RATING: 120 Vac, 60Hz, 35mA
INSTALL AND PROGRAM THE HOMELINK COMPATIBILITY BRIDGE
To prevent possible SERIOUS INJURY or DEATH from a moving
gate or garage door:
• ALWAYS keep remote controls out of reach of children.
NEVER permit children to operate, or play with remote
control transmitters.
• Activate gate or door ONLY when it can be seen clearly, is
properly adjusted, and there are no obstructions to door
travel.
• ALWAYS keep gate or garage door in sight until completely
closed. NEVER permit anyone to cross path of moving gate
or door.
HOMELINK
®
COMPATIBILITY BRIDGE™
INTRODUCTION
The HomeLink Compatibility Bridge™ is designed to allow
compatibility between a new Chamberlain, Sears Craftsman, or
LiftMaster* garage door opener and the HomeLink
®
system in
your vehicle. Refer to the your vehicle owner’s manual for specific
instructions on programming the HomeLink system. Your model
may look different than illustrated in this programming guide.
* Chamberlain and LiftMaster are Trademarks of Chamberlain Group. Sears is a Trademark of
Sears Roebuck.
NOTICE: To comply with FCC and or Industry Canada (IC) rules, adjustment or modifications of this
receiver and/or transmitter are prohibited, except for changing the code setting or replacing the
battery. THERE ARE NO OTHER USER SERVICEABLE PARTS.
This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the
following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
The device shall be used in such a manner that the potential for human contact normal operation is
minimized. This equipment complies with RSS-102 radiation exposure limits. This equipment
should be installed and operated with a minimum distance of 20 cm between the radiator and your
body. This device and its antenna(s) must not be co-located or operating in conjunction with any
other antenna or transmitter.
ATTENTION
ATTENTION
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
Antenna Indicator Light
HomeLink Compatibility Bridge
Be sure that your vehicle is parked outside of the garage before
programming the HomeLink Compatibility Bridge. Two people
may be needed to program the HomeLink system.
1. Program the new remote control
included with the HomeLink
Compatibility Bridge to the
Homelink button in your vehicle.
Refer to the owner’s manual for
your vehicle for programming
steps.
2. Plug the HomeLink Compatibility
Bridge into a 120 Vac polarized
outlet, located as close as
possible to your garage door
opener.
3. Straighten the antenna.
4. Press and release the YELLOW
Learn button on the garage door
opener. The Learn LED will glow
steadily.
5. Within 30 seconds press and
hold the programmed HomeLink
button in your vehicle.
6. Release the HomeLink button
when the garage door opener
light blinks. If light bulbs are
not installed in the garage door
opener, two clicks will be heard.
Programming is complete.
7. To ensure the garage door
opener operates from the
HomeLink button, press the
programmed HomeLink button
in the vehicle. If it does not
operate the garage door opener,
repeat the steps.
Remote Control
NOTES:
• If you are using the HomeLink Compatibility Bridge with a
garage door opener that has a Battery Backup system, ensure
the original remote control is programmed to the garage door
opener and place it in your glove box for use in the event of a
power outage.
• The remote control included with the Compatibility Bridge
MUST be kept for future programming (i.e. a new vehicle, a
new garage door opener, etc.).
