User’s Manual
MODEL:
Microwave Oven
CCM07M1B
4558001
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY....................................................................................
SPECIFICATIONS.............................................................................................
IMPORTANT SAFETY INSTRUCTIONS...........................................................
GROUNDING INSTRUCTIONS......................................................................... 7
UTENSILS.......................................................................................................... 9
MATERIALS YOU CAN USE IN MICROWAVE OVEN.......................................
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN.................................... 10
SETTING UP YOUR OVEN................................................................................11
OPERATION.......................................................................................................13
3
3
4
10
MAINTENANCE..................................................................................................19
WARRANTY........................................................................................................2 0
2
(a). Do not attempt to operate this oven with the door
open since open door operation can result in
harmful exposure to microwave energy.
It is important not to defeat or tamper with the
safety interlocks.
(b). Do not place any object between the oven front face
and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
(c). Do not operate the oven if it is damaged. It is
particularly important that the oven door closes
properly and that there is no damage to the:
(1). DOOR (bent)
(2). HINGES AND LATCHES (broken or loosened)
(3). DOOR SEALS AND SEALING SURFACES
(d). The oven should not be adjusted or repaired by
anyone except properly qualified service personnel.
Specifications
Model:
Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Oven Capacity:
Turntable Diameter:
External
Dimensions:
Net Weight:
120V~60Hz
1050W
700W
CCM07M1B
10. 0 inches
0.7Cu.ft
Approx.19.97
17.30(W)x12.99(D)x10.14(H)inches
LBS
3
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
When using electrical appliances basic safety
precautions should be followed, including the following.
To reduce the risk of burns, electric shock, fire, injury to
persons or exposure to excessive microwave energy.
1. Read all instructions before using the appliance.
2. Read and follow the specific: "PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY" found on page 3.
3. This appliance must be grounded. Connect only to
properly grounded outlet. See "GROUNDING
INSTRUCTIONS" found on page 7.
4. Install or locate this appliance only in accordance with
the provided installation instructions.
5. Some products such as whole eggs and sealed
containers - for example, closed glass jars - are able
to explode and should not be heated in this oven.
6. Use this appliance only for its intended use as
described in the manual. Do not use corrosive
chemicals or vapors in this appliance. This type of
oven is specifically designed to heat, cook or dry food.
It is not designed for industrial or laboratory use.
7. As with any appliance, close supervision is necessary
when used by children.
8. Do not operate this appliance if it has a damaged cord
or plug, if it is not working properly, or if it has been
damaged or dropped.
9. This appliance should be serviced only by qualified
service personnel. Contact nearest authorized service
facility for examination, repair, or adjustment.
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this
product near water - for example, near a kitchen
sink, in a wet basement, near a swimming pool, or
similar location.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surface.
14. Do not let cord hang over edge of table or counter.
15. When cleaning surfaces of door and oven that comes
together on closing the door, use only mild,
nonabrasive soaps, or detergent applied with a
sponge or soft cloth.
16. To reduce the risk of fire in the oven cavity:
− Do not overcook food. Carefully attend appliance
when paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
− Remove wire twist-ties from paper or plastic bag
before placing bag in oven.
− If material inside of the oven ignite, keep oven door
closed, turn oven off, and disconnect the power
cord, or shut off power at the fuse or circuit
breaker panel.
− Do not use the cavity for storage purposes. Do not
leave paper products, cooking utensils, or food in
the cavity when not in use.
17. Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without appear-
ing to be boiling. Visible bubbling or boiling when the
container is removed from the microwave oven is not
always
present. THIS COULD RESULT IN VERY HOT
LIQUID SUDDENLY BOILING OVER WHEN THE
CONTAINER IS DISTURBED OR A UTENSIL IS
INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons:
− Do not overheat the liquid.
− Stir the liquid both before and halfway through
heating it.
− Do not use straight-sided containers with narrow
necks.
− After heating, allow the container to stand in the
microwave oven for a short time before removing
the container.
− Use extreme care when inserting a spoon or other
utensil into the container.
SAVE THESE INSTRUCTIONS
4
IMPORTANT SAFETY
INSTRUCTIONS
When using electrical appliances basic safety
precautions should be followed, including the following.
To reduce the risk of burns, electric shock, fire, injury to
persons or exposure to excessive microwave energy.
1. Read all instructions before using the appliance.
2. Read and follow the specific: "PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY" found on page 2.
3. This appliance must be grounded. Connect only to
properly grounded outlet. See "GROUNDING
INSTRUCTIONS" found on page 5.
4. Install or locate this appliance only in accordance with
the provided installation instructions.
5. Some products such as whole eggs and sealed
containers - for example, closed glass jars - are able
to explode and should not be heated in this oven.
6. Use this appliance only for its intended use as
described in the manual. Do not use corrosive
chemicals or vapors in this appliance. This type of
oven is specifically designed to heat, cook or dry food.
It is not designed for industrial or laboratory use.
7. As with any appliance, close supervision is necessary
when used by children.
8. Do not operate this appliance if it has a damaged cord
or plug, if it is not working properly, or if it has been
damaged or dropped.
9. This appliance should be serviced only by qualified
service personnel. Contact nearest authorized service
facility for examination, repair, or adjustment.
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this
product near water - for example, near a kitchen
sink, in a wet basement, near a swimming pool, or
similar location.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surface.
14. Do not let cord hang over edge of table or counter.
15. When cleaning surfaces of door and oven that comes
together on closing the door, use only mild,
nonabrasive soaps, or detergent applied with a
sponge or soft cloth.
16. To reduce the risk of fire in the oven cavity:
− Do not overcook food. Carefully attend to appliance
when paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
− Remove wire twist-ties from paper or plastic bag
before placing bag in oven.
− If material inside of the oven ignites, keep oven door
closed, turn oven off, and disconnect the power
cord, or shut off power at the fuse or circuit
breaker panel.
− Do not use the cavity for storage purposes. Do not
leave paper products, cooking utensils, or food in
the cavity when not in use.
17. Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without appear-
ing to be boiling. Visible bubbling or boiling when the
container is removed from the microwave oven is not
always
present. THIS COULD RESULT IN VERY HOT
LIQUID SUDDENLY BOILING OVER WHEN THE
CONTAINER IS DISTURBED OR A UTENSIL IS
INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons:
− Do not overheat the liquid.
− Stir the liquid both before and halfway through
heating it.
− Do not use straight-sided containers with narrow
necks.
− After heating, allow the container to stand in the
microwave oven for a short time before removing
the container.
− Use extreme care when inserting a spoon or other
utensil into the container.
SAVE THESE INSTRUCTIONS
5
When using electrical appliances basic safety
precautions should be followed, including the following.
To reduce the risk of burns, electric shock, fire, injury to
persons or exposure to excessive microwave energy.
1. Read all instructions before using the appliance.
2. Read and follow the specific: "PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY" found on page 2.
3. This appliance must be grounded. Connect only to
properly grounded outlet. See "GROUNDING
INSTRUCTIONS" found on page 5.
4. Install or locate this appliance only in accordance with
the provided installation instructions.
5. Some products such as whole eggs and sealed
containers - for example, closed glass jars - are able
to explode and should not be heated in this oven.
6. Use this appliance only for its intended use as
described in the manual. Do not use corrosive
chemicals or vapors in this appliance. This type of
oven is specifically designed to heat, cook or dry food.
It is not designed for industrial or laboratory use.
7. As with any appliance, close supervision is necessary
when used by children.
8. Do not operate this appliance if it has a damaged cord
or plug, if it is not working properly, or if it has been
damaged or dropped.
9. This appliance should be serviced only by qualified
service personnel. Contact nearest authorized service
facility for examination, repair, or adjustment.
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this
product near water - for example, near a kitchen
sink, in a wet basement, near a swimming pool, or
similar location.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surface.
14. Do not let cord hang over edge of table or counter.
15. When cleaning surfaces of door and oven that comes
together on closing the door, use only mild,
nonabrasive soaps, or detergent applied with a
sponge or soft cloth.
16. To reduce the risk of fire in the oven cavity:
− Do not overcook food. Carefully attend appliance
when paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
− Remove wire twist-ties from paper or plastic bag
before placing bag in oven.
− If material inside of the oven ignite, keep oven door
closed, turn oven off, and disconnect the power
cord, or shut off power at the fuse or circuit
breaker panel.
− Do not use the cavity for storage purposes. Do not
leave paper products, cooking utensils, or food in
the cavity when not in use.
17. Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without appear-
ing to be boiling. Visible bubbling or boiling when the
container is removed from the microwave oven is not
always
present. THIS COULD RESULT IN VERY HOT
LIQUID SUDDENLY BOILING OVER WHEN THE
CONTAINER IS DISTURBED OR A UTENSIL IS
INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons:
− Do not overheat the liquid.
− Stir the liquid both before and halfway through
heating it.
− Do not use straight-sided containers with narrow
necks.
− After heating, allow the container to stand in the
microwave oven for a short time before removing
the container.
− Use extreme care when inserting a spoon or other
utensil into the container.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY(
NOT
FOR COMMERCIAL USE)
6
When using electrical appliances basic safety
precautions should be followed, including the following.
To reduce the risk of burns, electric shock, fire, injury to
persons or exposure to excessive microwave energy.
1. Read all instructions before using the appliance.
2. Read and follow the specific: "PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY" found on page 2.
3. This appliance must be grounded. Connect only to
properly grounded outlet. See "GROUNDING
INSTRUCTIONS" found on page 5.
4. Install or locate this appliance only in accordance with
the provided installation instructions.
5. Some products such as whole eggs and sealed
containers - for example, closed glass jars - are able
to explode and should not be heated in this oven.
6. Use this appliance only for its intended use as
described in the manual. Do not use corrosive
chemicals or vapors in this appliance. This type of
oven is specifically designed to heat, cook or dry food.
It is not designed for industrial or laboratory use.
7. As with any appliance, close supervision is necessary
when used by children.
8. Do not operate this appliance if it has a damaged cord
or plug, if it is not working properly, or if it has been
damaged or dropped.
9. This appliance should be serviced only by qualified
service personnel. Contact nearest authorized service
facility for examination, repair, or adjustment.
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electric current. This appli-
ance is equipped with a cord having a grounding wire with a
grounding plug. The plug must be plugged into an outlet that
is properly installed and grounded.
WARNING - Improper use of the grounding can result in a risk
of electric shock. Consult a qualified electrician or serviceman
if the grounding instructions are not completely understood, or
if doubt exists as to whether the appliance is properly ground-
ed. If it is necessary to use an extension cord, use only a
3-wire extension cord that has a 3-blade grounded plug, and
3-slot receptacle that will accept the plug on the appliance.
The marked rating of the extension cord shall be equal to or
greater than the electrical rating of the appliance.
DANGER - Electric Shock Hazard
Touching some of the internal components can cause serious
personal injury or death. Do not disassemble this appliance.
WARNING - Electric Shock Hazard
Improper use of the grounding can result in electric shock. Do
not plug into an outlet until appliance is properly installed and
grounded.
1. A short power-supply cord is provided to reduce the risks
resulting from becoming entangled in or tripping over a
longer cord.
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this
product near water - for example, near a kitchen
sink, in a wet basement, near a swimming pool, or
similar location.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surface.
14. Do not let cord hang over edge of table or counter.
15. When cleaning surfaces of door and oven that comes
together on closing the door, use only mild,
nonabrasive soaps, or detergent applied with a
sponge or soft cloth.
16. To reduce the risk of fire in the oven cavity:
− Do not overcook food. Carefully attend appliance
when paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
− Remove wire twist-ties from paper or plastic bag
before placing bag in oven.
− If material inside of the oven ignite, keep oven door
closed, turn oven off, and disconnect the power
cord, or shut off power at the fuse or circuit
breaker panel.
− Do not use the cavity for storage purposes. Do not
leave paper products, cooking utensils, or food in
the cavity when not in use.
17. Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without appear-
ing to be boiling. Visible bubbling or boiling when the
container is removed from the microwave oven is not
always
present. THIS COULD RESULT IN VERY HOT
LIQUID SUDDENLY BOILING OVER WHEN THE
CONTAINER IS DISTURBED OR A UTENSIL IS
INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons:
− Do not overheat the liquid.
− Stir the liquid both before and halfway through
heating it.
− Do not use straight-sided containers with narrow
necks.
− After heating, allow the container to stand in the
microwave oven for a short time before removing
the container.
− Use extreme care when inserting a spoon or other
utensil into the container.
SAVE THESE INSTRUCTIONS
2. Longer cord sets or extension cords are available and
may be used if care is exercised in their use.
3. If a long cord or extension cord is used:
(1). The marked electrical rating of the cord set or
extension cord should be at least as great as the
electrical rating of the appliance.
(2). The extension cord must be a grounding-type 3-wire
cord.
(3). The longer cord should be arranged so that it will
not drape over the counter top or tabletop where it
can be pulled on by children or tripped over
unintentionally.
7
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electric current. This appli-
ance is equipped with a cord having a grounding wire with a
grounding plug. The plug must be plugged into an outlet that
is properly installed and grounded.
WARNING - Improper use of the grounding can result in a risk
of electric shock. Consult a qualified electrician or serviceman
if the grounding instructions are not completely understood, or
if doubt exists as to whether the appliance is properly ground-
ed. If it is necessary to use an extension cord, use only a
3-wire extension cord that has a 3-blade grounded plug, and
3-slot receptacle that will accept the plug on the appliance.
The marked rating of the extension cord shall be equal to or
greater than the electrical rating of the appliance.
DANGER - Electric Shock Hazard
Touching some of the internal components can cause serious
personal injury or death. Do not disassemble this appliance.
WARNING - Electric Shock Hazard
Improper use of the grounding can result in electric shock. Do
not plug into an outlet until appliance is properly installed and
grounded.
1. A short power-supply cord is provided to reduce the risks
resulting from becoming entangled in or tripping over a
longer cord.
2. Longer cord sets or extension cords are available and
may be used if care is exercised in their use.
3. If a long cord or extension cord is used:
(1). The marked electrical rating of the cord set or
extension cord should be at least as great as the
electrical rating of the appliance.
(2). The extension cord must be a grounding-type 3-wire
cord.
(3). The longer cord should be arranged so that it will
not drape over the countertop or tabletop where it
can be pulled on by children or tripped over
unintentionally.
1. Operation of the microwave oven may cause interfer-
ence to your radio, TV or similar equipment.
2. When there is interference, it may be reduced or elimi-
nated by taking the following measures:
(1). Clean door and sealing surface of the oven.
(2). Reorient the receiving antenna of radio or television.
(3). Relocate the microwave oven with respect to the
receiver.
(4). Move the microwave oven away from the receiver.
(5). Plug the microwave oven into a different outlet so
that microwave oven and receiver are on different
branch circuits.
8
RADIO INTERFERENCE
Tightly-closed utensils could explode. Closed containers
should be opened and plastic pouches should be pierced
before cooking.
See the instructions on "Materials you can use in
microwave oven or to be avoided in microwave oven."
There may be certain non-metallic utensils that are not safe
to use for microwaving. If in doubt, you can test the utensil
in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water
(250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm,
do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
9
This device complies
with part 18 of the
FC C Rules.
NOTE KEEP THE CAVITY CLEAN
UTENSILS
Utensils Remarks
Follow manufacturer instructions. The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Follow manufacturer instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short term cooking/warming only. Do not leave oven unattended
while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision
for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Browning dish
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Dinnerware
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
10
MATERIALS YOU CAN USE IN MICROWAVE OVEN
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
F
G
A
C B
E
D
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Hub (underside)
Glass tray
Turntable ring assembly
a. Never place the
glass tray
upside down. The glass
tray should never be restricted.
b. Both
glass tray
and
turntable ring assembly
must
always be used during cooking.
c. All food and containers of food are always placed
on the
glass tray
for cooking.
d. If
glass tray
or
turntable ring assembly
cracks or
breaks, contact your nearest authorized service
center.
Turntable Installation
Turntable shaft
11
Installation
A minimum clearance of 3.0 inches
(7.5cm) is required between the oven and
any adjacent walls. One side must be open.
(1) Leave a minimum clearance of 12
inches (30cm) above the oven.
(2) Do not remove the legs from the
bottom of the oven.
(3) Blocking the intake and/or outlet openings
can damage the oven.
(4) Place the oven as far away from
radios and TV as possible.
Operation of microwave oven may
cause interference to your radio or TV
reception.
2. Plug your oven into a standard household
outlet. Be sure the voltage and the
frequency is the same as the voltage
and the frequency on the rating label.
WARNING: Do not install oven over a
range cooktop or other heat-producing
appliance. If installed near or over a heat
source, the oven could be damaged and
the warranty would be void.
3.0 inch(7.5cm)
3.0 inch(7.5cm)
12 inch(30cm)
OPEN
Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Countertop Installation
Cabinet: Remove any protective film found
on the microwave oven cabinet surface.
Do not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.
1.
Select a level surface that provides
enough open space for the intake
and/or outlet vents.
12
OPERATION
Control Panel and Features
(1) TIME COOK
(2) TIME DEFROST
(3) WEIGHT DEFROST
(4) POWER
(5) CLOCK
(6) KITCHEN TIMER
(7) AUTO MENU
(8) NUMBER KEYS
(9) STOP/CANCEL
(11) START/+30SEC.
(1)
(2)
(5)
(4)
(9)
(3)
(6)
(11)
(10)
(7)
(8)
(10) MEMORY
13
1. Power Level
11 power levels are available.
Level
Power
Display
10
100%
PL10
9
90%
PL9
8
80%
PL8
7
70%
PL7
6
60%
PL6
5
50%
PL5
4
40%
PL4
3
30%
PL3
2
20%
PL2
1
10%
PL1
2. CLOCK SETTING
(1) Press " CLOCK "once, "00:00" will display.
(2) Press the number keys and enter the current time. For example,
time is 12:10 now, please press " 1, 2, 1, 0" on the key pad.
(3) Press " CLOCK " to finish clock setting. ":" will flash and the clock will light up.
(4) If the numbers entered are not within the range of 1:00--12:59, the setting will be invalid
until valid numbers are input.
3. KITCHEN TIMER
(1) Press "KITCHEN TIMER " once, the screen will display 00:00.
(2) Press the number keys and enter the desired time. (The maximum cooking time is
99 minutes and 99 seconds.)
(3) Press "
START/+30SEC. " to confirm setting.
(4) When the desired time reaches the end, the buzzer will beep 5 times.
If the clock has been set (12-hour cycle), the screen will display the previously set clock
time.
Note: 1) The kitchen timer is not the same as clock.
2) Other functions will not be available to use at the same time with this mode.
4. MICROWAVE COOK
(2) Press number keys to enter the cooking time; the maximum cooking time is 99
minutes and 99 seconds.
0
0%
PL0
Note:
(1) In the process of clock setting, if the "
STOP/C " button is pressed or if
there is no operation within 1 minute, the microwave oven will go back to the previous
setting automatically.
(2) If the clock needs to be reset, please repeat step 1 to step 3.
(1) Press "
TIME COOK" once, the screen will display "00:00".
(3) Press " POWER " once, the screen will display "PL10". The default power level is 100%.
Now you can press number keys to adjust the power level.
(4) Press " START/+30SEC." to start cooking.
ANCEL
14
For Example: to cook the food with 50% microwave power for 15 minutes.
a. Press "TIME COOK" once. "00:00" displays.
b. Press "1", "5", "0", "0" in order.
c. Press "POWER" once, then press "5" to select 50% microwave power.
d. Press "START/+30SEC." to start cooking.
Note:
(1) In the process of setting, if the " STOP/CANCEL" button is pressed or if there is
no operation within 1 minute, the microwave oven will go back to the former setting
automatically.
(2) If "PL 0" selected, the oven will work with fan but no power. You can use this level to
eliminate odor from microwave oven's cavity.
(3) During microwave cooking, "POWER" can be pressed to change the power level to the
one you need.
After pressing "POWER",the current power will flash for 3 seconds, then you can press
number keys to change the power level. The microwave oven will work with the selected
power level for the rest of the set cooking time.
5. SPEEDY COOKING
(1) In a waiting state, press a number key between 1 and 6 for instant cooking at 100%
microwave power level.
(2) Press "START/+30SEC." to add cooking time for additional 30 seconds. The maximum
cooking time is 99 minutes and 99 seconds.
6. WEIGHT DEFROST FUNCTION
(1) Press " WEIGHT DEFROST "once, the screen will display "dEF1".
(2) Press number keys buttons to enter weight to be defrosted.
Input the weight ranged between 4~100 Oz.
(3) Press " START/+30SEC. " to start defrosting and the remaining cooking time will be
displayed.
15
8. POPCORN
a) Press " POPCORN " repeatedly until the weight you desire appears on the display,
"1.75", "3.0" ,"3.5" Oz will be the three options displayed in this order.
For example, press "POPCORN" once, "1.75" will appear.
b) Press " START/+30 SEC. " to start cooking. The buzzer will beep once. When it reaches
the end of the cooking time, the buzzer will beep 5 times to remind you and then go back
to standby mode.
9. POTATO
a) Press " POTATO " repeatedly until the number you desire appears on the display,
"1", "2", "3" will be the three options displayed in this order.
"1" SET : 1 potato (about 8 Oz)
"2" SETS: 2 potatoes (about 16 Oz)
"3" SETS: 3 potatoes (about 24 Oz)
For example, press "POTATO" once, "1" appears.
b) Press " START/+30 SEC. "to start cooking. The buzzer will beep once. When it reaches
the end of the cooking time, the buzzer will beep 5 times to remind you and then go back
to standby mode.
10. FROZEN VEGETABLE
a) Press " FROZEN VEGETABLE " repeatedly until the weight you desire appears on the
display, "4.0", "8.0", "16.0" Oz will be the three options displayed in this order.
For example, press "FROZEN VEGETABLE" once, "4.0" will appear.
b) Press " START/+30 SEC. " to start cooking. The buzzer will beep once. When it reaches
the end of the cooking time, the buzzer will beep 5 times to remind you and then go back
to standby mode.
11. BEVERAGE
a) Press " BEVERAGE " repeatedly until the number you desire appears on the
display, "1", "2", "3" cups will be the three options displayed in this order. One cup is about
4.0 Oz. For example, press "BEVERAGE" once, "1" appears.
b) Press " START/+30 SEC. " to start cooking. The buzzer will beep once. When it reaches
the end of the cooking time, the buzzer will beep 5 times to remind you and then go back
to standby mode.
7. TIME DEFROST FUNCTION
(1) Press " TIME DEFROST " once, the screen will display "dEF2".
(2) Press number key pads to enter defrosting time. The effective time range is 0:01~99:99
minutes.
(3) The default microwave power level is 3 or 30%. If you want to change the power level,
press " POWER " once, and the screen will display "PL 3", then press the number key
pad of the power level you desire.
(4) Press " START/+30SEC. " to start defrosting. The remaining cooking time will be
displayed.
16
12. DINNER PLATE
a) Press " DINNER PLATE " repeatedly until the weight you desire appears in the
display, "9.0", "12.0", "18.0" Oz will be the three options displayed in this order.
For example, press "DINNER PLATE" once, " 9.0" appears.
b) Press " START/+30 SEC. " to start cooking. The buzzer will beep once. When it reaches
the end of the cooking time, the buzzer will beep 5 times to remind you and then go back
to standby mode.
13. PIZZA
a) Press " PIZZA " repeatedly until the weight you desire appears on the display,
"4.0", "8.0", "14.0" Oz will be the three options displayed in this order.
For example, press " PIZZA" once, "4.0" appears.
b) Press " START/+30 SEC. " to start cooking. The buzzer will beep once. When it reaches
the end of the cooking time, the buzzer will beep 5 times to remind you and then go back
to standby mode.
14. MEMORY FUNCTION
(1) Press "0/MEMORY" to choose memory 1-3 function. The screen will display 1, 2, 3.
(2) If the function has been set, press " START/ +30 SEC." to start cooking. If not, continue to
set the function. Only one or two stages can be set.
(3) After finishing the setup, press "START/ +30 SEC." once to save the procedure.
If " START/ +30 SEC." is pressed again, it will start cooking.
For example: To set the following function as the second memory, that is memory 2.
To cook the food at 80% microwave power level for 3 minutes and 20 seconds, follow
these steps:
a. In a standby mode, press "0/MEMORY" twice, until the screen displays "2".
b.Press "TIME COOK" once, then press "3", "2", "0".
c. Press "POWER" once, "PL10" will display, then press "8" and "PL8" will display.
d. Press "START/ +30 SEC." to save the setting. Buzzer will beep once and the screen will
display "2". If you press "START/+30SEC." again, the function will be saved as the
memory 2.
e. The function will be saved for the future cooking. If power loss is experienced, it will need
to be re-entered.
f. If you want to run the saved function, in a standby mode, press "0/MEMORY" twice,
screen will display "2", then press "START/+30SEC." start cooking.
17
15. MULTI-STAGE COOKING
Up to 2 stages can be set for cooking. In multi-stage cooking, if one stage is
defrosting, then defrosting will be placed as the first stage automatically.
Note: Auto cooking cannot be selected for multi-stage cooking.
For example: if you want to cook with 80% microwave power for 5 minutes and 60%
microwave power for 10 minutes, here are the setup steps:
(1) Press "TIME COOK" once, then press "5", "0", "0" to set the cooking time;
(2) Press "POWER" once, then press "8" to select 80% oven power level..
(3) Press "TIME COOK" once, then press "1", "0", "0", "0" to set the second cooking time;
(4) Press "POWER" once, then press "6" to select 60% as the second microwave oven power
level.
(5) Press "START/ +30 SEC." to start cooking.
16. CHILD LOCK FUNCTION
Lock: In standby mode, press " STOP/CANCEL " for 3 seconds, there will be a long "beep"
denoting the entering into the children-lock state; meanwhile, screen will display " ".
Unlock: While in locked mode, press "STOP/CANCEL" for 3 seconds, there will be a long
beep indicating that unit is unlocked.
17. INQUIRING FUNCTION
(1) In cooking mode, press " CLOCK ", the microwave oven will display clock for three
seconds.
(2) In the microwave cooking mode, press " POWER " to check microwave power level. After
three seconds, the microwave oven will go back to stand by mode. In multi-stage mode,
power level can be checked the same way.
18. BUZZER BEEP FUNCTION
When cooking timer ends, the buzzer will beep 5 times to remind you.
19. OTHER SPECIFICATIONS
(1) In standby mode, the set clock time will have ":" flash. Otherwise, it will display "0:00".
(2) In a setting mode, the screen displays corresponding setting.
(3) In cooking or pause mode, the screen displays cooking time.
18
Troubleshooting
Check your problem by using the chart below and try the solutions for each problem. If the
microwave oven still does not work properly, contact the nearest authorized service center.
TROUBLE
Oven will not start
POSSIBLE CAUSE POSSIBLE REMEDY
a. Electrical cord for oven is
not plugged in.
b. Door is open.
c. Wrong operation is set.
a. Plug into the outlet.
b. Close the door and try
again.
c. Check instructions.
Arcing or sparking
a. Materials to be avoided in
microwave oven were
used.
b. The oven is operated when
empty.
c. Spilled food remains in the
cavity.
a. Use microwave-safe
cookware only.
b. Do not operate with oven
empty.
c. Clean cavity with wet towel.
Unevenly cooked
foods
a. Materials to be avoided in
microwave oven were
used.
b. Food is not defrosted
completely.
c. Cooking time, power level
is not suit ble.
d. Food is not turned or stirred.
a. Use microwave-safe
cookware only.
b. Completely defrost food.
c. Use correct cooking time,
power level.
d. Turn or stir food.
Overcooked foods
Cooking time, power level is
not suitable.
Use correct cooking time,
power level.
Undercooked foods
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted
completely.
c. Oven ventilation ports are
restricted.
d. Cooking time, power level is
not suitable.
a. Use microwave-safe
cookware only.
b. Completely defrost food.
c. Check to see that oven venti-
lation ports are not restricted.
d. Use correct cooking time,
power level.
Improper defrosting
a. Materials to be avoided in
microwave oven were used.
b. Cooking time, power level is
not suitable.
c. Food is not turned or stirred.
a. Use microwave-safe
cookware only.
b. Use correct cooking time,
power level.
c. Turn or stir food.
MAINTENANCE
a
19
ONE YEAR LIMITED WARRANTY
This product carries a warranty stating that it will be free from defects in material and
workmanship for a period of one year from the date of purchase. This warranty is valid
for the original retail purchaser from the date of initial retail purchase and is not
transferable. Keep your original sales receipt.
IMPORTANT:
If service is required during the warranty period, properly pack your unit. We
If additional assistance is needed, please contact
recommend using the original carton and packing materials.
customer assistance at:
Some states do not allow this exclusion
quential losses so the foregoing disclaimer may not
rights which may vary from state to state.
SAVE THIS FOR YOUR RECORDS
Made in China
apply to you. This warranty gives you specific legal rights, and you may also have other
expressly disclaims all responsibility for consequential damages or Midea America Corp
incidental losses caused by use of the appliance.
or limitation of incidental or conse
The serial number can be found on the back cabinet. We suggest that you record the
serial number of your unit in the space below for future reference
Model Number:_______________________
Serial Number:________________________
1-866-646-4332
.
1. This warranty does not cover damages resulting from accident, misuse or abuse,
lack of reasonable care, the affixing of any attachments not provided with the
product, loss of parts, or subjecting the appliance to any but the specified
voltage. ( Read directions carefully. )
2. This warranty is void if this product is ever used for other than private household
purposes.
3. This warranty is void if this product is ever used outside of United State .
s
20
Product registration is not mandatory. Failure to complete and return the card or form does
not diminish the consumer' s warranty rights.
PN:16170000A85921
