ASSEMBLY INSTRUCTIONS
Before assembling your headboard, please read through these
MADISON HEADBOARD
Page 1 of 3
Instructions apply for bed sizes
QUEEN > KING
PARTS LIST HARDWARE
JCB M6 X 120mm (4 3/4”) - 4 pcs
Spare - 1 pc
A
B
ATTENTION! If you receive a damaged or defective item,
please contact Atlantic Furniture at [email protected] or 1-800-955-3726
Barrel nut - 4 pcs
Spare - 1 pc
READY
ASSEMBLE
TO
instructions carefully and familiarize yourself with the different parts.
Split washer - 4 pcs
Flat washer - 4 pcs
JCB M6 X 25mm (1”) - 4 pcs
HARDWARE FOR METAL BED FRAME
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
E
D
C
F
Allen wrench - 1pc
Spare - 1pc
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
1
2
3
4
5
B
B
B
A
A
A
A
FRONT VIEW
TAPER INSIDE AND
HOLES TO THE FRONT.
Step 1
Remove packing stick (5) from headboard panel (1) and DISCARD.
HEADBOARD PANEL 1 PC
1
2
3
4
5
1 PC
1 PC
1 PC
2 PCS
LEFT LEG
RIGHT LEG
PILLOW STOP
PACKING STICK
Adult assembly
1
5
5
Step 2
Attach the legs (2) and (3) to headboard panel (1)
and pillow stop (4) using JCB (A) and barrel nut (B).
Tighten with the Allen wrench (F).
BACK VIEW
A
B
If you purchased a wood headboard to attach to metal bed frame, please refer to page 3.
