4411 Instruction Manual
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic safety should always be
followed, including the following:
Read all instructions before using this sewing machine.
1. An appliance should never be left unattended when plugged in.
2. Always unplug this appliance from the electric outlet immediately
after using and before cleaning.
3.
1. Do not allow to be used as a toy. Close attention is necessary
when this appliance is used by or near children.
2. Use this appliance only for its intended use as described in this
manual. Use only attachments recommended by the
manufacturer as contained in this manual.
3. Never operate this appliance if it has a damaged cord or plug, if it
is not working properly, if it has been dropped or damaged, or
dropped into water. Return the appliance to the nearest
authorized dealer or service center for examination, repair,
electrical or mechanical adjustment.
4. Never operate the appliance with any air openings blocked. Keep
ventilation openings of the sewing machine and foot controller
free from accumulation of lint, dust, and loose cloth.
5. Keep fingers away from all moving parts. Special care is required
around the sewing machine needle.
6. Always use the proper needle plate. The wrong plate can cause
the needle to break.
7. Do not use bent needles.
8. Do not pull or push fabric while stitching. It may deflect the
needle causing it to break.
9. Switch the sewing machine off ("O") when making any adjustments
in the needle area, such as threading needle, changing needle,
threading bobbin, or changing presser foot, and the like.
10. Always unplug sewing machine from the electrical outlet when
removing covers, lubricating, or when making any other user
servicing adjustments mentioned in the instruction manual.
11. Never drop or insert any object into any opening.
12. Do not use outdoors.
13. Do not operate where aerosol spray products are being used or
where oxygen is being administered.
14. To disconnect, turn all controls to the off ("O") position, then
remove plug from outlet.
15. Do not unplug by pulling on cord. To unplug, grasp the plug, not
the cord.
This sewing machine is intended for household use only.
DANGER - To reduce the risk of electric shock:
- To reduce the risk of burns, fire, electric
shock, or injury to persons:
WARNING
Please turn off the machine or unplug when the machine is not
operating properly.
18. Never place anything on the foot controller.
19. If the supply cord that is fixed with foot controller is damaged, it
must be replaced by the manufacturer or its service agent or a
similar qualified person in order to avoid a hazard.
20. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
21. Children should be supervised to ensure that they do not play
with the appliance.
SAVE THESE INSTRUCTIONS
The LED lamp maximum power is 0.3W, maximum voltage is DC
9V. If the lamp is damaged, you should not use the product, send
it to SINGER or a service agent to repair or replace at once.
16. The sound pressure level under normal operating conditions is
75dB(A).
17.
I
As the owner of a new Singer sewing machine, you are about to begin an exciting adventure in
creativity. From the moment you first use your machine, you will know you are sewing on one
of the easiest to use sewing machines ever made.
May we recommend that, before you start to use your sewing machine, you discover the many
features and the ease of operation by going through this instruction book, step by step, seated
at your machine.
To ensure that you are always provided with the most modern sewing capabilities, the
manufacturer reserves the right to change the appearance, design or accessories of this
sewing machine when considered necessary.
SINGER is the exclusive trademark of The Singer Company Limited S.à.r.l. or its Affiliates.
©2012 The Singer Company Limited S.à.r.l. or its Affiliates. All rights reserved.
Congratulations
II
List of Contents
Machine Basics
Sewing
General Information
Maintenance and Troubleshooting
Principle Parts of the Machine..............................................................................................................................................2/3
Connecting Machine to Power Source ....................................................................................................................................4
Two Step Presser Foot Lifter/ .............................................................................................5
Accessories .............................................................................................................................................................................6
Winding the Bobbin .................................................................................................................................................................7
Inserting the Bobbin ................................................................................................................................................................8
Threading the Upper Thread ...................................................................................................................................................9
Raising the Bobbin Thread....................................................................................................................................................10
How to Choose Your Pattern .................................................................................................................................................12
Stitch Length Dial ...................................................................................................................................14
Sewing Straight Stitch ...........................................................................................................................................................15
Reverse Sewing/ ...................................................................................................16
Blind Hem..............................................................................................................................................................................17
...........................................................................................................................................................................18
Sewing on Buttons ................................................................................................................................................................20
Installing the Removable Extension Table.............................................................................................................................21
Attaching the Presser Foot Shank.........................................................................................................................................22
Needle/ Fabric/ Thread Chart................................................................................................................................................23
.........................................................................................................................................................24
Inserting & Changing Needle ................................................................................................................................................25
Troubleshooting Guide ..........................................................................................................................................................26
Adjusting Presser Foot Pressure
Thread Tension ......................................................................................................................................................................11
Three Needle Position Dial....................................................................................................................................................13
Stitch Width Dial &
Removing the Work/ Cutting the Thread
Buttonholes
Left and Right Side Balance for Buttonhole ..........................................................................................................................19
How To Drop Feed Dog
Threading the Machine
III
1. Thread tension dial
2. Presser foot pressure adjustment
3. Thread take-up lever
4. Reverse sewing lever
5. Thread cutter
6. Presser foot
7. Needle plate cover
8. Removable extension table/ accessory storage
9. Three needle position dial
10. Bobbin stopper
11. Stitch width dial
12. Stitch length dial
13. Pattern selector dial
2
1
2
3
5
6
8
7
13
11
12
10
4
9
Principal Parts of the Machine
14. Horizontal spool pin
15. Bobbin winding spindle
16. uxiliary spool pin
17. Handwheel
18. Buttonhole stitch balance adjustment slot
19. Power and light switch
20. Main plug socket
21. Bobbin thread guide
22. Upper thread guide
23. Face plate
24. Handle
25. Presser foot lifter
26. Drop feed control
27. Foot speed control
28. Power cord
Hole for a
3
28
24
25
27
22
23
26
19
20
21
14
15
16
18
17
Principal Parts of the Machine
Connect the machine to a power source as illustrated. (1)
Unplug power cord when machine is not in use.
The foot control pedal regulates the sewing speed. (2)
Consult a qualified electrician if in doubt of how to connect
machine to power source.
Unplug power cord when machine is not in use.
The foot control must be used with the appliance by
Press main switch (A) to"l"forpower and light.
Attention:
Foot control
Attention:
Sewing light
(110-120V area)/ (220-240V area)/
(110-125V area).
FC-
1902A FC-2902A 4C-
316Q
2
4
1
A
Connecting Machine to Power Source
5
When sewing several layers or thick fabrics, the presser foot
can be raised for easy positioning of the
work. (A)
to a higher position
A
The presser foot pressure of the machine has been pre-set
and requires no particular readjustment according to the type
of fabric (light-or-heavy weight).
However, if you need to adjust the presser foot pressure,
turn the presser adjusting screw with a coin.
For sewing very thin fabric, loosen the pressure by turning
the screw counter clockwise, and for heavy fabric, tighten by
turning it clockwise.
Two Step Presser Foot Lifter
Adjusting Presser Foot Pressure
006918008
1 Standard accessories
2 Optional accessories
m
h
g
e
f
i
j
l
k
a
b
c
d
006905008 006914008
006909008
Standard accessories (1)
Optional accessories (2)
a. All purpose foot
b. Zipper foot
c. Buttonhole foot
d. Button sewing foot
e. Seam ripper/ brush
f. Edge/ quilting guide
g. Pack of needles
h. Spool holders
i. Bobbin (3x)
j. L-screwdriver
k. Auxiliary Spool Pin
l. Spool pin felt
m. Soft cover
(These 10 accessories are not supplied with this machine;
they are, however, available for purchase from your authorized
retailer.)
n. Satin stitch foot
o. Overcasting foot
p. Hemmer foot
q. Cording foot
r. Blind hem foot
s. Quilting/ straight stitch foot
t. Gathering foot
u. Darning/ embroidery foot
v. Even Feed foot
w. Twin needle
onpqr
s
t
u
vw
006916008 006016008006917008 0061850081
006904008006172008 006907008 006900008
006813008
Accessories
6
- corresponding
. (1/2)
- Snap thread into thread guide. (3)
- Wind thread clockwise around bobbin winder tension discs. (4)
- Thread bobbin as illustrated and place on spindle. (5)
- Push bobbin spindle to right. (6)
- Hold thread end. (7)
- Step on foot control pedal. (8)
- Cut thread. (9)
- Push bobbin spindle to left (10) and remove.
When the bobbin winder spindle is in "bobbin winding"
position, the machine will not sew and the .
To start sewing, push the bobbin winder spindle to the left
(sewing position).
Please Note:
Place thread and spool holder on to spool
pin
handwheel turn
1
2
4
7
8
9
5
6
3
10
Winding the Bobbin
7
When inserting or removing the bobbin, the needle must
be fully raised.
Attention:
1. Insert the bobbin in the bobbin case with the thread
running counterclockwise direction (arrow).
2. Pull the thread through the slit (A).
3. Draw the thread clockwise until it slips into the notch (B).
4. Pull out about 15 cm (6 inches) of thread and attach the
bobbin cover plate. (C)
Turn power switch to off ("O") before inserting or
removing the bobbin.
A
B
C
1
3
4
2
Inserting the Bobbin
8
2
1
6
8
7
5
This is a simple operation but it is important to carry out correctly
as by not doing so .
- Start by raising the needle to its highest point (1), and
continue turning the handwheel counterclockwise until the
needle just slightly begins to descend. Raise the presser
foot to release the tension discs.
For safety, it is strongly suggested you turn off the
power before threading.
- Lift up the spool pin. Place the spool of thread on the
holder with the thread coming off the spool as shown. For
small thread spools, place small side of spool holder next
to spool. (2)
- Draw thread from spool through the upper thread guide (3)
and pulling thread through pre-tension spring as illustrated.
(4)
- Thread tension module by leading thread down right
channel and up left channel. (5) During this process it is
helpful to hold the thread between the spool and thread
guide.
- At the top of this movement pass thread from right to left
through the slotted eye of the take-up lever and then
downwards again. (6)
-
several sewing problems could result
Note:
Now pass the thread behind the horizontal thread guide,
and then behind the thin wire needle clamp guide (7) and
then down to the needle which should be threaded from
front to back.
- Pull about 6-8 inches of thread to the rear beyond the needle
eye. Trim thread to length with built in thread cutter. (8)
3 4
Threading the Upper Thread
9
1
2
3
Hold the upper thread with the left hand. Turn the handwheel
(1) towards you (counterclockwise) lowering, then raising
needle.
If it is difficult to raise the bobbin thread, check to make sure
the thread is not trapped by the hinged cover or the
Removable Extension Table.
Gently pull on the upper thread to bring the bobbin thread up
through the needle plate hole. (2)
Lay both threads to the back under the presser foot. (3)
Note:
10
Raising the Bobbin Thread
11
BA
C
D
1
Upper thread tension
Lower thread tension
Please note:
Basic thread tension setting: "4". (1)
To increase the tension, turn the dial to the next number up.
To reduce the tension, turn the dial to the next number down.
A. Normal thread tension for straight stitch sewing.
B. Thread tension too loose for straight stitch sewing. Turn
dial to higher number.
C. Thread tension too tight for straight stitch sewing. Turn
dial to lower number.
D. Normal thread tension for zig zag and decorative sewing.
Correct thread tension is when a small amount of the
upper thread appears on the bottom side of fabric.
-.
- There is no single tension setting appropriate for all stitch
functions, thread or fabric.
- A balanced tension (identical stitches both top and bottom) is
usually only desirable for straight stitch construction sewing.
- 90% of all sewing will be between "3" and "5".
- For zig zag and decorative sewing stitch functions, thread
tension should generally be less than for straight stitch
sewing.
- For all decorative sewing you will always obtain a nicer
stitch and less fabric puckering when the upper thread
appears on the bottom side of your fabric.
The bobbin tension has been set correctly at the factory, so
you do not need to adjust it.
Proper tension setting is important for strong seams
Thread Tension
12
The diagram on this page display the stitch patterns available
on the machine.
The Pattern Selector Dial may be turned in either direction.
a. Reverse Sewing Lever
b.
c. Stitch Width Dial
d. Stitch Length Dial
e. Pattern Selector Dial
Turn the Pattern Selector Dial (e) to select the desired
pattern. Use the Stitch Length Dial (d) to adjust the stitch
length as desired for the project. Use the Stitch Width Dial (c)
to adjust the width of the stitch as desired.
Three Needle Position Dial
c
e
d
a b
3
1
4
2
ABCDEFGH I
J
How to Choose Your Pattern
13
The needle position can be altered with the "Three needle
position dial". For normal work, the needle position is middle.
For edge stitching or sewing parallel lines of top stitch, select
needle position left or right. For twin needle stitching, needle
position is middle.
a. Straight
b. Zig-zag
L. Left Needle Position
M. Middle Needle Position
R. Right Needle Position
L M R
a
b
Three Needle Position Dial
14
1
2
Function of stitch width dial
Function of stitch length dial while zig-zag stitching
Function of stitch length dial for when straight stitching
The maximum zigzag stitch width for zigzag stitching is 6mm;
however, the width can be reduced on any patterns. The
width increases as you move zigzag dial from "0" - "6". (1)
Set the Pattern Selector Dial to zig-zag.
The density of zig-zag stitches increase as the setting of stitch
length dial approaches "0".
.(2)
Dense zig-zag stitches are called satin stitches. (2)
For straight stitch sewing, turn the Pattern Selector Dial to
the straight stitch setting. Turn the Stitch Length Dial, and the
length of the individual stitches will decrease as the dial
approached "0". The length of the individual stitches will
increase as the dial approaches "4". Generally speaking, use
a longer stitch length when sewing heavier weight fabrics or
when using a thicker needle or thread. Use a shorter stitch
length when sewing lighter weight fabrics or when using a
finer needle or thread.
Standard zigzag stitches are usually achieved at "3" or below
Stitch Width Dial & Stitch Length Dial
4
3
2
1
0.5
15
To begin sewing, set the machine for straight stitch. (1)
Place the fabric under the presser foot with the fabric edge
lined up with the desired seam guide line on the needle plate.
(2)
Lower the presser foot lifter, and then step on the foot
controller to start sewing. (3)
1
2
3
Sewing Straight Stitch
Turn the handwheel toward you (counterclockwise) to bring
the thread take up lever to its highest position, raise the
presser foot and remove work behind
(2)
the needle and presser
foot.
Pull the threads under and behind the presser foot. Guide
the threads to the side of the face plate and into thread cutter
(B). Pull threads down to cut. (3)
To secure the beginning and the end of a seam, press down
the reverse sewing lever (A). Sew a few reverse stitches.
Release the lever and the machine will sew forward again. (1)
1
3
2
A
B
16
Removing the Work
Cutting the Thread
Reverse Sewing
17
2
1
For hems on curtains, trousers, skirts, etc.
Blind hem for stretch fabrics.
Blind hem for firm fabrics.
Set the Stitch Width Dial at
a setting appropriate for the weight/type of fabric being sewn,
within the range shown in the diagram on the right of the
page. Generally, a narrower stitch is used for lighter weight
fabrics, and a wider stitch is used for heavier weight fabrics.
Sew a test first to make sure the machine settings are
appropriate for the fabric.
Blind Hem:
Set the Stitch Length Dial with the range shown on the
diagram at the right. Blind hems, however, are normally sewn
with a longer stitch length setting.
Turn up the hem to the desired width and press. Fold back
(as shown in Fig. 1) against the right side of the fabric with
the top edge of the hem extending about 7 mm (1/4") to the
right side of the folded fabric.
Start to sew slowly on the fold, making sure the needle
touches slightly the folded top to catch one or two fabric
threads. (2)
Unfold the fabric when hemming is completed and press.
To make blind hem sewing even easier, use a blind hem
foot, available from your SINGER retailer. (See page 6 for
part number)
Note:
M
Blind Hem
18
Prepare
Note:
Tips:
1. Take off the all purpose foot and attach the buttonhole foot.
Adjust the Stitch Length Dial in the " " to set stitch density.
Density varies according to the fabric.
Always test sew a buttonhole on the fabric you are using to
sew the buttonhole.
Follow the 4-step sequence changing from one step to
another with the Pattern Selector Dial. When moving from
step to step through the buttonhole process, be sure that the
needle is raised before turning the Pattern Selector Dial to
the next step. Take care not to sew too many stitches in
steps 1 and 3. Use seam ripper and cut buttonhole open
from both ends towards the middle.
- Slightly reducing upper thread tension will produce better
results.
- Use a stabilizer for fine or stretchy fabrics.
- It is advisable to use heavy thread or cord for stretch or knit
fabrics. The zig-zag should sew over the heavy thread or
cord. (A)
2. Measure diameter and thickness of button and add 0.3 cm
(1/8") for bar tacks to obtain correct buttonhole length; mark
buttonhole length on fabric (a).
3. Place fabric under the foot, so that marking on the
buttonhole foot aligns with starting marking on fabric.
Lower the foot, so that the buttonhole center line marked
on the fabric aligns with the center of the buttonhole foot (b).
Set the stitch width at "6". The width however may need to be
adjusted according to the project, sew a test first to determine
this.
(a) (b)
M
Buttonholes
19
Stitch density on right and left sides of buttonhole can be
adjusted by buttonhole balance control dial.
This dial should usually be in a neutral position (between "+"
and " ")
If the stitches on the left side of buttonhole are too close
together, turn the dial to the left (+).
* Turning dial to the left opens left side.
If the stitches on the left side of the buttonhole are too open,
turn the dial to the right ( ).
* Turning dial to right closes left side.
–
–
Left and Right Side Balance for Buttonhole
20
4
3
1
2
Move the drop feed control to right side to lower the feed
dogs. (1)
Change the all purpose foot to the button sewing foot. (2)
Set the stitch length to "0".
Set the machine for zig-zag stitch, then set the width to
number "3" - "6". Turn the handwheel to check that the
needle goes cleanly into the left and right holes of the button.
Adjust the stitch width, as needed, according to the distance
between the holes of the button. Slowly sew on the button
with about 10 stitches.
Raise the needle out of the fabric. Set the machine for straight
If a shank is required, place a darning needle on top of the
button and sew. For buttons with 4 holes, sew through the
front two holes first, push the work forward and then sew
through the back two holes.
Place the button and fabric under the Button Sewing foot, as
illustrated in (3).
stitch again, then sew a few securing stitches to finish.
L R
a
b
a
b
Sewing on Buttons
1
2
21
Hold the removable extension table horizontally, and push it
in the direction of the arrow. (1)
To remove the extension table, pull it toward the left.
The inside of the removable extension table can be utilized
as an accessory box.
To open, flip cover down as shown. (2)
Installing the Removable Extension Table
12
3
4
a
c
d
e
f
b
b
a
e
g
22
Raise the presser bar
dge/ quilting
dge/ quilting
(a) with the presser foot lifter. Attach
the presser foot shank (b) as illustrated. (1)
Lower the presser foot shank (b) using the presser foot lifter,
until the cut-out (c) is directly above the pin (d). (2) The
presser foot (f) will engage automatically.
Raise the presser foot using the presser foot lifter. (3)
Raise the lever (e) and the foot disengages.
Attach the e guide (g) in the slot as illustrated.
Adjust as needed for hems, pleats, quilting, etc. (4)
Turn power switch to off ("O") when carrying out any of
the above operations!
Attaching the presser foot
Removing the presser foot
Attaching the e guide
Attention:
Attaching the Presser Foot Shank
23
Heavy woolen, overcoat fabrics, upholstery fabrics, some
leathers and vinyls.
EXPLANATION
Standard sharp needles. Sizes range
thin to large. 9 (70) to 18 (110).
Semi-ball point needle, scarfed.
9 (70) to 18 (110).
Leather needles. 12 (80) to 18 (110).
SINGER
®
2020
SINGER
®
2045
SINGER
®
2032
9-11 (70-80)
11-14 (80-90)
14 (90)
16 (100)
18 (110)
NEEDLE, FABRIC, THREAD SELECTION GUIDE
NEEDLE SIZE
FABRICS
THREAD
NEEDLE, FABRIC SELECTION
IMPORTANT: Match needle size to thread size and weight of fabric.
Lightweight fabrics-thin cottons, voile, silk, muslin,
interlocks, cotton knits, tricots, jerseys, crepes, woven
polyester, shirt & blouse fabrics.
Light-duty thread in cotton, nylon, polyester or
cotton wrapped polyester.
Medium weight fabrics-cotton duck, woolen, heavier knits,
terrycloth, denims.
Heavyweight fabrics-canvas, woolens, outdoor tent and
quilted fabrics, denims, upholstery material (light to medium).
Heavy duty thread, carpet thread.
Most threads sold are medium size and suitable
for these fabrics and needle sizes.
Use polyester threads on synthetic materials
and cotton on natural woven fabrics for best
results.
Always use the same thread on top and bottom.
Medium weight fabrics-cotton, satin, kettlecloth, sailcloth,
double knits, lightweight woolens.
NEEDLES TYPE OF FABRIC
Natural woven fabrics-wool, cotton, silk, etc.
Not recommended for double knits.
Natural and synthetic woven fabrics, polyester blends.
Knits-polyesters, interlocks, tricot, single and double knits.
Also sweater knits, Lycra , swimsuit fabric, elastic.
®
Leather, vinyl, upholstery. (Leaves smaller hole than standard
large needle.)
Note :
1. For best sewing results always use genuine SINGER needles.
2. Replace needle often (approximately every other garment ) and/ or at first thread breakage or skipped stitches.
®
N Charteedle/ Fabric/ Thread
24
For ordinary sewing, keep the feed dog up, for freehand
embroidery, sewing on buttons and darning, drop the feed
dog.
To raise (a) and lower (b) feed dog. (2)
1
2
a
b
a
b
How To Drop Feed Dog
25
A
C
B
A
B
C
D
1
2
Change the needle regularly, especially if it is showing signs
of wear and causing problems. For best sewing results
always use SINGER Brand Needles.
Insert the needle
A. Loosen the needle clamp screw and tighten again after
inserting the new needle. (1)
B. The flat side of the shaft should be towards the back.
C/D.Insert the needle as far up as it will go.
Turn power switch to off ("O") before inserting or removing
the needle.
Needles must be in perfect condition. (2)
Problems can occur with:
A. Bent needles
B. Damaged points
C. Blunt needles
®
Attention:
as illustrated as follows:
Inserting & Changing Needles
Problem Cause Correction
Upper thread
breaks
Lower thread
breaks
Skipped stitches
Needle breaks
Loose stitches
Seams gather or
pucker
Uneven stitches,
uneven feed
The machine is
noisy
The machine
jams
1. The machine is not threaded correctly.
2. The thread tension is too tight.
3. The thread is too thick for the needle.
4. The needle is not inserted correctly.
5. The thread is wound around the spool holder pin.
6. The needle is damaged.
1. The bobbin case is not inserted correctly.
2. The bobbin case is threaded wrong.
3. The lower thread tension is too tight.
1. The needle is not inserted correctly.
2. The needle is damaged.
3. The wrong size needle has been used.
4. The foot is not attached correctly.
1. The needle is damaged.
2. The needle is not correctly inserted.
3. Wrong needle size for the fabric.
4. The wrong foot is attached.
1. The machine is not correctly threaded.
2. The bobbin case is not correctly threaded.
3. Needle/ fabric/ thread combination is wrong.
4. Thread tension wrong.
1. The needle is too thick for the fabric.
2. The stitch length is adjusted wrong.
3. The thread tension is too tight.
1. Poor quality thread.
2. The bobbin case is threaded wrong.
3. Fabric has been pulled.
1. Lint or oil have collected on the hook or needle bar.
2. The needle is damaged.
Thread is caught in the hook.
1. Rethread the machine.
2. Reduce the thread tension. (lower number)
3. Select a larger needle.
4. Remove and reinsert the needle. (flat side towards the back)
5. Remove the reel and wind thread onto reel.
6. Replace the needle.
1. Remove and reinsert the bobbin case and pull on the thread.
The thread should pull easily.
2. Check both bobbin and bobbin case.
3. Loosen lower thread tension as described.
1. Remove and reinsert needle. (flat side towards the back)
2. Insert a new needle.
3. Choose a needle to suit the thread and fabric.
4. Check and attach correctly.
1. Insert a new needle.
2. Insert the needle correctly. (flat side towards the back)
3. Choose a needle to suit the thread and fabric.
4. Select the correct foot.
1. Check the threading.
2. Thread the bobbin case as illustrated.
3. The needle size must suit the fabric and thread.
4. Correct the thread tension.
1. Select a finer needle.
2. Readjust the stitch length.
3. Loosen the thread tension.
1. Select a better quality thread.
2. Remove bobbin case, thread and insert correctly.
3. Do not pull on the fabric while sewing, let the feed dogs pull
the fabric under the foot.
1. Clean the hook and feed dog as described.
2. Replace the needle.
Remove the upper thread and bobbin case, turn the handwheel
backwards and forwards by hand and remove the thread.
26
Troubleshooting Guide
021Q2D0102(B)(EN)
Please note that on disposal, this product must be safely recycled in accordance with relevant
National legislation relating to electrical/electronic products. If in doubt please contact your retailer
for guidance.
