RED006
2277 Harbor Bay Pkwy
1.888.880.8368
Alameda, CA 94502
6” Round Airflow Reducer - 25 CFM Reduction
For use with the following models:
Arc and Cheng Collection (w/CBI-600A blower),
AK75xxASX and AK8300ASX (w/CBI-600B blower),
AK70xxAS, AK8100AS, ZAG-xxxAG, ZAN-xxxAS,
ZAZ-xxxAS, ZSA-xxxBS, ZFI-M90BS, ZRM-xxxBS,
ZRO-xxxBS.
AUG11.0101
3
21
25 CFM
REDUCER
KIT INSTALLED
RED006 - 2011
25 CFM
REDUCER
KIT INSTALLED
RED006 - 2011
4
1. Remove existing damper and damper
clips from blower collar.
2. Position CFM reducer so that reducer
clips hang over blower collar.
3. Firmly press down on CFM reducer
clips to secure CFM reducer in place.
4. Attach reducer installation confirmation
sticker to a conspicuous location on the
interior back wall of the unit.
25 CFM
REDUCER
KIT INSTALLED
RED006 - 2011
6” Round Damper
CFM Reducer Plate
Installation Confirmation
Sticker
Included Materials:
