SF20208 — November 2018 — For latest specs visit www.legrand.us/radiant
3rd Party Compliance
WATTSTOPPER
®
radiant
®
CFL/LED & Incandescent Dimmer
450W CFL/LED & 700W Incandescent/Halogen
cULus listed, UL1472, CSA
Features & Benefits
Energy-saving dimming for CFL,
LED and Incandescent loads.
RHCL453P
radiant
®
dimmers help save energy simply, and as part of
the radiant collection, now offer a better fit, form and finish.
Compatible with CFL/LED dimmable bulbs (with the exception
of 0-10V LED drivers), these dimmers feature constant memory
that returns lights to the previous level after a power failure for
automatic control and convenience.
• Preset, Single Pole and 3-Way operation.
• Constant memory returns lights to
previous level after a power failure.
• Compatible with CFL/LED dimmable bulbs
(with the exception of 0-10V LED drivers).
• No de-rating required in multi-gang
applications.
• Interchangeable face plates available in
eight colors (RHKIT*; sold separately).
RHCL453PW
RHCL453PW
Convenient operation: combines
ON/OFF paddle switch with
separate slider for dimming control.
White LED glows when device is
OFF to make dimmer easy to find
in the dark.
Sleek, ergonomic design that
matches today’s styles.
Wider slide controller: for easier
dimming operation.
Adjustment dial allows users to
adjust the bottom of the dimming
range for a wide range of CFL and
LED bulbs.
SF20208 — November 2018 — For latest specs visit www.legrand.us/radiant
2
WATTSTOPPER
®
radiant
®
CFL/LED & Incandescent Dimmer
450W CFL/LED & 700W Incandescent/Halogen
Warranty
Lifetime
Technical Information
RHCL453PW
1.29"
1.0"
3.18"
2.60
Performance
Electrical
Supply Voltage 120VAC
Ratings 450W CFL/LED; 700W Incandescent/Halogen
Frequency 60Hz
Installation Single Pole or 3-Way
Environmental
Application Indoor Use Only
Mechanical
Enclosure Material Polycarbonate
SF20208 — November 2018 — For latest specs visit www.legrand.us/radiant
3
WATTSTOPPER
®
radiant
®
CFL/LED & Incandescent Dimmer
450W CFL/LED & 700W Incandescent/Halogen
Ordering Information
radiant
®
CFL/LED Incandescent/Halogen Dimmers
Catalog Number Description Color Voltage Rating
RHCL453PTC
Preset, Single Pole and
3-Way
Three
interchangeable
Face Colors: Ivory,
White, Light Almond
120VAC
60Hz
700W Inc/Halogen
450W CFL/LED
RHCL453PW
Preset, Single Pole and
3-Way
Face Color: White 120VAC
60Hz
700W Inc/Halogen
450W CFL/LED
RHCL453PGCCV4
Preset, Single Pole and
3-Way
Face Color: Graphite 120VAC
60Hz
700W Inc/Halogen
450W CFL/LED
RHCL453PDBCCV4
Preset, Single Pole and
3-Way
Face Color: Dark Bronze 120VAC
60Hz
700W Inc/Halogen
450W CFL/LED
RHCL453PNICCV4
Preset, Single Pole and
3-Way
Face Color: Nickel 120VAC
60Hz
700W Inc/Halogen
450W CFL/LED
RHKIT
Interchangeable Faces
Brown
RHKITBK
Black
RHKITGRY
Gray
RHKITI
Ivory
RHKITLA
Light Almond
RHKITNI
Nickel
RHKITW
White
RHKITDB
Dark Bronze
Legrand, North America
60 Woodlawn Street
West Hartford, CT 06110
1.877.BY.LEGRAND (295.3472)
www.legrand.us
905.738.9195
www.legrand.ca
SF20208 November 2018 ©2018 Legrand All Rights Reserved
FOLLOW US
The paper used to print this document is an environmentally responsible paper with
10% post consumer waste, with FSC and SFI Chain of Custody certifications, Lacey
Act complaint. 100% of the electricity used to manufacture Flo sheets is generated with
Green-e certified renewable energy.
All brand and product names referenced in this document are registered trademarks or
trademarks of their respective holders.
WATTSTOPPER
®
radiant
®
CFL/LED & Incandescent Dimmer
450W CFL/LED & 700W Incandescent/Halogen
• Office • Residential • Multiple Dwelling • Hospitality/Lodging
Vertical Markets
• GFCI Receptacles
• Tamper-Resistant
and Standard Duplex
Receptacles
• Paddle Switches
• Fan Controls
• Sensors
• Timers
• Home Automation Controls
• USB Charging Devices
• Night Lights
• Screwless Wall Plates
Also available in the radiant
®
collection
