Dryer
User manual
DVE(G)55CG7500*/DVE(G)55CG7100*
Untitled-4 1 2023-03-21 11:43:25
English
English2
Contents
Safety information
4
What you need to know about the safety instructions 4
Important safety symbols 4
CALIFORNIA PROPOSITION 65 WARNING 7
Important safety precautions 8
Warnings 9
Cautions 9
Regulatory notice
11
FCC Notice 11
IC Notice 12
Open Source Announcement 13
Installation requirements
14
Key installation requirements 14
Location considerations 14
Ducting requirements 18
Exhausting requirements 19
Gas requirements 20
Electrical requirements 21
Installation
23
What’s included 23
Step-by-step installation 25
Vent blockage test 32
Exhaust ducting guide 34
Switching the door position 34
Before you start
37
Sort and load 37
Functional prerequisite 37
RACK DRY (applicable models only) 38
Untitled-4 2 2023-03-21 11:43:25
English
English 3
Operations 40
Control panel 40
Simple steps to start 44
Cycle overview 44
Cycle chart 46
Cycle guide 48
Special features 49
SmartThings 51
Maintenance
52
Vent Sensor (DVE(G)55CG7500* models only) 52
Cleaning 53
Troubleshooting
54
Checkpoints 54
Information codes 57
Specifications
58
Fabric care chart 58
Protecting the environment 59
Specification sheet 59
Untitled-4 3 2023-03-21 11:43:25
English
SAVE THESE INSTRUCTIONS
English4
Safety information
Congratulations on your new Samsung dryer. This manual contains important information on the
installation, use and care of your appliance. Please take some time to read this manual to take full
advantage of your dryer’s many benefits and features.
What you need to know about the safety instructions
Please read this manual thoroughly to ensure that you know how to safely and efficiently operate the
extensive features and functions of your new appliance. Please store the manual in a safe location close
to the appliance for future reference. Use this appliance only for its intended purpose as described in this
instruction manual.
Warnings and Important Safety Instructions in this manual do not cover all possible conditions and
situations that may occur. It is your responsibility to use common sense, caution and care when installing,
maintaining and operating your dryer.
Because the following operating instructions cover various models, the characteristics of your dryer may
differ slightly from those described in this manual and not all warning signs may be applicable. If you have
any questions or concerns, contact your nearest service center or find help and information online at www.
samsung.com.
Important safety symbols
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury, death and/or property damage.
CAUTION
Hazards or unsafe practices that may result in personal injury and/or property damage.
NOTE
Indicates that a risk of personal injury or material damage exists.
These warning signs are here to prevent injury to yourself and others.
Please follow them explicitly.
After reading this manual, store it in a safe place for future reference.
Read all instructions before using the appliance.
As with any equipment that uses electricity and moving parts, potential hazards exist. To safely operate
this appliance, familiarize yourself with its operation and exercise care when using it.
Untitled-4 4 2023-03-21 11:43:25
English
SAVE THESE INSTRUCTIONS
English 5
WARNING - Risk of Fire
• Clothes dryer installation must be performed by a qualified
installer.
• Install the clothes dryer according to the manufacturer’s
instructions and local codes.
• Do not install a clothes dryer with flexible plastic venting materials.
If flexible metal (foil type) duct is installed, it must be of a specific
type identified by the appliance manufacturer as suitable for
use with clothes dryers. Flexible venting materials are known to
collapse, be easily crushed, and trap lint. These conditions will
obstruct clothes dryer airflow and increase the risk of fire.
• Do not install a booster fan in the exhaust duct.
• To reduce the risk of severe injury or death, follow all installation
instructions.
• Save these instructions.
Untitled-4 5 2023-03-21 11:43:25
English
SAVE THESE INSTRUCTIONS
Safety information
English6
WARNING - To reduce the risk of fire or explosion:
• Do not dry items that have been previously cleaned, washed,
soaked, or spotted with gasoline, dry cleaning solvents, or other
flammable or explosive substances. They emit vapors that could
ignite or explode. Any material that has been in contact with a
cleaning solvent or flammable liquids or solids should not be placed
in the dryer until all traces of these flammable liquids or solids and
their fumes have been removed. There are many highly flammable
items used in homes, such as acetone, denatured alcohol, gasoline,
kerosene, some liquid household cleaners, some spot removers,
turpentine, waxes, and wax removers.
• Items containing foam rubber (which may be labeled latex foam)
or similarly textured rubberlike materials must not be dried on
a heat setting. Heated foam rubber materials can, under certain
circumstances, ignite spontaneously.
WARNING - Fire or explosion hazard
• Failure to follow safety warnings exactly could result in serious
injury, death or property damage.
• Do not store or use gasoline or other flammable vapors and liquids
near this or any other appliance.
• Installation and service must be performed by a qualified installer,
service agency, or the gas supplier.
• Do not install a booster fan in the exhaust duct.
Untitled-4 6 2023-03-21 11:43:25
English
SAVE THESE INSTRUCTIONS
English 7
WARNING - What to do if you smell gas:
• Do not try to light any appliance.
• Do not turn on the appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Clear the room, building or area of all occupants.
• Immediately call your gas supplier from a neighbor’s phone. Follow
the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
CALIFORNIA PROPOSITION 65 WARNING
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
Untitled-4 7 2023-03-21 11:43:25
English
SAVE THESE INSTRUCTIONS
Safety information
English8
Important safety precautions
WARNING
To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic
precautions, including the following:
1. Read all instructions before using this appliance.
2. Do not dry articles that have been previously cleaned in, washed in, soaked in, or spotted with gasoline,
dry-cleaning solvents, or other flammable or explosive substances, as they give off vapors that could
ignite or explode.
3. Do not use the dryer to dry clothes which have traces of any flammable substance, such as vegetable
oil, cooking oil, machine oil, flammable chemicals, paint thinner, etc., or anything containing wax or
chemicals, such as mops and cleaning cloths. Flammable substances may cause the fabric to catch fire
by itself.
4. Do not store or use gasoline or other flammable vapors and liquids near this or any other appliance.
5. Do not allow children to play on or in the appliance. Close supervision of children is necessary when the
appliance is used near children.
6. Before the appliance is removed from service or discarded, remove the door to the drying compartment.
7. Do not reach into the appliance if the drum is moving.
8. Do not install or store this appliance where it will be exposed to the weather.
9. Do not tamper with internal controls.
10. Do not repair or replace any part of the appliance or attempt any service unless specifically
recommended in the user-maintenance instructions or in published user-repair instructions that you
understand and have the skills to carry out.
11. Do not use fabric softeners or products to eliminate static unless recommended by the manufacturer of
the fabric softener or product.
12. Clean the lint screen before or after each load.
13. Do not use heat to dry articles containing foam rubber or similarly textured rubber-like materials.
14. Keep area around the exhaust opening and adjacent surrounding areas free from the accumulation of
lint, dust, and dirt.
15. The interior of the appliance and exhaust duct should be cleaned periodically by qualified service
personnel.
16. Do not place items exposed to cooking oils in your dryer. Items contaminated with cooking oils may
contribute to a chemical reaction that could cause a load to catch fire. To reduce the risk of fire due to
contaminated loads, the final part of a tumble dryer cycle occurs without heat (cool down period). Avoid
stopping a tumble dryer before the end of the drying cycle unless all items are quickly removed and
spread out so that the heat is dissipated.
17. This appliance must be grounded. See “Electrical requirements” and ”Grounding” in “Installation”
section.
Untitled-4 8 2023-03-21 11:43:25
English
SAVE THESE INSTRUCTIONS
English 9
18. Do not allow children to play on or in the appliance. Close supervision of children is necessary when the
appliance is used near children.
19. Do not insert your hand under the dryer.
- This may result in injury.
20. Take care that children’s fingers are not caught in the door when closing it.
- This may result in injury.
21. The control board and inlet valve are intentionally not grounded and may present a risk of electric
shock only during servicing.
- Do not contact these parts while the appliance is energized.
Warnings
WARNING
• Ensure pockets are free of small, irregularly shaped hard objects and foreign material, i.e. coins, knives,
pins, etc. These objects could damage your dryer.
• Gas leaks may occur in your system, resulting in a dangerous situation.
Cautions
CAUTION
• Do not allow children or pets to play on, in, or in front of the appliance. Close supervision is necessary
when the appliance is used near children and pets.
• Before discarding or removing your dryer from service, remove the door to the drying compartment to
prevent children or animals from becoming trapped inside.
• Do not reach into the appliance when the drum is moving.
• Do not install or store this appliance where it will be exposed to the weather.
• Do not tamper with the controls.
• Do not repair, replace, or attempt to service any part of the appliance unless specifically instructed to in
the user-repair instructions and you have the understanding and skills to carry out the procedure.
• Do not use fabric softeners or products to eliminate static unless the softener or product is
recommended for dryer use by the manufacturer of the fabric softener or product.
• Clean the lint screen before or after each load.
• Keep the area around the exhaust opening and surrounding areas free from lint, dust, and dirt.
• The interior of the dryer and exhaust duct should be cleaned periodically by qualified service personnel.
• This appliance must be properly grounded. Never plug the power cord into a receptacle that is
not grounded adequately or not in accordance with local and national codes. See the installation
instructions for information about grounding this appliance.
• Do not sit on top of the dryer.
• Do not dry clothing with large buckles, buttons, or other heavy metal or solid objects.
• Gas leaks may not be detected by smell alone.
Untitled-4 9 2023-03-21 11:43:26
English
SAVE THESE INSTRUCTIONS
Safety information
English10
• Gas suppliers recommend you purchase and install a UL-approved gas detector.
• Install and use in accordance with the manufacturer’s instructions.
• Do not place items in your dryer that have been spotted or soaked with vegetable oil or cooking oil. Even
after being washed, these items may contain significant amounts of these oils.
• Residual oil on clothing can ignite spontaneoulsy. The potential for spontaneous combustion increases
when items containing vegetable oil or cooking oil are exposed to heat. Heat sources such as your dryer
can warm these items, allowing an oxidation reaction in the oil to occur. Oxidation creates heat. If this
heat cannot escape, the items can become hot enough to catch fire. Piling, stacking, or storing these
kinds of items may prevent heat from escaping and can create a fire hazard.
• All washed and unwashed fabrics that contain vegetable oil or cooking oil can be dangerous.
Washing these items in hot water with extra detergent will reduce, but not eliminate, the hazard.
Always use the Cool Down cycle for these items to reduce their temperature. Never remove these items
from the dryer hot or interrupt the drying cycle until the items have run through the Cool Down cycle.
Never pile or stack these items when they are hot.
Untitled-4 10 2023-03-21 11:43:26
English
SAVE THESE INSTRUCTIONS
English 11
Regulatory notice
FCC Notice
CAUTION
Any changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
This device complies with Part 15 of FCC Rules. Operation is Subject to following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received including interference that cause undesired
operation.
For products sold in the US and Canadian markets, only channels 1–11 are available. You cannot select any
other channels.
FCC STATEMENT:
This equipment has been tested and found to comply within the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorienting or relocating the receiving antenna
• Increasing the separation between the equipment and receiver
• Connecting the equipment to an outlet that is on a different circuit than the radio or TV.
• Consulting the dealer or an experienced radio/TV technician for help.
Untitled-4 11 2023-03-21 11:43:26
English
SAVE THESE INSTRUCTIONS
Regulatory notice
English12
IC Notice
The term “IC” before the radio certification number only signifies that Industry Canada technical
specifications were met. Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that may cause undesired operation of
the device.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme á la norme NMB-003 du Canada.
For products sold in the US and Canadian markets, only channels 1–11 are available. You cannot select any
other channels.
IC RADIATION EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated so there is at least 8 inches (20 cm)
between the radiator and your body. This device and its antenna(s) must not be colocated or operated in
conjunction with any other antenna or transmitter.
Untitled-4 12 2023-03-21 11:43:26
English
SAVE THESE INSTRUCTIONS
English 13
Open Source Announcement
The software included in this product contains open source software. You may obtain the complete
corresponding source code for a period of three years after the last shipment of this product by contacting
our support team via http://opensource.samsung.com (Please use the "Inquiry" menu.)
It is also possible to obtain the complete corresponding source code in a physical medium such as a CD-
ROM; a minimal charge will be required.
The following URL http://opensource.samsung.com/opensource/SMART_AT_051/seq/0 leads to the
open source license information as related to this product. This offer is valid to anyone in receipt of this
information.
NOTE
Hereby, Samsung Electronics, declares that the radio equipment type appliance is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet
address: The official Declaration of conformity may be found at http://www.samsung.com, go to Support >
Search Product Support and enter the model name.
Wi-Fi max transmitter power : 20 dBm at 2.412 GHz – 2.472 GHz
Untitled-4 13 2023-03-21 11:43:26
English
English14
Installation requirements
Read through the following instructions before installing the dryer, and keep this manual for future
reference.
WARNING
Certain internal parts are intentionally not grounded and may present a risk of electric shock only during
servicing. Service Personnel - Do not contact the following parts while the appliance is energized: Control
board and inlet valve.
Key installation requirements
• A grounded electrical outlet.
• A power cord for electric dryers (except in Canada).
• Gas lines (for gas models) that must meet national and local regulations.
• An exhaust system made of rigid metal or flexible stiff-walled metal exhaust ducting.
WARNING
Remove the door from all discarded appliances to prevent a child from suffocating.
Location considerations
• Adequate clearances between the dryer and adjacent walls or other surfaces.
• Adequate air circulation for ventilation and gas combustion.
• Away from water and weather.
WARNING
• Make sure to exhaust the dryer outdoors to reduce the risk of fire.
• Keep the dryer area clear of combustible materials, gasoline, and other flammable vapors and liquids.
• Do not install other fuel-burning appliances around or in the same place as the dryer.
• Place the dryer at least 18 in. (460 mm) above the floor for garage installation.
Untitled-4 14 2023-03-21 11:43:26
English
English 15
Dimensions
U
9
A
Type Front loading dryer
Model DVE(G)55CG7500* / DVE(G)55CG7100*
Dimensions
(in. (mm))
A. Overall height 45.8 (1163)
B. Width 27.0 (686)
C. Depth with door open 50.1 (1273)
D. Depth 30.2 (768)
Untitled-4 15 2023-03-21 11:43:26
English
Installation requirements
English16
Clearance requirement
This clearance requirement is applicable for dryers only.
NOTE
• For washer's clearance requirement, see the washer's user manual.
• If the washer and dryer have different clearance requirements, use the one with the larger value.
Alcove or closet installations
WARNING
• The dryer must be exhausted to the outside to reduce the risk of fire when installed in an alcove or
closet.
• No other fuel-burning appliance should be installed in the same closet as the dryer.
• Place the dryer at least 18 in. (460 mm) above the floor for garage installation.
Minimum clearance for stable operation:
Sides Top Rear Front
1 in. / 25 mm 17 in. / 432 mm 4.0 in. / 102 mm 1 in. / 25 mm
If both the washer and a dryer are installed in the same location, the front of the alcove or closet must have
two unobstructed air openings for a combined minimum total area of 72 in.² (465 cm²).
Untitled-4 16 2023-03-21 11:43:26
English
English 17
This clearance requirement is applicable for washer and dryer pair installation.
Side by side installation
A A C D
B
A 1 in. (25 mm)
B 21 in. (533 mm)
C 1 in. (25 mm)
D
4.0 in. / 102 mm
Untitled-4 17 2023-03-21 11:43:26
English
Installation requirements
English18
Ducting requirements
Recommended
Use only for short-run
installation
Weather hood type
4” (10.2 cm) 2.5” (6.4 cm)
No. of 90° elbows Rigid Rigid
0 80 ft. (24.4 m) 74 ft. (22.6 m)
1 68 ft. (20.7 m) 62 ft. (18.9 m)
2 57 ft. (17.4 m) 51 ft. (15.5 m)
3 47 ft. (14.3 m) 41 ft. (12.5 m)
NOTE
* Use a 4-inch (10.2 cm) diameter rigid aluminum or galvanized steel duct.
If you integrate the dryer’s vent system with an existing exhaust system, make sure:
• The exhaust system meets all applicable local, state, and national regulations.
• Not to use a flexible plastic duct.
• To regularly check and clean all lint buildup from inside the existing ducts.
• The duct is not kinked or crushed.
• The exhaust hood damper opens and closes freely.
Manometer measurements
The static pressure in any exhaust system must not exceed 0.83 inches of water column or be less than 0.
Note that these values are measured with the dryer running with a manometer presented to the exhaust
duct that connects to the dryer. The dryer tumbler must be empty and lint filter clean.
Untitled-4 18 2023-03-21 11:43:26
English
English 19
Exhausting requirements
The dryer must not be exhausted into a chimney,
a wall, a ceiling, an attic, a crawl space, or a
concealed space of a building. Exhausting the
dryer to the outside will prevent large amounts of
lint and moisture from being blown into the room.
In the United States and Canada
• All dryers must be exhausted to the outside.
• The required exhaust duct is 4 inches (10.2 cm)
in diameter.
• See “Ducting requirements” in the
“Installation” section for the maximum duct
length and number of bends that can be used.
• The total length of flexible metal duct must
not exceed 7’ 10 1/2” (2.4 m).
• Do not assemble the duct with screws or other
fastener means that extend into the duct and
catch lint.
• For the United States only: Use only those foil-
type flexible ducts, if any, specifically identified
for use with the appliance by the manufacturer
and that comply with the Outline for Clothes
Dryer Transition Duct. Use Subject 2158A.
Outside the United States and Canada
• Refer to the local codes.
WARNING
• You must exhaust the dryer to the outside to
reduce the risk of fire when you install the
dryer in an alcove or closet.
• Do not use a plastic or non-metal flexible duct.
• If your existing ductwork is plastic, non-metal,
or combustible, replace it with metal.
• Use only a metal exhaust duct that is non-
flammable to ensure containment of exhaust
air, heat, and lint.
Untitled-4 19 2023-03-21 11:43:27
English
Installation requirements
English20
Gas requirements
WARNING
• Use only natural or LP (liquid propane) gases.
• The installation must be conformed with local
codes, or in the absence of local codes, with the
national fuel gas code, ANSI Z223.1/NFPA 54,
latest revision (for the UNITED STATES), or with
the natural gas and propane installation code,
CSA B149.1 (for Canada).
• Gas dryers are equipped with a burner vent for
use with natural gas. If you plan to use your
dryer with LP (liquid propane) gas, it must be
converted for safe and proper performance by
a qualified service technician. (LNG models
only)
You must check the burner of your model and
use the proper LP Kit accordingly. To check the
detail information of the burner, open the door
and check the rating label location on the door
frame.
- 20,000 BTU: LPKIT-4/XAA (DC98-04114A)
- 22,000 BTU: LPKIT-3/XAA (DC99-00792A)
• A 1/2” (1.27 cm) gas supply line is
recommended and must be reduced to connect
to the 3/8” (1 cm) gas line on your dryer. The
National Fuel Gas Code requires that an
accessible, approved manual gas shut-off valve
be installed within 6” of your dryer.
• Gas dryers installed in residential garages
must be raised 18 inches (46 cm) above the
floor.
• Additionally, a 1/8” (0.3 cm) N.P.T. (National
Pipe Thread) plugged tapping, accessible
for test gauge connection, must be installed
immediately upstream of your dryer’s gas
supply connection.
• Your dryer must be disconnected from the gas
supply pipe system during any pressure testing
of the system.
• Do not reuse old flexible metal gas lines.
Flexible gas lines must be designed and
certified by the standard for connectors for Gas
Appliances, ANSI Z21.24 • CSA 6.10.
NOTE
• Your dryer uses an automatic ignition system
to ignite the burner. There is no constant
burning pilot.
• Any pipe joint compound used must be
resistant to the action of any liquefied
petroleum gas.
• As a courtesy, most local gas utilities will
inspect a gas appliance installation.
Commonwealth of Massachusetts
installation instructions
Your dryer must be installed by a licensed plumber
or gas fitter. A “T” handle manual gas valve must
be installed in the gas supply line to your dryer. If a
flexible gas connector is used to install your dryer,
the connector can be no longer than 3’ (36”).
WARNING
• Gas leaks may occur in your system, creating a
dangerous situation.
• Gas leaks may not be detected by smell alone.
• Gas suppliers recommend you purchase and
install a UL-approved gas detector.
• Install and use in accordance with the
manufacturer’s instructions.
Untitled-4 20 2023-03-21 11:43:27
English
English 21
Electrical requirements
The wiring diagram is located on the plate under
the control panel or rear frame.
WARNING
• Improperly connecting the equipment
grounding conductor can result in a risk
of electric shock. Check with a qualified
electrician or serviceman if you are in doubt as
to whether your dryer is properly grounded. Do
not modify the plug provided with your dryer –
if it doesn’t fit the outlet, have a proper outlet
installed by a qualified electrician.
• To prevent unnecessary risk of fire, electrical
shock, or personal injury, all wiring and
grounding must be done in accordance with
local codes, or in the absence of local codes,
in accordance with the National Electrical
Code, ANSI/NFPA No. 70-Latest Revision (for
the U.S.) or the Canadian Electrical Code CSA
C22.1 – Latest Revisions and local codes and
ordinances. It is your responsibility to provide
adequate electrical service for your dryer.
• All gas installations must be done in
accordance with the national Fuel Code
ANSI/Z2231 – Latest Revision (for the U.S.) or
CAN/CGA – B149 Installation Codes – Latest
Revision (for Canada) and local codes and
ordinances.
Grounding
This dryer must be grounded. In the event of
malfunction or breakdown, the ground will reduce
the risk of electrical shock by providing a path of
least resistance for the electrical current.
Gas models
WARNING
• Your dryer has a cord with an equipment-
grounding conductor and a grounding plug.
The plug must be plugged into an appropriate
outlet that is properly installed and grounded
in accordance with all local codes and
ordinances.
• Do not modify the plug provided with your
dryer – if it doesn’t fit the outlet, have a proper
outlet installed by a qualified electrician.
• Do not connect the ground wire to plastic
plumbing lines, gas lines, or hot water pipes.
Electric models
WARNING
• Your dryer has an optional cord with an
equipment-grounding conductor and a
grounding plug. This cord is sold separately.
• The plug must be plugged into an appropriate
outlet that is properly installed and grounded
in accordance with all local codes and
ordinances.
• Do not modify the plug provided with your
dryer – if it doesn’t fit the outlet, have a proper
outlet installed by a qualified electrician.
• If a power cord is not used and the electric
dryer is to be permanently wired, the dryer
must be connected to a permanently grounded
metal wiring system, or an equipment
grounding conductor must be run with the
circuit conductors and connected to the
equipment grounding terminal or lead on the
dryer.
Untitled-4 21 2023-03-21 11:43:27
English
Installation requirements
English22
Electrical connections
Before operating or testing, follow all grounding
instructions in the “Grounding” section. An
individual branch (or separate) circuit serving only
your dryer is recommended.
Do not use an extension cord.
Gas models – U.S. and Canada
A 120 volt, 60 Hz AC approved electrical service
with a 15-ampere fuse or circuit breaker is
required.
Electric models – U.S. only
Most U.S. dryers require a 120 / 240 volt, 60 Hz
AC approved electrical service. Some require 120
/ 208 volt, 60 Hz approved electrical service. The
electric service requirements can be found on the
data label located behind the door. A 30-ampere
fuse or circuit breaker on both sides of the line is
required.
• If a power cord is used, the cord should be
plugged into a 30-ampere receptacle.
• The power cord is not provided with U.S.
electric model dryers. This cord is sold
separately.
WARNING
Risk of Electric Shock
When local codes allow, you can connect the
dryer’s electrical supply with a new power supply
cord kit, marked for use with a dryer, that is
U.L. listed and rated at a minimum of 120 / 240
volts, 30-amperes with three No. 10 copper wire
conductors terminated with closed loop terminals,
open-end spade lugs with turned up ends, or with
tinned leads.
• Do not reuse a power supply cord from an old
dryer. The power cord electric supply wiring
must be supported at the dryer cabinet by a
suitable UL-listed strain relief.
• Grounding through the neutral conductor
is prohibited for (1) new branch-circuit
installations, (2) mobile homes, (3) recreational
vehicles, and (4) areas where local codes
prohibit grounding through the neutral
conductor. (Use a 4-prong plug for a 4 wire
receptacle, NEMA type 14-30R.)
Electric models – Canada Only
A 120 / 240 volt, 60 Hz AC approved electrical
service fused through a 30-ampere fuse or circuit
breaker on both sides of the line is required.
NOTE
All Canadian models are shipped with the power
cord attached. The power cord should be plugged
into a 30-ampere receptacle. In Canada, you may
convert a dryer to 120 / 208 volts.
Untitled-4 22 2023-03-21 11:43:27
English
English 23
Installation
This dryer must be installed by a qualified technician. The installer is responsible for connecting the dryer
to the main power while observing the relevant safety regulations of your area.
What’s included
Make sure all the parts are included in the product package. If you have a problem with the dryer or the
parts, contact a local Samsung customer center or the retailer.
01
02
03
04
05
01 Control panel 02 Worktop 03 Lint filter
04 Door 05 Exhaust duct
Untitled-4 23 2023-03-21 11:43:27
English
Installation
English24
Parts supplied
Y-connector Water hose (Canadian elec.
models only)
Short water hose
Tools needed for installation
Pliers Cutting knife Pipe wrench (gas
models only)
Nut driver
Level Phillips screwdriver Duct tape Wrench
LPG-safe compound
or Teflon Tape (for gas
installation)
Gloves
WARNING
Packing materials can be dangerous to children. Keep all packing materials (plastic bags, polystyrene, etc.)
out of children’s reach.
Untitled-4 24 2023-03-21 11:43:28
English
English 25
Step-by-step installation
Make sure you have a qualified technician install the dryer. Step by step installation instructions start
below.
• Do not remove the protective film on the door before completing the product installation. If you remove
the protective film before the installation is complete, the door may get scratched or damaged during
installation.
• Make sure the installation location allows enough space for the dryer door to be fully open.
STEP 1 Install the exhaust system
1. Select a location and move the dryer to the site. For easy access, we recommend you install the dryer in
the same location as your washer.
2. To change the door direction, see “Switching the door position” on page 34.
3. Install the exhaust system as instructed in the “Exhaust ducting guide” section.
CAUTION
Before installing your dryer, remove the packing in the duct.
NOTE
• To move the dryer easily, lay two of the carton cushion-from the packaging on the floor. Tip the dryer on
its side so it lies across both cushion-tops. Push the dryer so that it is near its final location, and then set
the dryer upright.
• Secure room around the dryer to facilitate ducting and wiring.
STEP 2 Connect the gas line (for gas models)
Before connecting the gas line, make sure you have read the “Gas requirements” section on page 20.
1. Remove the protective cap from the gas pipe.
2. Apply an LPG (Liquefied Petroleum Gas)-safe compound or 1.5 wraps of Teflon tape to all threaded
connections.
3. Connect the gas supply to the dryer. An additional fitting is required to connect the 3/4” (1.9 cm) female
thread end of a flexible connector to the 3/8” (1 cm) male threaded end on the dryer. Tighten up the
fitting over all threads.
4. Turn on the gas supply, and check for any leaks using a soap solution. If a leak is found, tighten the
connections and try again. Do not use an open flame to check for gas leaks.
Untitled-4 25 2023-03-21 11:43:28
English
Installation
English26
STEP 3 Connect the electrical wiring (for electric models)
Before connecting the electrical wiring, make sure you have read the “Electrical requirements” section on
page 21.
3-wire system
A B C L2 L1
D
E
A. External ground connector
B. Neutral grounding wire (white)
C. Center silver-colored terminal block
screw
D. Neutral wire (white or center wire)
E. 3/4” (1.9 cm) UL-listed strain relief
1. Loosen or remove the screws from the center
terminal block.
2. Connect the neutral wire (white or center wire) of the
power cable to the center, silver-colored terminal
screw of the terminal block. Tighten the screws.
3. Connect the other wires to outer terminal block
screws. Tighten the screws.
4. Tighten the strain relief screws.
5. Insert the terminal block cover into the rear panel of
the dryer. Then, secure the cover with a hold-down
screw.
CAUTION
• To convert from the 4-wire system to 3-wire system,
connect the ground strap to the terminal block
support to ground the dryer frame to the neutral
conductor.
• Ring-type terminals are recommended. If using strap
terminals, make sure they are tightened.
• Connect the power cord and check L1/L2/N voltage.
If the voltage is low, it may not heat properly. Review
the “Electrical requirements” section on page 21 if
needed.
Untitled-4 26 2023-03-21 11:43:28
English
English 27
4-wire system
F
A B C L2 L1
D
E
A. External ground connector
B. Neutral grounding wire (white)
C. Center silver-colored terminal block
screw
D. Neutral wire (white or center wire)
E. ¾” (1.9 cm) UL-listed strain relief
F. Neutral wire (white or center wire)
1. Remove the external ground connector’s screw and
connect the ground wire (green or unwrapped) of the
power cable to the screw.
CAUTION
- To connect the ground wire to the neutral position
without through contact A (cabinet ground),
contact a technician. This is not user serviceable.
- Ring-type terminals are recommended. If using
strap terminals, make sure they are tightened.
2. Loosen or remove the screws from the center
terminal block.
3. Connect the neutral wire (white or center wire)
and ground wire (white) to the center screw of the
terminal block. Tighten the screw.
4. Connect the other wires to the outer terminal block
screws. Tighten the screws.
5. Tighten the strain relief screws.
6. Insert the tab of the terminal block cover into the
rear slot of the dryer. Secure the cover with a hold-
down screw.
CAUTION
Connect the power cord and check L1/L2/N voltage. If the voltage is low, it may not heat properly. Review
the “Electrical requirements” section on page 21 if needed.
WARNING
• All U.S. models are designed for a 3-wire system connection. The dryer frame is grounded to the
neutral conductor at the terminal block. A 4-wire system connection is required for new or remodeled
construction, mobile homes, or if local codes do not permit grounding through neutral. If you use the
4-wire system, you cannot ground the dryer frame to the neutral conductor at the terminal block.
• Remove the terminal block cover plate. Insert the power cord with a UL-listed strain relief through the
hole provided in the cabinet near the terminal block.
• A strain relief must be used. Do not loosen the nuts already installed on the terminal block. Be sure
they are tight. Use a 3/8” (1 cm) deep well socket.
• Since january 1, 1996, The national electric code requires that new wiring (not existing) utilize a 4-wire
connection to this dryer.
Untitled-4 27 2023-03-21 11:43:29
English
Installation
English28
STEP 4 Connect the water hose
The dryer must be connected to a cold water tap using the provided water hoses.
1. Close the cold water tap. If you have a washer’s cold
water hose attached to the cold water tap, unscrew
and remove the hose. Then, connect the female end
of the Y-connector to the cold water tap.
2. Connect the straight end of the water hose to the
Y-connector.
3. Using pliers, tighten the coupling an additional two-
thirds turn. Do not overtighten because the coupling
may be damaged.
4. Connect the angled end of the water hose to the
filling valve at the bottom of the rear frame. Turn the
coupling manually until it is tight.
5. Using pliers, tighten the coupling an additional two-
thirds turn. Do not overtighten because the coupling
may be damaged.
6. If you detached the cold water hose from your
washer, attach the hose to the open end of the
Y-connector, tighten the coupling by hand until it is
tight, and then, using a pliers, tighten an additional
two-thirds turn.
7. Open the cold water tap, and then check for any
leaks.
If the Y-connector cannot be directly connected to the cold water tap, use the short hose. See the “Using
the short hose as an extension” section on page 29.
Untitled-4 28 2023-03-21 11:43:29
English
English 29
Using the short hose as an extension
B
A
C
1. Close the cold water tap. If you have a washer’s cold
water hose attached to the cold water tap, unscrew
and remove the hose. Then, connect the short hose
(B) to the cold water tap. Turn the coupling by hand
until it is tight.
2. Using pliers, tighten the coupling an additional two-
thirds turn. Do not overtighten because the coupling
may be damaged.
3. Connect the Y-connector (A) to the brass male end
of the short hose. Turn the coupling by hand until it
is tight.
4. Using pliers, tighten the coupling an additional two-
thirds turn. Do not overtighten because the coupling
may be damaged.
5. Connect the angled end of the water hoses (C) to the
filling valve at the bottom of the rear frame. Turn the
coupling manually until it is tight.
6. Using pliers, tighten the coupling an additional two-
thirds turn. Do not overtighten because the coupling
may be damaged.
7. If you detached the cold water hose from your
washer, attach the hose to the free end of the
Y-connector, tighten the coupling by hand until it is
tight, and then, using a pliers, tighten an additional
two-thirds turn.
8. Open the cold water tap, and then check for any
leaks.
Untitled-4 29 2023-03-21 11:43:29
English
Installation
English30
STEP 5 Level the dryer
To ensure optimal performance, the dryer must be level.
A
B
Using a level (A), check if the dryer is level side to side
and then front to back. If the dryer is not level, turn
the leveling feet (B) clockwise to lower the dryer or
counterclockwise to raise the dryer.
A B
NOTE
• To set the dryer to the same height as your washer,
fully retract (A) the leveling feet by turning them
counterclockwise, then loosen (B) the feet by turning
them clockwise. Once the dryer is the same height as
the washer, follow the directions above to level the
dryer.
• Adjust the leveling feet only as much as necessary to
level the dryer. Extending the leveling feet more than
necessary can cause the dryer to vibrate.
Untitled-4 30 2023-03-21 11:43:29
English
English 31
STEP 6 Power on (for gas models)
Make sure all gas connections, the exhaust line, and all wiring is connected correctly. Then, plug the power
cord into a power source and check the dryer’s installation and operation using the final checklist in Step 7
below.
STEP 7 Final check
When installation is complete, confirm that:
• The dryer is plugged into an electrical outlet and grounded properly.
• The exhaust ductwork is connected, and the joints are taped.
• You have used rigid or stiff-walled flexible metal duct material, not plastic flexible duct.
• The dryer is level and is sitting firmly on the floor.
• The dryer starts, runs, heats, and shuts off properly.
For gas models:
• The gas is supplied properly with no leaks (For gas models only).
CAUTION
The burner may not ignite initially due to air in the gas line. Allowing your dryer to operate on a heat setting
will purge the line. If the gas does not ignite within 5 minutes, turn your dryer off and wait 5 minutes. Be
sure the gas supply to your dryer has been turned on. To confirm gas ignition, check the exhaust for heat.
Untitled-4 31 2023-03-21 11:43:29
English
Installation
English32
Vent blockage test
After the dryer is installed, start the Vent Blockage Test to check if the duct system is properly installed.
The Vent Blockage Test automatically detects the status of the ducts and reports any blockage or problems.
Proper ducting can reduce drying time and save energy.
NOTE
The Vent Blockage Test must run when the dryer is cool. If the dryer warms up after the installation check,
run the AIR FLUFF cycle for several minutes to reduce its internal temperature.
Running the vent blockage test
1. Make sure the drum is empty, and then close the door. (If there are any clothes or other items in the
drum, the test will not give accurate results.)
2. Press the Power button to turn the dryer on, then simultaneously press and hold the Adjust Time
and Dryness buttons for 3 seconds. “InS or In” appears in the dryer’s display. (If you have started other
procedures before the Vent Blockage Test, the dryer will not enter the Vent Blockage Test mode.)
3. Press the Start/Pause (Hold to Start) button. The Vent Blockage Test starts immediately. During the
test, the number indicator makes a circle in 6 clockwise steps. The test takes about 2 minutes. Do not
open the door during the test.
4. After 2 minutes, when the test is complete, the results are displayed and the dryer sounds a tone. If
status of the duct system is normal, “0” appears and the dryer sounds a completion tone. If the duct
system cannot exhaust properly, the check code appears, and the dryer sounds an alarm tone. For
description about the code, see the “Installation check codes” section on page 33.
If there are any other problems, an information code appears in the display. For description about the
code, see the “Information codes” section on page 57.
- To stop or cancel the Vent Blockage Test, press the Power button to turn off your dryer.
- The results remain on the display for about 5 minutes and then automatically turn off. You can turn
the results off immediately by pressing the Power button.
NOTE
• During or after the test, the internal drum is hot. Use caution to prevent burns. The Vent Blockage Test
is used to check for problems in the current duct system when the dryer is installed for the first time.
• If the test result displays check code (the duct system is blocked ), refer to the “Ducting requirements”
section on page 18 and the “Exhaust ducting guide” section below, and then take proper measures to
correct any problems. If the test is suspended, it could result in incorrect results. Follow the proper
procedures when testing the dryer.
• Even if the test result is normal (“End or 0”), the duct system could be blocked slightly. Properly install
all duct work according to the installation instructions in this manual.
Untitled-4 32 2023-03-21 11:43:30
English
English 33
Installation check codes
Check code Meaning Solution
0 Vent condition is good.
Clg (Cg) The vent is clogged.
1. Clean the lint filter.
2. Check your vent condition. (Refer to the
“Ducting requirements” section)
* You must take measures (such as
cleaning) through expert personnel.
C80 (C8)
About 80 % of the vent is clogged.
(This may decrease the drying
performance.)
C90 (C9)
Over 90 % of the vent is clogged.
(This may lead to poor drying performance
or cause malfunction)
Ct
The internal temperature of the dryer is
too low (below 32 °F (0 °C)) or too high
(over 104 °F (40 °C)) and therefore vent
blockage cannot be detected.
Leave the dryer at room temperature
(41~95 °F (5~35 °C)) for an hour and check
again.
tC Temperature sensor error Contact a service center.
C1
Unit is detecting items inside the drum or
there is an error on the dry sensor.
Remove items from the drum and check
again.
If the problem continues, contact a service
center.
dC Unit is detecting door is open
Close the door properly and check again.
If the problem continues, contact a service
center.
9C1 Abnormal voltage detected
Check the power connection. (Refer to the
“Connect the electrical wiring (for electric
models)” section)
If the problem continues, contact a service
center.
HC
Detection of abnormal temperature in
drum.
Check the power connection.
Check the vent condition if the problem
continue, contact a service center.
Untitled-4 33 2023-03-21 11:43:30
English
Installation
English34
Exhaust ducting guide
Ducting
1. Make sure the dryer is installed properly so the air exhausts freely.
2. Use 4-inch rigid metal ducts. Tape all joints including the dryer connection. Never use lint-trapping
screws.
3. To facilitate the exhaust, keep the ducts as straight as possible.
Cleaning
Clean all old ducts before installing the dryer, and make sure the vent flap opens and closes freely. We
recommend that you to clean the exhaust system annually or on a regular basis.
WARNING
• To prevent fire, do not use plastic, thin-foil, or non-metal flexible ducts of any kind.
• Do not use a poor exhaust system because it slows down the dryer’s performance.
• Do not use excessively long ducts that have multiple elbows.
• Do not use crushed or clogged venting or ducts.
Switching the door position
To reverse the direction of the door, we recommend that
you contact a qualified technician.
1. Put a soft rug on the floor to rest the door on after
you have removed it. This will prevent the door from
being scratched.
2. Unplug the power cord of the dryer.
3. Remove the four hinge screws from the door, and
then remove the door by lifting it up slightly.
4. Remove the two screws from the lever holder, and
then remove the holder cover.
5. Put the lever holder on the other side as shown, and
then tighten the screws. Install the holder cover on
the opposite side as shown.
Untitled-4 34 2023-03-21 11:43:30
English
English 35
6. Use a flat-head screwdriver to remove the two hinge
covers from the original side. Install the hinge covers
on the opposite side as shown.
B
7. Locate and remove the 10 screws as shown. Note that
screw B (x2) is longer than the others.
8. Remove the glass holder, and switch the positions of:
a. the hinge cover and the door handle.
b. the hinge holder and the glass-guide holder
9. Remove the door lever, and then move it to the other
side as shown.
Untitled-4 35 2023-03-21 11:43:30
English
Installation
English36
B
C
10. Remove the hole cover (C), and then insert and
tighten the glass holder using the removed 10
screws.
11. Install the hole cover on the opposite side as shown.
12. Reinstall the door on the front frame, and then
carefully insert and tighten the 4 hinge screws.
Untitled-4 36 2023-03-21 11:43:30
English
English 37
Before you start
Here are a few things you should know before starting your dryer.
Sort and load
• Put one wash load in the dryer at a time.
• Do not mix heavy and lightweight items
together.
• To improve drying efficiency for one or two
items, add a dry towel to the load.
• For best results, untangle items before
inserting them into the dryer. Tangled items
may degrade the drying efficiency or cause the
door to open.
• Overloading reduces the tumbling
performance, resulting in uneven drying and
wrinkling.
• Unless recommended on the care label, do not
dry woolens or fiberglass items.
• Avoid drying unwashed items.
• Do not dry items soiled with oil, alcohol,
gasoline, etc.
Functional prerequisite
Lint filter
A
To prevent a risk of fire, make sure to clean the lint filter
before or after every load.
1. Turn off the dryer.
2. Open the door and pull out the lint filter (A) from
inside the drum.
3. Remove the lint, and then clean the lint filter.
4. Reinsert the lint filter, and then close the door.
CAUTION
• Do not operate the dryer without the lint filter in
place.
• Do not use a damaged or broken lint filter. This may
reduce performance and/or cause fire.
Untitled-4 37 2023-03-21 11:43:31
English
Before you start
English38
RACK DRY (applicable models only)
Some models come with a drying rack which is inserted into the drum at the factory. If your model came
with a drying rack, remove the rack from the drum before you use the dryer for the first time. To remove the
rack, pull the rack straight up, and then take it out of the drum. Remove the drying rack from its packaging
and store the rack for later use.
A
If a drying rack is not provided, you can purchase it
at a local Samsung service center. (Part Code : DC93-
00374H)
To use the drying rack, follow these steps:
1. Insert the drying rack (A) inside the tumbler with the
filter handle to the front.
2. Insert the rear legs of the drying rack into the
recessed areas of the rear wall, and then press down
the middle of the drying rack to secure it in place.
3. Put items to dry on the rack. Make sure to leave
space between the items for air flow.
4. Press RACK DRY or other Cycle Setting according to
rack drying suggestions below, then select the drying
time.
5. When the items are dry, remove the them from the
dryer, and then remove the drying rack.
Untitled-4 38 2023-03-21 11:43:31
English
English 39
Drying rack drying suggestions
Item Cycle settings
Washable sweaters (fold sweater into same shape
as rack and lay it flat on the rack)
TIME DRY with the Low temperature setting
Stuffed toys (cotton or polyester fiber-filled)
Stuffed toys (foam or rubber-filled)
AIR FLUFFFoam rubber pillows
Sneakers
WARNING
• Make sure to unpack the drying rack before using it. Otherwise, the dryer can be damaged or its
performance diminished.
• Drying foam rubber, plastic, or rubber on a heat setting may damage the items and create a fire hazard.
Untitled-4 39 2023-03-21 11:43:31
English
English40
Operations
WARNING
To reduce the risk of fire, electric shock, or injury to persons, read the “Safety information” before operating
this appliance.
Control panel
DVE55CG7500*
02
01
03 04 05 06
07
08
09
12
13
10
11
DVG55CG7500*
02
01
03 04 05 06
07
08
09
12
13
10
11
DVE55CG7100*
02
01
03 04 05 06
07
08
09
12
13
10
11
Untitled-4 40 2023-03-21 11:43:31
English
English 41
DVG55CG7100*
02
01
03 04 05 06
07
08
09
12
13
10
11
01 Cycle Selector
Turn the Cycle Selector to select a desired cycle. When a cycle is selected,
the cycle indicator lights up.
•
Steam Cycles: The dryer sprays water into the drum to deodorize clothes
and reduce static electricity and wrinkles.
• Manual Dry: The drying time is fixed.
02 Digital Graphic
Display
Displays all cycle information, including the cycle time, information code,
and operating status.
03 Dryness
Press to select a dry level. You can select from 5 different options (Less to
More). Please refer to following recommendations to select the appropriate
dryness.
• For larger or bulkier loads, select More for complete dryness.
• For items that needs to lay flat or hang to dry, use Less to partially dry
items.
NOTE
This option is not available with REFRESH, STEAM SANITIZE⁺, ACTIVEWEAR,
TIME DRY, QUICK DRY, and AIR FLUFF.
04 Temp.
Temperature can only be adjusted in TIME DRY cycle.
Press to change the temperature of the current cycle. You can select from 5
different options (Low to High). Please select the appropriate temperature
depending on the items in the load.
•
High: For sturdy cottons or those labeled Tumble Dry.
• Medium: For permanent press, synthetics, lightweight cottons, or items
labeled Tumble Dry Medium.
• Low: For heat sensitive items labeled Tumble Dry Low or Tumble Dry
Warm. Provides the lowest heated drying temperature possible.
Untitled-4 41 2023-03-21 11:43:32
English
Operations
English42
05 Time
Press to adjust the drying time for the Manual Dry cycles. This is not
available with the Sensor Dry cycles because the dryer determines the
drying time by sensing the current moisture level of the load.
06 Wrinkle Prevent
Wrinkle Prevent provides approximately 180 minutes of intermittent
tumbling in unheated air at the end of the cycle to reduce wrinkling. Press
Wrinkle Prevent to activate this feature. The load is dry, and can be removed
at any time during the Wrinkle Prevent cycle.
07 Eco Dry
This function is available with NORMAL and TIME DRY.
With the Eco Dry activated, drying takes a longer time but the power
consumption is reduced.
The drying time can be extended by up to 3 times depending on the
temperature and load. (See the “Cycle chart” on page .)
08 Damp Alert
This alert is available for all Sensor Dry cycles except for ACTIVEWEAR.
Available dry levels are Normal, More, and Extra.
If a load contains mixed fabrics, the Damp Alert indicator blinks when
average dryness of the items in the load is 80 % dry. This lets you take items
that you don’t want fully dried or that dry quickly out of the dryer early while
letting others continue to dry.
09 Drum Light
Press to turn the interior lamp on or off. The lamp stays lit for 2 minutes after
it has turned on, regardless of whether the power is on or off or the door is
open or closed, and then turns off automatically.
10 Adjust Time
You can change the set time in the Manual Dry cycles. (QUICK DRY, TIME
DRY
, and AIR FLUFF) To change the cycle time, press or until the
desired time is displayed.
11 Smart Control
(Electric models
only) / Smart
Monitor (Gas models
only)
After connecting the Tumble Dryer to your home network using the
Samsung Smart Washer/Dryer app, you can control or monitor the dryer
remotely. When started, the Smart Control (Smart Monitor) indicator blinks.
The dryer enters waiting mode and waits for remote commands.
12 Power Press to turn on/turn off the dryer.
13 Start/Pause (Hold to
Start)
Press to start or stop operation.
NOTE
Do not take extremely tangled items from your washer and put them into the dryer. They can degrade the
drying efficiency of the dryer or cause the door to open. We recommend that you untangle the items before
putting them into the dryer. Also, do not put objects on the dryer, especially on the control panel.
CAUTION
Do not spray water directly onto the control panel. This may cause a system failure.
Untitled-4 42 2023-03-21 11:43:32
English
English 43
Icon description
Sensor Dry
This icon appears when the dryer operates the cycle which senses the
internal humidity to determine the drying time.
Filter Check
This icon displays after every load as a reminder to clean the lint
filter. Clean the lint filter before every cycle and make sure the filter is
properly inserted before starting a cycle.
Vent Sensor
(DVE(G)55CG7500*
models only)
The dryer features a vent sensor that detects and notifies you when it
is time to clean the ductwork. The indicator lets you know the status
of the duct.
Steam
This icon appears when the dryer is in steam process. The dryer sprays
water into the drum to deodorize clothes and reduce static electricity
and wrinkles.
Child Lock
This icon indicates that Child Lock is on. For more information on Child
Lock, see page 49.
Sound Off
This icon indicates that the alarm is off. For more information on Sound
Off, see page 49.
Wi-Fi This icon indicates that the dryer is connected to Wi-Fi.
Untitled-4 43 2023-03-21 11:43:33
English
Operations
English44
Simple steps to start
1. Press Power to turn the dryer on.
2. Turn the Cycle Selector to select a cycle.
3. Change the cycle settings (Dryness, Temp., and Time) as necessary.
4. Select desired options as necessary.
5. Press and hold Start/Pause (Hold to Start).
To change the cycle during operation
1. Press Start/Pause (Hold to Start) to stop operation.
2. Select a different cycle, and repeat steps 2-4 above if necessary.
3. Press and hold Start/Pause (Hold to Start) again to start the new cycle.
Cycle overview
Standard Cycles
Cycle Description
NORMAL
For most fabrics including cottons and linens.
If NORMAL is selected, the Eco Dry function is enabled. For more
information, see Eco Dry in the “Control panel” section.
HEAVY DUTY
For drying items made out of heavy fabrics, such as jeans, corduroys, or work
clothes, with high temperature heat.
ACTIVEWEAR
For exercise wear and outdoor wear such as sports jerseys, training pants,
water-repellent jackets, and other performance clothing. Thick fabrics like a
zipper or velcro closure of a jacket, or training socks may not be completely
dried.
PERM PRESS
For drying wrinkle-free cottons, synthetic fabrics, knits, and permanent
press fabrics automatically.
DELICATES For heat-sensitive items at a low drying temperature.
BEDDING For bulky items such as blankets, sheets, and comforters.
DOWNLOADED
• Select to choose from more cycles available on the Samsung Smart
Washer/Dryer app on your smartphone.
• Available cycles: ECO NORMAL, SHIRTS, DENIM, TOWELS, RACK DRY,
WRINKLE AWAY, SANITIZE, WOOL, LOW TEMP.
• Factory setting: WRINKLE AWAY
Untitled-4 44 2023-03-21 11:43:33
English
English 45
Manual Dry
You can change the drying settings manually to your preference.
Cycle Description
QUICK DRY
A quick drying cycle running for 30 minutes.
The default cycle time is 30 minutes. However, you may manually change
the cycle time if necessary.
TIME DRY
You can specify a cycle time in minutes.
If TIME DRY is selected, the Eco Dry function is enabled by default. For more
information, see Eco Dry in the “Control panel” section.
AIR FLUFF Tumbles the load in room temperature air.
Steam Cycles
Use steam to reduce wrinkling and odors on items.
Cycle Description
STEAM SANITIZE⁺
Use to sanitize items by applying steam and high-temperature heat to the
fabric. This cycle can make items soft and reduce smells. Confirm that the
laundry load is wet or partially wet before starting this cycle.
REFRESH
Use to smooth out wrinkles and reduce odors in loads of one to four items.
With this cycle selected, a small amount of water is sprayed into the dryer
drum after several minutes of tumbling with heat. Confirm that the laundry
load is dry.
Untitled-4 45 2023-03-21 11:43:33
English
Operations
English46
Cycle chart
NOTE
For best results, follow the load size recommendations for each dry cycle.
•
Large load: Fill the drum to about 3/4 full. Do not add items over this level as they need to tumble
freely.
• Medium load : Fill the drum to about 1/2 full.
• Small load : Fill the drum with 3-5 items, not more than 1/4 full.
Cycle Recommended items Load size Dry level
NORMAL Cottons, work clothes, linens, mixed loads
Normal dry
(Adjustable)
HEAVY DUTY Heavy fabrics such as jeans, corduroys, heavy work clothes
Normal dry
(Adjustable)
ACTIVEWEAR
Water-repellent wear, performance clothes, sports wear
(Maximum : 4 lbs)
Normal dry (Not
adjustable)
PERM PRESS
Shirts, synthetic fabrics, knits, wrinkle-free cottons, permanent
press
Normal dry
(Adjustable)
DELICATES Underwear, blouses, lingerie
Normal dry
(Adjustable)
BEDDING Bulky items such as blankets, sheets, comforters, pillows
Normal dry
(Adjustable)
QUICK DRY Small loads -
TIME DRY Any load -
AIR FLUFF Foam,rubber, plastic -
STEAM SANITIZE⁺ Bedding, curtains, children's clothing
Very dry (Not
adjustable)
REFRESH Shirts, trousers, comforters, pillows -
Untitled-4 46 2023-03-21 11:43:33
English
English 47
NOTE
: factory setting, : can be selected
Cycle
Functions (Temp. Control)
Time
High
Low
NORMAL
HEAVY DUTY
ACTIVEWEAR
PERM PRESS
DELICATES
BEDDING
QUICK DRY
TIME DRY
AIR FLUFF
STEAM SANITIZE⁺
REFRESH
Cycle
Options
Adjust Time Damp Alert Eco Dry Wrinkle Prevent
NORMAL
: DVE(G)55CG7100*
models
: DVE(G)55CG7500*
models
HEAVY DUTY
ACTIVEWEAR
PERM PRESS
DELICATES
BEDDING
QUICK DRY
TIME DRY
AIR FLUFF
STEAM SANITIZE⁺
REFRESH
Untitled-4 47 2023-03-21 11:43:34
English
Operations
English48
Cycle guide
The best way to dry items is to follow the instructions on the care label. If no drying instructions are
provided, see the following table for reference.
Cycle Description
Bedspreads & Comforters
Follow the care label instructions or dry using BEDDING.
• Make sure the item is thoroughly dry before using or storing.
• May require repositioning in the drum to ensure even drying.
Blankets
Use NORMAL and dry only one blanket at a time for best tumbling action.
• Make sure blankets are thoroughly dry before using or storing.
Curtains & Draperies
Use PERM PRESS and the Medium temperature setting to help minimize
wrinkling.
• Dry curtains and draperies in small loads for best results and remove as
soon as possible.
Cloth Diapers Use NORMAL and the Medium temperature setting for soft, fluffy diapers.
Down–filled Items
(jackets, sleeping bags,
comforters, etc.)
Use NORMAL and the Medium temperature setting.
• Add a couple of dry towels to absorb moisture and shorten drying time.
Foam Rubber (rug backs,
stuffed toys, shoulder
pads, etc.)
Do not dry on a heat setting.
WARNING
Drying a rubber item with heat may damage it or cause a fire.
Pillows
Use NORMAL.
• Add a couple of dry towels and a pair of clean sneakers to help the
tumbling action and to fluff the items.
• Do not dry kapok or foam pillows using a heated drying cycle.
Plastics (shower curtains,
outdoor furniture covers,
etc.)
Use TIME DRY and the Low or Extra Low temperature settings depending on
the care label instructions.
WARNING
Do not dry:
• Fiberglass items (curtains, draperies, etc.)
• Woolens, unless recommended on the label
• Items spotted or soaked with vegetable or cooking oils
Untitled-4 48 2023-03-21 11:43:34
English
English 49
Special features
Child Lock
Child Lock prevents children from playing with the dryer. When Child Lock is activated, all buttons except
for the Power button are disabled.
To activate/deactivate Child Lock, simultaneously press and hold
Dryness and Temp. for 3 seconds.
NOTE
Once Child Lock is activated, it will remain active even after you restart the dryer. If other buttons, except
for the Power button, do not respond, check the Child Lock indicator. If the indicator is on, follow the
instructions above to turn Child Lock off.
Sound Off
You can turn on or off the sound from the dryer. Please note that this setting does not affect the sound that
notifies information codes and Damp Alert.
• To mute the sound, hold down
Drum Light for 3 seconds.
• To unmute the sound, hold down again for 3 seconds.
Smart Control
To enable this function, you must first download the Samsung Smart Washer/Dryer app at the Play Store or
the App Store and install it on a mobile device featuring a camera function. The Smart Control function has
been optimized for Galaxy & iPhone series (applicable models only).
1. When the dryer detects an issue to check, an information code appears on the display. To enter Smart
Control mode, press and hold Wrinkle Prevent for 3 seconds.
2. The dryer starts the self-diagnosis procedure and displays an information code if a problem is detected.
3. Run the Samsung Smart Washer/Dryer app on your mobile device, and then tap Smart Control.
4. Put the mobile device close to the dryer’s display so that the smartphone camera and the dryer face
each other. The app automatically recognizes the information code.
5. When the information code is recognized correctly, the app provides detailed information about the
problem with applicable solutions.
NOTE
• The function name, Smart Control, may differ depending on the language.
• If light is reflected off the dryer’s display, the app may fail to recognize the information code.
• If the app fails to recognize the information code, you can enter the code manually in the app.
Untitled-4 49 2023-03-21 11:43:34
English
Operations
English50
DOWNLOADED cycle
You can choose from more cycles available on the SmartThings app on your smartphone.
1. On your smartphone, select the DOWNLOADED cycle.
You can choose from TOWELS, SANITIZE, SHIRTS, DENIM, WOOL, ECO NORMAL, LOW TEMP., RACK DRY,
and WRINKLE AWAY.
2. Press Power on your dryer.
3. Turn the Cycle Selector to DOWNLOADED.
4. Press and hold Start/Pause (Hold to Start).
Untitled-4 50 2023-03-21 11:43:34
English
English 51
SmartThings
Wi-Fi connection
On your smartphone, go to
Settings, turn on the wireless connection, and then select your AP (Access
Point).
• This appliance supports the Wi-Fi 2.4 GHz protocols.
Download
On an app market (Google Play Store, Apple App Store, Samsung Galaxy Apps), find the SmartThings app
using the search term “SmartThings”. Download and install the app on your device.
NOTE
The app is subject to change without notice for improved performance.
Log in
You must first log into SmartThings with your Samsung account. To create a new Samsung account, follow
the instructions in the app. You don’t need a separate app to create your account.
NOTE
If you have a Samsung account, use the account to log in. A registered Samsung smartphone user
automatically logs in.
To register your appliance to SmartThings
1. Make sure your smartphone is connected to a wireless network. If not, go to Settings and turn on the
wireless connection, and then select your AP (Access Point).
2. Open SmartThings on your smartphone.
3. If the “A new device is found.” message appears, select Add.
4. If no message appears, select + and then select your appliance from the list of devices available. If
your appliance is not listed, select Device Type > Specific Device Model, and then add your appliance
manually.
5. Register your appliance to the SmartThings app.
a. Add your appliance to SmartThings. Make sure your appliance is connected to SmartThings.
b. When registration is complete, then name of your appliance appears on your smartphone.
Untitled-4 51 2023-03-21 11:43:34
English
English52
Maintenance
Keep the dryer clean to prevent decreased performance and to lengthen its life.
WARNING
Certain internal parts are intentionally not grounded and may present a risk of electric shock only during
servicing. Service Personnel - Do not contact the following parts while the appliance is energized: Control
board and inlet valve.
Vent Sensor (DVE(G)55CG7500* models only)
The dryer features a vent sensor that detects and notifies you when it is time to clean the ductwork. The
indicator lets you know the status of the duct.
Level
Indicator
Status Action
0 Off The ductwork is not clogged.
1 On
• The duct or lint filter is clogged.
• The pressure applied to the duct
is high because the duct is too
long or bent.
• Check the lint filter or duct and
clean if necessary.
• Check the duct connections and
shorten or straighten the duct if
necessary.
2 Blinking
• The duct or lint filter is severely
clogged.
• The pressure applied to the duct
is very high because the duct is
too long or bent.
• Check and clean the lint filter or
duct and make sure they are not
clogged.
• Check the duct connections and
shorten or straighten the duct
work.
If the dryer is in the Level 2 state, the
indicator blinks for 3 hours after the completion of the current
cycle. If you press Power or open the door, the dryer powers off immediately.
NOTE
• For duct installation, see “Exhaust ducting guide” on page 34 and “Ducting requirements” on page 18.
• The dryer may keep running even if the duct is clogged, but the drying time will be extended.
• If the indicator turns on for the first time and is solid (not blinking), check and clean the lint filter and/
or duct.
• If the indicator turns on again later, it is because the duct is installed or connected with some
restrictions (it’s too long or has too many bends). This is not a system failure. However, drying time may
be extended or the drying performance may be degraded.
Untitled-4 52 2023-03-21 11:43:34
English
English 53
Cleaning
Control panel
• Clean with a soft, damp cloth. Do not use
abrasive substances.
• Do not spray liquid cleaning agents directly
onto the dryer display.
• Some laundry pre-treatment soil and stain
removers may damage the control panel.
• When using liquid cleaning agents, apply
them to the cleaning cloth. Do not apply them
directly to the dryer. Wipe up any spills or
overspray immediately.
Drum
• Remove any stains from the drum with an all-
purpose cleaner.
• Tumble old towels or rags to remove any
remaining stains or cleaning substances.
Stains may be still visible but will not affect
subsequent loads.
Powder coated drum
To clean the powder coated drum, use a damp
cloth with a mild, non-abrasive cleaner suitable
for easily marred surfaces.
Remove cleaner residue and dry with a clean cloth.
Dryer exterior
• Clean with a soft, damp cloth. Do not use
abrasive substances.
• Protect the surface from sharp objects.
• Do not place any heavy or sharp objects or
a detergent container on the dryer. They can
scratch or damage the top cover of the dryer.
• The dryer has a high-gloss finish on the entire
surface. Be careful not to scratch or damage
the surface.
Exhaust system
• Check and clean the exhaust system
on a regular basis to maintain optimum
performance.
• The external exhaust hood must be cleaned
frequently to ensure proper air flow.
Untitled-4 53 2023-03-21 11:43:34
English
English54
Troubleshooting
Checkpoints
If the dryer operates abnormally, first check the list of problems in the table below and try the suggested
actions.
Problem Action
Does not run.
• Make sure the door is latched shut.
• Make sure the power cord is plugged into a live electrical outlet.
• Check your home’s circuit breakers or fuses.
• Press or tap Start/Pause (Hold to Start) again if the door is opened
during a cycle.
• Clean the lint filter.
Does not heat.
• Check your home’s circuit breakers or fuses.
• Some cycles do not require heating. Check the selected cycle again.
• For a gas dryer, make sure the gas supply is on.
• Clean the lint filter and exhaust duct.
• The dryer may have moved into the cool-down phase of the cycle.
• Turn off the Eco Dry option for the NORMAL or TIME DRY cycles. When
the Eco Dry option is on, the dryer performs an air dry process in the
beginning of the cycle to reduce energy consumption. The air dry
process does not use heated air, so you may feel that the dryer is not
being heated, but this is normal.
Does not dry.
• Check all of the above, plus...
• Make sure the exhaust hood outside your home can open and close
freely.
• Check the exhaust system for lint buildup. Ducting should be
inspected and cleaned annually.
• Use a 4” rigid metal exhaust duct.
• Do not overload. 1 wash load = 1 dryer load.
• Dry heavy items and light weight items separately.
• Large, bulky items, such as blankets or comforters, may require
repositioning to ensure even drying.
• Make sure that your washer is draining properly and extracting
adequate water from the load.
• The load may be too small to tumble properly. Add a few towels and
restart the dryer.
• The load may be too large to tumble properly. Remove some items
and restart the dryer.
• Clean the lint filter.
Untitled-4 54 2023-03-21 11:43:34
English
English 55
Problem Action
Is noisy.
• Check the load for objects such as coins, loose buttons, nails, etc.
Remove promptly.
• It is normal to hear the dryer gas valve or heating element cycle on
and off during the drying cycle.
• Make sure the dryer is leveled properly as outlined in the installation
instructions.
• It is normal for the dryer to hum due to the high velocity of air moving
through the dryer drum, fan, or exhaust system.
Dries unevenly.
• Seams, pockets, and other similarly heavy areas may not be
completely dry when the rest of the load has reached the selected
dryness level. This is normal. You can choose a higher dryness level or
a cycle that involves a higher dryness level.
• If one heavy item is dried with a light weight load, such as one towel
with sheets, it is possible that the heavy item will not be completely
dry when the rest of the load has reached the selected dryness level.
• For the best drying results, dry heavy items and light weight items
separately.
Has odors.
• Household odors from paint, varnish, strong cleaners, etc. may enter
the dryer with the surrounding room air. This is normal as the dryer
draws the air from the room, heats it, pulls it through the tumbler, and
exhausts it outside.
• When these odors linger in the air, completely ventilate the room
before using the dryer.
• Use a cycle featuring the Refresh function. If odors persist, wash and
dry the item again.
• Use the REFRESH cycle. If odors persist, wash and dry the items again.
Lint on clothes.
• Make sure the lint filter is cleaned before every load. For clothes that
naturally build up lint, clean the filter during the cycle.
• Some fabrics are lint producers (for example, a fuzzy white cotton
towel) and they must be dried separately from clothes that are lint
trappers (for example, a pair of black linen pants).
• Divide larger loads into smaller loads for drying.
• Check pockets thoroughly before drying, then dry clothes.
• Remove lint inside the drum before drying.
Items still wrinkled after
WRINKLE PREVENT
(WRINKLE-CARE, WRINKLE
RELEASE).
• Small loads of 1 to 4 items work best.
• Load fewer items. Load similar-type items.
• Take out the items immediately after drying is complete.
Untitled-4 55 2023-03-21 11:43:34
English
Troubleshooting
English56
Problem Action
Water drips from the nozzle
when STEAM CARE starts.
• This is steam condensation. The dripping water will stop after a short
time.
Sprayed water is not visible
during STEAM CARE.
• Sprayed water is difficult to see when the door is closed.
Extended time.
• Sensor Dry automatically senses the moisture in the load and shuts
the dryer off when the selected dryness level is reached. The drying
time can change according to the type and amount of laundry. See the
cycle chart for reference.
If a problem persists, contact a local Samsung service center.
Untitled-4 56 2023-03-21 11:43:34
English
English 57
Information codes
If the dryer fails to operate, you may see an information code on the display panel. To determine what you
should do, check the list of codes in the table below, and then try the suggested actions.
Code Action
dC
Operating the dryer with the door open.
• Make sure the door is properly closed.
• Make sure laundry is not caught in the door.
FC
Invalid power source frequency.
• Try restarting the cycle.
• If this information code remains, contact a Samsung service center.
AC
Electronic control problem (Invalid Communication).
• Contact a Samsung service center.
HC
High temperature heating check
• Clean the lint filter.
• If this information code remains, contact a Samsung service center. (enter the
line test mode)
9C1
The electronic control needs to be checked.
• Check if power cord is connected properly.
• Check if the electrical outlet is working properly.
• If the information code remains, contact a Samsung service center.
tC
The Thermistor1 resistance is very low or high.
• Check for a clogged lint screen
• Check if the vent system is restricted.
• If this information code remains, contact a Samsung service center.
tC5
The Thermistor2 resistance is very low or high.
• Check for a clogged lint screen.
• Check if the vent system is restricted.
• If this information code remains, contact a Samsung service center.
dF
Incorrect door switch.
• Contact a Samsung service center.
3C
The PBA needs to be checked.
• Unplug the power plug and contact a Samsung service center.
If any information code keeps appearing on the display, contact a Samsung service center.
Untitled-4 57 2023-03-21 11:43:35
English
English58
Specifications
Fabric care chart
The following symbols provide garment care direction. The clothing care labels include symbols for drying.
The use of symbols ensures consistency among garment manufacturers of domestic and imported items.
Follow care label directions to optimize garment life and reduce laundering problems.
Tumble Dry Cycles
Dry
Normal
Permanent Press
Delicate/Gentle
Do Not Dry (Used with Do Not Wash)
Do Not Tumble Dry
In the Shade (Added to Line Dry, Drip Dry or Dry Flat)
Line Dry/ Hang to Dry
Drip Dry
Dry Flat
Tumble Dry Heat Setting
Any Heat
High
Medium
Low
No Heat/ Air
Untitled-4 58 2023-03-21 11:43:36
English
English 59
Protecting the environment
This appliance is manufactured from recyclable materials. If you decide to dispose of this appliance, please
observe local waste disposal regulations. Cut off the power cord so that the appliance cannot be connected
to a power source. Remove the door so that animals and small children cannot get trapped inside the
appliance.
Specification sheet
Type Front loading dryer
Capacity (Cu.ft) 7. 4
Water pressure (psi (kPa)) 20-116 (137-800)
Weight lb (kg) 119.0 (54.0)
Heater rating
Electric dryer (W) 5300
Gas dryer (BTU/hr) 20000
Power consumption (W) 5400
Untitled-4 59 2023-03-21 11:43:36
English60
LIMITED WARRANTY (U.S.A.)
SAMSUNG DRYER
LIMITED WARRANTY TO ORIGINAL CONSUMER PURCHASER WITH PROOF OF PURCHASE
This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS AMERICA, INC.
(SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by
SAMSUNG against manufacturing defects in materials or workmanship for the limited warranty period,
starting from the date of original purchase, of:
One (1) Year All Parts and Labor
This limited warranty is valid only on products purchased and used in the United States that have been
installed, operated, and maintained according to the instructions attached to or furnished with the product.
To receive warranty service, the purchaser must contact SAMSUNG at the address or phone number
provided below for problem determination and service procedures. Warranty service can only be performed
by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as
proof of purchase to SAMSUNG or SAMSUNG’s authorized service center to receive warranty service.
SAMSUNG will provide in-home service within the contiguous United States during the warranty period
at no charge, subject to availability of SAMSUNG authorized servicers within the customer’s geographic
area. If in-home service is not available, SAMSUNG may elect, at its option, to provide transportation of
the product to and from an authorized service center. If the product is located in an area where service by a
SAMSUNG authorized servicer is not available, you may be responsible for a trip charge or required to bring
the product to a SAMSUNG authorized service center for service.
To receive in-home service, product must be unobstructed and accessible to the service agent.
During the applicable warranty period, a product will be repaired, replaced, or the purchase price refunded,
at the sole option of SAMSUNG. SAMSUNG may use new or reconditioned parts in repairing a product, or
replace the product with a new or reconditioned product. Replacement parts and products are warranted
for the remaining portion of the original product’s warranty or ninety (90) days, whichever is longer. All
replaced parts and products are the property of SAMSUNG and you must return them to SAMSUNG.
This limited warranty covers manufacturing defects in materials or workmanship encountered in normal
household, noncommercial use of this product and shall not cover the following: damage that occurs in
shipment, delivery, installation, and uses for which this product was not intended; damage caused by
unauthorized modification or alteration of the product; product where the original factory serial numbers
have been removed, defaced, changed in any way, or cannot be readily determined; cosmetic damage
including scratches, dents, chips, and other damage to the product’s finishes; damage caused by abuse,
misuse, pest infestations, accident, fire, floods, or other acts of nature or God; damage caused by use of
equipment, utilities, services, parts, supplies, accessories, applications, installations, repairs, external
wiring or connectors not supplied or authorized by SAMSUNG; damage caused by incorrect electrical
line current, voltage, fluctuations and surges; damage caused by failure to operate and maintain the
product according to instructions; in-home instruction on how to use your product; and service to correct
installation not in accordance with electrical or plumbing codes or correction of household electrical or
plumbing (i.e., house wiring, fuses, or water inlet hoses). The cost of repair or replacement under these
excluded circumstances shall be the customer’s responsibility.
Untitled-4 60 2023-03-21 11:43:36
English 61
Visits by an authorized servicer to explain product functions, maintenance or installation are not covered
by this limited warranty. Please contact SAMSUNG at the number below for assistance with any of these
issues.
EXCLUSION OF IMPLIED WARRANTIES
IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitations or
exclusions may not apply to you. This warranty gives you specific rights, and you may also have other rights,
which vary from state to state.
LIMITATION OF REMEDIES
YOUR SOLE AND EXCLUSIVE REMEDY IS PRODUCT REPAIR, PRODUCT REPLACEMENT, OR REFUND OF
THE PURCHASE PRICE AT SAMSUNG’S OPTION, AS PROVIDED IN THIS LIMITED WARRANTY. SAMSUNG
SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT
LIMITED TO TIME AWAY FROM WORK, HOTELS AND/OR RESTAURANT MEALS, REMODELING EXPENSES,
LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS REGARDLESS OF
THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. Some states do not allow exclusion or limitation of incidental or
consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives
you specific rights, and you may also have other rights, which vary from state to state.
SAMSUNG does not warrant uninterrupted or error-free operation of the product. No warranty or
guarantee given by any other person, firm, or corporation with respect to this product shall be binding on
SAMSUNG.
To obtain warranty service, please contact SAMSUNG at:
Samsung Electronics America, Inc.
85 Challenger Road
Ridgefield Park, NJ 07660
1-800-SAMSUNG (726-7864)
www.samsung.com/us/support
Untitled-4 61 2023-03-21 11:43:36
English62
Warranty (CANADA)
SAMSUNG DRYER
LIMITED WARRANTY TO ORIGINAL PURCHASER
This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS CANADA, INC.
(SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by
SAMSUNG against manufacturing defects in materials and workmanship for a limited warranty period of:
• One (1) year part and labor
This limited warranty begins on the original date of purchase, and is valid only on products purchased and
used in the Canada.
To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service
procedures.
Warranty service can only be performed by a SAMSUNG authorized service center.
The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or
SAMSUNG’s authorized service center.
SAMSUNG will provide in-home service during the warranty period at no charge, subject to availability
within the Canada.
In-home service is not available in all areas.
To receive in-home service, product must be unobstructed and accessible to the service agent.
If service is not available, SAMSUNG may elect to provide transportation of the product to and from an
authorized service center.
SAMSUNG will repair, replace, or refund this product at our option and at no charge as stipulated herein,
with new or reconditioned parts or products if found to be defective during the limited warranty period
specified above.
All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG.
Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is
longer.
This limited warranty covers manufacturing defects in materials and workmanship encountered in normal,
noncommercial use of this product and shall not apply to the following: damage that occurs in shipment;
delivery and installation; applications and uses for which this product was not intended; altered product
or serial numbers; cosmetic damage or exterior finish; accidents, abuse, neglect, fire, water, lightning,
or other acts of nature or God; use of products, equipment, systems, utilities, services, parts, supplies,
accessories, applications, installations, repairs, external wiring or connectors not supplied or authorized
by SAMSUNG that damage this product or result in service problems; incorrect electrical line voltage,
fluctuations and surges; customer adjustments and failure to follow operating instructions, maintenance
and environmental instructions that are covered and prescribed in the instruction book; product removal
and reinstallation; problems caused by pest infestations.
This limited warranty does not cover problems resulting from incorrect electric current, voltage or supply,
light bulbs, house fuses, house wiring, cost of a service call for instructions, or fixing installation errors.
SAMSUNG does not warrant uninterrupted or error-free operation of the product.
Untitled-4 62 2023-03-21 11:43:36
English 63
EXCEPT AS SET FORTH HEREIN, THERE ARE NO WARRANTIES ON THIS PRODUCT EITHER EXPRESS OR
IMPLIED, AND SAMSUNG DISCLAIMS ALL WARRANTIES INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF MERCHANTABILITY, INFRINGEMENT OR FITNESS FOR A PARTICULAR PURPOSE.
NO WARRANTY OR GUARANTEE GIVEN BY ANY PERSON, FIRM, OR CORPORATION WITH RESPECT TO THIS
PRODUCT SHALL BE BINDING ON SAMSUNG.
SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR
OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE
USE, MISUSE, OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE
CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE
PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE.
WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE,
OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR PROPERTY
ARISING OUT OF THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT.
THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF
THIS PRODUCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY.
Some provinces do not allow limitations on how long an implied warranty lasts, or the exclusion or
limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to
you.
This warranty gives you specific rights, and you may also have other rights, which vary from province to
province.
To obtain warranty service, please contact SAMSUNG at:
Samsung Electronics Canada Inc.
2050 Derry Road West,
Mississauga, Ontario L5N 0B9 Canada
1-800-SAMSUNG (726-7864)
www.samsung.com/ca/support (English)
www.samsung.com/ca_fr/support (French)
Visits by a Service Engineer to explain functions, maintenance, or installation is not covered by warranty.
Please contact the Samsung call center at the number above for help with any of these issues.
Untitled-4 63 2023-03-21 11:43:36
Scan this with your smartphone
Energy Star only applies to DVE(G)55CG7500* model.
This product qualifies for ENERGY STAR in the factory default "
NORMAL + Eco Dry"
setting.
If you change the factory default setting or enable other features, power consumption
could increase and exceed the limits qualified for ENERGY STAR.
QUESTIONS OR COMMENTS?
COUNTRY CALL OR VISIT US ONLINE AT
U.S.A 1-800-SAMSUNG (726-7864) www.samsung.com/us/support
CANADA 1-800-SAMSUNG(726-7864)
www.samsung.com/ca/support (English)
www.samsung.com/ca_fr/support (French)
Untitled-4 64 2023-03-21 11:43:37
