HRVF254
Contents
Safety and warning information…......
2
2
For your safety and correct usage before installing and first
using the appliance, read this user manual carefully, including
its hints and warnings. To avoid unnecessary mistakes and
accidents, it is important to make sure that all people using the
appliance are thoroughly familiar with its
operation and safety features. Save these instructions and be
sure that they remain with the appliance if it is moved or sold,
so that anyone using it throughout its life, will be properly
informed on its usage and safety notices.
For the safety of life and property, keep the precautions of
these user's instructions as the manufacturer is not
,
responsible for damages caused by omission.
Hisense Refrigerator
Safety for children and otherswho are vulnerable people
According to EN standard
According to IEC standard
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
8
10
9
13
13
13
14
16
3
Hisense Refrigerator
Keep all packaging away from children as there is risk of
suffocation.
If you are discarding the appliance, pull the plug out of the
socket, cut the connection cable (as close to the appliance
as you can) and remove the door to prevent children playing
from suffering an electric shock or from closing themselves
inside it.
If this appliance, featuring a magnetic door seals, is to
replace an older appliance having a spring lock (latch) on the
door or lid, be sure to make the spring lock unusable before
you discard the old appliance. This will prevent it from
becoming a death trap for a child.
General safety
WARNING —This appliance is intended to be used in
household and similar applications such as
-staff kitchen areas in shops, offices and other working
environments;
-farm houses and by clients in hotels, motels and other
residential type environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
WARNING — Do not store explosive substances such as
aerosol cans with a flammable propellant in this appliance.
WARNING — If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
WARNING — Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING — Do not use mechanical devices or other
means to accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING — Do not damage the refrigerant circuit.
WARNING — Do not use electrical appliances inside the
food storage compartments of the appliance, unless they are
of the type recommended by the manufacturer.
4
Hisense Refrigerator
WARNING — The refrigerant and insulation blowing gas are
flammable. When disposing of the appliance, do so only at
an authorized waste disposal centre. Do not expose to
flame.
WARNING —When positioning the appliance, ensure the
supply cord is not trapped or damaged.
WARNING —Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the appliance.
Refrigerant
The refrigerant isobutene (R600a) is contained within the
refrigerant circuit of the appliance, a natural gas with a high
level of environmental compatibility, which is nevertheless
flammable. During transportation and installation of the
appliance, ensure that none of the components of the
refrigerant circuit becomes damaged.
The refrigerant (R600a) is flammable.
WARNING
If the refrigerant circuit should be damaged:
-Avoid opening flames and sources of ignition.
-Thoroughly ventilate the room in which the appliance is
situated.
WARNING — Refrigerators contain refrigerant andgases in
the insulation. Refrigerant and gases must be disposed of
professionally as they may cause eye injuries or ignition.
Ensure that tubing of the refrigerant circuit is not damage
prior to proper disposal.
Replacing the illuminating lamps
WARNING—The illuminating lamps must not be replaced by
the user! If the illuminating lamps is damaged, contact the
customer helpline for assistance.
This warning is only for refrigerators that contain illuminating
lamps.
or repairs which
hydrocarbon refrigerants
Authorization for
Service
In Queensland the Authorized
Gas Work
to carry out servicing
Person MUST hold a
this appliance.
Person to service
It is hazardous for
anyone other than an Authorized Service
involve removal of covers.
:
Risk of fire / flammable materials
5
Hisense Refrigerator
Daily use
Do not store flammable gass or liquids in the appliance,
There is a risk of an explosion.
Do not operate any electrical appliances in the appliance
(e.g.electric ice cream makers,mixers etc.).
When unplugging always pull the plug from the mains
socket,do not pull on the cable.
Do not place hot items near the plastic components of this
appliance.
Electrical safety
1.The power cord must not be lengthened.
2. Make sure that the power plug is not crushed or damaged.
A crushed or damaged power plug may overheat and cause a
fire.
3. Make sure that you can access the main plug of the
appliance.
4. Do not pull the main cable.
5. If the power plug socket is loose, do not insert the power
plug. There is a risk of electric shock or fire.
6.You must not operate the appliance without the interior
lighting lamp cover.
7.The fridge is only applied with power supply of single phase
alternating current of 220~240V/50Hz. If fluctuation of voltage
in the district of user is so large that the voltage exceeds the
above scope, for safety sake, be sure to apply A.C. Automatic
voltage regulator of more than 350W to the fridge. The fridge
must employ a special power socket instead of common one
with other electric appliances. Its plug must match the socket
with ground wire.
It is dangerous to alter the specifications or modify this
product in any way.
Any damage to the cord may cause a shortcircuit, fire, and/or
electric shock.
6
Hisense Refrigerator
Do not place food products directly against the air outlet on
the rear wall.
Store pre-packed frozen food in accordance with the frozen
food manufacture’s instructions.
The appliances manufactures storage recommendations
should be strictly adhered to.Refer to relrelevant instructions
for storage.
Do not place carbonated or fizzy drinks in the freeze
compartment as it creates pressure on the container,which
may cause it to explode,resulting in damage to the
appliance.
Frozen food can cause frost burns if consumed straight from
the freezer compartment.
Do not place the appliance in direct sunlight.
Keep buring candles,lamps and other items with naked
flames away from the appliance so that do not set the
appliance on fire.
The appliance is intended for keeping food stuff and/or
beverages in normal household as explained in this
instruction booklet The appliance is heavy.Care should be
taken when moving it.
Do not remove nor touch items from the freezer
compartment if your hands are damp/wet,as this could cause
skin abrasions or frost/freezer burns.
Never use the base,drawers, doors etc. to stand on or as
supports.
Frozen food must not be refrozen once it has been thawed
out.
Do not consume ice popsicles or ice cubes straight from
the freezer as this can cause freezer burn to the mouth
and lips.
To avoid items falling and causing injury or damage to
the appliance, do not overload the door racks or put too
much food in the crisper drawers.
caution!
Care and cleaning
7
Hisense Refrigerator
Adequate air circulation should be around the appliance,
lacking this leads to overheating. To achieve sufficient
ventilation, follow the instructions relevant to installation.
Wherever possible the back of the product should not be too
close to a wall to avoid touching or catching warm parts
(compressor, condenser) to prevent the risk of a fire, follow
the instructions relevant to installation.
The appliance must not be locate close to radiators or
cookers.
Make sure that the mains plug is accessible after the
installation of the appliance.
Service
Any electrical work required to do the servicing of the
appliance should be carried out by qualified electrician or
competent person.
This product must be serviced by an authorized Service
Center, and only genuine spare parts must be used.
1)If the appliance is Frost Free.
2)If the appliance contains freezer compartment.
Installation Important!
For electrical connection carefully, follow the instructions
given in this manual.
Unpack the appliance and check if there are damages on it.
Do not connect the appliance if it is damaged. Report
possible damages immediately to the place you bought it. In
this case retain packing.
It is advisable to wait at least four hours before connecting
the appliance to allow the oil to flow back in the compressor.
Before maintenance, switch off the appliance and disconnect
the mains plug from the mains socket.
Do not clean the appliance with metal objects, steam
cleaner, ethereal oils, organic solvents or abrasive
cleansers.
Do not use sharp objects to remove frost from the appliance.
Use a plastic scraper.
Note: Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances.(This clause applies only to the
EU region.)
It may not work properly if being left at
a temperature above or below the
indicated range for a long period.
Installing your new appliance
Before using the appliance for the first
time, you should be informed of the
following tips.
Ventilation of appliance
In order to improve efficiency
of the cooling system and
save energy, it is necessary to
maintain good ventilation around the
appliance for the dissipation of heat.
For this reason, sufficient clear space
should be available around the
refrigerator.
It is advisable for there to be
to the wall, at least 100mm from its
Suggest :
top,at last 50mm from its side to the
wall and a clear space in front to allow
the doors to open 135°. As shown in
following diagrams.
Note:
This appliance performs well within
the climate class from SN to T showed in
the table below.
●
Leveling of appliance
For sufficient leveling and air
circulating in the lower rear section of
the appliance, the bottom feet may
need to be adjusted. You can adjust
them manually by hand or by using a
suitable spanner.
To allow the door to self-close, tilt the
top backwards by about 10mm.
●
●
Adjusting the door handle
Before you use the appliance, please
check the refrigerator handle. If the
handle is loose, please adjust them by
using an Allen wrench in the clockwise
direction until handle is securely in
place. the handle is fitted with 2
screws.
Allen wrench
Hexagon socket
set screws
Symbol
Ambient Temperature
range()°C
SN
N
ST
T
+10 to +32
+16 to +32
+16 to +38
+16 to +43
Class
Extended
Temperate
Temperate
Subtropical
Tropical
Hisense RefrigeratorHisense Refrigerator
8
≤10mm≤10mm
50mm
50mm
50mm
50mm
685
Stand your appliance in a dry place to
avoid high moisture.
Keep the appliance out of direct
sunlight rain or frost. Stand the
appliance away from heat sources
such as stoves, fires or heaters.
，
●
●
of space from the back
Hisense R efrig erator
9
Description of the appliance
View of the appliance
Upper cover of door
Corner cover
3
6.
10.
Block cover
Upper cover
19. Cabinet
1.
2.
.Flapcover
4. Twist ice maker
5.
Handle(back)
7. Upper freezer drawer
8. Middle freezer drawer(huge box)
9. Freezer door
Lower freezer drawer
11. Freezer door seal
12. Adjustable bottom feet
13. Hinge cover
14.
15.
16. Glass shelf
17. Narrow freezer drawer
18. Shelf bracket(inside)
Ice storage box
Note: Due to constant improvement of our products, your refrigerator may be
slightly different from this instruction manual, but its functions and using methods
remain the same. To get more space in the freezer, you can remove drawer(except
lower freezer drawer), installation bracket and integrative ice maker/twistable ice
tray.
Note: To get the best energy efficiency of this product, please place all shelves,
drawers and baskets on their original position as the illustration above.
3
4
5
6
7
8
9
10
11
12
13
14
15
16
2
17
18
19
1
Hisense R efrig erator
10
Display controls
We recommend that when you start
your refrigerator for the first time, the
temperature for the refrigerator is set to
-18°C. If you want to change the
Controlling the temperature
faster. This feature also helps to keep
the vitamins and nutrition of fresh food
for longer period.
and the freezer
temperature setting displays -24
-20
,
●
●
●
●
Press “Super Freeze” button to
activate the super freeze function. The
light will come on
.
In case of the maximum amount of
food to be frozen, please wait about
24 h.
Super freeze automatically switches
off after 26 hours and the freezer
temperature goes to below
When super freeze function is on
you can switch off super freeze function
by pressing “Super Freeze” or
“Freezer” button, then the freezer
temperature setting or function mode
will revert back to the previous setting.
℃
℃
.
Super Freeze will quickly
lower the temperature within
the freezer so food will freeze
Press “Freezer” button to set freezer
temperature between -14 and -24
as needed, and control panel will
display corresponding values according
to the following sequence.
℃℃
1. Freezer
-16
℃
-17
℃
-18
℃
-19
℃
-20
℃
-21
℃
-15
℃
-24
℃
-23
℃
-22
℃
-14℃
2. Super Freeze
11
3
5
2
4
6
All functions and controls of the unit are
accessible from a control panel
conveniently located on the door of the
refrigerator. A keypad of touch buttons
and a digital display allow easy
configuration of features and settings in
a simple and intuitive manner.
Touch buttons require only
a short press on a button to operate.
The operation occurs when releasing
your finger from the button, not while
the button is pressed. There is no need
for applying pressure on the keypad.
“Eco Energy” and “Child Lock” buttons
require a long touch of a least 3 sec.
Please refer to those related sections
of this Manual for detailed instructions.
The control panel consists of the
indicating temperature area, four icons
representing different modes and six
touch buttons. When the appliance is
powered on for the first time, the
backlight of the display panel turns on.
If no buttons have been pressed and
the door remains closed, the backlight
will turn off after 60 sec.
Important!
temperature, follow the instructions
below.
Caution! When you set a temperature,
you set an average temperature for the
whole refrigerator cabinet.
Temperature inside the compartment
may vary from the temperature values
displayed on the panel, depending on
how much food you store and where
you place them. Ambient temperature
may also affect the actual temperature
inside the appliance.
Hisense Refrigerator
11
5. Power
If you want to stop using it, you can turn
the appliance off by pressing “Power”
button.
Do not store any food in the
fridge during this time.
When the appliance is power off, you
can switch the appliance on by
pressing “Power” button for 1 second,
and the refrigerator returns to the
previous temperature setting.
Important!
●
●
When the refrigerator is working, you
can switch the appliance off by
pressing “Power” button for 5 seconds,
meanwhile the display panel will be
turned off.
●
6. hild LockC
You can press the “Child
Lock” button in case
children touch the buttons
to avoid wrong set. When the Child
Lock function is activated, pressing the
other buttons would not work except
“Alarm” button.
●
●
When the appliance is unlocked, you
can activate the Child Lock function by
pressing “Child Lock” button for 3
seconds, meanwhile “Child Lock” icon
will be illuminated.
When the Child Lock function is
activated, you can switch off this
function by pressing “Child Lock” button
for 3 seconds, meanwhile “Child Lock”
icon will be turned off.
●
When the Eco Energy function is on,
you can switch it off by pressing any
button of “Eco Energy” or “Freezer”
button. The freezer temperature
setting will revert back to the previous
setting.
for when you are away on holiday by
reducing energy consumption.Pressing
“Eco Energy” button for 3 seconds until
the light comes on.
When the Eco Energy function is
activated, the temperature of the
freezer is automatically switched to
-15 to minimize the energy
consumption.
●
℃
The function makes the
freezer work in a power
saving mode which is useful
3. Eco Energy
4. Alarm
In case of alarm, “Alarm” icon
will light up and a buzzing
sound will start.
Press “Alarm” button to stop alarm and
buzzing then “Alarm” icon will turn off.
When the refrigerator is
turned on after a period of inactivity, the
Alarm may be activated. In this case,
press “Alarm” button to cancel it.
The alarm light on and a buzzing sound
indicate abnormal conditions, such as
accidentally a door left open.
Leaving the door of refrigerator open
for over 2 minutes will activate a door
alarm and buzzer. The buzzer will beep
3 times per minute for 10 minutes.
Closing the door cancels the door
alarm and buzzer.
To save energy, please avoid keeping
the door open for a long time when
using refrigerator. The door alarm can
also be cleared by closing the door.
This is an important feature that alerts
users of potential damage to stored
Caution!
Door Alarm
Temperature alarm
●
●
food. If a power failure occurs, for
example a blackout in your area of
residence while you are away, the
temperature alarm may be activated
when power is restored to be the
unit.Pressing the “alram” button for 3
sec can refer the alarm temperature.
this is likely to be the maximum
temperature reached by frozen items.
Hisense R efrig erator
12
Using your appliance
This section explains that how to
use the refrigerator features. We
recommend that you read through
carefully before using the appliance.
You can turn the flap cover upwards
when you want to take out the food in
the top chamber.
Before you open or close the flap
cover, you must lift it to the guide track
first. Then, the flap cover can slide
along the guide track to the top or the
bottom.
Flap cover
●
●
4
2
1
3
Freezer Drawer
It is used to store food which
needs to be frozen, including meat,
fish, ice cream, etc.
●
Twistable ice tray
Note: If the ice tray is used for the first
time or has not been used for a long
time, please clean it before using.
The twist ice tray is used to make and
deposit ice cubes. You should use it as
follows.
1. Pull out the twistable ice tray from
the installation bracket.
2. Pour water into the ice trays and the
water level shall not exceed the
maximum line.
●
3. Place the filled ice tray back to the
bracket.
4. When ice cubes form, twist the
knobs clockwise and the ice will drop
into the ice box below.
5. Ice cubes can be stored in the ice
box, if you need them, you can pull out
the ice box and take them out.
Hisense R efrig erator
13
Switching off your appliance
If the appliance needs to be switched
off for an extended period, the following
steps should be taken prevent mould
on the appliance.
1. Remove all food.
2. Remove the power plug from the
mains socket.
3. Clean and dry the interior thoroughly.
4. Ensure that all the doors are wedged
open slightly to allow air to circulate.
Hints for the storage of frozen food
Ensure that frozen food has been
stored correctly by the food retailer.
Once defrosted food will deteriorate
rapidly and should not be re-frozen. Do
not exceed the storage period indicated
by the food manufacturer.
，
●
●
Hints for fresh food refrigeration
Do not place hot food directly into
the refrigerator, the internal
temperature will increase resulting
in the compressor having to work
harder and will consume more
energy.
Do cover or wrap the food
particularly if it has a strong flavor.
Place food properly so that air can
circulate freely around it.
，
●
●
●
Hints for freezing
When first starting-up or after a
period out of use, let the appliance run
at least 2 hours on the higher settings
before putting food in the compartment.
●
Helpful hints and tips
Energy saving tips
We recommend that you follow the tips
below to save energy.
Try to avoid keeping the door open
for long periods in order to conserve
energy.
Ensure the appliance is away from
any sources of heat. (Direct sunlight,
electric oven or cooker etc.)
Don't set the temperature colder than
necessary.
Don't store warm food or evaporating
liquid in the appliance.
●
●
●
Place the appliance in a well
ventilated, humidity free, room. Please
refer to Installing your new appliance
chapter.
If the diagram shows the correct
combination for the drawers, crisper
and shelves, do not adjust the
combination as this is designed to be
the most energy efficient configuration.
●
●
●
Iced products, if consumed
immediately after removal from the
freezer compartment, will probably
cause frost burns to the skin.
It is recommended to label and date
each frozen package in order to keep
track of the storage time.
●
●
Prepare food in small portions to
enable it to be rapidly and completely
frozen and to make it possible to
subsequently thaw only the quantity
required.
Wrap up the food in aluminum foil or
polyethylene food wraps which are
airtight.
Do not allow fresh, unfrozen food to
touch the food which is already frozen
to avoid temperature rise of the latter.
●
●
●●
Cleaning and careCleaning and care
For hygienic reasons the appliance (including exterior and interior accessories)
should be cleaned regularly at least every two months.
The appliance must not be connected to the mains during cleaning.
Danger of electrical shock! Before cleaning switch the appliance off and remove
the plug from the mains socket.
Caution!
Hisense R efrig erator
14
Take care to keep door seals clean.
Sticky food and drinks can cause seals
to stick to the cabinet and tear when
you open the door. Wash seal with a
mild detergent and warm water. Rinse
and dry it thoroughly after cleaning.
Only after the door seals are
completely dry should the appliance be
powered on.
Caution!
Door seal cleaning
Troubleshooting
If you experience a problem with your appliance or are concerned that the appliance
is not functioning correctly, you can carry out some easy checks before calling for
service, please see below.
Don't try to repair the appliance yourself. If the problem persists after you
have made the checks mentioned below, contact a qualified electrician, authorized
service engineer or the shop where you purchased the product.
Warning!
Caution!
-Don't use sharp objects as they are
likely to scratch the surface.
-Don't use Thinner, Car detergent,
Clorox, ethereal oil, abrasive cleansers
or organic solvent such as Benzene for
cleaning. They may damage the
surface of the appliance and may
cause fire.
Interior cleaning
-Wipe the digital panel and display
panel with a clean, soft cloth.
-Spray water onto the cleaning cloth
instead of spraying directly on the
surface of the appliance. This helps
ensure an even distribution of moisture
to the surface.
-Clean the doors, handles and cabinet
surfaces with a mild detergent and
then wiped dry with a soft cloth.
Exterior cleaningExterior cleaning
To maintain good appearance of your
appliance, you should clean it regularly.
You should clean the appliance interior
regularly. It will be easier to clean when
food stocks are low. Wipe the inside of
the fridge freezer with a weak solution
of bicarbonate of soda, and then rinse
with warm water using a wrung-out
sponge or cloth. Wipe completely dry
before replacing the shelves and
baskets.
Thoroughly dry all surfaces and
removable parts.
Although this appliance automatically
defrosts, a layer of frost may occur on
the freezer compartment's interior walls
if the freezer door is opened frequently
or kept open too long. If the frost is too
thick, choose a time when the supply of
food stocks are low and proceed as
follows:
1.Remove existing food and
accessories baskets, unplug the
appliance from the mains power and
appliance from the mains power and
leave the doors open. Ventilate the
room thoroughly to accelerate the
thawing process.
2. When defrosting is completed, clean
your freezer as described above.
Don't use sharp objects to
remove frost from the freezer
compartment. Only after the interior is
completely dry should the appliance be
switched back on and plugged back
into the mains socket.
Caution!
Hisense R efrig erator
15
Appliance is not
working correctly
●
●
●
●
●
●
●
●
●
●
●
●
●
Problem
Odours from the
compartments
Noise from the
appliance
The motor runs
continuously
A layer of frost
occurs in the
compartment
Temperature inside
is too warm
Possible cause & Solution
Check whether the power cord is plugged into the power
outlet properly.
Check whether the “Power” funtion is on by pressing the
“power” button for 1 second.
Check the fuse or circuit of your power supply, replace if
necessary.
The ambient temperature is too low. Try setting the chamber
temperature to a colder level to solve this problem.
It is normal that the refrigerator is not operating during the
automatic defrost cycle, or for a short time after the
appliance is switched on to protect the compressor.
The interior may need to be cleaned.
Some food, containers or wrapping cause odours.
The sounds below are quite normal:
Compressor running noises.
Air movement noise from the small fan motor in the fridge
compartment or other compartments.
Gurgling sound similar to water boiling.
Popping noise during automatic defrosting.
Clicking noise before the compressor starts.
Other unusual noises are due to the reasons below and may
need you to check and take action:
The cabinet is not level.
The back of appliance touches the wall.
Bottles or containers fallen or rolling.
It is normal to frequently hear the sound of the motor, it will
need to run more when in following circumstances:
Temperature setting is set colder than necessary
Large quantity of warm food has recently been stored
within the appliance.
The temperature outside the appliance is too high.
Doors are kept open too long or too often.
After your installing the appliance or it has been switched
off for a long time.
Check that the air outlets are not blocked by food and
ensure food is placed within the appliance to allow sufficient
ventilation. Ensure that door is fully closed. To remove the
frost, please refer to cleaning and care chapter.
You may have left the doors open too long or too frequently;
or the doors are kept open by some obstacle; or the
appliance is located with insufficient clearance at the sides,
back and top.
Hisense R efrig erator
16
Increase the temperature by following the “Display
controls” chapter.
Check whether the top of the refrigerator is tilted back
by 10-15mm to allow the doors to self close, or if
something inside is preventing the doors from closing.
The water pan (located at the rear bottom of the
cabinet) may not be properly leveled, or the draining
spout located underneath the top of the compressor
depot may not be properly positioned to direct water
into this pan, or the water spout is blocked. You may
need to pull the refrigerator away from the wall to check
the pan and spout.
（
）
Temperature inside
is too cold
Doors can't be
closed easily
Water drips on the
floor
Disposal of the appliance
It is prohibited to dispose of this appliance as household waste.
Packaging materials
Packaging materials with the recycle symbol are recyclable. Dispose of the
packaging into a suitable waste collection container to recycle it.
Before disposal of the appliance
1. Pull out the mains plug from the mains socket.
2. Cut off the power cord and discard with the mains plug.
Refrigerators contain refrigerant and gases in the insulation.
Refrigerant and gases must be disposed of professionally as they may cause
eye injuries or ignition. Ensure that tubing of the refrigerant circuit is not
damage prior to proper disposal.
Warning!
Correct Disposal of this product
This symbol on the product or in its packing indicates that this
product may not be treated as household waste. Instead, it should
be taken to the appropriate waste collection point for the recycling of
electrical and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could
otherwise be caused by the inappropriate waste handling of this
product. For more detailed information about the recycling of this
product, please contact your local council your household waste
disposal service, or the shop where you purchased the product.
To avoid contamination of food, please respect the following instructions
Opening the door for long periods can cause a significant increase of the temperature
in the compartments of the appliance.
systems.
- Store raw meat and fish in suitable containers in the refrigerator, so that it is not in
contact with or drip onto other food.
- Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or
making icecream and making ice cubes.
- One-, two- and three-star compartments are not suitable for the freezing of fresh food.
-
- Clean regularly surfaces that can come in contact with food and accessible drainage
Order
Compartments
TYPE
Target storage
temp.[℃]
Appropriate food
1
Fridge
+2 +8
Eggs, cooked food, packaged food, fruits and
vegetables, dairy products, cakes, Drinks and
other foods which are not suitable for freezing.
2
( Freezer***)*-
≤-18
Seafood (fish, shrimp, shellfish), freshwater
aquatic products and meat products
(recommended time is 3 months – nutrition
values and taste decrease with time), suitable
for frozen fresh food.
3
***-Freezer
≤-18
Seafood (fish, shrimp, shellfish), freshwater
aquatic products and meat products
(recommended time is 3 months – nutrition
values and taste decrease with time). Not
suitable for freeing fresh food.
4
**-Freezer
≤-12
Seafood (fish, shrimp, shellfish), freshwater
aquatic products and meat products
(recommended time is 2 months – nutrition
values and taste decrease with time). Not
suitable for freeing fresh food.
5
*-Freezer
≤-6
Seafood (fish, shrimp, shellfish), freshwater
aquatic products and meat products
(recommended time is 1 month – nutrition
values and taste decrease with time). Not
suitable for freeing fresh food.
6
0-star
-6 0
Fresh pork, beef, fish, chicken, some packaged
processed foods, etc. (Recommended to eat
within the same day, preferably not later than
3 days) .
Partially packed/wrapped up encapsulated
processed foods (non-freezable foods)
7
Chill
-2 +3
Fresh/frozen pork, beef, chicken, freshwater
aquatic products, etc.(7 days below 0 ℃ and
above 0 ℃ is recommended for consumption
within that day, preferably no more than 2 days).
Seafood (less than 0 for 15 days, it is not
recommended to store above 0 ℃)
~
~
~
Hisense R efrig erator
17
8
Fresh Food
0 +4
Fresh pork, beef, fish, chicken, cooked food, etc.
(Recommended to eat within the same day,
preferably no more than 3 days)
9
Wine
+5 +20
red wine,white wine,sparkling wine etc.
Water dispenser cleaning (special for water dispenser products):
- Clean water tanks if they have not been used for 48 h; flush the water system
connected to a water supply if water has not been drawn for 5 days.
- If the refrigerating appliance is left empty for long periods, switch off, defrost, clean,
dry, and leave the door open to prevent mould developing within the appliance.
Note: please store different foods according to the compartments or target storage
temperature of your purchased products.
WARNING! Food needs to be packed in bags before putting into the refrigerator, and
liquids need to be packed in bottles or capped containers to avoid the problem that
the product design structure is not easy to clean.
~
~
Hisense R efrig erator
18
