Sencor SHB 4359BK-EUE3 Hand Blender User Manual

- 1 -

10/2019

EN Stick blender

Translation of the original manual

SHB 4358WH / SHB 4359BK

- 2 -

10/2019

Stick blender

Important safety instructions

READ CAREFULLY AND STORE FOR FUTURE USE.

General warnings

■ This appliance may not be used by children. Keep the appliance and its power cord away

from children.

■ These appliances may be used by persons with reduced physical, sensory or mental

capabilities or with a lack of experience and knowledge, if they are supervised or have

been instructed to use the appliance in a safe manner and understand the potential

dangers.

■ Cleaning and maintenance performed by the user must not be performed by unsupervised

children.

■ In the event that the power cord is damaged, have it repaired at a professional service

centre to prevent causing a dangerous situation. It is forbidden to use the appliance if it

has a damaged power cord.

Warning:

Incorrect use may lead to injuries.

■ Be especially careful not to injure yourself on the sharp cutting edges when handling

the chopping blades, especially when removing the blades from the blending jar, when

emptying the container and when cleaning it.

■ The surfaces of the appliance that come into contact with food must always be cleaned

according to the instructions in this user’s manual.

■ Always turn off the appliance and disconnect it from the power socket if you will not be

using it and if you will be leaving it without supervision, before assembly, disassembly,

cleaning or moving it.

■ Before replacing the accessories or accessible parts that move during use, turn the

appliance off and disconnect it from the power supply.

■ Children must not play with the appliance.

Electrical safety

■ Before connecting this appliance to apower socket, make sure that the voltage stated on

its rating label corresponds to the voltage in your power socket

■ Connect the appliance only to aproperly grounded socket. Do not use an extension cord.

■ Never connect the appliance to apower socket until it is properly assembled.

- 3 -

10/2019

■ Fully unwind the power cord before using it.

■ Do not connect and disconnect the power cord to and from the power socket with wet

hands.

■ Ensure that the power plug contacts do not come into contact with water or any other

liquid. If precisely this happens, carefully dry the power plug before using it again.

■ Do not disconnect the appliance from the power socket by pulling on the power cord.

This could damage the power cord or the power socket. Disconnect the power cord from

the power socket by pulling on the plug.

■ Do not place heavy items on the power cord. Make sure the power cord does not hang

over the edge of atable or that it is not touching ahot surface or sharp objects.

■ Do not wind the power cord around the appliance.

■ To avoid the danger of injury by electrical shock, do not repair the appliance yourself or

make any adjustments to it. Have all repairs or adjustments of the appliance performed

at an authorised service centre. Tampering with the appliance during the warranty period

may void the warranty.

■ To prevent the risk of injury by electrical shock, never submerge the motor unit and its

power cord in water or any other liquid, or wash these parts under running water.

■ Always turn off the appliance and disconnect it from the power socket when you have

finished using it.

■ In the event that the appliance falls into water, under no condition reach for it, rather,

immediately disconnect the power cord from the power socket. Never use an appliance

that was submerged in water. Hand it over to an authorised service centre for inspection.

Safety during use

■ This appliance is designed for household and is intended for blending, chopping and

whipping food. It is also suitable for processing hard ingredients such as coffee beans,

cocoa beans, ice cubes, nutmeg, etc.

■ Do not use the appliance in an industrial environment or outdoors. Do not use it for any

other purposes than those for which it is intended.

■ The appliance is intended for domestic use and similar locations such as:

– kitchens in stores; offices and other workplaces;

– in agriculture;

– for guests of hotels, motels and other similar locations;

– in bed and breakfast establishments.

■ This appliance is not intended to be operated using an external timer switch or aremote

control system.

- 4 -

10/2019

■ Use the appliance and its accessories in accordance with the instructions contained in this

user’smanual.

■ Only use the appliance with the original accessories that came with it.

■ Before every use, check the selected accessory for damage. Never use the appliance with

adamaged accessory.

■ Do not place the appliance or its accessories on an electric or gas stove or in its vicinity,

on the edge of atable or on an unstable surface. Only place the appliance on an even, dry

and stable surface.

■ Do not expose the appliance and its accessories to the outdoor environment, extreme

temperatures, direct sunlight, excessive humidity or excessively dusty environments.

■ Do not place the appliance and its accessories near heaters, open fires or other sources

of heat.

■ Make sure that the appliance is correctly assembled before putting it into operation.

■ Do not touch moving rotating parts during operation. Otherwise, this could result in

injury.

■ Be especially careful when handling hot liquids and foods. Hot steam or splashing hot

foods and liquids may cause scalding. For reasons of increased safety, allow hot foods and

liquids to cool down to at least 45 °C before blending.

■ The operating time of the appliance is 1 minute. Before turning it on again, allow it to

cool down for at least 3 to 5 minutes. When using the appliance to blend sticky or harder

foodstuffs, interrupt operation already after 30 seconds.

■ Do not turn on the appliance when it is empty. Incorrect use of the appliance may

negatively affect its lifetime.

■ Check that the motor unit is turned off, disconnected from the power socket and that the

rotating parts have come to acomplete stop before disassembling the appliance into its

individual parts.

■ Do not perform any maintenance on the appliance other than cleaning the individual

components as described in chapter Cleaning and maintenance.

■ Never use an appliance that is damaged in any way.

■ Do not use the appliance if it has fallen on the floor, if it was submerged in water, if it is not

functioning correctly or if it is damaged in any other way.

■ When handling the blade assembly of the blender or chopper unit, especially when taking

the blade assembly out of the bowl, when emptying the bowl and cleaning it, take special

care to avoid injury by the blades.

■ Do not use the appliance when it is not functioning properly or showing signs of damage.

- 5 -

10/2019

■ In order to prevent ahazardous situation arising, do not repair the appliance yourself

or modify it in any way. Have all repairs performed at an authorised service centre. By

tampering with the appliance, you risk voiding your legal rights arising from unsatisfactory

performance or quality warranty.

■ Store the appliance in adry environment.

- 6 -

10/2019

SHA 9200WH

- 7 -

10/2019

- 8 -

10/2019

Stick blender

User'smanual

■ Prior to using this appliance, please read the user’smanual thoroughly, even in cases, when one has already familiarised themselves with previous use of similar types of

appliances. Only use the appliance in the manner described in this user’smanual. Keep this user’smanual in asafe place where it can be easily retrieved for future use. In the event

that you hand this appliance over to somebody else, make sure to also include this user’smanual.

■ Carefully unpack the appliance and take care not to throw away any part of the packaging before you find all its parts. We recommend saving the original cardboard box,

packaging material, purchase receipt and responsibility statement of the vendor or warranty card for at least the duration of the legal liability for unsatisfactory performance or

quality. In the event of transportation, we recommend that you pack the appliance in the original box from the manufacturer.

DESCRIPTION OF THE APPLIANCE AND ITS ACCESSORIES

A1 Normal speed switch

A2 High speed switch (turbo)

A3 Motor unit

A4 Removable blender stick attachment

A5 Blade assembly

Contains 4 stainless steel blades

A6 Beaker, volume 700 ml

A7 Anti-slip base pad / lid

B1 Help arrow

B2 „Unlocked” symbol

B3 „Locked” symbol

PURPOSE OF USE

■ The stick blender is suitable for blending soft ingredients and liquids as well as processing hard ingredients. It is used namely for preparing baby food, various types of shakes,

sauces, spreads, grinding coffee beans, cocoa beans, ice cubes, nutmeg, etc.

BEFORE FIRST USE

■ Thoroughly wash accessories that are intended for coming into contact with food (blender stick attachment A4, blending beaker A6 and base pad A7) using warm water with

neutral kitchen detergent. Then rinse them with clean water and allow them to dry naturally or wipe them thoroughly dry using afine wiping cloth.

Attention:

When cleaning the blade assembly A5, be very careful not to injure yourself on its sharp edges.

■ When cleaning the blender attachment A4, do not submerge the top end that connects to the motor unit A3.

OPERATING THE APPLIANCE

■ Slide attachment A4 on to the motor unit A3 from underneath so that the arrow B1 on the rear side of the motor unit points at the unlocked padlock symbol B2 on the

attachment.

■ Turn the motor unit so that the arrow moves to the locked padlock symbol B3. The connection of both parts is accompanied by aclick.

■ To release the attachment from the motor unit, firmly grasp both parts and turn the motor unit so that the arrow points at the open padlock symbol. Pull both parts away from

each other.

Attention:

Before attaching or removing attachment A4, make sure that the motor unit A3 is turned off and disconnected from the power socket and that the rotating

parts have come to acomplete stop. The part of the attachment that is connected to the motor unit must be thoroughly dry.

■ For blending, use the beaker A6 or another suitable container intended for coming into contact with food. The anti-slip base pad A7 also serves as alid for the beaker, when you

wish to use it for short term storage of food.

■ Do not overfill the beaker A6 past the maximum level mark. This will prevent splattering the ingredients while they are processed.

■ Connect the motor unit A3 to apower socket.

■ Put the attachment into the bottom of the beaker. Use speed switch A1 or A2 to start the appliance. Move the blender slowly up and down to blend the ingredients to the

required consistency. The appliance will run as long as the switch is held down. Releasing the switch will turn off the appliance.

Attention:

The maximum continuous operating time of the appliance is 1 minute. Then allow it to cool down for 3to 5minutes. When using the appliance to blend sticky

or harder foodstuffs, interrupt operation already after 30 seconds.

■ After you finish using it, disconnect the power cord from the power socket. Make sure that the rotating parts have stopped rotating, and disassemble the appliance into its

individual parts. Then clean all used parts according to the instructions in chapter Cleaning and maintenance.

ADVICE AND TIPS

■ It is recommended to always blend at alower speed. While blending, move the blender up and down to blend the ingredients to the required consistency.

■ To prevent ingredients from splattering, put the blender attachment A5 into the beaker containing the ingredients before starting it, and conversely turn it off before pulling

the attachment out of the beaker.

■ To prevent ingredients from splattering, keep the blade assembly A6 of the blending attachment submerged while the appliance is running. It is recommended to divide alarger

amount of processed ingredients into several batches and to regularly inspect the contents inside the beaker.

■ When using the blender attachment, it is recommended to process ingredients using short pulses. This will prevent the ingredients from being excessively pulverised and optimal

results will be achieved.

■ To make blending and chopping easier, cut hard ingredients into small pieces.

■ To achieve better blending results, hold the stick blender slightly tilted, while carefully moving it up and down in the beaker. Do not use force to push ingredients down with

the stick blender.

■ Before blending or chopping, remove hard parts such as fruit stones or bones from the blended ingredients. This will prevent damaging the blade assembly.

- 9 -

10/2019

QUICK GUIDE TO PROCESSING INGREDIENTS

■ The food processing times provided below are only areference. The actual processing time depends on the size of the ingredients, their amount and the required final consistency.

If the required consistency is not achieved during the maximum operating time of the appliance, you may continue processing the food after the appliance has cooled down.

INGREDIENTS AMOUNT SPEED SETTING PROCESSING TIME

Baby food 300 g Medium to maximum 45 s

Spreads 200 g Medium to maximum 30 s

Fruit and vegetables (cooked) 200 g Medium to maximum 45 s

Sauces 500 ml Medium to maximum 45 s

Shakes 500 ml Medium to maximum 30 s

Meat 300 g Medium to maximum 30 s

Fruit and vegetables 200 g Medium to maximum 15 s

Hard and semi-hard cheeses 150 g Maximum 10 s

Hard baked goods 100 g Medium to maximum 20 s

Nuts with shells removed 100 g Maximum 15 s

Herbs 50 g Medium 10 s

■ First, cut up the food into approximately 2 cm cubes and only then blend it. With vegetables like onion, it is sufficient to cut them into quarters.

CLEANING AND MAINTENANCE

■ Before cleaning it, make sure that the appliance is turned off, disconnected from the power socket and that the rotating parts have stopped.

■ Disassemble the appliance into its individual parts. Thoroughly wash the used blender attachment and beaker in warm water using neutral kitchen detergent. Then rinse them

with clean water and allow them to dry naturally or dry them out thoroughly using awiping cloth.

■ When cleaning the blender attachment A4, do not submerge the top end that connects to the motor unit A3.

■ The beaker A6 and the anti-slip base pad A7 can be washed in adishwasher. Other parts are not intended for washing in adishwasher.

Attention:

When cleaning the blade assembly A5, be very careful not to injure yourself on its sharp edges.

■ After finishing using the blade assembly A5, it is also possible to clean it by submerging it in warm water with kitchen detergent, and running it for ashort time. Then disconnect

the appliance from the power socket, disassemble it, and rinse the blade assembly with clean drinking water and dry it thoroughly.

■ To clean the outer surface of the motor unit A3, use acloth lightly dipped in aweak detergent solution. After applying the detergent solution, wipe the surface with acloth

lightly dampened in clean water and then wipe dry. Do not use solvents, abrasive cleaning products, etc. for cleaning the appliance. Otherwise the surface coat of the appliance

may be damaged.

Attention:

Never submerge the motor unit A3 or the power cord in water or in any other liquid.

STORAGE

■ When you have finished using the appliance, place it and its accessories in aclean, dry place out of children’sreach. Keep the stored appliance and its accessories away from

extreme temperatures, direct sunlight and excessive humidity and do not store it in an overly dusty environment.

TECHNICAL SPECIFICATIONS

Rated voltage range ................................................................................................................................................................................................................................................................................................... 220–240 V

Rated frequency ..............................................................................................................................................................................................................................................................................................................50/60 Hz

Rated power input .............................................................................................................................................................................................................................................................................................................. 800 W

Electrical shock protection class ............................................................................................................................................................................................................................................................................................... II

Noise level .......................................................................................................................................................................................................................................................................................................................... 73 dB(A)

The declared noise emission level of the appliance is 73 dB(A), which represents alevel Aof acoustic power with respect to areference acoustic power of 1 pW.

EXPLANATION OF TECHNICAL TERMINOLOGY

Safety class for electrical shock protection:

Class II – Electrical shock protection is provided by double or heavy-duty insulation.

Changes to text and technical parameters are reserved.

- 10 -

10/2019

INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS

Dispose of used packaging material at asite designated for waste in your municipality.

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT

This symbol on products or original documents means that used electric or electronic products must not be added to ordinary municipal waste. For proper

disposal, renewal and recycling hand over these appliances to determined collection points. Alternatively, in some European Union states or other European

countries you may return your appliances to the local retailer when buying an equivalent new appliance. Correct disposal of this product helps save valuable

natural resources and prevents potential negative effects on the environment and human health, which could result from improper waste disposal. Ask your local

authorities or collection facility for more details. In accordance with national regulations penalties may be imposed for the incorrect disposal of this type of waste.

For business entities in European Union states

If you want to dispose of electric or electronic appliances, ask your retailer or supplier for the necessary information.

Disposal in other countries outside the European Union.

This symbol is valid in the European Union. If you wish to dispose of this product, request the necessary information about the correct disposal method from the local council or

from your retailer.

This appliance meets all the basic requirements of EU directives related to it.
