ZRC-02AZ
2277 Harbor Bay Pkwy
1.888.880.8368
Alameda, CA 94502
For use with models : ZAZ-C
LIST OF MATERIALS
(8) M3*10
8 3/16”
(208mm)
3 1/8”
(80mm)
OCT 17.0201 XP022460(2)
Remove all black foam from filter opening
before installing the charcoal filter brackets.
(6) Brackets
Place charcoal filter on back-side of baffle
fiter. And place filter brackets over charcoal
filter and secure in place by
tucking each
end of bracket under the baffle filter frame.
Re-install baffle filter.
Follow instructions in hood
manual to enable the
“replace charcoal filter”
indicator on the hood
controls.
3
