Included 1” X 18” belts are listed below.
Replacement Belt Kits (WSSAKO81115) are available at select
retailers and WorkSharpTools.com.
For reference, belts are equivalent to: X65 (P220) | X22 (P1000) | X4 (P3000)
Use only as directed in Work Sharp User’s Guide.
WARNING: To minimize the risk of injury, always use proper eye
and respiratory protection. Use only as directed in Work Sharp
User’s Guide.
WARNING! CHOKING HAZARD!
Small Parts - Not for children under 3-yrs.
WARNING: This product contains a chemical known to the State
of California to cause cancer. Some dust created by power sanding
and grinding as well as contents from the machine may contain
chemicals known to the State of California to cause cancer, birth
defects or other reproductive harm.
Push lock release lever & rotate knife sharpening cassette to
remove cassette.
KNIFE & TOOL SHARPENER
BLADE GRINDING ATTACHMENT
Video Demos and Replacement Belts Available at:
WORKSHARPTOOLS.COM
Grit:
Size:
Use:
X65 Grit | Coarse
Norax 65µ
Shape
Grit:
Size:
Use:
X22 Grit | Medium
Norax 22µ
Sharpen
Grit:
Size:
Use:
X4 Grit | Fine
Norax 4µ
Hone
Grit:
Size:
Use:
12000 Grit | Extra Fine
SiC 1µ
Strop
1
Install Blade Grinding Attachment by aligning the chassis
to the keyed “on / off” position then rotate into the
“sharpening position”.
2
Install Hub Fastener onto
drive shaft.
3
Push in and turn tensioner
clockwise to install / uninstall belt.
4
Use tracking knob to center
belt on pulley.
Optional: Use a clamp to secure to work bench.
5
Power Platform
Push Tensioner in Turn Tensioner
to lock into position
Release Tensioner
once belt is in place.
Angle
Indicator
Tracking Knob
Tensioner
Assembly
Tension Assembly
Clamp Lever
Bench
Mount Tab
Bench
Mount Tabs
Bench
Mount Tab
Hub Fastener
(Left-Handed Thread)
90° Grind Plate
Short
Distance
Center
Angle Adjustment Lever
Angle Selection
Clamp Knob
Long Distance Center
Reference
Plate
Remember: Counter-clockwise to tighten, clockwise to loosen.
Blade Grinding Attachment
Mount TabsMount Tabs
