User Manual Friedrich FD36K2RPACK07 48 pages

Specifications

Brand: Friedrich

Model: FD36K2RPACK07

Category: Fans

Width: 22 1/2 Inch

Depth: 22 1/2 Inch

Height: 8 1/2 Inch

Net Weight: 33 Lbs.

Shipping Weight: 39.7 Lbs.

Heating Capacity: 12,000 BTU

Liquid Line Outer Diameter: 1/4 Inch

Suction Line Outer Diameter: 3/8 Inch

Min. Line Length Total: 10 Ft.

Max. Line Length Total: 82 Ft.

Max Connectable Capacity: 48,000 BTU

Min. Line Length Each: 25 Ft.

Max. Line Length Each: 66 Ft.

Max. Height Diff. btwn. Indoor and Outdoor Units: 49 Ft.

Max. Height Diff. btwn. Indoor Units: 24 Ft.

Operation: Cooling with Heat Pump

Energy Star Certified: Yes

Operating Sound Level Low: 33 dB

Operating Sound Level Medium: 37 dB

Operating Sound Level High: 42 dB

Program Timer: Yes

Sleep Mode: Yes

Quiet/Sleep Mode: Yes

Parts Warranty: 5 Year

Auto Operation: Yes

Compressor Noise Level Cooling: 59 dB

Compressor Noise Level Heating: 59 dB

Drain Line Inner Diameter: 13/22 Inch

Outside Temperature Range for Cooling Min.: 14 °F

Outside Temperature Range for Cooling Max.: 115 °F

Outside Temperature Range for Heating Min.: 13 °F

Outside Temperature Range for Heating Max.: 75 °F

Low Ambient Operating Threshold: 4

Wireless Remote Control Included: Included

Refrigerant Connection Type: Flare

WiFi Connected: Yes

Min No. of Connectible Indoor Units: 1

Max No. of Connectible Indoor Units: 4

Wired Remote Control Included: Optional

Control Lock Function: Yes

Power and Communication Cable No.: 4

Power and Communication Cable AWG: 14

Auto Restart on Power Failure: Yes

Voltage: 230 Volts

Power Input Cooling Min.: 700 Watts

Power Input Cooling Rated: 2,520 Watts

Power Input Cooling Max.: 5,000 Watts

Power Input Heating Min.: 600 Watts

Power Input Heating Rated: 3,060 Watts

Power Input Heating Max.: 6,000 Watts

Factory Precharge: 106 Oz.

See other models: FD36K2RPACK08 FD36K4RPACK12 FD36K2RPACK01 FD36K2RPACK02 FD36K3RPACK01

Friedrich FD36K2RPACK07 Dual Zone Mini Split System
