JBL Consumer Products
250 Crossways Park Drive, Woodbury, NY 11797
8500 Balboa Boulevard, Northridge, CA 91329
800-336-4JBL (4525) (USA only)
www.jbl.com
©2001 JBL, Incorporated.
JBL is a registered trademark of JBL, Incorporated.
Part No.
ai5139
DESIGN GOAL: Bring the thrill of live performance and movie sound to
the home environment bycalling on JBL’s professional engineering leadership.
SATELLITE TYPE: Titanium-laminate-dome tweeter, sealed enclosure
SUBWOOFER TYPE:
Bass-reflex enclosure
PORT DESIGN:FreeFlow™ flared
PROFESSIONAL REFERENCE: Cinema Loudspeaker Series
OWNER’S GUIDE
PRO SOUND
COMES HOME
™
PRODUCT LINE:
Surround Cinema Speakers
MODEL
SCS150
NUMBER:
SPECIFICATIONS
All features and specifications are subject to change without notice.
* Dolby and Pro Logic are trademarks of Dolby Laboratories.
DTS is a registered trademark of Digital Theater Systems, Inc.
SCS150 System
Frequency Response
30Hz – 20kHz (–6dB)
Satellites
Recommended Power
10 – 100 watts
Impedance
8 ohms nominal
Sensitivity
88dB @ 1 watt/1 meter
Tweeter
One 1/2"titanium-laminate
dome, video-shielded
Midrange
Dual 3" drivers, video-shielded
Dimensions (H x W x D)
8-1/8" x 3-1/2" x 3-7/8"
206mm x 89mm x 99mm
Weight
2.65 lb/1.2kg
Center
Recommended Power
10 – 100 watts
Impedance
8 ohms nominal
Sensitivity
88dB @ 1 watt/1 meter
Tweeter
One 1/2"titanium-laminate
dome, video-shielded
Midrange
Dual 3" drivers, video-shielded
Dimensions (H x W x D)
3-1/2" x 8-1/8" x 3-7/8"
89mm x 206mm x 99mm
Weight
2.65 lb/1.2kg
Subwoofer
Amplifier
150 watts RMS
Woofer
10"
Enclosure
Bass reflex
Dimensions (H x W x D)
17-3/4" x 15-3/4" x 16-3/4"
451mm x 400mm x 426mm
Weight
35 lb/15.9kg
