Stock No.
33166
Preparing 2 Door
Tall Cabinet
Item Description Quantity
1
Top Panel 1
2
Bottom Panel 1
3
Left Side Panel 1
4
Right Side Panel 1
5
Left Back Panel 1
6
Right Back Panel 1
7
Left Door 1
8
Right Door 1
9
Front Kick Panel 1
10
Side Kick Panel 2
11
Shelf Panel 4
12
Foot Holder 4
13
Leg Leveller 4
14
M8 x 16mm bolt 16
15
M6 x 16mm bolt 12
16
12 x 7 x 5mm
Flat Washer
1
To make assembly easier we recommend having two
persons aid one another in assembly.
1
2
10
13
8
9
12
3
5
6
4
11
7
14
15
16
CABINET CONNECTION
Connect the side panels of two cabinets
with (4) bolt M6 x 16mm and nut M6,
and tighten with phillips screwdriver
(not included).
Note: remove the drawers and open the
doors before cabinet connection.
