User Guide
Kasa Smart Wi-Fi Plug Mini
EP10
© 2021 TP-Link1910012920 REV1.0.0
Contents
About This Guide ···················································· 1
Introduction ······························································· 2
Appearance ······························································· 3
Set Up Your Smart Wi-Fi Plug Mini ················ 4
Simple to Set up and Use with Alexa ·········· 5
Main Device Controls ··········································· 6
Congure Your Smart Wi-Fi Plug Mini ········· 7
Create Scenes························································12
Smart Actions ·························································14
Discover Kasa ·························································25
1
About This Guide
This guide provides a brief introduction to Kasa Smart Wi-Fi Plug Mini and the Kasa Smart app, as well as regulatory information.
Please note that features of Kasa Smart Wi-Fi Plug Mini may vary slightly depending on the model and software version you have, and on your location,
language and internet service provider. All images, steps, and descriptions in this guide are only examples and may not reect your actual experience.
Conventions
In this guide, the following convention is used:
Convention Description
Teal
Key information appears in teal, including management page text such as menus, items, buttons and so on.
Underline
Hyperlinks are in teal and underlined. You can click to redirect to a website.
More Info
• Operating temperature, storage temperature, and other specications can be found on the product page at
https://www.tp-link.com.
• Our Technical Support and troubleshooting information can be found at
https://www.tp-link.com/support/.
• A TP-Link Community is provided for you to discuss our products at
https://community.tp-link.com.
2
Introduction
Kasa Smart Wi-Fi Plug Mini is a compact home device that turns your typical electrical wall outlet into a controllable, customizable and multi-functional
outlet, enabling you to easily control your lights and household electronic devices via Kasa Smart app on your iOS or Android devices, no matter where
you nd yourself.
Control from Anywhere Compact Design
No Hub Required Home Automation Away ModeSchedule and Timer
• Control from Anywhere- Manages plugged-in electronics from anywhere with the Kasa Smart app.
• Compact Design- Allows two plugs to be stacked in the same outlet.
• No Hub Required- Connects to your home’s Wi-Fi network. No need for a hub or extra equipment.
• Home Automation- Set multiple schedules, create scenes and groups, and simulate occupancy while away with away mode.
• Schedule and Timer- Preset a schedule to automatically manage devices and create countdown timer lists for connected electronics.
• Away Mode- Automatically turns devices on and o at dierent times to give the appearance that someone is home.
Supported Load Types:
Heater: ≤1500 W Toaster: ≤850 W
Humidier: ≤260 W Tower Fan: ≤50 W
Iron: ≤1500 W
3
Appearance
Smart Wi-Fi Plug Mini has a control button to turn on/o devices plugged in: It is super easy to use.
*EP10 (US version) is used for demonstration in this guide.
Press to turn the socket ON or OFF.
Press for 5s to reset Wi-Fi connection.
Press for 10s to restore to factory default settings.
Blinking orange & blue: Ready to be set up.
Solid blue: Setup is completed.
4
Set Up Your Smart Wi-Fi Plug Mini
Follow the steps below to set up your smart plug via Kasa Smart app.
1. Install Kasa Smart app
Get the Kasa Smart app from Google Play or
the Apple App Store, or scan the QR code
below to download it.
2. Log in or sign up with TP-Link ID
Open the Kasa Smart app and log in with
your TP-Link ID. If you don’t have an account,
create one rst.
3. Add Device
Tap the button in the Kasa Smart app,
select
Device > Smart Plugs > Smart Plug Mini
and then follow step-by-step app instructions
to complete the setup.
5
Simple to Set up and Use with Alexa
Setup is faster than ever before with Alexa. Use your Echo device to set up the plug via voice command.
Once you’ve set up your Echo
device, plug in your TP-Link
smart plug. If Alexa or the Alexa
app says “New plug found,” go
straight to step 3.
In the Kasa app, click the ‘+’
icon and then follow the step-
by-step instructions to set up
your smart plug and link your
TP-Link account to Amazon.
To use your device with Alexa,
just say “Alexa, turn on First
Plug.”
6
Main Device Controls
After you successfully set up your smart plug, you will see the home page of the Kasa Smart app. Here you can view and manage all devices that you've
added to Kasa. Tap a smart plug to control and manage it.
Home Page
Device Status
7
Congure Your Smart Wi-Fi Plug Mini
Set Schedule
You can set schedules for your smart plug to turn on/o automatically to simplify your daily rountine.
1. Tap
on the Device Status Page.
2. Tap the + icon and select the time and
frequency for your smart plug to turn on or o
automatically.
3. You can also choose to turn your plug on or
o at Sunrise or Sunset, which is based on the
your location.
8
Set Away Mode
You can set Away Mode for your smart plug to turn on/o automatically at random intervals while you are away to make the appearance that someone
is at home.
2. Set the time period during which your smart
plug will turn on/off automatically and select
the repeating frequency.
1. Tap
on the Device Status page.
9
Set Timer
Set the countdown timer and your smart plug will automatically be turned on/o after the time ends.
2. Set the time period after which your smart
plug will turn on or o automatically.
1. Tap
on the Device Status page.
10
Check Usage
You can view and track energy consumption of your smart plug.
2. Check the runtime of your smart plug.
1. Tap
on the Device Status page.
11
Change Device Settings
You can change the device name and check device information in Device Settings.
1. Tap
in the Device Status page.
2. You can view
Device Info and change the
name of your smart plug.
12
Create Scenes
A scene is a preset group of smart devices that can be programmed, customized and activated simultaneously at the touch of a button from your
smartphone or tablet, allowing you to easily set your mood, activity or t any special occasion. This page allows you to preset how your smart home
devices should act automatically at special occasions.
1. Tap
at the bottom, then tap + at the
top right corner.
2. Select a scene or create your own scene.
For example: I want to turn off Air Cleanser
light and turn on Fan simultaneously with just
a tap in the Kasa Smart app .
3. Select devices for the scene to work on
and set their status respectively.
13
4. Pick an icon for your scene. 5. Name your scene. 6. Your scene is created and is displayed in
the scene list. Just tap the scene to activate
it.
14
Smart Actions
Smart Actions is a function provided that enables device interconnections and home automations. With Smart Actions, your Kasa devices can work
together to create a smarter smart home. From the moment you wake up to the moment you drift asleep, Smart Actions make your home safer and
more comfortable.
1. Tap
at the bottom, then tap Add
an Action
.
2. Select an automation type for your Smart
Actions.
Motion Sensing: Take actions when a Kasa
camera senses a motion.
Control With a Switch: Extending the Smart
Switch control to other Kasa Smart devices. Turn
on/o a group of devices with the Smart Switch
all together.
Schedule a Scene: Schedule a “Scene” to be
turned on automatically at the time specied.
Auto-off Timer: Whenever a Smart device is
turned on, turn it o after the designated amount
of time.
15
1. Tap Motion Sensing then select a camera. 2. Select the outlet of your Smart Power
Strip which your living room light is plugged
in.
1. Congure Motion Sensing If you already have a Kasa Smart Camera
e.g.: I want to turn the living room light on when my Kasa camera senses a motion.
16
3. Set the time when you want to be notied. You can choose Always or tap Custom to choose time according to your needs.
For example: I want the motion to trigger the light on from 11:00 PM to 7:00 AM every day.
17
4. (Optional) Set an auto-o timer then tap Complete. Then your living room light will be
turned o after the time you set.
5. Name your action for easy identication.
18
6. The Smart Action is created successfully
and displayed in the Smart Actions list.
19
1. Tap Control With a Switch. 2. Add a Kasa smart switch. Then select the
outlet of your Smart Power Strip which your
living room light is plugged in.
2. Congure Control With a Switch If you already have a Kasa Smart Switch
e.g.: I want to turn the living room light on when I turn on my switch, and turn the light o when I turn o the switch.
20
3. Name your action for easy identication. 4. Now Your Smart Action is created
successfully.
21
1. Tap
Schedule a Scene then select a scene you have created.
For example: I want to turn on my
Good Morning scene, which turns on my bedroom and
kitched light with just a tap, at 7: 20 AM every weekday.
2. Set the time and frequency at which you
want your scene to be turned on .
3. Congure Schedule a Scene
e.g.: I want to turn on the scene I have created automatically at scheduled time.
22
3. Name your action for easy identication. 4. The Smart Action is created successfully
and displayed in the Smart Actions list.
23
1. Tap Auto-O Timer then select a device. 2. Set the time.
4. Congure Auto-O Timer
e.g.: I want to turn o my air cleaner is plugged in after 30 minutes whenever it is turn on.
24
3. Name your action for easy identication. 4. The Smart Action is created successfully
and displayed in the Smart Actions list.
25
Discover Kasa
Use the Kasa Smart app to pair your Smart Wi-Fi Power Strip with Amazon Alexa or Google Home Assistant, and enjoy a full hands-free experience.
Kasa helps manage the rest of your smart home too, working with Samsung SmartThings to trigger changes when you arrive home or leave for the day.
Launch the Kasa Smart app. Go to the sidebar and tap Work with Kasa. You can choose Amazon Alexa / Google Assistant/ IFTTT / Samsung
SmartThings for detailed instructions.
26
FCC compliance information statement
Product Name: Kasa Smart Wi-Fi Plug Mini
Model Number: EP10
Responsible party:
TP-Link USA Corporation, d/b/a TP-Link North America, Inc.
Address: 145 South State College Blvd. Suite 400, Brea, CA 92821
Website:
http://www.tp-link.com/us/
Tel: +1 626 333 0234
Fax: +1 909 527 6803
E-mail:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
27
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications
could void the user’s authority to operate the equipment.
FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be
co-located or operating in conjunction with any other antenna or transmitter.
“To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile Configurations. The antennas used for this
transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction
with any other antenna or transmitter.”
We, TP-Link USA Corporation, has determined that the equipment shown as above has been shown to comply with the applicable technical standards,
FCC part 15. There is no unauthorized change is made in the equipment and the equipment is properly maintained and operated.
Issue Date: 2021-04-28
28
Canadian Compliance Statement
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-
exempt RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement
économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
1) L’appareil ne doit pas produire de brouillage;
2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
Déclaration d’exposition aux radiations:
Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être
installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps.
Industry Canada Statement
CAN ICES-3 (B)/NMB-3(B)
Korea Warning Statements
당해 무선설비는 운용중 전파혼신 가능성이 있음.
NCC Notice
29
BSMI Notice
30
Safety Information
• The automatic operation feature is Type 1.B action according to UL 60730-1.
• The product is Pollution Degree 2, which is intended to be used in a household environment or similar.
• Keep the device away from water, fire, humidity or hot environments.
• Do not attempt to disassemble, repair, or modify the device.
• Do not use the device where wireless devices are not allowed.
• The socket-outlet shall be installed near the equipment and shall be easily accessible.
• For passthrough devices, plug the power strips into the integrated electrical sockets of the devices, but devices of the same or another type not
be stacked in normal use.
• Please read and follow the above safety information when operating the device. We cannot guarantee that no accidents or damage will occur due
to improper use of the device. Please use this product with care and operate at your own risk.
• Supported load types
Coffee Maker: ≤800 W Heater: ≤1500 W Toaster: ≤850 W Tower
Desk Lamp: ≤235.2 W Humidifier: ≤260 W Fan: ≤50 W
LCD: ≤270 W Iron: ≤1500 W
31
Operating Temperature: 0 ºC~ 40 ºC (32°F ~ 104°F )
Storage Temperature: -40 ºC~ 70 ºC (-40°F ~ 158°F )
Explanation of the symbols on the product label
AC voltage
Indoor use only
μ
Switch of micro-gap / micro-disconnection construction
RECYCLING
This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must
be handled pursuant to European directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment.
User has the choice to give his product to a competent recycling organization or to the retailer when he buys a new electrical or electronic
equipment.
