ZRC-01AN
For use with models: ZAN-C
1
15/16
”
(50mm)
4 5/16”
(110mm)
2
INCLUDED MATERIALS
(2) M3.5*1”
(2)
M4*8
(6)
Brackets
OCT 17.0201
XP022458(2)
2277 Harbor Bay Pkwy
Alameda, CA 94502
1.888.880.8368
Remove all black foam from filter opening
before installing the charcoal filter brackets.
Place charcoal lter on back-side of bae
lter. And place lter brackets over
charcoal lter and secure in place by
tucking each end of bracket under the
bae lter frame. Re-install bae lter.
1 3
Follow instructions in hood
manual to enable the
“replace charcoal filter”
indicator on the hood
controls.
