EN
CORDLESS HAND BLENDER
Translation of the original manual
SHB 9000WH
SHB 9001GY
SHB 9000WH
SHB 9001GY
A
9
2
3
7
13
14
6
8
15
10
11
1
12
16
4
5
17
B
2
3
4
5
1
- 1 -
06/2023
2023,
EN Cordless hand blender
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
General warnings
• This appliance may not be used by children. Keep the
appliance and its power cord away from children.
• The appliance may be used by persons with reduced
physical, sensory or mental capabilities or with alack of
experience and knowledge, if they are supervised or have
been instructed to use the appliance in asafe manner and
understand the potential dangers.
• Children must not play with the appliance.
• Cleaning and maintenance performed by the user must
not be performed by unsupervised children.
• In the event that the power cord is damaged, have it
repaired at aprofessional service centre to prevent causing
adangerous situation. It is forbidden to use the appliance if
it has adamaged power cord.
Warning:
Incorrect use may lead to injuries.
• Be especially careful not to injure yourself on the sharp
cutting edges when handling the chopping blades,
especially when removing the blades from the blending
jar, when emptying the container and when cleaning it.
- 2 -
06/2023
2023,
• The surfaces of the appliance that come into contact with
food must always be cleaned according to the instructions
in this user'smanual.
• Always turn off the appliance and disconnect it from
the power socket if you will not be using it and if you
will be leaving it without supervision, before assembly,
disassembly, cleaning or moving it.
• Before replacing the accessories or accessible parts that
move during use, turn the appliance off and disconnect it
from the power supply.
Electrical safety
• Before connecting this appliance to apower socket, make sure that the voltage stated on its rating label corresponds to the voltage in your power
socket.
• Connect the appliance only to aproperly grounded socket. Do not use an extension cord.
• Fully unwind the power cord before using it.
• Do not connect and disconnect the power cord and adapter to and from the power socket with wet hands.
• Ensure that the adapter plug contacts do not come into contact with water or any other liquid. If precisely this happens, carefully dry the power plug
before using it again.
• Do not disconnect the appliance from the power socket by pulling on the power cord. This could damage the power cord or the power socket.
Disconnect the power cord from the power socket by pulling on the plug.
• Do not place heavy items on the power cord. Make sure the power cord does not hang over the edge of atable or that it is not touching ahot
surface or sharp objects.
• Keep the power cord and adapter dry.
• If the power cord or the adapter is damaged, it must be replaced by the manufacturer, its service technician or by asimilarly qualified person, as
this will prevent adangerous situation from arising. It is forbidden to use adamaged power cord or adapter.
• Do not wind the power cord around the appliance.
• Always turn off the appliance and disconnect it from the power socket when not using it, when leaving it without supervision and before removing
or replacing accessories, and before cleaning, maintenance or storage.
• The appliance is equipped with abuilt-in long-life battery that can only be removed at aprofessional service centre. Never attempt to remove it
from the appliance yourself.
Attention:
Never disassemble the appliance for the purpose of removing the battery. Never short circuit the appliance or throw it into afire.
Incorrect use, risks releasing toxic substances or causing afire or explosion.
• Do not repair the appliance yourself or make any adjustments to it. Have all repairs or adjustments of the appliance performed at an authorised
service centre. Tampering with the appliance during the warranty period may void the warranty.
• To prevent the risk of injury by electrical shock, never submerge the motor unit and its power cord in water or any other liquid, or wash these parts
under running water.
• Always turn off the appliance and disconnect it from the power socket when you have finished charging it.
• If the appliance falls into water, under no circumstances continue using it, but rather hand it over to an authorised service centre for inspection.
• This appliance is designed for household use. Do not use it for commercial purposes or for other purposes for which it is not intended.
Safety during use
• This appliance is designed for household use and is intended for blending, chopping and whisking ingredients. It is also suitable for processing hard
ingredients such as coffee beans, cocoa beans, ice cubes, nutmeg, etc.
• Do not use the appliance in an industrial environment or outdoors. Do not use it for any other purposes than those intended.
• The appliance is intended for domestic use and similar locations such as:
- kitchens in stores; offices and other workplaces;
- in agriculture;
- for guests of hotels, motels and other similar locations;
- in bed and breakfast establishments.
• This appliance is not intended to be operated using an external timer switch or aremote control system.
- 3 -
06/2023
2023,
• Use the appliance and its accessories in accordance with the instructions contained in this user'smanual.
• Only use the appliance with the original accessories that came with it.
• Before every use, check the selected accessory for damage. Never use the appliance with adamaged accessory.
• Do not place the appliance or its accessories on an electric or gas stove or in its vicinity, on the edge of atable or on an unstable surface. Only place
the appliance on an even, dry and stable surface.
• Do not expose the appliance and its accessories to the outdoor environment, extreme temperatures, direct sunlight, excessive humidity or
excessively dusty environments.
• Do not place the appliance and its accessories near heaters, open fires or other sources of heat.
• Make sure that the appliance is correctly assembled before putting it into operation.
• Do not touch moving rotating parts during operation. Otherwise, this could result in injury.
• Be especially careful when handling hot liquids and foodstuffs. Hot steam or splattering hot foods and liquids may cause scalding. For reasons of
increased safety, allow hot foods and liquids to cool down to at least 45°C before blending.
• The operating time of the appliance is 1 minute. Before turning it on again, allow it to cool down for at least 10 minutes. When using the appliance to
blend sticky or harder foodstuffs, interrupt operation already after 30 seconds.
• Do not continuously mix dry, thick or heavy mixtures for longer than 10 seconds. Stop using the appliance and mix the ingredients together before
continuing.
• Do not turn on the appliance when it is empty. Incorrect use of the appliance may negatively affect its lifetime.
• Check that the motor unit is turned off and that the rotating parts have come to acomplete stop before disassembling the appliance into its
individual parts.
• Do not perform any maintenance on the appliance other than cleaning the individual components as described in this user'smanual.
• Never use an appliance that is damaged in any way.
• Do not use the appliance if it has fallen on the floor, if it was submerged in water, if it is not functioning correctly or if it is damaged in any other way.
• When handling the blade assembly of the blender or chopper unit, especially when taking the blade assembly out of the bowl, when emptying the
bowl and cleaning it, take special care to avoid injury by the blades.
• Do not use the appliance when it is not functioning properly or showing signs of damage.
• In order to prevent ahazardous situation arising, do not repair the appliance yourself or modify it in any way. Have all repairs performed at an
authorised service centre. By tampering with the appliance, you risk voiding your legal rights arising from unsatisfactory performance or quality
warranty.
• Store the appliance in adry environment.
- 4 -
06/2023
2023,
• Prior to using this appliance, please read the user'smanual
thoroughly, even in cases, when one has already familiarised
themselves with previous use of similar types of appliances. Only use
the appliance in the manner described in this user’smanual. Keep this
user'smanual in asafe place where it can be easily retrieved for future
use. In the event that you hand this appliance over to somebody else,
make sure to also include this user'smanual.
• Carefully unpack the appliance and take care not to throw away any
part of the packaging before you find all its parts. We recommend
saving the original cardboard box, packaging material, purchase
receipt and responsibility statement of the vendor or warranty card for
at least the duration of the legal liability for unsatisfactory performance
or quality. In the event of transportation, we recommend that you pack
the appliance in the original box from the manufacturer.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DESCRIPTION OF THE APPLIANCE
A1 Speed control buttons
A2 Battery power level indicators
A3 Body of the appliance (motor
unit)
A4 Safety button
Secures the appliance against
being accidentally started
A5 USB slot
A6 Removable blender stick
attachment
A7 Blade assembly
A8 Whisk attachment with gear
system
A9 Whisk
A10 Chopper bowl lid with gear
system
A11 Chopper with blade assembly
A12 Base stand
A13 Measuring cup, volume
700ml
A14 Chopper bowl, volume
500ml
A15 Central pin
A16 USB power cable
A17 Power cable adapter
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B1 Low speed button (I)
B2 High speed button with pulse
function (II)
B3 High battery capacity
indicator
B4 Medium battery capacity
indicator
B5 Low battery capacity indicator
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PURPOSE OF USE
STICK BLENDER ATTACHMENT
• This stainless steel stick blender is suitable for blending soft
ingredients and liquids. It is used for effective blending of ingredients
for smoothies, various types of cocktails, soups, sauces, spread, baby
food, etc.
WHISK
• The stainless steel whisk is suitable for preparing light batters or for
whipping cream, egg whites, dessert creams, liquid sponge cake
doughs, mayonnaise, etc. Do not use it to whisk thick doughs.
CHOPPER
• It is suitable for chopping tougher ingredients such as nuts, herbs,
cheeses, fruit and vegetables in their raw state or even well diced
meat. It is also suitable for chopping hard ingredients such as ice
cubes, cocoa beans, nutmeg, cocoa beans, etc.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BEFORE FIRST USE
• Wash the base stand and the beaker using warm water and neutral
kitchen detergent. Then rinse them with clean water and allow them to
dry naturally or dry them out their using awiping cloth.
• Clean the other parts with only adampened cloth. At the same time,
ensure that water does not enter into these parts, especially into the
motor unit speed control buttons. Do not submerge any of these parts
in water, do not clean them under running water or place them in
adishwasher.
Warning:
When cleaning the blade assemblies of the stick
blender and the chopper, be very careful not to injure
yourself on their sharp edges.
• Only clean the power cord and adapter using adry wiping cloth, never
wash with water.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CHARGING THE BATTERY
• To ensure the best possible performance, we recommend to fully
charge the appliance before first use. Acomplete charge takes up to
5 hours.
• Insert the smaller end of the power cord into the USB socket in the
top part of the motor unit and the larger end into the supplied power
adapter. Then insert the power adapter into apower socket.
Note:
The appliance can be charged even when located in the
base stand.
• During the charging process, indicators on the motor unit may flash or
be lit depending on the charge status. The meaning of the light signals
is the following:
Indicator (fig. B) Battery capacity
All indicators are flashing Low
Indicator B5 is lit, and indicators B4 andB3
are flashing
Medium
All indicators are lit
The battery is fully
charged
• After acomplete charge, the battery enables up 8-10 work cycles. The
actual number of cycles, however, will differ depending on the load
placed on the blender, operating mode and the ingredients that are
processed. For example, with frequent use of high speed, the battery
will discharge faster.
RECOMMENDATIONS FOR EXTENDING THE LIFETIME OF THE
BATTERY
• In order for the battery to serve you as long as possible, charge,
use and store the appliance in adry environment at an ambient
temperature of 15-35°C. Lower or higher temperatures have
anegative impact on the lifespan of the battery.
• When the appliance is not used for an extended period of time, charge
it at least once every 6 months.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ASSEMBLY
Attention:
Before attaching/removing attachments or
assembling/disassembling the chopper, the motor
unit must be turned off and disconnected from the
power cord.
When handling the blade assembly or the chopper,
be very careful not to injure yourself on the sharp
cutting edges.
BEATING OR WHISKING ATTACHMENTS
• Depending on the type of activity, select an attachment and place
it against the motor unit from below. Align the locking tabs on the
EN
Cordless hand blender
User'smanual
- 5 -
06/2023
2023,
attachment with the grooves on the motor unit and turn the motor unit
in the clockwise direction until it is securely seated in place.
• To release the attachment from the motor unit, firmly grasp both parts
and turn the motor unit anticlockwise until the tabs are released from
the grooves. Then pull the attachment out of the motor unit.
CHOPPER AND BEAKER
• Place the blending beaker on an even and stable surface. Put the
chopper on to the central pin located on the bottom of the beaker.
• Put the lid on to the beaker so that the shaft of the chopper slides into
the central part of the lid and turn the lid clockwise until it is firmly
secured in place.
• Mount the motor unit on to the lid following the same procedure as
when mounting the attachments.
• To remove them proceed in the reverse sequence to their assembly.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OPERATION
Attention:
Always keep fingers, hair, clothing, etc. at asafe
distance from the moving blade assembly of the
blender and the chopper blades.
Do not use the blending attachment to process very
hard ingredients such as coffee beans, ice, bone-in
meat or frozen foods, etc. Processing these foods
may damage the appliance.
Do not blend hot ingredients. Splattering hot liquids
and ingredients may cause serious scalding. For
reasons of increased safety, allow hot ingredients to
cool down to at least 45°C before blending them.
Note:
You may detect aslight odour when the appliance is used
for the first time. That is normal and this odour will go away
with further use.
CONTROLS
• To start the appliance, first press the safety button on the top part of
the motor unit. Indicators B3 to B5 will start flashing, which means
that the appliance is unlocked and ready for use.
• Press and hold down the low (I) or high (II) speed button. Releasing the
button will stop the turning of the appliance.
Note:
If you do not press any speed button within acertain time,
the indicators will turn off and the buttons will be locked.
The appliance is thus secured against being accidentally
started.
• If you wish to prevent ingredients from being excessively pulverised or
to prevent ingredients from spraying out of the beaker when blending
at high speed, we recommend using so-called pulse switching. Press
and hold down button (II) for approx. 5 seconds and then release it.
Wait afew moments and then repeat the procedure. However, do not
use these pulse intervals for longer than 1 minute.
Note:
If you have been using the pulse intervals for 1 minute
then leave the appliance idle for 5 minutes to allow it to
cool down.
BLENDING AND WHISKING
• Select the attachment that you wish to use, and mount it according to
the instructions in the chapter ASSEMBLY.
• Place the ingredients into the included beaker or another larger
kitchen container. Do not overfill the beaker past the maximum level
mark. In the event that there is no maximum level mark, fill it up to
amaximum of 2/3 of its capacity. This will prevent splattering the
ingredients while they are processed.
• Use one hand to hold the appliance by the top part of the motor unit
and submerge the attachment into the prepared ingredients. Use the
other hand to hold the container with the ingredients.
• Select the speed by pressing the respective button and move the
blender slowly up and down in circular motions so that the ingredients
are blended.
• As soon as the ingredients are processed, release the speed button
and wait for the blade assembly or beaters/whisks to come to astop.
Only then remove the attachment from the container.
Attention:
The maximum continuous operating time of the
appliance is 1 minute. Then allow it to cool down for
approximately 10 minutes. When using the appliance
to blend sticky or harder foodstuffs, interrupt
operation already after 30 seconds.
CHOPPER
• When assembling the chopper, first place the chopper on to the
central pin on the bottom of the beaker and only then insert the
ingredients. Do not fill the beaker past the maximum level mark.
• Mount the lid and motor unit on to the beaker as described in chapter
ASSEMBLY.
• Use one hand to hold the appliance by the top part of the motor unit
and the other to hold the beaker.
• Start the chopper by pressing the button and process the ingredients.
• As soon as the ingredients are processed, release the speed button
and wait for the chopper to come to astop. Only then remove the lid
with the motor unit from the beaker.
AUTOMATIC ANTI-OVERLOADING FUNCTION
• The appliance has an automatic anti-overloading function. In the event
that the motor unit is overloaded, e.g. due to the ingredients being too
tough or hard, indicators B3 to B5 will simultaneously flash five times
and then the unit will turn itself off. If this happens, allow the appliance
to rest for at least 10 minutes and adjust the amount and/or size of the
ingredients. Only then continue using the appliance.
BATTERY CAPACITY INDICATOR
• The battery will start discharging when the appliance is used. Its
capacity is shown using indicators B3 to B5 as follows:
Indicator Battery capacity
All indicators are lit High
Indicators B4 to B5 are lit
Medium
Indicator B5 is lit
Low
Indicator B5 is flashing
The battery is almost flat
ADVICE AND TIPS
• Before blending or chopping, remove hard parts such as fruit stones
or bones from the blended ingredients. This will prevent damaging the
blade assembly.
• To make blending and chopping easier, cut hard ingredients into small
pieces.
• When using the blender attachment, it is recommended to always
start blending at speed level (I). While blending, move the blender up
and down to blend the ingredients to the required consistency.
• To prevent ingredients from splattering, put the blender attachment
or the whisk into the beaker containing the ingredients before starting
it, and conversely turn it off before pulling the attachment out of the
beaker.
• To prevent ingredients from splattering, keep the blade assembly of
the blending attachment and whisk submerged while the appliance
is running. It is recommended to divide alarger amount of processed
ingredients into several batches and to regularly inspect the contents
inside the beaker.
• When using the blender or chopper attachment, it is recommended
to process ingredients using pulse switching with speed (II). This will
prevent the ingredients from being excessively pulverised and optimal
results will be achieved.
• To achieve better blending results, hold the stick blender slightly tilted,
while carefully moving it up and down in the beaker. Do not use force
to push ingredients down with the stick blender.
- 6 -
06/2023
2023,
QUICK GUIDE TO PROCESSING INGREDIENTS
• The food processing times provided below are only areference. The
actual processing time depends on the size of the ingredients, their
amount and the required final consistency. If the required consistency
is not achieved during the maximum operating time of the appliance,
you may continue processing the food after the appliance has cooled
down.
BLENDING
INGREDIENTS AMOUNT
SPEED
SETTING
PROCESSING
TIME
Baby food 300g (I) to (II) 45 s
Spreads 200g (I) to (II) 30 s
Fruit and
vegetables
(cooked)
200g (I) to (II) 45 s
Sauces 500ml (I) to (II) 45 s
Shakes 500ml (I) to (II) 30 s
WHISKING
INGREDIENTS AMOUNT
SPEED
SETTING
PROCESSING
TIME
Egg whites 4 pcs (II) 60 s
Whipping cream 200ml (II) 60 s
Light doughs 500g (I) to (II) 60 s
CHOPPER
INGREDIENTS AMOUNT
SPEED
SETTING
PROCESSING
TIME
Meat 300g (I) to (II) 30 s
Fruit and
vegetables
200g (I) to (II) 15 s
Hard and semi-
hard cheeses
150g (II) 10 s
Hard baked
goods
100g (I) to (II) 20 s
Nuts with shells
removed
100g (II) 15 s
Herbs 50g (I) to (II) 10 s
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CLEANING AND MAINTENANCE
Warning:
When cleaning the blade assemblies of the stick
blender and the chopper, be very careful not to injure
yourself on their sharp edges.
Do not use solvents, abrasive cleaning products, etc.
for cleaning the appliance. Otherwise the surface coat
of the appliance may be damaged.
• Before cleaning, the appliance must be turned off and disconnected
from the power cord.
• Disassemble the appliance into its individual parts. Thoroughly wash
the blade assembly, whisk or chopper and beaker in warm water and
neutral kitchen detergent. Then rinse them with clean water and allow
them to dry naturally or dry them out thoroughly using awiping cloth.
Attention:
When washing attachments, ensure that water does
not enter into the top parts by means of which they
are mounted on to the motor unit. These parts contain
agear system that could be damaged by water.
Do not submerge any of the attachments or the lid
entirely in water, do not clean them under running
water or place them in adishwasher.
• When you have finished using the stick blender, it is possible to clean
the blade assembly by submerging it in warm water with kitchen
detergent, and running it for ashort time. Then remove the attachment
and rinse the blade assembly with clean drinking water and dry it
thoroughly.
• Wipe the motor unit with adry or slightly dampened cloth. Make sure
that water does not enter into speed control buttons.
• Only clean the power cord and adapter using adry wiping cloth, never
wash with water liquids or other liquids.
• Never dry parts of the appliance over heat sources such as wood
stoves, electric or gas stoves, etc.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
STORAGE
• When you have finished using the appliance and have cleaned it,
place it and its accessories in aclean, dry place out of children'sreach.
Keep the stored appliance and its accessories away from extreme
temperatures, direct sunlight and excessive humidity and do not store
it in an overly dusty environment.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TECHNICAL SPECIFICATIONS
Power Adapter:
Input ....................................................................100-240V ~ 50/60Hz, 0.5A Max
Output ..........................................................................................5.0V
2.0A, 10W
Unit:
Battery ..................................................................................... 11,1V Li-Ion, 2000mAh
Rated Input ............................................................................................5.0V 2.0A
Work Power ..........................................................................................................200W
Electrical shock protection class ............................................................................... II
Noise level ........................................................................................................90 dB(A)
The declared noise emission level of the appliance is 90dB(A), which
represents alevel Aof acoustic power with respect to areference acoustic
power of 1 - pW.
Explanation of technical terminology
Safety class for electrical shock protection:
Class II – Electrical shock protection is provided by
double or heavy-duty insulation.
Changes to text and technical parameters are reserved.
- 7 -
06/2023
2023,
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF
USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your
municipality.
DISPOSAL OF USED BATTERIES
Prior to handing over the appliance at aspecialised collection facility, it is
necessary to ensure that the built-in battery is removed. Battery removal
will be performed at the authorised service centre. In the event that the
product has been disassembled for the purpose of ecological disposal
then it must not be reassembled.
This symbol indicates that the used battery does not
belong in ordinary municipal waste. Hand over the used
battery to designated collection points for proper disposal.
Correct disposal of the battery will help prevent negative
impacts on the environment and human health.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this
product, request the necessary information about the correct disposal
method from the local council or from your retailer.
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF
USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your
municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that
used electric or electronic products must not be added to
ordinary municipal waste. For proper disposal, renewal and
recycling, hand over these products to determined
collection points. Alternatively, in some European Union
states or other European countries you may return your
appliances to the local retailer when buying an equivalent
new appliance. Correct disposal of this product helps save
valuable natural resources and prevents potential negative effects on the
environment and human health, which could result from improper waste
disposal. Ask your local authorities or collection facility for more details. In
accordance with national regulations penalties may be imposed for the
incorrect disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electrical or electronic equipment, ask your
retailer or supplier for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this
product, request the necessary information about the correct disposal
method from the local council or from your retailer.
This product meets all the basic requirements of EU
directives related to it.
FAST ČR, a.s.
U Sanitasu 1621
CZ-251 01 Říčany
www.sencor.eu
