Friedrich FPHW243A 24000 BTU Single Zone Mini Split System with Wall Mounted Heat Pump, WiFi, Remote Control, Sleep Mode and Auto Restart - 230/208 Volts

Installation Manual

For FPHW243A. Also, The document are for others Friedrich models: FPHFW09A3A, FPHSR09A3A, FPHFW12A3A, FPHSR12A3A, FPHFW18A3A, FPHSR18A3A, FPHFW24A3A, FPHSR24A3A, FPHSW36A3A, FPHSR36A3A, FRHSW09A1A, FRHSR09A1A, FPHSW12A1A, FPHSR12A1A, FRHSW09A3A, FRHSR09A3A, FRHSW12A3A, FRHSR12A3A

PDF File Manual, 92 pages, Read Online | Download pdf file

FRHSW09A1A

FRHSR09A1A

FPHSW12

A1A

FPHSR12A1A

FRHSW09A3A

FRHSR09A3A

W12

A3A

FRHSR12A3A

F3H)W09A3A

F3HS509A3A

F3HS5A3A

F3H)W1A3A

FPHS518A3A

FPHFW24A3A

FPHSR24A3A

FPHSW36A3A

FPHSR36A3A

F3HW09

F3H)W12A3AF3HW123

F3+:

F3+:

F3+:

F3+:

F3+:

FRH:

F5+:

Loading ...

File type: PDF

File name: 11139613_fphw243a.pdf

File size: 40.61 MB

File Language: English, French, Spanish

Pages: 92

Author: Friedrich

File created: 2022-03-11

Published: 2022-06-02

Updated: 2023-12-04

Verified by Delores Murray on 2023-12-04

Download File

Specifications

Brand: Friedrich

Model: FPHW243A

Category: Air Conditioners

Width: 45 1/8 Inch

Depth: 10 Inch

Height: 13 1/8 Inch

Net Weight: 33 Lbs.

Shipping Weight: 38.5 Lbs.

Heating Capacity: 26,000 BTU

Liquid Line Outer Diameter: 3/8 Inch

Suction Line Outer Diameter: 5/8 Inch

Min. Line Length Total: 10 Ft.

Max. Line Length Total: 66 Ft.

Min Connectable Capacity: 1 BTU

Max Connectable Capacity: 1 BTU

Max. Height Diff. btwn. Indoor and Outdoor Units: 33 Ft.

Operation: Cooling with Heat Pump

Energy Star Certified: Yes

Operating Sound Level Quiet: 33 dB

Operating Sound Level Low: 36 dB

Operating Sound Level Medium: 42 dB

Operating Sound Level High: 47 dB

Program Timer: Yes

Sleep Mode: Yes

Self Cleaning Indoor Coil: Yes

Parts Warranty: 5 Year

Compressor Noise Level Cooling: 58 dB

Compressor Noise Level Heating: 58 dB

Outside Temperature Range for Cooling Min.: 5 °F

Outside Temperature Range for Cooling Max.: 115 °F

Outside Temperature Range for Heating Min.: 4 °F

Outside Temperature Range for Heating Max.: 75 °F

Low Ambient Operating Threshold: 4

Wireless Remote Control Included: Included

Refrigerant Connection Type: Flare

WiFi Connected: Yes

Min No. of Connectible Indoor Units: 1

Max No. of Connectible Indoor Units: 1

Power and Communication Cable No.: 4

Power and Communication Cable AWG: 14

Auto Restart on Power Failure: Yes

Voltage: 230/208 Volts

Power Input Cooling Rated: 1,880 Watts

Power Input Heating Rated: 2,500 Watts

Refrigerant Charge: 66.3 Ft.
