1 Programme selector
2 “Start/Pause” button
3 “Reset/Drain” button
4 “Start delay” button
5 “Spin speed” button
6 Time indication
7 Washing phase
INDICATORS
Door locked
Failure: Call Service
Failure: Water lter clogged
Failure: No water
In the event of any failure, refer to the
“TROUBLESHOOTING” section
THANK YOU FOR BUYING A HOTPOINT PRODUCT.
In order to receive a more complete assistance,
please register your product on
www.hotpoint.eu/register
CONTROL PANEL
PROGRAMME CHART
PRODUCT DESCRIPTION
1. Lid handle
2. Lid
3. Control panel
4. Detergent dispenser
5. Drum
6. Water lter - behind the cover
7. Mobility lever (depending on model)
8. Adjustable feet (x2)
5.
1.
6.
7.
2.
3.
4.
8.
DETERGENT DISPENSER
Main wash compartment
Detergent for the main wash, stain remover or
water softener.
Prewash compartment
Detergent for the prewash.
Softener compartment
Fabric softener. Liquid starch. Bleach.
Pour in softener, starch or bleach solution
only up to the “max” mark.
Release button
Press to remove tray for cleaning.
Max load 7,0 Kg
Power consumption in o-mode 0,11 W / in left-on mode 0,11 W
Detergents and additives
Recommended
detergent
Residual
dampness % *
Energy
consumption
kWh
Total water lt
Laundry
temperature °C
Programme
Temperatures
Max, spin
speed
(rpm)
Max
load
(kg)
Duration
(h : m)
Prewash
Main
wash
Softener
Powder Liquid
Setting Range
Cotton 60°C 40 - 90°C 1200 7,0 3:00
64 1,33 52 55
Synthetics 40°C 40 - 60°C 1200 3,0 1:50
40 0,56 50 40
Anti stain 20°C 20°C 1200 4,0 ** –
– – – –
Mini 30°C 30°C 1200 1,0 ** –
–
– – – –
Delicates 30°C 30°C 1000 1,5 **
–
– – – –
Wool 40°C 40°C 1000 1,0 ** –
–
– – – –
Baby 60°C 60°C 1000 4,0 **
–
– – – –
Mix 15’ 30°C 30°C 1200 3,0 0:15 –
57 0,15 30 21
Mix 30’ 30°C 30°C 1200 3,0 ** –
– – – –
Mix 60’ 40°C 40°C 1200 3,0 ** –
– – – –
Jeans 40°C 40°C 1000 4,0 **
–
– – – –
Eco 40–60 40°C 40°C
1151 7,0 3:25 –
62 1,23 57 45
1151 3,5 2:40 –
62 0,57 41 36
1151 2,0 1:50 –
62 0,35 32 31
20°C 20°C 20°C 1200 7,0 2:45 –
–
62 0,27 48 20
Rinse & Spin – – 1200 7,0 ** – –
– – – – – –
Spin – – 1200 7,0 ** – – – – – – – – –
Drain – – – – – – – – – – – – – –
Eco Cotton 60°C
60°C 1200
7,0 4:00 –
62 0,90 48 –
3,5 2:50 –
62 0,75 34 –
40°C 1200 3,5 2:30 –
62 0,65 34 –
Dosing required Dosing optional
EN
Quick guide
Before using the appliance carefully read the Safety Instruction.
Before using the machine, it is imperative that the transport bracket is removed.
For more detailed instructions on how to remove it, see the Installation Guide.
1 2 43 5
7 6
This data may dier in your home due to changing conditions in inlet water temperature,
water pressure etc. Approximate programme duration values refer to the default setting of
the programmes, without options. The values given for programmes other than the eco 40-
60 programme are indicative only.
* After programme end and spinning with maximum selectable spin speed, in default
programme setting.
** The duration of the programme is shown on the display.
The sensor technology adapts water, energy and programme duration to your wash load.
Eco cotton - Test wash cycles in compliance with regulations 1061/2010. Set “Cotton 40 °C” or
“Cotton 60°C” wash cycle together with “Energy saver” option to access this cycles.
Eco 40-60 - Test wash cycle in compliance with 2019/2014 regulation. The most ecient
programme in terms of energy and water consumption for washing normally soiled cotton
laundry. Display only: Spin speed values shown on the display can slightly diers from the
values stated in the table
For all Test Institutes
Long wash cycle for cottons: set wash cycle Cotton with a temperature of 40°C.
Synthetic program along: set wash cycle Synthetics with a temperature of 40°C.
