Cinema 510
2
3
1
Mono RCA Cable (included)
Receiver or
Amplifier
SUBWOOFER
LFE OUT
SUBWOOFER
LEVEL
MIN MAX
4
FL FR CSL SR
+
-
Wire with white stripe is ‘−’ terminal
5
6
+
_
Red switch is ‘+’
Wire with white
stripe is ‘−’
AVR
Frequency response: 46Hz –20kHz
Maximum SPL: 109 dB
Power (sub): 60W
Satellites
Impedance: 8 ohms nominal
Recommended power: 10 - 100 watts
Subwoofer
Low frequency transducer: 6,5" (165mm) cone
Amplifier power: 60 watts RMS
Enclosure type: Bass Reflex
Plage de fréquences : 46 Hz –20 kHz
Pression sonore max. : 109 dB
Puissance (graves) : 60 W
Satellites
Impédance : 8 ohms nominal
Puissance recommandée : 10 - 100 watts
Caisson de graves
Transducteur basses fréquences : cône 165mm
(6.5")
Puissance de l'amplificateur : 60 watts RMS
Type d'enceinte : Bass Reflex
