EN User Manual | Fridge Freezer
Welcome to our family
Thank you for bringing Frigidaire into your home! We see your purchase as the
beginning of a long relationship together.
This manual is your resource for the use and care of your product. Please read it
before using your appliance. Keep it handy for quick reference. If something doesn’t
seem right, the troubleshooting section will help you with common issues.
FAQ, helpful tips and videos, cleaning products, and kitchen and home accessories
are available at http://www.frigidaire.com.
We are here for you! Visit our website, chat with an agent, or call us if you need
help. We may be able to help you avoid a service visit. If you do need service, we
can get that started for you.
Let’s make it official! Be sure to register your product.
CONTENTS
1. IMPORTANT SAFETY INFORMATION................................................. 2
2. FEATURES............................................................................................ 5
3. INSTALLATION......................................................................................5
4. CONTROLS AND SETTINGS................................................................7
5. STORAGE FEATURES..........................................................................8
6. CARE AND CLEANING......................................................................... 9
7. TROUBLESHOOTING......................................................................... 10
8. LIMITED WARRANTY..........................................................................10
1. IMPORTANT SAFETY
INFORMATION
1.1 Keep a record for
quick reference
Model number
..........................................................
Serial number
..........................................................
Purchase date
..........................................................
1.2 Serial number
location
WARNING!
You must follow these guidelines to
ensure that your appliance’s safety
mechanisms are operating correctly.
2 ENGLISH
1.3 Safety definitions
This is the safety alert symbol. It is
used to alert of potential personal
injury hazards. Obey all safety
messages that follow this symbol to
avoid possible injury or death.
DANGER
DANGER indicates an imminently
hazardous situation which, if not
avoided, will result in death or serious
injury.
WARNING!
WARNING indicates a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury.
CAUTION!
CAUTION indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury.
IMPORTANT
IMPORTANT indicates installation,
operation or maintenance information
which is important but not hazard-
related.
1.4 Child safety
This appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision or
instruction concerning use of the
appliance by a person responsible
for their safety.
Destroy or recycle the carton,
plastic bags, and any exterior
wrapping material immediately after
the appliance is unpacked. Children
should never use these items to
play. Cartons covered with rugs,
bedspreads, plastic sheets or
stretch wrap may become airtight
chambers, and can quickly cause
suffocation.
1.5 Important safety
instructions
DANGER
DANGER Risk of fire or
explosion. Flammable
refrigerant used. Do not use
mechanical devices to defrost
the appliance. Do not puncture
refrigerant tubing.
DANGER Risk of fire or
explosion. Flammable
refrigerant used. To be
repaired only by trained
service personnel. Use only
manufacturer-authorized
service parts. Any repair
equipment used must be
designed for flammable
refrigerants. Follow all
manufacturer repair
instructions. Do not puncture
refrigerant tubing.
CAUTION!
CAUTION Risk of fire or
explosion due to puncture of
refrigerant tubing. Follow
handling instructions carefully.
Flammable refrigerant used.
This appliance is forstorage only
and should not be used for any
other purpose.
Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
appliance.
Do not store explosive substances
such as aerosol cans with a
flammable propellant in this
appliance.
Do not operate the appliance in the
presence of explosive fumes
ENGLISH 3
Avoid contact with any moving parts
of automatic ice maker.
Remove all staples from the carton.
Staples can cause severe cuts, and
also destroy finishes if they come in
contact with other appliances or
furniture.
WARNING!
Do not use electrical appliances inside
the food storage compartments of the
appliance unless they are of the type
recommended by the manufacturer.
WARNING!
CALIFORNIA RESIDENTS ONLY
WARNING! Cancer and Reproductive
Harm http://www.P65Warnings.ca.gov
1.6 Proper disposal of
your appliance
CAUTION!
CAUTION Risk of fire or
explosion. Dispose of the
appliance properly in
accordance with the applicable
federal or local regulations.
Flammable refrigerant used.
Risk of child entrapment
Child entrapment and suffocation
are not problems of the past.
Junked or abandoned appliances
are still dangerous – even if they will
sit for “just a few days”. If you are
getting rid of your old appliance,
follow the instructions below to help
prevent accidents.
We strongly encourage responsible
appliance recycling/disposal
methods. Check with your utility
company or visit http://
www.energystar.gov/recycle for
more information on recycling your
old appliance.
Before you throw away your old
appliance:
• Remove doors.
• Leave shelves in place so children may
not easily climb inside.
• Have it removed by a qualified service
technician.
1.7 Electrical
information
• The appliance must be plugged into its
own dedicated 115 Volt, 60 Hz., 15
Amp, AC only electrical outlet. The
power cord of the appliance is
equipped with a three-prong grounding
plug for your protection against
electrical shock hazards. It must be
plugged directly into a properly
grounded three-prong receptacle. The
receptacle must be installed in
accordance with local codes and
ordinances. Consult a qualified
electrician. Do not use an extension
cord or adapter plug.
WARNING!
Avoid fire hazard or electric shock.
• If the power cord is damaged, it should
be replaced by an authorized service
technician to prevent any risk.
• Never unplug the appliance by pulling
on the power cord. Always grip the plug
firmly, and pull straight out from the
receptacle to prevent damaging the
power cord.
• Unplug the appliance before cleaning
and before replacing the light bulb to
avoid electrical shock.
• Performance may be affected if the
voltage varies by 10% or more.
Operating the appliance with
insufficient power can damage the
4 ENGLISH
compressor. Such damage is not
covered under your warranty.
• Do not plug the unit into an electrical
outlet controlled by a wall switch or pull
cord to prevent the appliance from
being turned off accidentally.
• Do not pinch, knot, or bend the power
cord in any manner.
WARNING!
When positioning the appliance,
ensure the supply cord is not trapped
or damaged.
Do not locate multiple portable socket-
outlets or portable power supplies at
the rear of the appliance.
WARNING!
Do not, under any circumstances, cut,
remove, or bypass the grounding
prong (A). Always use the power cord
with a three-prong grounded plug and
grounding type wall receptacle.
2. FEATURES
Table title
.
IMPORTANT
*Features may vary by model.
Accessories are available for your appliance and may be purchased at
Frigidaire.com or by calling toll-free 1-800-374-4432.
2.1 Product overview
1
2
3
4
1
2
3
4
1
Drawer
2
Shelf
3
Temperature Control
4
Door compartments
3. INSTALLATION
This User Manual provides general
installation and operating instructions for
your model. We recommend using a
service or kitchen contracting professional
to install your appliance. Use the
appliance only as instructed in this User
Manual. Before starting the appliance,
follow these important first steps.
ENGLISH 5
3.1 Location
• If possible, place the appliance out of
direct sunlight and away from the
range, dishwasher, or other heat
sources.
• The appliance must be installed on a
floor that is level and strong enough to
support a fully loaded appliance.
WARNING!
This appliance is intended for use in
residential household and similar
interior applications such as:
• Kitchen / kitchenette
• Pantry room
• Basement
• Enclosed garage
• Other interior residential type
environments
CAUTION!
Do not install the appliance where the
temperature will drop below 50°F
(10°C) or rise above 110 °F (43 °C).
The compressor will not be able to
maintain proper temperatures inside
the appliance.
NOTE
Do not block the lower front of the
appliance.
Sufficient air circulation is essential for
the proper operation of the appliance.
WARNING!
Allow the following clearances for
ease of installation, proper air
circulation, plumbing, and electrical
connections:
• Top 3" (75 mm)
• Sides 3" (75 mm)
• Back 4" (101.6 mm)
NOTE
If you place the appliance with the
door hinge side against a wall, you
may have to allow additional space so
the door can be open wider.
3.2 Leveling
When positioning the appliance, ensure
that it is level, with all bottom corners
resting firmly on a solid floor. You can
adjust this using the two leveling feet
located at the front bottom of the
appliance.
3.3 Door Removal
CAUTION!
Before you begin, turn the appliance
temperature control to OFF and
remove the electrical power cord from
the wall outlet. Remove any food from
door shelves.
NOTE
The direction in which the appliance
doors open (door swing) can be
reversed, from left to right or right to
left, by moving the door hinges from
one side to the other. Reversing the
door swing should be performed by a
qualified person.
CAUTION!
The door is heavy. We recommend
two people to remove or replace the
door assembly from the appliance.
NOTE
Keep the removed parts so they can
be used on the opposite side.
CAUTION!
If you place the appliance on its back
or side, let it stand upright for 6 hours
before you plug it in. This prevents
damage to internal components.
NOTE
The shape of the hinges may vary by
model.
1. Remove the hinge cover and the
upper hinge from the top left side of
the appliance and remove the door.
6 ENGLISH
2. Remove the central hinge from the
middle of the appliance and remove
the refrigerator door. Move the screw
hole cover from the left side to the
right.
3. Move the hinge hole covers from the
top left side to the top right side of the
freezer and refrigerator doors.
4. Remove both feet. Remove the lower
hinge and turn it over before
reinstallation.
5. Install the lower hinge on the left side
of the appliance.
6. Install the door.
7. Install both feet and the screw hole
cover on the top right side of the
appliance.
8. Ensure that the top of the door is level
and the rubber gasket is making a
good seal.
9. Tighten the screws.
4. CONTROLS AND SETTINGS
4.1 Cool Down Period
To ensure safe food storage, allow the
appliance to operate with the doors closed
for at least 4 hours. The appliance runs
continuously during this time.
4.2 Temperature Adjustment
NOTE
Adjusting the temperature control to
OFF/0 turns off the compressor and
prevents the refrigerator from cooling,
but does not disconnect the power to
the light bulb and other electrical
components. To turn off power to your
refrigerator, you must unplug the
power cord from the wall outlet.
Adjust the temperature gradually: adjust
the knobs in small increments, allowing
the temperature to stabilize.
• For colder temperatures, adjust the
control toward MAX/COOLER/3.
• For warmer temperatures, adjust the
control toward MIN/NORMAL/1.
ENGLISH 7
5. STORAGE FEATURES
5.1 Shelf adjustment
Adjust the shelves to suit individual needs.
Before adjusting the shelves, remove all
food.
To adjust shelves, slide the shelf by
moving it forward and lifting it upward.
To replace shelves, insert the rear of the
shelf into any pair of shelf rails and
carefully push the shelf back into position,
making sure the shelf clips (A) go in the
notch in the liner.
Glass Shelf
1
2
A
CAUTION!
When reinstalling the shelf, ensure the
shelf clip is attached to the liner and
holds it in place.
CAUTION!
Do not clean glass shelves or covers
with warm water when they are cold.
Shelves and covers may break if
exposed to sudden temperature
changes or impact, such as bumping.
Tempered glass is designed to shatter
into many small, pebble-size pieces.
This is normal. Glass shelves and
covers are heavy. Use both hands
when removing them to avoid
dropping.
NOTE
To avoid personal injury or property
damage, handle tempered glass
shelves carefully. Shelves may break
suddenly if nicked, scratched, or
exposed to sudden temperature
change.
5.2 Crispers
Crispers allow you the flexibility to store
any manner of items including fruits,
vegetables, nuts, etc. Crispers do not
feature humidity controls.
8 ENGLISH
6. CARE AND CLEANING
6.1 Care & Cleaning Tips
Table title
Part What to use Tips and precautions
Interior and door liners
• Soap and water
• Baking soda and water
Use 2 tablespoons of baking soda in 1 quart of
warm water. Be sure to wring excess water out of
sponge or cloth before cleaning around controls,
light bulb or any electrical part.
Door gaskets Soap and water Wipe gaskets with a clean soft cloth.
Drawers and bins Soap and water Use a soft cloth to clean drawer runners and
tracks.
Glass shelves
• Soap and water
• Glass cleaner
• Mild liquid sprays
Allow glass to warm to room temperature before
immersing in warm water.
Exterior and handles
• Soap and water
• Non abrasive glass
cleaner
Do not use commercial household cleaners con
taining ammonia, bleach or alcohol to clean han
dles. Use a soft cloth to clean smooth handles.
Do not use a dry cloth to clean smooth doors.
Exterior and handles
(Stainless steel models
only)
• Soap and water
• Stainless steel cleaners
Never use chloride or cleaners with bleach to
clean stainless steel.
Clean stainless steel front and handles with non-
abrasive soapy water and a dishcloth. Rinse with
clean water and a soft cloth. Use a non-abrasive
stainless steel cleaner. These cleaners can be
purchased at most home improvement or major
department stores. Always follow manufacturer’s
instructions. Do not use household cleaners con
taining ammonia or bleach.
Always clean, wipe and dry with the grain to pre
vent scratching. Wash the rest of the cabinet with
warm water and mild liquid detergent. Rinse well,
and wipe dry with a clean soft cloth.
Replacing LED bulbs
1. Unplug the appliance.
2. Wear gloves.
3. Remove light cover.
4. Replace old bulb.
5. Replace light cover.
6. Plug in the appliance.
Caution: Wear gloves when replacing LED light
bulbs to avoid getting cut.
Use same wattage when replacing bulb.
Use only a 5-watt or less AC LED light bulb.
6.2 Defrosting the Appliance
(some models)
To defrost the appliance:
1. Remove all food and objects from the
appliance.
2. Ensure the drip pan is in place under
the freezer compartment.
3. Unplug the appliance and ensure the
cord is in a safe, dry location.
4. The defrost process may take a few
hours. To speed up the defrost time,
keep the door open and place a bowl
of warm water in the appliance. Never
use sharp objects to remove the frost.
5. During the defrost cycle, water
accumulates in the drip tray. If
necessary, empty the drip tray during
the defrost cycle.
6. After defrosting is complete, empty
and wipe down the drip tray and the
interiors.
7. Reset the appliance to the desired
temperature and put all food and
objects back.
ENGLISH 9
7. TROUBLESHOOTING
Table title
.
Let us help you troubleshoot your concern! This section will help you with common issues. If
you need us, visit our website, chat with an agent, or call us. We may be able to help you
avoid a service visit. If you do need service, we can get that started for you!
Visit Frigidaire.com or call toll-free 1-800-374-4432.
7.1 Common occurrences
Table title
.
The appliance does not run.
• Ensure the plug is tightly pushed into an electri
cal outlet.
• Check/replace the fuse with a 15amp time-delay
fuse. Reset the circuit breaker.
• The appliance may be in defrost cycle.
Wait 20 minutes and check again.
The appliance temperature is unsatisfactory.
• Set the appliance control to a warmer or colder
setting until the temperature is satisfactory. Al
low 24 hours for the temperature to stabilize.
The appliance is noisy or vibrates.
• The cabinet is not level.
• Floor is weak.
• Refer to Normal Operating Sounds.
• Adjust the anti-tip bracket. Refer to Setting the
anti-tip brackets in Installation.
Odors in the appliance.
• The interior needs to be cleaned.
• Cover or wrap the foods that produce odors.
Cabinet light is not working.
• Replace with only a 5Watt or less AC LED light
bulb.
• Ensure the plug is tightly pushed into an electri
cal outlet.
• The light switch may be stuck. Push in the light
switch, located on the refrigerator side wall, to
release.
Mullion or side walls of the appliance are warm. Mullion or side walls of the appliance may be warm
to the touch for the first 24 hours of operation. This
is normal.
8. LIMITED WARRANTY
Your appliance is covered by a one year
limited warranty. For one year from your
date of delivery, Electrolux will pay all
costs for repairing or replacing any parts of
this appliance that prove to be defective in
materials or workmanship when such
appliance is installed, used and
maintained in accordance with the
provided instructions.
Exclusions
This warranty does not cover the following:
1. Products with original serial numbers
that have been removed, altered or
cannot be readily determined.
2. Product that has been transferred from
its original owner to another party or
removed outside the USA or Canada.
3. Rust on the interior or exterior of the
unit.
4. Products purchased “as-is” are not
covered by this warranty.
5. Food loss due to any refrigerator or
freezer failures.
6. Products used in a commercial setting.
10 ENGLISH
7. Service calls which do not involve
malfunction or defects in materials or
workmanship, or for appliances not in
ordinary household use or used other
than in accordance with the provided
instructions.
8. Service calls to correct the installation
of your appliance or to instruct you
how to use your appliance.
9. Expenses for making the appliance
accessible for servicing, such as
removal of trim, cupboards, shelves,
etc., which are not a part of the
appliance when it is shipped from the
factory.
10. Service calls to repair or replace
appliance light bulbs, air filters, water
filters, other consumables, or knobs,
handles, or other cosmetic parts.
11. Surcharges including, but not limited
to, any after hour, weekend, or holiday
service calls, tolls, ferry trip charges,
or mileage expense for service calls to
remote areas, including the state of
Alaska.
12. Damages to the finish of appliance or
home incurred during transportation or
installation, including but not limited to
floors, cabinets, walls, etc.
13. Damages caused by: services
performed by unauthorized service
companies; use of parts other than
genuine Electrolux parts or parts
obtained from persons other than
authorized service companies; or
external causes such as abuse,
misuse, inadequate power supply,
accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED
WARRANTIES; LIMITATION OF
REMEDIES
CUSTOMER’S SOLE AND EXCLUSIVE
REMEDY UNDER THIS LIMITED
WARRANTY SHALL BE PRODUCT
REPAIR OR REPLACEMENT AS
PROVIDED HEREIN. CLAIMS BASED
ON IMPLIED WARRANTIES, INCLUDING
WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED TO ONE YEAR
OR THE SHORTEST PERIOD ALLOWED
BY LAW, BUT NOT LESS THAN ONE
YEAR. ELECTROLUX SHALL NOT BE
LIABLE FOR CONSEQUENTIAL OR
INCIDENTAL DAMAGES SUCH AS
PROPERTY DAMAGE AND INCIDENTAL
EXPENSES RESULTING FROM ANY
BREACH OF THIS WRITTEN LIMITED
WARRANTY OR ANY IMPLIED
WARRANTY. SOME STATES AND
PROVINCES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL
DAMAGES, OR LIMITATIONS ON THE
DURATION OF IMPLIED WARRANTIES,
SO THESE LIMITATIONS OR
EXCLUSIONS MAY NOT APPLY TO
YOU. THIS WRITTEN WARRANTY
GIVES YOU SPECIFIC LEGAL RIGHTS.
YOU MAY ALSO HAVE OTHER RIGHTS
THAT VARY FROM STATE TO STATE.
If You Need Service
Keep your receipt, delivery slip, or some
other appropriate payment record to
establish the warranty period should
service be required. If service is
performed, it is in your best interest to
obtain and keep all receipts. Service under
this warranty must be obtained by
contacting Electrolux at the addresses or
phone numbers below.
This warranty only applies in the USA and
Canada. In the USA, your appliance is
warranted by Electrolux Major Appliances
North America, a division of Electrolux
Consumer Products, Inc. In Canada, your
appliance is warranted by Electrolux
Canada Corp. Electrolux authorizes no
person to change or add to any obligations
under this warranty. Obligations for service
and parts under this warranty must be
performed by Electrolux or an authorized
service company. Product features or
specifications as described or illustrated
are subject to change without notice.
USA
1-800-374-4432
Frigidaire
10200 David Taylor Drive
Charlotte, NC 28262
Canada
1-800-265-8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada L5V 3E4
ENGLISH 11
*
A31155901 (September 2025)
