ww w.PyleUSA.com
PLMR6KB - PLMR6KW
Dual 6.5'' Water Resistant Marine Speakers
2-Way Full Range Stereo Sound, Built-in Tweeters, 200 Watt
Wiring Instruction for PLMR6KB - PLMR6KW
Installation Instructions
The tweeter can be mounted in 2 dierent directions
What's in the Box:
• (2) 6.5” Component Speaker
• (2) Tweeter
• Passive Crossover
• Wiring Kit
• Mounting Hardware
IN
RED (+) WHITE (-)
RED (+) WHITE (-)
LF
RED (+) WHITE (-)
HF
(A) ANGLE MOUNT (B) FLUSH MOUNT
