Owner's Manual Electric Fireplace Dimplex PF3033HG

Table of Contents

  • Welcome & Congratulations
  • IMPORTANT INSTRUCTIONS
  • Fireplace Installation
  • Operation
  • Maintenance
  • Warranty
  • Replacement Parts

Fireplace Installation

WARNING: Ensure the power cord is not installed so that it is pinched or against a sharp edge and ensure that the power cord is stored or secured to avoid tripping or snagging to reduce the risk of fire, electric shock or injury to persons.

WARNING: Construction and electrical outlet wiring must comply with local building codes and other applicable regulations to reduce the risk of fire, electric shock and injury to persons.

WARNING: Do not attempt to wire your own new outlets or circuits. To reduce the risk of fire, electric shock or injury to persons, always use a licensed electrician. WARNING: To reduce the risk of fire, do not store or use gasoline or other flammable vapors or liquids in the vicinity of the heater.

Grounding Instructions

  • This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
  • This product is for use on a nominal 120-volt circuit and has a grounding plug that looks like the plug in Figure 1. Make sure that the product is connected to an outlet having the same configuration as the plug. No adapter should be used with this product.

Bathroom Installation

  • This firebox must be protected by a GFI receptacle or circuit. If a receptacle is used it must be readily accessible.
  • To prevent electrical shock this unit is an electrical appliance that is not watertight and must be installed as to prevent water from entering the unit. This unit must be installed away from showers, tubs, etc. Never locate fireplace where it may fall into a bathtub or other water containers.

Media Installation

Depending on the model, the media may come installed in the unit or packaged seperately

Media Seperately Packaged

  1. Remove the front glass by lifting the 2 hooks off of the 2 mounts on the firebox.
  2. Place the large media in the Media Tray in the center at the back (for optimum media effect), then carefully pour and evenly distribute the smaller media into the Media Tray.
  3. Replace the front glass.

Maintenance

Glass Cleaning

  • The front glass is cleaned in the factory during the assembly operation. During shipment, installation, handling, etc., the front glass may collect dust particles, these can be removed by dusting lightly with a clean dry cloth.
  • To remove fingerprints or other marks, the glass can be cleaned with a damp cloth. The glass should be completely dried with a lint free cloth to prevent water spots. To prevent scratching, do not use abrasive cleaners or spray liquids on the glass surface

Fireplace Surface Cleaning

  • To remove fingerprints or other marks, the exterior finish can be cleaned with a damp cloth with a mild detergent.
  • The surface should be completely dried with a lint free cloth to prevent water spots.

Servicing

  • Except for installation and cleaning described in this manual, an authorized service representative should perform any other servicing.
