you are now the proud owner of an ILVE cooking appliance.
Thank you for purchasing ILVE and welcome to the exciting
world of cooking the ILVE way.
This instruction manual has been specially created to inform
you of the full range of features your ILVE appliance has to offer
and serves as an introduction to the wonderful benefits of ILVE’s
dynamic cooking systems.
We present detailed information on each of the advanced
cooking systems built into ILVE appliances. Once you have read
this section you will be able to choose the most appropriate
settings for your appliance when cooking different types of
food.
Please carefully READ these instructions BEFORE INSTALLING
AND USING the appliance and retain them for future reference.
It is important that you keep potentially hazardous packaging
(plastic bags, polystyrene, etc.) out of reach of children.
Congratulations,
IV600BIM Microwave Manual 2014 V1.indd 4 22/05/2014 5:45 pm
Warning and Safety instructions 6
Modes of Operation 11
Suitable Containers for Microwave Ovens 12
Operation 14
Cleaning and Care 18
Installation 19
Warranty Card 21
Contents
IV600BIM Microwave Manual 2014 V1.indd 5 22/05/2014 5:45 pm
• THIS APPLIANCE IS NOT INTENDED FOR USE BY PERSONS (INCLUDING CHILDREN) WITH
REDUCED PHYSICAL, SENSORY OR MENTAL CAPABILITIES, OR LACK OF EXPERIENCE AND
KNOWLEDGE, UNLESS THEY HAVE BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING
USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY. CHILDREN SHOULD
BE SUPERVISED TO ENSURE THAT THEY DO NOT PLAY WITH THE APPLIANCE
• During use the appliance becomes hot. Care should be taken to avoid touching heating elements
inside the oven.
• Accessible parts may become hot during use Young children should be kept away.
• When this appliance is operated in the combination mode, children should be in adult supervision due
to the temperatures generated.
• If the door or door seals are damaged, the oven must not be operated until it has been repaired by a
competent person.
• It is hazardous for anyone other than a competent person to carry out any service or repair operation
that involves the removal of a cover which gives protection against exposure to microwave energy.
• Liquids and other foods must not be heated in sealed containers as they are liable to explode. When
heating liquids, milk, sauces etc. the boiling point of the liquid may be reached without the production
of typical bubbles.The liquid does not boil evenly throughout.This so-called ‘boiling delay’ can cause a
sudden build-up of bubbles when the container is removed from the oven or shaken,which can lead to
the liquid boiling over suddenly and explosively and can cause skin burning.
• Only allow children to use the oven with supervision when adequate instructions have been given so
that the child is able to use the oven in a safe way and understands the hazards of improper use.
• When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of
ignition. If smoke is observed, switch off or unplug the appliance and keep the door closed in order to
stifle any flames.
• Microwave heating of beverages can result in delayed eruptive boiling; therefore care must be taken
when handling the container.
• Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could
adversely affect the life of the appliance and possibly result in a hazardous situation. Improper use can
present a risk of both personal injury and material damage. To avoid the risk of accidents and damage
to the appliance please read these operating instructions carefully before installation and before using
it for the first time. They contain important notes on installation, safety, operation and care of the
appliance. Keep these instructions in a safe place and pass them on to any future user.
• Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they
can scratch the surface, which may result in shattering of the glass. A steam cleaner is not to be used.
• This appliance complies with all relevant local and national safety requirements.
• The appliance is intended for domestic use only: to cook, defrost, reheat and to grill food. Any other
usage is not supported by the manufacturer and could be dangerous. The manufacturer cannot be held
liable for damage caused by improper or incorrect use of the appliance. Never use the microwave to
store or dry items which could ignite easily. Moisture evaporates and create a Fire hazard.
• This appliance is not a toy! To avoid the risk of injury, do not allow children to play on or near it or to
play with the controls.
Warning and Safety Instructions
6 ILVE Operating Manual
IV600BIM Microwave Manual 2014 V1.indd 6 22/05/2014 5:45 pm
• Supervise its use by older children, the elderly or infirm. If allowing older children to use the appliance
without supervision, please ensure that they are aware of how a microwave oven works and understand
the dangers of improper use.
Technical safety
• If the connection cable is damaged, the new cable must be fitted by a ILVE approved service
technician.
• Do not use the microwave if the door is warped, the door hinges are loose, holes or cracks are visible
in the casing, the door or the oven interior walls. Operating the appliance with this type of damage will
result in microwave leakage and present a hazard to the user.
• Never open the casing of the appliance. Tampering with electrical connections or components and
mechanical parts is highly dangerous and can cause operational faults or electric shock.
• Before connecting the appliance to the mains supply, make sure that the rating on the data plate
corresponds to the voltage and frequency of the household supply. This data must correspond in order
to avoid risk of damage to the appliance. Consult a qualified electrician if in any doubt.
• Do not connect the appliance to the mains electricity supply by an extension lead. Extension leads do
not guarantee the required safety of the appliance (e.g. danger of overheating).
• The electrical safety of this appliance can only be guaranteed when continuity is complete between it
and an effective earthing system which complies with local and national safety regulations. It is most
important that this basic safety requirement is present and regularly tested and where there is any
doubt, the on-site electrical wiring should be inspected by a qualified electrician. The manufacturer
cannot be held liable for the consequences of an inadequate earthing system (e.g. electric shock).
• The appliance must be built in before operation to ensure that no electrical components are accessible.
• Repairs may only be carried out by a suitably qualified and competent person in accordance with
national and local safety regulations. Repairs and other work by unqualified persons could be
dangerous. The manufacturer cannot be held liable for unauthorised work.
• The appliance is only completely isolated from the electricity supply when it is switched off at the wall
socket and the plug removed or the mains fuse is disconnected or the screw-out fuse is removed
(in countries where this is applicable).
• This equipment may only be used in mobile installations such as ships, caravans, aircraft etc. if a risk
assessment of the installation has been carried out by a suitably qualified engineer.
• In countries where there are areas which may be subject to infestation by cockroaches or other
vermin, pay particular attention to keeping the appliance and its surroundings in a clean condition at all
times. Any damage which may be caused by cockroaches or other vermin will not be covered by the
guarantee.
7ILVE Operating Manual
IV600BIM Microwave Manual 2014 V1.indd 7 22/05/2014 5:45 pm
Warning and Safety Instructions
Using the Microwave Oven
• Always ensure that food is sufficiently heated.
• Many factors will affect the overall cooking time, including the size and amount of food, its initial
temperature, changes to the recipe and the shape and size of cooking container.
• Some foods may contain micro-organisms which are only destroyed by thorough cooking, therefore
when cooking or reheating foods, e.g. poultry, it is particularly important that food is fully cooked
through (at temperatures over 70°C for more than 10 minutes). If in doubt, select a longer cooking or
reheating time.
• It is important that the heat is allowed to spread evenly throughout the food being cooked. This can be
achieved by stirring and/or turning the food, and by observing a sufficiently long standing time, which
should be added to the time needed for cooking, reheating or defrosting.
• Always remember that times for cooking, reheating and defrosting in a microwave oven are usually
considerably shorter than with traditional methods of food preparation.
• Excessively long cooking times can lead to food drying out and burning, or could even cause it to
catch fire. There is also a danger of fire if breadcrumbs, flowers, herbs, etc., are dried in the microwave
oven.
• Always ensure that this type of procedure is supervised.
• Do not use the microwave function to heat up cushions or pads filled with cherry kernels, wheat grains,
lavender or gel, such as those used in aromatherapy. These pads can ignite when heated, even after
they have been removed from the microwave.
• Exercise caution when cooking or reheating food with a high sugar content, e.g. Christmas pudding. If
heated for too long, the sugar may caramelise or ignite.
• Do not use full power to warm empty dishes.
• Do not use the appliance without food, or if it is incorrectly loaded.
• Never cook or reheat food or liquids in sealed containers, jars or bottles. With baby bottles, the screw
top and teat must be removed. Otherwise pressure builds up which can cause the bottle or container
to explode, posing a severe risk of injury.
• Before serving, remember to allow a sufficient standing time and then always check the temperature
of the actual food itself after taking it out of the microwave. The temperature of the container is not an
indication of the temperature of the food or liquid in it. This is particularly important when preparing
food for babies, children, and the elderly or infirm. Shake or stir baby milk and food thoroughly after
heating, and try it for temperature to ensure that it will not scald the baby. When heating food and drink
remember that the heat is created in the food itself, and that the container will normally be cooler. The
dish is only warmed by the heat of the food.
8 ILVE Operating Manual
IV600BIM Microwave Manual 2014 V1.indd 8 22/05/2014 5:45 pm
• To avoid fuelling any flames, do not open the oven door if smoke occurs in the oven interior.
• Interrupt the process by pressing the Stop/C button twice. Switch off at the wall socket, and where
applicable, remove the plug. Do not open the door until the smoke has dispersed.
• Never heat undiluted alcohol in the oven as this can easily ignite.
Danger of Injury or Fire:
• Do not heat up tins in the microwave oven.
• Pressure can build up and they may explode resulting in injury or damage.
• Cover any food which is left in the oven to be kept hot, as moisture in the food could lead to corrosion
damage in the oven. This also prevents the food from drying out.
• Try to avoid the interior walls being splashed with food or liquids containing salt. If it does happen, wipe
these away thoroughly to avoid corrosion on the stainless steel surface.
• Do not use any containers or cutlery made from or containing metal, aluminium foil, lead crystal
glassware, temperature-sensitive plastics, wooden utensils or cutlery, metal clips or wire ties. Do not
use bowls with milled rims, or cream pots with the tinfoil lid only partially removed. Such items could
be damaged or cause a fire hazard. The gourmet plate supplied with the appliance are designed to
be compatible with microwaves and can therefore be used for grilling with or without the microwave
function.
• The mircowave grill rack should only be used when grilling and NOT when microwaving or using
combination microwave and grill.
• Do not use the rack and the gourmet plate at the same time. This will damage the gourmet plate.
Always place the gourmet plate directly on the turntable.
• Do not leave the oven unattended when reheating or cooking food in disposable containers made of
plastic, paper or other inflammable materials. Before using single-use plastic containers, make sure
they are suitable for use in microwave ovens. See appropriate section.
• Eggs can only be cooked in their shells in the microwave oven in a specially designed egg boiling
device available from specialist shops.
9ILVE Operating Manual
IV600BIM Microwave Manual 2014 V1.indd 9 22/05/2014 5:45 pm
Warning and Safety Instructions
• Similarly, hard-boiled eggs should not be reheated in the microwave oven as this may lead to the eggs
bursting, even after they have been taken out of the oven.
• Eggs can be cooked without their shells using microwave heat only if the yolk membrane has been
punctured several times first. The pressure could otherwise cause the egg yolk to explode.
• Use a suitable heat-resistant mat or pot rest.
• Do not use the oven to heat up the room. Due to the high temperatures radiated, objects left near the
appliance could catch fire.
• When using kitchen appliances connected to sockets near the appliance, ensure that the cable cannot
get trapped in a hot oven door, which could melt the cable insulation and be dangerous.
• To check food temperature, first interrupt the cooking process. Only use a thermometer specifically
approved for food use to measure the temperature of the food. Never use a thermometer containing
mercury or liquid, as these are not suitable for use with very high temperatures and will break very
easily.
• Do not use a steam-cleaning appliance to clean this appliance. Pressurised steam could reach the
electrical components and cause a short circuit.
When using browning dishes:
• Always use oven gloves when handling the browning dish to avoid burns.
• Never place the browning dish directly onto a table or work surface. Use a suitable heat resistant mat,
grid or board to protect the work surface or table and prevent heat marks.
• Browning dishes should only be used in a microwave oven, or as a serving dish.
• In a conventional oven the special glaze would suffer damage.
Disposal of your old appliance:
• Before disposing of your old appliance, first make it unusable.
• Disconnect it from the mains, cut off the cable near the appliance and cut off and render any plug
unusable. This should be done by a competent person.
• The manufacturer cannot be held liable for damage caused by non-compliance with these Warning and
Safety instructions.
10 ILVE Operating Manual
IV600BIM Microwave Manual 2014 V1.indd 10 22/05/2014 5:45 pm
In a microwave oven there is a high-frequency tube called a magnetron. This converts electrical energy
into microwaves. These microwaves are distributed evenly throughout the oven interior and rebound off
the metal sides of the oven interior to reach the food from all sides. Microwave distribution is improved
with the turntable engaged. In order for microwaves to reach the food, they must be able to penetrate the
cooking utensil being used. Microwaves can penetrate porcelain, glass, cardboard and plastics, but not
metal. Do not, therefore, use utensils made of metal, or which contain metal, for example in the form of
gold or silver trim. The metal reflects the microwaves and this could lead to the creation of sparks. The
microwaves cannot be absorbed. Microwaves pass through a suitable container and find their way directly
into the food. All food contains moisture molecules which, when subjected to microwave energy, start to
oscillate 2.5 thousand million times a second.
The friction caused by this vibration creates heat, which first starts developing around the outside of the
food and then slowly penetrates towards centre. The moisture, fat and sugar content of food will affect the
speed at which it is cooked.
As heat is produced directly in the food,
– food can generally be cooked without adding much liquid or cooking oil.
– cooking, reheating and defrosting in a microwave oven is quicker than using conventional methods.
– nutrients, such as vitamins and minerals, are generally retained.
– the colour, texture and taste of food are not impaired. Microwaves stop being produced as soon as the
cooking process is interrupted or the appliance door is opened. When the appliance is in operation, the
closed, sealed door prevents microwaves escaping from the appliance.
Modes of Operation
11ILVE Operating Manual
IV600BIM Microwave Manual 2014 V1.indd 11 22/05/2014 5:45 pm
Suitable Containers for Microwave Ovens
Microwaves
– are reflected by metal,
– pass through glass, porcelain, plastic and card,
– and are absorbed by food.
Material and shape
The material and shape of containers used affect cooking results and times. Heat distribution is more even
in round and oval shaped flat containers than in rectangular containers, providing better results.
Metal
Metal containers, aluminium foil and metal cutlery, or china with metallic decoration, such as gold rims
or cobalt blue must not be used in an oven being used in microwave mode. The metal reflects the
microwaves, hindering the cooking process.
Exceptions:
– Ready-meals in aluminium foil dishes.
These can be defrosted and reheated in the microwave oven, if recommended by the manufacturer.
However, as food is only heated from the top, it is better to remove the food from the aluminium foil
container and transfer it to a dish suitable for a microwave oven. The heat distribution will be more even.
If sparks and arcing occur when using an aluminium container, stop and transfer the food to a microwave
safe container.
– Pieces of aluminium foil
For even defrosting and to avoid overcooking unevenly shaped cuts of meat, poultry or fish, small pieces
of aluminium foil may be used to mask wingtips or other thin parts for the last few minutes of the
programme. Make sure that the aluminium foil is at least 2 cm from the oven walls at all times. It must not
touch the walls.
– Metal meat skewers or clamps.
These should only be used if they are very small in comparison to the size of the cut of meat.
– Glassware
Heat-resistant glass or ceramic glass are ideal for use in the microwave oven. Crystal glass contains lead
which could cause the glass to crack. Glass dishes with a milled rim are also subject to this risk. Both are
unsuitable.
Porcelain
Porcelain is a suitable material. Do not use porcelain with gold or silver edging or items with hollow knobs
or handles, as insufficient ventilation may cause pressure.
Earthenware
Decorated earthenware is only suitable if the decoration is beneath an all-over glaze. Earthenware can get
very hot, and may crack.
Glazes and colours
Some glazes and colours contain metals which make them unsuitable for use in a microwave oven.
12 ILVE Operating Manual
IV600BIM Microwave Manual 2014 V1.indd 12 22/05/2014 5:45 pm
Suitable Containers for Microwave Ovens
Plastics
When purchasing plasticware, make sure that it is suitable for use in a microwave oven. Plastic containers
must only be used in microwave mode alone. Plastics must be heat-resistant to a minimum of 110 °C.
Otherwise the plastic may melt and fuse with the food. Special plastic utensils designed for use in
microwave ovens are available from good retail outlets. Melamine is not suitable as it absorbs energy and
heats up. Disposable containers, such as trays made from polystyrene, can only be used for very short
timed warming and reheating of food. Plastic boiling bags can be used for cooking and reheating. They
should be pierced beforehand so that steam can escape. This prevents a build-up of pressure and
reduces the risk of the bag bursting. Roasting bags and tubes can also be used. Roasting tubes should
be about 40 cm longer and roasting bags about 20 cm longer than the food being roasted, and carefully
tied with string. Turn the ends over and secure them. The bag should be pierced according to the
manufacturer’s instructions. Do not use metal clips, plastic clips containing metal parts or paper ties
containing wire. There is a danger that they will ignite when heated.
Wood
Wooden dishes are not suitable. Moisture contained in the wood evaporates when exposed to microwave
energy, causing the wood to dry and crack.
Disposable containers
Only those plastic disposable containers which are specified by the manufacturer as suitable for use in a
microwave oven may be used. Do not leave the oven unattended when reheating or cooking food in
disposable containers made of plastic, paper or other inflammable materials. Disposable containers are
not always recyclable or bio-degradable.
Testing dishes for their suitability
If in doubt as to whether glass, earthenware or porcelain plates or dishes are suitable for use in a
microwave oven, a simple test can be performed:
Place the item you wish to test in the centre of the oven, fill a suitable glass with water and also place this
in the oven.
- Close the door.
- Turn the power selector to 900 W.
- Enter a time of 30 seconds with the time selector.
- Press the Start button.
At the end of the test, the water in the glass should be warm and the dish cool. If the dish is hot the water
cold it would be unwise to use the dish.
If a crackling noise is heard accompanied by sparks during the test, switch the appliance off immediately
(press button Stop/C twice).
Any crockery which causes this reaction is unsuitable for use with microwave power.
If any doubt exists about the suitability of containers, please contact the supplier.
This test cannot be used to check whether items with hollow knobs or handles are suitable for use with
microwave power.
13ILVE Operating Manual
IV600BIM Microwave Manual 2014 V1.indd 13 22/05/2014 5:45 pm
Operation
Interior and Accessories
1- Oven door
2- Door locking mechanism
3- Grill/browning element
4- Control panel
5- Turntable
6- Grilling rack
7- Turntable support
Control Panel
8- Display screen
9- Time/weight knob
10- Function knob
11- Auto menu/timer
12- Stop/cancel
13- Confirm/start
14- Door release button
14 ILVE Operating Manual
IV600BIM Microwave Manual 2014 V1.indd 14 22/05/2014 5:45 pm
Function Lock
The function lock prevents the function being used by children, for example.
To activate the function lock press button 12 for 3 seconds until the screen display’s the below.
To cancel the system lock:
Press button 12 for 3 seconds until the screen display’s the below:
Time Setting
Press button 11 for 3 seconds to adjust the hours by turning knob 9. Press button 11 once again to adjust
minutes. Press button 11 once more to confirm time.
Defrost
Turn knob 10 to select ‘Defrost’ and the screen display P-30, then turn knob 9 to set time from 0:05 to 60:00, and press button
13 to confirm.
Example: If you want to use Defrost for 30 minutes, you can operate the microwave oven as the following steps.
1)Turn knob 10 to select ‘Defrost’ and the screen display P-30.
2)Turn knob 9 to set time until displays 30:00
3)Press button 13 to confirm.
Microwave Cooking
Turn knob 10 to select microwave power,
Turn knob 9 to select cooking time from 0:05 to 60:00
Press button 13 to confirm and start cooking.
Turn Power Screen
15ILVE Operating Manual
IV600BIM Microwave Manual 2014 V1.indd 15 22/05/2014 5:45 pm
Note: the step quantities for the adjustment time are as follow:
0---1 min: 5 seconds
1---3 min: 10 seconds
3---10 min: 30 seconds
10---30 min: 1 minute
30---60 min: 5 minutes
Example: If you want to use 80% microwave power to cook for 30 minutes, you can operate the microwave oven as
the following steps.
1)Turn knob 10 to select ‘M.High’ and the screen display P-80.
2)Turn knob 9 to set time until displays 30:00
3)Press button 13 to confirm and start cooking.
Grill
Turn knob 10 to ‘Grill’ position, turn knob 9 to set cooking time from 0:05 to 60:00, press button 13 to confirm and
start cooking.
Example: If you want to use ‘Grill’ function to cook for 20 minutes, you can operate the microwave oven as the
following steps.
1)Turn knob 10 to select ‘Grill’
2)Turn knob 9 to set time until displays 20:00
3)Press button 13 to confirm and start cooking.
IMPORTANT: When using the grill function do not use the quick start button to set the cooking time as this will trigger
the microwave function. Operating the microwave function with the grill rack in the unit can cause sparking and
potentially irreparable damage.
Warm
Turn knob 10 to ‘Warm’ position, turn knob 9 to set cooking time from 0:05 to 60:00, press button 13 to confirm
and start cooking.
Sterilize
Turn knob 10 to ‘Sterilize’ position, press button 13 to confirm and start sterilize. The sterilize time is 5 minutes which
can’t be adjusted.
Warning: the sterilize function is to be used as part of the Microwave’s disinfection program. This function is not
suitable for metal utensils or anything that has metal or any item that is not of a thermo labile material.
Combination Cooking
Turn knob 10 to ‘COMB’ position. There are 3 combination programs as below:
COMB 1: (30% micro+70% grill), the screen display CO-1
COMB 2: (55% micro+45% grill), the screen display CO-2
COMB 3: (70% micro+30% grill), the screen display CO-3
Turn knob 9 to set cooking time from 0:05 to 60:00, press button 13 to confirm and start cooking.
Example: If you want to use 55% microwave power and 45% grill power (CO-2) to cook for 10 minutes, you can operate
the microwave oven as the following steps.
1)Turn knob 10 to select ‘COMB 2’ and the screen display CO-2
2)Turn knob 9 to set time until displays 10:00
3)Press button 13 to confirm and start cooking.
IMPORTANT: do not use the grilling rack in microwave or combination grilling modes. Operating the microwave function
with the grill rack in the unit can cause sparking and potentially irreparable damage.
Operation
16 ILVE Operating Manual
IV600BIM Microwave Manual 2014 V1.indd 16 22/05/2014 5:45 pm
Automatic programmers
Press button 11 to select cooking program according to below table:
Turn knob
9 to select weight, and press button 13 to c rm and start cooking.
No. AUTO MENU 1 2 3 4 5 6 7 8 9 10
cup cup cup
RICE
VEGETABLE
MILK/COFFE
POPCORN
POTATO
PIZZA
FISH
BREAD
CHICKEN
MEAT
SKEWERED
MEAT
Operation
17
ILVE Operating Manual
IV600BIM Microwave Manual 2014 V1.indd 17 22/05/2014 5:45 pm
Cleaning and Care
AUTO MENU DISPLAY
RICE A-01
VEGETABLE A-02
MILK/COFFE A-03
POPCORN A-04
POTATO A-05
PIZZA A-06
FISH A-07
BREAD A-08
CHICKEN A-09
MEAT A-10
SKEWERED MEAT A-11
1.Turn the oven off and remove the power plug from the wall socket before cleaning.
2.Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe with
a damp cloth. The use of harsh detergent or abrasives is not recommended.
3.The outside oven surface should be cleaned with a damp cloth. To prevent damage to the operating
parts inside the oven, water should not be allowed to seep into the ventilation openings.
4.Do not allow the Control Panel to become wet. Clean with a
soft, damp cloth and mild non abbraisive
detergent. Do not use abrasives or spray-on cleaners on the control Panel.
5.If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may
occur when the microwave oven is operated under high humidity conditions and in no way indicates
malfunction of the unit.
6.It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy water or
in a dishwasher.
7.The roller ring and oven cavity floor should be cleaned regularly to avoid excessive noise. Simply wipe
the bottom surface of the oven with mild detergent, water or window cleaner and dry. The roller ring may
be washed in mild sudsy water or dish washer. Cooking vapour collect during repeated use but in no
way affect the bottom surface or roller ring wheels. When removing the roller ring from cavity floor for
cleaning, be sure to replace it in the proper position.
8.Remove odors from your oven by combining a cu
p of water with the juice and skin of one lemon in a
deep microwaveable bowl. Microwave for 5 minutes, wipe thoroughly and dry with a soft cloth.
9.When it becomes necessary to replace the oven light, please consult a dealer to have it replaced.
18 ILVE Operating Manual
IV600BIM Microwave Manual 2014 V1.indd 18 22/05/2014 5:45 pm
When installing the appliance, ensure that the vent outlets at the front of the appliance are not hindered,
and that there is adequate ventilation to the rear of the housing unit by leaving a large enough gap (see
diagram: 50 mm x unit width). Do not block the ventilation gaps with any objects. The appliance is
designed to be built into a tall unit. To transport the appliance, make sure that you lift it by the appliance
housing and not by the frame. The frame is not sturdy enough to bear the weight of the appliance when it
is being carried. Building-in dimensions:
The appliance must be built in before it can be used. Otherwise it poses an electric shock hazard.
InstallationInstallation
19
ILVE Operating Manual
IV600BIM Microwave Manual 2014 V1.indd 19 22/05/2014 5:46 pm
058
50
390
390
368
595
595
560-595
380-390
380-390
560-595
COMPONENTS
1
2
bolt
φ3×20mm 2PCS
screwcover
3
bolt
φ4×35mm
1PCS
1PCS
20
ILVE Operating Manual
IV600BIM Microwave Manual 2014 V1.indd 20 22/05/2014 5:46 pm
1 Put the microwave oven into the cabinet and keep
the microwave oven in a horizontal direction and keep
the edge distance of two side as same.Then fix the
bolt(component 1) on the top of microwave oven and beat it into the cabinet.
2 Open the microwave oven, fix
the bolt (Component 3) and beat
it into the cabinet, then install
screw cover
FRAME INSTALLATION STEPS
EUROLINX LIMITED WARRANTY
Eurolinx Pty Limited A.B.N. 50 001 473 347
WARRANTY REGISTRATION
Your ongoing satisfaction with your product is
important to us. We ask that you complete the enclosed
Warranty Registration Card and return it to us so that
we have a record of the products you purchased.
Alternatively you can register on line (see registration
card for details)
PRIVACY
We respect your privacy and is committed to handling
your personal information in accordance with the
National Privacy Principles and the Privacy
Act 1988
(Cth). A copy of the Privacy Policy is available at
www.eurolinx.com.au. Eurolinx will not disclose
any personal information set out in the Warranty
Registration Card (“Personal Information”) without your
consent unless required by:
1. law;
2. any Eurolinx related company;
3. any service provider which provide services to
Eurolinx or assist Eurolinx in providing services
(including repair and warranty services) to customers.
Our purpose in collecting the Personal Information is
to keep a record of the Eurolinx product purchased by
you, in order to provide a better warranty service to you
in the unlikely event that there is a problem with your
Eurolinx product. Eurolinx may contact you at any one
or more of the address, email address or telephone
numbers set out in the Warranty Registration Card.
Please contact Eurolinx on 1300 694 583 should you
not wish to be contacted by Eurolinx.
WARRAN
TY
1. Warranty
Eurolinx warrants that each Eurolinx product will
remain, for a period of twenty four (24) months
computed from the date of purchase of the Eurolinx
product, free from defects arising in the manufacture of
the Eurolinx product (“Warranty”). Except for consumer
guarantees set out in the Competition and Consumer
Act 2010 (Cth) (“Act”), Eurolinx does not make any
further warranties or representations in relation to
Eurolinx products.
2. What is not Covered by the Warranty.
The Warranty does not apply if an Eurolinx product is
defective by a factor other than a defect arising in the
manufacture of the Eurolinx product, including but not
limited to:
(a) damage through misuse (including failure to
maintain, service or use with proper care), neglect,
accident or ordinary wear and tear (including
deterioration of parts and accessories and glass
breakage);
(b) use for purpose for which t
he Eurolinx product was
not sold or designed;
(c) use or installation which is not in accordance with
(d) use or operation after a defect has occurred or been
discovered;
(e) damage through freight, transportation or handling in
transit (other than when Eurolinx is responsible);
(f ) damage through exposure to chemicals, dusts,
residues, excessive voltage, heat, atmospheric
conditions or other forces or environmental factors
outside the control of Eurolinx;
any person other than Eurolinx, an employee of Eurolinx
or an authorised Eurolinx service contractor;
(h) use of parts, components or accessories which have
(i) damage to surface coatings caused by cleaning or
maintenance using products not recommended in the
Eurolinx product handbook provided to the purchaser
upon purchase of the Eurolinx product;
(j) damage to the base of an electric oven due to items
having been placed on the base of the oven cavity or
covering the base, such as aluminium foil (this impedes
the transfer of heat from the element to the oven cavity
and can result in irreparable
damage); or
(k) damages, dents or other cosmetic imperfections not
an Eurolinx product purchased as a “factory second”
or from display. The Warranty does not extend to light
globes used in Eurolinx products.
3. Domestic Use
Each Eurolinx product is made for domestic use. This
Warranty may not extend to Eurolinx products used for
commercial purposes; under those circumstances the
warranty period is limited to 3 month.
4. Time for Claim under the Warranty
You must make any claim under this Warranty within
twenty eight (28) days after the occurrence of an event
which gives rise to a claim pursuant to the Warranty, by
booking a service call on the telephone number below.
5. Proof of Purchase
Customers must retain proof of purchase in order to
be eligible to make a warranty claim in respect of an
Eurolinx product.
Continued over...
6. Claiming under the Warranty
Customers will bear the cost of claiming under this
Warranty unless Eurolinx determines the expenses are
reasonable, in which case the customer must claim
those expenses by providing written evidence of each
expense to Eurolinx at the address on the Warranty
Registration Card.
7. Statutory Rights
(a) These terms and conditions do not a ect your
statutory rights.
(b) The limitations on the Warranty set out in this
documen
t do not exclude or limit the application of the
consumer guarantees set out in the Act or any other
equivalent or corresponding legislation in the relevant
jurisdiction where to do so would:
(i) contravene the law of the relevant jurisdiction; or
(ii) cause any part of the Warranty to be void.
(c) Eurolinx excludes indirect or consequential loss of
any kind (including, without limitation, loss of use of the
Eurolinx product) and (other than expressly provided for
in these terms and conditions) subject to all terms,
conditions and warranties implied by custom, the
general law, the Act or other statute.
(d) The liability of Eurolinx to you for a breach of any
express or non-excludable implied term, condition or
warranty is limited at the option of Eurolinx to:
(i) replacing or repairing the defective part of the
Eurolinx product;
(ii) paying the cost of replacing or repairing the defective
part of the Eurolinx product;
(iii) replacing the Eurolinx product; or
(iv) paying the cost of replacing the Eurolinx product.
(e) Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to
have the goods repaired or replaced if the goods fail
to be of acceptable quality and the failure does not
amount to a major failure.
8. Defects
Any part of an Eurolinx product deemed to be defective
and replaced by Eurolinx is the property of Eurolinx.
Eurolinx reserves the right to inspect and test Eurolinx
products in order to determine the extent of any defect
and the validity of a claim under the Warranty.
*To locate your closest Eurolinx authorised service
agent please contact Eurolinx on 1300 694 583,
customercare@eurolinx.com.au or visit
http://support.eurolinx.com.au
IMPORTANT!
All warranty service calls must be booked via
the customer care department. The team can
be contacted on 1 300 85 64 11 option 1 or
customercare@eurolinx.com.au
Service is delivered through a network of Service
Agents. If the Appliance is located outside our
normal Service Area of our agents you, t he
Customer will need to bear the cost of travel outside
that area.
If you are unable to provide proof of purchase, the
fault is not covered under warranty or the product
required to bear the full cost of the service visit
12062019
EUROLINX LIMITED WARRANTY
Please complete and send to Eurolinx at: REPLY PAID 83617
LEICHHARDT NSW
2040
Last Name: First Name:
Address:
State: Postcode: Email:
Home Phone: Mobile:
Purchase Date:
/ / (Please attach proof of purchase to validate warranty)
MODEL NUMBER
SERIAL NUMBER
(if you cannot locate the serial number please call Eurolinx on 1300 85 64 11)
1
2
3
4
WARRANTY REGISTRATION CARD
12062019
Notes
facebook.com/ILVEappliances
twitter.com/#!/ILVE_appliances
youtube.com/user/ILVEappliances
livewithilve.com
You can now find us on:
IV600BIM Microwave Manual 2014 V1.indd 24 22/05/2014 5:46 pm
Australia National T elephone Number 1300 MYILVE (694 583)
New Zealand Telephone Number 0508 458 369
ILVE showrooms are open daily from 9am-5pm and Saturdays 10am-4pm
(WA by appointment only on Saturdays)
ilve.com.au
48-50 Moor e Street
Leichhardt
F 02 8569 4699
VIC, TAS & SA
1211 Toorak Road
Camberwell
F 03 9809 2155
QLD
1/42 Cavendish Road Coorparoo
F 07 3397 0850
WA & NT
Unit 10/55 Howe Street
Osborne Park
F 08 9201 9188
New Zealand
PO Box 11.160
Sockburn Christchurch
F 03 344 5906
IV600BIM Microwave Manual 2014 V1.indd 25 22/05/2014 5:46 pm
V20211130
