Memphis VGC21DB4 Grills 21 inch Four Drawer Stack User Manual



PrepareCabinetRoughOpening:

Preparetheroughopeningusingthedimensionsinthefollowingtable.Theopeningshouldbeplumb,levelandsquare.



 15”WideCabinet

VGC15XXX

21”WideCabinet

VGC21XXX

LowerDrawerPro

VGC30LD1

LowerDrawerElite

VGC42LD1

RoughOpeningHeight 29‐1/8” 29‐1/8” 11‐5/8” 11‐5/8”

RoughOpeningWidth 14‐3/8” 20‐3/8” 27‐3/4” 40‐1/8”

RoughOpeningDepth 21‐1/8” 21‐1/8” 21‐1/8” 21‐1/8”



RemoveDrawers:

Removethedrawerstogainaccesstothecabinetmountingholes.Fullyextendthedrawersandpresstheblacklever

upwardsontherighthandsideofthedraweranddownwardsonthelefthandside.Whilepressingtheleverspullthe

draweroutofthecabinetandsetthedrawersaside.



1)Opendrawersandreleasethedrawerslides2)Removedrawersfromcabine t



 



InstallCabinet:

Installthecabinetintothepreparedroughopening.Ensurethatthecabinetisplumb,levelandsquareintheopeningand

fastenthecabinettothestructure.Useaminimumoffourfastenersthatareappropriateforthestructure’smaterial.Once

installed,doublecheckthatthecabinetisstillplumb,levelandsquare.Reinstallthedrawersbyaligningtheslidesonthe

drawerwiththeslidesinthecabinet.Pushthedrawerbackintotheclosedposition.



3)Fastencabinettostructure4)ReinstallDrawers5)CloseDrawers



  


