Smart Plug-In Dimmer, Wi-Fi
before you start
Review this guide in its entirety. Consult an electrician with any questions or if
you are unsure of your abilities.
Caution: To reduce the risk of injury and/or overheating and damage to
other equipment:
• For dry, indoor use only.
• Connect the Smart Plug-In Dimmer to a 120 VAC, 60 Hz power
source ONLY.
• This Smart Plug-In Dimmer is intended for lamps with dimmable
bulbs ONLY.
• To reduce the risk of electrical shock, this equipment has a grounding
type plug that has a third (grounding) pin. If the plug does not fi t in
outlet, contact a qualifi ed electrician to install the proper outlet.
Visit www.legrand.us/radiant/smart-lighting/support for support.
installation & setup
1 | plug in the smart plug-in dimmer
Insert the lamp or device to be controlled into the outlet on the Smart
Plug-In Dimmer.
The Smart Dimmer up/down buttons can be reversed for use in outlets with the
ground plug up:
• Hold the bottom button while plugging in your dimmer. The dimmer
automatically adjusts the orientation.
2 | test the smart plug-in dimmer
a
With the lamp or device on, press the top button on the Smart Plug-In
Dimmer to turn your device on.
b
Hold the bottom button to decrease the light level.
c
Hold the top button to increase the light level.
d
Press the bottom button to turn your device off.
TROUBLESHOOTING TIP:
If the device is not responding to the dimmer, confi rm that the outlet is
powered and that the device is functional.
getting to know your plug-in
Item Name Description
1 Top Button
• Press to turn the light on or double-tap to
raise the dimming percentage to 100%.
• Press and hold any button to quickly change
the dimming percentage by 20% per second.
2 Bottom Button
• Press to turn the device off.
3 LED Locator Light
• Indicates the current state of the device. Refer
to “LED Locator Light Explanations” for detail.
4 Outlet
• Plug your dimmable device into the socket.
specifi cations
Load Rating
Incandescent/halogen 300 W
CFL/LED 100 W
Legrand reserves the right to change specifi cations without notice.
NOTE: The dimmer ships in forward phase mode to accommodate most load
types. For loads that require reverse phase dimming, such as ELV loads, adjust
the phase using the app.
SCAN TO WATCH THE
INSTALLATION VIDEO
3 | set up your system
a
Download and launch the Smart Lights, Wi-Fi app by Legrand. The app is
available on the App Store or on Google Play.
b
Connect your Smart Plug-In Dimmer to your home network by following the
step by step instructions in the app.
c
Use the app to control your Smart Plug-In Dimmer.
Google Play and the Google Play logo are trademarks of Google LLC.
App Store is a service mark of Apple Inc., registered in the U.S. and other countries.
SCAN TO WATCH HOW
TO SET UP THE APP
SCAN TO DOWNLOAD
RESET TO FACTORY DEFAULT
You can delete the device from the
app to reset or while device is off
press and hold dim button for 10
seconds then release.
NOTE: When it is turned on, the Smart
Dimmer recalls the most recent
dimming level.
1
2
3
4
LED LOCATOR LIGHT EXPLANATIONS
LED
Color
State of Light Explanation
Blinking
Amber
Factory default; ready to connect to your network.
Solid White Device is connected to your network.
