Engine Stand 450kg
Stock No.53092 Part No.ES450
SPECIFICATION
The Draper Tools policy of continuous improvement determines the right to change specification
without notice.
Stock No. ............................................................................................................................................. 53092
Part No. .............................................................................................................................................. ES450
Max. capacity ...................................................................................................................................... 450kg
Width: Front ..................................................................................................................................... 400mm
Rear ....................................................................................................................................... 800mm
Length .............................................................................................................................................. 800mm
Height .............................................................................................................................................. 910mm
WARNING
Do not overload. Overloading could cause damage or failure of the engine stand.
Never use the stand on an uneven floor surface as this could result in the stand tipping over.
Always lock the rotating mechanism before applying a load.
Ensure that the load is centered and secured to the mounting plate. An off centre or insecure load could
cause the load and handle to rotate in either direction when the locking mechanism is released.
Always release the locking mechanism slowly and carefully.
The nuts and bolts supplied with the engine stand are all high strength and should not be substituted by
inferior types.
Before each use, ensure all nuts and bolts are correctly fitted and tight.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN LOSS OF LOAD,
PERSONAL INJURY OR PROPERTY DAMAGE.
09/2015INSTRUCTIONS
KNOW YOUR ENGINE STAND
Adjustable mounting slides Mounting plate
Rotating handle
Locking mechanism
Stable H frame
Fixed position rear wheels
Front castor wheels
