Model #: SC1D1 AUS, NZ
CUSTOMER SERVICE:
1800 663 866 (AUS) 0800 666 783 (NZ)
M3
FLOOR STEAM CLEANER
WITH ULTRA DRY STEAM
Floor Steam Cleaner with Frontal Steam Jet
INSTRUCTION MANUAL
Before using this product, please read the instructions and keep it for future references
S
t
e
a
m
B
o
o
s
t
e
r
SAVE THESE INSTRUCTIONS
When using an electrical appliance, basic safety precautions
should always be observed, including the following:
Read all instructions before using this appliance.
WARNING:
To reduce the risk of re, electrical shock, or injury:
1. This appliance is authorized for household/domestic use only.
2. Do not charge or use outdoors or on wet surfaces. Do not immerse the oor steamer in
water or other liquids.
3. Do not allow oor steamer to be used as a toy. Close attention is necessary when used
by or near children. Do not leave Steamer unattended. Always unplug unit when not
in use.
4. Use only as described and for the uses described in this manual. Use only manufac-
turer’s approved and supplied parts and accessories. Use of other accessories is not
recommended and will void the warranty.
5. Always make sure the Handle Assembly is in the upright “off” position before plugging
in or unplugging. Keep cord away from heated surfaces (e.g., cooking surfaces), and
sharp edges and corners.
6. Do not use if power cord or plug has been damaged, or if any part of appliance has
been dropped, damaged, left outdoors, or dropped in water. Do not attempt to disas-
semble or repair appliance. Return it to the manufacturer or an authorized service
center for examination or repair.
7. Do not wrap cord too tightly around appliance. Never carry by the cord or yank to
disconnect from an outlet. To unplug, always grasp plug to remove from outlet – do not
pull on cord.
8. Do not handle cord or appliance with wet hands or without shoes on.
9. Look closely at Steamer and follow all labels and marking instructions.
10. Do not put any objects into openings. Do not use with any opening blocked.
11. Before lling with water or emptying, always place Handle Assembly in upright “off”
position, unplug Steamer and allow it to cool completely.
12. Turn the Boiler Cap slowly to open the boiler – this will allow any remaining steam to
escape gradually.
13. Use caution while emptying the appliance. Contact with hot water or steam may
cause burns.
14. Be sure Boiler Cap is (and remains) closed and do not open during use.
15. The Antibak Tank Cover should never be opened during use except to rell while
Steamer is stationary.
16. Never use cleaning solutions, perfumes, oils, Antibak or substances other than tap or
distilled/demineralized water in the Boiler. Use of any chemicals in Boiler may damage
Steamer and will automatically void the warranty.
17. Antibak should ONLY be used in the Antibak Tank (as detailed on pages 9 and 10).
18. When in use, never turn the appliance on its side. Remove the plug from the socket-
outlet before cleaning or maintaining the appliance. Do not direct steam at people,
animals, plants or electrical equipment (i.e, inside an oven).
19. Do not operate around ammable or combustible liquids such as gasoline, or in areas
where fumes may be present.
20. To reduce the likelihood of circuit overload, do not operate another high wattage ap-
pliance on the same circuit. Plug in to a standard (220-240V, 50/600Hz) electrical outlet.
ATTENTION: This appliance is equipped with a 3-prong grounded power
cord. Insert only into a 3-prong grounded electrical outlet. Do not try to
remove the contacts of the grounded connection.
IMPORTANT SAFE
TY INSTRUCTIONS
2
Safety Instructions
SAVE THESE INSTRUCTIONS
FE
TY INSTRUCTIONS
21. Do not use extension cords or outlets with inadequate voltage.
22. Store appliance indoors in a cool, dry place.
23. If appliance or supply cord is damaged, it must be repaired by the manufacturer or an
authorized service agent to avoid safety issues or risk of danger to the operator.
24. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of appliance by a
person responsible for their safety. Children should be supervised to ensure that they
do not play with the appliance.
25. Do not use Antibak sanitizer on carpets or rugs (or any other soft furnishings such as
mattresses or lounge). When using the Carpet Glide on carpets or rugs, do not pull the
trigger on the Handle to dispense Antibak. The steam coming from the bottom of the
26. Read and follow all important notices in this guide.
result of improper use of the appliance, not in conformity with what’s
written in this instruction manual.
3
Safety Instructions
*IMPORTANT*
Please read all of the
instructions for use and
Important Safety
Instructions carefully.
Remove and discard all
packaging materials
and keep them out
of the reach of children.
WARNING
THIS FLOOR STEAMER WAS DESIGNED TO USE
ANTIBAK
CLEANING
SOLUTION
ONLY! DO NOT USE
ANY OTHER SOLUTION OR CLEANING
AGENT OR YOU WILL HARM THE STEAMER AND VOID THE WARRANTY.
CAUTIONS
• Do not use your Floor Steamer without a Hard Surface Pad or Carpet Glide &
Pad attached to the system.
• Never leave your Floor Steamer in one spot on any surface for any period
of time. Always place on the Parking Pad and make sure the Floor Steamer
Handle Assembly is in the fully upright position when not in use - this turns the
Steamer Off.
• DO NOT disassemble Floor Steamer after assembly. This will cause damage.
Save your back
No need to
press hard
The steamer
does the
work for you
Safety Informations in Digital Format: www.plastecs.it/warning
Attention: the photographs and/or drawings in this document are for illustrative purposes
only. Actual appliance and the accessories may vary due to product enhancement.
One (1) Floor Steamer
1
11
6
3
7
10
2
1 - Cord Winder
2 - Handle
3 - Metal Extension Tube
4 - Measuring Cup
(pre-marked)
5 - Filler Funnel
6 - Boiler Cap
7 - Steam Ready Indicator Light
(green)
8 - Power Indicator Light
(orange)
9 - Power Cord
10 - Front Steam Jets
11 - Antibak Tank Cover
12 - Carpet Pad
13 - Scrubbing Floor Pad (2)
14 - Carpet Glide
15 - Parking Pad
16 - Bottle of Antibak
17 - Antibak Tank Funnel
Product Feautres
4
Product Features
9
8
Technical Data
Adapter Input: 220-240V~, 50/60Hz
Cord Length: 7 m
Power: 1200 watts
Boiler: Stainless Steel
Boiler Capacity: 0.6 lt
Pressure: 3.5 bars
4
1/2 Cup
1 Cup
F
I
L
L
U
N
I
T
W
I
T
H
2
C
U
P
S
W
A
T
E
R
M
A
X
C
L
E
A
N
B
L
A
S
T
(
M
a
x
)
16
5
17
PARKING PAD
15
14
12
13
Before Use
5
Before Use
Assembly of Parts & Preparation of Steamer
Make sure all parts are in the box (see pg 4).
IMPORTANT: FOLLOW THESE INSTRUCTIONS CAREFULLY!
1
*IMPORTANT*
Frontal steam can only be generated when Extension Tube is in the
“Maximum Extension” position.
BE SURE EXTENSION TUBE IS FULLY
EXTENDED AND LOCKED IN PLACE FOR OPTIMAL STEAM OPERATION.
“Maximum Extension” Position
3. Snap the Locking Clamp closed, to
lock the Extension Tube in position.
Pull apart Extension Tube
A. Assemble Handle
After removing Handle Assembly from carton:
1. Pull Extension Tube apart until you see the lock opening
(hole) on the Tube.
2. Line up the peg on Locking Clamp with the
hole on Extension Tube and...
6
Before Use
Before Use
B. Attach Handle to Steamer
• Before starting, remove the self-tapping screw from the bottom
of Extension Tube.
• Insert the Handle Assembly into the Floor Steamer Base. Align
Arrow on Handle with Arrow on Base (as shown in Fig. A).
• Once inserted, twist Handle Assembly 90° clockwise (as shown
in Fig. B). Be sure Arrow on the Handle is aligned with Line/Lock
Icon on Base.
• Align the Handle Assembly
screw hole with the opening
in the steamer housing.
Secure the Handle assembly
with self-tapping screw
which was removed from
bottom of Extension Tube
(as shown in Fig. C).
Fig. A
Fig. B
Fig. C
Front View Side View
90°
7
Before Use
Before Use
ATTACHING CARPET GLIDE WITH CARPET PAD
place Carpet Pad on top of Carpet Glide. Hold
Floor Steamer over Carpet Glide and gently lower
the Steamer onto the Glide. Make sure the 4 clips
on Glide are around the outside of the Steamer
Base and using hands, attach the 4 clips of the
Carpet Glide to the Steamer Base.
USE ON HARDWOOD FLOORS –
For hardwood
Move Steamer forward and backward while
cleaning, carefully observing the amount of
steam used, as too much water could cause
damage.
C. Attach Cleaning Pads to Steamer
WARNING:
Scrubbing Floor Pad or the Carpet Glide Accessory with Carpet Pad
when using your Floor Steamer. NEVER USE WITHOUT EITHER OF THESE
ATTACHMENTS AFFIXED TO THE MACHINE.
ATTACHING SCRUBBING FLOOR PAD
A -
Heat Plate on
bottom of Base
provides additional
cleaning boost.
Scrubbing Floor Pad –
Place Scrubbing Floor Pad
center Scrub Strip facing down (and positioned to
match metal heat plate on bottom of Base-see“A”).
Hold Floor Steamer about 2” above Pad and gently
place Floor Steamer on the Pad. Firmly press down
to assure Pad is adhered to the Floor Steamer.
NOTE: See “Maintenance & Cleaning” for care and cleaning instructions for
IMPORTANT NOTE ABOUT LINOLEUM FLOORING
Steam can cause wax to be stripped from, and consequently damage, some
For some varieties of linoleum or vinyl floors the floor steamer is harder to push
forward and back.
Before Use
8
Before Use
D. Filling Boiler with Water
WARNINGS:
• Carefully read all instructions before removing Boiler Cap.
• Always unplug appliance before lling the Boiler.
• The appliance must be unplugged after use and before performing
user maintenance on the appliance.
Follow these instructions to avoid overlling
the Boiler.
• Be sure appliance is unplugged from the
electrical power outlet, and has
cooled for
at least 5 minutes before lling with water.
• Make sure Handle Assembly is in the
upright “off” position.
Remove Boiler Cap
by turning it counterclockwise.
• Pour in 600 mls of water using
the Measuring Cup and Filler
Funnel provided – ll cup to the
“200 ml” marking three times.
Be careful not to overll the
Boiler.
Please note that excess
water will be ushed out during
use if the Boiler is overlled, resul-
ting in wet oors.
• Replace Boiler Cap by turning it clockwise.
Do not tighten Boiler Cap too much – nger
tightening is sufcient to lock the steam in the Boiler.
If using cold water, heating time is about 3-5 minutes. If using warm
water, heating time is reduced.
*IMPORTANT*
Use ordinary tap water. Distilled or demineralized water is
recommended if tap water is too hard.
DO NOT add detergents,
perfumes, oils, Antibak or other chemical substances to the Boiler.
The product warranty will be null and void if anything other than
water is added to the Boiler.
100 ml
200 ml
A
N
T
(
M
a
x
*IMPORTANT*
Do not overll the Boiler as excess water will be ushed out of the Boiler
before dry steam will emit. If re-lling the Boiler while Steamer has been in
use, be sure to allow Steamer to cool for at least 5 minutes and loosen Boiler
Cap slowly to allow any excess steam to escape before completely removing
Cap. (See step 2D, “Relling Boiler During Use” for detailed instructions.)
100 ml
200 ml
A
N
T
I
B
A
K
(
M
a
x
)
9
Before Use
Before Use
Continued on next page
WARNING:
Do not put Antibak sanitizer in the
Boiler. This will damage the Steamer and it will
void the warranty.
E. The Antibak Sanitizing System
This Superclean Floor Steamer is equipped with a unique
surfaces (sealed wood, tile, marble, granite, linoleoum, etc.).
Included in this package is a 200 ml bottle of “Antibak”, a special
sanitizing agent that will quickly kill up to 99.9% of germs and bacteria.
The Antibak continues to work after it’s used, by killing bacterial spores
for up to 7 days following use. Be sure to use as directed.
C
A
Adding Antibak Sanitizer
• Push Antibak Tank Cover in the upward
direction (as shown in “A”) to reveal opening.
• Insert the small Antibak Tank Funnel in the
Antibak Tank.
Tank (Figs. “B” and “C”). Pour Antibak into
Measuring Cup up to the “Antibak (Max)”
marking. We recommend tilting the Steamer
Be careful
REMEMBER: YOU CAN FILL THE ANTIBAK TANK WHEN
THE STEAMER IS ON AND HOT. BUT NEVER FILL THE
BOILER TANK WHILE THE STEAMER IS HOT!
• Remove the small Antibak Tank Funnel from the
Antibak Tank.
D
Trigger
E
100 ml
200 ml
A
N
T
I
B
A
K
(
M
a
x
)
B
• Close the Antibak Tank Cover “D”.
• You can now sanitize on
demand by pulling back the
Trigger on the Handle “E”.
10
Before UseUsing Your Floor Steamer
Before Use & Using Your Floor Steamer
Using Your Floor Steamer
2
A. Using the Parking Pad
PARKING PAD
*IMPORTANT*
damage that can result from leaving a hot
steamer resting on the same spot for too
long. ALWAYS place Floor Steamer on the
Parking Pad when not in use, or while it is
cooling before storage.
You can use the Parking Pad if the Steamer
is warm or hot.
B. Starting the Appliance
Antibak (if using) has been added to Antibak Tank.
• Insert the plug into a-3 prong grounded
electrical outlet (orange Power Indicator Light
will illuminate).
• Keep the Handle in the upright “off”
position. Wait until the (green) Steam Ready
Indicator Light illuminates.
• Once Boiler is lled and the green Steam Ready
Indicator Light illuminates, the Floor Steamer is
ready to clean.
PLEASE NOTE: The green Steam Ready Indicator
Light will turn on and off during
use. This is normal and not a fault.
F
The Steamer was designed to be used with
Antibak only. Any other cleaning solution used
may harm your Steamer and will void the warranty.
HINT: A little Antibak
E. The Sanitizing System (continued)
• The sanitizer is delivered to the surface only
through the front ports of the Steamer “F”.
WARNING:
Only use Antibak sanitizer in the
Antibak Tank located on the front of Steamer.
*IMPORTANT*
Do not use Antibak sanitizer on carpets or rugs (or any other soft furnishings
such as mattresses or lounge). When using the Carpet Glide on carpets or rugs,
do not pull the trigger on the Handle to dispense Antibak. The steam coming
11
Using Your Floor Steamer
Using Your Floor Steamer
To Use the Sanitizing System
The Superclean Steamer will
surfaces by using a sanitizing agent
called Antibak. The Antibak will
the growth of bacterial spores for 7
days after use.
To sanitize
9 of this manual.
To release
pull the trigger on the Handle. The
Antibak will mix into the steam as it exits from the 4 front steam jets. Push the
A small amount of Antibak goes a long way. One pull of the trigger will release
enough Antibak to cover an area of 1 meter by 1 meter. The Antibak sanitizer
that is mixed with the steam coming from the front jets will get under furniture
and cabinets and disinfect to a distance of 30 cm.
bottles can be purchased from the appliance retailer who sold you the
Superclean Floor Steamer.
To stop steam,
simply return Handle to the upright position.
The Floor Steamer will stop producing steam when the
according to the instructions (see step 2D,
During Use”).
C. Using Floor Steamer
• To start cleaning using the
bottom steam ports, simply pull
the Handle downward.
Always
.
Steamer can easily clean most
steam alone.
NOTE:
REMINDER:
If Floor or Carpet Pad become too wet or too
dirty, replace with a clean, dry Pad and continue cleaning.
*IMPORTANT*
Do not use Antibak sanitizer on carpets or rugs (or any other soft furnishings
such as mattresses or lounge). When using the Carpet Glide on carpets or rugs,
do not pull the trigger on the Handle to dispense Antibak. The steam coming
steamer back and forth on the floor to spread the Antibak.
12
Using Your Floor Steamer
Using Your Floor Steamer
WARNING:
Let Steamer cool 5 minutes before opening Boiler Cap.
Use care when opening Boiler Cap as it may still be hot and steam
may escape, causing burns. If Boiler is still hot, water may spurt out
during relling which can also cause burns.
•
Unplug the appliance from the electrical power outlet. This will stop
the Steamer from continuing to heat up.
• Once unplugged from the power outlet, place Handle in the “On”
position to release any residual steam and pressure from the Boiler.
• After all steam and pressure has been expressed from the Steamer,
return the Handle to the upright “Off” position.
• Slowly turn Boiler Cap counterclockwise. This will allow remaining
steam to escape.
•
Be sure Steamer has cooled 5 minutes before relling with water.
The product warranty will be null and void if
anything other than water is added to the Boiler.
• Pour in 600 mls of water using the Measuring Cup
and Filler Funnel provided – ll the Measuring
Cup to the 200 ml marking 3 times. Be careful
not to overll the Boiler.
• Replace Boiler Cap by turning it clockwise.
Do not tighten Boiler Cap too much – nger
tightening is sufcient to lock the steam in
the Boiler.
• Insert plug into 3-prong electrical outlet. Wait for
green Steam Ready Indicator Light to turn on. Steamer is ready to use
once again.
D. Relling Boiler During Use
When the Floor Steamer has run out of water, there will be no more
steam coming out of the unit. At this stage it is time to rell the Boiler.
Follow the relling instructions below.
100 ml
200 ml
A
N
T
(
M
a
x
*IMPORTANT*
The Floor Steamer has a Boiler that should not be overlled. To avoid the
potential for overlling, only rell the Boiler when it is completely run out of
water and only add 600ml. Always follow the practice of using the Floor Steamer
until it has run out of water and then rell 600ml only.
If oor cleaning is completed and water remains in the Boiler, the Floor Steamer
can be stored with the remaining water in the Boiler, there will be no harm done
to the unit. At the next cleaning session simply heat up the unit and use the
water already in the Boiler, then rell when empty.
Or alternatively at the next cleaning session, open the Boiler Cap when the unit
is still cold and pour out the water and then rell (if this alternative method is
used, it is recommended that only 500ml of water is added, because the unit
will not completely drain when the water is poured out from the Boiler).
13
Using Your Floor Steamer & Maintenance & Cleaning
Using Your Floor Steamer Maintenance & Cleaning
*IMPORTANT*
Boiler before dry steam will emit.
If distilled or demineralized water is regularly used in the Steamer,
cleaning of the Boiler can be done less frequently. In some areas tap
water is very hard, it is recommended that the Boiler is cleaned more
frequently if hard water is used.
The cleaning of the Boiler and Steamer is the sole responsibility of the
appliance owner. Calcium, mineral deposits and other sediment left
to build up in the Floor Steamer causing the Steamer to fail and/or the
steam pathways in the Steamer to block, is not covered by the product
warranty. Users must follow the cleaning instructions above.
If the Steamer and Boiler are not cleaned according to the instruc-
tions above and the product fails and/or the steam pathways are
blocked, the appliance owner should send the product for servicing
by contacting the Customer Support Line.
The Superclean Floor Steamer is intended for domestic
household use only. It is not intended for commercial use. Any use other
than for domestic household purposes will void the product warranty.
Cleaning the Floor Steamer
We recommend you periodically clean the Floor Steamer to prevent
the accumulation of calcium, mineral deposits and other sediment
three-quarters full of hot tap water, shake several times and empty
out the water into sink. Repeat several times to ensure that the Boiler
base with a damp cloth and dry.
NEVER HOLD THE STEAMER UNDER THE TAP TO FILL. Use the Measuring
3
REMINDERS
• Always use ordinary tap water.
• If tap water is too hard, use distilled or demineralized water to
avoid the risk of mineral deposits and sediment from forming.
• Do not add detergents, perfumes, oils or other chemical
substances to the Boiler or Antibak Tank. This will damage the
Steamer and void the warranty.
• The green Steam Ready Indicator Light may turn on and off during
use. This is normal and not a fault.
• Only use Antibak sanitizer in the front Ant
ibak Tank.
14
Maintenance & Cleaning
Maintenance & Cleaning
regularly, either by hand (using mild soap and warm water) or in your
clothes washer on a delicate cycle, cool water. Never use fabric
softener or bleach. We recommend letting Pads air dry to maintain
maximum long term effectiveness.
Replacement pads are available at most retail outlets or by calling
customer service.
SCRUBBING FLOOR PAD
75% Polyester / 25% Polyamide
Hand wash only
Tumble dry low or air dry
No bleach / No fabric softener
CARPET PAD
80% Polyester / 20% Polyamide
Hand wash only
Tumble dry low or air dry
No bleach / No fabric softener
*IMPORTANT*
Do not add detergents, perfumes, oils, or other chemicals to the Boiler.
The product warranty will be null and void if anything other than water is
added to the Boiler.
15
Troubleshooting
Troubleshooting
IMPORTANT QUESTION:
Steamer?
A. YES!
Floor Steamer should NEVER be used without either a Hard Surface
Floor Pad or Carpet Glide with Carpet Pad.
Issues Possible Causes Solutions
Steam is not coming out of the Improper Handle assembly. Call Customer Service to receive instructions
Steam Nozzles. to correct the problem.
The Scrubbing Floor Pad Not enough pressure was Position Steamer about 2” above Pad and
is not adhering to Steamer. applied when attaching Pad. FIRMLY press it down onto the Pad.
Floor Pad requires replacing Replacement Floor Pads can be purchased at
due to age of the Floor Pad. most electrical appliance retail outlets.
The Cleaning Pads are getting Boiler is overfilled. Let Steamer run until excess water ceases.
soaked (too wet). Why? -OR- Remove some water from Boiler once
the Boiler has cooled down completely.
Green “Steam Ready Indicator Wait for green “Steam Ready Indicator Light”
Light” is not illuminated. to illuminate.
The steam seems to be Front Steam Jets are being Only use Front Steam Jets in short bursts for
making my floor too wet. used too frequently. cleaning tougher stains or to clean hard to
reach areas.
Antibak Sanitizer Trigger is Pull the Trigger less frequently, use more
being used too often. sparingly.
The Cleaning P
ad is too wet Replace the wet Pad with a dry, clean Pad
(saturated with moisture) and continue cleaning.
The Antibak is running out Trigger is being used too Pull Trigger less frequently and use Antibak
quickly. frequently. more sparingly.
SC1D1 (Australia/NZ) REV1 09/18
EFLX-092AB
Customer Support
Customers needing assistance with their Floor Steamer can call the Customer Support Line on the phone
numbers listed below. Customers should also call the Customer Support Line if they require product
warranty repair or post-warranty product servicing.Our friendly Customer Service Team can assist you with
getting the best cleaning results from your Floor Steamer, they are full of helpful steam cleaning tips, too.
Customer Support Line
AUSTRALIA 1800 663 866
NEW ZEALAND 0800 666 783
Euroflex Australia Pty Ltd
79 Furniss Road
DARCH WA 6065
AUSTRALIA
TEL: 08 9302 2526
Email: [email protected]
Website: www.euroflex.com.au
Euroflex New Zealand Ltd
c/- Dubins
137 Glenfield Road
Birkenhead Auckland 0626
NEW ZEALAND
TEL: 0800 666 783
Email: [email protected]
Website: www.euroflex.com.au
Plastecs SRL
Via dei Colli, 59
31058 Susegana (TV)
ITALY
Tel: +39 0438 453334
Email: [email protected]
Website: www.euroflex-appliances.com
