Frigidaire FPSC2277RF2 22.6 Cu. Ft. Counter-Depth User Manual

TABLE OF CONTENTS

www.frigidaire.com USA 1-800-374-4432 www.frigidaire.ca Canada 1-800-265-8352

All about the

Use & Care

of your Refrigerator

A14788802 (November 2018)

Important Safety Instructions ......................2

Features At A Glance - Baseline Model .........4

Features At A Glance - Gallery/Pro Model .....5

Installation ................................................6

Door Removal Instructions ..........................8

Handle Installation ...................................10

Connecting the Water Supply ....................11

Controls - Frigidaire Gallery ....................... 13

Controls - Frigidaire & Frigidaire Gallery .....16

Controls - Frigidaire Professional ...............17

Storage Features ...................................... 20

Automatic Ice & Water Dispenser -

Frigidaire Gallery (some models) ...............21

Automatic Ice & Water Dispenser -

Frigidaire Gallery/Pro (some models) .........24

Changing the Filter - Frigidaire Gallery .......27

Changing the Filter - Frigidaire Pro ............29

Normal Operating Sounds and Sights ......... 30

Care & Cleaning .......................................31

Before You Call ........................................35

Major Appliance Warranty .........................40

Doors

 Handles are secure and tight

 Door seals completely to cabinet on all

sides

 Freezer door is level across the top

Leveling

 Refrigerator is level, side-to-side and tilted

¼” (6mm) front-to-back

 Toe grille is properly attached to refrigerator

 Cabinet is setting solid on all corners

Electrical Power

 House power turned on

 Refrigerator plugged in

Ice Maker

 House water supply connected to refrigerator

 No water leaks present at all connections -

recheck in 24 hours

 Ice maker is turned ON

 Ice & water dispenser operates correctly

 Front lter must be ush with lter

housing (select models)

Final Checks

 Shipping material removed

 Fresh food and freezer temperatures set

 Crisper humidity controls set

 Registration card sent in

Installation Checklist

Denitions

This is the safety alert symbol. It is

used to alert you to potential personal injury

hazards. Obey all safety messages that follow

this symbol to avoid possible injury or death.

For your Safety

• DO NOT store or use gasoline, or other am-

mable liquids in the vicinity of this or any other

appliance. Read product labels for warnings

regarding ammability and other hazards.

• DO NOT operate the refrigerator in the pres-

ence of explosive fumes.

• Avoid contact with any moving parts of

automatic ice maker.

• Remove all staples from the carton. Staples

can cause severe cuts, and also destroy

nishes if they come in contact with other

appliances or furniture.

Child Safety

Destroy or recycle the carton, plastic bags, and

any exterior wrapping material immediately

after the refrigerator is unpacked. Children

should NEVER use these items to play.

Cartons covered with rugs, bedspreads, plastic

sheets or stretch wrap may become airtight

chambers, and can quickly cause suffocation.

Proper Disposal of your

Refrigerator or Freezer

Risk of child entrapment

Child entrapment and suffocation are not

problems of the past. Junked or abandoned

refrigerators or freezers are still dangerous

– even if they will sit for “just a few days”. If

DANGER

DANGER indicates an imminently hazardous

situation which, if not avoided, will result in

death or serious injury.

WARNING

WARNING indicates a potentially hazardous

situation which, if not avoided, could result

in death or serious injury.

CAUTION

CAUTION indicates a potentially hazardous

situation which, if not avoided, may result in

minor or moderate injury.

IMPORTANT

IMPORTANT indicates installation, operation

or maintenance information which is

important but not hazard-related.

WARNING

Please read all instructions before using

this refrigerator.

IMPORTANT SAFETY INSTRUCTIONS

Grounding type wall receptacle

Do not, under any

circumstances,

cut, remove, or

bypass the

grounding prong.

Power cord with

3-prong gounded plug

Electrical information

• The refrigerator must be plugged into

its own dedicated 115 Volt, 60 Hz.,

15 Amp, AC only electrical outlet. The

power cord of the appliance is equipped

with a three-prong grounding plug for your

protection against electrical shock hazards.

It must be plugged directly into a properly

grounded three prong receptacle. The

receptacle must be installed in accordance

with local codes and ordinances. Consult

a qualied electrician. Avoid connecting

IMPORTANT

Pressing and holding the On/Off button for

three seconds, located on the temperature

control panel (Electronic controls), or turn-

ing the Freezer and Fresh Food controls to

“0” (Mechanical controls) will disable your

refrigerator’s cooling system, but does not

disconnect the power to the lighting system

and other electrical components. To turn off

power to your refrigerator you must unplug

the power cord from the electrical outlet.

refrigerator to a Ground Fault Interrupter

(GFI) circuit. Do not use an extension

cord or adapter plug.

• If the power cord is damaged, it should be

replaced by an authorized service technician

to prevent any risk.

• Never unplug the refrigerator by pulling on

the power cord. Always grip the plug rmly,

and pull straight out from the receptacle to

prevent damaging the power cord.

• Unplug the refrigerator before cleaning and before

replacing a light bulb to avoid electrical shock.

• Performance may be affected if the voltage

varies by 10% or more. Operating the

refrigerator with insufcient power can

damage the compressor. Such damage is

not covered under your warranty.

• Do not plug the unit into an electrical outlet con-

trolled by a wall switch or pull cord to prevent the

refrigerator from being turned off accidentally.

you are getting rid of your old refrigerator or

freezer, please follow the instructions below to

help prevent accidents.

Proper Disposal of Refrigerators/Freezers

We strongly encourage responsible appliance

recycling/disposal methods. Check with your utility

company or visit www.energystar.gov/recycle for

more information on recycling your old refrigerator.

Before you throw away your old

refrigerator/freezer:

• Remove doors.

• Leave shelves in

place so children

may not easily

climb inside.

• Have refrigerant

removed by a

qualied service

technician.

IMPORTANT

CFC/HCFC Disposal

Your old refrigerator may have a cooling system

that used CFCs or HCFCs (chlorouorocarbons

or hydrochlorouorocarbons). CFCs and HCFCs

are believed to harm stratospheric ozone if

released to the atmosphere. Other refrigerants

may also cause harm to the environment if

released to the atmosphere.

If you are throwing away your old refrigera-

tor, make sure the refrigerant is removed for

proper disposal by a qualied technician. If

you intentionally release refrigerant, you may

be subject to nes and imprisonment under

provisions of environmental legislation.

WARNING

These guidelines must be followed to ensure

that safety mechanisms in this refrigerator

will operate properly.

CAUTION

To avoid personal injury or property

damage, handle tempered glass shelves

carefully. Shelves may break suddenly if

nicked, scratched, or exposed to sudden

temperature change.

IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT

Features not included with your refrigerator can be purchased

at www.frigidaire.com or by calling 1-800-374-4432.

FEATURES AT A GLANCE - BASELINE MODEL

Features may vary according to model

CAUTION:

Do Not Remove

Magnet Behind

Dairy

Compartment

Dairy

Compartment

Glass Shelf

Door Bin

Crisper Pan

and Cover

Fixed

Door Bin

Toe Grille

Door Bin

Ice

Container

Shelf

Water Filter

(Location varies by model)

Ice Cream Shelf

Ice Maker

Door Bins

Fixed

Door Bin

Slide Out Basket

Door Bin

Glass Shelf

Glass Shelves

LED Lights

FEATURES AT A GLANCE - GALLERY/PRO MODEL

Features may vary according to model

Shelves

Tinted

Door Bin

Slim Ice Maker

Pizza Shelf

Air Filter

Water Filter

Tinted Dairy

Compartment

Tinted

Door Bin

Shelves

Tinted Chill

Drawer

Tinted

Door Bin

Can Rack

Tinted Crisper

Pan

Tinted

Door Bin

Toe Grille

Tinted

Door Bin

Large

Glide Out

Basket

Tinted

Door Bin

Large

Basket

Tinted

Door Bin

Tinted

Door Bin

Tinted Deli

Drawer

IMPORTANT

Features not included with your refrigerator can be purchased

at www.frigidaire.com or by calling 1-800-374-4432.

INSTALLATION

This Use & Care Guide provides general

operating instructions for your model. Use the

refrigerator only as instructed in this Use &

Care Guide. Before starting the refrigera-

tor, follow these important rst steps.

Location

• Choose a place that is near a grounded

electrical outlet. Do Not use an extension

cord or an adapter plug.

• If possible, place the refrigerator out of

direct sunlight and away from the range,

dishwasher or other heat sources.

• The refrigerator must be installed on a oor

that is level and strong enough to support a

fully loaded refrigerator.

• Consider water supply availability for models

equipped with an automatic ice maker. If

you do not hook up water to the refrigerator,

remember to turn the ice maker off.

Installation

Installation clearances

Allow the following clearances for ease

of installation, proper air circulation, and

plumbing and electrical connections:

Sides & Top ⅜ inch

Back 1 inch

Toe Grille Installation and Removal

To install toe grille

1. Open both doors. Slide left and right

sides of toe grille over lower hinges of

refrigerator.

2. While pushing toe grille rmly against

cabinet, fasten bottom clips of toe grille

to cabinet.

3. Fasten top clips to cabinet.

4. Close the doors. Fasten right and left side

clips into groove of bottom hinge.

To remove toe grille

1. With both doors closed, unfasten right

and left side clips of toe grille from

bottom hinge groove.

2. Open both doors. Press rmly on top of

toe grille until top of toe grille pops off.

3. Pull toe grille outward toward your body

and off of lower hinges.

Removing Toe Grille

CAUTION

Do Not install the refrigerator where the

temperature will drop below 55°F (13°C) or

rise above 110°F (43°C). The compressor

will not be able to maintain proper tempera-

tures inside the refrigerator.

Do Not block the toe grille on the lower

front of your refrigerator. Sufcient air circu-

lation is essential for the proper operation of

your refrigerator.



NOTE

If your refrigerator is placed with the door

hinge side against a wall, you may have to

allow additional space so the door can be

opened wider.

Installing Toe Grille

INSTALLATION

Raise

Door Opening

Your refrigerator should be positioned to

allow easy access to a counter or table when

removing food. For best use of drawers and

freezer baskets, the refrigerator should be

in a position where both the refrigerator and

freezer doors can be fully opened.

Guidelines for nal positioning of

your refrigerator:

• All four corners of the cabinet must rest

rmly on the oor.

• The cabinet should be level at the front

and rear.

• The sides should tilt ¼ inch (6 mm) from

front to back (to ensure that doors close and

seal properly).

• Doors should align with each other and

be level.

All of these conditions can be met by

raising or lowering the adjustable

front rollers.

To level the cabinet using the front rollers:

1. Open both doors and remove the toe

grille (see “Toe Grille Installation

and Removal” in the “Installation”

section).

2. Close the doors and use a at-blade

screwdriver or ⅜ inch socket wrench to

raise or lower the front rollers.

3. Ensure both doors are bind-free with their

seals touching the cabinet on all 4 sides.

Set Screw

(some models)

Hinge

Hinge Flange

Open Door

7/16" Wrench and

3/32" Hex Key (some models)

Door Stop

Flange

6. Replace the toe grille by tting it into

place (see “Toe Grille Installation and

Removal” in the “Installation” section).

Raise

Door

Raise

Door

Door Door

To level the doors using the adjustable

lower hinge (some models):

1. Before leveling either door, remove set

screw that locks door height into position.

(The door cannot be adjusted without set

screw removed).

2. If the refrigerator door is lower than the

freezer door, raise the refrigerator door by

turning the adjustment screw clockwise

using a

inch wrench. (See illustration.)

3. If the freezer door is lower than the

refrigerator door, raise the freezer door by

turning the adjustment screw clockwise

using a

inch wrench. (See illustration.)

4. After leveling, verify door stop contacts

lower hinge and top of door does

not contact upper hinge through full

movement of door (from fully closed to

fully open).

5. Reinstall set screw, locking the door height.



NOTE

The refrigerator doors are designed to shut

by themselves within a 20 degree opening.

DOOR REMOVAL INSTRUCTIONS

To prepare for removing the doors:

1. Make sure the electrical power cord is

unplugged from the wall outlet.

2. Open both doors and remove the toe

grille (as explained in the Installation In-

structions that came with your appliance).

3. Remove any food from the door shelves.

4. Close the doors.

To remove the refrigerator top hinge cover:

5. Remove the 3 screws from each cover

over the top door hinges.

6. Lift hinge cover straight up and off.

To remove the refrigerator door:

1. Trace lightly around the door’s top hinge with

a pencil. This makes reinstallation easier.

Rear Cover

Screw

Front Cover

Screws

Top

Hinge

Cover

Hinge

Screws

Top

Hinge

2. Remove the 2 screws from the top hinge.

Lift the door off of the bottom hinge and

set it aside.

Phillips™

Head

Tools Necessary:

Socket

Wrench Set

Adjustable

Wrench

3/8" Fixed

Wrench

Top

Hinge

Screw

Bottom

Hinge

Screw

Top Hinge

Cover Front

Screw

Top Hinge

Cover Rear

Screw

DOOR REMOVAL INSTRUCTIONS

To remove the freezer top hinge cover:

1. Remove the 2 screws from each cover

over the top door hinges.

2. Lift hinge cover straight up and off.

Front

Cover Screws

Rear Cover

Screw

Top Hinge

Cover

Hinge

Screws

Multi-Wire

Cable

Top

Hinge

To remove the freezer door:

1. Detach the

multi-wire

cable

connector

located

above the

top hinge.

Grasp both

sides of the

connector

rmly and

pull apart.

2. Trace lightly around the hinge with a

pencil. This makes reinstallation easier.

3. Detach the water tube from the connector

located below the freezer door. The

connector releases when you press its

outer sleeve inward.

Door

Hinge

Assembly Screws

Water

Line

Tubing

Non-Adjusting Hinge (some models)

Closer

Hinge

Door

Water

Line

Tubing

Screws

Hinge

Assembly

Adjustable Hinge (some models)

4. Remove the screws from the top hinge

and pull the multi-wire cable through it.

Lift the door off of the bottom hinge.

5. Remove the 2 bottom hinge screws and

hinge if necessary.

Adjustable Hinge (some models)

Door

Hinge

Assembly

Closer

Hinge

Screws

1. Remove the 2 bottom hinge screws and

hinge if necessary.

To reinstall the refrigerator door, reverse the

above steps.

To Disconnect

1. Press outer ring against face of

fitting

2. Pull to

remove tube

Insert tube and push until mark

touches face of fitting

To Connect

6. Lay the door on its side to avoid damage to the

water tube extending from the bottom hinge.

To reinstall the freezer door, reverse the above steps.

CAUTION

Be sure doors are set aside in a secure position

where they cannot fall and cause personal injury.

HANDLE INSTALLATION

Freezer Upper

End Cap

Refrigerator Upper

End Cap

Frigidaire Gallery

Refrigerator Lower

End Cap

Freezer Lower

End Cap

Freezer Upper

End Cap

Refrigerator Lower

End Cap

Refrigerator Upper

End Cap

Freezer Lower

End Cap

Frigidaire Professional

1. Remove handles from protective

packaging.

2. Position freezer handle end caps

over upper and lower pre-installed

shoulder bolts (A) that are fastened

into door, ensuring the holes for

the set screws are facing towards

the refrigerator door.

3. While holding handle rmly against

door, fasten furthermost upper and

furthermost lower Allen set screws

(B) with supplied Allen wrench.

4. Firmly tighten the inside Allen

set screws.

5. Repeat steps 2 through 4 to install

refrigerator handle. Ensure the

holes for the set screws are facing

towards the freezer door.

CAUTION

Wear gloves and safety goggles and

use extreme CAUTION when installing

these handles. The rounded end of the

handles may be sharp (some models).

IMPORTANT

To ensure proper installation of

handles, please review these instruc-

tions and illustrations thoroughly prior

to installing the handles.

Ensure Handle Set Screws

are Facing Each Other

with Doors Closed



NOTE

All set screws should be tightened and

sub-ush (Allen set screw should be

seated just below the surface of the

end cap) of handle end cap. The end

caps should be drawn tight to freezer

and refrigerator doors with no gaps.

CONNECTING THE WATER SUPPLY

Before Installing The Water Supply Line,

You Will Need:

• Basic Tools: adjustable wrench, at-blade

screwdriver, and Phillips

screwdriver

• Access to a household cold water line with

water pressure between 30 and 100 psi.

• A water supply line made of ¼ inch

(6.4 mm) OD, copper or stainless steel

tubing. To determine the length of tubing

needed, measure the distance from the

ice maker inlet valve at the back of the

refrigerator to your cold water pipe. Then

add approximately 7 feet (2.1 meters),

so the refrigerator can be moved out for

cleaning (as shown).

• A shutoff valve to connect the water supply

line to your household water system. Do not

use a self-piercing type shutoff valve.

• Do not reuse compression tting or use

thread seal tape.

To Connect Water Supply Line To Ice

Maker Inlet Valve

1. Disconnect refrigerator from electric

power source.

2. Place end of water supply line into sink or

bucket. Turn ON water supply and ush

supply line until water is clear. Turn OFF

water supply at shutoff valve.

3. Remove plastic cap from water valve inlet

and discard cap.

4. If you use copper tubing - Slide brass

compression nut, then ferrule (sleeve)

onto water supply line. Push water supply

line into water valve inlet as far as it

will go (¼ inch/6.4 mm). Slide ferrule

(sleeve) into valve inlet and nger tighten

compression nut onto valve. Tighten

another half turn with a wrench; DO NOT

overtighten. See Figure 1.

If you use braided exible stainless

steel or polyline tubing - The nut is

already assembled on the tubing. Slide

nut onto valve inlet and nger tighten

nut onto valve. Tighten another half turn

with a wrench; DO NOT overtighten. See

Figure 2.

• A compression nut and ferrule (sleeve) for

connecting a copper water supply line to the

ice maker inlet valve.

WARNING

To avoid electric shock, which can cause death

or severe personal injury, disconnect the

refrigerator from electrical power before con-

necting a water supply line to the refrigerator.

CAUTION

To Avoid Property Damage:

• Copper or Stainless Steel braided tubing

is recommended for the water supply line.

Water supply tubing made of ¼ inch plastic

is not recommended to be used. Plastic tub-

ing greatly increases the potential for water

leaks, and the manufacturer will not be

responsible for any damage if plastic tubing

is used for the supply line.

• DO NOT install water supply tubing in areas

where temperatures fall below freezing.

• Chemicals from a malfunctioning softener

can damage the ice maker. If the ice maker

is connected to soft water, ensure that the

softener is maintained and working properly.

IMPORTANT

Ensure that your water supply line connec-

tions comply with all local plumbing codes.



NOTE

Check with your local building authority

for recommendations on water lines and

associated materials prior to installing your

new refrigerator. Depending on your local/

state building codes, Frigidaire recom-

mends for homes with existing valves its

Smart Choice

water line kit 5304490728

(with a 6 ft. Stainless Steel Water Line) or

5304493869 (with a 6 ft. Polyline Water

Line) and for homes without an existing

valve, Frigidaire recommends its Smart

Choice

water line kit 5304490717 (with

a 20 ft. copper water line with self-tapping

saddle valve). Please refer to www.frigid-

aire.com/store for more information.

IMPORTANT

After connecting the water supply, refer to

“How to Prime the Water Supply System”

for important information about priming an

empty water supply system.

To ensure that your water dispenser works

properly, the water supply system must be

completely lled with water when your re-

frigerator is rst connected to the household

water supply line.

Figure 1

Plastic Water

Tubing to Ice

Maker Fill

Tube

Steel

Clamp

Brass

Compression

Nut

Ferrule

(Sleeve)

Copper

water line

Water Valve

Bracket

Valve Inlet

Water Valve

Copper water line

from household

water supply

(Include enough tubing in loop to allow

moving refrigerator out for cleaning.)

CONNECTING THE WATER SUPPLY

Figure 2

Steel

Clamp

Water Line

Water Valve

Bracket

Valve Inlet

Water Valve

Water line

from household water supply

Plastic Water Tubing

to Ice Maker

Fill Tube

(Include enough tubing in loop to allow

moving refrigerator out for cleaning.)

5. With steel clamp and screw, secure water

supply line (copper tubing only) to rear

panel of refrigerator as shown.

6. Coil excess water supply line (copper

tubing only), about 2½ turns, behind

refrigerator as shown and arrange coils so

they do not vibrate or wear against any

other surface.

7. Turn ON water supply at shutoff valve and

tighten any connections that leak.

8. Reconnect refrigerator to electrical

power source.

9. To turn ice maker on, lower wire signal

arm (side mounted) or set the ice maker’s

On/Off power switch to the “I” position

(rear mounted).mounted).

CONTROLS - FRIGIDAIRE GALLERY

User Interface (varies by model)



NOTE

The recommended settings for a product installed in a kitchen is 37ºF for the fresh food

copartment and 0ºF for the freezer.

Operating the Controls

Press Options key

Use Arrow keys ^/ᴠ to scroll the menu selections

Use the + or - keys to change the option from on/off/change temperature or mode ºF/ºC

Use the Options key to exit and save changes

Quick Freeze

On Off

Activates a faster rate for freezing food. Deactivates after 12 hours.

Ice Maker

On Off

Press and hold for three seconds to toggle the ice maker in the freezer

compartment “on” and “off”.

Display

On Off

Toggles the temperature displays On and Off.

Refrigeration Temp Allows the temperature set points to be adjusted. Control tempera-

tures range from +33°F / +1°C to +47°F / +8°C.

Freezer Temp Allows the temperature set-points to be adjusted. Control temperatures

range from -6°F / -21°C to +6°F / -15°C.

Mode °F °C Toggles display from Fahrenheit to Celsius.

User Interface (varies by model)

Operating the Controls

Press Options key

Use Arrow keys ^/ᴠ to scroll the menu selections

Press and hold Set key for 3 seconds

Use the Options key to exit and save changes

power off Press and hold Set for 3 seconds to turn off the cooling system. It

also turns off the ice maker and all dispenser functions. The display

will read power off. Press and hold Set to turn power on.

water lter Displays the current status of the water lter (Good, Order, or

Replace). To reset the lter status to Good, press and hold the Set

key for 3 seconds.

air lter Displays the current status of the air lter (Good,

Order, or Replace). To reset the lter status to Good, press and

hold the Set key for 3 seconds.

default settings While in the default option, press and hold the Set key for 3 seconds

to reset all refrigerator settings to their factory default settings.

CONTROLS - FRIGIDAIRE GALLERY

User Interface (varies by model)

Operating the Controls

To activate features press the corresponding icon key on the display

water Press the Water key to select water. Indicator light will be illuminated

above the active feature.

cube Press the Cube key to select cubed ice. Indicator light will be illumi-

nated above the active feature.

crush Press the Crush key to select crushed ice. Indicator light will be

illuminated above the active feature.

control

locked

Press and hold for 3 seconds to lock the display. While in the locked

state, you will not be able to change any settings on the display nor

dispense ice and water. The Control Locked indicator will ash and

illuminate and an audible warning tone will sound. Press and hold a

second time to unlock the display.

light Toggles dispenser light On and Off.

Alarms Sabbath Mode

The Sabbath Mode is a feature that disables

portions of the refrigerator and its controls

in accordance with observance of the weekly

Sabbath and religious holidays within the

Orthodox Jewish community.

Sabbath Mode is turned ON and OFF by

pressing and holding both the “∨” and “+” for

ve seconds. The display shows “Sb” while in

Sabbath mode.

In the Sabbath Mode, the High Temp alarm

is active for health reasons. For example,

if the door is left ajar the High Temp alarm

is activated. The refrigerator will function

normally once the door is closed, without

any violation of the Sabbath/Holidays. The

High Temp alarm is permitted when cabinet

temperature is outside the safe zone for 20

minutes. The alarm silences itself after 10

minutes while the High Temp icon stays lit until

the Sabbath mode is exited.

For further assistance, guidelines for proper

usage and a complete list of models

with the Sabbath feature, please visit

the web at http:\\www.star-k.org.

Power

Failure

In the event of a power failure,

the power fail alert will be

illuminated. Press alarm reset to

acknowledge the alarm. Other

modes may be turned off until

the alarm is acknowledged.

When the power fail alert is

acknowledged, the refrigerator

will resume normal operation.

The high temp alarm may

also be illuminated until a safe

operating range temperature

has been reached.

Freezer

Temp

If the freezer temperature

reaches 26°F or greater, the

alarm will sound and the

temperature will ash. You can

disable the alarm by pressing

the set key but the “High Temp”

indicator will illuminate until the

temperature goes below 26°F.

Fresh Food

Temp

If the fresh food temperature

reaches 55°F or greater, the

alarm will sound and the

temperature will ash. You can

disable the alarm by pressing

the set key but the “High Temp”

indicator will illuminate until the

temperature goes below 55°F.

Door Ajar If the freezer or fresh food

doors have been left open for

ve minutes or more, an alarm

will sound and the door ajar

indicator will illuminate on the

display. Press the set key to

reset any system alarms.

Flapper When “Cube” or “Crush” is

selected, if the apper (or ice

chute door) is being held open by

a jammed ice cube, an alarm will

sound for two minutes. The alarm

will reset after 2 minutes or when

the ice cube is removed and the

set key is pressed to reset.

CONTROLS - FRIGIDAIRE & FRIGIDAIRE GALLERY



NOTE

While in Sabbath Mode, neither the lights,

dispenser, nor the control panel will work until

Sabbath Mode is deactivated.

Refrigerator stays in Sabbath Mode after

power failure recovery. It must be deactivated

with the buttons on the control panel.



NOTE

Although you have entered the Sabbath

Mode, the ice maker will complete the cycle

it had already initiated. The ice cube com-

partment will remain cold and new ice cubes

can be made with standard trays.

User Interface In-Door Controls

(options may vary)

CONTROLS - FRIGIDAIRE PROFESSIONAL

POWER

ON-OFF

Press and hold for 3 seconds to turn

off the cooling system. It also turns

off the ice maker and all dispenser

functions. The display will read “OFF”.

DEFAULT

SETTINGS

Press and hold for 3 seconds to

reset all refrigerator settings to their

factory default settings.

ICE MAKER

ON-OFF

Press and hold for 3 seconds to

toggle the ice maker in the freezer

compartment “ON” or “OFF”.

POWERPLUS

FREEZE

Activates a faster rate for freezing food

and increases ice production in the

freezer. Deactivates after 12 hours.

AIR FILTER Displays the current status of the air

lter (GOOD, ORDER, or REPLACE).

To reset the lter status to “GOOD”,

press and hold for 3 seconds.

WATER FILTER Displays the current status of the water

lter (GOOD, ORDER, or REPLACE). To

reset the lter status to “GOOD”, press

and hold for 3 seconds.

REFRIGERATOR

TEMP

Allows the temperature set-

points to be adjusted. Press the

“-” or “+” indicator to adjust the

temperature to the desired setting.

Control temperatures range from

+33°F / +1°C to +43°F / +6°C.

FREEZER TEMP Allows the temperature set-

points to be adjusted. Press the

“-” or “+” indicator to adjust the

temperature to the desired setting.

Control temperatures range from

-6°F / -21°C to +4°F / -16°C.

Alarms

Power Failure

In the event of a power failure, the “POWER

FAIL” alert will be illuminated. Press “MUTE

ALARM” to acknowledge the alarm. Other modes

may be turned off until the alarm is acknowl-

edged. While a “POWER FAIL” alert is displayed

on the control panel, the unit will continue

normal operation. The “POWER FAIL” alert on

the control panel will be removed once the user

acknowledges the power fail condition by press-

ing “MUTE ALARM” or “DEFAULT SETTINGS”.

Freezer Temp

If the freezer temperature reaches 26°F

or greater, the alarm will sound and the

temperature will ash and the dispenser

control will display “HIGH TEMP DETECTED”.

You can disable the alarm by pressing “MUTE

ALARM” but the “HIGH TEMP DETECTED”

indicator will illuminate until the temperature

goes below 26°F.

Fresh Food Temp

If the fresh food temperature reaches 55°F

or greater, the alarm will sound and the

temperature will ash and the dispenser

control will display “HIGH TEMP DETECTED”.

You can disable the alarm by pressing “MUTE

ALARM” but the “HIGH TEMP DETECTED”

indicator will illuminate until the temperature

goes below 55°F.

Door Ajar

If the freezer or fresh food doors have been

left open for ve minutes or more, an alarm

will sound and the door ajar indicator will

illuminate on the display. Press “MUTE ALARM”

to reset any system alarms.

Flapper

When “CUBES” or “CRUSHED” is selected,

if the apper (or ice chute door) is being

held open by a jammed ice cube, an alarm

will sound for two minutes and the current

selection will blink on the dispenser control.

The alarm will reset after two minutes or when

the ice cube is removed.

Dispenser Controls

(options may vary)

WATER Press the “WATER” key to

select water.

CUBES Press the “CUBES” key to

select cubed ice.

CRUSHED Press the “CRUSHED” key to

select crushed ice.

light Toggles dispenser light on

and off.

CONTROLS - FRIGIDAIRE PROFESSIONAL

Sabbath Mode

The Sabbath Mode is a feature that disables

portions of the refrigerator and its controls

in accordance with observance of the weekly

Sabbath and religious holidays within the

Orthodox Jewish community.

Sabbath Mode is turned ON and OFF by

simultaneously pressing and holding both

the freezer “-” and the refrigerator “+” for

ve seconds. The display shows “Sb” while in

Sabbath mode.

In the Sabbath Mode, the “HIGH TEMP” alarm

is active for health reasons. For example, if

the door is left ajar the “HIGH TEMP” alarm

is activated. The refrigerator will function

normally once the door is closed, without

any violation of the Sabbath/Holidays. The

“HIGH TEMP” alarm is permitted when cabinet

temperature is outside the safe zone for 20

minutes. The alarm silences itself after 10

minutes while the “HIGH TEMP” icon stays lit

until the Sabbath mode is exited.

For further assistance, guidelines for

proper usage and a complete list of

models with the Sabbath feature,

please visit the web at

http:\\www.star-k.org.

CONTROLS - FRIGIDAIRE PROFESSIONAL



NOTE

While in Sabbath Mode, neither the lights,

dispenser, nor the control panel will work until

Sabbath Mode is deactivated.

Refrigerator stays in Sabbath Mode after

power failure recovery. It must be deactivated

with the buttons on the control panel.



NOTE

Although you have entered the Sabbath

Mode, the ice maker will complete the cycle

it had already initiated. The ice cube com-

partment will remain cold and new ice cubes

can be made with standard trays.

CAUTION

To avoid personal injury or property damage,

handle tempered glass shelves carefully.

Shelves may break suddenly if nicked,

scratched, or exposed to sudden temperature

change. Allow the glass shelves to stabilize

to room temperature before cleaning. Do not

wash in dishwasher.



NOTE

Leafy vegetables keep best when stored with

the humidity control set on Higher Humidi-

ty, or in a drawer without a Humidity Control.

This keeps incoming air to a minimum and

maintains maximum moisture content.

STORAGE FEATURES

Door storage

Door bins and shelves are provided for

convenient storage of jars, bottles, and cans.

Frequently used items can be quickly selected.

Some models have door bins that can

accommodate gallon-sized plastic drink

containers and economy-sized jars and

containers. Some bins are adjustable for

maximum storage capacity.

The dairy compartment, which is warmer than

the general food storage section, is intended for

short term storage of cheese, spreads, or butter.

Crisper Humidity Control

Higher Humidity Lower Humidity

Crisper Drawer

Crispers

Crispers allow you

the exibility to store

any manner of items

including fruits,

vegetables, nuts, etc.

Crispers do not feature

humidity controls.

Fresh Drawers with Humidity

Control (some models)

The fresh drawers, located under the bottom

refrigerator shelf, are designed for storing

fruits, vegetables, and other fresh produce.

The fresh drawers feature humidity control

which allows you to adjust the humidity within

the drawer. This can extend the life of fresh

vegetables that keep best in high humidity.

Wash items in clear water and remove excess

water before placing them in the crispers.

Items with strong odors or high moisture

content should be wrapped before storing.

Cool Drawer (some models)

Some models are equipped with a Cool Drawer

for storage of luncheon meats, spreads,

cheeses, and other deli items. This drawer

does not have a separate temperature control.

Chill Drawer (some models)

Some models are equipped with a Chill Drawer.

Chill Drawer temperatures can be adjusted by

sliding the Chill Drawer Temperature Control

in either direction. Use this pan for short term

storage of bulk meat

items. If meats are to

be kept longer than

one or two days, they

should be frozen. The

Chill Drawer is xed and

cannot be moved up or

down. If fruits or veg-

etables are to be stored

in the Chill Drawer,

set the Chill Drawer

Temperature Control

to a warmer setting to

prevent freezing.

Colder

Warmer

Chill Drawer

with Temperature

Control

Cantilever Glass Shelf

Cantilever Shelf Adjustment

Refrigerator

shelves are easily

adjusted to suit

individual needs.

Before adjusting

the shelves,

remove all food.

Cantilever shelves

are supported at

the back of the

refrigerator.

To adjust cantilever shelves:

1. 1Lift front edge up.

2. 2Pull shelf out.

Replace the shelf by inserting the hooks at rear

of the shelf into the wall bracket. Lower the shelf

into the desired slots and lock into position.



NOTE

The water dispenser has a built-in device that

shuts off the water ow after three minutes

of continuous use. To reset this shutoff de-

vice, simply release the dispenser paddle.



NOTE

Dispensed water is not chilled. For colder

water, add ice to cup or container before

dispensing water.

AUTOMATIC ICE & WATER DISPENSER -

FRIGIDAIRE GALLERY (SOME MODELS)

Priming the Water Supply

System

Your refrigerator’s water supply system

includes several tubing lines, an advanced

water lter, and a distribution valve bank to

ensure ample supply to the ice and water

dispenser at all times. This system needs to

be completely lled with water when rst

connected to an external supply line.

To prime the water supply system:

1. Begin lling the system by pressing and

holding a drinking glass against the water

dispenser paddle.

2. Keep the glass in this position until water

comes out of the dispenser. It may take

about 1½ minutes.

3. Continue dispensing water for about four

minutes to ush the system and plumbing

connections of any impurities (stopping to

empty the glass as necessary).

Ice Maker Operation & Care

The ice maker, ice bin, and dispenser feeding

mechanism are located in the top of the

freezer compartment. After the refrigerator is

installed properly and has cooled for several

hours, the ice maker can produce ice within

24 hours. It can completely ll an ice bin in

about two days.

Ice Production: What to Expect

How much ice will a side-mounted ice

maker produce in 24 hours?

A side mounted ice maker will produce 4 to

4.5 pounds of ice every 24 hours, depending

on usage conditions. Ice is produced at a rate

of 8 cubes every 75 to 90 minutes.

How much ice can be stored in the bin?

When completely full, the bin in standard

depth units will hold about 9.5 pounds of ice.

The bin in counter depth units will hold about

5.5 pounds of ice.

Using the Ice Maker after Installation

Before making ice for the rst time, be sure

to prime the water supply system. Air in new

plumbing lines can result in two or three empty

ice maker cycles. Furthermore, if the system

is not ushed, the rst ice cubes may be

discolored or have an odd avor.

CAUTION

For proper dispenser operation, recom-

mended water supply pressure should fall

between 30 psi and 100 psi. Excessive pres-

sure may cause water lter to malfunction.

IMPORTANT

Your ice maker is shipped from the factory

with the wire signal arm in the ON position.

To ensure proper function of your ice maker,

hook up water supply immediately or turn

ice maker OFF by lifting the wire signal arm

until it clicks and locks in the UP position.

If the ice maker is not turned off and

the water supply is not connected, the

water valve will make a loud chatter-

ing noise.

Turning the SIDE MOUNTED Ice

Maker On and Off

To begin ice production, lower the wire signal

arm to the DOWN or ON position. The ice

maker turns off automatically when the ice

container becomes full. To stop the ice maker,

raise the wire signal arm until it clicks and

locks in the UP or OFF position.

AUTOMATIC ICE & WATER DISPENSER -

FRIGIDAIRE GALLERY (SOME MODELS)

IMPORTANT

Small ice cubes or ice chips jamming in the

ice maker may be a sign that your water

lter needs changing. If you have a side

mounted ice maker you may also experi-

ence hollow cubes partially frozen cubes

with water inside. When these cubes are

harvested, they break open and spill water

over the other ice cubes in the ice container,

forming a solid mass of ice. As the water

lter nears the end of its useful life and be-

comes clogged with particles, less water is

delivered to the ice maker during each cycle.

The ice maker can’t ll every cube in the ice

maker mold, leading to small cubes or chips

that can get caught between the ice ejector

blades and the stripper. Remember, if your

ice maker is jamming with small ice cubes or

it’s been six months or longer since you last

changed your water lter replace the water

lter with a new one. Poor quality household

water may require the lter to be changed

more frequently.

Ice Maker/Dispenser Tips

• Ice cubes stored too long may develop

an odd avor. Empty the ice container as

explained below.

• Occasionally shake the ice container to keep

ice separated.

• If your refrigerator is not connected to a

water supply or the water supply is turned

off, turn Off the ice maker.

• If you need a large quantity of ice at one

time, it is best to get cubes directly from the

ice container.

• The following sounds are normal when the

ice maker is operating:

- Motor running

- Ice dropping into ice container

- Water valve opening or closing

- Ice loosening from tray

- Running water

• When dispensing ice, you will hear a

snapping or clicking sound when the ice

chute opens and closes.

• To avoid splashing, dispense ice into your

container before adding liquids.

• It is normal for ice to ll to the top of the

ice bin.

• Turn Off the ice maker when cleaning the

freezer and during vacations.

- If you turn Off the ice maker for a

long period of time, you should also

turn off the water supply valve.

CAUTION

Chemicals from a malfunctioning water soft-

ener can damage the ice maker. If the water

supply to your refrigerator is softened, be sure

the softener is maintained to work properly.

OFF

Wire

Signal Arm

Cleaning the Ice Maker

Clean the ice maker and ice bin at regular

intervals, particularly before you take a

vacation or move.

To clean the ice maker:

1. Turn Off the ice maker.

2. Remove the ice bin by lifting up and out.

3. Empty and carefully clean the ice bin with

mild detergent. Rinse with clear water. Do

not use harsh or abrasive cleaners.

4. Allow the ice bin to dry completely before

replacing in the freezer.

5. Remove ice chips and clean the ice bin

shelf and the freezer door chute.

6. Replace the ice bin. Turn On the ice

maker to resume ice production.

Remove and empty the ice storage bin if:

• An extended power failure (one hour or

longer) causes ice cubes in the ice storage

bin to melt and freeze together, jamming the

dispenser mechanism.

• You do not use the ice dispenser frequently.

Ice cubes will freeze together in the bin,

jamming the dispenser mechanism.

Remove the ice storage bin and shake to

loosen the cubes or clean as explained above.

AUTOMATIC ICE & WATER DISPENSER -

FRIGIDAIRE GALLERY (SOME MODELS)

CAUTION

NEVER use an ice pick or similar sharp instru-

ment to break up the ice. This could damage

the ice storage bin and dispenser mechanism.

IMPORTANT

When removing or replacing the ice bin,

ensure that the ice bin is fully seated before

closing the freezer door. If the ice bin is not

positioned correctly the refrigerator will not

dispense ice. The freezer door also may not

close properly causing warm air to leak into

the freezer compartment.



NOTE

The water dispenser has a built-in device that

shuts off the water ow after three minutes

of continuous use. To reset this shutoff de-

vice, simply release the dispenser paddle.



NOTE

Dispensed water is not chilled. For colder

water, add ice to cup or container before

dispensing water.



NOTE

The ice maker also has a built-in plastic

signal arm that automatically stops ice pro-

duction when the ice bin is full. This signal

arm should not be used to manually stop

the ice maker.

IMPORTANT

Turning off the ice maker simply disables

ice making. You will still be able to dispense

existing ice, and you will still be able to

dispense water.

AUTOMATIC ICE & WATER DISPENSER -

FRIGIDAIRE GALLERY/PRO (SOME MODELS)

CAUTION

For proper dispenser operation, recom-

mended water supply pressure should fall

between 30 psi and 100 psi. Excessive pres-

sure may cause the system to malfunction.

Priming the water supply system

Ice maker operation & care

After the refrigerator is installed properly and

has cooled for several hours, the ice maker can

produce ice within 24 hours. The ice maker will

ll the ice bin from the rear. You must dispense

some ice to force the ice forward in the bin.

This will allow the bin to ll completely.

Ice Maker and Storage Bin

Capacity

This ice maker should produce 2.5 to 3 pounds

of ice per 24 hours, depending on usage

conditions. Ice is produced at a rate of 10

cubes every 75 to 90 minutes.

How much ice can be stored in

the ice bin?

When completely full, the bin in standard

depth units will hold about 11 pounds of ice

(total weight of ice and bin will be about 15

pounds). The bin in counter depth units will

hold about 8.5 pounds of ice (total weight of

ice and bin will be about 12 pounds).

Turning the ice maker on and off

Ice production is controlled by the ice maker’s

On/Off feature on the control panel. Pressing

and holding the On/Off button toggles the ice

maker On/Off.

1. Begin lling the system by pressing and

holding a drinking glass against the water

dispenser

paddle.

2. Keep the

glass

in this

position

until

water

comes

out of the

dispenser.

It may

take

about 1½

minutes.

3. Continue

dispensing water for about four minutes

to ush the system and plumbing

connections of any impurities (stopping to

empty the glass as necessary).

Dispenser

(varies by model)

Ice maker/dispenser tips

• If your refrigerator is not connected to a

water supply or the water supply is turned

off, turn off the ice maker as described in

the previous section.

• The following sounds are normal when

the ice maker is operating:

- Motor running

- Ice dropping into ice bin

- Water valve opening or closing

- Running water

• When dispensing ice, you will hear a

snapping or clicking sound when the ice

chute opens and closes.

• If you need a large quantity of ice at one

time, it is best to get cubes directly from

the ice bin.

• Ice cubes stored too long may develop an

odd avor. Empty the ice bin as explained

below.

• When dispensing cubed ice, it is normal

to have a small quantity of little pieces

along with the whole cubes.

• To avoid splashing, dispense ice into your

container before adding liquids.

• It is normal for ice to ll to the top of the

ice bin.

IMPORTANT

Your ice maker is turned on at the factory

so it can work as soon as you install your

refrigerator. If you cannot connect a water

supply, set the ice maker’s On/Off feature

to Off; otherwise, the ice maker’s ll valve

may make a loud chattering noise when it

attempts to operate without water.

IMPORTANT

On occasion, unusually small ice cubes may

be noticed in the bucket or in dispensed ice.

This could occur in normal operation of the

ice maker. If you start seeing these more

frequently, it may be an indication of low

water pressure or the water lter needs to

be replaced. As the water lter nears the

end of its useful life and becomes clogged

with particles, less water is delivered to the

ice maker during each cycle. Remember, if

it’s been six months or longer since you last

changed your water lter, replace the water

lter with a new one. Poor quality household

water may require the lter to be changed

more frequently.

Using the ice maker after

installation

Before making ice for the rst time, be sure

to prime the water supply system. Air in new

plumbing lines can result in two or three empty

ice maker cycles. Furthermore, if the system

is not ushed, the rst ice cubes may be

discolored or have an odd avor.

AUTOMATIC ICE & WATER DISPENSER -

FRIGIDAIRE GALLERY/PRO (SOME MODELS)

CAUTION

If the water supply to your refrigerator is

softened, be sure the softener is properly

maintained. Chemicals from a water softener

can damage the ice maker.

AUTOMATIC ICE & WATER DISPENSER -

FRIGIDAIRE GALLERY/PRO (SOME MODELS)

Cleaning the storage bin

Clean the ice

maker and ice

bin at regular

intervals, espe-

cially prior to

vacation

or moving.

1. Turn off

the ice

maker.

2. Remove

the ice bin

by lifting

up slightly on the front of the bin and pull-

ing it straight out of the ice maker housing.

Removing Ice Bin

3. Empty and carefully clean the ice bin

with mild detergent. Do not use harsh or

abrasive cleaners. Rinse with clear water.

4. Allow the ice bin to dry completely before

replacing in the freezer.

5. Remove ice chips and clean the ice bin

shelf and the freezer door chute.

6. Replace the ice bin. Turn the ice maker on

to resume ice production.

Remove and empty the ice bin if:

• An extended power failure (1 hour or longer)

causes ice cubes in the ice bin to melt and

refreeze together after power is restored,

jamming the dispenser mechanism.

• You do not use the ice dispenser

frequently. Ice cubes will freeze together

in the bin, jamming the dispenser

mechanism.

Remove the ice bin and shake to loosen the

cubes or clean as explained above.

CAUTION

Be sure to rmly support the underside

of the ice bin when removing it from the

refrigerator. A standard depth bin that is full

of ice will weigh about 15 pounds total, and

a counter depth bin that is full of ice will

weigh about 12 pounds total.

CAUTION

NEVER use an ice pick or similar sharp instru-

ment to break up the ice. This could damage

the ice bin and dispenser mechanism.

To loosen stuck ice, use warm water.

Before replacing the ice bin, make sure it is

completely dry.

IMPORTANT

When removing or replacing the ice bin,

ensure that the ice bin is fully seated before

closing the freezer door. If the ice bin is not

positioned correctly the refrigerator will not

dispense ice. The freezer door also may not

close properly causing warm air to leak into

the freezer compartment.

CHANGING THE FILTER - FRIGIDAIRE GALLERY

Air Filter (some models)

The air lter is located at the top of the fresh

food compartment next to the water lter.

Replacing the Air Filter

In general, you should change the air lter

every six months (the lter status light on

the control panel prompts you to replace

the lter after six months) to ensure optimal

ltering of refrigerator odors. You may want

to adjust this time period depending on the

types and amounts of food you typically

store in your refrigerator. To replace your

PureSource Ultra

air lter:

1. Pull the air lter housing straight out.

2. Remove the old lter and discard it.

3. Unpack the new lter and place it inside

the housing.

4. Slide the housing back into position.

Air Filter

Locating the Filter

Your refrigerator is equipped with a water

ltering system. The water lter system lters

all dispensed drinking water, as well as the

water used to produce ice.

Ordering Replacement Filters

To order your replacement lters, please visit

our online store at www.frigidaire.com/store,

by calling toll-free at 1-800-374-4432, or by

visiting the dealer where you purchased your

refrigerator. Frigidaire recommends that you

order extra lters when you rst install your

refrigerator, and that you replace your lters at

least once every six months.

Here are the product numbers to request

when ordering:

PureSource Ultra

Water Filter

Part# ULTRAWF

Water Filter

The water lter is located at the top right side

of the fresh food compartment.

Replacing the Water Filter

In general, you should change the water lter

every 6 months to ensure the highest possible

water quality. Water Filter Status on the user

interface prompts you to replace the lter

after a standard amount of water (200 gal-

lons/757 liters for PureSource Ultra

) has

owed through the system.

If your refrigerator has not been used for a peri-

od of time (during moving for example), change

the lter before reinstalling the refrigerator.

Filter Cartridge

Do not use with water that is microbiologically

unsafe or of unknown quality without adequate

disinfection before or after the system.

Systems certied for cyst reduction may be

used on disinfected waters that may contain

lterable cysts.

Test & certication results:

• Rated Capacity - 200 gallons/757 liters for

PureSource Ultra

ice and water lter

• Rated service ow - .50 gallons per minute

• Operating Temp.: Min. 33°F, Max. 100°F

• Maximum Rated Pressure - 100 pounds per

square inch

• Recommended Minimum Operating

Pressure: 30 pounds per square inch

To replace your water lter:

It is not necessary to turn the water supply off

to change the lter. Be ready to wipe up any

small amounts of water released during the

lter replacement.

1. Turn Off the ice maker.

2. Remove the lter by pushing on the end/

face of the lter.

3. Slide the old water lter cartridge straight

out of the housing and discard it.

4. Unpackage the new lter cartridge. Using

the alignment guide, slide it gently into the

lter housing until it stops against the snap-

in connector at the back of the housing.

5. Push rmly until the cartridge snaps into

place (you should hear a click as the

cartridge engages the snap-in connector).

6. Press a drinking glass against the water

dispenser while checking for any leaks at

the lter housing. Any spurts and sputters

that occur as the system purges air out of

the dispenser system are normal.

More about your Advanced

Water Filter

The PureSource Ultra

ice and

water lter system is tested and

certied to NSF/ANSI Standards

42, 53 and 401 for the reduction

of claims specied on the perfor-

mance data sheet.

7. After lling 1 glass of water, continue

ushing the system for about 4 minutes.

8. Turn On the ice maker.

9. Press and hold the Water Filter button on

the Ice & Water Dispenser control panel

for 3 seconds. When the display changes

from “Red” to “Green,” the status has

been reset.

CHANGING THE FILTER - FRIGIDAIRE GALLERY



NOTE

When ordering your replacement lter,

please reorder the same lter type that is

currently in your refrigerator.

Locating the Filters

Your refrigerator is equipped with water ltering

system. The water lter system lters all dis-

pensed drinking water, as well as the water used

to produce ice. The lter is located in the top

right rear corner of the fresh food compartment.

Water Filter

The water lter is located at the top right side

of the fresh food compartment.

Ordering Replacement Filters

To order your replacement lters, please visit

our online store at www.frigidaire.com/store,

by calling toll-free at 1-800-599-7569, or by

visiting the dealer where you purchased your

refrigerator. Frigidaire recommends that you

order extra lters when you rst install your

refrigerator, and that you replace your lters at

least once every 6 months.

Here is the product number to request

when ordering:

PureSource Ultra II

Water Filter

Part #EPTWFU01

Replacing the Water Filter

In general, you should change the water lter

every 6 months to ensure the highest possible

water quality. Water Filter Status on the

user interface prompts you to replace the

lter after a standard amount of water (125

gallons/473 liters for PureSource Ultra II

)

has owed through the system.

If your refrigerator has not been used for a period

of time (during moving for example), change the

lter before reinstalling the refrigerator.

Do not use with water that is microbiologically

unsafe or of unknown quality without adequate

disinfection before or after the system. Systems

certied for cyst reduction may be used on dis-

infected waters that may contain lterable cysts.

Test & certication results:

• Rated Capacity - 125 gallons/473 liters for

PureSource Ultra II

ice and water lter

• Rated service ow - .65 gallons per minute

• Operating Temp: Min. 33°F, Max. 100°F

• Maximum Rated Pressure - 100 pounds

per square inch

• Recommended Minimum Operating

Pressure: 30 pounds per square inch

To replace your PureSource Ultra II

water lter:

It is not necessary to turn the water supply off

to change the lter. Be ready to wipe up any

small amounts of water released during the

lter replacement.

1. Turn Off the ice maker power switch.

2. Remove the old lter by rotating it counter-

clockwise (to the left) 90 degrees to release it.

3. Slide the old lter cartridge straight out of

the housing and discard it.

4. Unpackage the new lter cartridge. Slide

it into the lter housing as far as it will go

with the grip end horizontal.

5. Push lightly inward on the lter while rotat-

ing it clockwise (to the right). The lter will

then pull itself inward as it is rotated. Rotate

the lter 90 degrees until it stops and the

grip end is vertical. You may be able to feel a

very light click as the lter locks into place.

6. Press a drinking glass against the water

dispenser while checking for any leaks at

the lter housing. Any spurts and sputters

that occur as the system purges air out of

the dispenser system are normal.

7. Continue dispensing water for 3-4 minutes

or until 1.5 gallons of water has owed

through the system. You will likely need to

empty and rell your glass several times.

8. Turn On the ice maker.

9. Press and hold the Water Filter reset

button on the control panel for three

seconds. When the display changes from

Red to Green, the status has been reset.

The PureSource Ultra II

ice and water lter system is

tested and certied to NSF/ANSI

Standards 42, 53 and 401 for the

reduction of claims specied on

the performance data sheet.

More about your Advanced

Water Filter

Filter Cartridge

CHANGING THE FILTER - FRIGIDAIRE PRO

Understanding the Sounds you

may Hear

Your new, high-efciency refrigerator may intro-

duce unfamiliar sounds. These sounds normally

indicate your refrigerator is operating correctly.

Some surfaces on oors, walls, and kitchen cabi-

nets may make these sounds more noticeable.

Following is a list of major components in your

refrigerator and the sounds they can cause:

A. Evaporator Refrigerant through the

evaporator may create a boiling or

gurgling sound.

B. Evaporator fan You may hear air be-

ing forced through the refrigerator by

the evaporator fan.

C. Defrost heater During defrost cycles,

water dripping onto the defrost heater may

cause a hissing or sizzling sound. After

defrosting, a popping sound may occur.

D. Automatic ice maker When ice has

been produced, you will hear ice cubes

falling into the ice bin.

E. Electronic control & automatic de-

frost control These parts can produce

a snapping or clicking sound when

turning the cooling system on and off.

F. Condenser fan You may hear air be-

ing forced through the condenser.

G. Compressor Modern, high-efciency

compressors run much faster than in

the past. The compressor may have a

high-pitched hum or pulsating sound.

H. Water valve Makes a buzzing sound

each time it opens to ll the ice maker.

I. Drain pan (not removable) You may

hear water dripping into the drain pan

during the defrost cycle.

J. Condenser May create minimal

sounds from forced air.

K. Motorized damper May produce a

light humming during operation.

L. Ice chute When dispensing ice, you

will hear a snapping or clicking sound

when the solenoid opens and closes

the ice chute.



NOTE

Energy efcient foam in your refrigerator is

not a sound insulator.



NOTE

During automatic defrost cycle, a red glow in

the back wall vents of your freezer compart-

ment is normal.

NORMAL OPERATING SOUNDS AND SIGHTS

CAUTION

• Pull the refrigerator straight out to move it. Shifting it from side to side may damage

ooring. Be careful not to move the refrigerator beyond the plumbing connections.

• Damp objects stick to cold metal surfaces. Do not touch refrigerated surfaces with wet or

damp hands.

Protecting your investment

Keeping your refrigerator clean maintains appearance and prevents odor build-up. Wipe up any

spills immediately and clean the freezer and fresh food compartments at least twice a year.

When cleaning, take the following precautions:

• Never use CHLORIDE or cleaners with bleach to clean stainless steel.

• Do not wash any removable parts in a dishwasher.

• Always unplug the electrical power cord from the wall outlet before cleaning.

• Remove adhesive labels by hand. Do not use razor blades or other sharp instruments which

can scratch the appliance surface.

• Do not remove the serial plate.

Do not use abrasive cleaners such as window sprays, scouring cleansers, brushes, ammable

uids, cleaning waxes, concentrated detergents, bleaches or cleansers containing petroleum

products on plastic parts, interior doors, gaskets or cabinet liners. Do not use paper towels,

metallic scouring pads, or other abrasive cleaning materials or strong alkaline solutions.



NOTE

If you set your temperature controls to turn off cooling, power to lights and other electrical

components will continue until you unplug the power cord from the wall outlet.

CARE & CLEANING

Vacation and moving tips

Occasion Tips

Short

Vacations

• Leave refrigerator operating during vacations of three weeks or less.

• Use all perishable items from refrigerator compartment.

• Turn automatic ice maker off and empty ice bucket, even if you will only be

gone a few days.

Long

Vacations

• Remove all food and ice if you will be gone one month or more.

• Turn the cooling system off (see “Controls” section for location of On/Off

button) and disconnect power cord.

• Turn water supply valve to closed position.

• Clean interior thoroughly.

• Leave both doors open to prevent odors and mold build-up. Block doors open

if necessary.

Moving • Remove all food and ice.

• If using a handcart, load from the side.

• Adjust rollers all the way up to protect them during sliding or moving.

• Pad cabinet to avoid scratching surface.

IMPORTANT

If you store or move your refrigerator in freezing temperatures, be sure to completely drain

the water supply system. Failure to do so could result in water leaks when the refrigerator is

put back into service. Contact a service representative to perform this operation.

CARE & CLEANING

Care and Cleaning Tips

Part Cleaning

Agents

Tips and Precautions

Interior &

Door Liners

• Soap and water

• Baking soda

and water

• Use two tablespoons of baking soda in one quart of

warm water.

• Be sure to wring excess water out of sponge or cloth

before cleaning around controls, light bulb or any

electrical part.

Door Gaskets • Soap and water • Wipe gaskets with a clean soft cloth.

Drawers &

Bins

• Soap and water • Use a soft cloth to clean drawer runners and tracks.

• Do not wash any removable items (bins, drawers, etc.)

in dishwasher.

Glass

Shelves

• Soap and water

• Glass cleaner

• Mild liquid sprays

• Allow glass to warm to room temperature before

immersing in warm water.

Toe Grille • Soap and water

• Mild liquid sprays

• Vacuum

• Remove toe grille (see Installation Instructions).

• Vacuum both sides and wipe with sudsy cloth or

sponge. Rinse and dry.

Exterior &

Handles

• Soap and water

• Non abrasive

glass cleaner

• Do not use commercial household cleaners containing

ammonia, bleach or alcohol to clean handles.

• Use a soft cloth to clean smooth handles.

• Do not use a dry cloth to clean smooth doors.

Exterior &

Handles

(Stainless

Steel Models

Only)

• Soap and water

• Stainless steel

cleaners

• Never use CHLORIDE or cleaners with bleach to clean

stainless steel.

• Clean stainless steel front and handles with non-

abrasive soapy water and a dishcloth. Rinse with clean

water and a soft cloth.

• Use a non-abrasive stainless steel cleaner. These

cleaners can be purchased at most home improvement

or major department stores. Always follow

manufacturer’s instruction. Do not use household

cleaners containing ammonia or bleach. NOTE: Always

clean, wipe and dry with grain to prevent scratching.

• Wash the rest of the cabinet with warm water and

mild liquid detergent. Rinse well and wipe dry with a

clean soft cloth.

Replacing

Light Bulbs

• Unplug

refrigerator

• Wear gloves

• Remove light cover

• Replace old bulb

• Replace light cover

• Plug in the

refrigerator

• CAUTION: Wear gloves when replacing light bulbs to

avoid getting cut.

• Use same wattage when replacing bulb.

CARE & CLEANING



NOTE

LED lights are in series so if one is bad or

unplugged, several lights may not light up.

Replacing LED Lights

(select models)

The fresh food compartments of your

refrigerator may have LED lights. Always use

Frigidaire parts for replacement.

To replace LED Lights:

1. Unplug your refrigerator’s power cord.

2. Remove lens cover.

3. Remove LED board.

4. Replace LED board and snap in place

assuring the light is facing in toward the

unit (inside fresh food).

5. Replace lens cover.

Ordering Replacement LED Lights

Order new LEDs by calling 1-800-374-4432, on-

line at www.frigidaire.com/store, or through the

dealer where you bought the refrigerator. Here is

the product number to request when ordering:

LED Light, Part #242196201

LED Light Board Removal

Lens Removal

Replacing light bulbs

(select models)

Both the freezer and fresh food compartments

of your refrigerator include light bulbs that

will need replacing from time to time. Some

lights have covers that you will need to remove

before replacing the bulbs. Always use bulbs

that are designed for appliance lighting.

To replace light bulbs:

1. Unplug your refrigerator’s power cord.

2. Wear gloves as protection against

possible broken glass.

3. Remove light cover, if necessary.

4. Unscrew and replace old bulb with an

appliance bulb of the same type and

wattage (normally 40 watts).

5. Replace light cover, if necessary.

6. Plug in the refrigerator’s power cord.

CAUTION

Wear gloves when replacing light bulbs to

avoid getting cut.

Crisper Light

Cover

Light Bulbs

Light Socket

Located Behind

Rear of

Crispers

Light Bulb

Light socket

located behind right

rear of ice container

CARE & CLEANING

Water

Filter

Bulbs

BEFORE YOU CALL

Visit our web site at

www.frigidaire.com

1-800-374-4432 (United States)

1-800-265-8352 (Canada)

CONCERN CAUSE SOLUTION

AUTOMATIC ICE MAKER

Ice maker is not

making any ice.

• Ice maker is turned off.

• Refrigerator is not con-

nected to water line or

water valve is not open.

• The water supply line

is kinked.

• The water lter is not

seated properly.

• The water lter may

be clogged with

foreign material.

• Freezer ice maker wire

signal arm is being held

up by an item not allowing

it to go in the on or down

position. (Does not apply to

Frigidaire Professional)

• Turn on ice maker. Press and hold the “ON-

OFF” button on the display panel for three

seconds until the indicator light turns on.

(Some Models) Move wire signal arm to the

“down” position on the ice maker.

• Connect the unit to the household water

supply and ensure the water valve is open.

• Ensure that the supply line does not kink

when the refrigerator is pushed into place

against the wall.

• For Frigidaire Gallery, remove and re-install

the water lter. Be sure to push the lter rmly

so that you hear it lock solidly into position.

For Frigidaire Professional, remove

and re-install the water lter. Remove by

rotating it counter-clockwise (to the left)

90 degrees to release it. Re-install by

sliding it into the lter housing as far as it

will go with the grip end horizontal. Push

lightly inward on the lter while rotating it

clockwise (to the right). The lter will then

pull itself inward as it is rotated. Rotate the

lter 90 degrees until it stops and the grip

end is vertical. You may be able to feel a

very light click as the lter locks into place.

• If water dispenses slowly or not at all, or

if the lter is six months old or older, it

should be replaced.

• Move any item or frozen ice cubes that

may block the signal arm from being in the

on or down position. See Automatic Ice

Maker-Freezer section in manual.

BEFORE YOU CALL

CONCERN CAUSE SOLUTION

AUTOMATIC ICE MAKER (Continued)

Ice maker is

not making

enough ice.

• Ice maker is producing

less ice than you expect.

• The water lter may be

clogged with foreign material.

• The water supply line

is kinked.

• Saddle valve on cold water

pipe is clogged or restrict-

ed by foreign material.

• Heavy trafc, opening

or closing of the

doors excessively.

• Freezer control is set

too warm.

• The ice maker produces approximately 2.5

to 3 pounds every 24 hours depending on

usage conditions.

• If water dispenses slower than normal,

or if the lter is 6 months old or older, it

should be replaced.

• Ensure that the supply line does not kink

when the refrigerator is pushed into place

against the wall.

• Turn off household water line valve. Re-

move valve. Ensure that valve is not a self-

piercing saddle valve. Clean valve. Replace

valve if necessary.

• Press Fast Freeze to temporarily increase

ice production rate. (Does not apply to

Frigidaire Professional.)

• Set freezer control to colder setting to

improve performance of the ice maker.

Allow 24 hours for temperature to stabilize.

Ice maker

will not stop

making ice

(select models).

• Ice maker wire signal arm

is being held down by a

package in the freezer

that has fallen against ice

maker. (Does not apply to

Frigidaire Professional.)

• Move any item or frozen ice cubes that

may block the signal arm from being in the

off or upward position. See Automatic Ice

Maker-Freezer section in manual.

Ice cubes

are freezing

together.

• Ice cubes are not being

used frequently enough

or interruption of power

for prolonged time.

• Ice cubes are small or hol-

low (shells of ice with water

inside). The hollow cubes

break open in the bin and

leak their water onto exist-

ing ice, which causes it to

freeze together.

• Remove ice container and discard ice. The

ice maker will produce fresh supply. Ice

should be used at least twice weekly to

keep the cubes separated.

• This generally occurs when the ice maker

does not get enough water. This is usually

the result of a clogged water lter or

restricted water supply. Replace the water

lter and if the condition still occurs check

for a Saddle Valve, water valve not turned

on all the way or kinked water supply line.

DISPENSER (Ice & Water)

Dispenser will

not dispense ice.

• Dispenser lock out is en-

gaged. (Does not apply to

Frigidaire Professional.)

• There is no ice in the bin

to be dispensed.

• The refrigerator doors are

not completely closed.

• Dispenser paddle has

been pressed too long

and the dispenser motor

has overheated.

• Press and hold control lock for three

seconds.

• See the “Ice maker is not making any ice”

section above.

• Be sure the refrigerator doors are

completely closed.

• The motor overload protector will reset in about

three minutes and then ice can be dispensed.

BEFORE YOU CALL

CONCERN CAUSE SOLUTION

DISPENSER (Ice & Water)(Continued)

Ice dispenser

is jammed.

• Ice has melted and fro-

zen around auger due to

infrequent use, tempera-

ture uctuations, and/or

power outages.

• Ice cubes are jammed

between ice maker and

back of ice container.

• Remove ice container, thaw, and empty the

contents. Clean container, wipe dry, and

replace in proper position. When new ice is

made, dispenser should operate.

• Remove ice cubes that are jamming

the dispenser.

Dispenser will

not dispense

water.

• Dispenser lock out is

engaged. (Does not apply

to Frigidaire Professional.)

• Water lter not

seated properly.

• Water lter is clogged.

• Household water line

valve is not open.

• Press and hold control lock for 3 seconds.

• For Frigidaire Gallery, remove and

reinstall the water lter. Be sure to push

the lter rmly so that you hear it lock

solidly into position.

For Frigidaire Professional, remove and

reinstall the water lter. Be sure to press

inward as you rotate it clockwise to lock it

in place.

• For Frigidaire Gallery, replace lter

cartridge. Be sure to remove protective

caps and push the lter rmly so that you

hear it lock solidly into position.

For Frigidaire Professional, replace lter

cartridge. Be sure to press inward as you

rotate it clockwise to lock it in place.

• Open household water line valve. See

CONCERN column AUTOMATIC ICE MAKER.

Water has an

odd taste and/

or odor.

• Water has not been

dispensed for an

extended period of time.

• Unit not properly con-

nected to cold water line.

• Draw and discard 10-12 glasses of water to

freshen the supply.

• Connect unit to cold water line that

supplies water to the kitchen faucet.

Water pressure

is extremely low.

• Cut-off and cut-on

pressures are too low

(well systems only).

• Reverse osmosis system

is in regenerative phase.

• Have someone turn up the cut-off and cut-

on pressure on the water pump

system (well systems only).

• It is normal for a reverse osmosis system to be

below 20 psi during the regenerative phase.

Water not

cold enough.

• The water dispensing system

is not designed to chill water.

• Add ice to cup or container before

dispensing water.

BEFORE YOU CALL

CONCERN CAUSE SOLUTION

OPENING/CLOSING OF DOORS/DRAWERS

Door(s) will

not close.

• Door was closed too

hard, causing other door

to open slightly.

• Refrigerator is not level.

It rocks on the oor when

moved slightly.

• Refrigerator is touching a

wall or cabinet.

• Close both doors gently.

• Ensure oor is level and solid, and can

adequately support the refrigerator. Contact a

carpenter to correct a sagging or sloping oor.

• Ensure oor is level and solid, and can

adequately support the refrigerator. Contact a

carpenter to correct a sagging or sloping oor.

Drawers are

difcult to

move.

• Food is touching shelf on

top of drawer.

• Track that drawers slide

on is dirty.

• Remove top layer of items in drawer.

• Ensure drawer is properly installed on track.

• Clean drawer, rollers, and track. See Care

& Cleaning.

RUNNING OF REFRIGERATOR

Compressor

does not run.

• Freezer control is set to

“OF” or “0”.

• Refrigerator is in

defrost cycle.

• Plug at electrical outlet

is disconnected.

• House fuse blown or

tripped circuit breaker.

• Power outage.

• Set freezer control.

• This is normal for a fully automatic defrost

refrigerator. The defrost cycle occurs

periodically, lasting about 30 minutes.

• Ensure plug is tightly pushed into outlet.

• Check/replace fuse with a 15 amp time-

delay fuse. Reset circuit breaker.

• Check house lights. Call local

electric company.

Refrigerator

runs too much

or too long.

(Single Speed

Compressor)

(Some Models)

• Room or outside weather

is hot.

• Doors are opened too

frequently or too long.

• Fresh Food/freezer door

may be slightly open.

• Freezer control is set

too cold.

• Fresh Food/freezer gasket

is dirty, worn, cracked, or

poorly tted.

• Condenser is dirty.

• It’s normal for the refrigerator to work

longer under these conditions.

• Warm air entering the refrigerator causes it

to run more. Open doors less often.

• Ensure refrigerator is level. Keep food

and contains from blocking door. See

PROBLEM column OPENING/CLOSING

OF DOORS/DRAWERS.

• Set Fresh Food control to warmer setting

until refrigerator temperature is satisfactory.

Allow 24 hours for temperature to stabilize.

• Clean or change gasket. Leaks in door

seal will cause refrigerator to run longer in

order to maintain desired temperatures.

• Clean condenser. See CARE & CLEANING.

Compressor

goes off and

on frequently.

• Thermostat keeps

the refrigerator at a con-

stant temperature.

• This is normal. Refrigerator goes on and

off to keep temperature constant. (Single

Speed Compressor) (Some Models)

BEFORE YOU CALL

CONCERN CAUSE SOLUTION

RUNNING OF REFRIGERATOR (Continued)

Refrigerator

seems to run

too much

or too long.

(Variable Speed

Compressor)

(Some Models)

• Your variable speed

compressor is designed

to run 100% of the time

except during the defrost

cycle. At times it will run

faster, such as after a

defrost cycle.

• It is normal for the compressor to run

continuously except during defrost mode.

DIGITAL TEMPERATURE DISPLAY

Digital temper-

ature displays

are ashing.

• Electronic control system

has detected a

performance problem.

• Call your Frigidaire service representative,

who can interpret any messages or number

codes ashing on the digital displays.

WATER/MOISTURE/FROST INSIDE REFRIGERATOR

Moisture collects

on inside of re-

frigerator walls.

• Weather is hot and humid.

• Door is slightly open.

• The rate of frost buildup and internal

sweating increases.

• See PROBLEM column OPENING/

CLOSING OF DOORS/DRAWERS.

Water collects

on bottom side

of drawer cover.

• Vegetables contain and

give off moisture.

• It is not unusual to have moisture on the

bottom side of the cover.

• Move humidity control (some models) to

lower setting.

Water collects

in bottom

of drawer.

• Washed vegetables

and fruit drain while

in the drawer.

• Dry items before putting them in the drawer.

Water collecting in bottom of drawer is normal.

WATER/MOISTURE/FROST OUTSIDE REFRIGERATOR

Moisture collects

on outside of

refrigerator or

between doors.

• Weather is humid.

• Door is slightly open,

causing cold air from

inside refrigerator to meet

warm air from outside.

• This is normal in humid weather. When hu-

midity is lower, the moisture should disappear.

• See PROBLEM column OPENING/

CLOSING OF DOORS/DRAWERS.

MAJOR APPLIANCE WARRANTY

Your appliance is covered by a one year limited warranty. For one year from your original date of

purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove

to be defective in materials or workmanship when such appliance is installed, used and maintained in

accordance with the provided instructions.

Exclusions

If You Need Service

This warranty does not cover the following:

1. Products with original serial numbers that have been removed, altered or cannot be readily determined.

2. Product that has been transferred from its original owner to another party or removed outside

the USA or Canada.

3. Rust on the interior or exterior of the unit.

4. Products purchased “as-is” are not covered by this warranty.

5. Food loss due to any refrigerator or freezer failures.

6. Products used in a commercial setting.

7. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances

not in ordinary household use or used other than in accordance with the provided instructions.

8. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.

9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards,

shelves, etc., which are not a part of the appliance when it is shipped from the factory.

10. Service calls to repair or replace appliance light bulbs, air lters, water lters, other

consumables, or knobs, handles, or other cosmetic parts.

11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry

trip charges, or mileage expense for service calls to remote areas, including the state of Alaska.

12. Damages to the nish of appliance or home incurred during installation, including but not

limited to oors, cabinets, walls, etc.

13. Damages caused by: services performed by unauthorized service companies; use of parts other

than genuine Electrolux parts or parts obtained from persons other than authorized service

companies; or external causes such as abuse, misuse, inadequate power supply, accidents,

res, or acts of God.

DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES

CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT

REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES,

INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE

LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE

YEAR. ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH

AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS

WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO

NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES,

OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS OR

EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL

RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.

This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by

Electrolux Major Appliances North America, a division of Electrolux Home Products, Inc. In Canada,

your appliance is warranted by Electrolux Canada Corp. Electrolux authorizes no person to change

or add to any obligations under this warranty. Obligations for service and parts under this warranty

must be performed by Electrolux or an authorized service company. Product features or specications

as described or illustrated are subject to change without notice.

Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty

period should service be required. If service is performed, it is in your best interest to obtain and

keep all receipts. Service under this warranty must be obtained by contacting Electrolux at the

addresses or phone numbers below.

USA

1-800-374-4432

Frigidaire

10200 David Taylor Drive

Charlotte, NC 28262

Canada

1.800.265.8352

Electrolux Canada Corp.

5855 Terry Fox Way

Mississauga, Ontario, Canada

L5V 3E4

Frigidaire FPSC2277RF2 22.6 Cu. Ft. Counter-Depth Side-by-Side Refrigerator

Product's Documents

Use & Care

Specifications

Frigidaire FPSC2277RF2 Questions and Answers
