EN
1
APPLIANCE
PRODUCT DESCRIPTION
DAILY REFERENCE
GUIDE
THANK YOU FOR BUYING A HOTPOINT PRODUCT.
In order to receive a more complete
assistance, please register your appliance on:
www.hotpoint.eu/register
You can download the Safety Instructions and the
User
Manual, by visiting our website
docs.hotpoint.eu and
following the Instructions on the back of this booklet.
CONTROL PANEL
Before using the appliance carefully read Safety Instructions guide.
1 2 3 4 5 6 7 8 9 10
11
1. On-O/Reset button with indicator light
2. Program selection button
3. Salt rell indicator light
4. Rinse Aid rell indicator light
5. Program number and delay time indicator
6. Tablet indicator light
7. Display
8. Zone Wash 3D indicator lights
9. Zone Wash 3D button
10. Delay button
11. START/Pause button with indicator light / Tab
1. Upper rack
2. Foldable aps
3. Upper rack height adjuster
4. Upper spray arm
5. Lower rack
6. Cutlery basket
7. Lower spray arm
8. Filter Assembly
9. Salt reservoir
10. Detergent and Rinse Aid dispensers
11. Rating plate
12. Control panel
0000 000 00000
Service:
1
2
3
4
5
6
10
12
7
11
9
8
