OWNER’S MANUAL
Ceramic Heater
MODEL: NTH15-17BRA
PLEASE READ AND SAVE THESE
INSTRUCTIONS
1
IMPORTANT INSTRUCTIONS
PLEASE READ AND SAVE THESE IMPORTANT SAFETY
INSTRUCTIONS
When using electrical appliances,basic precautions should
always be followed to reduce the risk of fire,electric shock,and
injury to persons,including the following:
1. Read all instructions before using heater.
2. This heater is hot when in use. To avoid burns, do not let
bare skin touch hot surface. If provided, always use handles
when moving this heater. Keep combustible materials such
as furniture, pillows, bedding, papers, clothes and curtains at
least 3 feet (0.9m) from the front of the heater and keep
them away from the sides and rear.
3. Extreme caution is necessary when any heater is used by or
near children or invalids and whenever the heater is left
operating and unattended.
4. Always unplug the heater when not in use.
5. Do not operate any heater with a damaged cord or plug or
after the heater malfunctions, has been dropped or damaged
in any manner. Discard heater or return heater to authorized
service facility for examination, electrical or mechanical
adjustment, or repair.
6. Do not use the heater outdoors.
7. This heater is not intended for use in bathroom, laundry
areas and similar moist indoor locations. Never locate heater
where it may fall into a bathtub or other water container.
8. Do not run cord under carpeting. Do not cover cord with
throw rugs, runners, or similar coverings. Do not route cord
under furniture or appliances. Arrange cord away from traffic
area and where it will not be tripped over.
9. CAUTION: This appliance has a polarized plug (one blade is
wider than the other). To reduce the risk of shock, this plug
is intended to fit only one way in a polarized outlet. If the
plug does not fit fully in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician. DO NOT attempt
2
to defeat this safety feature. To do so could result in an
electric shock hazard.
10. This heater draws 12.5 amps during operation. To prevent
overloading a circuit, do not plug the heater into a circuit that
already has other appliances working.
11. CAUTION: It is normal for the plug to feel warm to the touch;
however, a loose fit between the AC outlet (receptacle) and
plug may cause overheating and distortion of the plug.
Contact a qualified electrician to replace loose or worn outlet.
12. To disconnect the heater, first turn controls to off, then
remove plug from outlet. Never pull by the cord.
13. Do not insert or allow foreign objects to enter any ventilation
or exhaust opening as this may cause an electric shock or
fire, or damage the heater.
14. To prevent a possible fire, do not block air intakes or
exhaust in any manner. Do not use on soft surface, like a
bed, where openings may become blocked.
15. A heater has hot and arcing or sparking parts inside. Do not
use it in the areas where gasoline, paint, or flammable
liquids are used or stored.
16. Use this heater only as described in this manual. Any other
use not recommended by the manufacturer may cause fire,
electric shock, or injury to persons.
17. CAUTION: Always plug heaters directly into a wall
outlet/receptacle. Never use with an extension cord or
reloadable power tap (outlet/power strip).
18. The output of this heater may vary and its temperature may
become intense enough to burn exposed skin. Use of this
heater is not recommended for persons with reduced
sensitivity to heat or an inability to react to avoid burns.
19. Disposal of oil contained within should be in accordance with
applicable regional, national, and local laws and regulations.
20. “SAVE THESE INSTRUCTIONS”
3
PART FIGURE
Control panel
Front cover
Grille
OPERATING INSTRUCTION
Check before turning on the machine
1.
Check if the power wire is under good condition.
2.
The product adopts 120V AC power supply, before use, please confirm if
the rated current of the power socket meets the local requirements with safe
grounding device, otherwise, please replace it with the qualified socket.
Vertical and horizontal
This product can stand to use or lie to use, please according to the use of the
scene and the way they like to choose to use or lie.
Start the machine
Plug the unit into a grounded 120V outlet, press the ON/OFF key (or press the
ON/OFF key of the remote controller) for start, the machine supplies air at high
power after start,the display will show the temperature of 95°F.
4
Function setting
Repeatedly press the "Mode" key so that the heater switches in the order of
"high gear - low gear - fan - ECO mode - high gear".
Temperature setting
In the working state of the machine, press "+" or "-" can set the temperature value,
set the range of 40-95°F.When the room temperature reaches the set temperature, the
display flashes 10S, the machine stops working, in the standby state, when the
temperature is lower than the set temperature, the machine starts to heat up again.
Timing function
Timing stop
When the electric heater is turned on, press the TIMER key to enter the timing stop
state (within 0-24 hours), then press the “+” key to increase the timing stop time by
1 hour once, and press the “-” key to decrease the timing stop time by 1 hour once.
Timing start
When the electric heater is in the standby mode, press the TIMER key to enter the
reservation start mode (within 0-24 hours), then press the “+” key to increase the
reservation start time by 1 hour once, and press the “-” key to decrease the
reservation start time by 1 hour once.
Swing function
The electric heater in operation mode, press the "swing" key to open the swing
function, pressing this button to turn off the swing function; when the electric heater
stops heating function, the wind swinging function also stop.
memory function
Machine after normal shutdown, restart, will be in accordance with the recent
shutdown before the state run.
Power off, once again, in accordance with the factory default values. high gear start.
Set temperature by default to 95°F.
Off screen function
Machine in the working state, 1 minutes without operation, the screen automatically
goes out, only to keep the heating logo lit. While holding the "+" and "-" button for 2
seconds, you can turn off the screen function, once again hold the "+" and "-" button
for 2 seconds, turn off the screen function.
Temperature sensor short circuit, open circuit protection function
No matter in what mode, the temperature sensor appears short circuit protection,
digital screen display room temperature digital tube display E1 or E2 and constantly
flicker, any key operation is invalid. The buzzer ringing 10 times.
5
Safety protection
In the start state, when the room temperature TH is above 122 °F, close all outputs
system, The digital screen displays "FF" and flashes 1 times per second at a
frequency of 75 times, press any key will not work, only the power down to exit the
protection.
ECO energy saving function
Select the ECO energy saving gear, electric heater according to the ambient
temperature and the temperature setting of the machine to do comparison, select the
appropriate gear operation to achieve the purpose of saving energy.
Remote controller
Use of the remote controller: the key functions are basically the same as the body
operation panel.
6
MAIN TECHNOLOGY SPECIFICATIONS
Power supply: AC 120V ~ 60Hz
MODEL
POWER REGULATION RANGE (W)
LOW
HIGH
LOW OSC
HIGH OSC
NTH15-17BRA
900
1500
900
1500
Troubleshooting
If the product does not operate or does not operate properly, first check according to the following
list. If the reason the product does not operate or does not operate properly is not included in the
following list, the product mayhave failed. At this time, it is recommended to send the product to
the dealer for treatment.
Problem
Possible Cause
Solution
After the power is
engaged,the machine does
not work.
The plug may not be
plugged well.
Check whether the plug is
properly inserted into the
receptacle.
The machine suddenly
stops during heating.
The temperature exceeds
the threshold of the
thermal cut- off.
Unplug the heater and cool
the machine before us
CLEANING AND STORAGE
It is recommended that the heater be cleaned at least one time during the operating season in
order to provide the optimum level of performance. ALWAYS TURN THE POWER SWITCH
OFF AND UNPLUG THE HEATER BEFORE CLEANING. Be sure to save the box for off-
season storage.
Turn the heater “OFF”, unplug it and wait for the heater to cool down.
Use a dry cloth to clean only external surfaces of the heater.
Do not use any cleaning agents or detergents.
Never immerse the heater in water.
Pack the heater in the original carton and store it in a cool and dry place.
READ AND SAVE THESE INSTRUCTIONS
