Stand Mixer
5K45 Series,
5KSM45 - 5KSM200 Series
EN Use and Care manual 2
DE Gebrauchs- und Pegeanleitung 13
FR Manuel d’utilisation et d’entretien 25
IT Manuale d’uso e manutenzione 38
NL Gebruiks- en
onderhoudshandleiding
49
ES Manual de uso y cuidado
60
PT Manual de utilização e
manutenção
71
EL Εγχειρίδιο Χρήσης και Φροντίδας 82
SV Handbok för skötsel och
användning
93
NO Håndbok for bruk og vedlikehold 103
FI Käyttö- ja huolto-opas 113
DA Vejledning til anvendelse og
vedligehold
123
IS Notenda & Meðhöndlunar
handbók
133
RU Руководство по эксплуатации и
уходу
143
PL Instrukcja obsługi i konserwacji 156
CS Návod k použití a údržbě 166
TR Kullanım ve Bakım kılavuzu 176
UK Посібник із використання й
догляду
186
AR
1
W11555951C_01_EN.indd 1W11555951C_01_EN.indd 1 07-10-2021 18:33:1807-10-2021 18:33:18
2
PARTS AND FEATURES
*Included with select models only. Also available as optional accessory.
**The Bowl design, size and material depend on the Stand Mixer model.
***Can also be used to scrape your bowl.
1
2
4
5
6
11
10
1 Speed Control Lever
2 Motor Head
3 Attachment Hub
4 Attachment Knob
5 Motor Head Locking Lever
(not shown)
6 Beater Shaft
7 Beater Height Adjustment Screw
(not shown)
8 Bowl Clamping Plate
9 Bowl**
10 Pouring Shield*
11 2.8 L (3 qt) Stainless Steel Bowl*
12 Dough Hook
13 Wire Whip
14 Flex Edge Beater*
15 Flat Beater*
16 Pastry Beater* and Scraper*** *
12
13
14
15
8
9
3
7
16
W11555951C_01_EN.indd 2W11555951C_01_EN.indd 2 07-10-2021 18:33:1807-10-2021 18:33:18
ENGLISH
3
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions. Misuse of appliance may result in personal injury.
2. To protect against risk of electrical shock, do not put Stand Mixer in water or
other liquid.
3. This appliance is not intended for use by persons (including children) with
reduced physical, sensory, or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
4. European Union Only: Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children shall not play with
the appliance.
5. European Union Only: This appliance shall not be used by children. Keep the
appliance and its cord out of reach of children.
6. Turn the appliance OFF/0, then unplug from the outlet when not in use, before
assembling or disassembling parts and before cleaning. To unplug, grasp the
plug and pull from the outlet. Never pull from the power cord.
7. Avoid contacting moving parts. Keep hands, hair, clothing, as well as spatulas
and other utensils away from beater during operation to reduce the risk of injury
to persons and/or damage to the Stand Mixer.
8. Do not operate any appliance with a damaged cord or plug, or after the
appliance malfunctions, or is dropped or damaged in any manner. Return
appliance to the nearest Authorised Service Facility for examination, repair, or
electrical or mechanical adjustment.
PRODUCT SAFETY
W11555951C_01_EN.indd 3W11555951C_01_EN.indd 3 07-10-2021 18:33:1807-10-2021 18:33:18
4
9. The use of attachments not recommended or sold by KitchenAid may cause fire,
electrical shock or injury.
10. Do not use the Stand Mixer outdoors.
11. Do not let the cord hang over edge of table or counter.
12. Do not let the cord contact hot surfaces, including the stove.
13. Remove Flat Beater, Flex Edge Beater, Wire Whip, Dough Hook, or Pastry Beater
from Stand Mixer before washing.
14. Children should be supervised to ensure that they do not play with the appliance.
15. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent, or similarly qualified persons in order to avoid a hazard.
16. Never leave the appliance unattended while it is in operation.
17. To avoid product damage, do not use the Stand Mixer Bowls in areas of high
heat such as an oven, microwave, or on a stovetop.
18. Allow the appliance to cool completely before putting on or taking off parts, and
before cleaning the appliance.
19. Refer to the “Care and Cleaning” section for instructions on cleaning the
surfaces in contact with food.
20. This appliance is intended to be used in household and similar applications such
as:
- staff kitchen areas in shops, offices, or other working environments;
- farmhouses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
SAVE THESE INSTRUCTIONS
Instructions are also available online, visit our website at:
www.KitchenAid.co.uk or www.KitchenAid.eu
ELECTRICAL REQUIREMENTS
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these
instructions can result in
death, fire, or electrical shock.
Wattage:
300 W
For 5KSM125 - 5KSM200 Series
275 W
For 5K45, 5KSM45 - 5KSM100 Series
Voltage: 220-240 V~
Frequency: 50-60 Hz
NOTE: If the plug does not fit in the
outlet, contact a qualified electrician.
Do not modify the plug in any way.
Do not use an adapter.
Do not use an extension cord. If the power
supply cord is too short, have a qualified
electrician or service technician install an
outlet near the appliance.
PRODUCT SAFETY
W11555951C_01_EN.indd 4W11555951C_01_EN.indd 4 07-10-2021 18:33:1807-10-2021 18:33:18
ENGLISH
5
PRODUCT SAFETY
ELECTRICAL EQUIPMENT WASTE DISPOSAL
Recycling the product
- This appliance is marked in compliance
with law in the EU and UK covering,
Waste Electrical and Electronic
Equipment (WEEE).
- By ensuring this product is disposed
of correctly, you will help prevent
potential negative consequences for
the environment and human health,
which could otherwise be caused by
inappropriate waste handling of this
product.
- The symbol on the product or
on the accompanying documentation
indicates that it should not be treated
as domestic waste but must be taken
to an appropriate collection centre for
the recycling of electrical and electronic
equipment.
For more detailed information about
treatment, recovery and recycling
of this product, please contact your
local city office, your household waste
disposal service, or the shop where you
purchased the product.
DISPOSAL OF PACKING MATERIAL
The packing material is recyclable and is marked with the recycle symbol ( ). The
various parts of the packing must therefore be disposed of responsibly and in full
compliance with local authority regulations governing waste disposal.
DECLARATION OF CONFORMITY (UK)
This appliance has been designed, constructed and distributed in compliance with
the safety requirements of UK Legislation: Electrical Equipment (Safety) Regulations
2016, Electromagnetic Compatibility Regulations 2016. The Ecodesign for Energy-
Related Products and Energy Information (Amendment) (EU Exit) Regulations
2019. The Restriction of the Use of Certain Hazardous Stubstances in Electrical and
Electronic Equipment Regulations 2012.
DECLARATION OF CONFORMITY (EU)
This appliance has been designed, constructed, and distributed in compliance
with the safety requirements of EC Directives: Low Voltage Directive 2014/35/EU,
Electromagnetic Compatibility Directive 2014/30/EU, Ecodesign Directive 2009/125/
EC, RoHS Directive 2011/65/EU and following amendments.
W11555951C_01_EN.indd 5W11555951C_01_EN.indd 5 07-10-2021 18:33:1807-10-2021 18:33:18
6
NOTE: The speed control lever can be set between the speeds listed in the above chart to
obtain speeds 3, 5, 7, and 9 if a finer adjustment is required. To move Speed Control Lever
with ease, lift up slightly as you move it across the settings in either direction.
IMPORTANT: Do not exceed Speed 2 when preparing yeast doughs as this may cause
damage to the Stand Mixer.
SPEED CONTROL GUIDE
Speed Action Accessory
Description
1
Stir
Flat Beater*
Flex Edge Beater*
For slow stirring, combining, mashing,
starting all mixing procedures. Use to add
flour and dry ingredients to batter, and to
add liquids to dry ingredients. Do not use
Speed 1 to mix or knead yeast doughs.
2
Slow
Mixing
Stir
Flat Beater*
Flex Edge Beater*
Dough Hook
Pastry Beater*
For slow mixing, mashing, faster stirring.
Use to mix and knead yeast doughs,
heavy batters and candies, start mashing
potatoes or other vegetables, cut
shortening into flour, and mix thin or
splashy batters.
Cut butter into flour to make pastry
dough; Mash fruits and vegetables.
4
Mixing,
Beating
Flat Beater*
Flex Edge Beater*
Wire Whip
Pastry Beater*
For mixing semi-heavy batters, such
as cookies. Use to combine sugar and
shortening and to add sugar to egg
whites for meringues. Medium speed for
cake mixes. For shredding meats.
6
Beating,
Creaming
For medium-fast beating (creaming) or
whipping. Use to finish mixing cake,
doughnut, and other batters. High speed
for cake mixes.
8
Fast
Beating,
Whipping
Wire Whip
For whipping cream, egg whites, and
boiled frostings.
10
Fast
Whipping
For whipping small amounts of cream,
egg whites, or for final whipping of
mashed potatoes.
PRODUCT USAGE
*Included with select models only. Also available as optional accessory.
W11555951C_01_EN.indd 6W11555951C_01_EN.indd 6 07-10-2021 18:33:1907-10-2021 18:33:19
ENGLISH
7
PRODUCT USAGE
ACCESSORY GUIDE
Accessory Use to mix
Suggested items
Flat Beater*
Flex Edge Beater*
Normal to heavy
mixtures:
Cakes, creamed frostings, candies, cookies,
pie pastry, Shredding meats, biscuits, meat
loaf, mashed potatoes.
Wire Whip
Mixtures that need air
incorporated:
Eggs, egg whites, heavy cream,
boiled frostings, sponge cakes, mayonnaise,
some candies.
Dough Hook
Mixing and kneading
yeast doughs:
Breads, rolls, pizza dough, coffee cakes, buns.
Pastry Beater* Cut butter into flour:
For pie dough, biscuits and other pastries,
mashing fruits and vegetables, and shredding
meats.
*Included with select models only. Also available as optional accessory.
ATTACHING/REMOVING THE BOWL
To attach Bowl: Turn Speed Control
Lever to “0”. Unplug Stand Mixer.
1
Place Bowl on Bowl Clamping Plate. Turn
Bowl gently in clockwise direction.
3
Unlock and lift the Motor Head. The
lock** engages automatically to keep the
head locked in place.
2
To remove Bowl: Repeat steps 1 and 2.
Turn Bowl gently counterclockwise.
4
NOTE: Motor Head should always be in locked position when using the Stand Mixer.
**Locking option is available on select models.
NOTE: Scraper assists in cleaning the Pastry Beater. It may also be useful in scraping
ingredients from the bowl.
W11555951C_01_EN.indd 7W11555951C_01_EN.indd 7 07-10-2021 18:33:1907-10-2021 18:33:19
8
PRODUCT USAGE
ATTACHING/REMOVING THE FLAT BEATER, FLEX EDGE BEATER*,
WIRE WHIP, PASTRY BEATER* OR DOUGH HOOK
To attach accessory: Turn speed control
to “0”. Unplug Stand Mixer.
1
To remove accessory: Repeat steps 1
and 2. Press accessory upward as far as
possible and turn to the left. Then pull
accessory from the Beater Shaft.
4
Unlock and lift the Motor Head. The
lock** engages automatically to keep the
head locked in place.
2
Slip accessory onto Beater Shaft and
press upward as far as possible. Then,
turn accessory to the right, hooking
accessory over the pin on the shaft.
3
* Included with select models only. Also available as an optional accessory.
**Locking option is available on select models.
Scan code for more information
W11555951C_01_EN.indd 8W11555951C_01_EN.indd 8 07-10-2021 18:33:1907-10-2021 18:33:19
ENGLISH
9
PRODUCT USAGE
BEATER TO BOWL CLEARANCE
Your Stand Mixer is adjusted at the factory so the Flat Beater just clears the bottom of
the Bowl. If, for any reason, the Flat Beater hits the bottom of the Bowl or is too far away
from the Bowl, you can correct clearance easily.
NOTE: When properly adjusted, the Flat Beater will not strike on the bottom or side of
the Bowl. If the Flat Beater or the Wire Whip is so close that it strikes the bottom of the
Bowl, coating may wear off the beater or wires on whip may wear.
Turn Speed Control Lever to “0”. Unplug
Stand Mixer.
1
Lift motor head. Turn screw slightly
counterclockwise (left) to raise Flat
Beater or clockwise (right) to lower Flat
Beater. Make adjustment with Flat Beater,
so it just clears surface of Bowl. If you
overadjust the screw, the Bowl lock lever
may not lock into place.
2
CARE AND CLEANING
Always be sure to unplug Stand Mixer
before cleaning. Wipe Stand Mixer with a
soft, damp cloth. Do not use
household/commercial cleaners. Wipe
off beater shaft frequently, removing any
residue that may accumulate. Do not
immerse in water.
1
Bowls, Pouring Shield*, Flat Beater*, Flex
Edge Beater*, Pastry Beater* and
Scraper** and Dough Hook may be
washed on the top rack in dishwasher. Or,
clean them thoroughly in hot sudsy water
and rinse completely before drying. Do
not store beaters on shaft.
2
*Included with select models only. Also available as an optional accessory.
**Can also be used to scrape your bowl.
IMPORTANT: Allow the appliance to cool completely before putting on or taking off
parts, and before cleaning the appliance.
W11555951C_01_EN.indd 9W11555951C_01_EN.indd 9 07-10-2021 18:33:1907-10-2021 18:33:19
10
CARE AND CLEANING
IMPORTANT: The Wire Whip is only
dishwasher-safe for models 5KSM200,
5KSM185, and 5KSM180. For all other
models: Wash it thoroughly in hot sudsy
water and rinse completely before drying.
Do not store Wire Whip on shaft.
3
TROUBLESHOOTING
Problem Solution
If Stand Mixer warms up
during use:
Heavy loads should not exceed Speed 2. Under heavy loads
with extended mixing time periods, you may not be able to
comfortably touch the top of the unit. This is normal.
The Stand Mixer emits a
pungent odour:
This is common with electric motors, especially when new.
If the Flat Beater hits the
Bowl:
Stop the Stand Mixer. See the “Beater to Bowl clearance”
section and adjust the beater to bowl clearance.
If your Stand Mixer should fail
to operate, please check the
following:
Is the Stand Mixer plugged in?
Is the fuse in the circuit to the Stand Mixer in working
order? If you have a circuit breaker box, be sure the circuit
is closed.
Turn off the Stand Mixer for 10-15 seconds, then turn it back
on. If the Stand Mixer still does not start, allow it to cool for
30 minutes before turning it back on.
If the problem cannot be
corrected:
See the “Terms of KitchenAid Guarantee (“Guarantee”)”
section.
Do not return the Stand Mixer to the retailer; retailers do
not provide service.
WARNING
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove an earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death, re,
or electrical shock.
W11555951C_01_EN.indd 10W11555951C_01_EN.indd 10 07-10-2021 18:33:2007-10-2021 18:33:20
ENGLISH
11
TERMS OF KITCHENAID GUARANTEE
("GUARANTEE")
Covering U.K. - Ireland - South Africa - UAE
KitchenAid Europa, Inc., Nijverheidslaan 3, Box 5, 1853 Strombeek-Bever, Belgium ("Guarantor") grants the end-customer, who
is a consumer, a Guarantee pursuant to the following terms.
FOR U.K.:
The Guarantee applies in addition to and does not limit or affect the statutory warranty rights of the end-customer against the
seller of the product. In summary, the Consumer Rights Act 2015 says products must be as described, fit for purpose and of
satisfactory quality. During the expected lifespan of your product your legal rights entitle you to the following:
- Up to 30 days: if your product is faulty, then you can get an immediate refund.
- Up to six months: if your product can't be repaired or replaced, then you're entitled to a full refund, in most cases.
- Up to six years: if your product does not last a reasonable length of time you may be entitled to some money back.
These rights are subject to certain exceptions. For detailed information please visit the Citizens Advice website
www.adviceguide.org.uk or call 03454 04 05 06.
FOR IRELAND:
The Guarantee applies in addition to and does not limit or affect the statutory warranty rights of the end-customer against
the seller of the product under the European Communities (Certain Aspects of the Sale of Consumer Goods and Associated
Guarantees Regulations 2003 (S.I. No. 11/2003)) and other enactments governing the sale of consumer goods.
FOR SOUTH AFRICA:
The Guarantee applies in addition to and does not limit or affect the statutory warranty rights of the end-customer against the
seller of the product. In summary, the Consumer Protection Act, 2008 says that products must be: (i) reasonably suitable for
the purpose for which they are intended; (ii) in good working order, of good quality and free of any defects; (iii) useable and
durable for a reasonable period of time, having regard to the use to which they would normally be put and to all the surrounding
circumstances; and (iv) in compliance with any applicable standards or any other public regulations.
During the expected lifespan of your product and where the products are not purchased online, your legal rights will entitle you
to the following:
- You will be entitled to a full refund, if you did not have the opportunity to examine the product before delivery and if you
rejected delivery of the product on the basis that the type and quality of the product was not as reasonably expected or did not
reasonably conform to the material specifications.
- Within 5 business days after delivery: you may rescind your purchase and request a refund, if your purchase resulted from direct
marketing.
- Within 10 business days after delivery: you will be entitled to a full refund, if it is found that the product was unsuitable for a
particular purpose specifically communicated to you by the Guarantor.
- Within 15 business days after delivery: you will be entitled to a refund if: (i) the product was not delivered to you; or (ii) if you
returned the product to the Guarantor.
- Within 6 months after delivery: you will be entitled to a refund or a replacement product, if the product is defective or fails to
operate in terms of its specifications.
Where you have purchased a product online your legal rights will be governed by the Electronic Communications and
Transactions Act, 2002 and you will be entitled to the following:
- Within 7 days after conclusion of the transaction or after delivery: you may cancel your purchase without reason and without
penalty.
- Within 30 days of the date of cancellation of the transaction: you will be entitled to receive a refund, if you have already made
payment.
- You will only be liable for the direct costs of returning the product to the Guarantor.
FOR UAE:
The Guarantee applies in addition to and does not limit or affect the statutory warranty rights of the end-customer against the
seller of the product.
1) SCOPE AND TERMS OF THE GUARANTEE
a) The Guarantor grants the Guarantee for the products mentioned under Section 1.b) which a consumer has purchased from
a seller or a company of the KitchenAid-Group within the following countries: U.K., Ireland, or South Africa, or the United Arab
Emirates (UAE).
b) The Guarantee period depends on the purchased product and is as follows:
5KSM125 - 5KSM200 Five years full guarantee from date of purchase.
5K45, 5KSM45 - 5KSM100 Two years full guarantee from date of purchase.
c) The Guarantee period commences on the date of purchase, i.e. the date on which a consumer purchased the product from a
dealer or a company of the KitchenAid-Group.
d) The Guarantee covers the defect-free nature of the product.
e) The Guarantor shall provide the consumer with the following services under this Guarantee, at the choice of the Guarantor, if
a defect occurs during the Guarantee period:
- Repair of the defective product or product part, or
- Replacement of the defective product or product part. If a product is no longer available, the Guarantor is entitled to
exchange the product for a product of equal or higher value.
W11555951C_01_EN.indd 11W11555951C_01_EN.indd 11 07-10-2021 18:33:2007-10-2021 18:33:20
12
f) If the consumer wishes to make a claim under the Guarantee, the consumer has to contact the country specific KitchenAid
service centres or the Guarantor directly at KitchenAid Europa, Inc. Nijverheidslaan 3, Box 5, 1853 Strombeek-Bever, Belgium;
Email-Address U.K.: CONSUMERCARE. [email protected]
Email-Address IRELAND: [email protected]
Toll Free Number U.K. & IRELAND: 00 800 381 040 26
FOR SOUTH-AFRICA:
Our local KitchenAid Distributor:
KitchenAid Africa
PO Box 52102
V&A Waterfront
Cape Town
8002
Contact our distributor:
Telephone: +27 21 555 0700
You can contact our Customer Service Centre for Small Domestic Appliances from 8.30 am to 1.00 pm and from 1.30 pm to
5.00 pm or write to us at the following address: [email protected]
FOR UAE:
AL GHANDI ELECTRONICS.
POST BOX NO. 9098,
DUBAI, UNITED ARAB EMIRATES
Toll free number: +971 4 2570007
g) The costs of repair, including spare parts, and any postage costs (if applicable) for the delivery of a defect-free product
or product part shall be borne by the Guarantor. The Guarantor shall also bear the postage costs for returning the defective
product or product part if the Guarantor or the country specific KitchenAid customer service centre requested the return of the
defective product or product part. However, the consumer shall bear the costs of appropriate packaging for the return of the
defective product or product part.
h) To be able to make a claim under the Guarantee, the consumer must present the receipt or invoice of the purchase of the
product.
2) LIMITATIONS OF THE GUARANTEE
a) The Guarantee applies only to products used for private purposes and not for professional or commercial purposes.
b) The Guarantee does not apply in the case of normal wear and tear, improper or abusive use, failure to follow the
instructions for use, use of the product at the wrong electrical voltage, installation and operation in violation of the
applicable electrical regulations, and use of force (e.g. blows).
c) The Guarantee does not apply if the product has been modified or converted, e.g. conversions from 120 V products to
220-240 V products.
d) The provision of Guarantee services does not extend the Guarantee period, nor does it initiate the commencement of
a new Guarantee period. The Guarantee period for installed spare parts ends with the Guarantee period for the entire
product.
e) FOR SOUTH-AFRICA & UAE ONLY:
Further or other claims, in particular claims for damages, are excluded unless liability is mandatory by law.
After expiry of the Guarantee period or for products for which the Guarantee does not apply, the KitchenAid customer service
centres are still available to the end-customer for questions and information.
Further information is also available on our website:
- For U.K. & Ireland www.kitchenaid.eu
- For South-Africa: www.kitchenaidafrica.com
- For UAE: www.KitchenAid-MEA.com
TERMS OF KITCHENAID GUARANTEE
("GUARANTEE")
PRODUCT REGISTRATION
Register your new KitchenAid appliance now: http://www.kitchenaid.eu/register
©2021 All rights reserved.
KITCHENAID and the design of the stand mixer are trademarks in the U.S. and elsewhere.
W11555951C_01_EN.indd 12W11555951C_01_EN.indd 12 07-10-2021 18:33:2007-10-2021 18:33:20
