F4DWT24DS1
F4DWT24SS1
EN
INSTALLATION 0$18$/
',6+:$6+(5
This Dishwasher includes heating element. Do not touch the heating
element during or after immediately after use.
(model depending)
570mm
600 mm
860 mm- 910 mm
( 33 7/8"- 35 7/8")
105mm
570mm
(22 1/2")
(4 1/8”)
(22 1/2")
(1 31/32”)
(23 5/8")
( 34"- 36")
864 mm-914 mm
598 mm
(23 9/16")
There shall be an opening
through the partition
between the compartments
that is large enough for the
attachment plug to pass
through. the longest
dimension of the opening
shall not be more than
38.1 mm (1.5 inch)
The edges of the cabinetry,
if the partition is wood,
be smooth and rounded,
or, if the partition is metal,
be covered with an edge
protector and care shall be
exercised, when the appliance
is installed or removed, to
reduce the likelihood of damage
to the power supply cord.
570mm
600 mm
860 mm- 910 mm
( 33 7/8"- 35 7/8")
105mm
570m
m
(22 1/2")
(4 1/8”)
(22 1/2")
(1 31/32”)
(23 5/8")
( 34"- 36")
864 mm-914 mm
598 mm
(23 9/16")
DOC COD.
5.000.007.0 - 06/21
