ICH587A03/05
11/14
CHANDELIER
TOOLS AND MATERIALS REQUIRED:
Phillips
Screwdriver
Wire Cutters
Pliers Wrench
Wiring supplies
as required by
the Canadian
Electrical Code
and/or the
Quebec
Electrical code
!
INSTRUCTIONS PERTAINING TO RISK OF FIRE OR INJURY TO PERSONS
READ ALL INSTRUCTIONS
IMPORTANT SAFETY
INSTRUCTIONS
SAVE THESE INSTRUCTIONS
L
I
G
H
T
I
N
G
&
F
A
N
S
E
C
L
A
I
R
A
G
E
S
&
V
E
N
T
I
L
A
T
E
U
R
S
QUESTIONS OR CONCERNS CONTACT CANARM AT:
1-800-265-1833 (English) / 1-800-567-2513 (French)
Monday through Friday 8:00 AM to 5:00 PM E.S.T.
Step 2
Step 1
Step 1
Step 3
Loop
Power
Cord
Chain
Lower
Connector
Nipple
Hex Nut
Outlet Box
Outlet Box Screws
(not included)
Mounting
Bracket
Attach the mounting bracket to the outlet box using electrical
box screws (not included) . Attach the nipple to the mounting
bracket and adjust until it will clear the canopy when assembled
(Place the canopy over the nipple and tighten the upper
connector onto the nipple until snug. The upper connector
should hold the canopy snug to the ceiling). Lock the nipple in
the correct position using the hex nut.
To attach chain loop to light fixture, use a screwdriver and wrench
to open and close chain loop. Ensure to close the opening.
Weave the power cord and ground wire through the links in the
chain.
Spread the arms evenly.
Tighten the loop to the stem on the canopy.
INSTALLATION:
SAFETY PRECAUTIONS:
1. TURN OFF ELECTRICAL POWER BEFORE STARTING INSTALLATION OF LIGHT FIXTURE.
2. THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE
BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE
HAZARDS INVOLVED.
3. CONNECT THE GROUND WIRES (BARE COPPER OR GREEN) FROM YOUR FIXTURE TO THE GROUND
WIRE (BARE COPPER OR GREEN) OR GROUND SCREW IN THE ELECTRICAL OUTLET BOX.
NOTE: Product May Not Look Exactly As Shown In Figures.
