v1.6
User Manual
2022.05
2
©
2021 DJI All Rights Reserved.
Revision Log
Version
Date
Revisions
v1.2
2021.12
Added Intelligent Flight Mode section.
v1.4
2022.1
Updated Smart RTH, added QuickShots, QuickTransfer and USB Mode
features.
v1.6
2022.5
Updated Tele Camera features, etc.
Searching for Keywords
Search for keywords such as “battery” and “install” to find a topic. If you are using Adobe
Acrobat Reader to read this document, press Ctrl+F on Windows or Command+F on Mac to
begin a search.
Navigating to a Topic
View a complete list of topics in the table of contents. Click on a topic to navigate to that
section.
Printing this Document
This document supports high resolution printing.
2
©
2021 DJI All Rights Reserved.
Legend
Read Before the First Flight
Video Tutorials
Download the DJI Fly App
Download DJI Assistant 2 (Consumer Drones Series)
Using this Manual
Warning Important
Hints and Tips
Reference
Read the following documents before using the DJI
TM
MAVIC
TM
3:
1.
Safety Guidelines
2.
Quick Start Guide
3.
User Manual
I
t
i
s
r
e
c
o
mme
n
d
e
d
t
o
wa
t
c
h
a
ll
t
u
t
o
r
i
a
l
v
i
d
e
o
s
o
n
t
h
e
o
ffi
c
i
a
l
D
J
I
we
b
s
i
t
e
a
n
d
r
ea
d
s
a
f
e
t
y
g
u
i
d
e
li
n
e
s
before using for the first time. Prepare for your first flight by reviewing the quick start guide and refer
to this user manual for more information.
Go to the address below or scan the QR code to watch the DJI Mavic 3 tutorial videos, which
demonstrate how to use the Mavic 3 safely:
MAVIC 3
MAVIC 3 CINE
https://s.dji.com/ZGppL5 https://s.dji.com/ZGppL4
Make sure to use DJI Fly during flight. Scan the QR code above to download the latest version.
download DJI Fly to their mobile device when using DJI RC-N1 remote controller.
The Android version of DJI Fly is compatible with Android v6.0 and later. The iOS version of DJI Fly is
compatible with iOS v11.0 and later.
* For increased safety, flight is restricted to a height of 98.4 ft (30 m) and range of 164 ft (50 m) when not
connected or logged into the app during flight. This applies to DJI Fly and all apps compatible with DJI aircraft.
Download DJI Assistant 2 (Consumer Drones Series) at http://www.dji.com/mavic-3/downloads.
temperature for military grade application (-55° to 125° C), which is required to endure greater
environmental variability. Operate the product appropriately and only for applications that it meets the
operating temperature range requirements of that grade.
The operating temperature of this product is -10° to 40° C. It does not meet the standard operating
The DJI RC Pro remote controller has the DJI Fly app already installed. Users are required to
3
©
2021 DJI All Rights Reserved.
Contents
Using this Manual
2
Legend 2
Read Before the First Flight 2
Video Tutorials 2
Download the DJI Fly App 2
Download DJI Assistant 2 (Consumer Drones Series) 2
Product Profile
6
Introduction 6
Using for the First Time 7
Diagram 9
Aircraft
14
Flight Modes 14
Aircraft Status Indicators 15
Return to Home 16
Vision Systems and Infrared Sensing System 21
Intelligent Flight Mode 23
Advanced Pilot Assistance Systems (APAS 5.0) 30
Flight Recorder 30
QuickTransfer 31
Propellers 32
Intelligent Flight Battery 33
Gimbal and Camera 38
Remote Controller
41
DJI RC Pro 41
RC-N1 49
Linking the Remote Controller 53
DJI Fly App
55
Home 55
Camera View 56
5
©
2021 DJI All Rights Reserved.
Product Profile
This section introduces DJI Mavic 3 and
lists the components of the aircraft and
remote controller.
6
©
2021 DJI All Rights Reserved.
Product Profile
Introduction
DJI Mavic 3 features both an Infrared Sensing System and Forward, Backward, Upward, Lateral,
and Downward Vision Systems, allowing for hovering and flying indoors as well as outdoors and for
automatic Return to Home while avoiding obstacles in all directions. The aircraft has a maximum flight
speed of 47 mph (75.6 kph) and a maximum flight time of 46 minutes.
The DJI RC Pro remote controller has a built-in 5.5-in high brightness 1000cd/m
2
screen with a
resolution of 1920x1080 pixels. Users can connect to the internet via Wi-Fi while the Android operating
system includes Bluetooth and GNSS. The DJI RC Pro comes with a wide range of aircraft and gimbal
controls as well as customizable buttons and has a maximum operating time of 3 hours. The RC-N1
remote controller displays the video transmission from the aircraft to DJI Fly on a mobile device. The
aircraft and camera are easy to control using the onboard buttons and the remote controller has a
runtime of 6 hours.
Feature Highlights
Gimbal and Camera: DJI Mavic 3 uses a 4/3-in CMOS sensor Hasselblad L2D-20c camera, capable
of shooting 20MP photos and 5.1K 50fps/DCI 4K 120fps Apple ProRes 422 HQ* and H.264/H.265
videos. The camera has an adjustable aperture of f/2.8 to f/11, a dynamic range of 12.8 stops, and
supports 10-bit D-Log video. The tele camera helps users to capture at up to 28x zoom using Explore
mode.
Video Transmission: With four built-in antennas and DJI’s long-range transmission O3+ technology, DJI
Mavic 3 offers a maximum transmission range of 15 km and video quality at up to 1080p 60fps from
the aircraft to the DJI Fly app. The remote controller works at both 2.4 and 5.8 GHz, and is capable of
selecting the best transmission channel automatically.
Intelligent Flight Modes: The user can focus on operating the aircraft while the Advanced Pilot
Assistance System 5.0 (APAS 5.0) helps the aircraft to avoid obstacles in all directions.
* Only the DJI Mavic 3 Cine aircraft comes with a built-in 1TB SSD, which supports the recording and storing
of Apple ProRes 422 HQ video. Otherwise, the features and functions described in this user manual apply to
both the DJI Mavic 3 and DJI Mavic 3 Cine aircraft.
The maximum flight time was tested in an environment without wind while flying at a consistent flight
speed of 20.1 mph (32.4 kph). The maximum flight speed was tested at sea level altitude without
wind. Note that the maximum flight speed is limited to 42 mph (68.4 kph) in the European Union (EU).
These value are for reference only.
The remote controller reaches its maximum transmission distance (FCC) in a wide-open area with
no electromagnetic interference at an altitude of about 400 ft (120 m). The maximum transmission
distance refers to the maximum distance that the aircraft can still send and receive transmissions. It
does not refer to the maximum distance the aircraft can fly in a single flight. The maximum runtime
was tested in a laboratory environment and without charging the mobile device. This value is for
reference only.
5.8 GHz is not supported in some regions. Observe the local laws and regulations.
DJI Mavic 3
User Manual
7
©
2021 DJI All Rights Reserved.
1
2
DJI Mavic 3 is folded before being packaged. Follow the steps below to unfold the aircraft and remote
controller.
Preparing the Aircraft
1.
Remove the storage cover.
2. All Intelligent Flight Batteries are in hibernation mode before delivery to ensure safety. Use the
provided charger to charge and activate the Intelligent Flight Batteries for the first time. It takes
approximately 1 hour and 36 minutes to fully charge an Intelligent Flight Battery. Charging time is
tested when using the fixed cable of the charger. It is recommended to use this cable to charge the
Intelligent Flight Battery.
3.
Unfold the front arms, followed by the rear arms, and then the propeller blades.
Make sure to unfold the front arms before unfolding the rear arms.
Make sure the storage cover is removed and all arms are unfolded before powering on the aircraft.
Otherwise, it may affect the aircraft self-diagnostics.
Attach the storage cover when the aircraft is not in use.
Using for the First Time
DJI Mavic 3
User Manual
8
©
2021 DJI All Rights Reserved.
2
1
2
1
Preparing the Remote Controller
Follow the steps below to prepare to use the DJI RC Pro remote controller.
1. Use the provided charger to charge the remote controller via the USB-C port to active the battery.
2. Remove the control sticks from the storage slots on the remote controller and screw them into place.
3.
Unfold the antennas.
4.
The remote controller needs to be activated before using for the first time and an internet connection
is required for activation. Press and then press and hold the power button to power on the remote
controller. Follow the on-screen prompts to activate the remote controller.
Follow the steps below to prepare the DJI RC-N1 remote controller.
1.
Remove the control sticks from their storage slots on the remote controller and screw them into
place.
2.
Pull out the mobile device holder. Choose an appropriate remote controller cable based on the type
of mobile device. A Lightning connector cable, Micro USB cable, and USB-C cable are included in
the packaging. Connect the end of the cable with the phone icon to your mobile device. Make sure
the mobile device is secured.
If a USB connection prompt appears when using an Android mobile device, select the option to
charge only. Otherwise, it may fail to connect.
DJI Mavic 3
User Manual
9
©
2021 DJI All Rights Reserved.
2
7
8
6
A
1
2
B
3
10
4
5
9
16
17
11
13
14
12
15
Activating DJI Mavic 3 Aircraft
DJI Mavic 3 requires activation before using for the first time. After powering on the aircraft and remote
controller, follow the on-screen prompts to activate DJI Mavic 3 using DJI Fly. An internet connection is
required for activation.
Binding the Aircraft and Remote Controller
It is recommended to bind the aircraft and remote controller to help ensure the best possible after-sales
service. Follow the on-screen prompts after activation to bind the aircraft and remote controller.
Updating Firmware
A prompt will appear in DJI Fly when new firmware is available. It is recommended to update the
firmware whenever prompted to do so in order to ensure the best possible user experience.
Diagram
Aircraft
1. Gimbal and Camera
A.
Tele Camera
B.
Hasselblad L2D-20c Camera
2. Horizontal Omnidirectional Vision System
3. Auxiliary Bottom Light
4. Downward Vision System
5. Infrared Sensing System
6. Front LEDs
7.
Motors
8. Propellers
9. Aircraft Status Indicators
10. Landing Gears (Built-in antennas)
11. Upward Vision System
12. Intelligent Flight Battery
13. Battery Level LEDs
14. Power Button
15. Battery Buckles
16. USB-C Port
17. microSD Card Slot
DJI Mavic 3
User Manual
10
©
2021 DJI All Rights Reserved.
1
2
3
4
8
9
5 6
7
10
11
12
13
14
15
19
18
16
17
DJI RC Pro
1. Antennas
Relay aircraft control and video wireless
signals.
2.
Back Button
Press once to return to the previous screen.
Press twice to return to the home screen.
3. Control Sticks
Use the control sticks to control the aircraft
movements. Set the flight control mode in DJI
Fly. The control sticks are removable and easy
to store.
4. Return to Home (RTH) Button
Press and hold to initiate RTH. Press again to
cancel RTH.
5. Flight Pause Button
Press once to make the aircraft brake and
hover in place (only when GNSS or Vision
Systems are available).
6. Flight Mode Switch
Switch between Cine, Normal, and Sport
mode.
7. 5D Button
View the 5D Button features in DJI Fly by
entering Camera View, Settings, and then
Control.
8. Power Button
Press once to check the current battery level.
Press and then press and hold to power the
remote controller on or off. When the remote
controller is powered on, press once to turn
the touchscreen on or off.
9. Confirm Button
Press once to confirm a selection. The button
does not have a function when using DJI Fly.
10. Touchscreen
Touch the screen to operate the remote
controller. Note that the touchscreen is not
waterproof. Operate with caution.
11. microSD Card Slot
Use to insert a microSD card.
12.
USB-C port
For charging.
13. Mini HDMI Port
For video output.
14. Gimbal Dial
Controls the tilt of the camera.
15. Record Button
Press once to start or stop recording.
16. Status LED
Indicates the status of remote controller.
17. Battery Level LEDs
Displays the current battery level of the
remote controller.
18. Focus/Shutter Button
Press halfway down on the button to auto
focus and press all the way down to take a
photo.
19. Camera Control Dial
For zoom control.
DJI Mavic 3
User Manual
11
©
2021 DJI All Rights Reserved.
10
9
6
5
8
3
2
7
1
4
11
12
13
14
15
20. Air Vent
Used for heat dissipation. Do not block the
air vent during usage.
21. Control Sticks Storage Slot
For storing the control sticks.
22. Customizable C1 Button
Switch between recentering the gimbal and
pointing the gimbal downward. The function
can be set in DJI Fly.
23. Speaker
Outputs sound.
24. Customizable C2 Button
Press once to turn the Auxiliary Bottom Light
on or off. The function can be set in DJI Fly.
25. Air Intake
Used for heat dissipation. DO NOT cover the
air intake during use.
RC-N1
1. Power Button
Press once to check the current battery level.
Press once, then again, and hold to power the
remote controller on or off.
2. Flight Mode Switch
Switch between Sport, Normal, and Cine
mode.
3. Flight Pause/Return to Home (RTH) Button
Press once to make the aircraft brake and
hover in place (only when GNSS or Vision
Systems are available). Press and hold the
button to initiate RTH. Press again to cancel
RTH.
4. Battery Level LEDs
Displays the current battery level of the remote
controller.
5. Control Sticks
Use the control sticks to control the aircraft
movements. Set the flight control mode in DJI
Fly. The control sticks are removable and easy
to store.
6. Customizable Button
Press once to turn the Auxiliary Bottom Light
on or off. Press twice to recenter the gimbal or
tilt the gimbal downward (default settings). The
button can be set in DJI Fly.
20
21
24
23
22
25
DJI Mavic 3
User Manual
12
©
2021 DJI All Rights Reserved.
7. Photo/Video Toggle
Press once to switch between photo and
video mode.
8. Remote Controller Cable
Connect to a mobile device for video linking
via the remote controller cable. Select the
cable according to the mobile device.
9. Mobile Device Holder
Used to securely mount the mobile device to
the remote controller.
10. Antennas
Relay aircraft control and video wireless
signals.
11. USB-C Port
For charging and connecting the remote
controller to the computer.
12. Control Sticks Storage Slot
For storing the control sticks.
13. Gimbal Dial
Controls the tilt of the camera. Press and hold
the customizable button to use the gimbal dial
to adjust the zoom in Explore Mode.
14.
S
hut
t
er
/
R
ecor
d
B
ut
t
on
Press once to take photos or start or stop
recording.
15. Mobile Device Slot
Used to secure the mobile device.
13
©
2021 DJI All Rights Reserved.
Aircraft
DJI Mavic 3 contains a flight controller,
video downlink system, vision systems,
infrared sensing system, propulsion
system, and an Intelligent Flight Battery.
14
©
2021 DJI All Rights Reserved.
Aircraft
DJI Mavic 3 contains a flight controller, video downlink system, vision systems, infrared sensing system,
propulsion system, and an Intelligent Flight Battery.
Flight Modes
DJI Mavic 3 has three flight modes, plus a fourth flight mode that the aircraft switches to in certain
scenarios. Flight modes can be switched via the Flight Mode switch on the remote controller.
Normal Mode: The aircraft utilizes GNSS and the Forward, Backward, Lateral, Upward, and Downward
Vision Systems and Infrared Sensing System to locate and stabilize itself. When the GNSS signal is
strong, the aircraft uses GNSS to locate and stabilize itself. When the GNSS is weak but the lighting and
other environment conditions are sufficient, the aircraft uses the vision systems to locate and stabilize
itself. When the Forward, Backward, Lateral, Upward, and Downward Vision Systems are enabled and
lighting and other environment conditions are sufficient, the maximum tilt angle is 30° and the maximum
flight speed is 15 m/s.
Sport Mode: In Sport Mode, the aircraft uses GNSS for positioning and the aircraft responses are
optimized for agility and speed making it more responsive to control stick movements. Note that
obstacle sensing is disabled and the maximum flight speed is 21 m/s (19 m/s when flying in the EU).
Cine Mode: Cine mode is based on Normal mode and the flight speed is limited, making the aircraft
more stable during shooting.
The aircraft automatically changes to Attitude (ATTI) mode when the Vision Systems are unavailable or
disabled and when the GNSS signal is weak or the compass experiences interference. In ATTI mode,
the aircraft may be more easily affected by its surroundings. Environmental factors such as wind can
result in horizontal shifting, which may present hazards, especially when flying in confined spaces.
The Forward, Backward, Lateral, and Upward Vision Systems are disabled in Sport mode, which
means the aircraft cannot sense obstacles on its route automatically.
The maximum speed and braking distance of the aircraft significantly increase in Sport mode. A
minimum braking distance of 30 m is required in windless conditions.
A minimum braking distance of 10 m is required in windless conditions while the aircraft is ascending
and descending.
The responsiveness of the aircraft significantly increases in Sport mode, which means a small control
stick movement on the remote controller translates into the aircraft moving a large distance. Make
sure to maintain adequate maneuvering space during flight.
DJI Mavic 3
User Manual
15
©
2021 DJI All Rights Reserved.
DJI Mavic 3 has front LEDs and aircraft status indicators.
Front LED
Front LED
Aircraft Status Indicator
Aircraft Status Indicator
When the aircraft is powered on but the motors are not running, the front LEDs glow solid red to
display the orientation of the aircraft.
When the aircraft is powered on but the motors are not running, the aircraft status indicators display
the status of the flight control system. Refer to the table below for more information about the aircraft
status indicators.
Aircraft Status Indicator States
Alternating red, green,
and yellow
Blinks
Turning on and performing self-
diagnostic tests
After the motor starts, the front LEDs blink red and green alternately and the aircraft status indicators
blink green.
To obtain better footage, the front LEDs turn off automatically when shooting if the front LEDs are
s
e
t
t
o
a
ut
o
i
n
D
J
I
Fl
y.
Li
ght
i
ng
r
e
q
ui
r
eme
nt
s
va
r
y
d
e
p
e
nd
i
ng
on
r
e
gi
on.
Obs
e
r
ve
l
oc
a
l
l
a
ws
a
nd
regulations.
Yellow
Blinks quickly
Remote controller signal lost
Red
Blinks quickly
Critically low battery
Alternating red and yellow
Blinks quickly
Compass calibration required
—— Red Solid
Critical error
Red
Blinks slowly
Low battery
Warning States
Green
Blinks slowly
GNSS enabled
Yellow
Blinks slowly
NO GNSS or Vision Systems
×2 Green Periodically blinks twice
Vision Systems enabled
×4 Yellow Blinks four times
Warming up
Normal States
Aircraft Status Indicators
DJI Mavic 3
User Manual
16
©
2021 DJI All Rights Reserved.
Return to Home
Return to Home (RTH) returns the aircraft to the last recorded Home Point when the positioning system
is functioning normally. There are three types of RTH: Smart RTH, Low Battery RTH, and Failsafe RTH.
The aircraft automatically flies back to the Home Point and lands when Smart RTH is initiated, the
aircraft enters Low Battery RTH, or the video link signal is lost during flight.
GNSS
Description
Home
Point
10
The default Home Point is the first location where the aircraft received a
strong to moderately strong GNSS signal where the icon is white. The Home
Point can be updated before takeoff as long as the aircraft receives a strong
to moderately strong GNSS. If the GNSS signal is weak then the Home Point
cannot be updated.
Smart RTH
If the GNSS signal is sufficient, Smart RTH can be used to bring the aircraft back to the Home Point.
Smart RTH is initiated either by tapping
in DJI Fly or by pressing and holding the RTH button on the
remote controller until it beeps. Exit Smart RTH by tapping in DJI Fly or by pressing the RTH button
on the remote controller.
Advanced RTH
Advanced RTH is enabled if the lighting is sufficient and the environment is suitable for vision systems
when Smart RTH triggered. The aircraft will automatically plan the best RTH path, which will be
displayed in DJI Fly and will adjust according to the environment.
RTH Settings
RTH settings are available for Advanced RTH. Go the camera view in DJI Fly, tap System, Safety, and
then RTH.
1.
Optimal: Regardless of the RTH Altitude settings, the aircraft automatically plans the optimal RTH
path and adjusts the altitude according to environmental factors such as obstacles and transmission
signals. The optimal RTH path means the aircraft will travel the shortest distance possible reducing
the amount of battery power used and increasing flight time.
2.
Preset: When the aircraft is further than 50 m from the home point when RTH begins, the aircraft
will plan the RTH path, fly to an open area while avoiding obstacles, ascend to the RTH Altitude,
and return to home using the best path. When the aircraft is a distance of 5 to 50 m from the home
point when RTH begins, the aircraft will not ascend to the RTH Altitude and instead return to home
using the best path at the current altitude. When the aircraft is near the home point, the aircraft will
descend while flying forward if the current altitude is higher than the RTH Altitude.
Advanced RTH Procedure
1.
The Home Point is recorded.
2.
Advanced RTH is triggered.
3.
The aircraft brakes and hover in place.
a. The aircraft lands immediately if it is less than 5 m from the Home Point when RTH begins.
b.
If the aircraft is farther than 5 m from the home point when RTH begins, the aircraft will plan the
best path according to the RTH settings and fly to the home point while avoiding obstacles and
GEO zones. The aircraft front will always point in the same direction as the flight direction.
DJI Mavic 3
User Manual
17
©
2021 DJI All Rights Reserved.
During Advanced RTH, the aircraft will adjust the flight speed automatically to environmental factors
4.
The aircraft will fly automatically according to the RTH settings, environment, and the transmission
signal during RTH.
5.
The aircraft lands and the motors stop after reaching the Home Point.
Straight Line RTH
The aircraft will enter Straight Line RTH when the lighting is not sufficient and the environment is not
suitable for the Advanced RTH.
Straight Line RTH Procedure:
1.
The Home Point is recorded.
2.
Straight Line RTH is triggered.
3.
The aircraft brakes and hover in place.
a.
If the aircraft is farther than 50 m from the Home Point when RTH begins, the aircraft adjusts its
orientation and ascends to the preset RTH altitude and flies to the Home Point. If the current
altitude is higher than the RTH altitude, the aircraft flies to the Home Point at the current altitude.
b.
If the aircraft is at a distance of 5 to 50 m from the Home Point when RTH begins, the aircraft
adjusts its orientation and flies to the Home Point at the current altitude. If the current altitude is
lower than 2 m when RTH begins, the aircraft will ascend to 2 m and files to the Home Point.
c. The aircraft lands immediately if it is less than 5 m from the Home Point when RTH begins.
4.
The aircraft lands and the motors stop after reaching the Home Point.
such as wind speed and obstacles.
The aircraft cannot avoid small or fine objects such as tree branches or power lines. Fly the aircraft to
an open area before using Smart RTH.
Set Advanced RTH as Preset if there are power lines or towers that the aircraft cannot avoid on the
RTH path and make sure the RTH Altitude is set higher than all obstacles.
The aircraft will brake and return to home according to the latest settings if the RTH settings are
changed during RTH.
If the max altitude is set below the current altitude during RTH, the aircraft will descend to the max
altitude and return to home.
The RTH Altitude cannot be changed during RTH.
If there is a large difference in the current altitude and the RTH altitude, the amount of battery power
used cannot be calculated accurately due to wind speeds at different altitudes. Pay extra attention to
the battery power and warning prompts in DJI Fly.
Advanced RTH will not be available if the lighting condition and environment were not suitable for
vision systems during takeoff or RTH.
DJI Mavic 3
User Manual
18
©
2021 DJI All Rights Reserved.
During Advanced RTH, the aircraft will enter Straight Line RTH if the lighting condition and
environment was not suitable for vision systems and the aircraft cannot avoid obstacles. An
appropriate RTH altitude must be set before entering RTH.
When the remote controller signal is normal during Advanced RTH, the pitch stick can be used to
control the flight speed but the orientation and altitude cannot be controlled and the aircraft cannot
be flown left or right. Acceleration uses more power. The aircraft cannot avoid obstacles if the flight
speed exceeds the effective sensing speed. The aircraft will brake and hover in place and exit from
RTH if the pitch stick is pulled all the way down. The aircraft can be controlled after the pitch stick is
released.
When ascending in Straight Line RTH, the aircraft will stop ascending and exit from RTH if the throttle
stick is pulled all the way down. The aircraft can be controlled after the throttle stick is released.
When flying forward in Straight Line RTH, the aircraft will brake and hover in place and exit from
RTH if the pitch stick is pulled all the way down. The aircraft can be controlled after the pitch stick is
released.
If the aircraft reaches the max altitude while it is ascending during RTH, the aircraft stops and returns
to the Home Point at the current altitude.
The aircraft will hover in place if it reaches the max altitude while it is ascending after detecting
obstacles in front.
During Straight Line RTH, the speed and altitude of the aircraft can be controlled using the remote
controller if the remote controller signal is normal. The orientation of the aircraft and the direction of
flight, however, cannot be controlled. The aircraft cannot avoid obstacles if the pitch stick is used to
accelerate and the flight speed exceeds the effective sensing speed.
Low Battery RTH
Low Battery RTH is triggered when the Intelligent Flight Battery is depleted to the point that the safe
return of the aircraft may be affected. Return home or land the aircraft immediately when prompted.
In order to avoid unnecessary danger due to insufficient power, the aircraft automatically calculates if the
battery power is sufficient to return to the Home Point according to the current position, environment,
and flight speed. A warning prompt will appear in DJI Fly when the battery level is low and the aircraft
can only support Low Battery RTH.
The user can cancel RTH by pressing the RTH button on the remote controller. If RTH is cancelled
following a low battery level warning, the Intelligent Flight Battery may not have enough power for the
aircraft to land safely, which may lead to the aircraft crashing or being lost.
The aircraft will land automatically if the current battery level can only support the aircraft long enough
to descend from its current altitude. Auto landing cannot be canceled but the remote controller can be
used to alter the direction and the speed of descent of the aircraft during landing. The throttle stick can
be used to increase the ascent speed by 1 m/s if there is sufficient power. The throttle stick cannot be
used to increase the ascent speed and the aircraft will land if there is no power left.
During auto landing, find an appropriate place to land the aircraft as soon as possible. The aircraft will
fall if there is no power remaining.
Failsafe RTH
If the Home Point was successfully recorded and the compass is functioning normally, Failsafe RTH
automatically activates after the remote controller signal is lost for more than six seconds. Note that the
action the aircraft performs when the remote controller is lost must be set to Return to Home in DJI Fly.
When the lighting is sufficient and the vision systems are working normally, DJI Fly will display the RTH
path that was generated by the aircraft before the remote controller signal was lost and return to home
using Advanced RTH according to the RTH settings. The aircraft will remain in RTH even if the remote
DJI Mavic 3
User Manual
19
©
2021 DJI All Rights Reserved.
If the RTH is triggered through DJI Fly and the aircraft is farther than 5 m from the Home Point, a
controller signal is restored.
When the lighting is not sufficient and the vision systems are not available, the aircraft will enter Original
Route RTH.
Original Route RTH Procedure:
1.
The aircraft brakes and hover in place.
2. a. If the aircraft is farther than 50 m from the Home Point, the aircraft adjust its orientation and flies
backwards for 50 m on its original flight route before entering Straight Line RTH.
b. If the aircraft is farther than 5 m but less than 50 m from the Home Point, it enters Straight Line
RTH.
c. The aircraft lands immediately if it is less than 5 m from the Home Point when RTH begins.
3.
The aircraft lands and the motors stop after reaching the Home Point.
The aircraft will enter or remain in Straight Line RTH even if the remote controller signal is restored during
Original Route RTH.
prompt will appear in the app to select a landing option.
The aircraft may not be able to return to the Home Point normally if the GNSS signal is weak or
unavailable. The aircraft may enter ATTI mode if the GNSS signal becomes weak or unavailable after
entering Failsafe RTH. The aircraft will hover in place for a while before landing.
It is important to set a suitable RTH altitude before each flight. Launch DJI Fly and set the RTH
altitude. The default RTH altitude is 100 m.
The aircraft cannot avoid obstacles during Failsafe RTH if the vision systems are unavailable.
GEO zones may affect the RTH. Avoid flying near GEO zones.
The aircraft may not be able to return to a Home Point when the wind speed is too high. Fly with caution.
Be aware of small or fine objects (such as tree branches or power lines) or transparent objects (such
as water or glass) during RTH. Exit RTH and control the aircraft manually in an emergency.
RTH may not be available in some environments even if the vision systems are working. The aircraft
will exit RTH in such cases.
Landing Protection
Landing Protection will activate during Smart RTH. When aircraft begins landing, Landing Protection is
enabled.
1.
During Landing Protection, the aircraft will automatically detect and carefully land on suitable ground.
2.
If the ground is determined unsuitable for landing, the aircraft will hover and wait for pilot
confirmation.
3.
If Landing Protection is not operational, DJI Fly will display a landing prompt when the aircraft
descends below 0.5 m. Pull down on the throttle stick or use the auto landing slider to land.
Precision Landing
The aircraft automatically scans and attempts to match the terrain features below during RTH. The
aircraft will land when the current terrain matches the Home Point. A prompt will appear in DJI Fly if the
terrain match fails.
DJI Mavic 3
User Manual
20
©
2021 DJI All Rights Reserved.
Landing Protection is activated during Precision Landing.
The Precision Landing performance is subject to the following conditions:
a.
The Home Point must be recorded upon takeoff and must not be changed during flight.
Otherwise, the aircraft will have no record of the Home Point terrain features.
b.
During takeoff, the aircraft must ascend at least 7 m before flying horizontally.
c.
The Home Point terrain features must remain largely unchanged.
d.
The terrain features of the Home Point must be sufficiently distinctive. Terrain such as snow-
covered areas are not suitable.
e.
The lighting conditions must not be too light or too dark.
The following actions are available during Precision Landing:
a. Press the throttle stick down to accelerate landing.
b.
Move the control sticks in any direction apart from the throttle direction to stop Precision Landing.
The aircraft will descend vertically after the control sticks are released.
DJI Mavic 3
User Manual
21
©
2021 DJI All Rights Reserved.
90° 90°
85° 85°
Vision Systems and Infrared Sensing System
DJI Mavic 3 is equipped with both an Infrared Sensing System and Forward, Backward, Lateral,
Upward, and Downward Vision Systems.
The Upward and Downward Vision Systems consist of two cameras each, and the Forward, Backward,
and Lateral Vision Systems consist of four cameras in total.
The Infrared Sensing System consists of two 3D infrared modules. The Downward Vision System and
Infrared Sensing System helps the aircraft maintain its current position, hover in place more precisely,
and to fly indoors or in other environments where GNSS is unavailable.
In addition, the Auxiliary Bottom Light located on the underside of the aircraft improves visibility for the
Downward Vision System in weak light conditions.
Horizontal Omnidirectional Vision System
Infrared Sensing System
Auxiliary Bottom Light
Downward Vision System
Detection Range
Forward Vision System
Precision Measurement Range: 0.5-20 m; FOV: 90° (horizontal), 103° (vertical)
Backward Vision System
Precision Measurement Range: 0.5-16 m; FOV: 90° (horizontal), 103° (vertical)
Lateral Vision System
Precision Measurement Range: 0.5-25 m; FOV: 90° (horizontal), 85° (vertical)
Upward Vision System
Precision Measurement Range: 0.2-10 m; FOV: 100° (front and back), 90° (left and right)
Downward Vision System
Precision Measurement Range: 0.3-18 m; FOV: 130° (front and back), 160° (left and right). The
Downward Vision System works best when the aircraft is at an altitude of 0.5 to 30 m.
0.5-20 m
160°
0.5-30 m
0.2-10 m
100°
103°
103°
130° 130°
90° 90°
90° 90°
90° 90°
90° 90°
0.5-16 m
Upward Vision System
Horizontal Omnidirectional
Vision System
0.5-25 m
0.5-25 m
DJI Mavic 3
User Manual
22
©
2021 DJI All Rights Reserved.
Vision Systems have limited ability to sense and avoid obstacles, and the performance may be
Using the Vision Systems
When GNSS is unavailable, the Downward Vision System is enabled if the surface has a clear texture
and sufficient light.
The Forward, Backward, Lateral, and Upward Vision Systems will activate automatically when the
aircraft is powered on if the aircraft is in Normal or Cine mode and Obstacle Avoidance is set to Bypass
or Brake in DJI Fly. The aircraft can actively brake when detecting obstacles when using the Forward,
Backward, Lateral, and Upward Vision Systems. The Forward, Backward, Lateral, and Upward Vision
Systems work best with adequate lighting and clearly marked or textured obstacles. Due to inertia,
users must make sure to brake the aircraft within a reasonable distance.
affected by the surrounding environment. Make sure to maintain visual line of sight with the aircraft
and pay attention to prompts in DJI Fly.
The Downward Vision Systems work best when the aircraft is at an altitude from 0.5 to 30 m if there
is no GNSS available. Extra caution is required if the altitude of the aircraft is above 30 m as the
Vision Systems may be affected.
The Auxiliary Bottom Light can be set in DJI Fly. If set to Auto, it is automatically enabled when the
environment light is too weak. Note that the Vision System cameras performance may be affected
when the Auxiliary Bottom Light is enabled. Fly with caution if the GNSS signal is weak.
The Vision Systems may not function properly when the aircraft is flying over water or snow-covered
areas. Aircraft may not be able to land properly over water. Make sure to maintain visual line of sight
with the aircraft and pay attention to prompts in DJI Fly.
The Vision Systems cannot work properly over surfaces that do not have clear pattern variations. The
Vision Systems cannot work properly in any of the following situations. Operate the aircraft cautiously.
a. Flying over monochrome surfaces (e.g., pure black, pure white, pure green).
b. Flying over highly reflective surfaces.
c. Flying over water or transparent surfaces.
d. Flying over moving surfaces or objects.
e. Flying in an area where the lighting changes frequently or drastically.
f. Flying over extremely dark (< 10 lux) or bright (> 40,000 lux) surfaces.
g. Flying over surfaces that strongly reflect or absorb infrared waves (e.g., mirrors).
h. Flying over surfaces without clear patterns or texture.
i. Flying over surfaces with repeating identical patterns or textures (e.g., tiles with the same design).
j. Flying over obstacles with small surface areas (e.g., tree branches).
Keep the sensors clean at all times. DO NOT tamper with the sensors. DO NOT use the aircraft in
dusty or humid environments.
Vision System cameras may need to be calibrated after being stored for an extended period. A
prompt will appear in DJI Fly and calibration will be performed automatically.
DO NOT fly when it is raining, foggy, or if there is no clear sight.
Check the following before each takeoff:
a. Make sure there are no stickers or any other obstructions over the Infrared Sensing and Vision Systems.
b.
If there is any dirt, dust, or water on the Infrared Sensing and Vision Systems, clean it with a soft
cloth. Do not use any cleanser that contains alcohol.
c. Contact DJI Support if there is any damage to the glass of the Infrared Sensing and Vision Systems.
DO NOT obstruct the Infrared Sensing System.
DJI Mavic 3
User Manual
23
©
2021 DJI All Rights Reserved.
Intelligent Flight Mode
FocusTrack
FocusTrack includes Spotlight 2.0, Point of Interest 3.0, and ActiveTrack 5.0.
Spotlight 2.0
Control the aircraft manually while the camera remains locked on the subject. The mode supports both
stationary and moving subjects such as vehicles, boats, and people. Move the roll stick to circle the
subject, move the pitch stick to alter the distance from the subject, move the throttle stick to change the
altitude, and move the pan stick to adjust the frame.
In Spotlight mode, the aircraft will hover in place when there is an obstacle detected when the vision
systems are working normally, no matter the behavior is set to Bypass or Brake in DJI Fly. Note that the
vision systems are disabled in Sport mode.
Point of Interest 3.0 (POI 3.0)
The aircraft tracks the subject in a circle based on the radius and flight speed that is set. The mode
supports both static and moving subjects such as vehicles, boats, and people. The max flight speed is
15 m/s and the flight speed may be adjusted dynamically according the actual radius. Move the roll stick
to change the speed, the pitch stick to alter the distance from the subject, the throttle stick to change
the altitude, and the pan stick to adjust the frame.
The aircraft will bypass obstacles in this mode regardless of the settings in DJI Fly when the vision
systems are working normally.
ActiveTrack 5.0
ActiveTrack 5.0 is divided into Trace and Parallel, which support tracking both stationary and moving
subjects such as vehicles, boats, and people. In Sport, Normal, and Cine mode, the maximum flight
speed is 12 m/s when flying forward and backward and 15 m/s when flying left and right. Move the
roll stick to circle the subject, the pitch stick to alter the distance from the subject, the throttle stick to
change the altitude, and the pan stick to adjust the frame.
The aircraft will bypass obstacles in ActiveTrack 5.0 regardless of the settings in DJI Fly.
Trace: The aircraft tracks the subject at a constant distance and altitude with a constant angle with the
direction of the subject. The aircraft can track subjects in eight directions including front, back, left, right,
forward diagonal left, front diagonal right, backward diagonal left, and backward diagonal right. The
direction is set to back by default and this setting is only available when the subject is moving in a stable
direction. The direction of tracking can be adjusted during tracking.
Parallel: The aircraft tracks the subject at a constant angle and distance from the side.
In ActiveTrack, the aircraft maintains a distance of 4-20 m when tracking people with an altitude of 2-20 m
(the optimal distance is 5-10 m and altitude is 2-10 m), and a distance of 6-100 m when tracking vehicles
or boats with an altitude of 6-100 m (the optimal distance is 20-50 m and altitude is 10-50 m). The aircraft
will fly to the supported distance and altitude range if the distance and altitude is out of range when
ActiveTrack begins. Fly the aircraft at the optimal distance and altitude for the best performance.
Using FocusTrack
1.
Take off.
DJI Mavic 3
User Manual
24
©
2021 DJI All Rights Reserved.
Mode N
In Flight
80
12 26
RC
20
只能放置在控件
7.9m/s
1.6m/s
GO
4K 30
EV
H 164.0 m D 108
m
Spotline
POI
1:30:30 +0.7
Mode N
In Flight
80
12 26
RC
20
F
L
R
只能放置在控件
7.9m/s
1.6m/s
GO
B
4K 30
EV
H 164.0 m D 108
m
Spotline
POI
1:30:30 +0.7
2.
Drag a box around the subject in the camera view or enable Subject Scanning under Control settings
in DJI Fly Control and tap the recognized subject to enable FocusTrack. The default mode is Spotlight.
Tap the icon to switch between Spotlight, ActiveTrack, and POI. FocusTrack supports 2x zoom. The
zoom ratio will be limited if it is too large to recognize a subject. Tap GO to start FocusTrack.
3.
In Trace of ActiveTrack, the tracking direction can be changed using the direction wheel. The
direction wheel will be minimized if there is no operation for an extended period or any other area of
the screen is tapped. Trace or Parallel can be selected once the direction wheel is minimized. The
tracking will be reset to back once Trace is selected again.
4.
Tap the shutter/record button to take photos or start recording. View the footage in Playback.
Exiting FocusTrack
Tap Stop in DJI Fly or press the Flight Pause button once on the remote controller to exit FocusTrack.
DO NOT use FocusTrack in areas with people and animals running or vehicles moving.
DO NOT use FocusTrack in areas with small or fine objects (e.g., tree branches or power lines), or
transparent objects (e.g., water or glass).
Operate the aircraft manually. Press the Flight Pause button or tap stop in DJI Fly in an emergency.
DJI Mavic 3
User Manual
25
©
2021 DJI All Rights Reserved.
2 m
Mode N
In-Flight
80
24 17
RC
20
Video
1x
Start
Super
S
A
ho
F
t
Timelapes
Be extra vigilant when using FocusTrack in any of the following situations:
a. The tracked subject is not moving on a level plane.
b. The tracked subject changes shape drastically while moving.
c.
The tracked subject is out of sight for an extended period.
d. The tracked subject is moving on a snowy surface.
e. The tracked subject has a similar color or pattern to its surrounding environment.
f. The lighting is extremely low (<300 lux) or high (>10,000 lux).
Make sure to follow local privacy laws and regulations when using FocusTrack.
It is recommended to only track vehicles, boats, and people (but not children). Fly with caution when
tracking other subjects.
Do not track a remote control model car or boat.
The tracking subject may inadvertently swap to another subject if they pass nearby to each other.
FocusTrack is disabled in Explore mode, when using a ND filter, or when recording in 5.1K and above
or 120fps and above, and Apple ProRes 422 HQ/422/422LT.
ActiveTrack is unavailable when the lighting is insufficient and the vision systems are unavailable. POI
for static subjects and Spotlight can still be used, but obstacle sensing is not available.
FocusTrack is unavailable when the aircraft is on the ground.
FocusTrack may not function properly when the aircraft is flying near flight limits or in a GEO zone.
MasterShots
MasterShots keeps the subject in the center of the frame while executing different maneuvers in
sequence to generate a short cinematic video.
Using MasterShots
1.
Take off and hover at least 2 m above the ground.
2.
In DJI Fly, tap the shooting mode icon to select MasterShots and follow the prompts. Make sure that
you understand how to use the shooting mode and that there are no obstacles in the surrounding
area.
3.
Select your target subject in the camera view by tapping the circle on the subject or dragging a box
around the subject. Tap Start to begin recording. The aircraft flies back to its original position once
shooting is finished.
DJI Mavic 3
User Manual
26
©
2021 DJI All Rights Reserved.
Mode N
In-Flight
80
24 17
RC
20
Free
Circle
Video
1x
AF
Super Shot
Course
00:10:20
124
Timelapes
4.
Tap
to access the video.
Exiting MasterShots
Press the Flight Pause button once or tap
in DJI Fly to exit MasterShots. The aircraft will hover in place.
Use MasterShots at locations that are clear of buildings and other obstacles. Make sure that there
are no humans, animals, or other obstacles on the flight path. When the lighting is sufficient and
the environment is suitable for vision systems, the aircraft will brake and hover in place if there is an
obstacle detected.
Pay attention to objects around the aircraft and use the remote controller to avoid collisions with the
aircraft.
DO NOT use MasterShots in any of the following situations:
a.
When the subject is blocked for an extended period or outside the line of sight.
b.
When the subject is similar in color or pattern with the surroundings.
c.
When the subject is in the air.
d. When the subject moves fast.
e. The lighting is extremely low (<300 lux) or high (>10,000 lux).
DO NOT use MasterShots in places that are close to buildings or where the GNSS signal is weak.
Otherwise, the flight path will be unstable.
Make sure to follow local privacy laws and regulations when using MasterShots.
Hyperlapse
Hyperlapse shooting modes include Free, Circle, Course Lock, and Waypoint.
Free
The aircraft automatically takes photos and generates a timelapse video. Free mode can be used while
the aircraft is on the ground. After takeoff, control the movement and gimbal angle of the aircraft using
the remote controller. Follow the steps below to use Free:
1. Set the interval time, video duration, and max speed. The screen displays the number of photos that
will be taken and how long the shooting time will be.
2. Tap the shutter/record button to begin.
Cruise Control: Set the function of the Customizable button (C1 or C2 button for DJI RC Pro and Fn
button for DJI RC-N1 remote controller) to Cruise Control and press the Customizable button and
control stick at the same time to enter Cruise Control. The aircraft will continue to fly at the same speed.
DJI Mavic 3
User Manual
27
©
2021 DJI All Rights Reserved.
Circle
The aircraft automatically takes photos while flying around the selected subject to generate a timelapse
video. Follow the steps below to use Circle:
1.
Set the interval time, video duration, and max speed. Circle can be selected to travel in either a
clockwise or counter-clockwise direction. The screen displays the number of photos that will be
taken and how long the shooting time will be.
2.
Select a subject on the screen. Use the pan stick and gimbal dial to adjust the frame.
3.
Tap the shutter/record button to begin.
Course Lock
Course Lock can be used in two ways. In the first way, the orientation of the aircraft is fixed, but a
subject cannot be selected. In the second way, the orientation of the aircraft is fixed and the aircraft flies
around a selected object. Follow the steps below to use Course Lock:
1. Set the interval time, video duration, and max speed. The screen displays the number of photos that
will be taken and how long the shooting time will be.
2.
Set a flight direction.
3. If applicable, select a subject. Use the gimbal dial and pan stick to adjust the frame.
4. Tap the shutter/record button to begin.
Waypoints
The aircraft automatically takes photos on a flight path of two to five waypoints and generates a
timelapse video. The aircraft can fly in order from waypoint 1 to 5 or 5 to 1. Follow the steps below to
use Waypoints.
1.
Set the desired waypoints and the lens direction.
2. Set the interval time, video duration, and max speed. The screen displays the number of photos that
will be taken and how long the shooting time will be.
3.
Tap the shutter button to begin.
The aircraft will generate a timelapse video automatically, which is viewable in playback. In the camera
settings, users can select to save the footage in JPEG or RAW format and to store the footage in the
built-in storage or the microSD card.
For optimal performance, it is recommended to use Hyperlapse at an altitude higher than 50 m and
to set a difference of at least two seconds between the interval time and shutter.
It is recommended to select a static subject (e.g., high-rise buildings, mountainous terrain) at a safe
distance from the aircraft (farther than 15 m). Do not select a subject that is too near the aircraft.
When the lighting is sufficient and the environment is suitable for vision systems, the aircraft brakes
and hovers in place if an obstacle is detected during Hyperlapse. If the lighting becomes insufficient
or the environment is not suitable for vision systems during Hyperlapse, the aircraft will continue to
shoot without obstacle avoidance. Fly with caution.
The aircraft only generates a video if it has taken at least 25 photos, which is the amount required
to generate a one second video. The video is generated when a user command is received from the
remote controller or if the mode is exited unexpectedly such as when Low Battery RTH is triggered.
DJI Mavic 3
User Manual
28
©
2021 DJI All Rights Reserved.
2 m
QuickShots
QuickShots shooting modes include Dronie, Rocket, Circle, Helix, Boomerang, and Asteroid. Mavic 3
records according to the selected shooting mode and automatically generates a short video. The video
can be viewed, edited, or shared to social media from playback.
Dronie: The aircraft flies backward and ascends, with the camera locked on the subject.
Rocket: The aircraft ascends with the camera pointing downward.
Circle: The aircraft circles around the subject.
Helix: The aircraft ascends and spirals around the subject.
Boomerang: The aircraft flies around the subject in an oval path, ascending as it flies away from
its starting point and descending as it flies back. The starting point of the aircraft forms one
end of the long axis of the oval while the other end of the long axis is at the opposite side of the
subject from the starting point. Make sure there is sufficient space when using Boomerang. Allow
a radius of at least 30 m around the aircraft and allow at least 10 m above the aircraft.
Asteroid: The aircraft flies backward and upward, takes several photos, and then flies back to
the starting point. The video generated starts with a panorama of the highest position and then
shows the descent. Make sure there is sufficient space when using Asteroid. Allow at least 40 m
behind and 50 m above the aircraft.
Using QuickShots
1.
Take off and hover at least 2 m above the ground.
2.
In DJI Fly, tap the shooting mode icon to select QuickShots and follow the prompts. Make sure that
you understand how to use the shooting mode and that there are no obstacles in the surrounding
area.
3.
Select your target subject in the camera view by tapping the circle on the subject or dragging a box
around the subject. Choose a shooting mode and tap Start to begin recording.
DJI Mavic 3
User Manual
29
©
2021 DJI All Rights Reserved.
4.
Tap
to access the video.
Exiting QuickShots
Press the Flight Pause button once or tap in DJI Fly to exit QuickShots. The aircraft will hover in
place.
Use QuickShots at locations that are clear of buildings and other obstacles. Make sure that there are
no humans, animals, or other obstacles on the flight path. The aircraft will brake and hover in place if
there is an obstacle detected.
Pay attention to objects around the aircraft and use the remote controller to avoid collisions with the
aircraft.
DO NOT use QuickShots in any of the following situations:
a.
When the subject is blocked for an extended period or outside the line of sight.
b.
When the subject is more than 50 m away from the aircraft.
c.
When the subject is similar in color or pattern with the surroundings.
d. When the subject is in the air.
e. When the subject moves fast.
f. The lighting is extremely low (<300 lux) or high (>10,000 lux).
DO NOT use QuickShots in places that are close to buildings or where the GNSS signal is weak.
Otherwise, the flight path will be unstable.
Make sure to follow local privacy laws and regulations when using QuickShots.
Mode N In-Flight
80
24 17
RC
20
Rocket
Video
Dronie
Start
Quickshot
Circle
Timelapes
7.9m/s 1.6m/s
H 126m D 1014.4m
EV AE
+1.0
DJI Mavic 3
User Manual
30
©
2021 DJI All Rights Reserved.
Flight Recorder
The Advanced Pilot Assistance Systems 5.0 (APAS 5.0) feature is available in Normal and Cine mode.
When APAS is enabled, the aircraft continues to respond to user commands and plans its path according
to control stick inputs and the flight environment. APAS makes it easier to avoid obstacles, obtain
smoother footage, and gives a better flying experience.
Keep moving the control sticks in any directions. The aircraft will avoid the obstacles by flying above,
below, or to the left or right of the obstacle. The aircraft can also response to the control stick inputs while
avoiding obstacles.
When APAS is enabled, the aircraft can be stopped by pressing the Flight Pause button on the remote
controller or tapping the screen in DJI Fly. The aircraft hovers for three seconds and awaits further pilot
commands.
To enable APAS, open DJI Fly, enter System Settings, then Safety, and enable APAS by selecting Bypass.
Select Normal or Nifty mode when using Bypass. Nifty mode, the aircraft can fly faster, smoother, and
closer to obstacles obtaining better footage while avoiding obstacles. Meanwhile, the risk of crashing with
the obstacles increases. Fly with caution.
Nifty cannot work normally in the following situations:
1.
When aircraft orientation changes rapidly flying near obstacles when using Bypass.
2.
When flying through narrow obstacles such as canopies or bushes at high speed.
3.
When flying near obstacles that are too small to detect.
4.
When flying with the propeller guard.
Landing Protection
Landing Protection will activate if Obstacle Avoidance is set to Bypass or Brake and the user pulls the
throttle stick down to land the aircraft. Landing Protection is enabled once the aircraft begins to land.
1.
During Landing Protection, the aircraft will automatically detect and carefully land on suitable ground.
2.
If the ground is determined unsuitable for landing, the aircraft will hover when the aircraft descends
below 0.8 m. Pull down on the throttle stick for more than five seconds and the aircraft will land
without obstacle avoidance.
Make sure you use APAS when the vision systems are available. Make sure there are no people,
animals, objects with small surface areas (such as tree branches), or objects with transparent
surfaces (such as glass or water) along the flight path.
Make sure you use APAS when the Downward Vision System is available or the GNSS signal is
strong. APAS may not function properly when the aircraft is flying over water or snow-covered areas.
Be extra cautious when flying in extremely dark (<300 lux) or bright (>10,000 lux) environments.
Pay attention to DJI Fly and make sure APAS is working normally.
APAS may not function properly when the aircraft is flying near flight limits or in a GEO zone.
Flight data including flight telemetry, aircraft status information, and other parameters are automatically
saved to the internal data recorder of the aircraft. The data can be accessed using DJI Assistant 2
(Consumer Drones Series).
Advanced Pilot Assistance Systems (APAS 5.0)
DJI Mavic 3
User Manual
31
©
2021 DJI All Rights Reserved.
Mavic 3 can connect directly to mobile devices via Wi-Fi, enabling users to download photos and videos
from the aircraft to the mobile device through DJI Fly without the need of the RC-N1 remote controller.
Users can enjoy faster and more convenient downloads with a transmission rate of up to 80 MB/s.
Usage
Method 1: mobile device is not connected to the remote controller
1.
Power on the aircraft and wait until the self-diagnostic tests of the aircraft are complete.
2.
Make sure Bluetooth and Wi-Fi is enabled on the mobile device. Launch DJI Fly and a prompt will
automatically appear to connect to the aircraft.
3.
Tap Connect. Once successfully connected, the files on the aircraft can be accessed and
downloaded at a high speed.
Method 2: mobile device is connected to the remote controller
1.
Make sure that the aircraft is connected to the mobile device via the remote controller and the
motors have not started.
2.
Enable Bluetooth and Wi-Fi on the mobile device.
3.
Launch DJI Fly, enter playback, and tap in the upper right corner to access the files on the aircraft to
download at high speed.
DJI RC Pro cannot support QuickTransfer.
The maximum download speed can only be achieved in countries and regions where the 5.8
GHz frequency is permitted by laws and regulations, when using devices that support 5.8 GHz
frequency band and Wi-Fi 6 connection, with the footage using the internal storage of aircraft, and
in an environment without interference or obstruction. If 5.8 GHz is not allowed by local regulations
(such as in Japan), the mobile device of the user will not support the 5.8 GHz frequency band or the
environment will have severe interference. Under these circumstances, QuickTransfer will use the 2.4
GHz frequency band and its maximum download rate will reduce to 10 MB/s.
Make sure that Bluetooth, Wi-Fi, and location services are enabled on the mobile device before using
QuickTransfer.
When using QuickTransfer, it is not necessary to enter the Wi-Fi password on the settings page
of the mobile device in order to connect. Launch DJI Fly and a prompt will appear to connect the
aircraft.
Use QuickTransfer in an unobstructed environment with no interference and stay away from sources
of interference such as wireless routers, Bluetooth speakers, or headphones.
QuickTransfer
DJI Mavic 3
User Manual
32
©
2021 DJI All Rights Reserved.
B
A
A
B
1
2
There are two types of DJI Mavic 3 Low-Noise Quick Release Propellers, which are designed to spin in
different directions. Marks are used to indicate which propellers should be attached to which motors.
Make sure to match the propeller and motor following the instructions.
Attaching the Propellers
Attach the propellers with marks to the motors with marks and the unmarked propellers to the motors
without marks. Press each propeller down onto the motor and turn until it is secure.
Detaching the Propellers
Press the propellers down onto the motors and rotate them in the unlock direction.
Propeller blades are sharp. Handle with care.
Only use official DJI propellers. DO NOT mix propeller types.
Purchase the propellers separately if necessary.
Make sure that the propellers are installed securely before each flight.
Make sure all propellers are in good condition before each flight. DO NOT use aged, chipped, or
broken propellers.
Stay away from the rotating propellers and motors to avoid injuries.
Do not squeeze or bend the propellers during transportation or storage.
Make sure the motors are mounted securely and rotating smoothly. Land the aircraft immediately if a
motor is stuck and unable to rotate freely.
DO NOT attempt to modify the structure of the motors.
DO NOT touch or let your hands or body come in contact with the motors after flight as they may be
hot.
DO NOT block any of the ventilation holes on the motors or the body of the aircraft.
Make sure the ESCs sound normal when powered on.
Propellers
DJI Mavic 3
User Manual
33
©
2021 DJI All Rights Reserved.
The DJI Mavic 3 Intelligent Flight Battery is a 15.4 V, 5000 mAh battery with smart charging and
discharging functionality.
Battery Features
1.
Battery Level Display: The LED indicators display the current battery level.
2.
Auto-Discharging Function: To prevent swelling, the battery automatically discharges to 96% of the
battery level when it is idle for three days, and automatically discharges to 60% of the battery level
when it is idle for nine days. It is normal to feel moderate heat being emitted from the battery during
the discharging process.
3.
Balanced Charging: During charging, the voltages of the battery cells are automatically balanced.
4.
Overcharge Protection: The battery stops charging automatically once fully charged.
5. Temperature Detection: In order to protect itself, the battery only charges when the temperature is
between 5° and 40° C (41° and 104° F).
6.
Overcurrent Protection: The battery stops charging if an excess current is detected.
7. Over-Discharge Protection: Discharging stops automatically to prevent excess discharge when the
battery is not in use. Over-discharge protection is not enabled when the battery is in use.
8.
Short Circuit Protection: The power supply is automatically cut if a short circuit is detected.
9. Battery Cell Damage Protection: DJI Fly displays a warning prompt when a damaged battery cell is
detected.
10. Hibernation Mode: The battery switches off after 20 minutes of inactivity to save power. If the
battery level is less than 5%, the battery enters Hibernation mode to prevent over-discharge after
being idle for six hours. In Hibernation mode, the battery level indicators do not illuminate. Charge
the battery to wake it from hibernation.
11. Communication: Information about the voltage, capacity, and current of the battery is transmitted
to the aircraft.
Refer to the Safety Guidelines and the battery sticker before use. Users take full responsibility for all
operations and usage.
Intelligent Flight Battery
DJI Mavic 3
User Manual
34
©
2021 DJI All Rights Reserved.
: LED is on
: LED is flashing
: LED is off
Battery Level LEDs
Using the Battery
Checking Battery Level
Press the power button once to check the battery level.
L
LED4
LED1
LED2
LED3
LED4
Battery Level
Battery Level ≥ 88%
75% ≤ Battery Level < 88%
63% ≤ Battery Level < 75%
50% ≤ Battery Level < 63%
38% ≤ Battery Level < 50%
25% ≤ Battery Level < 38%
13% ≤ Battery Level < 25%
0% ≤ Battery Level < 13%
Powering On/Off
Press the power button once, then press again, and hold for two seconds to power the battery on or
off. The battery level LEDs display the battery level when the aircraft is powered on.
Low Temperature Notice
1.
Battery capacity is significantly reduced when flying in low-temperature environments of -10° to 5° C
(14° to 41° F). It is recommended to hover the aircraft in place for a while to heat the battery. Make
sure to fully charge the battery before takeoff.
2.
Batteries cannot be used in extremely low-temperature environments of lower than -10° C (14° F).
3.
When in low-temperature environments, end the flight as soon as DJI Fly displays the low battery
level warning.
4.
To ensure the optimal performance of the battery, keep the battery temperature above 20° C (68° F).
5.
The reduced battery capacity in low-temperature environments reduces the wind speed resistance
performance of the aircraft. Fly with caution.
6.
Fly with extra caution at high sea levels.
ED1
LED2
LED3
Power Button
DJI Mavic 3
User Manual
35
©
2021 DJI All Rights Reserved.
Blinking Pattern Description
Blinks yellow
Temperature of batteries too low or too high (no further operation needed)
Charging the Battery
Fully charge the Intelligent Flight Battery before every flight using the provided Mavic 3 Battery Charging
Hub and DJI 65W Portable Charger.
Using Charging Hub
When used with the DJI 65W Portable Charger, the DJI Mavic 3 Battery Charging Hub can charge up
to three Intelligent Flight Batteries in sequence from high to low power level. The charging time for one
battery is approximately 1 hour and 36 minutes.
1 2
3
1.
Status LED Indicator
2. Battery Port
3. Power Port
Usage
1. Insert the Intelligent Flight Battery into the battery port. Connect the charging hub to a power outlet
(100-240 V, 50-60 Hz) using the DJI 65W Portable Charger.
2.
The Intelligent Flight Battery with the highest power level will be charged first and then the rest will be
charged in sequence according to their power levels. Refer to the Status LED Indicator Descriptions
section for more information about the blinking patterns of the status LED indicator. The Intelligent
Flight Battery can be disconnected from the charging hub when charging is complete.
Status LED Indicator Descriptions
Solid yellow
No battery inserted
Solid green
All batteries fully charged
Solid red Power supply or battery error (remove and reinsert the batteries or unplug and
plug in the charger)
It is recommended to use a DJI 65W Portable Charger or DJI Mavic 3 Car Charger when using the
Mavic 3 Battery Charging Hub to charge Mavic 3 Intelligent Flight Batteries.
The charging hub is only compatible with BWX260-5000-15.4 Intelligent Flight Batteries. DO NOT
attempt to use the charging hub with other battery models.
Place the charging hub on a flat and stable surface when in use. Make sure the device is properly
insulated to prevent fire hazards.
DO NOT attempt to touch the metal terminals on the product.
Clean the metal terminals with a clean, dry cloth if there is any noticeable buildup.
Pulses green Charging
DJI Mavic 3
User Manual
36
©
2021 DJI All Rights Reserved.
It is recommended to discharge the Intelligent Flight Batteries to 30% or lower before transportation.
Using DJI 65W Portable Charger
1.
Connect the DJI 65W Portable Charger to an AC power supply (100-240 V, 50/60 Hz).
2.
Attach the aircraft to the charger using the battery charging cable with the battery powered off.
3.
The battery level LEDs display the current battery level during charging.
4.
The Intelligent Flight Battery is fully charged when all the battery level LEDs are off. Detach the
charger when the battery is fully charged.
DO NOT charge an Intelligent Flight Battery immediately after flight as the temperature may be too
high. Wait until it cools down to room temperature before charging again.
The charger stops charging the battery if the battery cell temperature is not within the operating
range of 5° to 40° C (41° to 104° F). The ideal charging temperature is 22° to 28° C (71.6° to 82.4° F).
Fully charge the battery at least once every three months to maintain battery health.
DJI does not take any responsibility for damage caused by third-party chargers.
This can be done by flying the aircraft outdoors until there is less than 30% charge left.
The table below shows the battery level during charging.
LED1
LED2
LED3
LED4
Battery Level
0% < Battery Level ≤ 50%
50% < Battery Level ≤ 75%
75% < Battery Level < 100%
Fully Charged
Battery Protection Mechanisms
The battery LED indicator can display battery protection prompts triggered by abnormal charging
conditions.
Battery Protection Mechanisms
LED1
LED2
LED3
LED4
Blinking Pattern
Status
LED2 blinks twice per second
Overcurrent detected
LED2 blinks three times per second
Short circuit detected
LED3 blinks twice per second
Overcharge detected
LED3 blinks three times per second
Over-voltage charger detected
LED4 blinks twice per second
Charging temperature is too low
LED4 blinks three times per second
Charging temperature is too high
DJI Mavic 3
User Manual
37
©
2021 DJI All Rights Reserved.
Click
1
2
If the battery protection mechanisms activate, in order to resume charging it is necessary to unplug
the battery from the charger and plug it in again. If the charging temperature is abnormal, wait for the
charging temperature to return to normal, and the battery will automatically resume charging without
requiring to unplug and plug in the charger again.
Inserting the Intelligent Flight Battery
Insert the Intelligent Flight Battery into the battery compartment of the aircraft. Make sure it is mounted
securely and that the battery buckles click into place.
Removing the Intelligent Flight Battery
Press the textured part of the battery buckles on the sides of the Intelligent Flight Battery to remove it
from the compartment.
DO NOT detach the battery when the aircraft is powering on.
Make sure that the battery is mounted firmly.
DJI Mavic 3
User Manual
38
©
2021 DJI All Rights Reserved.
Gimbal and Camera
Gimbal Profile
The 3-axis gimbal of DJI Mavic 3 provides stabilization for the camera, allowing you to capture clear and
stable images and video. The control tilt range is -90° to +35°.
35°
0°
Use the gimbal dial on the remote controller to control the tilt of the camera. Alternatively, enter the
camera view in DJI Fly. Press the screen until an adjustment bar appears and drag up and down to
control the tilt of the camera.
Gimbal Operation Modes
Two gimbal operation modes are available. Switch between the different operation modes in DJI Fly.
Follow Mode: The angle between the gimbal’s orientation and aircraft front remains constant at all times.
FPV Mode: The gimbal synchronizes with the movement of the aircraft to provide a first-person flying
experience.
Do not tap or knock the gimbal when the aircraft is powered on. To protect the gimbal during takeoff,
take off from open and flat ground.
Precision elements in the gimbal may be damaged in a collision or impact, which may cause the
gimbal to function abnormally.
Avoid getting dust or sand on the gimbal, especially in the gimbal motors.
A gimbal motor may enter protection mode in the following situations:
a. The aircraft is on uneven ground or the gimbal is obstructed.
b. The gimbal experiences excessive external force, such as during a collision.
DO NOT apply external force to the gimbal after the gimbal is powered on. DO NOT add any extra
payload to the gimbal as this may cause the gimbal to function abnormally or even lead to permanent
motor damage.
Make sure to remove the storage cover before powering on the aircraft. Also, make sure to mount
the storage cover when the aircraft is not in use.
Flying in heavy fog or clouds may make the gimbal wet, leading to temporary failure. The gimbal
recovers full functionality once it is dry.
Gimbal Axes Lock
For more convenient storage, the gimbal axes will automatically lock after the aircraft is powered off and
unlock when it is powered on again. No user operation is required.
-90°
DJI Mavic 3
User Manual
39
©
2021 DJI All Rights Reserved.
The gimbal lock function works normally when the operating temperature is -10° to 40° C (14° to
104° F). It may malfunction outside this temperature range and a prompt will appear in DJI Fly if this
occurs. If the gimbal lock malfunctions when attempting to unlock the gimbal, users can adjust the
gimbal axes manually to unlock the gimbal. It is not recommended to manually adjust the gimbal
axes unless necessary.
If the gimbal lock malfunctions, it will resume normal operation once the operating temperature is
-10° to 40° C (14° to 104° F).
It is normal for the gimbal to unlock if it is impacted in any way. Restart the aircraft to lock the gimbal again.
It is normal for the gimbal to vibrate slightly after it is locked.
Camera Profile
DJI Mavic 3 uses a 4/3-in CMOS sensor Hasselblad L2D-20c camera, which can take 20MP photos
and record at 5.1K 50fps/DCI 4K 120fps Apple ProRes 422 HQ and H.264/H.265 format videos. The
camera also supports 10-bit D-Log video, has an adjustable aperture of f/2.8 to f/11, and can shoot
from 1 m to infinity.
The tele camera boasts a 1/2-in CMOS sensor, capable of shooting 12MP photos with an aperture of
f/4.4 and shooting from 3 m to infinity. When in Explore mode, the tele camera can zoom at 28x.
Make sure the temperature and humidity is suitable for the camera during usage and storage.
Use a lens cleanser to clean the lens to avoid damage.
DO NOT block any ventilation holes on the camera as the heat generated may damage the device
and hurt the user.
Storing Photos and Videos
DJI Mavic 3 has 8 GB of built-in storage and supports the use of a microSD card to store photos and
videos. A SDXC or UHS-I microSD card is required due to the fast read and write speeds necessary for
high-resolution video data. Refer to the Specifications section for more information about recommended
microSD cards.
In addition, DJI Mavic 3 Cine aircraft comes with a built-in 1TB SSD. The footage can be output quickly
via the DJI 10Gbps Lightspeed Data Cable.
Do not remove the microSD card from the aircraft while it is powered on. Otherwise, the microSD
card may be damaged.
To ensure the stability of the camera system, single video recordings are limited to 30 minutes.
Check camera settings before use to ensure they are configured as desired.
Before shooting important photos or videos, shoot a few images to test the camera is operating
correctly.
Photos or videos cannot be transmitted or copied from the camera if the aircraft is powered off.
Make sure to power off the aircraft correctly. Otherwise, your camera parameters will not be saved
and any recorded videos may be damaged. DJI is not responsible for any failure of an image or video
to be recorded or having been recorded in a way that is not machine-readable.
40
©
2021 DJI All Rights Reserved.
Remote Controller
This section describes the features
of the remote controller and includes
instructions for controlling the aircraft
and the camera.
41
©
2021 DJI All Rights Reserved.
Remote Controller
DJI RC Pro
Th
e
D
J
I
R
C
P
r
o
r
em
o
t
e
co
n
tr
o
ll
e
r
f
ea
t
u
r
e
s
O
3
+
,
t
h
e
l
a
t
e
s
t
v
e
r
s
i
o
n
o
f
D
J
I
’
s
s
i
g
n
a
t
u
r
e
O
c
u
S
y
n
c
i
ma
g
e
transmission technology, works at both 2.4 and 5.8 GHz, is capable of selecting the best transmission
channel automatically, and can transmit a live HD view from the camera of the aircraft at a distance of
up to 15 km. The built-in 5.5-in high brightness 1000 cd/m
2
screen boasts a resolution of 1920×1080
pixels while the remote controller comes with a wide range of aircraft and gimbal controls as well as
customizable buttons. Users can connect to the internet via Wi-Fi and the Android 10 operating system
comes with a variety of functions such as Bluetooth and GNSS (GPS+GLONASS+Galileo).
With the built-in speaker, the remote controller supports H.264 4K/120fps and H.265 4K/120fps video,
which also supports video output via the Mini HDMI port. The internal storage of the remote controller is
32 GB and also supports the use of microSD cards to store the photos and videos.
The 5000 mAh and 36 Wh battery provides the RC Pro with a maximum operating time of 3 hours.
Using the Remote Controller
Powering On/Off
Press the power button once to check the current
battery level.
Press and then press again and hold to power
the remote controller on or off.
Charging the Battery
Use a USB-C cable to connect the charger to
the USB-C port of the remote controller.
Controlling the Gimbal and Camera
Focus/Shutter Button: Press halfway down to
auto focus and press all the way down to take
a photo.
Record Button: Press once to start or stop
recording.
Camera Control Dial: Use to adjust the zoom.
Gimbal Dial: Use to adjust the tilt of the gimbal.
Gimbal Dial
Record Button
Camera Control Dial
Focus/Shutter
Button
DJI Mavic 3
User Manual
42
©
2021 DJI All Rights Reserved.
Controlling the Aircraft
Three preprogrammed modes (Mode 1, Mode 2, and Mode 3) are available and custom modes can be
configured in DJI Fly. The default mode is Mode 2.
Mode 1
Left Stick
Turn Left
Forward
Backward
Turn Right
Right Stick
Left
Up
Down
Right
Mode 2
Left Stick
Turn Left
Up
Down
Turn Right
Right Stick
Left
Forward
Backward
Right
Mode 3
Left Stick
Left
Forward
Backward
Right
Right Stick
Turn Left
Up
Down
Turn Right
DJI Mavic 3
User Manual
43
©
2021 DJI All Rights Reserved.
Position Flight Mode
Remote
Controller
(Mode 2)
Aircraft
( Indicates Nose Direction)
Remarks
Moving the left stick up or down changes the
aircraft’s altitude. Push the stick up to ascend and
down to descend. The more the stick is pushed
away from the center position, the faster the
aircraft will change altitude. Push the stick gently
to prevent sudden and unexpected changes in
altitude.
Moving the left stick to the left or right controls
the orientation of the aircraft. Push the stick left to
rotate the aircraft counter-clockwise and right to
rotate the aircraft clockwise. The more the stick is
pushed away from the center position, the faster
the aircraft will rotate.
Moving the right stick up and down changes the
aircraft’s pitch. Push the stick up to fly forward
and down to fly backward. The more the stick is
pushed away from the center position, the faster
the aircraft will move.
Moving the right stick to the left or right changes
the aircraft’s roll. Push the stick left to fly left and
right to fly right. The more the stick is pushed
away from the center position, the faster the
aircraft will move.
Flight Mode Switch
Toggle the switch to select the flight mode.
S Sport Mode
C Cine Mode
N Normal Mode
DJI Mavic 3
User Manual
44
©
2021 DJI All Rights Reserved.
Blinking Pattern Descriptions
Blinks red
The temperature of the remote controller is too high or the battery level of the
aircraft is low
Blinks yellow
The battery level of the remote controller is low
RTH Button
Press and hold the RTH button until the remote controller beeps to start RTH. Press this button again to
cancel RTH and regain control of the aircraft. Refer to the Return to Home section for more information
about RTH.
Customizable Buttons
Including C1, C2, and the 5D button. Go to System Settings in DJI Fly and select Control to customize
the function of the button.
Combination Buttons
Back + Gimbal Dial: Adjust Brightness
Back + Camera Control Dial: Adjust Volume
Back + Record Button: Record Screen
Back + Shutter Button: Screenshot
Back + 5D Button: Up - Home, Down - Shortcut Settings, Left - Recent
Status LED and Battery Level LEDs Description
Status LED
Solid red
Disconnected with aircraft
Solid green
Connected with aircraft
Solid yellow
Firmware update failed
Blinks cyan Control sticks not centered
Battery Level Indicators
Blinking Pattern
Battery Level
75%~100%
50%~75%
25%~50%
0%~25%
Blinks blue
The remote controller is linking to an aircraft
DJI Mavic 3
User Manual
45
©
2021 DJI All Rights Reserved.
Remote Controller Alert
The remote controller vibrates or beeps when there is an error or warning. Pay attention when prompts
appear on the touchscreen or in DJI Fly. Slide down from the top to select Do Not Disturb or Mute to
disable some alerts.
Optimal Transmission Zone
The signal between the aircraft and the remote controller is most reliable when the antennas are
positioned in relation to the aircraft as illustrated below.
The optimal transmission range is where the antennas are facing toward the aircraft and the angle
between the antennas and the back of the remote controller is 180° or 270°.
Do not use other wireless devices operating at the same frequency as the remote controller.
Otherwise, the remote controller will experience interference.
A prompt will be received in DJI Fly if the transmission signal is weak during flight. Adjust the
antennas to make sure that the aircraft is in the optimal transmission range.
Linking the Remote Controller
The aircraft and remote controller must be linked before use. Follow these steps to link a new remote
controller.
Method 1:
1.
Power on the remote controller and the aircraft.
2.
Press the C1, C2, and record button simultaneously until the status LED blinks blue and the remote
controller beeps.
3.
Press and hold the power button of the aircraft for more than four seconds. The aircraft beeps once
to indicate it is ready to link. The aircraft beeps twice to indicate linking is successful. The battery
level LEDs of the remote controller will glow solid.
Method 2:
1.
Power on the remote controller and the aircraft.
2.
Launch DJI Fly.
3.
In camera view, tap
and select Control and Pair to Aircraft (Link).
4.
Press and hold the power button of the aircraft for more than four seconds. The aircraft beeps once
indicating it is ready to link. The aircraft beeps twice indicating linking is successful. The battery level
LEDs of the remote controller will glow solid.
DJI Mavic 3
User Manual
46
©
2021 DJI All Rights Reserved.
4:53
DJI Fly
Gallery
Files
Firefox
Setting
Guide
Touchscreen Operations
Home
The top of the touchscreen displays the time, Wi-Fi signal, and battery level of the remote controller.
Some apps are already installed by default such as DJI Fly, Gallery, Files, Firefox, Settings, and Guide.
Settings includes network, display, voice, and Bluetooth configurations. Users can quickly learn about
the features under Guide.
Operations
Slide from the left or right to the
center of the screen to return to
the previous screen.
Slide up from the bottom of the
screen and release to return to the
home screen.
Slide diagonally right from the
bottom of the screen and hold
to access recently opened apps
when on the home screen.
Slide up from the bottom of
the screen and hold to access
recently opened apps when not
on the home screen.
DJI Mavic 3
User Manual
47
©
2021 DJI All Rights Reserved.
Quick Settings
2
3 4
1
5
6
7
1.
Notifications
Tap to check system notifications.
2.
Recent
Tap to check recently opened apps.
3.
Home
Tap to return to the home screen.
4.
System Settings
Tap to access system settings.
5.
Shortcuts
: Tap to enable or disable Wi-Fi. Hold to enter settings and connect to or add a Wi-Fi network.
: Tap to enable or disable Bluetooth. Hold to enter settings and connect with nearby Bluetooth
devices.
: Tap to enable Do Not Disturb mode. In this mode, system prompts will be disabled.
: Tap to start recording the screen. While recording, the screen displays the recording time. Tap
Stop to stop recording.
: Tap to screenshot the screen.
: Mobile data.
: Tap to enable Airplane mode. Wi-Fi, Bluetooth, and mobile data will be disabled.
6.
Adjusting Brightness
: The screen is in auto brightness mode when the icon is highlighted. Tap this icon or slide the bar
and the icon will switch to manual brightness mode.
7.
Adjusting Volume
Slide the bar to adjust the volume and tap to mute.
Notifications
10:12
Sat, Mar 30
DJI Fly
Expore skypixel.com
11m ago
One billion colors captured by the 10-bit Dlog-
M color profile.
Wi-Fi Bluetooth Do not dist Record Scr
Screenshot Mobile Airplane
DJI Mavic 3
User Manual
48
©
2021 DJI All Rights Reserved.
Advanced Feature
Calibrating the Compass
The compass may need to be calibrated after the remote controller is used in areas with electromagnetic
interference. A warning prompt will appear if the compass of the remote controller requires calibration.
Tap the warning prompt to start calibrating. In other cases, follow the steps below to calibrate your
remote controller.
1.
Enter the home screen.
2. Select Settings, scroll down, and tap Compass.
3.
Follow the diagram on the screen to calibrate your remote controller.
4.
The user will receive a prompt when the calibration is successful.
HDMI Settings
The touchscreen can be shared to a display after connecting the HDMI port of the remote controller.
The resolution can be set by entering Settings, Display, and then Advanced HDMI.
DJI Mavic 3
User Manual
49
©
2021 DJI All Rights Reserved.
Built into the remote controller is DJI'S long-range tranmission technology, offering a maximum
transmission range of 15 km and displaying video from the aircraft to DJI Fly on a mobile device at up to
1080p 60fps (depending on phone type). The aircraft and camera are easy to control using the onboard
buttons and the detachable control sticks make the remote controller easier to store.
In a wide-open area with no electromagnetic interference, the aircraft uses O3+ to smoothly transmit
video links at up to 1080p 60fps (depending on phone type). The remote controller works at both 2.4
GHz and 5.8 GHz, automatically selecting the best transmission channel.
The built-in battery has a capacity of 5200 mAh and energy of 18.72 Wh and a maximum run time of
6 hours. The remote controller charges the mobile device with a charging ability of 500 mA@5 V. The
remote controller automatically charges Android devices. For iOS devices, first make sure that charging
is enabled in DJI Fly. Charging for iOS devices is disabled by default and needs to be enabled each time
the remote controller is powered on.
Compliance Version: The remote controller is compliant with local regulations.
Control Stick Mode: The control stick mode determines the function of each control stick movement.
Three pre-programmed modes (Mode 1, Mode 2, and Mode 3) are available and custom modes can
be configured in DJI Fly. The default mode is Mode 2.
Using the Remote Controller
Powering On/Off
Press the power button once to check the current
battery level. Press once, then again, and hold
to power the remote controller on or off. If the
battery level is too low, recharge before use.
Charging the Battery
Use a USB-C cable to connect the provided
charger to the USB-C port of the remote
controller. It takes approximately four hours to
fully charge the remote controller.
Controlling the Gimbal and Camera
Shutter/Record Button: Press once take a photo
or to start or stop recording.
Photo/Video Toggle: Press once to switch
between photo and video mode.
Gimbal Dial: Use to control the tilt of the gimbal.
Press and hold the customizable button in order
to be able to use the gimbal dial to adjust the
zoom in explore mode.
Gimbal Dial
Customizable
Button
Shutter/Record
Button
Photo/Video
Toggle
RC-N1
DJI Mavic 3
User Manual
50
©
2021 DJI All Rights Reserved.
Controlling the Aircraft
The control sticks control the aircraft’s orientation (pan), forward/backward movement (pitch), altitude
(throttle), and left/right movement (roll). The control stick mode determines the function of each control
stick movement. Three preprogrammed modes (Mode 1, Mode 2, and Mode 3) are available and
custom modes can be configured in DJI Fly. The default mode is Mode 2.
Mode 1
Left Stick
Turn Left
Forward
Backward
Turn Right
Right Stick
Left
Up
Down
Right
Mode 2
Left Stick
Turn Left
Up
Down
Turn Right
Right Stick
Left
Forward
Backward
Right
Mode 3
Left Stick
Left
Forward
Backward
Right
Right Stick
Turn Left
Up
Down
Turn Right
DJI Mavic 3
User Manual
51
©
2021 DJI All Rights Reserved.
Position Flight Mode
Remote
Controller
(Mode 2)
Aircraft
( Indicates Nose Direction)
Remarks
Moving the left stick up or down changes the
aircraft’s altitude. Push the stick up to ascend and
down to descend. The more the stick is pushed
away from the center position, the faster the
aircraft will change altitude. Push the stick gently
to prevent sudden and unexpected changes in
altitude.
Moving the left stick to the left or right controls
the orientation of the aircraft. Push the stick left to
rotate the aircraft counter-clockwise and right to
rotate the aircraft clockwise. The more the stick is
pushed away from the center position, the faster
the aircraft will rotate.
Moving the right stick up and down changes the
aircraft’s pitch. Push the stick up to fly forward
and down to fly backward. The more the stick is
pushed away from the center position, the faster
the aircraft will move.
Moving the right stick to the left or right changes
the aircraft’s roll. Push the stick left to fly left and
right to fly right. The more the stick is pushed
away from the center position, the faster the
aircraft will move.
Flight Mode Switch
Toggle the switch to select the flight mode.
S Sport Mode
C Cine Mode
N Normal Mode
DJI Mavic 3
User Manual
52
©
2021 DJI All Rights Reserved.
Flight Pause/RTH Button
Press once to make the aircraft brake and hover in place. If the aircraft is performing Smart RTH or auto
landing, press once to exit the procedure and then brake.
Press and hold the RTH button until the remote controller beeps to start RTH. Press this button again to
cancel RTH and regain control of the aircraft. Refer to the Return to Home section for more information
about RTH.
Customizable Button
Go to System Settings in DJI Fly and select Control to customize the function of the button. Functions
include recentering the gimbal, switching the auxiliary LED, and toggling the map and live view.
Remote Controller Alert
The remote controller sounds an alert during RTH or when the battery level is low (6% to 15%). The low
battery alert level can be cancelled by pressing the power button. The critical battery level alert (less
than 5%), however, cannot be cancelled.
Optimal Transmission Zone
The signal between the aircraft and the remote controller is most reliable when the antennas are
positioned in relation to the aircraft as depicted below.
Weak
Weak
Strong
Optimal Transmission Zone
DJI Fly
App
DJI Mavic 3
User Manual
53
©
2021 DJI All Rights Reserved.
The aircraft and remote controller must be linked before using. Follow these steps to link a new remote
controller:
1.
Power on the remote controller and the aircraft.
2.
Launch DJI Fly.
3.
In camera view, tap
and select Control and Pair to Aircraft (Link).
4.
Press and hold the power button of the aircraft for more than four seconds. The aircraft beeps once
indicating it is ready to link. The aircraft beeps twice indicating linking is successful. The battery level
LEDs of the remote controller will glow solid.
Make sure the remote controller is within 0.5 m of the aircraft during linking.
The remote controller will automatically unlink from an aircraft if a new remote controller is linked to
the same aircraft.
Fully charge the remote controller before each flight. The remote controller sounds an alert when the
battery level is low.
If the remote controller is powered on and not in use for five minutes, an alert will sound. After 6
minutes, the remote controller automatically powers off. Move the control sticks or press any button
to cancel the alert.
Adjust the mobile device holder to ensure the mobile device is secure.
Fully charge the battery at least once every three months to maintain battery health.
Linking the Remote Controller
54
©
2021 DJI All Rights Reserved.
DJI Fly App
This section introduces the main
functions of the DJI Fly app.
55
©
2021 DJI All Rights Reserved.
Altitude Zone (120m) Fly
Spots
Academy
Album
Skypixel
Profile
GO
FLY
DJI Fly App
Home
Launch DJI Fly and enter the home screen.
Fly Spots
View or share nearby suitable flight and shooting locations, learn more about GEO zones, and preview
aerial photos of different locations taken by other users.
Academy
Tap the icon in the top right corner to enter Academy. Product tutorials, flight tips, flight safety, and
manual documents can be viewed here.
Album
Allows you to view photos and videos from DJI Fly and mobile device. Create contains Templates and
Pro. Templates provides auto edit feature for imported footage. Pro allows you to edit the footage
manually.
SkyPixel
Enter SkyPixel to view videos and photos shared by users.
Profile
View the account information, flight records, DJI forum, online store, Find My Drone feature, and other
settings.
DJI Mavic 3
User Manual
56
©
2021 DJI All Rights Reserved.
N Mode In-Flight
80
24 17
RC
20
7x
1.0x
AF
3
3m
m
/
/s
s
4.6m/s
H 150 m D 80
m
Storage
RES&FPS
EV
1:30:30 5.1K 50
+0.7
Camera View
1 2 3 4 5 6 7
18
8
9
17
10
11
16 15 14 13 12
1. Flight Mode
N : Displays the current flight mode.
2. System Status Bar
In-Flight : Indicates aircraft flight status and displays various warning messages.
3. Battery Information
24'17"
: Displays the current battery level and remaining flight time. Tap to view more information about
the battery.
4. Video Downlink Signal Strength
RC
: Displays the video downlink strength between the aircraft and remote controller.
5. Vision Systems Status
: The left side of the icon indicates the status of the Forward, Backward, and Lateral Vision Systems
and the right side of the icon indicates the status of the Upward and Downward Vision Systems. The icon is
white when the vision system is working normally and red when the vision system is unavailable.
6. GNSS Status
20
: Displays the current GNSS signal strength. Tap to check the GNSS signal status. The Home Point
can be updated when the icon is white, which indicates the GNSS signal is strong.
7. System Settings
: Tap to view information about safety, control, and transmission.
Safety
Flight Assistance: Upward, Forward, Backward, and the Lateral vision systems are enabled after setting
Obstacle Avoidance to Bypass or Brake. The aircraft cannot sense obstacles if Obstacle Avoidance is
disabled. Select Normal or Nifty mode when using Bypass.
Radar Map Display: When enabled, the real-time obstacle detection radar map will be displayed.
Return to Home: Tap to set Advanced RTH, Auto RTH Altitude (default altitude is 100 m), and to update the
Home Point.
Flight Protection: Tap to set the max altitude and max distance, Auto RTH altitude (default altitude is 100 m),
and to update the Home Point.
80
DJI Mavic 3
User Manual
57
©
2021 DJI All Rights Reserved.
Sensors: Tap to view the IMU and compass status and start to calibrate if necessary.
Battery: Tap to view the battery information such as battery cell status, serial number and times charged.
Auxiliary LED: Tap to set the auxiliary LED to auto, on, or off. Do not turn on the Auxiliary LED before takeoff.
Aircraft Front Arm LEDs: In auto mode, the aircraft front LEDs will be disabled during recording to ensure the
quality is not affected.
Unlock GEO Zone: Tap to view the information about unlocking GEO zones.
The Find My Drone feature helps to find the location of the aircraft on the ground.
Advanced Safety Settings include the behavior settings of the aircraft when the remote controller signal is
lost, when the propellers can be stopped during flight, and the AirSense switch.
The behavior of the aircraft when the remote controller signal is lost can be set to Return to Home, Descend,
and Hover.
“Emergency Only” indicates that the motors can only be stopped mid-flight in an emergency situation such
as if there is a collision, a motor has stalled, the aircraft is rolling in the air, or the aircraft is out of control
and is ascending or descending very quickly. “Anytime” indicates that the motors can be stopped mid-flight
anytime once user performs a combination stick command (CSC). Stopping the motors in mid-flight will
cause the aircraft to crash.
An alert will appear in DJI Fly when a manned aircraft is detected if AirSense is enabled. Read the disclaimer
in the DJI Fly prompt before using AirSense.
Control
Aircraft Settings: Units Settings.
Gimbal Settings: Tap to set the gimbal mode, advanced settings, gimbal angle, and perform gimbal
calibration.
Remote Controller Settings: Tap to set the function of the customizable button, to calibrate the remote
controller, and to switch stick modes. Make sure to understand the operations of a stick mode before
changing stick mode.
Beginner Flight Tutorial: View the flight tutorial.
Connect to Aircraft: Tap to start linking when the aircraft is not linked to the remote controller.
Camera
Camera Parameter Settings: Displays different settings according to the shooting mode.
General Settings: Tap to view and set histogram, overexposure warning, gridlines, peaking level, white
balance, auto sync HD photos, and cache when recording.
Storage Location: Footage can be stored in the aircraft or on a microSD card. Internal storage and microSD
cards can be formatted. The max video cache capacity settings and camera reset settings can also be
adjusted.
USB Mode: Mavic 3 Cine supports USB mode, enabling users to copy footage when the battery level of
the aircraft is low. Enable USB mode, power on the aircraft, and connect to a computer to use USB mode.
During this time, the internal storage of the aircraft can be accessed but the SD card cannot.
Restart the aircraft and disable USB mode in DJI Fly to exit USB mode. USB mode will be enabled once
again when the aircraft is restarted if it was disabled via DJI Assistant 2.
In USB mode, the aircraft will disconnect from the remote controller, the frame arm light will turn
off, and the fan inside the aircraft will stop.
Transmission
Live Stream Platform, HDMI Output, Frequency, and Channel Mode settings.
DJI Mavic 3
User Manual
58
©
2021 DJI All Rights Reserved.
1x
7
x
5.1K 50
1:30:30
About
View device information, firmware information, app version, battery version, and more. Tap Reset All Settings
to reset settings including camera, gimbal and safety settings to default. Tap Clear All Data to reset all
settings to default, and delete all the data stored in internal storage, mircroSD card and SSD, including flight
log. It is recommended to provide proof (flight log) when claiming compensation. Contact DJI support before
clearing the flight log if an accident occurs during flight.
8. Shooting Modes
Video: Normal, Explore, and Slow Motion. Supported digital zoom for normal video mode. In Explore
mode, the icon shows the zoom ration, and tap to adjust the zoom ratio. The larger the zoom ratio, the
slower the aircraft will rotate.
Photo: Single, Explore, Burst Shooting, AEB, and Timed Shot.
MasterShots: Select a subject. The aircraft will record while executing different maneuvers in sequence and
keeping the subject in the center of the frame. A short cinematic video will be generated afterward.
QuickShorts: Dronie, Rocket, Circle, Helix, Boomerang, and Asteroid.
Hyperlapse: Choose from Free, Circle, Course Lock, and Waypoints.
Pano: Choose from Sphere, 180°, Wide Angle, and Vertical.
9.
Tele Camera
Tap to switch to tele camera in Photo or Video mode. Single, AEB, Burst, Time Shot photo mode, and
JPEG, RAW, and J+R format are supported, and ISO and shutter speed can be set manually in Photo
mode. 4K 25/30/50fps and 1080p 25/30/50fps format is supported, and ISO and shutter speed can be set
manually in Video mode. Tap
10.
S
hu
tter
/
Rec
or
d
Bu
tton
to switch to wide angle camera.
: Tap to take a photo or to start or stop recording a video.
11. Playback
: Tap to enter playback and preview photos and videos as soon as they are captured.
12. Camera Modes Switch
: Choose between Auto and Pro mode when in photo mode. Different parameters can be set in
different modes.
13. Shooting Parameters
RES&FPS
: Displays the current shooting parameters. Tap to access parameter settings.
14. Storage Information
Storage
: Displays the remaining number of photos or video recording time of the current storage. Tap to view
the available capacity of the SSD or microSD card.
15. Flight Telemetry
D
8
0
m
H
1
50
m
4
.
6
m
/
s
3
m
/
s
:
D
ispl
ay
s
th
e
dis
tan
ce
b
etween
t
h
e
a
ir
cr
aft
an
d
th
e
Ho
me
Po
int,
hei
g
h
t
fr
o
m
the Home Point, aircraft horizontal speed, and aircraft vertical speed.
16.
Map
: Tap to switch to the Attitude Indicator, which displays information such as the orientation and tilt angle
of the aircraft, position of the remote controller, and position of the Home Point.
Aircraft orientation
Remote controller position
Home Point
Collapse
Aircraft tilt angle
Switch to minimap
Switch to Attitude
Indicator
1.0x
DJI Mavic 3
User Manual
59
©
2021 DJI All Rights Reserved.
/
17. Auto Takeoff/Landing/RTH
: Tap the icon. When the prompt appears, press and hold the button to initiate auto takeoff or
landing.
:
Tap to initiate Smart RTH and have the aircraft return to the last recorded Home Point.
18. Back
: Tap to return to the home screen.
Press and hold on the screen to bring up the gimbal adjustment bar to adjust the gimbal angle.
Tap on the screen to enable focus or spot metering. Focus or spot metering will display differently
depending on the focus mode, exposure mode, and spot metering mode. After using spot metering, press
and hold on the screen to lock the exposure. To unlock the exposure, press and hold on the screen again.
Make sure to fully charge your device before launching DJI Fly.
Mobile cellular data is required when using DJI Fly. Contact your wireless carrier for data charges.
If you are using a mobile phone as your display device, DO NOT accept phone calls or use texting
features during flight.
Read all safety tips, warning messages, and disclaimers carefully. Familiarize yourself with the related
regulations in your area. You are solely responsible for being aware of all relevant regulations and
flying in a way that is compliant.
a. Read and understand the warning messages before using the auto-take off and auto-landing.
b. Read and understand the warning messages and disclaimer before setting the altitude beyond the
default limit.
c. Read and understand the warning messages and disclaimer before switching between flight modes.
d. Read and understand the warning messages and disclaimer prompts near or in GEO zones.
e. Read and understand the warning messages before using the Intelligent Flight modes.
Land the aircraft immediately in a safe location if prompted to do so in the app.
Review all warning messages on the checklist displayed in the app before each flight.
Use the in-app tutorial to practice your flight skills if you have never operated the aircraft or if you do
not have sufficient experience to operate the aircraft with confidence.
Cache the map data of the area where you intend to fly the aircraft by connecting to the internet
before each flight.
The app is designed to assist your operation. Use your sound discretion and DO NOT rely on the
app to control your aircraft. Your use of the app is subject to DJI Fly Terms of Use and DJI Privacy
Policy. Read them carefully in the app.
60
©
2021 DJI All Rights Reserved.
Flight
This section describes safe flight
practices and flight restrictions.
61
©
2021 DJI All Rights Reserved.
Flight
Once pre-flight preparation is complete, it is recommended to hone your flight skills and practice flying
safely. Make sure that all flights are carried out in an open area. Refer to the Remote Controller and DJI
Fly sections for information about using the remote controller and the app to control the aircraft.
Flight Environment Requirements
1. Do not use the aircraft in severe weather conditions including wind speeds exceeding 12 m/s, snow,
rain, and fog.
2. Only fly in open areas. Tall structures and large metal structures may affect the accuracy of the
onboard compass and GNSS system. It is recommended to keep the aircraft at least 5 m away from
structures.
3. Avoid obstacles, crowds, high voltage power lines, trees, and bodies of water. It is recommended to
keep the aircraft at least 3 m above water.
4. Minimize interference by avoiding areas with high levels of electromagnetism such as locations near
power lines, base stations, electrical substations, and broadcasting towers.
5. Aircraft and battery performance is subject to environmental factors such as air density and
temperature. Be careful when flying 6,000 m or more above sea level, since battery and aircraft
performance may be reduced.
6. Aircraft cannot use GNSS within the polar regions. Use the Downward Vision System when flying in
such locations.
7. DO NOT take off from moving objects such as cars, ships, and airplanes.
Flight Limits and GEO Zones
Unmanned aerial vehicle (UAV) operators should abide by the regulations from self-regulatory
organizations such as the International Civil Aviation Organization, the Federal Aviation Administration,
and local aviation authorities. For safety reasons, flight limits are enabled by default to help users
operate this aircraft safely and legally. Users can set flight limits on height and distance.
Altitude limits, distance limits, and GEO zones function concurrently to manage flight safety when GNSS
is available. Only altitude can be limited when GNSS is unavailable.
Flight Altitude and Distance Limits
The flight altitude and distance limits can be changed in DJI Fly. Based on these settings, the aircraft will
fly in a restricted cylinder, as shown below:
Max Flight Altitude
Height of aircraft
when takeoff
Max Radius
Home Point
DJI Mavic 3
User Manual
62
©
2021 DJI All Rights Reserved.
When GNSS is available
Flight Limits
DJI Fly App
Max Altitude
Aircraft's altitude cannot exceed the specified value
Warning: Height limit reached
Max Radius
Flight distance must be within the max radius
Warning: Distance limit reached
Only Downward Vision System is available
Flight Limits
DJI Fly App
Max Altitude
Height is restricted to 30 m when the GNSS signal is weak.
Height is restricted to 3 m when the GNSS signal is weak
and light conditions is not sufficient.
Warning: Height limit
reached.
Max Radius
The restrictions on the radius are disabled and warning prompts cannot be received in
the app.
The altitude limit when the GNSS is weak will not be restricted if there was a strong GNSS signal
when the aircraft was powered on.
If the aircraft reaches a limit, you can still control the aircraft, but you cannot fly it any further. If the
aircraft flies out of the max radius, it will automatically fly back within range when the GNSS signal is
strong.
For safety reasons, do not fly close to airports, highways, railway stations, railway lines, city centers,
or other sensitive areas. Fly the aircraft only within your line of sight.
GEO Zones
All GEO zones are listed on the DJI official website at http://www.dji.com/flysafe. GEO zones are divided
into different categories and include locations such as airports, flying fields where manned aircraft
operate at low altitudes, borders between countries, and sensitive locations such as power plants.
There will be prompts in the DJI Fly app to fly in GEO zones.
Pre-Flight Checklist
1.
Make sure the remote controller, mobile device, and Intelligent Flight Battery are fully charged.
2.
Make sure the Intelligent Flight Battery and the propellers are mounted securely.
3.
Make sure the aircraft arms are unfolded.
4.
Make sure the gimbal and camera are functioning normally.
5.
Make sure that there is nothing obstructing the motors and that they are functioning normally.
6.
Make sure that DJI Fly is successfully connected to the aircraft.
7.
Make sure that the camera lens and Vision System sensors are clean.
8. Use only genuine DJI parts or parts certified by DJI. Unauthorized parts or parts from non-DJI
certified manufacturers may cause system malfunctions and compromise safety.
DJI Mavic 3
User Manual
63
©
2021 DJI All Rights Reserved.
Auto Takeoff/Landing
Auto Takeoff
Use auto takeoff:
1.
Launch DJI Fly and enter the camera view.
2.
Complete all steps in the pre-flight checklist.
3.
Tap
. If conditions are safe for takeoff, press and hold the button to confirm.
4.
The aircraft will take off and hover 1.2 m above the ground.
Auto Landing
Use auto landing:
1.
Tap
. If conditions are safe to land, press and hold the button to confirm.
2.
Auto landing can be cancelled by tapping
.
3.
If the Vision System is working normally, Landing Protection will be enabled.
4. Motors stops after landing.
Starting/Stopping the Motors
Starting the Motors
A Combination Stick Command (CSC) is used to start the motors. Push both sticks to the bottom
inner or outer corners to start the motors. Once the motors have started spinning, release both sticks
simultaneously.
OR
Stopping the Motors
There are two methods to stop the motors.
Method 1: When the aircraft has landed, push and hold the left stick down. The motors will stop after
three seconds.
Method 2: When the aircraft has landed, push the left stick down and perform the same CSC that was
used to start the motors. The motors will stop immediately. Release both sticks once the
motors have stopped.
OR
Method 1 Method 2
DJI Mavic 3
User Manual
64
©
2021 DJI All Rights Reserved.
Flight Test
Stopping the Motors Mid-Flight
Stopping motors mid-flight will cause the aircraft to crash. The motors should only be stopped mid-
flight in an emergency situation such as if a collision has occurred or if the aircraft is out of control and
is ascending or descending very quickly, rolling in the air, or if a motor has stalled. To stop the motors
mid-flight use the same CSC that was used to start the motors. The default setting can be changed in
DJI Fly.
Takeoff/Landing Procedures
1.
Place the aircraft in an open, flat area with the aircraft status indicator facing towards you.
2.
Turn on the aircraft and the remote controller.
3.
Launch DJI Fly and enter the camera view.
4.
Wait until the self-check is finished, it is safe to fly if there is no abnormal warning in DJI Fly.
5.
Gently push the throttle stick to take off or use auto-takeoff.
6.
Pull the throttle stick or use auto-landing to land the aircraft.
7.
After landing, push the throttle stick down and hold. The motors stop after three seconds.
8.
Turn off the aircraft and remote controller.
Video Suggestions and Tips
1.
The pre-flight checklist is designed to help you fly safely and to ensure that you can shoot video
during flight. Go through the full pre-flight checklist before each flight.
2.
Select the desired gimbal operation mode in DJI Fly.
3.
Use Normal or Cine mode to record video.
4.
DO NOT fly in bad weather conditions such as when it is raining or windy.
5.
Choose the camera settings that best suit your needs.
6.
Perform flight tests to establish flight routes and to preview scenes.
Make sure to place the aircraft on a flat and steady surface before takeoff. DO NOT takeoff from your
palm or while holding the aircraft with your hand.
65
©
2021 DJI All Rights Reserved.
Appendix
66
©
2021 DJI All Rights Reserved.
Specifications
Aircraft
Dimensions (L×W×H)
Folded: 221×96.3×90.3 mm
Unfolded: 347.5×283×107.7 mm
Max Flight Time
46 min (measured while flying at 32.4 kph in windless conditions)
Max Tilt Angle
S Mode: 35°
N Mode: 30°
C Mode: 25°
Hovering Accuracy Range
Vertical: Vision Positioning: ±0.1 m
GNSS Positioning: ±0.5 m
Horizontal: Vision Positioning: ±0.3 m
High Accuracy System Positioning: ±0.5 m
Hasselblad Camera
Electronic Shutter Speed
1/8000-8 s
Appendix
Takeoff Weight 895 g (Mavic 3)
899 g (Mavic 3 Cine)
Diagonal Distance
380.1 mm
Max Descent Speed S Mode: 6 m/s
N Mode: 6 m/s
C Mode: 1 m/s
Max Speed
(near sea level, no wind)
S Mode: 21 m/s; S Mode (EU): 19 m/s
N Mode: 15 m/s
C Mode: 5 m/s
Max Service Ceiling Above Sea Level
6,000 m
Max Hover Time (without wind)
40 min
Max Wind Speed Resistance
12 m/s
Max Angular Velocity
200°/s
GNSS GPS + Galileo + BeiDou
Internal Storage
Mavic 3: 8 GB (7.2 GB of available storage)
Mavic 3 Cine: 1 TB (934.8 GB of available storage)
Sensor 4/3 CMOS Effective Pixels: 20 MP
ISO Range
Video: 100-6400
Photo: 100-6400
Max Image Size
5280 × 3956
Still Photography Modes
Single: 20 MP
Automatic Exposure Bracketing (AEB): 20 MP, 3/5 Frames at 0.7EV Step
Timed: 20 MP 2/3/5/7/10/15/20/30/60 seconds
Lens
FOV: 84°
Format Equivalent: 24 mm
Aperture: f/2.8-f/11
Shooting Range: 1 m to ∞ (with auto focus)
Operating Temperature
-10° to 40° C (14° to 104° F)
Max Flight Distance
30 km
Max Ascent Speed
S Mode: 8 m/s
N Mode: 6 m/s
C Mode: 1 m/s
DJI Mavic 3
User Manual
67
©
2021 DJI All Rights Reserved.
Max Video Bitrate
H.264/H.265: 200Mbps
Tele Camera
Normal/HLG/D-Log
Color Mode
Electronic Shutter Speed
1/8000-2 s
Still Photography Modes Single shot: 12 MP
Gimbal
4x
Digital Zoom
Max Control Speed (tilt)
100°/s
Video Resolution
Apple ProRes 422 HQ /422/422LT
5.1K: 5120 × 2700@24/25/30/48/50fps
DCI 4K: 4096 × 2160@24/25/30/48/50/60/120*fps
4K: 3840 × 2160@24/25/30/48/50/60/120*fps
H.264/H.265
5.1K: 5120 × 2700@24/25/30/48/50fps
DCI 4K: 4096 × 2160@24/25/30/48/50/60/120*fps
4K: 3840 × 2160@24/25/30/48/50/60/120*fps
FHD: 1920 × 1080@24/25/30/48/50/60/120*/200*fps
* Recorded frame rate, corresponding video plays as slow motion video
Supported File System
exFAT
Video Format
Mavic 3:
MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265)
Mavic 3 Cine:
MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265)
MOV (Apple ProRes 422 HQ)
Sensor 1/2-in CMOS
ISO Range
Video: 100-6400
Photo: 100-6400
Max Image Size
4000 × 3000
Video Format
MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265)
Video Resolution
H.264/H.265
4K: 3840 × 2160@25/30/50fps
FHD: 1920 × 1080@25/30/50fps
Stabilization
3-axis (tilt, roll, pan)
Controllable Range
Tilt: -90° to 35°
Pan: -5° to 5°
Angular Vibration Range
±0.007°
Mechanical Range
Tilt: -135° to +100°
Roll: -45° to +45°
Pan: -27° to +27°
Photo Format JPEG
Lens
FOV: 15°
Format Equivalent: 162 mm
Aperture: f/4.4
Shooting Range: 3 m to ∞
Photo Format JPEG/DNG (RAW)
DJI Mavic 3
User Manual
68
©
2021 DJI All Rights Reserved.
Forward Vision System
Precision Measurement Range: 0.5-20 m
Detection Range: 0.5-200 m
Effective Sensing Speed: ≤15 m/s
FOV: 90° (horizontal), 103° (vertical)
Lateral Vision System
Precision Measurement Range: 0.5-25 m
Effective Sensing Speed: ≤15 m/s
FOV: 90° (horizontal), 85° (vertical)
Downward Vision System
Precision Measurement Range: 0.3-18 m
Effective Sensing Speed: ≤6 m/s
FOV: 130° (front and back), 160° (left and right)
Transmission
Max Transmission Distance
(unobstructed, free of interference)
15 km (FCC), 8 km (CE/SRRC/MIC)
Latency (depending on environment 130 ms (with RC-N1)
and mobile device)
120 ms (with DJI RC Pro)
Standard Voltage
15.4 V
Weight 335.5 g
Output
USB-C: 5.0 V
5.0 A/9.0 V 5.0 A/12.0 V 5.0 A/15.0 V 4.3 A/
20.0 V
3.25 A/5.0 V~20.0 V 3.25 A USB-A: 5 V 2 A
Type
Omnidirectional Vision Systems and Infrared Sensing System
Backward Vision System
Precision Measurement Range: 0.5-16 m
Effective Sensing Speed: ≤12 m/s
FOV: 90° (horizontal), 103° (vertical)
Upward Vision System
Precision Measurement Range: 0.2-10 m
Effective Sensing Speed: ≤6 m/s
FOV: 100° (front and back), 90° (left and right)
Operating Environment
Forward, Lateral, Upward, Backward: Discernible surfaces, adequate
lighting of lux >15
Downward: Non-reflective, discernible surfaces with diffuse reflectivity
of >20%, such as walls, trees, people; Adequate lighting of lux >15
Surface with a clear pattern
Video Transmission System
O3+
Operating Frequency 2.400-2.4835 GHz, 5.725-5.850 GHz
Max Download Speed
SDR: 5.5 MB/s (with RC-N1)
15 MB/s (with DJI RC Pro)
Antennas
4 antennas, 2T4R
Capacity 5000 mAh
Max Charging Voltage
17.6 V
Energy 77 Wh
Charging Temperature
5° to 40° C (41° to 104° F)
Input 100-240 V AC (47-63 Hz) 2.0 A
Battery Charger
Battery Type LiPo 4S
Intelligent Flight Battery
2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC), <30 dBm (SRRC), <14 dBm (CE)
Transmitter Power (EIRP)
Live View Quality
Remote Controller: 1080p@30fps/1080p@60fps
Sensing System
DJI Mavic 3
User Manual
69
©
2021 DJI All Rights Reserved.
Charging Hub
Charging Type
Charge three Intelligent Flight Batteries in sequence
Output
USB-C: 5.0 V
5.0 A/9.0 V 5.0 A/12.0 V 5.0 A/15.0 V 4.3A/
20.0 V
3.25 A/5.0 V~20.0 V 3.25 A
USB-A: 5 V
2 A
Storage
Rated Power 65 W
Input
USB-C: 5 V-20 V
5.0 A max
Rated Power 65 W
Charging Temperature
5° to 40° C (41° to 104° F)
Input Car Power Port: 12.7 V-16 V 6.5 A, Voltage: 14 V DC
Rated Power 65 W
Charging Temperature
5° to 40° C (41° to 104° F)
Supported SD Cards
SDXC, UHS-I Speed Grade 3 rating microSD card
Recommended microSD Cards
When recording at normal video resolutions, it is recommended to use
the SD cards listed below.
Corresponding resolutions:
H.265
5.1K : 5120x2700@24/25/30/48/50fps
DCI 4K : 4096x2160@24/25/30/48/50/60/120fps
4K: 3840x2160@24/25/30/48/50/60/120fps
FHD : 1920x1080@24/25/30/48/50/60/120/200fps
H.264
DCI 4K : 4096x2160@24/25/30/48/50/60fps
4K : 3840x2160@24/25/30/48/50/60fps
FHD: 1920x1080@24/25/30/48/50/60/120/200fps
SanDisk Extreme Pro 64G V30 A2 microSDXC
SanDisk Extreme Pro 128G V30 A2 microSDXC
SanDisk Extreme Pro 256G V30 A2 microSDXC
SanDisk Extreme Pro 400G V30 A2 microSDXC
SanDisk High Endurance 64G V30 XC I microSDXC
SanDisk High Endurance 128G V30 XC I microSDXC
SanDisk High Endurance 256G V30 XC I microSDXC
SanDisk Extreme 128G V30 A2 microSDXC
SanDisk Extreme 256G V30 A2 microSDXC
SanDisk Extreme 512G V30 A2 microSDXC
Lexar 667x 64G microSDXC
Lexar 667x 128G microSDXC
Lexar 667x 256G microSDXC
Lexar High Endurance 64G V30 XC I microSDXC
Lexar High Endurance 128G microSDXC
Samsung Evo Plus 64G microSDXC
Samsung Evo Plus 128G microSDXC
Samsung Evo Plus 256G microSDXC
Samsung Evo Plus 512G microSDXC
Charging Time
Approx. 96 mins
Car Charger
Output Battery Port: 12 V - 17.6 V 5.0 A max
DJI Mavic 3
User Manual
70
©
2021 DJI All Rights Reserved.
DJI RC-N1 Remote Controller
Operating Time
6 hours (without charging the mobile device)
4 hours (with charging the mobile device)
Transmitter Power (EIRP)
2.4 GHz:
≤26 dBm (FCC), ≤20 dBm (CE/SRRC/MIC)
5.8 GHz:
≤26 dBm (FCC/SRRC), ≤14 dBm (CE)
SSD
Capacity: 1TB
Max Read Speed: 700MB/s*
Max Write Speed: 471MB/s*
* Max read or write speed of the aircraft. The speed may vary when
connected to a computer or other device.
Transmission System
When used with different aircraft hardware configurations, DJI RC-
N1 Remote Controllers will automatically select the corresponding
firmware version for updating and support the following transmission
technologies enabled by the hardware performance of the linked
aircraft models:
a.
DJI Mini 2/ DJI Mavic Air 2: O2
b.
DJI Air 2S: O3
c.
DJI Mavic 3: O3+
Supported USB Port Types
Lightning, Micro USB, USB-C
Operating Temperature
0° to 40° C (32° to 104° F)
Max Supported Mobile Device
Size(H×W×T)
180 mm × 86 mm × 10 mm
When recording at high video resolutions, it is recommended to use
SD cards listed below.
Corresponding resolutions:
H.264
5.1K: 5120x2700@24/25/30/48/50fps
DCI 4K: 4096x2160@120fps
4K : 3840x2160@120fps
SanDisk Extreme Pro 64G V30 A2 microSDXC
SanDisk Extreme Pro 128G V30 A2 microSDXC
SanDisk Extreme Pro 256G V30 A2 microSDXC
SanDisk Extreme Pro 400G V30 A2 microSDXC
SanDisk High Endurance 64G V30 XC I microSDXC
SanDisk High Endurance 128G V30 XC I microSDXC
SanDisk High Endurance 256G V30 XC I microSDXC
Lexar High Endurance 64G V30 XC I microSDXC
Lexar High Endurance 128G microSDXC
Lexar 667x 64G microSDXC
Lexar 667x 128G microSDXC
Lexar 667x 256G microSDXC
DJI Mavic 3
User Manual
71
©
2021 DJI All Rights Reserved.
After-Sales Information
Use DJI Fly or DJI Assistant 2 (Consumer Drones Series) to update the aircraft firmware.
Using DJI Fly
When you connect the aircraft or remote controller to DJI Fly, you will be notified if a new firmware
update is available. To start updating, connect your remote controller or mobile device to the internet
and follow the onscreen instructions. Note that you cannot update the firmware if the remote controller
is not linked to the aircraft. Internet is required.
Using DJI Assistant 2 (Consumer Drones Series)
Update the aircraft and remote controller firmware separately using DJI Assistant 2 (Consumer Drones
Series).
Follow the instructions below to update the aircraft firmware through DJI Assistant 2 (Consumer Drones
Serie
1.
Launch DJI Assistant 2 (Consumer Drones Series) and log in with your DJI account.
2. Power on the aircraft and connect the aircraft to a computer via the USB-C port.
3.
Select DJI Mavic 3 and click on Firmware Updates on the left panel.
4.
Select the firmware version that you wish to update to.
5.
Wait for the firmware to download. The firmware update will start automatically.
6.
The aircraft will reboot automatically after the firmware update is complete.
Follow the instructions below to update the remote controller firmware through DJI Assistant 2 (Consumer
Drones Series):
1.
Launch DJI Assistant 2 (Consumer Drones Series) and log in with your DJI account.
2. Power on the remote controller and connect to a computer via the USB-C port using a Micro USB
cable.
3.
Select DJI Mavic 3 Remote Controller and click on Firmware Updates on the left panel.
4.
Select the firmware version that you wish to update to.
5.
Wait for the firmware to download. The firmware update will start automatically.
6.
Wait for the firmware update to be completed.
Make sure follow all the steps to update firmware. Otherwise, the update may fail.
The firmware update will take approximately 10 minutes. It is normal that the gimbal goes limp,
aircraft status indicators blink, and the aircraft reboots. Wait patiently until the update is complete.
Make sure the computer has access to the internet.
Before performing an update, make sure the Intelligent Flight Battery is at least 40% charged and the
remote controller is at least 30% charged.
Do not disconnect the aircraft from the computer during an update.
Visit https://www.dji.com/support to learn more about after-sales service policies, repair services, and
support.
Firmware Update
DJI Support
http://www.dji.com/support
This content is subject to change.
Download the latest version from
http://www.dji.com/mavic-3
If you have any questions about this document, please contact
DJI by sending a message to
DocSupport@dji.com
.
DJI is a trademark of DJI.
Copyright © 2021 DJI All Rights Reserved.
