5. OPERATION
5.1 OPERATION
Now the pump is ready, start operating the pump by giving quick strokes to the lever handle.
NOTE:
1. Apply thread sealant to the threads of the suction tube assembly before attaching it to the
bung nut. Do not use undue force when tightening.
2. Ensure rubber gasket is positioned properly in spout nut before attaching the Delivery
spout .
3. The telescopic suction tube will automatically adjust to the proper position.
4. Do not tighten the pump by holding the lever handle .
5. Ensure that the retainer clip is bent properly so as eliminate possibility of pivot pin coming out
while using the pump.
NOTE: The pump is constructed using plated steel components. It should never be used to
transfer fluids that may cause the pump to rust. Certain fluids have a tendency to build a coating
on the surface when dry, it is recommended to leave the lever handle in upright position when not
in use.
5.2 PRIME THE PUMP
If the pumps fails to operate, it may be necessary to prime.
Turn the delivery spout upward.
Pour a few drops of the fluid being dispensed into the spout.
Start the pump by moving the lever with several quick strokes.
If the pump still fails to start:
Remove the pump from the drum and ensure the Suction tube is extended enough to reach the
bottom of the drum.
