The RICOH WG- Series: Hard-Working Cameras
Rugged high-performance model
Shockproof to 2.1m
Withstands as cold as -10℃ with dustproof quality
20m waterproof for up to 2 hours
Shockproof performance helps WG‑series
cameras withstand accidental drops. The
WG‑6 has passed RICOH’s in‑house version
of the Pentagon MIL‑Standard 810F Method
516.5–Shock drop test (a drop of 2.1m onto a
5cm. thick plywood surface).
With a body that keeps out dust and sand,
WG‑series cameras can be used on demolition
worksites and in other dusty locations, in cold
regions, and on winter building sites.
Dustproof: IP 68/JIS Class 6
WG‑series cameras can be used worry‑free
on muddy jobsites, in the rain, or where the
sea‑spray ies—and any dirt or salt can be
safely washed off with water.
Waterproof: IPX8/ JIS Class 8
Tough, full-featured base model
RICOH WG-6 Orange RICOH WG-70 OrangeRICOH WG-6 Black RICOH WG-70 Black
Toughness
A lens threaded for 37mm lters
A lens threaded for 37mm lters allows
the WG‑6 to be used with a wide variety of
third‑party lters, including PL lters and
protective lters to avoid dust, scratches and
condensation from the lens.
(WG‑6 only)
©
2020 Ricoh Imaging Americas Corporation
Support for DW‑5, 0.8X wide‑angle conversion lenses allows focal lengths as wide as 22mm (35 mm format equivalent). The DW‑5 not only lets you get large
objects in the frame when shooting outdoors, but helps you compose photographs in cramped indoor spaces that offer a limited choice of vantage points. It’s also
waterproof*, letting you use it in the rain.
* JIS Class 7.
Note: The WG‑6 attached with DW‑5 can be stored in the SC‑900 camera case.
Choose Digital Microscope mode for ultra‑close closeups lit by the camera’s LED Ring Light, letting you easily record ne details invisible to the naked eye.
RICOH-brand protector jackets
RICOH‑brand protector jackets are available to
shield the camera from impacts and scratches
while improving your grip and making the
buttons easier to operate.
Toughness
Wide and Macro
A wide-angle zoom lens with a
minimum focal length of 28mm
Outstanding macro performance
Support for wide-angle conversion lenses
Choose Digital Microscope mode to shoot from as close as 1cm
A 28mm–140mm *zoom lens offers a wide
angle of view even in small spaces.
*35 mm format equivalent.
Outstanding macro performance delivered by the
camera’s superior optics lets you shoot close‑ups
from ranges as little as 10cm for high‑resolution
photos that capture every detail of your subject,
down to its texture and individual lumps and
bumps. Perfect for photo records of precision
machinery or wherever ne details need be noted.
Macro mode
(WG‑6 only)
Note: The built‑in ash cannot be used as the light will be
blocked when the DW‑5 is attached.
Wide Conversion Lens DW-5 28mm 22mm
Comes with handy macro stand
WG‑70: 2M resolution, shot at maximum
magnication (optical + digital zoom)
WG‑70: 2M resolution, shot at
maximum magnication
(optical + digital zoom)
WG‑70: 12M resolution
(optical zoom; resolution of
12M in Digital Microscope mode
available with WG‑70 only)
Note: Image size for the WG‑6 is xed at 3M(4:3)
Recommended for
educational institutions
Subject for comparison photos is a crack gauge scale
O‑CC173 O‑CC1252
©
2020 Ricoh Imaging Americas Corporation
Note: Monitor display is concept art.
Taken using just the 3 LEDs on one side
A powerful, adjustable Ring Light
Equipped for low-light situation
A powerful, adjustable Ring Light with LEDs that can be selectively turned on or off gives you clear, 3D views of cracks and
other subjects best examined in close‑ups. Brightness can be adjusted according to the distance to your subject, preventing
loss of detail in highlights when using the monitor to frame shots under the oor and in tight spots.
Equipped with the latest technology—a CMOS image sensor that works well at high sensitivities and an image processing engine that excels at noise reduction—
WG‑series cameras can be used for ashless low‑light photography not only in darkened rooms but even at night with the faintest of light when the subject is too
distant to be lit by the ash.
Actual brightness Flash: AUTO
ISO: AUTO (125‑1600)
Flash: OFF
ISO: 6400
The WG‑6’s excellent performance at high sensitivities lets you
capture background details without using a ash.
Note: Illustratoins are concept art.
Low-Light Performance
Worksite-Ready
Simulation of Ring Light in action
Lighting adds shadows, throwing cracks
and other details into relief (concept art).
Quick access to frequently used settings
Settings can be saved to the U1 and U2 positions on
the mode dial for instant recall. These modes offer
a hassle‑free way of optimizing settings to the job
when you need to work fast to take photos for record
keeping. It can also help ensure that different workers
operating a shared camera use the same settings.
User modes
A customizable ADJ button
The customizable ADJ button can be used to quickly
view and change any one of the few core settings.
The button can be assigned whatever feature you
access most frequently
(at default settings, movie recording is assigned, but its role can
be changed via the menus).
ADJ button
©
2020 Ricoh Imaging Americas Corporation
Designed for comfortable hold and ease of use
Use for record-keeping on construction or building sites and in the lab, warehouse, and many more
work-related applications, including job or product inspection, project management, and advertising!
Featuring a secure grip designed for the best placement of your ngers on the
front and back of the camera, you’ll nd the WG‑6 easy to hold even while
wearing gloves. The big buttons make it even easier to use.
The indentations at the center make the WG‑70 easy to hold and help you keep
your grip, even in the rain.
The WG‑6 features three strap eyelets for a choice of two‑point strap congurations
that the keep the camera out of the way of your work.
With its slim design, the WG‑70 ts in the pockets of your work clothes.
©
2020 Ricoh Imaging Americas Corporation
WG-6/WG-70 Comparison Chart
Toughness
Low-Light Performance
Worksite-Ready
Worksite-Ready
Wide and Macro
Waterproof
Shockproof
Crushproof
Freezeproof
Filter support
High‑sensitivity performance
Effective pixels
Sensitivity
Display size
Display resolution
Display font quality
GPS
Movie recording
Movie shake reduction (SR)
External interface Tripod Mount
Ring Light
User mode
Customizable controls
Grip
Rear buttons
Outdoor View
Strap eyelets
Tripod Mount
Zoom lens
Wide Conversion Lens support
Macro
Digital Microscope mode
20m
2.1m
100kgf
‑10°C
Third‑party protective lters can be used to protect
the lens. PL lters can also be used.
Excellent
Excellent Good
Excellent
Excellent Good
Good
Good
Excellent Good
Equipped with the latest image processing engine
Settings can be saved to U1 and U2. ‑
Quick adjustment available via the ADJ button for
any one of 6 selectable settings.
Green button only (1 setting)
Green button
Excellent grip provided by rear thumb position and
nger pad on front of camera.
Central indentations for a secure grip, and a slim
design that allows the camera to be placed securely
in a pocket when not in use.
Large, widely‑spaced buttons that can be handled
easily even with gloves on.
‑
Three eyelets for two‑point suspension One eyelet
Metal, situated in the center of the camera body
20 megapixels 16 megapixels
ISO 125–6400 ISO 125–6400
3″, aspect ratio 4 : 3 2.7″, aspect ratio 16 : 9
1040K dots 230K dots
� ‑
4K Full HD
Movie SR+ MovieSR
USB 3.0 (Type C), HDMI output terminal (Type D) USB 2.0 (Micro B), HDMI output terminal (Type D)
Easy‑to‑read outline font Bitmap font
Plastic, situated at one end of the camera body
� �
Equipped with 6 powerful, adjustable LEDs that can
be selectively turned on or off, perfect not only for
low‑light macro photography but also for clear shots
of cracks and other ne details.
Except in Digital Microscope mode, the ring light can
be turned on to provide additional lighting
(brightness adjustment is not available).
Approx. 28mm ‑ 140mm*
Supports DW‑5 (optional accessory) for a combined
focal length equivalent to 22mm*
0.1m–0.6m (over entire zoom range)
Image size xed at 3M (4 : 3)
14m
1.6m
100kgf
‑10°C
‑
Approx. 28mm ‑ 140mm*
‑
0.1m–0.6m (over entire zoom range)
Image size can be selected from options ranging
from 2M–12M (16 : 9)
*All focal lengths are 35mm format equivalent.
