1
L-C2-197
REV 9 - 1004081058
Robert H. Peterson Co. • 14724 East Proctor Avenue • City of Industry, CA 91746
INSTALLER: Leave these instructions with consumer.
CONSUMER: Retain for future reference.
INSTALLATION AND OPERATING
INSTRUCTIONS
ELECTRIC
WARMING DRAWER
WARNING
When connecting this appliance to a power
supply make sure that it is the same voltage as
the unit rating. Improper connection may cause
severe damage to the components or decrease
the performance of your Fire Magic
®
electric
warming drawer. A rating plate specifying voltage,
hertz, wattage, and amps is attached to the
unit and also located on page 3. To avoid the
risk of property damage and/or personal injury,
installation work and electrical wiring must be
performed by a qualifi ed professional installer.
This appliance must be installed in accordance
with this instruction.
• EASY INSTALLATION
• TEMPERATURE RANGE UP TO 230
o
F
• MOISTURE REGULATION
• CONCEALED CONTROL
OUTSIDE DOOR MODELS: #33830-SW
#43830-SW
FLUSH DOOR MODELS: #53830-SW
SAFETY WARNINGS & CODES
PLEASE READ AND FOLLOW
• Removing permanently affi xed rating label
warnings WILL void the warranty.
• Observe all local codes and ordinances when
installing this appliance. If no local codes are
applicable, wire unit in accordance with the
National Electrical Code, ANSI/NFPA 70, latest
edition.
GENERAL INFORMATION
• When installing this unit directly below another unit,
only install with Fire Magic
®
built-in products.
• This appliance does not contain a fuse or surge
protector.
• The power to the unit must be made readily
accessible to the operator through means of a line
disconnect switch, circuit breaker, and/or easy to
reach receptacle.
• For safe operation ensure that the unit is grounded
properly per applicable electrical codes.
• Not following these instructions exactly will void
the manufacturer’s warranty.
• For outdoor installation, the circuit must have
ground fault interrupt.
FEATURES:
WARNING
To minimize the risk of property damage and/or
personal injury, do not use a fl exible extension
power-supply cord in addition to the one supplied
with this appliance.
Important: Read these instructions carefully
before starting installation.
33830-SW shown
254-B-07B-5
Certifi ed to: ANSI Z21.58-2007
CSA 1.6-2007
