Network Speed Dome
User Manual
Legal Informaon
©2020 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in v
arious jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DE
SCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND “WITH
ALL FAULTS AND ERRORS”. HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
Network Speed Dome User Manual
i
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.
Network Speed Dome User Manual
ii
Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Product Introducon .............................................................................................................. 1
1.2 Key Funcon .......................................................................................................................... 1
1.3 System Requirement .............................................................................................................. 1
Chapter 2 Device Acvaon and Accessing ................................................................................. 3
2.1 Acvate Device ...................................................................................................................... 3
2.1.1 Acvate Device via Web Browser .................................................................................. 3
2.1.2 Acvate via SADP .......................................................................................................... 4
2.2 Access Device via Web Browser ............................................................................................. 5
2.2.1 Plug-in Installaon ........................................................................................................ 5
2.2.2 Admin Password Recovery ............................................................................................ 6
2.2.3 Illegal Login Lock ........................................................................................................... 6
Chapter 3 Face Capture .............................................................................................................. 7
3.1 Set Auto Face Capture Rule .................................................................................................... 7
3.1.1 Normal Mode Sengs .................................................................................................. 7
3.1.2
Expert Mode
Sengs .................................................................................................... 8
3.2 Operate Manual Face Capture ............................................................................................... 9
3.3 Overlay and Capture .............................................................................................................. 9
3.4 Face Capture Algorithm Parameters .................................................................................... 10
Chapter 4 PTZ ........................................................................................................................... 12
4.1 PTZ Control .......................................................................................................................... 12
4.2 Set Preset ............................................................................................................................. 14
4.2.1 Special Presets ............................................................................................................ 14
4.3 Set Patrol Scan ..................................................................................................................... 15
4.3.1 Set One-Touch Patrol .................................................................................................. 16
4.4 Set Paern Scan ................................................................................................................... 16
Network Speed Dome User Manual
iii
4.5 Set Limit ............................................................................................................................... 17
4.6 Set Inial Posion ................................................................................................................ 17
4.7 Set Scheduled Tasks ............................................................................................................. 18
4.8 Set Park Acon ..................................................................................................................... 18
4.8.1 Set One-Touch Park ..................................................................................................... 18
4.9 Set Privacy Mask .................................................................................................................. 19
4.10 Set Smart Tracking ............................................................................................................. 19
4.11 Set Device Posion ............................................................................................................. 20
4.12 Set Power O Memory ...................................................................................................... 20
4.13 Set PTZ Priority ................................................................................................................... 20
4.14 Set Rapid Focus .................................................................................................................. 21
Chapter 5 Live View .................................................................................................................. 22
5.1 Live View Parameters ........................................................................................................... 22
5.1.1 Start and Stop Live View ............................................................................................. 22
5.1.2 Aspect
Rao ................................................................................................................ 22
5.1.3 Live View Stream Type ................................................................................................ 22
5.1.4 Quick Set Live View ..................................................................................................... 22
5.1.5 Select the Third-Party Plug-in ..................................................................................... 23
5.1.6 Start Digital Zoom ....................................................................................................... 23
5.1.7 Conduct Regional Focus .............................................................................................. 23
5.1.8 Conduct Regional Exposure ........................................................................................ 23
5.1.9 Count Pixel .................................................................................................................. 24
5.1.10 Light .......................................................................................................................... 24
5.1.11 Operate Wiper .......................................................................................................... 24
5.1.12 Lens Inializaon ...................................................................................................... 24
5.1.13 T
rack Manually .......................................................................................................... 25
5.1.14 Conduct 3D Posioning ............................................................................................. 25
5.1.15 OSD Menu ................................................................................................................. 25
Network Speed Dome User Manual
iv
5.1.16 Display Target Informaon on Live View ................................................................... 25
5.2 Set Transmission Parameters ............................................................................................... 26
5.3 Smart Display ....................................................................................................................... 27
Chapter 6 Video and Audio ....................................................................................................... 28
6.1 Video Sengs ...................................................................................................................... 28
6.1.1 Stream Type ................................................................................................................ 28
6.1.2 Video Type .................................................................................................................. 28
6.1.3 Resoluon ................................................................................................................... 28
6.1.4 Bitrate Type and Max. Bitrate ..................................................................................... 29
6.1.5 Video Quality .............................................................................................................. 29
6.1.6 Frame Rate .................................................................................................................. 29
6.1.7 Video Encoding ........................................................................................................... 29
6.1.8 I-Frame Interval ........................................................................................................... 31
6.2 Audio Sengs ...................................................................................................................... 31
6.2.1 Audio Input
................................................................................................................. 31
6.2.2 Audio Output .............................................................................................................. 32
6.2.3 Environmental Noise Filter .......................................................................................... 32
6.3 Two-way Audio .................................................................................................................... 32
6.4 ROI ....................................................................................................................................... 33
6.4.1 Set ROI ........................................................................................................................ 33
6.4.2 Set Target Tracking ROI ............................................................................................... 33
6.4.3 Set Face Tracking ROI .................................................................................................. 34
6.5 Display Info. on Stream ........................................................................................................ 34
6.6 Display Sengs .................................................................................................................... 34
6.6.1 Scene Mode
................................................................................................................ 35
6.6.2 Image Parameters Switch ............................................................................................ 38
6.6.3 Mirror .......................................................................................................................... 39
6.6.4 Video Standard ........................................................................................................... 39
Network Speed Dome User Manual
v
6.7 OSD ...................................................................................................................................... 39
Chapter 7 Video Recording and Picture Capture ........................................................................ 41
7.1 Storage Sengs ................................................................................................................... 41
7.1.1 Se
t Memory Card ........................................................................................................ 41
7.1.2 Set FTP ........................................................................................................................ 42
7.1.3 Set NAS ....................................................................................................................... 43
7.2 Video Recording ................................................................................................................... 44
7.2.1 Record Automacally .................................................................................................. 44
7.2.2 R
ecord Manually ......................................................................................................... 45
7.2.3 Playback and Download Video .................................................................................... 45
7.3 Capture Conguraon .......................................................................................................... 46
7.3.1 Capture Automacally ................................................................................................ 46
7.3.2 Capture Manually ........................................................................................................ 46
7.3.3 View and Download Picture ........................................................................................ 47
Chapter 8 Event and Alarm ....................................................................................................... 48
8.1 Basic Event ........................................................................................................................... 48
8.1.1 Set Moon
Detecon .................................................................................................. 48
8.1.2 Set Video Tampering Alarm ........................................................................................ 50
8.1.3 Set Excepon Alarm .................................................................................................... 51
8.1.4 Set Alarm Input ........................................................................................................... 52
8.2 Smart Event .......................................................................................................................... 52
8.2.1 Detect Audio Excepon ............................................................................................... 52
8.2.2 Se
t Intrusion Detecon ............................................................................................... 53
8.2.3 Set Line Crossing Detecon ......................................................................................... 54
8.2.4 Set Region Entrance Detecon ................................................................................... 56
8.2.5 Se
t Region Exing Detecon ....................................................................................... 57
8.2.6 Set Object Removal Detecon .................................................................................... 58
8.2.7 Set Unaended Baggage Detecon ............................................................................ 59
Network Speed Dome User Manual
vi
Chapter 9 Arming Schedule and Alarm Linkage ......................................................................... 62
9.1 Set Arming Schedule ............................................................................................................ 62
9.2 Linkage Method Sengs ...................................................................................................... 62
9.2.1 T
rigger Alarm Output .................................................................................................. 62
9.2.2 FTP/NAS/Memory Card Uploading ............................................................................. 63
9.2.3 Send Email .................................................................................................................. 64
9.2.4
Nofy Surveillance Center .......................................................................................... 65
9.2.5 Smart Tracking ............................................................................................................ 65
9.2.6 Trigger Recording ........................................................................................................ 65
9.2.7 Flashing Light .............................................................................................................. 65
9.2.8 Audible Warning ......................................................................................................... 66
Chapter 10 Network Sengs .................................................................................................... 67
10.1 TCP/IP ................................................................................................................................. 67
10.1.1
Mulcast ................................................................................................................... 68
10.1.2 Mulcast Discovery ................................................................................................... 68
10.2 Port .................................................................................................................................... 68
10.3 Port Mapping ..................................................................................................................... 69
10.3.1 Set Auto Port Mapping .............................................................................................. 70
10.3.2 Set Manual Port Mapping ......................................................................................... 70
10.3.3 Set Port Mapping on Router ..................................................................................... 70
10.4 SNMP ................................................................................................................................. 71
10.5 Access to Device via Domain Name ................................................................................... 72
10.6 Access to Device via PPPoE Dial Up Connecon ................................................................ 72
10.7 Accessing via Mobile Clien
t ................................................................................................ 73
10.7.1 Enable Hik-Connect Service on Camera .................................................................... 73
10.7.2 Set Up Hik-Connect ................................................................................................... 74
10.7.3 Add Camera to Hik-Connect ...................................................................................... 75
10.8 Wi-Fi ................................................................................................................................... 75
Network Speed Dome User Manual
vii
10.8.1 Connect Device to Wi-Fi ............................................................................................ 76
10.9 Set ISUP .............................................................................................................................. 76
10.10 Set Open Network Video Interface .................................................................................. 76
10.11 Set Network Service ......................................................................................................... 77
10.12 Set Alarm Server .............................................................................................................. 78
10.13 TCP Acceleraon .............................................................................................................. 78
10.14 Trac Shaping .................................................................................................................. 78
Chapter 11 System and Security ................................................................................................ 79
11.1 View Device Informaon .................................................................................................... 79
11.2 Restore and Default ........................................................................................................... 79
11.3 Search and Manage Log ..................................................................................................... 79
11.4 Import and Export Conguraon File ................................................................................ 80
11.5 Export Diagnose Informaon ............................................................................................. 80
11.6 Reboot ............................................................................................................................... 80
11.7 Upgrade ............................................................................................................................. 80
11.8 View Open Source Soware License .................................................................................. 81
11.9 Se
t Live View Connecon ................................................................................................... 81
11.10 Time and Da
te .................................................................................................................. 81
11.10.1 Synchronize Time Manually .................................................................................... 81
11.10.2 Set NTP Server ........................................................................................................ 81
11.10.3 Set DST .................................................................................................................... 82
11.11 Set RS-485 ........................................................................................................................ 82
11.12 Security ............................................................................................................................ 82
11.12.1 Authencaon ........................................................................................................ 83
11.12.2 Se
t IP Address Filter ................................................................................................ 83
11.12.3 Set HTTPS ................................................................................................................ 84
11.12.4 Security Audit Log ................................................................................................... 85
11.12.5 Set QoS .................................................................................................................... 86
Network Speed Dome User Manual
viii
11.12.6 Set IEEE 802.1X ....................................................................................................... 86
11.12.7 User and Account .................................................................................................... 87
Appendix A. Device Command .................................................................................................. 89
Appendix B. Device Communicaon Matrix .............................................................................. 90
Network Speed Dome User Manual
ix
Chapter 1 Overview
1.1 Product Introducon
E Series Network Speed Dome is an integraon of the HD zoom camera and the PT module, ideal
for remote monitoring. The device is easy to install and operate. The device has basic funcons,
such as presets and scans. Through Ethernet control, the device is able to compress and transmit
images to mulple users. With network aached storage (NAS), the device is able to store and
retrieve data easily.
The device is well suited for HD monitoring in various places, such as rivers, forests, roads, railways,
airports, ports, oil elds, posts, squares, parks, scenic areas, streets, staons, stadiums, residenal
blocks, prisons, libraries, shopping malls, hotels, government buildings, museums, and banks.
1.2 Key Funcon
The key funcons of the device are as follows. Actual funcons may vary for dierent models. You
can enable the funcons as you need.
Audio and Visual Alarm
The device supports ashing light alarm and audio alarm to warn intruders o.
Face Capture
The device captures human faces and uploads the pictures to the center.
Event Funcon
The device detects basic events and mulple smart events.
PTZ
Funcon
The device supports PTZ funcons, such as presets, scans, patrol, and power-o memory.
1.3 System Requirement
Your computer should meet the requirements for proper vising and operang the product.
Recommended Specicaons
Operang System Microso Windows XP/ Windows 7/ Windows 8/ Windows 10
Mac OS 10.13 or la
ter
CPU Intel® Penum® IV 3.0 GHz or higher
RAM 1 G or higher
Network Speed Dome User Manual
1
Recommended Specicaons
Display 1024 × 768 resoluon or higher
Web Browser Internet Explorer 10 and above version, Apple Safari 12 and above
version, Mozilla Firefox 52 and above version, Google Chrome 57 and
above version.
Network Speed Dome User Manual
2
Chapter 2 Device Acvaon and Accessing
To protect the security and privacy of the user account and data, you should set a login password
to acvate the device when access the device via network.
Note
Refer to the user manual of the soware client for the detailed informaon about the client
soware acvaon.
2.1
Acvate Device
The device need to be acvated by seng a strong password before use. This part introduces
acvaon using dierent client tools.
2.1.1 Acvate Device via Web Browser
Use web browser to acvate the device. For the device with the DHCP enabled by default, use
SADP
soware or PC client to acvate the device.
Before You Start
Make sure your device and your PC connect to the same LAN.
Steps
1. Change the IP address of your PC to the same subnet as the device.
The default IP address of the device is 192.168.1.64.
2. Open a web browser and input the default IP address.
3. Create and conrm the admin password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
y
our own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
4. Click OK t
o complete acvaon and enter Live View page.
5. Modify IP address of the camera.
1) Enter IP address modicaon page. Conguraon → Network → TCP/IP
2) Change IP address.
3) Save the sengs.
Network Speed Dome User Manual
3
2.1.2 Acvate via SADP
SADP is a tool to detect, acvate and modify the IP address of the device over the LAN.
Before You Start
• Get the SADP soware
from the supplied disk or the ocial website
hp://
www.hikvision.com/ , and install the SADP according to the prompts.
•
The device and the PC that runs the SADP tool should belong to the same subnet.
The following steps show how to acvate one device and modify its IP address. For batch acvaon
and IP address modicaon, refer to User Manual of SADP for details.
Steps
1. Run the SADP soware
and search the online devices.
2. Find and select your device in online device list.
3. Input new password (admin password) and conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
y
our own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
4. Click Acvate
to start acvaon.
Status of the device becomes Acve aer successful acvaon.
5. Modif
y IP address of the device.
1) Select the device.
2) Change the device IP address to the same subnet as your computer by either modifying the
IP address manually or checking Enable DHCP.
3) Input the admin password and click Modify to acvate your IP address modicaon.
Network Speed Dome User Manual
4
2.2 Access Device via Web Browser
Before You Start
Check the system requirement to conrm that the
operang computer and web browser meets
the requirements. See System Requirement .
Steps
1. Open the web browser.
2. Input IP address of the device to enter the login interface.
3. Input user name and password.
Note
Illegal login lock is acvated by default. If admin user performs seven failed password aempts
(v
e aempts for user/operator), the IP address is blocked for 30 minutes.
If illegal login lock is not needed, go to Conguraon → System → Security → Security Service
to turn it o.
4. Click Login.
5. Do
wnload and install appropriate plug-in for your web browser.
For IE based web browser, webcomponents and QuickTime
TM
are oponal. For non-IE based
w
eb browser, webcomponents, QuickTime
TM
, VLC and MJEPG are oponal.
2.2.1 Plug-in Installaon
Certain operaon systems and web browser may restrict the display and operaon of the device
funcon. You should install plug-in or complete certain sengs to ensure normal display and
operaon. For detailed restricted funcon, refer to the actual device.
Operang System Web Browser Operaon
Windows Internet Explorer 10+ Follow pop-up prompts to
complete plug-in installaon.
Windows 7 and above version Google Chrome 57+
Mozilla Firefox 52+
Click to
do
wnload and install plug-in.
Mac OS Google Chrome 57+
Mo
zilla Firefox 52+
Mac Safari 12+
Plug-in installaon is not
required.
Go to Conguraon →
Network → Advanced Sengs
→ Network Service to enable
WebSocket or Websockets for
normal view. Display and
operaon of certain funcons
Network Speed Dome User Manual
5
Operang System Web Browser Operaon
are restricted. For example,
Playback and Picture are not
available. For detailed
restricted funcon, refer to the
actual de
vice.
Note
The device only supports Windows and Mac OS system and do not support Linux system.
2.2.2 Admin Password Recovery
If you forget the admin password, you can reset the password by clicking F
orget Password on the
login page aer compleng the account security sengs.
You can reset the password by seng the security queson or email.
Note
When you need to reset the password, make sure that the device and the PC are on the same
ne
twork segment.
Security Queson
You can set the account security during the acvaon. Or you can go to Conguraon → S
ystem →
User Management , click Account Security Sengs, select the security queson and input your
answer.
You can click Forget Password and answer the security queson to reset the admin password when
access the de
vice via browser.
Email
You can set the account security during the acvaon. Or you can go to Conguraon → System →
User Management , click Account Security Sengs, input your email address to receive the
vericaon code during the recovering operaon process.
2.2.3 Illegal Login Lock
It helps to improve the security when accessing the device via Internet.
Go t
o Conguraon → S
ystem → Security → Security Service , and enable Enable Illegal Login
Lock.
With the funcon enabled, the device is locked aer 7 connuous failed login aempts.
Network Speed Dome User Manual
6
Chapter 3 Face Capture
Face capture funcon detects and captures faces in surveillance scenes. When the grading of the
detected face exceeds an algorithm-dened value, the PTZ camera channel captures the face and
triggers linkage acons. Set up rule and parameters before using the funcon.
Note
• For certain device models, you need to select F
ace Capture on VCA Resource page rst.
• This funcon is only supported by certain device models.
3.1 Set Auto Face Capture Rule
Aer set the face capture rules and algorithm parameters, the device captures faces and trigger
link
age acons
automacally.
Steps
1. Go to Conguraon → F
ace Capture → Rule .
2. Check Enable.
3. Select a conguraon mode.
Normal One detecon scene is allowed to set. The device captures face in the scene in set
arming schedule.
See Normal Mode
Sengs for details.
Expert The device can patrol among the detecon scenes and capture face images.
Detecon scenes and patrol schedule should be set in advance.
See Expert Mode Sengs for details.
4. Click Sa
ve.
What to do next
Go to Picture to search and view the captured pictures.
Go to Smart Display to see currently captured face pictures.
3.1.1 Normal Mode Sengs
Steps
1. Oponal: Click Lock t
o lock PTZ control to prevent the interrupon from other PTZ related
acon during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
2. Use PTZ control panel or click
to locate a scene with a face.
3. Click , and draw a detecon area on live image.
Network Speed Dome User Manual
7
4. Input Mounng Height of the de
vice.
5. Input or draw the min. pupil distance and the max. pupil distance.
The Min. Pupil Distance and the Max. Pupil Distance are used to improve detecon accuracy.
Only targets whose pupil distance are between the maximum distance and the minimum
distance trigger the capture.
Click
and to draw the distance on live image, or input values in the text elds of Min. Pupil
Dis
tance and Max. Pupil Distance.
6. Click Save.
7. Set arming schedule. See Set Arming Schedule .
8. Set linkage method. See Linkage Method Sengs .
3.1.2 Expert Mode Sengs
Steps
1. Oponal: Click Lock to lock PTZ control to prevent the interrupon from other PTZ related
acon during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
2. Input Mounng Height of the device.
3. Set detecon scenes and detecon areas.
1) Select a detecon scene.
2) Adjust the live image to a desired scene. You can use PTZ control buons or click
to locate
a scene with a f
ace.
3) Click
, and draw a detecon area on live image.
4)
Input or draw the min. pupil distance and the max. pupil distance.
The Min. Pupil Distance and the Max. Pupil Distance are used to improve detecon
accuracy. Only targets whose pupil distance are between the maximum distance and the
minimum dis
tance trigger the capture.
Click
and to draw the distance on live image, or input values in the text elds of Min.
Pupil Dis
tance and Max. Pupil Distance.
5) Click Save.
6) Repeat above steps to set other detecon scenes and areas.
4. Se
t patrol schedule.
1) Click Patrol Schedule.
2) Draw me bars as desired.
3)
Click a me bar and click Conguraon.
4) Edit patrol path and input dwell me for each detecon scene.
Add a detecon scene to the patrol path.
Adjust the order of the scenes.
Delete the detecon scene.
Network Speed Dome User Manual
8
5) Click Save.
5. Set linkage method. See Linkage Method Sengs .
3.2 Operate Manual Face Capture
Capture the target face manually in live view image.
St
eps
1. Click Live View.
2. Click
to start manual face capture.
3. Draw a frame to select the target face in live view image.
The captured picture can be uploaded to the center.
4. Click the icon again to stop manual face capture.
3.3 Overlay and Capture
Choose to congure capture parameters and the informaon you want to display on stream and
picture.
Display on Stream
Display smart informaon on stream, including the target and rules informaon.
Display on Picture
Ov
erlay the alarm picture with target informaon.
Target Picture Sengs
You can set the face picture type by selecng Cus
tom, Head Shot, Half-Body Shot, or Full-Body
Shot. If you select Custom, you can dene detailed picture width and height of a picture freely.
If the c
aptured pictures should have the same picture height, check Fixed Value and input
desired picture height.
Background Picture Sengs
Comparing to target picture, background picture is the scene image oers extra environmental
informaon. You can set the background picture quality and resoluon. If the background image
need t
o be uploaded to surveillance center, check Background Upload.
Camera Informaon
Enter De
vice No. and Camera Info in order to manage the monitoring device.
Text Overlay
You can check desired items and adjust their order to display on captured pictures by clicking
.
Network Speed Dome User Manual
9
3.4 Face Capture Algorithm Parameters
It is used to set and opmize the parameters of the algorithm library for face capture.
Face Capture Version
It refers to the current algorithm version, which cannot be edited.
Detecon Parameters
Generaon Speed
The speed to idenfy a target can be set by adjusng the slider, ranging from 1 to 5. The higher
the value is, the faster the target will be recognized. The default value is recommended.
Sensivity
The sensivity to idenfy a target can be set by adjusng the slider, ranging from 1 to 5. The
higher the value is, the easier a face will be detected, and the higher possibility of
misinformaon would be. The default value of 3 is recommended.
Capture Parameters
Upload Feature
Feature stands for the feature informaon the algorithm can tell from face pictures. For
e
xample, gender, facial expression, wearing glasses or not, etc. Check the funcon to upload the
informaon.
Best Shot
The device captures the target picture with the highest score aer
seng the parameters.
Capture Times
It refers to the capture mes a face will be captured during its stay in the detecon area.
Capture Threshold
It refers for the quality of face to trigger capture and alarm. Higher value means beer quality
should be me
t to trigger capture and alarm.
Quick Shot
The device captures the target picture once the score of the captured face exceeds the Quick
Shot Threshold during the Max. Capture Interval. Otherwise, the device selects and uploads
the picture with the highest score during the Max. Capture Interval.
Quick Shot Threshold
It refers to the quality of face to trigger quick shot.
Max. Capture Interval
It describes the max. me occupaon for one quick shot.
Cap
ture Times
Network Speed Dome User Manual
10
It refers to the capture mes a face will be captured during its stay in the congured area.
Unlimited
The device keeps capturing the target face, which exceeds the Quick Shot Threshold during
the Max. Capture Interval.
Limited
The device captures the target face according to the set mes.
Face Exposure
Enable the funcon, and the device automacally adjusts exposure level when human faces
appear in the scene.
Reference Brightness
It refers to the reference brightness of a face in the face exposure mode. If a face in the actual
scene is brighter than the set reference brightness, the device lower the exposure level. If a
face in the actual scene is darker than the set reference, the device increases the exposure
level.
Minimum Duraon
The extra me the device keeps the face exposure level aer the face disappears in the scene.
Face Filtering
Face Filtering Time
It means the
me interval between the camera detecng a face and taking a capture acon. If
the detected face stays in the scene for less than the set ltering me, capture will not be
triggered. For example, if the face ltering me is set as 5 seconds, the camera will capture the
detected face when the face keeps staying in the scene for 5 seconds.
Restore Default
Click Restore to restore all the sengs in advanced conguraon to the factory default.
Network Speed Dome User Manual
11
Chapter 4 PTZ
PTZ is an abbreviaon for pan, lt, and zoom. It means the movement opons of the camera.
4.1 PTZ Control
In live view interface, you can use the PTZ control buons to control the device panning, lng,
and zooming.
PTZ Control Panel
Click and hold the direconal buon to pan/lt
the device.
Note
• You can set K
eyboard Control Speed in
Conguraon → PTZ → Basic Sengs . The
speed of pan/lt movement in live view is
based on this speed level.
• You can set Max. Tilt-angle in Conguraon
→ PTZ → Basic Sengs to limit lt
movement range.
Click the buon, then the device keeps panning.
Note
You can set Aut
o Scan Speed in Conguraon
→ PTZ → Basic Sengs . The higher the value
you set, the faster the device pans.
Drag the slider to adjust the speed of pan/lt
movement.
Note
You can set Manual Con
trol Speed in Conguraon → PTZ → Basic Sengs .
Compable The control speed is same as Keyboard Control
Speed.
Pedestrian Choose Pedestrian when you monitor the
pedestrians.
Network Speed Dome User Manual
12
Non-motor Vehicle Choose Non-motor Vehicle when you monitor
the non-motor vehicles.
Motor Vehicle Choose Motor Vehicle when you monitor the
motor vehicles.
Auto You are recommended to set it as Aut
o when
the applicaon scene of the speed dome is
complicated.
To avoid blurred image resulted from fast zoom, you can check Enable Proporonal Pan in
Conguraon → PTZ → Basic Sengs . If you enable this funcon, the pan/lt speed change
according to the amount of zoom. When there is a large amount of zoom, the pan/lt speed will be
slower for keeping the image from moving too fast on the live view image.
Zoom in/out
Click the buon, and the lens zooms in.
Click the buon, and the lens zooms out.
Note
• You can set Z
ooming Speed in Conguraon → PTZ → Basic Sengs . The higher the value is,
the faster the zooming speed is.
• You can set Zoom Limit in Conguraon → Image → Display Sengs → Other to limit the
maximum value of the total zoom (digital zoom and opcal zoom).
Focus
Click the buon, then the lens focuses near and
the object nearb
y gets clear.
Click the buon, then the lens focuses far and
the object f
ar away gets clear.
Iris
When the image is too dark, click the buon to
enlar
ge the iris.
When the image is too bright, click the buon
to stop down the iris.
Network Speed Dome User Manual
13
4.2 Set Preset
A preset is a predened image posion. For the dened preset, you can call the preset No. to view
the posion.
Steps
1. Click to show the seng panel, and click .
2. Use the PTZ control buons to move the lens to the desired posion.
3. Select a pr
eset number from the preset list, and click
to
nish the seng.
Note
Some presets are predened with special command. You can only call them but not congure
them.
4. R
epeat the steps above to set mulple presets.
Click the buon to call the preset.
Click the buon to delete the preset.
Note
You can delete all presets in Conguraon → P
TZ → Clear Cong . Click Clear All Presets, and
click Save.
What to do next
Go t
o Conguraon → PTZ → Basic Sengs to set preset freezing and preset speed.
Aer enabling preset freezing, the live image switches directly from one preset to another, without
sho
wing the areas between these two scenes. It also guarantees the masked area will not be seen
when the device is moving.
4.2.1 Special Presets
You can call the following presets with special demands to enable corresponding funcons.
Preset No. Funcon Preset No. Funcon
33 Auto ip 48 Alarm light
o
34 Back to origin 92 Set manual limits
35 Call patrol 1 93 Save manual limits
36 Call patrol 2 94 Remote reboot
37 Call patrol 3 95 Call OSD menu
38 Call patrol 4 96 Stop a scan
Network Speed Dome User Manual
14
Preset No. Funcon Preset No. Funcon
39 Day mode 97 Start random scan
40 Night mode 98 Start frame scan
41 Call paern 1 99 Start auto scan
42 Call paern 2 100 Start
lt scan
43 Call paern 3 101 Start panorama scan
44 Call paern 4 102 Call patrol 5
45 One-touch patrol 103 Call patrol 6
46 Day/Night Mode 104 Call patrol 7
47 Alarm light on 105 Call patrol 8
4.3 Set Patrol Scan
Patrol scan is a funcon to automacally move among mulple presets.
Be
fore You Start
Make sure that you have dened more than one presets. See Set Preset for detailed conguraon.
Steps
1. Click
to show the seng panel, and click to enter patrol seng interface.
2. Select a pa
trol number from the list and click
.
3. Click to add presets.
Pr
eset
Select predened preset.
Speed
Se
t the speed of moving from one preset to another.
Time
It is the duraon
staying on one patrol point.
Delete the presets in patrol.
Adjust the preset order.
Note
A patrol can be congured with 32 presets at most, and 2 presets at least.
4. Click OK t
o nish a patrol seng.
5. R
epeat the steps above to congure mulple patrols.
6. Operate patrols.
Network Speed Dome User Manual
15
Call the patrol.
Stop patroling.
Delete the patrol.
Set the patrol.
Note
You can delete all patrols in Conguraon → PTZ → Clear Cong . Click Clear All Patrols, and
click Save.
4.3.1 Set One-Touch Patrol
The device automacally adds presets to one patrol path and starts patrol scan.
Steps
1. Set two or more presets among preset No.1 to preset No.32. For seng presets, refer to Set
Preset .
The device will automacally add presets to patrol path No.8.
2. Choose one of the following methods to enable the funcon.
-
Click .
-
Call pa
trol path No.8.
-
Select and call preset No.45.
4.4 Set Paern Scan
The device can move as the recorded paern.
Steps
1. Click
to show the PTZ control panel, and click .
2. Select one paern scan path that needs to be set.
3. Click to start recording paern scan.
4. Click P
TZ control buons as demands.
Note
Recording stops when the space for paern scan is 0%.
5. Click to complete one paern scan path sengs.
6. Click to call paern scan.
Stop paern scan.
Reset paern scan path.
Delete the selected paern scan.
Network Speed Dome User Manual
16
Note
If you need to delete all the paern scans, go to Conguraon → P
TZ → Clear Cong , and
check Clear All Paerns, and click Save.
4.5 Set Limit
The device can only move within the limited range.
St
eps
1. Go to Conguraon → PTZ → Limit .
2. Select Limit Type.
Manual Stops
It refers to the movement range limit when you control the device manually.
Scan Stops
It refers to the movement range limit when the device scans automacally.
Note
Scan limit is only supported by the device that has scan funcon.
3. Click Se
t and set limits according to the prompt on the live image.
4. Oponal: Click Clear to clear the limit sengs of the selected mode.
5. Click Save.
6. Check Enable Limit.
Note
If you need to cancal all the set patrol paths, go to Conguraon → P
TZ → Clear Cong , select
Clear All PTZ Limited, and click Save.
Result
The de
vice can only move within the set region aer saving the sengs.
4.6 Set Inial Posion
Inial posion refers to the relave inial posion of the device azimuth. You can set the inial
posion if you need to select one point in the scene as the base point.
St
eps
1. Go to Conguraon → PTZ → Inial Posion .
2. Move the device to the needed posion by manually controlling the PTZ control buons.
3. Click Se
t to save the informaon of inial posion.
Network Speed Dome User Manual
17
Call The device moves to the set inial posion.
Clear Clear the set inial posion.
4.7 Set Scheduled Tasks
You can set the device to perform a certain task during a certain period.
St
eps
1. Go to Conguraon → PTZ → Scheduled Tasks .
2. Check Enable Scheduled Task.
3. Select the task type and set the period. For seng the period, refer to Set Arming Schedule .
4. Repeat step 3 to set more than one scheduled tasks.
5. Set Park Time. During the set task period, if you operate the device manually, the scheduled
task will be suspended. When the manual operaon is over, the device will connue to perform
the scheduled task aer the set park me.
6. Click Save.
Note
If you want to clear all scheduled tasks, go to Conguraon → P
TZ → Clear Cong , check Clear
All Scheduled Tasks, and click Save.
4.8 Set Park
Acon
You can set the device to perform an acon (for example, preset or patrol) or return to a posion
aer a period of inacvity (park me).
Before You Start
Set the
acon type rst. For example, if you want to select patrol as park acon, you should set the
patrol. For seng patrols, refer to Set Patrol Scan .
Steps
1. Go to Conguraon → PTZ → Park Acon and check Enable Park Acon.
2. Set Park Time, the
inacve me before the device starts the park acon.
3. Select Acon Type according to your needs.
4. Click Save.
4.8.1 Set One-Touch Park
This funcon is used to start park instantly.
St
eps
1. Refer to Set Park Acon to set a park acon.
Network Speed Dome User Manual
18
2. Choose from the following methods to start one-touch park.
-
Click .
-
Call Pr
eset No. 32.
4.9 Set Privacy Mask
Privacy mask enables you to cover certain areas on the live image to prevent certain spots in the
surveillance area from being live viewed and recorded.
Steps
1. Go to Conguraon → P
TZ → Privacy Mask .
2. Check Enable Privacy Masks.
3. Adjust the live image to the target scene via PTZ control buons.
4. Draw the area.
Draw Area Click Draw Area, and click on the live view
image to determine the boundary of the
mask.
Stop Drawing ClickStop Drawing aer drawing the mask.
5. Click Add.
It is listed in Privacy Mask List.
6. Edit Name, Type, and
Acve Zoom Rao on your demand.
Acve Zoom Rao
When the actual zoom rao is less than the set acve zoom rao, the set area can not be
covered. When the actual zoom rao is greater than the set acve zoom rao, the privacy
mask is valid. The maximum value of acve zoom rao depends on the camera module.
7. R
epeat the steps above to set other privacy masks.
8. ClickSave.
4.10 Set Smart Tracking
The funcon allows the device detecng and tracking the moving targets in the scene. The target
s
tays in the center of the live image with a predened size during the tracking process.
Steps
1. Go to Conguraon → PTZ → Smart Tracking .
2. Check Enable Smart Tracking
3. Set the Duraon. The device stops tracking when the duraon
me is up.
4. Select a target in the live image and adjust the PTZ buons to see the target at desired size.
5. Click Set Zoom Rao. The device tracks the target at a xed zoom rao.
6. Click Save.
Network Speed Dome User Manual
19
4.11 Set Device Posion
Before You Start
Go to Conguraon → P
TZ → Basic Sengs → PTZ OSD to enable PT Status display.
Use other direcon
indicang devices to nd the North at the device locaon.
Steps
1. Go to Conguraon → PTZ → Posion Sengs .
2. Manually set device direcon by selecng the P
T Mode as Manual.
1) Adjust the lt
posion of the device to 0 by controling the up arrow and down arrow on the
PTZ panel.
2) Adjust the pan posion to show the live view of the north direcon by controling the le
arrow and right arrow on the PTZ panel.
3) Click Set as North.
3. Input the longitude and latude of the device manually.
4. Click Save.
What to do next
If you lost direcon when operang the device, you can click Point to North to call the north
posion that is saved in the device.
4.12 Set Power O Memory
This funcon can resume the previous PTZ status of device aer it restarng from a
power-o.
Steps
1. Go to Conguraon → PTZ → Basic Sengs .
2. Select Resume Time Point. When the device stays at one posion for the set resume me point
or mor
e, the posion is saved as a momory point. The device returns to the last memory point
when it restarts.
3. Click Save.
4.13 Set PTZ Priority
The funcon can set the PTZ priority of dierent signals.
St
eps
1. Go to Conguraon → PTZ → Priorize PTZ .
2. Set the priority signal and delayed me.
Network
The ne
twork signal controls the device with priority.
RS-485
Network Speed Dome User Manual
20
The RS-485 signal controls the device with priority.
Delay
It refers to the me interval of PTZ operaon controlled by dierent signals. When the
operaon with high priority is nished, the low priority signal controls the device aer the
seng interval.
3. Click Save.
4.14 Set Rapid Focus
Rapid focus is a funcon to reduce me of focusing comparing with that of normal focusing. To use
the funcon, calibraon should be done rst. Rapid focus may not be supported by certain device
models.
Steps
1. Go to Conguraon → PTZ → Rapid Focus .
2. Add scenes for calibraon.
1) Adjust the live image to a desired scene via PTZ control buons, and click Add.
2) Set the Rate and the Calibraon Point Amount of the added scene.
Note
More calibraon points may increase calibraon accuracy, but more focusing me is
r
equired. The default amount is recommended.
3. Select the scene t
o display the calibraon line.
A red line displays on live image.
4. Adjust the length and posion of the line by dragging its two endpoints.
Note
The red line is recommended to stay in the center of the scene and to cover ground at the same
me.
Double click the image to enter full screen mode.
5. Click St
art Calibraon.
Calibraon status displays on the live image.
6. Repeat to add other scenes and complete the calibraon.
7. Check Enable Heigh
t Compensaon if the mounng height of the device is lower than 3 meters.
8. Check Enable aer successful calibraon.
9. Click Save.
Network Speed Dome User Manual
21
Chapter 5 Live View
It introduces the live view parameters, funcon icons and transmission parameters sengs.
5.1 Live View Parameters
The supported funcons vary depending on the model.
5.1.1 Start and Stop Live View
Click Liv
e View. Click
to start live view. Click to stop live view.
5.1.2 Aspect Rao
Aspect
Rao is the display rao of the width to height of the image.
•
refers to 4:3 window size.
• refers to 16:9 window size.
• refers to original window size.
• refers to self-adapve window size.
• refers to original rao window size.
5.1.3 Live View Stream Type
Select the live view stream type according to your needs. For the detailed informaon about the
s
tream type selecon, refer to Stream T
ype .
5.1.4 Quick Set Live View
It oers the quick access to the display sengs, OSD, and video/audio on live view page.
Steps
1.
Click
and click Gener
al to show quick setup page.
2. Set display sengs, OSD, and video/audio.
-
F
or parameter explanaon and instrucons of display sengs, see Display Sengs .
-
For parameter explanaon and instrucons of OSD sengs, see OSD .
-
For parameter explanaon and instrucons of audio and video sengs, see Video and
Audio .
Network Speed Dome User Manual
22
5.1.5 Select the Third-Party Plug-in
When the live view cannot display via certain browsers, you can change the plug-in for live view
according to the browser.
Steps
1. Click Live View.
2. Click to select the plug-in.
-
When y
ou access the device via Internet Explorer, you can select Webcomponents or
QuickTime.
-
When you access the device via the other browsers, you can select Webcomponents,
QuickTime, VLC or MJPEG.
5.1.6 Start Digital Zoom
It helps to see a detailed informaon of any region in the image.
St
eps
1. Click to enable the digital zoom.
2. In live view image, drag the mouse to select the desired region.
3. Click in the live view image to back to the original image.
5.1.7 Conduct Regional Focus
You can enable the funcon to focus on certain area.
St
eps
1. Click
to enable regional focus.
2. Dr
ag the mouse on the live view to draw a rectangle as the desired focus area.
3. Click
to disable this funcon.
5.1.8 Conduct Regional Exposure
When the brightness of live view is not balanced, you can enable this funcon to
opmize the
exposure of the selected image region.
Steps
1. Click
to enable regional exposure.
2. Dr
ag the mouse on the live view to draw a rectangle as the desired exposure area.
3. Click
to disable this funcon.
Network Speed Dome User Manual
23
5.1.9 Count Pixel
It helps to get the height and width pixel of the selected region in the live view image.
Steps
1. Click to enable the funcon.
2. Dr
ag the mouse on the image to select a desired rectangle area.
The width pixel and height pixel are displayed on the boom of the live view image.
5.1.10 Light
Click
to turn on or turn o the illuminator.
5.1.11 Operate Wiper
For the device that has a wiper, you can control the wiper via web browser.
St
eps
1. Go to wiper seng page: Conguraon → PTZ → Wiper .
2. Select a wiper mode.
One
Time
The wiper wipes one me when you click
on live view page.
Cycle The wiper works on schedule at set wiping interval. Click
on live view to start
wiping.
Duraon
The schedule in which the wiper is ready to work.
In
terval
The interval between two secessive wiping acons.
Auto
Note
Auto mode is only available for device that supports rain-sensing auto wiper.
In auto mode, the wiper works when rain drops on the window.
5.1.12 Lens Inializaon
Lens inializaon is used on the device equipped with motorized lens. The funcon can reset lens
when long me zoom or focus results in blurred image. This funcon varies according to dierent
models.
Network Speed Dome User Manual
24
Click to operate lens inializaon.
5.1.13 Track Manually
In live view, manually select a target for the device to track.
Steps
1. Click on the toolbar of the live view page.
2. Click a moving object in the live image.
The camera tracks the target and keep it in the center of live view image.
5.1.14 Conduct 3D Posioning
3D
posioning is to relocate the selected area to the image center.
Steps
1. Click
to enable the funcon.
2. Select a target area in live image.
-
Le click on a point on live image: the point is relocated to the center of the live image. With
no zooming in or out eect.
-
Hold and dr
ag the mouse to a lower right posion to frame an area on the live: the framed
area is zoomed in and relocated to the center of the live image.
-
Hold and drag the mouse to an upper le posion to frame an area on the live: the framed
area is zoomed out and relocated to the center of the live image.
3. Click the buon again to turn o the
funcon.
5.1.15 OSD Menu
When network access is unavailable, you can call the Preset No.95 to show OSD menu to start
device conguraon.
Click direcon
buons or
and to move up and down.
Click to
conrm your selecon.
5.1.16 Display Target Informaon on Live View
Go to Conguraon → Local → Live View Parameters for sengs.
Note
Related smart
funcon should be congured and enabled in advance.
Display POS Informaon
Network Speed Dome User Manual
25
POS informaon refers to the target features, such as target ID, etc. Supported POS informaon
types varies according to device models.
5.2 Set Transmission Parameters
The live view image may be displayed abnormally according to the network condions. In dierent
network environments, you can adjust the transmission parameters to solve the problem.
Steps
1. Go to Conguraon → Local .
2. Set the transmission parameters as required.
Protocol
TCP
TCP ensures complete delivery of streaming data and beer video quality, yet the real-me
transmission will be aected. It is suitable for the stable network environment.
UDP
UDP is suitable for the unstable network environment that does not demand high video
uency.
MULTICAST
MUL
TICAST is suitable for the situaon that there are mulple clients. You should set the
mulcast address for them before selecon.
Note
For detailed informaon about mulcast, refer to Mulcast .
HTTP
HT
TP is suitable for the situaon that the third-party needs to get the stream from the
device.
Play Performance
Shortest Delay
The device takes the real-me video image as the priority over the video uency.
Balanced
The de
vice ensures both the real-me video image and the uency.
Fluent
The device takes the video uency as the priority over teal-me. In poor network
environment, the device cannot ensures video uency even the uency is enabled.
Cus
tom
Network Speed Dome User Manual
26
You can set the frame rate manually. In poor network environment, you can reduce the
frame rate to get a uent live view. But the rule informaon may cannot display.
3. Click OK.
5.3 Smart Display
This funcon displays real me images captured by certain smart funcons.
Note
To use this funcon, you should rst enable and congure certain smart funcons.
You can change the layout of the display page. Click and check the display content you need to
add t
o the layout.
Network Speed Dome User Manual
27
Chapter 6 Video and Audio
This part introduces the conguraon of video and audio related parameters.
6.1 Video Sengs
This part introduces the sengs of video parameters, such as, stream type, video encoding, and
resoluon.
Go to seng page: Conguraon → Video/Audio → Video .
6.1.1 Stream Type
For device supports more than one stream, you can specify parameters for each stream type.
Main Stream
The stream stands for the best stream performance the device supports. It usually oers the
best resoluon and frame rate the device can do. But high resoluon and frame rate usually
means larger storage space and higher bandwidth requirements in transmission.
Sub Stream
The stream usually oers comparavely low resoluon opons, which consumes less bandwidth
and s
torage space.
Other Streams
Steams other than the main stream and sub stream may also be oered for customized usage.
6.1.2 Video Type
Select the content (video and audio) that should be contained in the stream.
Video
Only video c
ontent is contained in the stream.
Video & Audio
Video content and audio content are contained in the composite stream.
6.1.3 Resoluon
Select video
resoluon according to actual needs. Higher resoluon requires higher bandwidth and
storage.
Network Speed Dome User Manual
28
6.1.4 Bitrate Type and Max. Bitrate
Constant Bitrate
It means that the stream is compressed and transmied at a comparavely xed bitrate. The
compression speed is fast, but mosaic may occur on the image.
Variable Bitrate
It means that the device automacally adjust the bitrate under the set Max. Bitrate. The
compression speed is slower than that of the constant bitrate. But it guarantees the image
quality of complex scenes.
6.1.5 Video Quality
When Bitrate Type is set as Variable, video quality is congurable. Select a video quality according
to actual needs. Note that higher video quality requires higher bandwidth.
6.1.6 Frame Rate
The frame rate is to describe the frequency at which the video stream is updated and it is
measured by frames per second (fps).
A higher frame rate is advantageous when there is movement in the video stream, as it maintains
image quality throughout. Note that higher frame rate requires higher bandwidth and larger
storage space.
6.1.7 Video Encoding
It stands for the compression standard the device adopts for video encoding.
Note
Available compression standards vary according to device models.
H.264
H.264, also known as MPEG-4 Part 10, Advanced Video Coding, is a compression standard. Without
c
ompressing image quality, it increases compression rao and reduces the size of video le than
MJPE
G or MPEG-4 Part 2.
Network Speed Dome User Manual
29
H.264+
H.264+ is an improved compression coding technology based on H.264. By enabling H.264+, you
can esmate the HDD consumpon by its maximum average bitrate. Compared to H.264, H.264+
r
educes storage by up to 50% with the same maximum bitrate in most scenes.
When H.264+ is enabled, Max. Average Bitrate is congurable. The device gives a recommended
ma
x. average bitrate by default. You can adjust the parameter to a higher value if the video quality
is less sasfactory. Max. average bitrate should not be higher than max. bitrate.
Note
When H.264+ is enabled, Video Quality, I Fr
ame Interval, Prole and SVC are not congurable.
H.265
H.265, also known as High Eciency Video Coding (HEVC) and MPEG-H Part 2, is a compression
s
tandard. In comparison to H.264, it oers beer video compression at the same resoluon, frame
rate and image quality.
H.265+
H.265+ is an improved compression coding technology based on H.265. By enabling H.265+, you
can esmate the HDD consumpon by its maximum average bitrate. Compared to H.265, H.265+
reduces storage by up to 50% with the same maximum bitrate in most scenes.
When H.265+ is enabled, Max. Average Bitrate is congurable. The device gives a recommended
ma
x. average bitrate by default. You can adjust the parameter to a higher value if the video quality
is less sasfactory. Max. average bitrate should not be higher than max. bitrate.
Note
When H.265+ is enabled, Video Quality, I Fr
ame Interval, Prole and SVC are not congurable.
Prole
This funcon means that under the same bitrate, the more complex the prole is, the higher the
quality of the imag
e is, and the requirement for network bandwidth is also higher.
SVC
Scalable Video Coding (SVC) is the name for the Annex G extension of the H.264 or H.265 video
c
ompression standard.
Network Speed Dome User Manual
30
The objecve of the SVC standardizaon has been to enable the encoding of a high-quality video
bitstream that contains one or more subset bitstreams that can themselves be decoded with a
complexity and reconstrucon quality similar to that achieved using the exisng H.264 or H.265
design with the same quanty of data as in the subset bitstream. The subset bitstream is derived
b
y dropping packets from the larger bitstream.
SVC enables forward compability for older hardware: the same bitstream can be consumed by
basic har
dware which can only decode a low-resoluon subset, while more advanced hardware
will be able decode high quality video stream.
Smoothing
It refers to the smoothness of the stream. The higher value of the smoothing is, the beer uency
of the stream will be, though, the video quality may not be so sasfactory. The lower value of the
smoothing is, the higher quality of the stream will be, though it may appear not uent.
MJPEG
Moon JPEG (M-JPEG or MJPEG) is a video compression format in which intraframe coding
technology is used. Images in a MJPEG format is compressed as individual JPEG images.
6.1.8 I-Frame Interval
I-frame interval
denes the number of frames between 2 I-frames.
In H.264 and H.265, an I-frame, or intra frame, is a self-contained frame that can be independently
decoded without any reference to other images. An I-frame consumes more bits than other
frames. Thus, video with more I-frames, in other words, smaller I-frame interval, generates more
steady and reliable data bits while requiring more storage space.
6.2 Audio Sengs
It is a funcon to set audio parameters such as audio encoding, environment noise ltering.
Go to the audio sengs page: Conguraon → Video/
Audio → Audio .
6.2.1 Audio Input
If built-in microphone or external audio pick-up device is available, audio encoding, audio input
mode and input v
olume are congurable.
Audio Encoding
The device oers several compression standard. Select according to your need.
Network Speed Dome User Manual
31
Audio Input
LineIn and MicIn are available. Select MicIn for the built-in microphone, and LineIn for external
audio pick-up device.
Input volume
Adjust the volume of the audio input.
6.2.2 Audio Output
You can output audio through built-in speaker or line out, or turn o audio output by seng it as
Close. You can adjust the output volume according to your need.
Note
Connect audio output device according to your need.
6.2.3 Environmental Noise Filter
Set it as OFF or ON. When the funcon is enabled, the noise in the environment can be ltered to
some e
xtent.
6.3 Two-way Audio
It is used to realize the two-way audio funcon between the monitoring center and the target in
the monitoring screen.
Before You Start
• Make sure the audio input device (pick-up or microphone) and audio output device (speaker)
connected to the device is working properly. Refer to specicaons of audio input and output
de
vices for device connecon.
• If the device has built-in microphone and speaker, two-way audio funcon can be enabled
dir
ectly.
Steps
1. Click Live View.
2. Click
on the toolbar to enable two-way audio funcon of the camera.
3. Click and select , move the slider to adjust the volume.
4. Click , disable the two-way audio funcon.
Network Speed Dome User Manual
32
6.4 ROI
ROI (Region of Interest) encoding helps to discriminate the ROI and background informaon in
video compression. The technology assigns more encoding resource to the region of interest, thus
to increase the quality of the ROI whereas the background informaon is less focused.
6.4.1 Set ROI
ROI (Region of Interest) encoding helps to assigns more encoding resource to the region of
interest, thus to increase the quality of the ROI whereas the background informaon is less
focused.
Before You Start
Please check the video coding type. ROI is supported when the video coding type is H.264 or H.
265.
Steps
1. Go to Conguraon → Video/Audio → ROI .
2. Check Enable.
3. Select Stream Type.
4. Select Region No. in Fixed Region to draw ROI region.
1) Click Drawing.
2) Click and drag the mouse on the view screen to draw the xed region.
3)
Click Stop Drawing.
Note
Select the xed region that needs to be adjusted and drag the mouse to adjust its posion.
5. Input the R
egion Name and ROI Level.
6. Click Save.
Note
The higher the ROI level is, the clearer the image of the detected region is.
7. Oponal: Select other r
egion No. and repeat the above steps if you need to draw mulple xed
regions.
6.4.2 Set Target Tracking ROI
The moving target is clearer than other areas in live image or recordings aer enabling the
funcon.
Before You Start
Go t
o Conguraon → PTZ → Smart Tracking to complete the smart tracking sengs.
Network Speed Dome User Manual
33
Steps
1. Go to Conguraon → Video/
Audio → ROI .
2. Check Enable Target Tracking.
3. Set ROI Level for target tracking. The higher the value is, the clearer the target is.
4. Click Save.
6.4.3 Set Face Tracking ROI
When the face tracking funcon is enabled in ROI and the face appears in the live picture, the
image of the face is clearer than that of the surrounding area.
Steps
1. Go to the ROI seng page: Conguraon → Video/Audio → ROI .
2. Check Enable Face Tracking.
3. Select ROI Level in Dynamic Region.
Note
ROI level means the image quality enhancing level. The larger the value is, the beer the image
quality w
ould be.
4. Click Sa
ve.
6.5 Display Info. on Stream
The informaon of the objects (e.g. human, vehicle, etc.) is marked in the video stream. You can
set rules on the connected rear-end device or client soware to detect the events including line
crossing, intrusion, etc.
Steps
1. Go to the seng page:
Conguraon → Video/Audio → Display Info. on Stream .
2. Check Enable Dual-VCA.
3. Click Save.
6.6 Display Sengs
It
oers the parameter sengs to adjust image features.
Go to Conguraon → Imag
e → Display Sengs .
Click Default to restore sengs.
Network Speed Dome User Manual
34
6.6.1 Scene Mode
There are several sets of image parameters predened for dierent installaon environments.
Select a scene according to the actual installaon environment to speed up the display sengs.
Image Adjustment
By adjusng the Brightness, Saturaon, Contrast and Sharpness, the image can be best displayed.
Exposure Sengs
Exposure is controlled by the combinaon of iris, shuer, and gain. You can adjust image eect by
seng exposure parameters.
Exposure Mode
Auto
The iris, shuer, and gain values are adjusted automacally.
You can limit the changing ranges of iris, shuer and gain by seng Ma
x. Iris Limit, Min. Iris
Limit, Max. Shuer Limit, Min. Shuer Limit and Limit Gain for beer exposure eect.
Iris Priority
The value of iris needs to be adjusted manually. The shuer and gain values are adjusted
automacally according to the brightness of the environment.
Y
ou can limit the changing ranges of the shuer and gain by seng Max. Shuer Limit, Min.
Shuer Limit and Limit Gain for beer exposure eect.
Shuer Priority
The v
alue of shuer needs to be adjusted manually. The iris and gain values are adjusted
automacally according to the brightness of the environment.
You can limit the changing ranges of the iris by seng Max. Iris Limit, Min. Iris Limit and
Limit Gain for beer exposure eect.
Manual
Y
ou need to set Iris, Shuer, and Gain manually.
Slow Shuer
The higher the slow shuer level is, the slower the shuer speed is. It ensures full exposure in
underexposure condion.
Focus
It oers
opons to adjust the focus mode and the minimum focus distance.
Network Speed Dome User Manual
35
Focus Mode
Auto
The device focuses automacally as the scene changes. If you cannot get a well-focused
image under auto mode, reduce light sources in the image and avoid ashing lights.
Semi-aut
o
The device focuses once aer the PTZ and lens zooming. If the image is clear, the focus does
not chang
e when the scene changes.
Manual
You can adjust the focus manually on the live view page.
Min. Focus Distance
When the distance between the scene and lens is shorter than the Min. Focus Distance, the lens
does not focus.
Day/Night Switch
Day/Night Switch funcon can provide color images in the day mode and black/white images in the
night mode. Switch mode is congurable.
Day
The imag
e is always in color.
Night
The image is always black/white
Auto
The camera switches between the day mode and the night mode according to the illuminaon
aut
omacally.
Scheduled-Switch
Se
t the Start Time and the End Time to dene the duraon for day mode.
Triggered by alarm input
Two trigger modes are available: Day and Night. For example, if the trigger mode is Night, the
image turns black and white when the device receives alarm input signal.
Note
Day/Night Switch funcon varies according to models.
Set Supplement Light
Steps
1. Go t
o Conguraon → System → Maintenance → System Service .
2. Check Enable Supplement Light.
Network Speed Dome User Manual
36
3. Click Save.
4. Go to Conguraon → Imag
e → Display Sengs → Day/Night Switch to set supplement light
parameters.
Smart Supplement Light
This feature uses smart image processing technology to reduce overexposure caused by
supplement light.
Supplememt Light Mode
When the mode is set to Auto, the supplement light is automacally turned on or o
according to the image brightness.
When the mode is se
t to Scheduled, set the start me and end me for the light to work.
When the mode is set to NC, the light is o.
Brightness Limit
Adjust the upper limit of supplement light power. For devices with both white light and IR
light, white light and IR light brightness limit can be set separately.
BLC
If you focus on an object against strong backlight, the object will be too dark to be seen clearly. BLC
(backligh
t compensaon) compensates light to the object in the front to make it clear. If BLC mode
is set as Custom, you can draw a red rectangle on the live view image as the BLC area.
HLC
When the bright area of the image is over-exposed and the dark area is under-exposed, the HLC
(High Light Compression) funcon can be enabled to weaken the bright area and brighten the dark
ar
ea, so as to achieve the light balance of the overall picture.
WDR
The WDR (Wide Dynamic Range) funcon helps the camera provide clear images in environment
with strong illuminaon dierences.
When there are both very bright and very dark areas simultaneously in the eld of view, you can
enable the WDR funcon and set the level. WDR automacally balances the brightness level of the
whole imag
e and provides clear images with more details.
Note
When WDR is enabled, some other funcons may be not supported. Refer to the actual interface
for details.
Network Speed Dome User Manual
37
DNR
Digital Noise Reducon is used to reduce the image noise and improve the image quality. Normal
and Expert modes are selectable.
Normal
Set the DNR level to control the noise reducon degree. The higher level means stronger
reducon degree.
Expert
Set the DNR level for both space DNR and me DNR to control the noise reducon degree. The
higher level means stronger reducon degree.
White Balance
White balance is the white rendion funcon of the camera. It is used to adjust the color
temperature according to the environment.
Defog
You can enable the defog funcon when the environment is foggy and the image is misty. It
enhances the subtle details so that the image appears clearer.
EIS
Increase the stability of video image by using jier compensaon technology.
6.6.2 Image Parameters Switch
The device automacally switches image parameters in set me periods.
Go t
o image parameters switch seng page: Conguraon → Imag
e → Image Parameters Switch ,
and set parameters as needed.
Set Scheduled-switch
Switch the image to the linked scene mode automacally in certain me periods.
Steps
1. Check Scheduled-switch.
2. Select and congure the corresponding me period and linked scene mode.
Network Speed Dome User Manual
38
Note
For Linked Scene conguraon, refer to Sc
ene Mode .
3. Click Sa
ve.
Set Link to Preset
You can set a preset to switch the image to a linked scene.
Steps
1. Check Link to Preset.
2. Select a preset.
3. Check and set a me period and a linked scene mode.
4. Click Save.
6.6.3 Mirror
When the live view image is the reverse of the actual scene, this funcon helps to display the
image normally.
Select the mirror mode as needed.
Note
The video recording will be shortly interrupted when the funcon is enabled.
6.6.4 Video Standard
Video standard is an ability of a video card or video display device that denes the amount of
c
olors that are shown and the resoluon. The two most common video standard used are NTSC
and PAL. In NTSC, 30 frames are transmied each second. Each frame is made up of 525 individual
scan lines. In PAL, 25 frames are transmied each second. Each frame is made up of 625 individual
scan lines. Select video signal standard according to the video system in your country.
6.7 OSD
You can customize OSD (On-screen Display) informaon such as device name, me/date, font,
c
olor, and text overlay displayed on video stream.
Go to OSD seng page: Conguraon → Imag
e → OSD Sengs . Set the corresponding
parameters, and click Save to take eect.
Network Speed Dome User Manual
39
Character Set
Select character set for displayed informaon. If Korean is required to displayed on screen, select
EUC-KR. Otherwise, select GBK.
Displayed Informaon
Set camera name, date, week, and their related display format.
Text Overlay
Set customized overlay text on image.
OSD Parameters
Set OSD parameters, such as Display Mode, OSD Size, Font Color, and Alignment.
Network Speed Dome User Manual
40
Chapter 7 Video Recording and Picture Capture
This part introduces the operaons of capturing video clips and snapshots, playback, and
downloading captured les.
7.1 Storage Sengs
This part introduces the conguraon of several common storage paths.
7.1.1 Set Memory Card
If you choose to store the les to memory card, make sure you insert and format the memory card
in advance.
Before You Start
Insert the memory card to the camera. For detailed installaon, refer to Quick Start Guide of the
camera.
Steps
1. Go to storage management seng page: Conguraon → St
orage → Storage Management →
HDD Management .
2. Select the memory card, and click Format to start inializing the memory card.
The Status of memory card turns to Normal from Uninialized, which means the memory card
c
an be used normally.
3. Oponal: Dene the Quota of the memory card. Input the quota percentage for dierent
contents according to your need.
4. Click Save.
Detect Memory Card Status
It helps to detect the memory card status of Hikvision memory card. You receive nocaons when
y
our memory card is detected abnormal.
Before You Start
Memory card should be installed to the device.
Steps
1. Go to memory card detecon
seng page: Conguraon → Storage → Storage Management
→ Memory Card Detecon .
2. Click St
atus Detecon to check the Remaining Lifespan and Health Status of your memory card.
Remaining Lifespan
Network Speed Dome User Manual
41
It shows the percentage of the remaining lifespan. The lifespan of a memory card may be
inuenced by factors such as its capacity and the bitrate. You need to change the memory
card if the remaining lifespan is not enough.
Health Status
It shows the condion of your memory card. There are three status descripons, good, bad,
and damaged. You will receive a nocaon if the health status is anything other than good
when the Arming Schedule and Linkage Method are set.
Note
It is recommended that you change the memory card when the health status is not “good”.
3. Click R/W Lock t
o set the authority of reading and wring to the memory card.
-
Add a Lock
a. Select the Lock Switch as ON.
b. Enter the password.
c. Click Save
-
Unlock
• If you use the memory card on the camera that locks it, unlocking will be done
automacally and no unlocking procedures are required on the part of users.
• If you use the memory card (with a lock) on a dierent camera, you can go to HDD
Management interface to unlock the memory card manually. Select the memory card, and
click the Unlock buon shown next to the Format buon. Then enter the correct
password to unlock it.
-
Remove the Lock
a. Select the Lock Switch as OFF.
b. Enter the password in Password Sengs.
c.
Click Save.
Note
• Only admin user can set the R/W Lock.
•
The memory card can only be read and write when it is unlocked.
• If the camera, which adds a lock to a memory card, is restored to the factory sengs, you can
g
o to HDD Management interface to unlock the memory card.
4. Se
t Arming Schedule and Linkage Method. Refer to Set Arming Schedule and Linkage Method
Sengs for details.
5. Click Save.
7.1.2 Set FTP
You can congure
the FTP server to save images which are captured by events or a med snapshot
task.
Network Speed Dome User Manual
42
Before You Start
Get the FTP server address rst.
Steps
1. Go to Conguraon → Ne
twork → Advanced Sengs → FTP .
2. Congure FTP sengs.
Server Address and Port
The FTP server address and corresponding port.
User Name and Password
The FTP user should have the permission to upload pictures.
If the FTP server supports picture uploading by anonymous users, you can check Anonymous
to hide your device informaon during uploading.
Dir
ectory Structure
The saving path of snapshots in the FTP server.
Picture Filling Interval
For beer picture management, you can set the picture ling interval from 1 day to 30 days.
Pictures captured in the same me interval will be saved in one folder named aer the
beginning date and ending date of the me interval.
Picture Name
Set the naming rule for captured pictures. You can choose Default in the drop-down list to
use the default rule, that is, IP address_channel number_capture me_event type.jpg (e.g.,
10.11.37.189_01_20150917094425492_F
ACE_DETECTION.jpg). Or you can customize it by
adding a Custom Prex
to the default naming rule.
3. Click Upload Picture to enable uploading snapshots to the FTP server.
4. Click Test to verify the FTP server.
5. Click Save.
7.1.3 Set NAS
Take network server as network disk to store the record les, captured images, etc.
Be
fore You Start
Get the IP address of the network disk rst.
Steps
1. Go t
o NAS seng page: Conguraon → Storage → Storage Management → Net HDD .
2. Click HDD No.. Enter the server address and le path for the disk.
Server Address
The IP address of the network disk.
File Path
Network Speed Dome User Manual
43
The saving path of network disk les.
Mounng Type
Select le system protocol according to the operaon system.
Enter user name and password of the net HDD to guarantee the security if SMB/CIFS is
selected.
3. Click Test to check whether the network disk is available.
4. Click Save.
7.2 Video Recording
This part introduces the operaons of manual and scheduled recording, playback, and
do
wnloading recorded les.
7.2.1 Record Automacally
This funcon can record video automacally during congured me periods.
Before You Start
Select Trigger Recording in event sengs for each record type except Connuous. See Event and
Alarm for details.
Steps
1. Go to Conguraon → St
orage → Schedule Sengs → Record Schedule .
2. Check Enable.
3. Select a record type.
Note
The record type is vary according to dierent models.
Connuous
The video will be recorded connuously according to the schedule.
Moon
When
moon detecon is enabled and trigger recording is selected as linkage method,
object movement is recorded.
Alarm
When alarm input is enabled and trigger recording is selected as linkage method, the video is
recorded aer receiving alarm signal from external alarm input device.
Moon | Alarm
Video is recorded when moon is detected or alarm signal is received from the external
alarm input device.
Moon & Alarm
Network Speed Dome User Manual
44
Video is recorded only when moon is detected and alarm signal is received from the
external alarm input device.
Event
The video is recorded when congured event is detected.
4. Set schedule for the selected record type. Refer to Set Arming Schedule for the seng
oper
aon.
5. Click Advanced to set the advanced sengs.
Overwrite
Enable Overwrite to overwrite the video records when the storage space is full. Otherwise
the camera cannot record new videos.
Pre-record
The me period you set to record before the scheduled me.
Post-record
The me period you set to stop recording aer the scheduled me.
Stream Type
Select the stream type for recording.
Note
When you select the stream type with higher bitrate, the actual me of the pre-record and
pos
t-record may be less than the set value.
6. Click Sa
ve.
7.2.2 Record Manually
Steps
1. Go to Conguraon → Local .
2. Set the Record File Size and saving path to for recorded les.
3. Click Sa
ve.
4. Click to start recording. Click to stop recording.
7.2.3 Playback and Download Video
You can search, playback and download the videos stored in the local storage or network storage.
St
eps
1. Click Playback.
2. Set search condion and click Search.
The matched video les showed on the ming bar.
3. Click
to play the video les.
Network Speed Dome User Manual
45
-
Click to clip video les.
-
Click to play video les in full screen. Press ESC to exit full screen.
Note
Go to Conguraon → Loc
al , click Save clips to to change the saving path of clipped video les.
4. Click on the playback interface to download les.
1) Set search
condion and click Search.
2) Select the video les and then click Download.
Note
Go to Conguraon → Loc
al , click Save downloaded les to to change the saving path of
downloaded video les.
7.3 Capture Conguraon
The device can capture the pictures manually or automacally and save them in congured saving
pa
th. You can view and download the snapshots.
7.3.1 Capture Automacally
This funcon can capture pictures automacally during congured me periods.
Before You Start
If event-triggered capture is required, you should congure related linkage methods in event
sengs. Refer to E
vent and Alarm for event sengs.
Steps
1. Go t
o Conguraon → Storage → Schedule Sengs → Capture → Capture Parameters .
2. Set the capture type.
Timing
Capture a picture at the congured me interval.
E
vent-Triggered
Capture a picture when an event is triggered.
3. Set the Format, Resoluon, Quality, Interval, and Capture Number.
4. Refer to Set Arming Schedule for conguring schedule me.
5. Click Sa
ve.
7.3.2 Capture Manually
Steps
1. Go to Conguraon → Local .
Network Speed Dome User Manual
46
2. Set the Image Format and saving path to for snapshots.
JPEG
The picture size of this format is comparavely small, which is beer for network
tr
ansmission.
BMP
The picture is compressed with good quality.
3. Click Save.
4. Click
near the live view or play back window to capture a picture manually.
7.3.3 View and Download Picture
You can search, view and download the pictures stored in the local storage or network storage.
St
eps
1. Click Picture.
2. Set search condion and click Search.
The matched pictures showed in the le list.
3. Select the pictur
es then click Download to download them.
Note
Go to Conguraon → Loc
al , click Save snapshots when playback to change the saving path of
pictures.
Network Speed Dome User Manual
47
Chapter 8 Event and Alarm
This part introduces the conguraon of events. The device takes certain response to triggered
alarm.
8.1 Basic Event
8.1.1 Set Moon Detecon
This funcon detects moving objects in the detecon region and trigger linkage acons.
Steps
1. Go to Conguraon → Event → Basic Event → Moon Detecon .
2. Check Enable Moon Detecon.
3. Oponal: Check Enable Moon Detecon in PTZ Control, and the device detects moving
targets in PTZ movement.
4. Oponal: Highlight moving objects in green.
1) Check Enable Dynamic Analysis for Moon.
2)
Go to Conguraon → Local to enable Rules.
5. Select Conguraon Mode. Normal mode and expert mode are selectable.
-
For the informaon about normal mode, see Normal Mode .
-
For the informaon about expert mode, see Expert Mode .
6. Se
t the arming schedule. See Set Arming Schedule for details.
7. Set linkage methods. See Linkage Method Sengs for details.
8. Click Save.
Normal Mode
You can set moon
detecon parameters according to the device default parameters.
Steps
1. Select normal mode in Conguraon.
2. Set the sensivity of normal mode. The higher the value of sensivity is, the more
sensive the
moon detecon is. If the sensivity is set to 0, moon detecon and dynamic analysis do not
take eect.
3. Click Draw Area. Click and drag the mouse on the live video, then release the mouse to nsh
drawing one area.
Network Speed Dome User Manual
48
Figure 8-1 Set Rules
Stop Drawing Stop drawing one area.
Clear All Clear all the areas.
4. Oponal: Y
ou can set the parameters of mulple areas by repeang the above steps.
Expert Mode
You can congure dierent moon
detecon parameters for day and night according to the actual
needs.
Steps
1. Select Expert Mode in Conguraon.
2. Set parameters of expert mode.
Scheduled Image Sengs
OFF
Imag
e switch is disabled.
Auto-Switch
The system switches day/night mode automacally according to environment. It displays
c
olored image at day and black and white image at night.
Scheduled-Switch
The system switches day/night mode according to the schedule. It switches to day mode
during the set periods and switches to night mode during the other periods.
Sensivity
The higher the value of sensivity is, the more
sensive the moon detecon is. If scheduled
image sengs is enabled, the sensivity of day and night can be set separately.
Network Speed Dome User Manual
49
3. Select an Area and click Draw Area. Click and drag the mouse on the live image and then
release the mouse to nish drawing one area.
Figure 8-2 Set Rules
Stop Drawing Finish drawing one area.
Clear All Delete all the areas.
4. Click Sa
ve.
5. Oponal: Repeat above steps to set mulple areas.
8.1.2 Set Video Tampering Alarm
When the congured area is covered and cannot be monitored normally, the alarm is triggered and
the de
vice takes certain alarm response acons.
Steps
1. Go to Conguraon → E
vent → Basic Event → Video Tampering .
2. Check Enable.
3. Set the Sensivity. The higher the value is, the easier to detect the area covering.
4. Click Draw Area and drag the mouse in the live view to draw the area.
Stop Drawing Finish drawing.
Clear All Delete all the drawn areas.
Network Speed Dome User Manual
50
Figure 8-3 Set Video Tampering Area
5. Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
6. Click Save.
8.1.3 Set Excepon Alarm
Excepon such as network
disconnecon can trigger the device to take corresponding acon.
Steps
1. Go to Conguraon → Event → Basic Event → Excepon .
2. Select Excepon Type.
HDD Full The HDD storage is full.
HDD Error Error occurs in HDD.
Network Disconnected The device is oine.
IP Address Conicted The IP address of current device is same as that of other device in
the ne
twork.
Illegal Login Incorrect user name or password is entered.
3. R
efer to Linkage Method Sengs for seng linkage method.
4. Click Save.
Network Speed Dome User Manual
51
8.1.4 Set Alarm Input
Alarm signal from the external device triggers the corresponding acons of the current device.
Before You Start
Make sure the external alarm device is connected. See Quick Start Guide for cables connecon.
Steps
1. Go to Conguraon → Event → Basic Event → Alarm Input .
2. Check Enable Alarm Input Handing.
3. Select Alarm Input NO. and Alarm Type from the dropdown list. Edit the Alarm Name.
4. Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
5. Click Copy to... to copy the sengs to other alarm input channels.
6. Click Save.
8.2 Smart Event
Note
• For certain device models, you need to enable the smart event funcon on V
CA Resource page
rst to show the funcon conguraon page.
• The funcon varies according to dierent models.
8.2.1 Detect Audio Excepon
Audio excepon
detecon funcon detects the abnormal sound in the surveillance scene, such as
the sudden increase/decrease of the sound intensity, and some certain acons can be taken as
response.
Steps
1. Go to Conguraon → E
vent → Smart Event → Audio Excepon Detecon .
2. Select one or several audio excepon detecon types.
Audio Loss Detecon
Detect sudden loss of audio track.
Sudden Incr
ease of Sound Intensity Detecon
Detect sudden increase of sound intensity. Sensivity and Sound Intensity Threshold are
congurable.
Network Speed Dome User Manual
52
Note
• The lower the sensivity is, the more signicant the change should be to trigger the
detecon.
• The sound intensity threshold refers to the sound intensity reference for the detecon. It is
r
ecommended to set as the average sound intensity in the environment. The louder the
environment sound, the higher the value should be. You can adjust it according to the real
environment.
Sudden Decrease of Sound Intensity Detecon
Detect sudden decrease of sound intensity. Sensivity is congurable.
3. R
efer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage methods.
4. Click Save.
Note
The
funcon varies according to dierent models.
8.2.2 Set Intrusion Detecon
Intrusion detecon detects the object movement of entering and loitering in a predened area.
When in
trusion occurs, the device takes linkage acons as response.
Steps
1. Go to Conguraon → E
vent → Smart Event → Intrusion Detecon .
2. Check Enable.
3. Oponal: Click Lock to lock PTZ control to prevent the interrupon from other PTZ related
acon during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
Y
ou can manually resume the lock when the countdown is over.
4. Adjust the live image to the desired scene by using PTZ control buons.
5. Dr
aw detecon area.
1) Select a Region No.. Up to 4 regions can be set.
2) Click Detecon Area.
3) Click on the live image to draw the boundaries of the detecon area, and right click to
complete drawing.
6. Oponal: Se
t the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the detecon.
1) Click Ma
x. Size, and drag the mouse on live image. If you want to change the size, click the
buon and draw again.
Network Speed Dome User Manual
53
2) Click Min. Size, and drag the mouse on the live image. If you want to change the size, click
the buon and draw again.
7. Set detecon parameters.
Sensivity It stands for the sensivity of detecng an target. The higher the value of
sensivity is, the more easily the target is detected.
Threshold Threshold stands for the me of the target loitering in the region. If the
me that she/he stays in the region exceeds the threshold, the alarm is
trig
gered.
Detecon
Target
You can specify the object type, and the device only detects the selected
type of objects.
Figure 8-4 Draw Area
8. Click Save.
9. Repeat above steps to set other detecon areas.
10. Set arming schedule. See Set Arming Schedule .
11. Set linkage method. See Linkage Method Sengs .
8.2.3 Set Line Crossing Detecon
Line crossing detecon is used to detect the object movement of crossing a predened line. When
it occur
s, the device takes linkage
acons as response.
Steps
1. Go to Conguraon → Event → Smart Event → Line Crossing Detecon .
2. Check Enable.
3. Oponal: Click Lock to lock PTZ control to prevent the interrupon from other PTZ related
acon during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
Y
ou can manually resume the lock when the countdown is over.
Network Speed Dome User Manual
54
4. Adjust the live image to the desired scene by using PTZ control buons.
5. Dr
aw detecon line.
1) Select a Line No.. Up to 4 lines can be set in the scene.
2) Click Detecon Area.
A yellow line is displayed on live image.
3) Click on the line, and drag its end points to adjust the length and posion.
4) Select the Direcon for the detecon line.
Direcon
It stands for the direcon from which the object goes across the line.
A<->B
The object g
oing across the line from both direcons can be detected and alarms are
triggered.
A->B
Only the object crossing the congured line from side A to side B can be detected.
B->A
Only the object crossing the congured line from side B to side A can be detected.
Figure 8-5 Draw Line
6. Oponal: Se
t the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the
detecon.
1) Click Max. Size, and drag the mouse on live image. If you want to change the size, click the
buon and draw again.
2) Click Min. Size, and drag the mouse on the live image. If you want to change the size, click
the buon and draw again.
7. Se
t detecon parameters.
Sensivity It stands for the sensivity of detecng an target. The higher the value is,
the mor
e easily the target is detected.
Network Speed Dome User Manual
55
Detecon
Target
You can specify the object type, and the device only detects the selected
type of objects.
8. Click Sa
ve.
9. Repeat above steps to set other lines.
10. Set arming schedule. See Set Arming Schedule .
11. Set linkage method. See Linkage Method Sengs .
8.2.4 Set Region Entrance Detecon
Region entrance
detecon is used to detect the object movement of entering a predened area.
When it occurs, the device takes linkage acons as response.
Steps
1. Go to Conguraon → Event → Smart Event → Region Entrance Detecon .
2. Check Enable.
3. Oponal: Click Lock to lock PTZ control to prevent the interrupon from other PTZ related
acon during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
Y
ou can manually resume the lock when the countdown is over.
4. Adjust the live image to the desired scene by using PTZ control buons.
5. Dr
aw detecon area.
1) Select a Region No.. Up to 4 regions can be set.
2) Click Detecon Area.
3)
Click on the live image to draw the boundaries of the detecon area, and right click to
complete drawing.
6. Oponal: Set the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the
detecon.
1) Click Max. Size, and drag the mouse on live image. If you want to change the size, click the
buon and draw again.
2) Click Min. Size, and drag the mouse on the live image. If you want to change the size, click
the buon and draw again.
7. Se
t detecon parameters.
Sensivity It stands for the sensivity of detecng an target. The higher the value is,
the mor
e easily the target is detected.
Detecon
Target
You can specify the object type, and the device only detects the selected
type of objects.
Network Speed Dome User Manual
56
Figure 8-6 Draw Area
8. Click Sa
ve.
9. Repeat above steps to set other regions.
10. Set arming schedule. See Set Arming Schedule .
11. Set linkage method. See Linkage Method Sengs .
8.2.5 Set Region Exing Detecon
Region exing detecon is used to detect the objects movement of exing from a predened area.
When it occurs, the device takes linkage acons as response.
St
eps
1. Go to Conguraon → Event → Smart Event → Region Exing Detecon .
2. Check Enable.
3. Oponal: Click Lock t
o lock PTZ control to prevent the interrupon from other PTZ related
acon during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
4. Adjust the live image to the desired scene by using PTZ control buons.
5. Dr
aw detecon area.
1) Select a Region No.. Up to 4 regions can be set.
2) Click Detecon Area.
3) Click on the live image to draw the boundaries of the detecon area, and right click to
c
omplete drawing.
6. Oponal: Set the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the
detecon.
1) Click Max. Size, and drag the mouse on live image. If you want to change the size, click the
buon and draw again.
Network Speed Dome User Manual
57
2) Click Min. Size, and drag the mouse on the live image. If you want to change the size, click
the buon and draw again.
7. Set detecon parameters.
Sensivity It stands for the sensivity of detecng an target. The higher the value is,
the mor
e easily the target is detected.
Detecon
Target
You can specify the object type, and the device only detects the selected
type of objects.
Figure 8-7 Draw Area
8. Click Sa
ve.
9. Repeat above steps to set other regions.
10. Set arming schedule. See Set Arming Schedule .
11. Set linkage method. See Linkage Method Sengs .
8.2.6 Set Object Removal Detecon
Object removal
detecon detects whether the objects are removed from the predened detecon
area, such as exhibits on display. When it occurs, the device takes linkage acons as response.
Steps
1. Go to Conguraon → E
vent → Smart Event → Object Removal Detecon .
2. Check Enable.
3. Oponal: Click Lock to lock PTZ control to prevent the interrupon from other PTZ related
acon during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
Y
ou can manually resume the lock when the countdown is over.
4. Adjust the live image to the desired scene by using PTZ control buons.
5. Dr
aw detecon area.
1) Select a Region No.. Up to 4 regions can be set.
Network Speed Dome User Manual
58
2) Click Detecon Area.
3) Click on the live image to draw the boundaries of the detecon area, and right click to
complete drawing.
6. Oponal: Se
t the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the detecon.
1) Click Max. Size, and drag the mouse on live image. If you want to change the size, click the
buon and draw again.
2)
Click Min. Size, and drag the mouse on the live image. If you want to change the size, click
the buon and draw again.
7. Set detecon parameters.
Sensivity The value of the sensivity denes the size of the object which can trigger the
alarm, when the
sensivity is high, a very small object can trigger the alarm.
Threshold The threshold is the me of the objects removed from the area. If you set the
v
alue as 10, alarm is triggered aer the object disappears from the area for 10
seconds.
Figure 8-8 Draw Area
8. Click Sa
ve.
9. Repeat above steps to set other regions.
10. Set arming schedule. See Set Arming Schedule .
11. Set linkage method. See Linkage Method Sengs .
8.2.7 Set Unaended Baggage Detecon
Unaended baggage detecon is used to detect the objects le over in the predened area.
Link
age methods are triggered aer the object is le and stays in the area for a set me period.
Network Speed Dome User Manual
59
Steps
1. Go to Conguraon → E
vent → Smart Event → Unaended Baggage Detecon .
2. Check Enable.
3. Oponal: Click Lock to lock PTZ control to prevent the interrupon from other PTZ related
acon during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
4. Adjust the live image to the desired scene by using PTZ control buons.
5. Draw detecon area.
1) Select a Region No.. Up to 4 regions can be set.
2) Click Detecon Area.
3) Click on the live image to draw the boundaries of the detecon area, and right click to
complete drawing.
6. Oponal: Set the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the detecon.
1) Click Max. Size, and drag the mouse on live image. If you want to change the size, click the
buon and draw again.
2)
Click Min. Size, and drag the mouse on the live image. If you want to change the size, click
the buon and draw again.
7. Se
t detecon parameters.
Sensivity The value of the sensivity denes the size of the object which can trigger the
alarm, when the
sensivity is high, a very small object can trigger the alarm.
Threshold It stands for the me of the objects le in the area. Alarm is triggered
aer the
object is le and stays in the area for the set me period.
Figure 8-9 Draw Area
8. Click Sa
ve.
9. Repeat above steps to set other regions.
Network Speed Dome User Manual
60
Chapter 9 Arming Schedule and Alarm Linkage
Arming schedule is a customized me period in which the device performs certain tasks. Alarm
linkage is the response to the detected certain incident or target during the scheduled me.
9.1 Set Arming Schedule
Set the valid me of the device tasks.
Steps
1. Click Arming Schedule.
2. Drag the me bar to draw desired valid me.
Note
Up to 8 periods can be congured for one day.
3. Adjus
t the me period.
-
Click on the selected me period, and enter the desired value. Click Save.
-
Click on the selected me period. Drag the both ends to adjust the me period.
-
Click on the selected me period, and drag it on the me bar.
4. Oponal: Click Cop
y to... to copy the same sengs to other days.
5. Click Save.
9.2 Linkage Method Sengs
You can enable the linkage funcons when an event or alarm occurs.
9.2.1 Trigger Alarm Output
If the device has been connected to an alarm output device, and the alarm output No. has been
congured, the device sends alarm informaon to the connected alarm output device when an
alarm is trig
gered.
Steps
1. Go to Conguraon → E
vent → Basic Event → Alarm Output .
2. Set alarm output parameters.
Automac Alarm For the informaon about the conguraon, see
Automac Alarm .
Manual Alarm For the informaon about the conguraon, see Manual Alarm .
3. Click Sa
ve.
Network Speed Dome User Manual
62
Automac Alarm
Set the automac alarm parameters, then the device triggers an alarm output automacally in the
set arming schedule.
Steps
1. Set automac alarm parameters.
Alarm Output No.
Select the alarm output No. according to the alarm interface connected to the external alarm
device.
Alarm Name
Custom a name for the alarm output.
Delay
It refers to the me duraon that the alarm output remains aer an alarm occurs.
2. Set the alarming schedule. For the informaon about the sengs, see Set Arming Schedule .
3. Click Copy to… to copy the parameters to other alarm output channels.
4. Click Save.
Manual Alarm
You can trigger an alarm output manually.
St
eps
1. Set the manual alarm parameters.
Alarm Output No.
Select the alarm output No. according to the alarm interface connected to the external alarm
device.
Alarm Name
Custom a name for the alarm output.
Delay
Select Manual.
2. Click Manual Alarm to enable manual alarm output.
3. Oponal: Click Clear Alarm t
o disable manual alarm output.
9.2.2 FTP/NAS/Memory Card Uploading
If you have enabled and congured the FTP/NAS/memory card uploading, the device sends the
alarm informaon to the FTP server, network aached storage and memory card when an alarm is
triggered.
Network Speed Dome User Manual
63
Refer to Set FTP to set the FTP server.
Refer to Set NAS for NAS conguraon.
Refer to Set Memory Card for memory card storage conguraon.
9.2.3 Send Email
Check Send Email, and the device sends an email to the designated addresses with alarm
informaon when an alarm event is detected.
For email sengs, refer to Set Email .
Set Email
When the email is congured and Send Email is enabled as a linkage method, the device sends an
email nocaon to all designated receivers if an alarm event is detected.
Before You Start
Set the DNS server before using the Email funcon. Go to Conguraon → Network → Basic
Sengs → TCP/IP for DNS sengs.
Steps
1. Go t
o email sengs page: Conguraon → Network → Advanced Sengs → Email .
2. Set email parameters.
1) Input the sender's email informaon, including the Sender's Address, SMTP Server, and
SMTP Port.
2) Oponal: If y
our email server requires authencaon, check Authencaon and input your
user name and password to log in to the server.
3) Set the E-mail Encrypon.
• When you select SSL or TLS, and disable STARTTLS, emails are sent aer encrypted by SSL
or TLS. The SMTP port should be se
t as 465.
• When you select SSL or TLS and Enable STARTTLS, emails are sent aer encrypted by
STARTTLS, and the SMTP port should be set as 25.
Note
If you want to use STARTTLS, make sure that the protocol is supported by your email
ser
ver. If you check the Enable STARTTLS while the protocol is not supported by your email
sever, your email is sent with no encrypon.
4) Oponal: If y
ou want to receive nocaon with alarm pictures, check Aached Image. The
nocaon email has 3 aached alarm pictures about the event with congurable image
c
apturing interval.
5) Input the receiver's informaon, including the receiver's name and address.
6) Click Test to see if the funcon is well congured.
3. Click Sa
ve.
Network Speed Dome User Manual
64
9.2.4 Nofy Surveillance Center
Check Nofy Surveillance Center, the alarm informaon is uploaded to the surveillance center
when an alarm event is detected.
9.2.5 Smart Tracking
Check Smart Tracking, and the device tracks the target when an alarm event is detected.
9.2.6 Trigger Recording
Check T
rigger Recording, and the device records the video about the detected alarm event.
For recording sengs, refer to Video R
ecording and Picture Capture
9.2.7 Flashing Light
Aer enabling Flashing Ligh
t and seng the Flashing Light Alarm Output, the light ashes when
an alarm event is detected.
Set Flashing Alarm Light Output
When events occur, the ashing light on the device can be triggered as an alarm.
Steps
1. Go to Conguraon → E
vent → Basic Event → Flashing Alarm Light Output .
2. Set Flashing Duraon, Flashing Frequency and Brightness.
Flashing Duraon
The
me that the ashing lasts when one alarm happens.
Flashing Frequency
The rate at which the light ashes. High frequency, medium frequency, low frequency, and
normally on are selectable.
Brightness
The brightness of the light.
3. Set the arming schedule. See Set Arming Schedule for details.
4. Click Save.
Note
Only certain device models support the funcon.
Network Speed Dome User Manual
65
9.2.8 Audible Warning
Aer enabling Audible Warning and seng the Audible Alarm Output, the built-in speaker of the
device or connected external speaker plays warning sounds when alarm happens.
For audible alarm output sengs, refer to Set Audible Alarm Output .
Note
Before using the
funcon, go to Conguraon → Video/Audio → Audio to enable built-in speaker
in advance.
The funcon is only supported by certain camera models.
Set Audible Alarm Output
When the device detects targets in the detecon area, audible alarm can be triggered as a
w
arning.
Steps
1. Go to Conguraon → Event → Basic Event → Audible Alarm Output .
2. Select Sound Type and set related parameters.
-
Select Prompt and set the alarm mes you need.
-
Select W
arning and its contents. Set the alarm mes you need.
-
Select Custom Audio. You can select a custom audio le from the drop-down list. If no le is
available, you can click Add to upload an audio le that meets the requirement. Up to three
audio les can be uploaded.
3. Oponal: Click T
est to play the selected audio le on the device.
4. Set arming schedule for audible alarm. See Set Arming Schedule for details.
5. Click Save.
Note
The
funcon is only supported by certain device models.
Network Speed Dome User Manual
66
Chapter 10 Network Sengs
10.1 TCP/IP
TCP/IP sengs must be properly congured before you operate the device over network. IPv4 and
IPv6 are both supported. Both versions can be congured simultaneously without conicng to
each other.
Go to Conguraon → Basic Conguraon → Network → TCP/IP for parameter sengs.
NIC Type
Select a NIC (Network Interface Card) type according to your network condion.
IPv4
Two IPv4 modes are available.
DHCP
The device automacally gets the IPv4 parameters from the network if you check DHCP. The
device IP address is changed aer enabling the funcon. You can use SADP to get the device IP
address.
Note
The network that the device is connected to should support DHCP (Dynamic Host
Conguraon
Protocol).
Manual
Y
ou can set the device IPv4 parameters manually. Input IPv4 Address, IPv4 Subnet Mask, and
IPv4 Default Gateway, and click Test to see if the IP address is available.
IPv6
Three IPv6 modes are available.
Route Adversement
The IPv6 address is generated by combining the route adversement and the device Mac
addr
ess.
Note
Route
adversement mode requires the support from the router that the device is connected
to.
DHCP
The IPv6 addr
ess is assigned by the server, router or gateway.
Manual
Network Speed Dome User Manual
67
Input IPv6 Address, IPv6 Subnet, IPv6 Default Gateway. Consult the network administrator for
required informaon.
MTU
It stands for maximum transmission unit. It is the size of the largest protocol data unit that can
be communicated in a single network layer transacon.
The valid value range of MTU is 1280 to 1500.
DNS
It stands for domain name server. It is required if you need to visit the device with domain
name. And it is also required for some applicaons (e.g., sending email). Set Preferred DNS
Server and Alternate DNS server properly if needed.
10.1.1 Mulcast
Mulcast is group communicaon where data transmission is addressed to a group of desnaon
devices simultaneously. Aer seng mulcast, you can send the source data eciently to mulple
receivers.
Go to Conguraon → Network → Basic Sengs → Mulcast for the mulcast sengs.
IP Address
It s
tands for the address of mulcast host.
Stream Type
The stream type as the mulcast source.
Video Port
The video port of the selected stream.
Audio Port
The audio port of the selected stream.
10.1.2 Mulcast Discovery
Check the Enable Mulcast Discovery, and then the online ne
twork camera can be automacally
detected by client soware via private mulcast protocol in the LAN.
10.2 Port
The device port can be modied when the device cannot access the network due to port conicts.
Cauon
Do not modify the default port parameters at will, otherwise the device may be inaccessible.
Network Speed Dome User Manual
68
Go to Conguraon → Network → Basic Sengs → Port for port sengs.
HTTP Port
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.168.1.64:81 in the browser for login.
HTTPS Port
It refers to the port through which the browser accesses the device with cercate. Cercate
vericaon is required to ensure the secure access.
RTSP Port
It refers to the port of real-me streaming protocol.
Server Port
It refers to the port through which the client adds the device.
Enhanced SDK Service Port
It refers to the port through which the client adds the device. Cercate vericaon is required
to ensure the secure access.
WebSocket Port
TCP-based full-duplex communicaon protocol port for plug-in free preview.
W
ebSockets Port
TCP-based full-duplex communicaon protocol port for plug-in free preview. Cercate
vericaon is required to ensure the secure access.
Note
• Enhanced SDK Service Port, WebSocket Port, and WebSockets Port are only supported by certain
models.
•
For device models that support that funcon, go to Conguraon → Ne
twork → Advanced
Sengs → Network Service to enable it.
10.3 Port Mapping
By seng port mapping, you can access devices through the specied port.
Before You Start
When the ports in the device are the same as those of other devices in the network, refer to Port
to modify the device ports.
Steps
1. Go to Conguraon → Ne
twork → Basic Sengs → NAT .
2. Select the port mapping mode.
Auto Port Mapping Refer to Se
t Auto Port Mapping for detailed informaon.
Network Speed Dome User Manual
69
Manual Port Mapping Refer to Se
t Manual Port Mapping for detailed informaon.
3. Click Save.
10.3.1 Set Auto Port Mapping
Steps
1. Check Enable UPnP
™, and choose a friendly name for the camera, or you can use the default
name.
2. Select the port mapping mode to Auto.
3. Click Save.
Note
UPnP™
funcon on the router should be enabled at the same me.
10.3.2 Set Manual Port Mapping
Steps
1. Check Enable UPnP
™, and choose a friendly name for the device, or you can use the default
name.
2. Select the port mapping mode to Manual, and set the external port to be the same as the
internal port.
3. Click Save.
What to do next
Go to the router port mapping sengs interface and set the port number and IP address to be the
same as those on the de
vice. For more informaon, refer to the router user manual.
10.3.3 Set Port Mapping on Router
The following sengs are for a certain router. The sengs vary depending on dierent models of
r
outers.
Steps
1. Select the WAN
Connecon Type.
2. Set the IP Address, Subnet Mask and other network parameters of the router.
3. Go to Forwarding → Virtual Severs , and input the Port Number and IP Address.
4. Click Save.
Example
When the cameras are connected to the same router, you can congure the ports of a camera as
80, 8000, and 554 with IP addr
ess 192.168.1.23, and the ports of another camera as 81, 8001, 555,
8201 with IP 192.168.1.24.
Network Speed Dome User Manual
70
Figure 10-1 Port Mapping on Router
Note
The port of the network camera cannot conict with other ports. For example, some web
manag
ement port of the router is 80. Change the camera port if it is the same as the management
port.
10.4 SNMP
You can set the SNMP network management protocol to get the alarm event and excepon
messages in network transmission.
Be
fore You Start
Before seng the SNMP, you should download the SNMP soware and manage to receive the
device informaon via SNMP port.
St
eps
1. Go to the sengs page: Conguraon → Network → Advanced Sengs → SNMP .
2. Check Enable SNMPv1, Enable SNMP v2c or Enable SNMPv3.
Note
The SNMP version you select should be the same as that of the SNMP soware.
And you also need to use the dierent version according to the security level required. SNMP v1
is not secur
e and SNMP v2 requires password for access. And SNMP v3 provides encrypon and
if you use the third version, HTTPS protocol must be enabled.
3. Congure
the SNMP sengs.
4. Click Sa
ve.
Network Speed Dome User Manual
71
10.5 Access to Device via Domain Name
You can use the Dynamic DNS (DDNS) for network access. The dynamic IP address of the device can
be mapped to a domain name resoluon server to realize the network access via domain name.
Be
fore You Start
Registraon on the DDNS server is required before conguring the DDNS sengs of the device.
St
eps
1. Refer to TCP/IP to set DNS parameters.
2. Go to the DDNS sengs page: Conguraon → Network → Basic Sengs → DDNS .
3. Check Enable DDNS and select DDNS type.
DynDNS
Dynamic DNS server is used for domain name resoluon.
NO-IP
NO-IP server is used for domain name resoluon.
4. Input the domain name informaon, and click Save.
5. Check the device ports and complete port mapping. Refer to Port to check the device port , and
refer to Port Mapping for port mapping sengs.
6. Access the de
vice.
By Browsers Enter the domain name in the browser address bar to access the
de
vice.
By Client Soware Add domain name to the client soware. Refer to the client manual for
specic adding methods.
10.6 Access to Device via PPPoE Dial Up
Connecon
This device supports the PPPoE auto dial-up funcon. The device gets a public IP address by ADSL
dial-up aer the device is connected to a modem. You need to congure the PPPoE parameters of
the device.
Steps
1. Go to Conguraon → Ne
twork → Basic Sengs → PPPoE .
2. Check Enable PPPoE.
3. Set the PPPoE parameters.
Dynamic IP
Aer successful dial-up, the dynamic IP address of the WAN is displayed.
User Name
User name f
or dial-up network access.
Password
Network Speed Dome User Manual
72
Password for dial-up network access.
Conrm
Input your dial-up password again.
4. Click Save.
5. Access the device.
By Browsers Enter the WAN dynamic IP address in the browser address bar to
access the de
vice.
By Client Soware Add the WAN dynamic IP address to the client soware. Refer to the
clien
t manual for details.
Note
The obtained IP address is dynamically assigned via PPPoE, so the IP address always changes
aer
reboong the camera. To solve the inconvenience of the dynamic IP, you need to get a
domain name from the DDNS provider (e.g. DynDns.com). Refer to Access to Device via Domain
Name for detail informaon.
10.7 Accessing via Mobile Client
Hik-Connect is an applicaon for mobile devices. Using the App, you can view live image, receive
alarm
nocaon and so on.
Note
Hik-Connect service should be supported by the camera.
10.7.1 Enable Hik-Connect Service on Camera
Hik-Connect service should be enabled on your camera before using the service.
Y
ou can enable the service through SADP soware or Web browser.
Enable Hik-Connect Service via Web Browser
Follow the following steps to enable Hik-Connect Service via Web Browser.
Before You Start
You need to acvate
the camera before enabling the service.
Steps
1. Access the camera via web browser.
2. Enter plaorm access conguraon interface.
Conguraon → Network → Advanced Sengs
→ Plaorm Access
Network Speed Dome User Manual
73
3. Select Hik-Connect as the Plaorm Access Mode.
4. Check Enable.
5. Click and r
ead "Terms of Service" and "Privacy Policy" in pop-up window.
6. Create a vericaon code or change the old vericaon code for the camera.
Note
The
vericaon code is required when you add the camera to Hik-Connect service.
7. Sa
ve the sengs.
Enable Hik-Connect Service via SADP Soware
This part introduce how to enable Hik-Connect service via SADP soware of an acvated camera.
Steps
1. Run SADP soware.
2. Select a camera and enter Modify Network Parameters page.
3. Check Enable Hik-Connect.
4. Create a vericaon code or change the old vericaon code.
Note
The
vericaon code is required when you add the camera to Hik-Connect service.
5. Click and r
ead "Terms of Service" and "Privacy Policy".
6. Conrm the sengs.
10.7.2 Set Up Hik-Connect
Steps
1. Get and install Hik-Connect applicaon by the following ways.
-
Visit
hps://appstore.hikvision.com to download the applicaon according to your mobile
phone s
ystem.
-
Visit the ocial site of our company. Then go to Support → Tools → Hikvision App Store .
-
Scan the QR code below to download the applicaon.
Note
If errors like "Unknown app" occur during the installaon, solve the problem in two ways.
•
Visit
hps://appstore.hikvision.com/stac/help/index.html to refer to the troubleshoong.
• Visit hps://appstore.hikvision.com/ , and click Installaon Help a
t the upper right corner of
the interface to refer to the troubleshoong.
2. St
art the applicaon and register for a Hik-Connect user account.
3. Log in aer registraon.
Network Speed Dome User Manual
74
10.7.3 Add Camera to Hik-Connect
Steps
1. Connect your mobile device to a Wi-Fi.
2. Log into the Hik-Connect app.
3. In the home page, tap "+" on the upper-right corner to add a camera.
4. Scan the QR code on camera body or on the Quick Start Guide cover.
Note
If the QR code is missing or too blur to be recognized, you can also add the camera by inpung
the camera's serial number.
5. Input the vericaon
code of your camera.
Note
• The required vericaon code is the code you create or change when you enable Hik-Connect
ser
vice on the camera.
• If you forget the
vericaon code, you can check the current vericaon code on Plaorm
Access conguraon page via web browser.
6. T
ap Connect to a Network buon in the popup interface.
7. Choose Wired Connecon or Wireless Connecon according to your camera funcon.
Wireless
Connecon
Input the Wi-Fi password that your mobile phone has connected to, and
t
ap Next to start the Wi-Fi connecon process. (Locate the camera within
3 meters from the router when seng up the Wi-Fi.)
Wired
Connecon
Connect the camera to the router with a network cable and tap
Connect
ed in the result interface.
Note
The router should be the same one which your mobile phone has connected to.
8. T
ap Add in the next interface to nish adding.
For detailed informaon, refer to the user manual of the Hik-Connect app.
10.8 Wi-Fi
Connect the device to wireless network by seng Wi-Fi parameters.
Note
This funcon is only supported by certain device models.
Network Speed Dome User Manual
75
10.8.1 Connect Device to Wi-Fi
Before You Start
Refer to the user manual of wireless router or AP to set SSID, key, and other parameters.
Steps
1. Go to TCP/IP sengs page: Conguraon → Network → Basic Conguraon → TCP/IP .
2. Select Wlan to set the parameters. Refer to TCP/IP for detailed conguraon.
Note
For stable use of Wi-Fi, it is not recommended to use DHCP.
3. Go t
o Wi-Fi sengs page: Conguraon → Network → Advanced Conguraon → Wi-Fi .
4. Set and save the parameters.
1) Click Search.
2) Select a SSID, which should be the same as that of wireless router or AP.
The parameters of the network is automacally shown in Wi-Fi.
3) Select the Network Mode as Manage.
4) Input the key to connect the wireless network. The key should be that of the wireless
network connecon you set on the router.
What to do next
Go to TCP/IP sengs page: Conguraon → Ne
twork → Basic Conguraon → TCP/IP , and click
Wlan to check the IPv4 Address and log in the device. See Access Device via Web Browser for
detailed informaon.
10.9 Set ISUP
When the device is registered on ISUP plaorm (formerly called Ehome), you can visit and manage
the de
vice, transmit data, and forward alarm informaon over public network.
Steps
1. Go to Conguraon → Ne
twork → Advanced Sengs → Plaorm Access .
2. Select ISUP as the plaorm access mode.
3. Select Enable.
4. Select a protocol version and input related parameters.
5. Click Save.
Register status turns to Online when the funcon is correctly set.
10.10 Set Open Network Video Interface
If you need to access the device through Open Network Video Interface protocol, you can
congure
the user sengs to enhance the network security.
Network Speed Dome User Manual
76
Steps
1. Go to Conguraon → Ne
twork → Advanced Sengs → Integraon Protocol .
2. Check Enable Open Network Video Interface.
3. Click Add to congure the Open Network Video Interface user.
Delete Delete the selected Open Network Video Interface user.
Modify Modify the selected Open Network Video Interface user.
4. Click Sa
ve.
5. Oponal: Repeat the steps above to add more Open Network Video Interface users.
10.11 Set Network Service
You can control the ON/OFF status of certain protocol as desired.
Steps
Note
This funcon varies according to
dierent models.
1. Go t
o Conguraon → Network → Advanced Sengs → Network Service .
2. Set network service.
WebSocket & WebSockets
WebSocket or WebSockets protocol should be enabled if you use Google Chrome 57 and its
above version or Mozilla Firefox 52 and its above version to visit the device. Otherwise, live
view, image capture, and digital zoom funcon cannot be used.
If the de
vice uses HTTP, enable WebSocket.
If the device uses HTTPS, enable WebSockets.
SDK Service & Enhanced SDK Service
Check Enable SDK Service to add the device to the client soware with SDK protocol.
Check Enable Enhanced SDK Ser
vice to add the device to the client soware with SDK over
TLS pr
otocol.
Note
When set up
connecon between the device and the client soware, it is recommended to
use Enhanced SDK Service and set the communicaon in Arming Mode to encrypt the data
transmission. See the user manual of the client soware for the arming mode sengs.
TLS (Transport Layer Security)
The de
vice oers TLS1.1 and TLS1.2. Enable one or more protocol versions according to your
need.
3. Click Save.
Network Speed Dome User Manual
77
10.12 Set Alarm Server
The device can send alarms to desnaon IP address or host name through HTTP, HTTPS, or ISUP
protocol. The desnaon IP address or host name should support HTTP, HTTP, or ISUP data
tr
ansmission.
Steps
1. Go to Conguraon → Ne
twork → Advanced Sengs → Alarm Server .
2. Enter
Desnaon IP or Host Name, URL, and Port.
3. Select Protocol.
Note
HTTP, HTTPS, and ISUP are selectable. It is recommended to use HTTPS, as it encrypts the data
tr
ansmission during communicaon.
4. Click T
est to check if the IP or host is available.
5. Click Save.
10.13 TCP Acceleraon
TCP acceleraon is used to improve latency and reduce packet loss caused by network congeson
in poor network condion, and guarantee the uency of live view.
10.14 Trac Shaping
Trac shaping is used to shape and smooth video data packet before transmission.
It help
s to improve latency and reduce packet loss caused by network congeson and ensure the
video quality as well. Shaping level is congurable.
Network Speed Dome User Manual
78
Chapter 11 System and Security
It introduces system maintenance, system sengs and security management, and explains how to
congure relevant parameters.
11.1 View Device Informaon
You can view device informaon, such as Device No., Model, Serial No. and Firmware Version.
Enter Conguraon → System → System Sengs → Basic Informaon to view the device
informaon.
11.2 Restore and Default
Restore and Default helps restore the device parameters to the default sengs.
Steps
1. Go to Conguraon → System → Maintenance → Upgrade & Maintenance .
2. Click Restore or Default according to your needs.
Restore Reset device parameters, except user informaon, IP parameters and video format
t
o the default sengs.
Default Reset all the parameters to the factory default.
Note
Be careful when using this funcon. Aer
reseng to the factory default, all the
parameters are reset to the default sengs.
11.3 Search and Manage Log
Log helps locate and troubleshoot problems.
St
eps
1. Go to Conguraon → System → Maintenance → Log .
2. Set search condions Major Type, Minor Type, Start Time, and End Time.
3. Click Search.
The matched log les will be displayed on the log list.
4. Oponal: Click Export t
o save the log les in your computer.
Network Speed Dome User Manual
79
11.4 Import and Export Conguraon File
It helps speed up batch conguraon on other devices with the same parameters.
Steps
1. Export conguraon
le.
1) Go to Conguraon → System → Maintenance → Upgrade & Maintenance .
2)
Click Device Parameters and input the encrypon password to export the current
conguraon le.
3) Set the saving path to save the conguraon le in local computer.
2. Import conguraon le.
1) Access the device that needs to be congured via web browser.
2) Click Browse to select the saved conguraon le.
3) Input the encrypon password you have set when exporng the conguraon le.
4) Click Import.
11.5 Export Diagnose Informaon
Diagnose informaon includes running log, system informaon, hardware informaon.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance , and click Diagnose
Informaon to export diagnose informaon of the device.
11.6 Reboot
You can reboot the device via browser.
Go t
o Conguraon → System → Maintenance → Upgrade & Maintenance , and click Reboot.
11.7 Upgrade
Before You Start
Y
ou need to obtain the correct upgrade package.
Cauon
DO NOT disconnect power during the process, and the device reboots automacally
aer upgrade.
Steps
1. Go t
o Conguraon → System → Maintenance → Upgrade & Maintenance .
2. Choose one method to upgrade.
Firmware Locate the exact path of the upgrade le.
Firmware Directory Locate the directory which the upgrade le belongs to.
Network Speed Dome User Manual
80
3. Click Browse to select the upgrade le.
4. Click Upgr
ade.
11.8 View Open Source Soware License
Go to Conguraon → System → System Sengs → About Device , and click View Licenses.
11.9 Set Live View Connecon
It controls the remote live view connecon amount.
Live view connecon controls the maximun live view that can be streamed at the same me.
Enter Conguraon → System → Maintenance → System Service to set the upper limit of the
remote connecon number.
11.10 Time and Date
You can congure me and date of the device by conguring me zone, me synchronizaon and
Daylight Saving Time (DST).
11.10.1 Synchronize Time Manually
Steps
1. Go to Conguraon → System → System Sengs → Time Sengs .
2. Select Time Zone.
3. Click Manual Time Sync..
4. Choose one me
synchronizaon method.
-
Select Set Time, and manually input or select date and me from the pop-up calendar.
-
Check Sync. with computer me to synchronize the me of the device with that of the local
PC.
5. Click Sa
ve.
11.10.2 Set NTP Server
You can use NTP server when accurate and reliable me source is required.
Be
fore You Start
Set up a NTP server or obtain NTP server informaon.
Steps
1. Go t
o Conguraon → System → System Sengs → Time Sengs .
2. Select Time Zone.
Network Speed Dome User Manual
81
3. Click NTP.
4. Set Server Address, NTP Port and Interval.
Note
Server Address is NTP server IP address.
5. Click T
est to test server connecon.
6. Click Sa
ve.
11.10.3 Set DST
If the region where the device is located adopts Daylight Saving Time (DST), you can set this
funcon.
Steps
1. Go t
o Conguraon → System → System Sengs → DST .
2. Check Enable DST.
3. Select Start Time, End Time and DST Bias.
4. Click Save.
11.11 Set RS-485
RS-485 is used to connect the device to external device. You can use RS-485 to transmit the data
between the device and the computer or terminal when the communicaon distance is too long.
Be
fore You Start
Connect the device and computer or termial with RS-485 cable.
Steps
1. Go to Conguraon → S
ystem → System Sengs → RS-485 .
2. Set the RS-485 parameters.
Note
You should keep the parameters of the device and the computer or terminal all the same.
3. Click Sa
ve.
11.12 Security
You can improve system security by seng security parameters.
Network Speed Dome User Manual
82
11.12.1 Authencaon
You can improve network access security by seng RTSP and WEB authencaon.
Go to Conguraon → S
ystem → Security → Authencaon to choose authencaon protocol
and method according to your needs.
RTSP
Authencaon
Digest and digest/basic are supported, which means authencaon informaon is needed when
RTSP request is sent to the device. If you select digest/basic, it means the device supports
digest or basic authencaon. If you select digest, the device only supports digest
authencaon.
RTSP Digest Algorithm
MD5, SHA256 and MD5/SHA256 encrypted algorithm in RTSP authencaon. If you enable the
digest algorithm except for MD5, the third-party plaorm might not be able to log in to the
device or enable live view because of compability. The encrypted algorithm with high strength
is recommended.
WEB Authencaon
Digest and digest/basic are supported, which means authencaon informaon is needed when
WEB request is sent to the device. If you select digest/basic, it means the device supports digest
or basic authencaon. If you select dig
est, the device only supports digest authencaon.
WEB Digest Algorithm
MD5, SHA256 and MD5/SHA256 encrypted algorithm in WEB authencaon. If you enable the
digest algorithm except for MD5, the third-party plaorm might not be able to log in to the
de
vice or enable live view because of compability. The encrypted algorithm with high strength
is recommended.
Note
Refer to the specic content of protocol to view authencaon requirements.
11.12.2 Set IP Address Filter
IP address lter is a tool for access control. You can enable the IP address lter to allow or forbid
the visits from the certain IP addresses.
IP address refers to IPv4.
Steps
1. Go to Conguraon → S
ystem → Security → IP Address Filter .
2. Check Enable IP Address Filter.
3. Select the type of IP address lter.
Forbidden IP addresses in the list cannot access the device.
Network Speed Dome User Manual
83
Allowed Only IP addresses in the list can access the device.
4. E
dit the IP address lter list.
Add Add a new IP address to the list.
Modify Modify the selected IP address in the list.
Delete Delete the selected IP address in the list.
5. Click Sa
ve.
11.12.3 Set HTTPS
HTTPS is a network protocol that enables encrypted transmission and identy authencaon,
which improves the security of remote access.
Steps
1. Go to Conguraon → Network → Advanced Sengs → HTTPS .
2. Check Enable .
3. Click Delete to recreate and install cercate.
Create and install self-signed cercate Refer to Creat
e and Install Self-signed Cercate
Create cercate request and install
cercate
Refer to Ins
tall Authorized Cercate
4. Click Save.
Create and Install Self-signed Cercate
Steps
1. Check Cr
eate Self-signed Cercate.
2. Click Create.
3. Follow the prompt to enter Country, Hostname/IP, Validity and other parameters.
4. Click OK.
Result
The device will install the self-signed cercate by default.
Install Authorized Cercate
If the demand for external access security is high, you can create and install authorized cercate
via HTTPS protocol to ensure the data transmission security.
St
eps
1. Select Create cercate request rst and connue the installaon.
2. Click Cr
eate.
Network Speed Dome User Manual
84
3. Follow the prompt to input Country, Hostname/IP, Validity and other parameters.
4. Click Download to download the cercate request and submit it to the trusted authority for
signa
ture.
5. Import cercate to the device.
-
Select Signed cercate is available, start the installaon directly. Click Browse and Install
to import the cercate to the device.
-
Select Create the cercate request rst and connue the installaon. Click Browse and
Install to import the cercate to the device.
6. Click Save.
11.12.4 Security Audit Log
The security audit logs refer to the security operaon logs. You can search and analyze the security
log les of the device so as to nd out the illegal intrusion and troubleshoot the security events.
Security audit logs can be saved on device internal storage. The log will be saved every half hour
aer device boong. Due to limited storage space, you can also save the logs on a log server.
Search Security Audit Logs
You can search and analyze the security log les of the device so as to nd out the illegal intrusion
and troubleshoot the security events.
Steps
Note
This funcon is only supported by certain camera models.
1. Go t
o Conguraon → System → Maintenance → Security Audit Log .
2. Select log types, Start Time, and End Time.
3. Click Search.
The log les that match the search condions will be displayed on the Log List.
4. Oponal: Click Export t
o save the log les to your computer.
Set Log Server
The log server should support syslog (RFC 3164) over TLS.
St
eps
1. Check Enable Log Upload Server.
2. Oponal: Check Enable Encrypted Transmission if you want the log data to be encrypted.
3. Input Log Server IP and Log Server Port.
4. Click Test to test the sengs.
Network Speed Dome User Manual
85
Note
Install cercates according to the requirement of the log server. If two-way authencaon is
r
equired, install the CA cercate and the client cercate. If one-way authencaon is required,
install the CA cercate.
1. Oponal: Ins
tall client cercate.
1) Click Create to create the cercate request. Fill in the required informaon in the pop-up
window.
2) Click Download to download the cercate request and submit it to the trusted authority for
signature.
3) Install the authorized cercate to the device.
6. Install the CA cercate to the device.
Note
Prepare a CA cercate in advance.
1) Click Br
owse, and select the CA cercate le.
2) Click Install.
11.12.5 Set QoS
QoS (Quality of Service) can help improve the network delay and network congeson by seng
the priority of data sending.
Note
QoS needs support from network device such as router and switch.
Steps
1. Go t
o Conguraon → Network → Advanced Conguraon → QoS .
2. Set Video/Audio DSCP, Alarm DSCP and Management DSCP.
Note
Network can idenfy the priority of data transmission. The bigger the DSCP value is, the higher
the priority is. Y
ou need to set the same value in router while conguraon.
3. Click Sa
ve.
11.12.6 Set IEEE 802.1X
IEEE 802.1x is a port-based network access control. It enhances the security level of the LAN/
WLAN. When de
vices connect to the network with IEEE 802.1x standard, the authencaon is
needed.
Go t
o Conguraon → Ne
twork → Advanced Sengs → 802.1X , and enable the funcon.
Network Speed Dome User Manual
86
Set Protocol and EAPOL Version according to router informaon.
Protocol
EAP-LEAP, EAP-TLS, and EAP-MD5 are selectable
EAP-LEAP and EAP-MD5
If you use EAP-LEAP or EAP-MD5, the authencaon server must be congured. Register a
user name and password for 802.1X in the server in advance. Input the user name and
password for authencaon.
EAP-TLS
If you use EAP-TLS, input Idenfy, Private Key Password, and upload CA Cercate, User
Cercate and Private Key.
EAPOL Version
The EAPOL version must be idencal with that of the router or the switch.
11.12.7 User and Account
Set User Account and Permission
The administrator can add, modify, or delete other accounts, and grant dierent permission to
dierent user levels.
Cauon
To increase security of using the device on the network, please change the password of your
acc
ount regularly. Changing the password every 3 months is recommended. If the device is used in
high-risk environment, it is recommended that the password should be changed every month or
week.
Steps
1. Go t
o Conguraon → System → User Management → User Management .
2. Click Add. Enter User Name, select Level, and enter Password. Assign remote permission to
users based on needs.
Administrator
The administrator has the authority to all operaons and can add users and operators and
assign permission.
User
User
s can be assigned permission of viewing live video, seng PTZ parameters, and changing
their own passwords, but no permission for other operaons.
Operator
Network Speed Dome User Manual
87
Operators can be assigned all permission except for operaons on the administrator and
creang accounts.
Modify Select a user and click Modif
y to change the password and permission.
Delete Select a user and click Dele
te.
Note
The administrator can add up to 31 user accounts.
3. Click OK.
Online Users
The informaon of users logging into the device is shown.
Go t
o Conguraon → System → User Management → Online Users to view the list of online
users.
Network Speed Dome User Manual
88
Appendix A. Device Command
Scan the following QR code to get device common serial port commands.
Note that the command list contains the commonly used serial port commands for all Hikvision
network cameras.
Network Speed Dome User Manual
89
Appendix B. Device Communicaon Matrix
Scan the following QR code to get device communicaon matrix.
Note that the matrix contains all communicaon ports of Hikvision network cameras.
Network Speed Dome User Manual
90
UD20638B
