User manual
ADD5910M
Water Dispenser
6
Clean and Maintenance
10
11
Trouble shooting
5
Guarantee and service
6
7
Packing list
8 11
Important
1 1
Parts and features
2 3
Installation
3 5
How to use
4 6
CONTENTS
English
01
Necessary precautions must be taken when using electrical appliances, and these include
the following:
• Read all instructions carefully before using.
• Install the appliance according to the installation instructions in this user manual.
• Never use the appliance if the power cord or plug are damaged or if the appliance itself is faulty.
• Ensure that the power cord does not come into contact with hot surfaces.
• Never place the appliance body, plug or power cord in water or other liquids. Always wipe it
clean with a damp cloth.
• Do not operate the appliance when the water is below the minimal water level to avoid
damaging the heating elements.
• Do not store or use this appliance outdoors.
• Do not let the cord hang over the edge of table or counter, and do not place the appliance
on hot surface.
• Do not place the appliance on or near any gas or electric burner or inside heated oven.
• Do not put the appliance into a working disinfection cabinet.
• Do not freeze the appliance in the refrigerator.
• Do not lean the appliance or operate it upside down.
• This appliance can be used by children aged from 8 years and above and persons with reduced
physical,sensory or mental capacities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
• Children shall not play with the appliance and user maintenance shall not be made by children
without supervision.
• Make sure to operate the appliance when children are under good custody.
• Please ensure the appliance is used on a firm and flat surface out of reach of children,
to avoid being overturned in a sudden and result in the scald or hitting injury.
the appliance in water or other liquid.
• Do not touch the hot surface, water spout when the appliance is operating.
• While the appliance is under working, do not touch or block the steam outlet by hand or
other stuff, do not open the water tank lid in a rush, in order to avoid the scald by the hot
steam or any other malfunctions.
1. Important
• To avoid being scalded, it is prohibited to use hand or any parts of your body to feel the
temperature or steam when the appliance is being used.
Do not operate it if water is below minimum.
• Unplug the appliance before cleaning and make sure it is cooled down thoroughly.
• If the power cord is damaged, in order to avoid any hazard, the cord must be replaced by
• The power cord could only be replaced by the exclusive power cord if any damages.
• Do not operate the appliance when it is out of order or with malfunctions, and return it to
the nearest authorized service agent or manufacturer for examination, repair or replacement,
do not try to disassemble it by yourself.
• This appliance is intended to be used in household and similar locations such as:
– staff kitchen areas in shops, offices and other working environments;
– farm houses;
– hotels, motels and other residential type environments;
– bed and breakfast type environments.
• Warning: misuse may cause injury.
• The heating element surface is subject to residual heat after use.
• Please keep this user manual for future reference.
or that has been microbiologically impaired into the product. Use only cold or ambient
temperature water. Do not use the appliance for baby food.
• Appliance outlet and other items may be hot after using.
• Be cautious of the hot steam when dispensing water ≥℃.
• Do not move the appliance unless the power is cut off.
• Failure to follow these instructions could cause scalding or damage to the product.
• WARNING: do not locate multiple portable socket-outlets or portable power supplies
at the rear of the appliance.
03
This is an instant heating water dispenser. With instant heating technology, it provides hot water
with different temperatures within seconds. Thanks to the Philips Micro X-Clean filter, you
can always enjoy the crispy and pure tasting water at home.
2. Parts and features
• If only a small amount of water is dispensed, there may be a temperature deviation.
We suggest preheating the before use.
• There may be a big water volume or temperature deviation if limescale builds up inside
the heating element. Please descale the appliance according to chapter 5.
Control panel
Nozzle
Drip tray plate
Drip tray
Water tank cover
Filter
Inner water tank
Water tank
1
8
7
6
5
4
3
2
4
3
2
1
7
5
6
8
Control panel
Tea program
Press to quickly set 100℃
Cleaning/descale button
Long press for 3 seconds to start the cleaning/descaling process. During cleaning/descaling,
press the button to pause, and press it again to restart. Note: the whole descale process is
Water temperature selection
Press to choose desired water temperature.
Safety lock
When hot water ≥℃ is chosen, press to unlock before pressing the dispense button.
It can also be used to wake up the appliance when it is under the sleep mode.
Water volume selection
Press to choose desired water volume.
Dispense button
Press to start or stop dispensing.
Filter lifetime indicator
Filter lifetime reset
Water shortage indicator
Descale indicator
Product model ADD5910M
Micro X-Clean:
Filter model
Main technical speci�cations
~
Municipal tap water
I
IPX0
Rated voltage
Rated power consumption
Applicable water source
Anti-shock level
Type of protection
Rated frequency
5℃-38℃
Applicable inlet water temperature
Before using the appliance for the first time
• Remove all packaging.
• Remove the tank lid and extract the inner water tank and water tank. Wash, rinse and
dry them thoroughly.
• Clean the appliance following the first time cleaning instruction in chapter 5.
WARNING:
3. Installation
Positioning of appliance
• Do not install this appliance in a very damp or hot place, or near heat source.
• Do not use this appliance outdoors. This appliance is only suitable for indoor use.
• Ensure that the ventilation on both sides is never blocked or covered.
05
• The appliance will automatically go to sleep mode if there is no operation within 1 minute.
Touch the safety lock button to wake up the appliance.
• Please discard the water in the drip tray when it's full.
• There could be a temperature deviation of ±5℃. There could be a volume deviation of ±10%.
The actual temperature and volume depends on the using environment and local tap
water quality.
Note
First time cleaning
1. Preparing the filter cartridge
• Remove the packaging. It is common that there is some powder on the surface of the cartridge.
These particles are harmless and can be washed off during the preparation process.
• Soak the filter cartridge in clean water for 15 minutes. Shake the filter cartridge in water
slightly to wash off the carbon powder on the surface.
5. Clean and Maintenance
Clean the appliance first according to the first time cleaning instruction in chapter 5.
set rate and it may take some time due to the action of the filter cartridge.
1. Plug in.
4. How to use
A-2
A-1
A-3
Routine maintenance
- Discard the water in the water tank. Rinse the tank.
- Dispense ambient water till the water tank is empty.
- The appliance is ready to use.
• Wash, rinse and dry the inner water tank, water tank and the tank cover regularly, at least when
1
2
• Remove the inner water tank.
• Ensure the seal ring is installed correctly.
• Reinsert the inner water tank into the water tank.
• Place a jug or vessel under the dispense outlet.
• Plug in.
• Dispense ambient water till the water tank is empty.
07
B-2B-1
• Wash drip tray with soapy water. Rinse all soap away with clean water. Allow the drip tray to
air dry.
Note
in the fridge. This will help to maintain the hygiene of the filter. Before using the filter after
storage, follow the preparation and installation instructions for use as normal.
• Always switch off and unplug the appliance before cleaning.
• Ensure the appliance is cooled down before cleaning.
• Do not use scouring pads, solvents or abrasives to clean as they may damage the appliance.
Descaling
• The descale Indicator lights up when the appliance requires the descale process.
• For safe and efficient operation of your appliance, it is important to descale regularly.
• Untreated scale deposits prevent the element conducting heat efficiently and may affect
its performance.
• Ensure the inner water tank and filter are removed before starting the descale process.
Descale Procedure
1. Remove the filter and the inner water tank.
5. The descale indicator will flash and the appliance will run
a descale process. It will take around 5 mins. Caution: dispensed
liquids will be hot.
citric acid solution, refill the water tank with fresh tap water to the
maximal water level.
7. The appliance will run a cleaning cycle.
8. The descale indicator will turn off once the descaling completes.
C-1
08
Replacing the �lter cartridge
indicator, or the suggested replacement cycle.
Model
Suggested Replacement Cycle
09
Filter lifetime indicator
Note
• During descaling, press the descale button to pause, press it again to restart.
9. Pull out the nozzle downwards. Rinse it with
10. Install the nozzle back. Ensure it is assembled
11. Re-insert the filter and inner water tank.
The appliance is ready to use.
C-2
1
2
C-3
1
2
6. Trouble shooting
10
Fill the water tank up to the maximal
water level.
The dispense button is locked. Press the safety lock button to unlock.
The appliance is not connected
to power.
Plug in the power plug.
The appliance is not connected
to power.
The appliance is not connected
to power.
Plug in the power plug. If it does
not work, please contact
consumer care.
The appliance does not
dispense hot water.
Plug in the power plug.
The water in the water tank is
below the minimal water level.
The display panel does
not light up.
The appliance is in sleep mode.
Touch the safety lock button to
wake up the appliance.
Problem Possible causes Solutions
Button/display panel
does not respond.
Leakage of the water tank
The water tank is not sitting well
on the base.
The sealing valve at the bottom
of the tank is faulty.
Please contact consumer care.
The appliance is in sleep mode.
Touch safety lock button to wake up
the appliance.
There is condensed water on the
display after dispensing hot water.
Wipe the panel with a dry cloth. If it does
not work, please contact consumer care.
The appliance does not
dispense ambient water.
The appliance is not connected
to power.
The water in the water tank is
below the minimal water level.
Fill the water tank up to the maximal
water level.
Plug in the power plug.
The water pump is damaged. Please contact consumer care.
Limescale builds up in the heating
element.
There is air in the water pump.
Fill the water tank up to the maximal
water level.
Follow the descaling instruction in
chapter 5 to descale.
Water shortage indicator
lights up.
The water in the water tank is
below the minimal water level.
Fill the water tank up to the maximal
water level.
The appliance is not cleaned
thoroughly after descaling.
a long time.
Discard the remaining water in the water
instruction to clean the appliance.
Odd taste of the water.
of life.
cartridge.
Limescale builds up in the heating
element.
Follow the descaling instruction
in chapter 5 to descale.
Please keep this user manual for future reference
11
8. Packing list
Water dispenser x1
x1
x1
x1
x1
Filter cartridge
Drip tray
User manual
Quick start guide
This symbol on the products and accompanying documents means that used electrical and
electronic products should not be mixed with general household waste. For proper disposal
or treatment, recovery and recycling, please take these products to designated collection
points where they will be accepted on a free of charge basis. In some countries you may
be able to return your products to your local retailer upon the purchase of a new product.
on human health and the environment, which could otherwise arise from inappropriate waste handling.
Please contact your local authority for further details of your nearest collection point for WEEE.
Penalties may be applicable for the incorrect disposal of this product in accordance with national legislation.
If you need information or if you have any questions, please visit the Philips website at
www.philips.com or contact the consumer care center in your country. If there is no consumer
care center in your country, go to the local dealer.
7. Guarantee and service
E1
The inlet water temperature sensor
is abnormal.
Please contact consumer care.
The outlet water temperature sensor
is abnormal.
Please contact consumer care.
Dry heating alarm
EU
E5
Display panel malfunction. Please contact consumer care.
Error Code What does it mean Solutions
All rights reserved.
Philips and the Philips Shield Emblem are registered trademarks of
This product has been manufactured by and is sold under the responsibility of
Speci�cations are subject to change without notice
Register your product and learn more via the website link below:
www.philips.com/water
