[en] Instruction manual
Built-in oven
HVA531NS0
Ú Table of contents[en] Instruction manual
: Important safety information
Read these instructions carefully. Only then will you be able to operate your appliance safely and correctly. Retain the instruction manual and installation instructions for future use or for subsequent owners.
This appliance is only intended to be fully fitted in a kitchen. Observe the special installation instructions.
Check the appliance for damage after unpacking it. Do not connect the appliance if it has been damaged in transport.
Only a licensed professional may connect appliances without plugs. Damage caused by incorrect connection is not covered under warranty.
This appliance is intended for domestic use only. The appliance must only be used for the preparation of food and drink. The appliance must be supervised during operation. Only use this appliance indoors.
This appliance is intended for use up to a maximum height of 2000 metres above sea level.
This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or are instructed by a person responsi...
Children must not play with, on, or around the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 8 years old and are being supervised.
Keep children below the age of 8 years old at a safe distance from the appliance and power cable.
Always slide accessories into the cooking compartment correctly. See "Description of accessories in the instruction manual.
Risk of fire!
■ Combustible items stored in the cooking compartment may catch fire. Never store combustible items in the cooking compartment. Never open the appliance door if there is smoke inside. Switch off the appliance and unplug it from the mains or switch ...
Risk of fire!
■ A draught is created when the appliance door is opened. Greaseproof paper may come into contact with the heating element and catch fire. Do not place greaseproof paper loosely over accessories during preheating. Always weight down the greaseproof...
Risk of burns!
■ The appliance becomes very hot. Never touch the interior surfaces of the cooking compartment or the heating elements. Always allow the appliance to cool down. Keep children at a safe distance.
Risk of serious burns!
■ Accessories and ovenware become very hot. Always use oven gloves to remove accessories or ovenware from the cooking compartment.
Risk of burns!
■ Alcoholic vapours may catch fire in the hot cooking compartment. Never prepare food containing large quantities of drinks with a high alcohol content. Only use small quantities of drinks with a high alcohol content. Open the appliance door with care
Risk of scalding!
■ The accessible parts become hot during operation. Never touch the hot parts. Keep children at a safe distance.
Risk of scalding!
■ When you open the appliance door, hot steam may escape. Open the appliance door with care. Keep children at a safe distance.
Risk of scalding!
■ Water in a hot cooking compartment may create hot steam. Never pour water into the hot cooking compartment.
Risk of injury!
Scratched glass in the appliance door may develop into a crack. Do not use a glass scraper, sharp or abrasive cleaning aids or detergents.
Risk of electric shock!
■ Incorrect repairs are dangerous. Repairs may only be carried out by one of our trained after-sales engineers. If the appliance is faulty, unplug the mains plug or switch off the fuse in the fuse box. Contact the after-sales service.
Risk of electric shock and serious injury!
■ The cable insulation on electrical appliances may melt when touching hot parts of the appliance. Never bring electrical appliance cables into contact with hot parts of the appliance.
Risk of electric shock!
■ Do not use any high-pressure cleaners or steam cleaners, which can result in an electric shock.
Risk of electric shock!
■ When replacing the cooking compartment bulb, the bulb socket contacts are live. Before replacing the bulb, unplug the appliance from the mains or switch off the circuit breaker in the fuse box.
Risk of electric shock!
■ A defective appliance may cause electric shock. Never switch on a defective appliance. Unplug the appliance from the mains or switch off the circuit breaker in the fuse box. Contact the after-sales service.
Causes of damage
Caution!
Your new appliance
Function selector
Note
Note
Temperature selector
The electronic clock
Accessories
Before using the oven for the first time
Setting the clock
1. Press the 0 button until the dot flashes on the display.
2. Set the current time with the "+" and "-" buttons.
Note
Baking out the oven
Precleaning the oven
1. Remove the accessories and the hook-in racks from the cooking compartment.
2. Completely remove any leftover packaging, e.g. small pieces of polystyrene, from the cooking compartment.
3. Some parts are covered with a protective film. Remove this scratch protection film.
4. Clean the outside of the appliance with a soft, damp cloth.
5. Clean the cooking compartment with hot soapy water.
Heating up the oven
1. Turn the function selector to the Top/bottom heating operating mode.
2. Turn the temperature selector to the maximum temperature.
3. Switch the oven off after 40 minutes.
Note
Recleaning the oven
1. Clean the cooking compartment with hot soapy water.
2. Refit the hook-in racks.
Cleaning the accessories
How to operate your oven
Switching on the oven
1. Use the function selector to set the heating function. An acoustic signal sounds.
2. Use the temperature selector to set the temperature.
Operating the electronic clock
1. Press the 0 button until the dot flashes on the display.
2. Set the current time with the "+" and "-" buttons.
Note
1. Press the 0 button until the V symbol flashes on the display and three zeros are displayed.
2. Set the required cooking time with the "+" and "-" buttons.
Notes
1. Press the "+" and "-" buttons simultaneously.
2. Press the 0 button.
3. Press the "-" button to select a different audible signal.
Setting the automatic timer
Automatic switch-off
1. Press the 0 button until the V symbol flashes on the display and three zeros are displayed.
2. Press the 0 function button again until "dur" and "0.00" flash alternately on the display panel and the "A" symbol flashes.
3. Set the cooking time with the "+" and "-" buttons.
4. Set the required heating function and temperature.
1. Switch off the temperature selector and function selector.
2. Press the 0 button until the Û symbol appears.
Automatic switch-on and switch-off
1. Press the 0 button until the V symbol flashes on the display and three zeros are displayed.
2. Press the 0 function button again until "dur" and "0.00" flash alternately on the display panel and the "A" symbol flashes.
3. Set the cooking time (e.g. 1 hour) with the "+" and "-" buttons.
4. Press the 0 function button again until "End" and the switch- off time "18:30" (i.e. the current time plus the set cooking time) flash alternately on the display panel.
5. Set the switch-off time (e.g. 19:30) using the "+" and "-" buttons.
6. Set the required heating function and temperature.
The Û symbol disappears from the display panel.
1. Switch off the temperature selector and function selector.
2. Press the 0 button until the Û symbol appears.
Displaying and changing set values
1. Press the 0 button until the V symbol flashes on the display panel.
2. Press the 0 button again until "dur" and the remaining cooking time flash alternately on the display panel and the A symbol flashes.
3. Press the 0 button again until "End" and the set switch-off time flash alternately on the display panel.
Care and cleaning
Notes
: Risk of electric shock!
: Risk of burns!
Cleaning agents
Removing and installing the door panels
Removing the door panels
1. Open the oven door fully.
2. Lock both hinges on the left and right using the locking pin.
Note
3. Lift the bottom of the inner panel slightly until the fastening pins come out of the holder (1).
4. Carefully lift the top of the inner panel until the fastening pins come out of the holder (2).
Caution!
5. Remove the inner panel.
6. Remove the middle panel.
Note
: Risk of injury!
Fitting the door panels
1. Reinsert the middle panel.
Notes
2. Reinsert the inner panel.
Note
3. Remove the locking pins and close the oven door.
Removing and fitting the appliance door
Removing the appliance door
1. Open the oven door fully.
2. Lock both hinges on the left and right using the locking pin (a).
Note
3. Grip the oven door on either side with both hands and close the oven door by approx. 30° (b).
4. Raise the oven door slightly and pull it out.
Note
Fitting the appliance door
1. Grip the oven door on either side with both hands.
2. Slide the hinges into the slots in the oven (a).
Note
3. Lower the door downwards.
4. Remove the locking pins.
: Risk of injury!
Removing and inserting the hook-in racks
Removing the hook-in racks
1. Grip the front of the hook-in rack and pull it to the middle of the cooking compartment.
2. Fold out the hook-in rack further and pull it from the rear holes of the side panel.
3. Hold the catalytic cooking compartment panel in place.
4. Remove the hook-in rack from the cooking compartment.
Inserting the hook-in rack
1. Hold the catalytic cooking compartment panel in place.
2. Insert the hooks of the hook-in rack into the rear holes in the side panel.
3. Press the front hook of the hook-in rack into the hole.
Troubleshooting
: Risk of electric shock!
Replacing the oven light bulb
: Risk of electric shock!
1. Allow the cooking compartment to cool down.
2. Open the appliance door.
3. Place a tea towel in the cooking compartment to prevent damage.
4. Remove the hook-in racks.
5. Remove the glass cover. To do this, open the glass cover at the front with your hand. Should you experience difficulties removing the glass cover, use a spoon to help.
6. Remove the oven light bulb.
7. Replace the oven light bulb with a bulb of the same type:
Voltage: 230 V;
Power: 40 W;
Fitting: G9;
8. Refit the glass cover for the oven light bulb.
9. Refit the hook-in racks.
10. Remove the tea towel.
11. Switch the circuit breaker back on.
12. Check that the oven lighting is working again.
After-sales service
E number and FD number
Repair order and advice if faults occur
Energy and environment tips
Saving energy
Environmentally-friendly disposal
Acrylamide in foodstuffs
Tips for using your appliance
Notes
Baking
Baking tips
Roasting and grilling
Roasting tips
Grilling tips
Roasting tips
Tested for you in our cooking studio.
Notes
