
salt and ground black pepper, if desired
Heat butter in a microwave-safe 23 cm
(9-inch) pie plate, 20 seconds at P10, or
until melted. Turn the plate to coat the
bottom with butter. Meanwhile, combine
the remaining ingredients in a separate
bowl, beat together and pour into the pie
plate. Cook, covered with vented plastic
wrap, using Omelet selection. Let stand 2
minutes. With a spatula, loosen the edges
of the omelet from the plate, fold into thirds
to serve.Always use scrambled eggs.
Yield: 1 serving
NOTE: Double ingredients for a 4 eggs
Omelet. (Cook at P6 power for 5 minutes.)
Spicy mango chutney
2 cups mango, peeled, seed removed,
diced
½ cup dark brown sugar
2 tablespoon cider vinegar
½ cup raisins
1 tablespoon jalapeno, minced
1 tablespoon garlic, minced
1 tablespoon ginger, minced
¼ teaspoon salt
¼ teaspoon black Pepper
Combine all the ingredients in a 2 qt.
microwave dish. Cover with plastic wrap,
then puncture holes with a small knife, for
steam to vent and microwave for at P10
for 6 minutes. Let cool, cover and keep
refrigerated until needed.
Yield: 2 cups
Macaroni and cheese
¼
cup butter
2 tablespoons chopped onion
1 clove minced garlic
¼
cup all-purpose flour
1 teaspoon dry mustard
1 teaspoon salt
¼
teaspoon ground black pepper
2 cups milk
2 cups grated cheddar cheese
220
g
(8 oz.) (dry weight) macaroni, cooked
and drained
1⁄3
cup bread crumbs
1 teaspoon paprika
In a 2-qt. casserole dish, melt the butter for
40 seconds at P10. Add onion and garlic
and cook for 1 minute at P10. Stir in flour,
mustard, salt and pepper, and gradually
add the milk. Cook for 3-4 minutes at P10
until sauce thickens, stirring once. Add the
cheddar cheese, stirring thoroughly. Pour
and stir the sauce into the macaroni, in a
3-qt. casserole dish.Top with bread crumbs
and paprika. Cover with lid or vented
plastic wrap. Cook at P6 power for 16-18
minutes.
Yield: 6 servings
North carolina barbecued pulled pork
2 tablespoon brown sugar
1 tablespoon paprika
1 tablespoon chili powder
1 tablespoon dry mustard
1 tablespoon red pepper flakes
½ cup cider vinegar
¼ cup white vinegar
½ cups ketchup 1
2 tablespoon worcestershire sauce
1 tablespoon tabasco sauce
1 tablespoon sugar
1 teaspoon salt
1 teaspoon black Pepper
680
g
(1 ½ lb.) pork butt
Combine all ingredients, except for the
pork, in a 1 qt. microwave container and
microwave covered for 1 minute. Place
pork butt into a large round microwave
dish. Pour barbecue sauce over pork and
cover. Microwave at P4 for 90 minutes
until meat starts to come apart very easily
when separating with a fork. (Baste
the pork every 20 minutes and check
on consistency of barbecue sauce. If
barbecue sauce becomes thick, dilute with
1-2 tablespoons of water).
Yield: 4 Portions
Quinoa salad
1 cup Quinoa
1 cucumber (cut into ½ inch cube)
1 tomatoes (remove seed and cut into
½ inch cube)
¼ cup (10
g
) parsley,chopped
⅓ cup (30
g
) your choice of roasted nuts
(e.g. sliced almond, sunflower seeds)
2 tablespoon (20
g
) dry fruits
(e.g. cranberry, raisin)
⅓ cup (40
g
) your choice of cheese
(optional,cut into ½ inch cube)
4 tablespoon olive oil
1 tablespoon rime or lemon juice
salt and pepper to taste
Cook quinoa by Auto function. After
cooking, stand for 13-15 minutes. Mix all
ingredients well, and Serve warm or chilled.
F0003BP83CP_En.indd 22 2017/12/20 9:23:10
23
Timer Feature
This feature allows you to program the
oven as a kitchen timer. It can also be used
to program a standing time after cooking is
completed and/or to program a delay start.
To Use as a Kitchen Timer:
Example: To count down 5 minutes.
1.
• Press Timer once.
2.
• Set desired amount
of time using number
pads.
3.
• Press Start.
Time will count down
without oven
operatings.
To Set Stand Time:
Example: To cook at P6 power for 3
minutes, with stand time of
5 minutes.
1.
Press 5 times
• Enter the desired
Power level (see
page 15 for directions).
2.
• Set desired cooking
time using number
pads.
3.
• Press Timer once.
4.
• Set desired amount
of Stand Time using
number pads.
5.
• Press Start.
Cooking will start.
After cooking, stand
time will count down
without oven
operating.
CAUTION:
If oven lamp is lit while using the
timer feature, the oven is incorrectly
programed. Stop oven immediately and
re-read instructions.
To Set Delay Start:
Example: To delay the start of cooking
for 5 minutes, and cook at
P6 power for 3 minutes.
1.
• Press Timer once.
2.
• Enter desired amount
of delay time using
number pads.
3.
Press 5 times
• Enter the desired
Power level (see
page 15 for directions).
4.
• Set desired cooking
time using number
pads.
5.
• Press Start.
Delay time will
count down. Then
cooking will start.
NOTES:
1. When each stage finishes, a two-beep
signal sounds. At the end of the pro-
gram, the oven will beep five times.
2. If the oven door is opened during Stand
Time, Kitchen Timer or Delay Time, the
time in the display will continue to count
down.
3. Stand time and Delay start cannot
be programmed before
inverter turbo
defrost, sensor or other auto features
.
This is to prevent the starting tempera-
ture of food from rising before defrosting
or cooking begins. A change in starting
temperature could cause inaccurate
results.
4. The maximum programmable time of
Standing Time, Kitchen Time or Delay
Time is up to 99 minutes and 99
seconds
F0003BP83CP_En.indd 23 2017/12/20 9:23:10
24
Microwave Shortcuts
FOOD POWER
TIME
(in mins.)
DIRECTIONS
To separate refrigerated
Bacon, 450
g
(1 pound)
P10
(HIGH)
30 sec.
Remove wrapper and place in micro-
wave safe dish. After heating, use a
plastic spatula to separate slices.
To soften Brown Sugar
250 ml (1 cup)
P10
(HIGH)
20 - 30 sec.
Place brown sugar in microwave safe
dish with a slice of bread. Cover with
lid or plastic wrap.
To soften refrigerated
Butter, 1 stick, 110
g
(¼ pound)
To melt refrigerated
Butter,1 stick, 110
g
(¼ poundh)
P3
(MED-LOW)
P6
(MEDIUM)
1
1½ - 2
Remove wrapper and place butter in a
microwave safe dish.
Remove wrapper and place butter in a
microwave safe dish covered with lid
or vented plastic wrap.
To melt Chocolate,
1 square, 28
g
(1 oz.)
To melt Chocolate,
125 ml (½ cup) chips
P6
(MEDIUM)
P6
(MEDIUM)
1 - 1½
1 - 1½
Remove wrapper and place chocolate
in a microwave safe dish. After heat-
ing, stir until completely melted.
NOTE: Chocolate holds its shape even
when softened.
To toast Coconut,
125 ml (½ cup)
P10
(HIGH)
1
Place in a microwave safe dish.
Stir every 30 seconds.
To soften Cream
Cheese, 225
g
(8 oz.)
P3
(MED-LOW)
1 - 2
Remove wrapper and place in a micro-
wave safe bowl.
To brown Ground Beef,
450
g
(1 pound)
P10
(HIGH)
4 - 5
Crumble into a microwave safe colan-
der set into another dish. Cover with
plastic wrap. Stir twice. Drain grease.
To cook Vegetables,
Fresh
(225
g
)
(½ pound)
Frozen
(280
g
)
(10 oz.)
Canned
(430
g
)
(15 oz.)
P8
P8
P8
3½ - 4
3½ - 4
3½ - 4
All pieces should be the same size.
Wash thoroughly, add 1 tbsp of water
per ½ cup of vegetables, and cover
with lid or vented plastic wrap. Do not
salt/butter until after cooking.
Wash thoroughly, add 1 tbsp of water
per ½ cup of vegetables, and cover
with lid or vented plastic wrap. Do not
salt/butter until after cooking. (Not suit-
able for vegetables in butter or sauce.)
Empty contents into microwave safe
serving bowl. Cover with lid or vented
plastic wrap.
F0003BP83CP_En.indd 24 2017/12/20 9:23:10
25
Microwave Shortcuts
(continued)
FOOD POWER
TIME
(in mins.)
DIRECTIONS
To cook baked Potato,
(170 - 220
g
)
(6 - 8 oz. each)
1
2
P8
P8
3½ - 4
6 - 7
Pierce each potato with a fork 6 times
spacing around surface. Place potato
or potatoes around the edge of paper-
towel-lined glass tray (Turntable), at
least 2.5 cm (1 inch) apart. Do not
cover. Let stand 5 minutes to complete
cooking.
To steam Hand Towels
- 4
P10
(HIGH)
20 - 30
sec.
Soak in water, then wring out excess.
Place on a microwave safe dish.
Heat. Present immediately.
To soften Ice Cream,
2 qt. (½ gallon)
P3
(MED-LOW)
1 - 1½ Check often to prevent melting.
Cup of liquid
To boil water, broth,
etc.
1 cup, 250 ml (8 oz.)
2 cups, 500 ml (16 oz.)
P10
(HIGH)
1½ - 2
2½ - 3
Heated liquids can erupt if not stirred.
Do not heat liquids in microwave oven
without stirring before heating.
Cup of liquid
To warm Beverage,
1 cup, 250 ml (8 oz.)
2 cups, 500 ml. (16 oz.)
P7
(MED-HIGH) 1½ - 2
2½ - 3
To roast Nuts,
375 ml (1½ cups)
P10
(HIGH)
3 - 4
Spread nuts into a 23 cm (9-inch)
microwave safe pie plate.
Stir occasionally.
To toast Sesame
Seeds, 60 ml (¼ cup)
P10
(HIGH)
2 - 2½
Place in a small microwave safe bowl.
Stir twice.
To skin Tomatoes,
(one at a time)
P10
(HIGH)
30 sec.
Place tomato into a microwave safe
bowl containing boiling water. Rinse
and peel. Repeat for each tomato.
To remove Cooking
Odours
P10
(HIGH)
5
Combine 250 - 375 ml (1 to 1½ cups)
water with the juice and peel of one
lemon in a 2 quart microwave safe
bowl. After water finishes boiling, wipe
interior of oven with a cloth.
You can also use a combination of sev-
eral whole cloves and ¼ cup of vinegar
with 1 cup of water.
F0003BP83CP_En.indd 25 2017/12/20 9:23:10
26
Food Characteristics
Bone and Fat
Both bone and fat affect cook-
ing. Bones may cause irregular
cooking. Meat next to the tips
of bones may overcook while
meat positioned under a large bone, such
as a ham bone, may be undercooked.
Large amounts of fat absorb microwave
energy and the meat next to these areas
may overcook.
Density
Porous, airy foods such as
breads, cakes or rolls take
less time to cook than heavy,
dense foods such as potatoes
and roasts. When reheating donuts or
other foods with different centers be very
careful. Certain foods have centers made
with sugar, water, or fat and these centers
attract microwaves (For example, jelly do-
nuts). When a jelly donut is heated, the jelly
can become extremely hot while the exte-
rior remains warm to the touch. This could
result in a burn if the food is not allowed to
cool properly in the center.
Quantity
Two potatoes take longer to cook
than one potato. As the quantity
of the food decreases so does
the cooking time. Overcooking
will cause the moisture content
in the food to decrease and a fire
could result. Never leave microwave unat-
tended while in use.
Shape
Uniform sizes heat more
evenly. The thin end of a
drumstick will cook more
quickly than the meaty
end. To compensate for irregular shapes,
place thin parts toward the center of the
dish and thick pieces toward the edge.
Size
Thin pieces cook more
quickly than thick pieces.
Starting Temperature
Foods that are at room temperature
take less time to cook than if they
are chilled, refrigerated, or frozen.
Cooking Techniques
Piercing
Foods with skins or mem-
branes must be pierced
scored or have a strip of skin
peeled before cooking to al-
low steam to escape. Pierce clams, oysters,
chicken livers, whole potatoes and whole
vegetables. Whole apples or new potatoes
should have a 1-inch strip of skin peeled
before cooking. Score sausages and frank-
furters. Do not Cook/Reheat whole eggs
with or without the shell. Steam build up in
whole eggs may cause them to explode,
and possibly damage the oven or cause
injury. Reheating SLICED hard-boiled eggs
and cooking SCRAMBLED eggs is safe.
Browning
Foods will not have the
same brown appearance
as conventionally cooked
foods or those foods which
are cooked utilizing a browning feature.
Meats and poultry may be coated with
browning sauce, Worcestershire sauce,
barbecue sauce or shake-on browning
sauce. To use, combine browning sauce
with melted butter or margarine and brush
on before cooking. For quick breads or muf-
fins, brown sugar can be used in the recipe
in place of granulated sugar, or the surface
can be sprinkled with dark spices before
baking.
Spacing
Individual foods, such as
baked potatoes, cupcakes
and appetizers, will cook
more evenly if placed in
the oven equal distances
apart. When possible, arrange foods in a
circular pattern.
F0003BP83CP_En.indd 26 2017/12/20 9:23:10
27
Cooking Techniques
(continued)
Covering
As with conventional cooking, moisture
evaporates during microwave cooking. Cas-
serole lids or plastic wrap are used for a
tighter seal. When using plastic wrap, vent the
plastic wrap by folding back part of the plastic
wrap from the edge of the dish to allow steam
to escape. Loosen or remove plastic wrap as
recipe directs for stand time. When removing
plastic wrap covers, as well as any glass lids,
be careful to remove them away from you to
avoid steam burns. Various degrees of mois-
ture retention are also obtained by using wax
paper or paper towels.
Shielding
Thin areas of meat and poultry cook more
quickly than meaty portions. To prevent over-
cooking, these thin areas can be shielded with
strips of aluminum foil. Wooden toothpicks
may be used to hold the foil in place.
CAUTION is to be exercised when using
foil. Arcing can occur if foil is too close to oven
wall or door and damage to your oven will
result.
Cooking time
A range of cooking time is given in each
recipe. The time range compensates for the
uncontrollable differences in food shapes,
starting temperature, and regional prefer-
ences. Always cook food for the minimum
cooking time given in a recipe and check
for doneness. If the food is undercooked,
continue cooking. It is easier to add time to
an undercooked product. Once the food is
overcooked, nothing can be done.
Stirring
Stirring is usually necessary during microwave
cooking. Always bring the cooked outside
edges toward the center and the less cooked
center portions toward the outside of the dish.
Rearranging
Rearrange small items such as chicken
pieces, shrimp, hamburger patties or pork
chops. Rearrange pieces from the edge to the
center and pieces from the center to the edge
of the dish.
Turning
It is not possible to stir some foods to distrib-
ute the heat evenly. At times, microwave en-
ergy will concentrate in one area of the food.
To help insure even cooking, these food need
to be turned. Turn over large foods, such as
roasts or turkeys, halfway through cooking.
Stand Time
Most foods will continue to cook by conduc-
tion after the microwave oven is turned off.
In meat cookery, the internal temperature will
rise 3 °C to 8 °C (5 °F to 15 °F), if allowed to
stand, tented with foil, for 10 to 15 minutes.
Casseroles and vegetables need a shorter
amount of standing time, but this standing
time is necessary to allow foods to complete
cooking to the center without overcooking on
the edges.
Test for Doneness
The same tests for doneness used in con-
ventional cooking may be used for microwave
cooking. Meat is done when fork-tender or
splits at fibers. Chicken is done when juices
are clear yellow and drumstick moves freely.
Fish is done when it flakes and is opaque.
Cake is done when a toothpick or cake tester
is inserted and comes out clean.
ABOUT FOOD SAFETY AND
COOKING TEMPERATURE
Check foods to see that they are cooked at
the recommended temperatures.
TEMP FOOD
71 °C (160 °F) ...for fresh pork, ground
meat, boneless white
poultry, fish, seafood, egg
dishes and frozen pre-
pared food.
74 °C (165 °F) ...for leftover, ready-to-re-
heat refrigerated, and deli
and carryout “fresh” food.
77 °C (170 °F) ...white meat of poultry.
82 °C (180 °F) ...dark meat of poultry.
To test for doneness, insert a meat thermom-
eter in a thick or dense area away from fat or
bone. NEVER leave the thermometer in the
food during cooking, unless it is approved for
microwave oven use.
F0003BP83CP_En.indd 27 2017/12/20 9:23:10
28
Before Requesting Service
These things are normal:
The oven causes
interference with my
TV.
Some radio, TV, Wi-Fi, cordless telephone, baby monitor,
blue tooth or other wireless equipment interference might
occur when you cook with the microwave oven. This inter-
ference is similar to the interference caused by small appli-
ances such as mixers, vacuums, blow dryers, etc. It does not
indicate a problem with your oven.
Steam accumulates
on the oven door and
warm air comes from
the oven vents.
During cooking, steam and warm air are given off from the
food. Most of the steam and warm air are removed from the
oven by the air which circulates in the oven cavity. However,
some steam will condense on cooler surfaces such as the
oven door. This is normal. After use, the oven should be
wiped dry (see page 10).
The oven is not plugged in
securely.
Remove plug from outlet, wait
10 seconds and re-insert.
Main circuit breaker or main
fuse is tripped or blown.
Reset main circuit breaker or
replace main fuse.
The Glass Tray is not
positioned properly on the
Roller Ring or there is food
under the Roller Ring.
Take out Glass Tray and Roller
Ring. Wipe with a damp cloth
and reset Roller Ring and
Glass Tray properly.
The CHILD LOCK was
activated.
Deactivate LOCK by pressing
Stop/Reset Pad 3 times.
The Roller Ring and oven
bottom are dirty.
Clean these parts according to
Care and Cleaning of your
Microwave oven (see page
10).
The door is not closed
completely.
Close the oven door securely.
Start Pad was not pressed
after programming.
Press Start Pad.
The program is not correct. Program again according to
the Operating Instructions.
Stop/Reset Pad has been
pressed accidentally.
Program oven again.
Another program is already
entered into the oven.
Press Stop/Reset Pad to can-
cel the previous program and
enter new program.
There is a problem with the
outlet.
Plug another appliance into the
outlet to check if it is working.
PROBLEM POSSIBLE CAUSE REMEDY
Oven will not turn on.
Oven will not start
cooking.
The Glass Tray
wobbles.
When the oven is
operating, there is
noise coming from
the glass tray.
The indication light
appears in the
Display Window.
This displaying indicates a
problem with the microwave
generation system.
Please contact an authorised
Service Center (see page 29).
The oven stops cook-
ing and “H00”, “H97” or
“H98” appears in the
display window.
F0003BP83CP_En.indd 28 2017/12/20 9:23:11
29
Warranty
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3
Panasonic PRODUCT – LIMITED WARRANTY
Panasonic Canada Inc.
warrants this product to be free from defects in material and workmanship under
normal use and for a period as stated below from the date of original purchase agrees to, at its option either
(a) repair your product with new or refurbished parts, (b) replace it with a new or a refurbished equivalent
value product, or (c) refund your purchase price. The decision to repair, replace or refund will be made by
Panasonic Canada Inc.
Category Service type Parts Labour Magnetron
Counter top microwave oven
(except Prestige models)
Carry-in 1 Year 1 Year
Additional 4 Years
(Part only)
Counter top microwave oven – Prestige model
(Genius Prestige, Genius Prestige Plus and
Genius Prestige Grill)
In-home 2 Years 2 Years
Additional 3 Years
(Part only)
Microwave Convection oven In-home 2 Years 2 Years
Additional 3 Years
(Part only)
Over The Range (OTR) microwave oven In-home 2 Years 2 Years
Additional 3 Years
(Part only)
In-home Service will be carried out only to locations accessible by roads and within 50 km of an authorized
Panasonic service facility.
This warranty is given only to the original purchaser, or the person for whom it was purchased as a gift, of a
Panasonic brand product mentioned above sold by an authorized Panasonic dealer in Canada and purchased
and used in Canada, which product was not sold “as is”, and which product was delivered to you in new
condition in the original packaging.
IN ORDER TO BE ELIGIBLE TO RECEIVE WARRANTY SERVICE HEREUNDER, A PURCHASE RECEIPT
OR OTHER PROOF OF DATE OF ORIGINAL PURCHASE, SHOWING AMOUNT PAID AND PLACE OF
PURCHASE IS REQUIRED
LIMITATIONS AND EXCLUSIONS
This warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER
normal wear and tear or cosmetic damage. The warranty ALSO DOES NOT COVER damages which
occurred in shipment, or failures which are caused by products not supplied by
Panasonic Canada Inc.
,
or failures which result from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty
installation, set-up adjustments, misadjustment of consumer controls, improper maintenance, power line
surge, lightning damage, modification, introduction of sand, humidity or liquids, commercial use such as hotel,
office, restaurant, or other business or rental use of the product, or service by anyone other than a Authorized
Servicer, or damage that is attributable to acts of God.
Over-The-Range cooktop light bulbs are excluded from coverage under this warranty.
In the case where the microwave oven is built-in, the warranty will be voided if using a non-Panasonic trim kit.
THIS EXPRESS, LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. IN NO EVENT WILL
Panasonic Canada Inc.
BE LIABLE FOR ANY SPECIAL, INDIRECT OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF
ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY. (As examples, this warranty excludes damages
for lost time, travel to and from the Authorized Servicer, loss of or damage to media or images, data or other
memory or recorded content. This list of items is not exhaustive, but for illustration only.)
In certain instances, some jurisdictions do not allow the exclusion or limitation of incidental or consequential
damages, or the exclusion of implied warranties, so the above limitations and exclusions may not be
applicable. This warranty gives you specific legal rights and you may have other rights which vary depending
on your province or territory.
WARRANTY SERVICE
PRODUCT OPERATION ASSISTANCE
For product information and operation assistance, please visit our Support page:
www.panasonic.ca/english/support
PRODUCT REPAIRS
Please locate your nearest Authorized Servicentre: panasonic.ca/english/support/servicentrelocator
IF YOU SHIP THE PRODUCT TO A SERVICENTRE
Carefully pack and send prepaid, adequately insured and preferably in the original carton.
Include details of the defect claimed, and proof of date of original purchase.
F0003BP83CP_En.indd 29 2017/12/20 9:23:11
30
Quick Guide to Operation
Feature How to Operate
To set
Clock
(
page 13)
Press. Press.Enter time of day.
Thru
To Use Child
Safety Lock
(
page 13)
To Set:
Press 3 times.
To Cancel:
Press 3 times.
To Use
Power and Time
(
page 15)
Press to select Power Level.
Press.
Thru
Set time.
To use
Keep warm
(
page 16)
Press.
Press.
Set time. (up to 30 min.)
Thru
To cook using
Quick 30
(
page 16)
To Set Time:
Press.
Set time.
(up to 5 min.)
Press to select
Power Level.
To Add Time:
Press to add time. (up to 5 min.)
During manual
cooking.
To cook using
Coffee/Milk
(
page 16)
Press.
Press to select food number.
Optional
.
To cook using
Popcorn
(
page 17)
Press.
Press to select weight.
Optional
.
To defrost using
Inverter Turbo
Defrost
(
page 18)
Press.Press. Set weight.
Thru
To reheat using
Sensor Reheat
(
page 20)
Optional
.
Press.
Press.
To cook using
Sensor Cook
(
page 20)
Press.Press to select
food number.
Optional
.
To use as a
Kitchen Timer
(
page 23)
Press. Press.Set time.
Thru
To set
Stand Timer
(
page 23)
Press. Set time. Press.
Input up to
2-stage cook-
ing programs.
( )
Thru
To set
Delay Start
(
page 23)
Input up to
2-stage cook-
ing programs.
( )
Press. Set time.
Press.
Thru
F0003BP83CP_En.indd 30 2017/12/20 9:23:11
31
Specifications
NN-ST975S
NN-ST785S NN-ST775S
NN-ST765S
Power Source: 120 V 60 Hz
Power Consumption: 12.3 A 1,460 W
Cooking Power:* 1,200 W
Outside Dimensions
(W x H x D):
606 mm x 356 mm x 493 mm
(23
/
” x 14” x 19
/
”)
555 mm x 304 mm x 493 mm
(21
/
” x 12” x 19
/
”)
Oven Cavity Dimensions
(W x H x D):
448 mm x 272 mm x 470 mm
(17
/
” x 10
/
” x 18 ½”)
398 mm x 210 mm x 470 mm
(15
/
” x 8
/
” x 18 ½”)
Operating Frequency: 2,450 MHz
Net Weight: Approx. 16.7
kg
(36.8 lbs.) Approx. 14.3
kg
(31.5 lbs.)
Trim Kit for 24” Cabinet:
NN-ST785S NN-ST775S NN-ST765S
Model Number:
NN-TK714S
Outside Dimensions
(W x H):
596 mm x 410 mm
(23 ½” x 16 ⅛”)
Cabinet Opening
(W x H x D):
600 mm x 395 mm x 533 mm
(23
/
” x 15
/
” x 21”)
Trim Kit for 27” Cabinet:
NN-ST975S
NN-ST785S NN-ST775S
NN-ST765S
Model Number:
NN-TK922S NN-TK722S
Outside Dimensions
(W x H):
684 mm x 472 mm
(27” x 18
⁄
”)
684 mm x 419 mm
(27” x 16
½
”)
Cabinet Opening
(W x H x D):
648 mm x 442 mm x 533 mm
(25
/
” x 17
/
” x 21”)
648 mm x 389 mm x 533 mm
(25
/
” x 15
/
” x 21”)
Trim Kit for 30” Cabinet:
NN-ST975S
NN-ST785S NN-ST775S
NN-ST765S
Model Number:
NN-TK932S NN-TK732S
Outside Dimensions
(W x H):
760 mm x 472 mm
(30” x 18
⁄
”)
760 mm x 419 mm
(30” x 16
½
”)
Cabinet Opening
(W x H x D):
724 mm x 442 mm x 533 mm
(28
/
” x 17
/
” x 21”)
724 mm x 389 mm x 533 mm
(28
/
” x 15
/
” x 21”)
*IEC Test procedure Specifications subject to change without notice.
F0003BP83CP_En.indd 31 2017/12/20 9:23:11
32
User’s Record
The serial number of this product may
be found on the back side of the oven
or on the left side of the control panel.
You should note the model number and
the serial number of this oven in the
space provided and retain this book as
a permanent record of your purchase
for future reference.
Model No.
Serial No.
Date of Purchase
F0003BP83CP_En.indd 32 2017/12/20 9:23:11
