2 IN 1 - SURFACE OR RECESSED
LED BACKLIT PANEL
INSTALLATION
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installing and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained and
ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty does not
apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no warranty
against damage to any surface due to incorrect removal and installation of the product. The products are suitable
for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This product is
warranted for manufacturing defects only.
WARNING!
1. Please make sure to turn o the power before starting the installation.
2. Installation should only be done by a certified electrician.
3. The light source of this luminaire is not replaceable, when the light source reaches its end of life the whole luminaire
should be replaced.
4. If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by the manufacturer or
his service agent or a similar qualified person in order to avoid a hazard.
5. Proper grounding should be ensured throughout the installation.
6. For Indoor use only
L
H
W
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
MULTI-LANGUAGE MANUAL QR CODE
Please scan the QR code to access the manual in
multiple languages.
INSTRUCTION MANUAL
Make a hole into the ceiling
Remove the cover as shown below.
Connect the cable into the terminal.
Fix the panel onto the ceiling.
Fix the cover and test the fixture light
Fix the Panel into the Ceiling
Connect the cable into the terminal
Turn on the switch and test
the Panel
AC:220-240V
AC:220-240V
Caution, risk of electric
shock.
This marking indicates that this
product should not be disposed of
with other household wastes.
Luminaires not suitable for covering
with thermally
insulating material.
'This product contains a light source of energy eciency class <E>', where <E> shall be replaced by the energy
eciency class of the contained light source.
MODEL
SKU WATTS LUMENS
BEAM
ANGLE
LIFE
SPAN
ON/OFF
CYCLE
DF CRI
BODY
TYPE
OPERATION
TEMPERATURE
DIMENSION
INPUT POWER
VT-6139 36 3960
20,000Hr >15,000
110 ≥0.9 ≥80
PP+Fe
-20°C to +40°C 595x595x30mm
AC:220-240V
50/60Hz
Times
638011
638021
6380
63801
6381
63811
