INSTRUCTION MANUAL
MICROWAVE SENSOR DOWNLIGHT TYPE-ADJUSTABLE
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code to
access the manual in multiple languages.
TECHNICAL DATA
MODEL VT-80360
SKU 23165
INPUT POWER AC: 220-240V, 50/60 Hz
RATED LOAD
Max. 1200W
300W +LED
TIME DELAY
Min. 10sec ±3sec
Max. 12min ±1min
DETECTION
RANGE
360°
DETECTION
DISTANCE
1-8m (Radius), Adjustable
DETECTION
MOVING SPEED
0.6-1.5m/s
WORKING
TEMPERATURE
-20°C to +40°C
POWER
CONSUMPTION
Approx, 0.5W
AMBIENT LIGHT <3-2000 LUX (Adjustable)
INSTALLATION
HEIGHT
1.5-3.5m
POWER
CONSUMPTION
approx 0.9w
DETECTION
MOTION SPEED
0.6-1.5 m/s
IP RATING IP20
HF SYSTEM
5.8Ghz CW Radar, ISM
Band
DIMENSION Ø80x66.6 mm
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 5 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product.
V-TAC LED
RANGE (UPTO 400W)
COMPATIBLE WITH
