1
Fits Graco® SnugRide® Click Connect™ 30, 35, and 40 Infant Car Seat (not included)
Fits Eveno® Embrace™ Select Infant Car Seat (not included)
Fits Chicco® Keyt 30™ Infant Car Seat (not included)
Fits Britax® B-Safe 35™ Infant Car Seat (not included)
Fits Eveno® Nurture™ Infant Car Seat (not included)
INSTRUCTION MANUAL
Customer Experience Center
email: [email protected]
DCP-IM-10052020
www.DeltaChildren.com
WARNING:
Adult assembly required because of
small parts. Keep assembly parts
out
of reach of children under 3 years.
CHOKING HAZARD
JEEP WRANGLER
STROLLER WAGON
Read all instructions BEFORE assembly and USE of product
KEEP INSTRUCTIONS FOR FUTURE USE.
60003
ADULT ASSEMBLY REQUIRED
STYLES AND COLORS MAY VARY
This stroller wagon is not from, sponsored or endorsed by Britax®.
This stroller wagon is not from, sponsored or endorsed by Artsana S.p.A.
This stroller wagon is not from, sponsored or endorsed by Eveno Company, Inc.
This stroller wagon is not from, sponsored or endorsed by Graco Children’s Products Inc.
2
Customer Service [email protected] www.DeltaChildren.com
• To clean the wagon use a mild household soap with warm water on a sponge or clean cloth.
• Check your wagon for loose screws, worn parts, torn material or stitching on a regular basis. Replace or
repair parts as needed.
• Discontinue use of wagon if it should become damaged or malfunctions. Please contact our customer
service email at [email protected] to arrange for repair or obtain replacement parts.
• If you experience any difculty with assembly, missing parts or use, please DO NOT return this item to the
store. Retail stores are unable to properly assist you. Contact our Customer Service Department directly
for assistance [email protected]
CARE AND MAINTENANCE
WARNING: Please follow all of these instructions to ensure the safety of your child. Keep these instructions
for future reference.
WARNING: Failure to follow these instructions could result in serious injury or death.
WARNING: Avoid serious injury from falling or sliding out. Always ensure that the child is properly positioned
by using the safety harness according to these instructions.
WARNING: Never leave children unattended.
CAUTION: This is a double occupant stroller wagon for two children only. The use of more than two children
may cause an unstable condition which can injure your child. Do not place parcels, diaper bags or accessory
items on sides of wagon or handles as this can cause an unstable condition.
• The maximum weight that can be carried in rear & front storage bag is 6 pounds (2.7kg) each.
• The maximum weight that can be carried in the cooler bag is 15 pounds (6.8kg).
• The maximum weight that can be carried in the wagon is 110 lbs combined. Any additional weight will
cause a hazardous unstable condition.
• Use of the wagon with children weighing more than 55 pounds (24.92 kg) or over 42 inches (106.7 cm)
tall, may cause a hazardous unstable condition to the wagon.
• ALWAYS lift wagon from handlebars when going over curbs.
• ALWAYS remove canopy before folding.
• ALWAYS lock brakes when adding and removing children from wagon, or when parked.
• NEVER allow children to play with this product.
• NEVER allow children to play in or around the wagon. This wagon is not a toy.
• NEVER use the wagon on stairways, escalators, or moving walkways.
• NEVER use the wagon in conjunction with bicycles, skateboards, roller skates, or in-line skates.
• NEVER use on unstable or uneven terrain.
• NEVER put child inside wagon when using wagon as storage for other items.
• NEVER use second seat for child when using the infant car seat adapter.
• NEVER use near open ames or other sources of heat.
• NEVER sit on top rail or canopy, doing so may cause a hazardous unstable condition.
NEVER install mattresses or similar items for use in wagon. Doing so may cause a hazardous unstable
condition.
• NEVER allow children to stand up or place arms and legs outside of wagon while moving.
• NEVER leave wagon on sloped surface even if brakes are engaged.
• We recommend that the child occupant needs to be 6 months of age, at the minimum, before use of the
wagon. NOTE: With the use of infant car seat adapter, the minimum age is newborn and up.
3
Customer Service [email protected] www.DeltaChildren.com
LIMITED MANUFACTURER WARRANTY
This Delta product is warranted to be free from defects for a period of 90 days from the
date of purchase under normal use. This warranty extends only to the original retail
purchaser and is valid only when supplied with proof of purchase, or if received as a gift, when the
registration is on file with Delta. This limited manufacturer warranty does not cover the following:
• Products purchased as floor models or samples.
• Items purchased on an “as-is” basis, as a second hand product, or as a resale product.
• Items purchased at a Final sale, a “Going out of Business” sale, or a Liquidation sale.
TO REGISTER YOUR PRODUCT for important safety alerts and updates to your product please
visit www.deltachildren.com
TO REPORT A PROBLEM, please log on to www.deltachildren.com and click the Consumer
Care Tab, or contact us by email at [email protected]
Date of Purchase: _____________ (you should also keep your receipt)
DON’T MISS YOUR CHANCE TO BE COVERED FOR ALL OF LIFES MISHAPS!
With Delta’s Extended Warranty, you’re covered for mechanical failure from normal use or if your item
stops working due to normal wear and tear, plus all those unexpected surprises.
2 YEARS OF PROTECTION
For Additional Information:
Simply visit our Website, register your product, and add the Extended Warranty
https://www.deltachildren.com/pages/product-registration
Extended Warranty only available in the following States: Arkansas, Colorado, Delaware, District of Columbia, Georgia, Idaho, Illinois, Indiana,
Iowa, Kansas, Kentucky, Louisiana, Maryland, Michigan, Mississippi, Missouri, Nebraska, Nevada, New Hampshire, New York, North Carolina,
North Dakota, Pennsylvania, Rhode Island, South Dakota, Tennessee, Utah, West Virginia
EXTENDED WARRANTY
4
Customer Service [email protected] www.DeltaChildren.com
Rear Wheel
(x2)
Support Bar Tube
(For Car seat adapter)
Cooler Adapter
Cooler Bag Parent Organizer
5-in-1 Infant Car Seat Adapter
Cup Holder
Fabric Liner
(Folded)
Wagon Frame
*Shown folded
without fabric
Car Seat Adapter
Housing
(x2)
Front Wheel (x2)
(Lock & Swivel)
Leatherette Handlebar
Cover (x2)
Canopy
(Folded)
Rear Wheel
Axle
IMPORTANT! Before assembly and each use, inspect this product for damaged hardware, loose joints, missing parts, or sharp
edges. NEVER use if any parts are missing or broken. Contact manufacturer for replacement parts and instructions if needed.
Never substitute parts. IMPORTANT! Adult assembly is required.
PARTS
IMPORTANT! Please remove all parts from the package and identify them before assembly.
5
Customer Service [email protected] www.DeltaChildren.com
Release
Pin
PREPARING WAGON
• Unfolding wagon: Unlatch wagon by pulling latch away from latch post (Fig. 1A).
• After latch is cleared, allow the wagon to unfold out, or manually pull the wagon apart (Fig. 1B)
*Frame shown without fabric
* Unfolded
1
ASSEMBLY
Fig 1A
FRONT
FRONT
FRONT
REAR
REAR
REAR
ATTACHING & REMOVING REAR WHEELS
• To attach rear wheels to axle: Push each rear wheel into the axle housing
as shown until they “CLICK” into a locked position (Fig. 2).
• Pull outward on wheel to ensure that the wheel is securely locked.
• To release rear wheels from axle: While pressing the release button
located on the back of the wheel housing, remove wheel by pulling
away from housing (Fig. 2A).
ATTACHING & REMOVING REAR WHEEL AXLE
• To attach rear wheel axle: Align axle with frame as shown and push
in until both release pins “CLICK” (Fig. 2B).
NOTE: Make sure brake is closest to right rear wheel.
• To detach rear wheel axle: Press in release pins on both sides of
axle, and pull away from wagon frame (Fig. 2D).
2
Fig. 2
Fig. 2A
Fig. 2B
Fig. 2C
Fig. 2D
*Frame shown without fabric
*Wagon frame shown upside-down
*Brake Lever
*Right rear wheel
Release
Button
6
Customer Service [email protected] www.DeltaChildren.com
Folded
3
21
ASSEMBLY
4
• To attach canopy: Align each of the 4 canopy rods with their
corresponding posts (Fig. 4).
• Firmly insert each rod into its housing (Fig. 4A).
• To remove canopy: While release tab is pressed, pull up on each rod
until it clears the wagon frame (Fig. 4B).
• Fold canopy by folding each rod, then folding canopy frame closed (Fig.
4C.)
• Canopy can be stored in front storage pocket (Fig. 4D)
ATTACHING & REMOVING CANOPY
Fig. 4
Fig. 4B
Fig. 4D
Fig. 4C
Fig. 4A
*Frame shown with fabric
*Assembled
3
• To attach front wheel: Push front wheel post into the front wheel housing
until it “CLICKS” into a fully locked position. (Fig. 3)
Note: Pull downward on wheel to ensure that the wheel is securely
locked.
• To release front wheel: Press the release button located on the side of
the wheel housing and pull down on wheel to release (Fig. 3A).
ATTACHING & REMOVING FRONT WHEEL
Note: Before attaching wheels, make sure the wagon is in a fully open position.
Fig. 3
Fig. 3A
Release
Button
Release
Tab
7
Customer Service [email protected] www.DeltaChildren.com
CURB
WARNING: Always lock brakes when the wagon is not being pushed so that the wagon will not roll away. Never leave wagon unattended on a hill or incline as the wagon
may slide down the hill.
WARNING: NEVER leave children unattended in wagon.
1
FRONT WHEEL BRAKE LOCK
• To engage brakes: Apply light downward pressure to the brake lever
located on the front of the wheel housing. (Fig. 1).
• Check to make sure the brakes are in a fully locked position, making
sure stroller will not move when pushed.
• To release brakes: Gently lift the brake lever up. (Fig. 1A)
2
REAR WHEEL BRAKE LOCK
• To engage brakes: Apply light downward pressure to the FRONT of
the brake lever located on the axle. (Fig. 2).
• Check to make sure the brakes are in a fully locked position, making
sure stroller will not move when pushed.
• To release brakes: Apply light downward pressure to the BACK of the
brake lever (Fig. 2A).
Fig. 2
Fig. 1
Fig. 1A
Fig. 2A
SETUP AND USE
FRONT WHEEL SWIVEL LOCK
• To lock the front swivel wheel lock: Rotate the lever located on the top
of the front wheel housing clockwise until it “CLICKS” into a fully locked
position (Fig. 4).
• To unlock the front swivel wheel lock: Rotate the lever located on the
top of the front wheel housing counter clockwise until it “CLICKS” into a
fully locked position (Fig. 4A).
CLEARING WAGON OVER SIDEWALKS AND CURBS
• To clear wagon over sidewalks and curbs: Lift wheels using the REAR
handlebars and PULL over the sidewalk or curb from a backwards posi-
tion (Fig. 4).
WARNING: Please do not attempt to push down on rear handlebars to
lift front wheels.
Fig. 3 Fig. 3A
3
4
Rotate clockwise
to lock
Rotate counter
clockwise to unlock
Fig. 4
8
Customer Service [email protected] www.DeltaChildren.com
Fig. 3A
5
ADJUSTING HANDLEBARS
• To adjust handle: Press BOTH buttons (located on either side of handle bar) (Fig. 3).
• With both buttons pressed, rotate the handle up or down to desired position (Fig. 3A).
• The buttons will “CLICK” on both sides once it is in a fully locked position.
• Confirm both buttons are depressed and handlebars are in a locked position before use.
Fig. 3
SETUP AND USE
4
• To use sun shade: Locate zipper at the top of the canopy (Fig. 4)
• Unzip to reveal sunshade and carefully roll down (Fig. 4A.)
• Use velcro attachments to firmly secure to wagon (Fig. 4C)
• To store sun shade: Detach sunshade from velcro attachment
points (Fig. 4B)
• Carefully roll the sun shade up so that it fits in storage compartment
as originally stored, and zip to enclose (Fig. 4A).
USING SUN SHADE
Fig. 4A Fig. 4C
Fig. 4B
Fig. 4
9
Customer Service [email protected] www.DeltaChildren.com
• To use Mesh Net: Locate the mesh net in the storage compartment
directly underneath the canopy at the front and rear of the wagon (Fig. 5).
• Remove mesh from storage compartment and roll down.
• Secure mesh around the frame of the wagon using toggle & loop
(Fig. 5A).
• To store mesh net: Unfasten toggle & loop from frame of wagon (Fig.
5B).
• Roll mesh net evenly towards the top of the wagon.
• Store in the storage compartment on the inside of the canopy (Fig.
5.)
SETUP AND USE
Fig. 5A
Fig. 5B
Fig. 5
5
USING MESH NET
Storage
Compartment
Fig. 6BFig. 6A
6
• To install cup holder: Align clip on cup holder with frame post and
apply downward pressure until it “SNAPS” into place (Fig. 6A).
• To remove cup holder: Apply upwards pressure until cup holder
releases from post (Fig. 6B).
POSITIONING CUP HOLDER
Note: Cup holder can be positioned in one of the two posts on the wagon frame (Fig. 6).
Fig. 6
10
Customer Service [email protected] www.DeltaChildren.com
Fig. 7A
Fig. 7
7
• If canopy is installed: Uninstall by pressing release tab and pulling up
on each rod until it clears the wagon frame (Fig. 7).
Note: Folded canopy can be optionally stored in front storage
compartment (Fig. 7A).
• To fold wagon frame: Locate handle in center of wagon seat pad
(Fig. 7B) and pull upward until wagon frame begins to fold (Fig. 7C).
• To finish the fold, apply pressure inwards until wagon is fully closed
and auto latch “CLICKS” (Fig. 7D).
• Pull outwards on wagon to confirm latch is secured.
FOLDING WAGON FOR STORAGE
SETUP AND USE
Fig. 7B
Fig. 7C
Fig. 7D
Release
Tab
11
Customer Service [email protected] www.DeltaChildren.com
SECURING CHILD
1
Securing Child
• Place your child in the stroller. Position the crotch belt between your
child’s legs.
• Pull shoulder straps over child’s arm and shoulder and fasten both strap
ends to the restraint system.
• Fasten both waist belts to the buckle on each side of the crotch belt.
Make sure you hear a “click” on both sides.
• Check to be sure the restraint system is securely attached by pulling it
away from your child. The restraint system should remain attached.
3
To tighten the waist belts and shoulder straps:
• Feed the anchored end of a waist belt up through the buckle to form a
loop
A
. Pull the free end of the waist belt
B
.
• Repeat this procedure to tighten the other waist belt.
• Feed the top end of the shoulder strap through the plastic stay to form
a loop . Pull the bottom end down to tighten the strap .
• Repeat this procedure to tighten the other shoulder strap.
To loosen the waist belts and shoulder straps:
• Feed the free end of the waist belt up through the buckle to form a
loop
A
. Enlarge the loop by pulling on the end of the loop toward the
buckle. Pull the anchored end of the waist belt to shorten the free end
of the waist belt
B
.
• Repeat this procedure to loosen the other waist belt.
• Feed the bottom end of the shoulder strap through the plastic stay to
form a loop . Pull the top end up to loosen the strap .
• Repeat this procedure to loosen the other shoulder strap.
Please Note: After adjusting the restraint system to t your child, make
sure you pull on it to be sure it is securely fastened.
TIGHTEN
LOOSEN
5 Point Safety
Harness
2
• Tighten each waist belt and shoulder strap so that the restraint system
is snug against your child.
Please refer to the next section for instructions to tighten the waist
belts.
C
C
D
D
Before Placing your Child in Stroller:
Close Canopy. Press both brake pedals down until they “click” into the locke position.
Make sure the brake pedals are pressed down completely.
Always set both brake pedals when parking the stroller.
Waist Belt
Waist Belt
Crotch Belt
Restraint System
12
Customer Service [email protected] www.DeltaChildren.com
1
• Installing fabric liner: Start by inserting fabric liner as shown with all
flaps inside (Fig. 1).
• Attaching buckle straps: Locate the 4 buckle straps on the sides of
fabric liner (Fig. 1A).
• Place each strap over wagon frame and use finger tip to pull buckle open.
While buckle is open, feed strap through and release finger from clip to
secure. Repeat for all 4 buckles (Fig. 1B).
• Attaching C-ring straps: Locate the 7 C-rings (3 front, 3 rear, 1 under) on front,
rear and underside of fabric liner (Fig. 1C, Fig. 1F).
• Place each strap over the wagon frame and secure by pulling strap
through the slit at the bottom of the C-ring (Fig. 1D). Do the same for
wagon underside but attach to center of frame (Fig. 1F)
• Attaching velcro straps: Locate the 4 velcro (2 front, 2 rear) straps on
the front and rear of fabric liner (Fig. 1E).
• Secure velcro straps by placing around wagon frame as shown
(Fig. 1E).
• Finish by securing fabric liner velcro attachments as shown (Fig. 1G).
• To remove fabric liner from wagon frame: Follow these steps in reverse.
INSTALLING & REMOVING FABRIC LINER FROM WAGON FRAME
CLEANING AND MAINTENANCE
Fig. 1
Fig. 1A
Fig. 1D
Fig. 1G
Fig. 1B
C-Rings
VelcroVelcro
Fig. 1C
Front & Rear view
Fig. 1F
*Wagon underside
FRONT & REARFRONT & REAR ALL SIDESALL SIDES
13
Customer Service [email protected] www.DeltaChildren.com
• Use earlier instructions on pg. 12 to remove fabric liner from frame.
• Locate zipper at the bottom edge of fabric (Fig. 3A).
• Unzip to remove foam and board (Fig. 3B).
• To replace, follow these steps in reverse.
• To install shoulder straps: Slide shoulder strap fabric onto C-ring strap
(Fig. 3)
• Slip C-ring strap through slit in fabric liner (Fig. 3A).
• Secure by placing strap over the wagon frame and pulling strap
through the slit at the bottom of the C-ring (Fig. 3B).
• To remove shoulder straps: Remove C-ring strap by pulling strap
through slit and removing (Fig. 3C)
• Remove strap from fabric liner slit (Fig. 3D)
• Remove shoulder strap fabric from harness by sliding up and off (Fig. 3E)
Fig. 3B
Fig. 3A
3
2
REMOVING SEAT PAD FOR CLEANING
INSTALLING & REMOVING SHOULDER STRAPS FOR CLEANING
Fig. 3C Fig. 3D Fig. 3E
Fig. 3 Fig. 3A Fig. 3B
CLEANING AND MAINTENANCE
14
Customer Service [email protected] www.DeltaChildren.com
ATTACHING CAR SEAT ADAPTER
ATTACHING CAR SEAT SUPPORT BAR TUBE TO WAGON FRAME
• To attach car seat bar: Locate attachment points on both sides of the
wagon frame and align support bar tube to frame (Fig. 1).
• Clip car seat bar to top frame, making sure the attachment knob in the
center of support bar tube is facing the REAR of the wagon (Fig. 1A).
ATTACHING CAR SEAT ADAPTER HOUSING TO SUPPORT BAR TUBE
• To attach car seat adapter housing: Attach first adapter to the support
bar tube by opening clip and closing it over the bar, ensuring the
attachment knob in the center of the support bar tube is aligned with
the hole in adapter housing (Fig. 2, Fig. 2A).
NOTE: The adapter housing can only attach in one direction.
• Clip remaining adapter to the frame towards the REAR of the wagon
(Fig. 2B).
ATTACHING 5-IN-1 ADAPTER TO CAR SEAT ADAPTER
• To attach 5-in-1 adapter: Align adapter with connection points (Fig. 3).
• Attach 5-in-1 adapter by pushing down on connection points. When correctly locked in place you will hear a “CLICK” on both sides. (Fig. 3A)
NOTE: The 5-in-1 adapter can attach to adapter housing in EITHER direction.
1 2
3
*Assembled
Fig. 1A
Fig. 3
FRONT
REAR
CENTER REAR
Fig. 1
Attachment Knob
(Must face REAR of wagon)
Fig. 2
Fig. 2B
Fig. 2A
Fig. 3A
“CLICK”“CLICK”
*Side view
15
Customer Service [email protected] www.DeltaChildren.com
ASSEMBLING COOLER ADAPTER
ATTACHING BOTTOM BASE TO SIDE FRAME ASSEMBLY
• To attach bottom base to the side frame assembly, insert the bottom
base to the ends of the side frame until it “CLICKS” into place (Fig. 1).
NOTE: Pull outward on the bottom base to ensure it is fully fastened.
ROTATING CLIP
• To complete the assembly, rotate the clip of the adapter until it is fully
upright (Fig. 2).
1 2
“CLICK”
Fig. 1
Fig. 2
16
Customer Service [email protected] www.DeltaChildren.com
ATTACHING COOLER & ADAPTER
ATTACHING COOLER TO COOLER ADAPTER
• To attach cooleer to cooler adapter, locate the back strap behind cooler and slide it over the cooler adapter hooks to secure in place (Fig. 1).
• Fully assembled cooler to cooler adapter (Fig. 1A).
ATTACHING COOLER ASSEMBLY TO WAGON FRAME
• To attach cooler assembly to wagon frame, locate the metal hooks on back of cooler and attach to the top rail of wagon (Fig. 2).
1
2
Fig. 2
WARNING
WARNING: The maximum weight that can be carried in the cooler bag is 15 pounds (6.8kg).
CAPACITY: Can hold a 10 pound (4.5kg) bag of ice (ONLY) & 16 (12oz) cans of soda.
*Assembled
Fig. 1
Fig. 1A
17
Customer Service [email protected] www.DeltaChildren.com
WARNING
WARNING: The maximum weight that can be carried in the parent organizer is 6 lbs (2.7kg).
ATTACHING PARENT ORGANIZER
ATTACHING PARENT ORGANIZER TO WAGON FRAME
• To attach the parent organizer to wagon frame, locate the two hooks on back of parent organizer and attach to the top rail of wagon (Fig. 1).
1
Fig. 1
*Assembled
18
Customer Service [email protected] www.DeltaChildren.com
4
Car Seat Adapter -
Correct Placement
Car Seat Adapter Clicks And Locks On
Both Sides Of The Wagon Frame When
In A Fully Locked Position
Back
Front
Insert On
Both Sides
Fig. 4A
Fig. 4B
Fig. 4C:
Fig. 4D:
Attaching Graco Car Seats- SnugRide® Click Connect™
30, 35
and 40:
Lock the rear wheels (Fig. 4). Attach the car seat adapter to the stroller
frame (Fig. 4A) until it clicks into a fully locked position (Fig. 4B). Place
car seat into car seat adapter until it “CLICKS” into a fully locked posi-
tion. Chicco car seats “CLICK” and lock on both sides of the adapter
when in a fully locked position (Fig. 4C). Make sure car seat is fully
fastened by pulling upward.
Fig. 4
Push downward on brake
lever to lock wagon
Lock The Rear Wheels:
Attaching Car Seat Adapter:
Securing Car Seat With Velcro Straps:
Locking Tabs
Located On Both
Sides Of Car Seat
Securing Car Seat With Velcro Straps:
Final step to secure the footrest side of car seat onto stroller, use the
straps with velcro to secure seat onto stroller. (Fig. 4D). Check that
car seat is securely attached by pulling up on the car seat. To remove,
undo latches and unlock car seat from adapter.
Removing Car Seat - To remove, squeeze release handle at back of
infant restraint and lift upward out of adapter.
Car Seat In A Fully
Locked Position
Car Seat Locking
Tabs Lock On Both
Sides When In A Fully
Locked Position
Graco SnugRide® Click Connect™ 30, 35, and 40
ATTACH GRACO
®
CAR SEATS
19
Customer Service [email protected] www.DeltaChildren.com
5
Car Seat Adapter -
Correct Placement
Car Seat Adapter Clicks And Locks On
Both Sides Of The Wagon Frame When
In A Fully Locked Position
Back
Front
Insert On
Both Sides
Fig. 5A
Fig. 5B
Fig. 5C:
Attaching Chicco Car Seats - Keyfit 30™:
Lock the rear wheels (Fig. 5). Attach the car seat adapter to the stroller
frame (Fig. 5A) until it clicks into a fully locked position (Fig. 5B). Place
car seat into car seat adapter until it “CLICKS” into a fully locked position.
Chicco car seats “CLICK” and lock on both sides of the adapter when
in a fully locked position (Fig. 5C). Make sure car seat is fully fastened by
pulling upward.
Fig. 5
Push downward on brake
lever to lock wagon
Lock The Rear Wheels:
Attaching Car Seat Adapter:
Securing Car Seat With Velcro Straps:
Locking Tabs
Located On Both
Sides Of Car Seat
Securing Car Seat With Velcro Straps:
Final step to secure the footrest side of car seat onto stroller, use the
straps with velcro to secure seat onto stroller. (Fig. 5D). Check that car
seat is securely attached by pulling up on the car seat. To remove, undo
latches and unlock car seat from adapter.
Removing Car Seat - To remove, squeeze release handle at back of
infant restraint and lift upward out of adapter.
Car Seat In A Fully
Locked Position
Car Seat Locking
Tabs Lock On Both
Sides When In A Fully
Locked Position
ATTACH CHICCO
®
CAR SEATS
Chicco Keyfit 30™
Fig. 5D
20
Customer Service [email protected] www.DeltaChildren.com
6
Car Seat Adapter -
Correct Placement
Car Seat Adapter Clicks And Locks On
Both Sides Of The Wagon Frame When
In A Fully Locked Position
Back
Front
Insert On
Both Sides
Fig. 6A
Fig. 6B
Fig. 6C:
Attaching Evenflo Car Seats - Evenflo®
Nurture™ and Embrace™
:
Lock the rear wheels (Fig. 6). Press both
buttons located on the front side of the
adapter and rotate into a downward position
(Fig. 6A). Attach the car seat adapter to the
stroller frame (Fig. 6B) until it clicks into a
fully locked position (Fig. 6C). Place car
seat into car seat adapter until it “CLICKS”
into a fully locked position. Evenflo car
seats “CLICK” and lock on the back of the
adapter when in a fully locked position (Fig.
6D). Make sure car seat is fully fastened by
pulling upward.
Fig. 6
Push downward on brake
lever to lock wagon
Lock The Rear Wheels:
Attaching Car Seat Adapter:
Securing Car Seat With Velcro Straps:
Locking Tabs
Located On Both
Sides Of Car Seat
Securing Car Seat With Velcro Straps:
Final step to secure the footrest side of car seat onto wagon, use the straps
with velcro to secure seat onto wagon. (Fig. 6D). Check that car seat is
securely attached by pulling up on the car seat. To remove, undo latches and
unlock car seat from adapter. NOTE: For Evenflo car seats, use extended
straps located on side of 5-in-1 infant car seat adapter.
Removing Car Seat - To remove, squeeze release handle at back of infant
restraint and lift upward out of adapter.
Car Seat In A Fully
Locked Position
Car Seat Locking
Tabs Lock On Both
Sides When In A Fully
Locked Position
ATTACH EVENFLO
®
CAR SEATS
Evenflo Nurture™ and Embrace™
Fig. 6D
Extended
Straps
21
Customer Service [email protected] www.DeltaChildren.com
7
Car Seat Adapter -
Correct Placement
Car Seat Adapter Clicks And Locks On
Both Sides Of The Wagon Frame When
In A Fully Locked Position
Back
Front
Insert On
Both Sides
Fig. 7A
Fig. 7B
Fig. 7C:
Attaching Britax Car Seats - B-Safe 35™
-
Lock the rear wheels (Fig. 7). Attach the car seat adapter to the wagon
frame (Fig. 7A) until it clicks into a fully locked position (Fig. 7B). Place
car seat into car seat adapter until it “CLICKS” into a fully locked position.
Britax car seats “CLICK” and lock on the both sides of the adapter
(Fig. 7C). Make sure car seat is fully fastened by pulling upward.
Fig. 7
Push downward on brake
lever to lock wagon
Lock The Rear Wheels:
Attaching Car Seat Adapter:
Securing Car Seat With Velcro Straps:
Locking Tabs
Located On Both
Sides Of Car Seat
Securing Car Seats With Velcro Straps -
Final step to secure the footrest side of car seat onto stroller, use the
straps with velcro to secure seat onto stroller. (Fig. 7D). Check that car
seat is securely attached by pulling up on the car seat. To remove, undo
latches and unlock car seat from adapter.
Removing Car Seat - To remove, squeeze release handle at back of
infant restraint and lift upward out of adapter.
Car Seat In A Fully
Locked Position
Car Seat Clicks And Locks Into
The Sides Of The Adapter
ATTACH BRITAX
®
CAR SEATS
Britax B-Safe 35™
Fig.7D
Delta Children's Products Corp.
114 West 26
th
Street
New York, NY 10001
www.DeltaChildren.com
© 2020 Delta Children's Products. All rights reserved.
