MOTORIZED WATER SHUTOFF VALVE
1
7382283 (Rev. B 8/14/20)
The Motorized Water Shutoff Valve may be used with a
W
i-Fi connected water softener and the iQua™ app to
remotely turn off the home’s water supply. For
example, you may want to turn off the water when
going away on vacation. Install the motorized shutoff
valve in the plumbing, upstream of the softener (see
page 2), and plug the cable into the softener’s electron-
i
c control board with the power off (see page 2 and
Schematic Figure 1).
On the iQua™ app, near the bottom of the softener’s
main dashboard, there is a line labeled “Water Control”
with a button that, when pressed, alternates between
“Water On” and “Water Off”. If you receive an alert indi-
cating continuous water flow, you can use this control to
r
emotely shut off the water.
The system default for triggering a continuous water
flow alert is 20 minutes of flow at 0.4 gallons per minute
or higher. The time and water flow trigger values may
a
lso be adjusted in the “Alerts” section.
To manually operate the motorized water shutoff valve,
pull out the round knob on the valve and turn it until the
red line in the sight glass matches the desired (open or
closed) position. See Figure 2. If you manually
operate the valve, the app’s “Water Control” feature will
be disabled until you reset it by clicking “Yes” next to
the “Regain Control?” prompt.
OPEN
Motorized Water Shutoff Valve
Knob -
pull out
to turn
OPEN
CLOSED
Sight
glass
FIG. 2
ONE YEAR LIMITED WARRANTY
Warrantor: Water Channel Partners, 1890 Woodlane Drive, Woodbury, MN 55125
Warrantor guarantees, to the original owner, that the Motorized Water Shutoff Valve, when installed and maintained in
accordance with the instructions, will be free from defects in materials and workmanship for a period of one year from date of
installation. If, within the first year, a part proves, after inspection, to be defective, Warrantor will, at its sole option, either replace
or repair the part without charge except installation charges. Labor to maintain the equipment is not part of the warranty.
TO OBTAIN WARRANTY PARTS, SIMPLY CALL 1-800-693-1604 for assistance. This warranty applies only while this product is
in use in the United States or Canada.
General Provisions
The above warranties are effective provided the Motorized Water Shutoff Valve is operated at water pressures not exceeding 100 psi, and at
water temperatures not exceeding 100°F; provided further that the Motorized Water Shutoff Valve is not subject to abuse, misuse, alteration,
neglect, freezing, accident or negligence; and provided further that the Motorized Water Shutoff Valve is not damaged as the result of any
unusual force of nature such as, but not limited to, flood, hurricane, tornado or earthquake. Warrantor is excused if failure to perform its warranty
obligations is the result of strikes, government regulation, materials shortages, or other circumstances beyond its control.
THERE ARE NO WARRANTIES ON THE WHOLE HOME WATER FILTRATION SYSTEM BEYOND THOSE SPECIFICALLY DESCRIBED
ABOVE. ALL IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR OF FITNESS FOR A
PARTICULAR PURPOSE, ARE DISCLAIMED TO THE EXTENT THEY MIGHT EXTEND BEYOND THE ABOVE PERIODS. THE SOLE OBLI-
GATION OF WARRANTOR UNDER THESE WARRANTIES IS TO REPLACE OR REPAIR THE COMPONENT OR PART WHICH PROVES TO
BE DEFECTIVE WITHIN THE SPECIFIED TIME PERIOD, AND WARRANTOR IS NOT LIABLE FOR CONSEQUENTIAL OR INCIDENTAL
DAMAGES. NO WARRANTOR DEALER, AGENT, REPRESENTATIVE, OR OTHER PERSON IS AUTHORIZED TO EXTEND OR EXPAND
THE WARRANTIES EXPRESSLY DESCRIBED ABOVE.
Some states do not allow limitations on how long an implied warranty lasts or exclusions or limitations of incidental or consequential damage, so
the limitations and exclusions in this warranty may not apply to you. This warranty gives you specific legal rights, and you may have other rights
which vary from state to state. This warranty applies to consumer-owned installations only.
Back of Electronic
Control Board
Valve
Motor
Power
Supply
Turbine
Sensor
Valve Position
Switch
Auxiliary
Output
Motorized
Water Shutoff
Valve
Wiring Schematic
FIG. 1
