Light up anytime anywhere
Product Introduction
The ANCEL 3-in-1 led work light is the latest. Not only can you display the remaining
power status in real time, but also have 4 lighting modes, with a waterproof
coefficient of up to IP44, which can be used for car maintenance, outdoor camping
and emergency charging treasures to meet your lighting needs in the wilderness
and accompany your safety.
NOTE: Please read the user manual carefully before use and installation.
ANCEL 3-in-1 led work light
SPECIFICATIONS:
Model No. SQ-129
Battery 3.7 V 4400mAh
Color Black & Red
CCT 6500K
Luminous flux 1200 LM
Dimming Two levels of 50% /100% brightness
Lighting Mode 4 Lighting Modes
Intelligent power display 4 blue light indicators
Waterproof Rate IP44
LED Quantity 2COB /2XPE
Working Time 4-15 hours (2COB- 4hours ;2XPE-15hours )
Input/output 5V-1.5A
User Manual
1* Work Light
1* USB Cable
1* User Manual
Press the power button to turn the fixture on and off, increase brightness, and change
modes. Note: When the light is on, the default 2COB lighting mode is cool white
(100% brightness), briefly press the button again to change the 2COB cool white 50%
brightness - the right single COB is on - the left single COB is on - the light off.
Operate Step Instruction:
Step 1: 2COB ON/OFF
1. Power/mode/brightness adjustment 5.hook up
2. Battery indicator 6.Type C&USB
3. Led COB 7.strong magnet
4. Led XPE 8. Tripod interface
What’s in box?
5
6
7
8
1
2
4
3
Press the switch for about 3 seconds in any lighting mode, 2XPE is on, Note:
Step 2: 2XPE ON /OFF
When the light is on, the default 2XPE lighting mode is cool white (100% brightness),
briefly press the button again to turn 2XPE SOS -off the light.
Connect the USB charging cable to the Type-C port to charge your device.
The charging power is Dc 5V/1.5A. The full charging time is 3 hours.
You can use it as a power bank. The port is USB output and the output
power is DC 5V/1.5A.
Step 4: USB Output Port
1. Strong magnetic installation, there is a strong magnet at the bottom of the lamp,
which can be magnetically attracted to the surface of metal-iron materials.
2. Carabiner installation, the screw at the bottom of the lamp can be turned clockwise
to install the carabiner, and the carabiner can be installed with a hook.
3. Tripod installation, the screw at the bottom of the lamp can be turned clockwise to
install the tripod.
Attention
1. Do not look directly at the LED light, it may hurt your eyes.
2. Please use the USB charging cable to charge the lamp before use. The input
power is DC 5V/1.5A, and it takes about 3 hours to fully charge the lamp. During
charging, the blue charging indicator will flash, and when it is fully charged, 4 blue
indicator lights will light up at the same time, indicating 100%power, 1 blue indicator
means 25% power, and the power can be judged by the number
of bright blue indicators, how many.
Step 5: Installation
Step 3: USB Charging Connection
Contact Us
3. Charge your light at least every 3 months to maintain battery status when not in
use for extended periods.
4. Do not immerse the light in water.
5. Keep away from fire and high temperatures.
6. Do not drop, knock, throw or shake the device as this may damage the
components inside.
7. Do not attempt to disassemble, modify or repair the device yourself.
If the battery becomes excessively hot, emits an odour, becomes dented, or exhibits
abnormal deformation, take it out of service immediately.
Web: www.anceltech.com
E-Mail: [email protected]
