USER’S MANUAL
Tower Fan
EP23485
2
www.costway.com
3
www.costway.com
Contact Us!
Do NOT return this item.
Contact our friendly customer service department for help first.
E-mail
US: cs.us@costway.com
UK: cs.uk@costway.com
Before You StartBefore You Start
Please read all instructions carefully.
Retain instructions for future reference.
Seperate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled near to the
area in which they will be placed in use, to avoid moving the product
unnecessarily once assembled.
Always place the product on a flat, steady and stable surface.
Keep all small parts and packaging materials for this product away from
babies and children as they potentially pose a serious choking hazard.
CAUTION
Read Rules of Safe Operation and Instructions Carefully.
WARNING
1.To reduce the risk of fire or electrical shock, do not use this fan with any solid state
speed control device.
2.If the power cord is damaged, stop using the product immediately.
3.This appliance has a polarized plug (one blade is wider than the other). To reduce the
risk of electric shock, this plug is intended to fit in a polarized outlet only one way. If the
plug does not fit fully in the outlet, reverse
the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to defeat this safety feature.
4.Do not leave the fan running unattended.
RULES FOR SAFE OPERATION
1.Never insert fingers, pencils, or any other objects through the fan housing when the
tower fan is running. Unplug the fan when moving it from one location to another.
2.Disconnect the fan before cleaning.
3.To avoid product tipping over, be sure the fan is on a stable surface when in operation.
4
.To reduce the risk of electric shock, DO NOT use the fan by a window.
5.The rules about cord and plug are as below:
(1 ) This product employs overload protection (fuse). A blown fuse indicates an overload
or short-circuit situation. If the fuse blows, unplug the product from the outlet Replace
the fuse as per the user servicing instructions (follow product marking for proper fuse
rating) and check the products. If the replacement fuse blows, a short-circuit may be
present
and
the product should be discarded or returned to service facility for
examination and/ or repair.
( 2 ) Do not operate any fan with a damaged cord or plug. Discard fan or return to an
authorized service facility for examination and/ or repair.
( 3 ) Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or
similar coverings. Do not route cord under furniture or appliances. Arrange cord away
from traffic area and where it will not be tripped over.
6.Do not use f
an i
n a window, rain may create electrical hazard.
7.Ensure that the fan is unplugged and switched off before removing the grill.
SPECIFICATIONS
1.Model No.: EP23485
2.Rated voltage: 120V~60Hz
3.Rated power: 35W
2
www.costway.com
3
www.costway.com
Contact Us!
Do NOT return this item.
Contact our friendly customer service department for help first.
E-mail
US: cs.us@costway.com
UK: cs.uk@costway.com
Before You StartBefore You Start
Please read all instructions carefully.
Retain instructions for future reference.
Seperate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled near to the
area in which they will be placed in use, to avoid moving the product
unnecessarily once assembled.
Always place the product on a flat, steady and stable surface.
Keep all small parts and packaging materials for this product away from
babies and children as they potentially pose a serious choking hazard.
CAUTION
Read Rules of Safe Operation and Instructions Carefully.
WARNING
1.To reduce the risk of fire or electrical shock, do not use this fan with any solid state
speed control device.
2.If the power cord is damaged, stop using the product immediately.
3.This appliance has a polarized plug (one blade is wider than the other). To reduce the
risk of electric shock, this plug is intended to fit in a polarized outlet only one way. If the
plug does not fit fully in the outlet, reverse
the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to defeat this safety feature.
4.Do not leave the fan running unattended.
RULES FOR SAFE OPERATION
1.Never insert fingers, pencils, or any other objects through the fan housing when the
tower fan is running. Unplug the fan when moving it from one location to another.
2.Disconnect the fan before cleaning.
3.To avoid product tipping over, be sure the fan is on a stable surface when in operation.
4
.To reduce the risk of electric shock, DO NOT use the fan by a window.
5.The rules about cord and plug are as below:
(1 ) This product employs overload protection (fuse). A blown fuse indicates an overload
or short-circuit situation. If the fuse blows, unplug the product from the outlet Replace
the fuse as per the user servicing instructions (follow product marking for proper fuse
rating) and check the products. If the replacement fuse blows, a short-circuit may be
present
and
the product should be discarded or returned to service facility for
examination and/ or repair.
( 2 ) Do not operate any fan with a damaged cord or plug. Discard fan or return to an
authorized service facility for examination and/ or repair.
( 3 ) Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or
similar coverings. Do not route cord under furniture or appliances. Arrange cord away
from traffic area and where it will not be tripped over.
6.Do not use f
an i
n a window, rain may create electrical hazard.
7.Ensure that the fan is unplugged and switched off before removing the grill.
SPECIFICATIONS
1.Model No.: EP23485
2.Rated voltage: 120V~60Hz
3.Rated power: 35W
4
www.costway.com
PARTS NAME
1.Body
2.Front base
3.Rear base
4.Base clip
5.Power cord
PARTS ASSEMBLY
1.Assemble the front and rear base by aligning the tabs and sliding them toge ther until
they form one base.
2.Place the assembled base on the bottom of the fan body, pull power cord through the
hole in the center of th e base until the bas e touches the bottom of the fan body.
3.Rotate the base in a clockwis e direction on the bottom of the fan until installed in place.
Pull the power cord through the hole on the sid
e of the base.
4.Install the base clip to secure the body an
d base. (see the assembly diagram as below)
OPERATING INSTRUCTIONS
A. Control parts description:
1.
Speed
switch
2.Body oscillating switch
B. Instructions:
1. Plug the power cord into a wall outlet.
2. To improve a i r circulation, the fan can oscillate. To
start the oscillation feature, press the oscillating switc
h
(2). To stop the fan from oscillating, press the oscillatio
n
switch (2) again.
3. The fan h as 3 speed settings, use the rotating spee
d
switch (1) to select desired speed.
USER SERVICING INSTRUCTIONS
1) Grasp plug and remove from the receptacle or other
outlet device. Do not unplug by pulling on cord.
2) Open fuse cover. Slide open fuse access cover on
top of attachment plug towards blades.
3) Remove fuse carefully. Push the fuse from the other
side or turn fuseholder over to remove fuse.
4) Risk of fire. Replace fuse only with 5 Amp, 125 Volt
fuse.
5) Close fuse cover. Slide close the fuse access cover on top of attachment plug.
6) Risk of fire. Do not replace attachment plug. Contai
ns a safety device (fuse) that
should not be removed. Discard product if the attachment plug is damaged.
CLEANING
1. Be sure to unplug the power cord from the outlet before cleaning.
2. Plastic parts should be cleaned with a damp cloth or sponge.
3. Be sure not to submerge in water or other liquids.
4. Avoid getting water or other liquids inside the motor housing.
www.costway.com
