the Instraction Book
™
Instruction Book – B#####
the Puck Sucker
™
Instruction Book – BEA503
2
Contents
2 Breville Recommends Safety First
6 Components
7 Assembly
8 Functions
9 Care & Cleaning
10 Troubleshooting
12 Warranty
BREVILLE
RECOMMENDS
SAFETY FIRST
At Breville we are very safety
conscious. We design and
manufacture consumer
products with the safety of you,
our valued customer, foremost
in mind. In addition, we ask
that you exercise a degree of
care when using any electrical
appliance and adhere to the
following precautions. Misuse
can cause potential injuries.
IMPORTANT
SAFEGUARDS
READ ALL INSTRUCTIONS
BEFORE USE AND SAVE FOR
FUTURE REFERENCE
• Remove and safely
discard any packaging
material or promotional
labels on the product
or on any of the
attachments before using
for the first time.
• Ensure the product is
properly assembled
before use.
• This appliance is not
intended for use by
persons (including
children) with reduced
physical, sensory or
mental capabilities,
or lack of experience
and knowledge,
unless they have been
given supervision or
instruction concerning
the use of the appliance
by a person responsible
for their safety.
3
• Children should be
supervised to ensure that
they do not play with the
appliance.
• The Puck Sucker™ is only
intended for use with
Breville 58mm portafilter
and basket.
• Always remove the
battery before storing or
when not in use for an
extended period of time.
• Keep the appliance clean.
• Do not use this appliance
if it is worn, has been
dropped or is damaged in
any way.
• Any maintenance other
than cleaning should
be performed at an
authorised Breville
Service Centre.
• This appliance is for
household use only.
Do not use the appliance
for anything other than
its intended purpose.
Do not use in moving
vehicles or boats.
Do not use outdoors.
Do not use on a sink
drain board. Misuse may
cause injury.
• Never use attachments
or accessories that
are not supplied with
this product. Failing to
follow this instruction
may cause product
malfunction, product
damage or even pose
safety risk.
• Do not attempt to operate
the appliance by any
method other than those
described in this book.
• Do not incinerate this
appliance even if it is
severely damaged.
• Do not use the Puck
Sucker™ with a plastic
bag in the container.
• Do not knock the
portafilter on the
Puck Sucker™ with
sudden force.
4
TYPES OF BATTERY
THAT MAY BE USED:
• 9V batteries:
• Alkaline 9V battery
(6LR61 6LF22 1604A)
• Lithium 9V battery
(1604LC)
WARNING
• Non-rechargeable
batteries are not to be
recharged.
• Different types of
batteries or new and
used batteries are not
to be mixed.
• Do not expose the
appliance or battery to
excessive temperatures.
• Batteries can contain
flammable substances,
and if handled improperly
may leak, heat up, ignite,
or explode.
• Terminals of the battery-
operated appliance
or battery being short
circuited by metal objects
can overheat and cause
injury or fire.
• Keep batteries out
of reach of children.
Swallowing can lead
to chemical burns,
perforation of soft
tissue, and death. Severe
burns can occur within
2 hours of ingestion.
Seek medical attention
immediately.
CAUTION
• Batteries are to be
inserted with the correct
polarity.
• Exhausted batteries are
to be removed from the
appliance and safely
disposed of.
• Do not use modified or
damaged batteries.
• The supply terminals
must not be short-
circuited.
• On battery leakage,
remove the battery
immediately, but proceed
with caution: work in a
well-ventilated area,
away from heat sources.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
5
Wear protective eyewear
and gloves if possible, to
avoid contact with the
residue. After removing
the leaked batteries,
clean out the battery
compartment with a
cotton swab or an old
toothbrush. Put the
batteries in a plastic bag
and recycle. Be sure to
avoid contact with the
battery leak residue at all
times. Wash your hands
thoroughly with soap and
water afterwards. In case
of eye and skin contact,
seek medical attention
immediately.
Do not immerse the
lid in water or any
liquid. The lid is not
dishwasher safe. Only the
container is dishwasher
safe. Use only a damp
sponge to clean.
The symbol shown
indicates that this
appliance should not
be disposed of in normal
household waste. It should
be taken to a local
authority waste collection
centre designated for this
purpose or to a dealer
providing this service. For
more information, please
contact your local council
office. Please dispose of
batteries in an
environmentally friendly
manner. Do not throw
batteries into normal
household waste. Please
use the return and
collection systems in your
community or contact the
retailer where you
purchased the product.
6
Components
A. Activation switch
B. Lid with battery compartment
– fits 58 mm Breville portafilters
C. * Air Outlet port
D. * Air Inlet port with filter
E. 9V Battery
F. Container
– dishwasher safe (top rack only)
NOTE
*Keep the inlet and outlet port area clean and
free from any coffee grounds or any particles to
maintain good quality suction.
A
E
B
F
C
D
7
Assembly
INSTALLING & REMOVING
THE 9V BATTERY
1. Holding the container on one hand,
pull upwards to remove the lid with the
other hand.
2. Using a Philips-head screwdriver, unscrew
the battery cover, found underneath.
3. Carefully set-aside the battery cover.
4. Insert the 9V battery, bottom side up, and
align the male (positive) connector to the
side of the screw lock.
5. Replace the battery cover and screw back
to close.
6. Secure the lid back to the container.
8
Functions
HOW TO USE THE PUCK SUCKER™
1. Ensure the Puck Sucker™ is stable and
upright on a flat surface.
2. Place the portafilter into the Puck Sucker™
ensuring the portafilter touches the
red switch.
3. Press and hold the portafilter horizontally
straight and flat on the Puck Sucker™ lid
until the coffee puck falls into the container.
NOTE
Avoid moving or wiggling the portafilter on
the Puck Sucker™ as this will void the build of
the vacuum. If the puck hasn’t come out after
10 seconds, remove the portafilter and try
again. This could be due to a lack of seal with
the Puck Sucker™.
NOTE
The machine has a continuous vacuum sound
until the portafilter is removed.
WARNING
Do not knock the portafilter on the
Puck Sucker™ with sudden force.
9
Care & Cleaning
HOW TO CLEAN THE CONTAINER
1. Separate the Puck Sucker™ lid from the
container and dispose the coffee pucks
into the bin. The easiest way to remove the
vessel is by popping the top out with your
thumbs on each side of the lid.
FILENAME: BEA503_PuckSucker QS Guide_E22
Application: Illustrator CC
Job Number: 203-05
Design: KC. Artwork: PR. Checked:
E22
E22
11/07/22
the Puck Sucker
™
BEA503
www.breville.com
58mm
!
Concertina FoldConcertina Fold
2. Once the container is completely empty,
wash the container with warm soapy water
and rinse thoroughly.
3. Using soft dry cloth, wipe the inside and the
outside of the container thoroughly.
NOTE
The container is dishwasher safe
(top rack only).
HOW TO CLEAN THE
PUCK SUCKER™ LID
Use a damp cloth to wipe any coffee residues
off the lid and dry thoroughly.
WARNING
• DO NOT wash the Puck Sucker™ lid under
running water or clean by rinsing.
• DO NOT submerge the Puck Sucker™ lid in
water or any other liquid.
• Keep the *inlet and *outlet port area clean
and free from any coffee grounds or any
particles to maintain good quality suction.
*refer to
Components section
USED BATTERIES
• Exhausted batteries are to be removed from
the appliance and safely disposed of.
• Refer to the safety section of this manual
for cautions and warnings on handling and
disposing of batteries.
NOTE
Depending on the daily usage, the battery life
should be a minimum of 12 months.
TBC
10
Troubleshooting
PROBLEM POSSIBLE CAUSES EASY SOLUTIONS
Coffee puck does not come out. Incomplete seal between the portafilter and the puck extractor.
→ Ensure there are no gaps between the portafilter and the seal to enable
the vacuum to build. Check the portafilter handle is horizontal and
centred on the extractor lid.
Extractor lid is not placed correctly on the vessel.
→ Ensure the extractor lid is firmly flat in place on the vessel. Check the
seal is clean and not damaged.
Portafilter not kept on the extractor lid long enough.
→ Wait a few more seconds to ensure enough vacuum is being created.
Filter basket comes loose
when using the puck extractor.
When using a dual wall filter basket, a greater vacuum will be built
compared to using a single wall filter basket resulting the drop of the filter
basket from the portafilter.
→ Keep the portafilter on the puck extractor for a maximum of 5 seconds
and try again.
Filter basket catches
(or stuck underneath)
the switch.
Incorrect portafilter removing action.
→ Lift the handle on the portafilter first, then take the portafilter out
vertically.
Puck Sucker™ would not start. Puck Sucker™ may be low in battery.
→ Replace batteries.
Avoid moving or wiggling
the portafilter on the
Puck Sucker™.
Do not knock the portafilter
on the Puck Sucker™ with
sudden force.
11
If the coffee puck came out partially, the suction in the PuckSucker™ has been consumed.
The remaining bits of coffee ground will need to be removed manually.
Refer to coffee extraction tips below:
Coffee Extraction
An illustrated guide to a proper coffee extraction,
or scan the QR code below to watch a quick coffee tutorial video.
An illustrated guide to a proper coffee extraction,
or scan the QR code below to watch a quick coffee tutorial video.
UNDER EXTRACTION OVER EXTRACTION
INCREASE
GRIND AMOUNT
DECREASE
GRIND AMOUNT
www.breville.com
Tamp using 10-15kgs of pressure.
The top edge of metal cap on the
tamper should be level with the top
of the lter basket AFTER tamping.
Remove the dosing funnel from the
portalter then trim the puck to the
right level using the Razor™
precision dose trimming tool.
ADJUST GRIND SIZE
FINER
ADJUST GRIND SIZE
COARSER
ADJUST & RE-TESTADJUST & RE-TEST
• Flow starts after 8-12 secs
• Flow slow like warm honey
• Crema is golden brown with
a ne mousse texture
• Espresso is dark brown
REMOVE USED GRINDS
Used grinds will form a coffee 'puck'.
If the puck is wet, refer to the 'Under
Extraction'section.
RINSE FILTER BASKET
Keep the lter basket clean to prevent
blockages. Without ground coffee in the lter
basket, lock the portalter into the machine
and run hot water through.
AFTER EXTRACTION
10-15kg
ANZ
12
Warranty
1 YEAR LIMITED
PRODUCT WARRANTY
During the design and engineering of this
product, quality was at the forefront of each
material and component choice we made,
which is why we proudly stand by it with a
1 Year Limited Product Warranty.
In Australia our goods come with guarantees
that cannot be excluded under the Australian
Consumer Law. You are entitled to a
replacement or refund for a major failure and
for compensation for any other reasonably
foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and
the failure does not amount to a major failure.
In New Zealand our goods come with
guarantees that cannot be excluded under the
Consumer Guarantees Act 1993.
So, as well as your statutory rights referred
to above and any other rights and remedies
you may have under any other laws relating
to your Breville product, we also provide you
with a Breville warranty. It’s important to note
that this warranty is valid only in the country
of purchase. However, in other countries it is
possible that other statutory warranties may
still apply.
Breville’s warranty for this product covers the
repair or replacement (at Breville’s discretion) if
it’s found to be defective due to faulty materials,
workmanship, or function within the warranty
period and will not extend the term of the
original product warranty period.
To the extent permitted by law, this Breville
Limited Product Warranty excludes liability for
consequential loss or any other loss or damage
caused to property or persons arising from any
cause whatsoever. It excludes defects caused by
the product not being used in accordance with
instructions, by accidental damage, by misuse,
or by being modified, altered, or tampered with
by unauthorised persons. It excludes damage
caused by insects or vermin and claims based
on the presence of insects or vermin.
It also excludes breakables such as glass and
ceramic items, consumable items such as those
that require periodic replacement as part of
the ordinary use, lack of care or maintenance
of the product or as directed by the instruction
booklet, minor cosmetic issues (including,
without limitation, paint and coatings) and
normal wear and tear, and does not cover
the cost of claiming under the warranty or
transporting the goods to and from the place of
purchase.
For support with your Breville product or to
make a claim under the Breville Warranty
please contact our Breville Customer Care
Team on:
Australia: 1300 139 798
New Zealand: 0800 273 845
Our Breville Customer Care Team can often
diagnose and resolve most issues over the
phone. In the event your product needs to be
inspected or repaired, our Breville Customer
Care Team will assist in arranging shipping at
no charge by providing you a pre-paid label or
nearest drop off point. Once the item is received
and the nature of the fault is determined we’ll
advise what remedy you may be entitled to
under the Breville Warranty. To obtain benefits
under this Product Warranty, you will need to
provide a proof of purchase in a form sufficient
for us to verify your purchase, including the
product, date of purchase and purchase price.
We therefore urge you to retain this portion
of the warranty card and the purchase receipt
during the warranty period.
And if for any reason you wish to contact us in
writing, please do so at:
Breville Service Centre Australia
Locked Bag 2000
Botany NSW 1455
Breville Service Centre New Zealand
PO Box 99027
Newmarket 1149, Auckland
Or click on Support at www.breville.com
13
REGISTER YOUR WARRANTY
AND GET MORE FROM YOUR
PURCHASE.
Warranty registration takes only a few minutes
and ensures a record of your purchase and your
warranty exists where it should. Registration
also makes it faster and easier to get support or
advice on any future question or issue you may
have, and if you wish to, you can also select to be
sent free recipes, tips, tricks and other relevant
information.
Go to www.breville.com and follow the prompts.
WHAT’S ON YOUR MIND?
Our constant desire is to improve the quality
and features of our wide range of home
appliances. We welcome comments, ideas and
constructive suggestions.
Go to www.breville.com and follow the prompts.
Breville, the Breville Logo, Barista Express and Temp Control are trademarks of Breville Pty Ltd (“Breville”) and Breville's products
are distributed in Australia and New Zealand under license.
Copyright Breville Pty. Ltd. 2022.
Due to continued product improvement, the products illustrated/photographed
in this brochure may vary slightly from the actual product.
B##### ANZ – #22
Breville Service Centre
Australian Customers
Phone:
1300 139 798
Web: www.breville.com
New Zealand Customers
Phone:
0800 273 845
Web: www.breville.com
BEA503 ANZ – A22
